ProdEq Trading GmbH

Condition: used, Year of construction: 2007, turning length: 600 mm, turning diameter: 140 mm, spindle speed (max.): 5,000 rpm, spindle speed (min.): 1 rpm, travel distance X-axis: 110 mm, travel distance Y-axis: 70 mm, travel distance Z-axis: 360 mm, total height: 2,810 mm, overall weight: 6,500 kg, bar passage: 65 mm, bar diameter: 65 mm, controller manufacturer: SIEMENS, controller model: 840 D POWER LINE, number of spindles: 2, space requirement length: 6,100 mm, space requirement width: 1,690 mm, CONTROLS .. CNC controls SIEMENS 840 D POWER LINE BASIC FUNCTIONS .. number of spindles: 2 .. number of turrets: 3 .. live positions: yes .. number of c-axes: 2 .. number of y-axes: 3 .. number of b-axes: 3 WORKING RANGE TURNING .. turning diameter (max): 140 mm .. bar diameter (max): 65 mm .. worpiece length max.: 600 mm MAIN SPINDLE .. spindle revolutions (min): 1 /min .. spindle revolutions (max): 5000 /min COUNTER SPINDLE .. spindle revolutions (min): 1 /min .. spindle revolutions (max): 5000 /min .. Z-axis travel: 600 mm Drg7Wf X/Z SLIDE .. Z-axis travel: 360 mm .. X-axis travel: 110 mm .. Y-axis travel: 70 mm .. rotating range B-axis up to: 1 ° .. rapid traverse Z: 45 mm/min .. rapid traverse X: 25 mm/min .. rapid traverse Y: 12 mm/min .. number of tool positions (total): 36 .. number of live positions: 36 .. - rotation speeds (max): 6000 /min ELECTRICAL SPECIFICATIONS .. mains power supply: 72 kVA .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 6100 mm .. space requirements -front/back-: 1690 mm .. total height: 2810 mm .. total weight approx.: 6500 kg ATTACHMENTS (TURNING) .. chip conveyor: yes .. through spindle coolant attachment: yes .. European CE standards: yes Including bar loader, Profimat 65.8*270/8 year 2005 loading length 500-3000mm. Spindeleinsatzrohren 16,25,30,40,45,55,60,65mm (multi-channel loading magazine) Including chip conveyor Chucks and tools are not included in the scope of delivery.

Year of construction: 2017, Condition: good (used), Endogas generator (endothermic protective or reaction gas) Generation capacity 24 - 60 m3/h H2/CO/N2 mixture Operating temperature 1000 °C Regeneration temperature 870 °C Electrical heating Gas consumption (input) Natural gas 13.8 m3/h Propane 9.6 kg/h Nitrogen 2 m3/h Electrical connection 27 kVA Drgyqh IPSEN EndoSave control system

Year of construction: 2020, Condition: good (used), controller manufacturer: SIEMENS, controller model: 840 D SL, CONTROLS .. CNC controls SIEMENS 840 D SL Microfinishing machine type Microstar 284 in vertical design with 8 workpiece holders and 4 microfinishing units for machining slide and counter ring grinding. - 6500 houers Workpiece spindles: 8 pieces B8Zbyyc3Yc Speed max 2000 rpm Number of finishing units 4 pieces max. speed 10'000 rpm max workpiece length 160 mm Loading height 1200 mm

Condition: used, Year of construction: 2019, travel distance X-axis: 2,200 mm, travel distance Y-axis: 2,200 mm, travel distance Z-axis: 1,610 mm, controller manufacturer: HEIDENHAIN, controller model: TNC 640, total height: 4,800 mm, table length: 1,400 mm, overall weight: 52,000 kg, spindle speed (max.): 15,000 rpm, space requirement length: 20,000 mm, space requirement width: 11,000 mm, CONTROLS .. CNC controls HEIDENHAIN TNC 640 WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 5 .. X-axis travel: 2200 mm .. Y-axis travel: 2200 mm .. Z-axis travel: 1610 mm .. rotating range A-axis from: 0 ° .. rotating range A-axis up to: 90 ° .. rotating range C-axis up to: 360 ° TABLE .. table surface (left-right): 1400 mm .. clamping surface diameter: 1800 mm SPINDLE / HEAD .. spindle revolutions (max): 15000 /min .. drive power S6 40%: 73 kW .. drive power S1 100%: 63 kW .. tool fixture: HSK A100 TOOL MAGAZINE .. number of positions: 304 AUTOMATIC WORKLOAD EQUIPMENT .. store type: pallet changer .. number of store positions: 4 .. workpiece diameter min: 2250 mm .. worpiece length max.: 1800 mm .. workpiece load (max): 4000 kg .. pallet length: 1800 mm .. pallet width: 1400 mm .. number of pallets: 4 ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 20000 mm .. space requirements -front/back-: 11000 mm .. total height: 4800 mm .. total weight approx.: 52000 kg ATTACHMENTS .. chip conveyor: yes .. coolant unit: yes .. band filtration unit: yes .. European CE standards: yes Drgep7 Operating hours: 33'000h upgraded for changing oversized tools up to Ø 520 x500 mm Enlarged swivel diameter for workpiece sizes up to Ø 3,100 mm Accessories - 4-fold palletizing system - Arno 3VF oil and emulsion mist separator - Internal coolant supply with paper belt filter with 2500 l tank - 3 longitudinally arranged apron chip conveyors - 1 transversely arranged apron chip conveyor

Condition: good (used), Year of construction: 2015, total height: 2,450 mm, space requirement length: 2,700 mm, space requirement width: 3,300 mm, power: 98 kW (133.24 HP), CONTROLS .. electronic controls DIMENSIONS / WEIGHTS B7Ww0Amlhk .. space requirements -left/right-: 2700 mm .. space requirements -front/back-: 3300 mm .. total height: 2450 mm ELECTRICAL SPECIFICATIONS .. total power consumption: 98 kW .. mains voltage: 400 V .. mains frequency: 50 Hz

Condition: used, Year of construction: 2000, travel distance X-axis: 180 mm, travel distance Y-axis: 215 mm, travel distance Z-axis: 1,250 mm, overall weight: 6,600 kg, controller manufacturer: SIEMENS, controller model: 840 C, number of spindles: 2, CONTROLS .. CNC controls SIEMENS 840 C BASIC FUNCTIONS Drfy9F .. number of spindles: 2 .. number of turrets: 2 .. live positions: yes .. number of c-axes: 2 X/Z SLIDE .. Z-axis travel: 1250 mm .. X-axis travel: 180 mm .. Y-axis travel: 215 mm .. number of tool positions (total): 12 X/Z SLIDE .. Z-axis travel: 1250 mm .. X-axis travel: 140 mm ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. total weight approx.: 6600 kg

Condition: used, Year of construction: 2000, turning length: 1,250 mm, travel distance X-axis: 215 mm, travel distance Y-axis: 180 mm, travel distance Z-axis: 1,250 mm, total height: 2,150 mm, controller manufacturer: INDEX, controller model: C200-4, number of spindles: 2, space requirement length: 5,300 mm, CONTROLS .. CNC controls INDEX C200-4 BASIC FUNCTIONS .. design principle: inclined bed .. number of spindles: 2 .. number of x/z slides: 2 .. number of turrets: 2 .. live positions: yes .. number of c-axes: 2 WORKING RANGE TURNING .. worpiece length max.: 1250 mm B7Wv3Gwyxa MAIN SPINDLE .. drive power S6 40%: 43 kW .. drive power S1 100%: 57 kW COUNTER SPINDLE .. drive power S6 40%: 28 kW .. drive power S1 100%: 40 kW .. spindle torque S6 40%: 178 Nm .. spindle torque S1 100%: 255 Nm .. c-axis: yes X/Z SLIDE .. Z-axis travel: 1250 mm .. X-axis travel: 215 mm .. Y-axis travel: 180 mm .. number of tool positions (total): 12 X/Z SLIDE .. Z-axis travel: 1250 mm .. X-axis travel: 140 mm .. tool fixture: Turret .. number of tool positions (total): 12 DIMENSIONS / WEIGHTS .. space requirements -left/right-: 5300 mm .. total height: 2150 mm ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz

Condition: excellent (used), Year of construction: 2020, total height: 2,100 mm, space requirement width: 1,250 mm, space requirement length: 1,500 mm, CONTROLS .. electronic controls ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 1500 mm .. space requirements -front/back-: 1250 mm .. total height: 2100 mm - Polishing cell C710 (1970 houres in production) Equipment of the machine: Collaborative UR3 e-series robot with intuitive HMI Automatic compensation for tool wear Polishing station Crevoisier C5100 (drive polishing tools) Drfy82 Spindle for holding standard Crevoisier collets Integrated suction with 14m/s Renishaw measuring probe for position detection Palletizing for approx. 40 STK 2 Pal. Two polishing paste dispensers with a capacity of three liters each

Condition: used, Year of construction: 2002, travel distance X-axis: 270 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 250 mm, controller manufacturer: HEIDENHAIN, total height: 2,200 mm, overall weight: 2,800 kg, spindle speed (max.): 40,000 rpm, spindle motor power: 10 W, space requirement length: 2,300 mm, space requirement width: 2,200 mm, CONTROLS .. CNC controls HEIDENHAIN WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 5 .. X-axis travel: 270 mm .. Y-axis travel: 250 mm .. Z-axis travel: 250 mm SPINDLE / HEAD B230Nge2Jy .. spindle revolutions (min): 10 /min .. spindle revolutions (max): 40000 /min .. drive power: 10 kW TOOL MAGAZINE .. number of positions: 60 AUTOMATIC WORKLOAD EQUIPMENT .. number of store positions: 24 DIMENSIONS / WEIGHTS .. space requirements -left/right-: 2300 mm .. space requirements -front/back-: 2200 mm .. total height: 2200 mm .. total weight approx.: 2800 kg

Condition: used, Year of construction: 2005, turning length: 380 mm, turning diameter: 400 mm, spindle speed (min.): 60 rpm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 160 mm, travel distance Y-axis: 60 mm, travel distance Z-axis: 380 mm, bar passage: 45 mm, total height: 1,950 mm, bar diameter: 45 mm, overall weight: 8,500 kg, controller manufacturer: FANUC, controller model: 18 ITB, machining diameter: 400 mm, number of spindles: 2, space requirement length: 3,650 mm, space requirement width: 1,820 mm, CONTROLS .. CNC controls FANUC 18 ITB BASIC FUNCTIONS .. number of spindles: 2 .. number of turrets: 1 .. live positions: yes .. number of c-axes: 1 .. number of y-axes: 1 .. number of b-axes: 1 WORKING RANGE TURNING .. swing diameter (max): 400 mm .. turning diameter (max): 220 mm .. bar diameter (max): 45 mm .. worpiece length max.: 380 mm MAIN SPINDLE .. spindle revolutions (min): 60 /min .. spindle revolutions (max): 5000 /min COUNTER SPINDLE .. drive power: 15 kW X/Z SLIDE B22Jbvngjg .. Z-axis travel: 380 mm .. X-axis travel: 160 mm .. Y-axis travel: 60 mm ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 3650 mm .. space requirements -front/back-: 1820 mm .. total height: 1950 mm .. total weight approx.: 8500 kg - Good condition, few operating hours - Operating hours: 47,000h - LNS bar loader (optional)

Condition: used, Year of construction: 2008, laser power: 4,400 W, sheet thickness steel (max.): 25 mm, overall weight: 11,000 kg, power: 63 kW (85.66 HP), sheet thickness (max.): 25 mm, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, controller manufacturer: BYSOFT, CONTROLS .. conventional BYSOFT WORKING RANGE -CUTTING MACHINE- .. laser capacity: 4400 W .. number of processing axes (excl parallel axes): 3 .. X-axis travel: 3000 mm .. Y-axis travel: 1500 mm .. z-axis travel (vertical): 170 mm .. sheet thickness max. St37: 25 mm .. sheet thickness max. (V2A): 20 mm .. sheet thickness max. (alumina): 12 mm .. workpiece load (max): 890 kg ELECTRICAL SPECIFICATIONS .. total power consumption: 63 kW .. mains power supply: 70 kVA .. mains voltage: 400 V B20Iosz8Oi .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. total weight approx.: 11000 kg

Condition: excellent (used), Year of construction: 2019, controller manufacturer: SIEMENS, controller model: 840 D SL, power: 210 kW (285.52 HP), overall weight: 23,000 kg, CONTROLS .. CNC controls SIEMENS 840 D SL DIMENSIONS / WEIGHTS .. total weight approx.: 23000 kg ELECTRICAL SPECIFICATIONS .. total power consumption: 210 kW Dre7Rb .. mains voltage: 400 V .. mains frequency: 50 Hz

Condition: good (used), Year of construction: 2003, grinding length: 400 mm, grinding diameter: 200 mm, controller manufacturer: SIEMENS, controller model: SINUMERIK 840 D, CONTROLS .. CNC controls SIEMENS SINUMERIK 840 D B2Czz7Jxsm WORKING RANGE EXTERNAL GRINDING .. grinding diameter (max): 200 mm .. grinding length: 400 mm GRINDING TOOL .. type of grinding tool: wheel .. diameter (max): 500 mm ELECTRICAL SPECIFICATIONS .. mains power supply: 45 kVA .. mains voltage: 400 V .. mains frequency: 50 Hz Equipment: - Automatic workpiece loading - Dresser diamond disc - Marpo's measuring station

Condition: used, Year of construction: 2004, turning length: 850 mm, turning diameter: 600 mm, spindle speed (max.): 4,500 rpm, total height: 2,500 mm, overall weight: 11,000 kg, bar passage: 82 mm, bar diameter: 82 mm, controller manufacturer: SIEMENS, controller model: SINUMERIK 840 D, machining diameter: 600 mm, number of spindles: 2, space requirement length: 6,000 mm, space requirement width: 2,300 mm, CONTROLS .. CNC controls SIEMENS SINUMERIK 840 D BASIC FUNCTIONS .. number of spindles: 2 .. number of x/z slides: 2 .. number of turrets: 2 .. live positions: yes .. number of c-axes: 2 WORKING RANGE TURNING .. swing diameter (max): 600 mm .. turning diameter (max): 290 mm .. bar diameter (max): 82 mm Dre30H .. worpiece length max.: 850 mm MAIN SPINDLE .. spindle revolutions (max): 4500 /min .. spindle bore diameter: 65 mm .. c-axis: optional COUNTER SPINDLE .. spindle revolutions (max): 4500 /min .. c-axis: yes X/Z SLIDE .. tool fixture: Turret ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 6000 mm .. space requirements -front/back-: 2300 mm .. total height: 2500 mm .. total weight approx.: 11000 kg

Condition: used, Year of construction: 2012, travel distance X-axis: 830 mm, travel distance Z-axis: 180 mm, spindle speed (max.): 4,500 rpm, turning diameter: 150 mm, total height: 3,000 mm, overall weight: 15,000 kg, controller manufacturer: SIEMENS, controller model: SINUMERIK 840 DSL, number of spindles: 2, space requirement length: 4,300 mm, space requirement width: 2,550 mm, CONTROLS .. CNC controls SIEMENS SINUMERIK 840 DSL BASIC FUNCTIONS .. number of spindles: 2 .. number of turrets: 2 WORKING RANGE TURNING .. turning diameter (max): 150 mm MAIN SPINDLE .. spindle revolutions (max): 4500 /min X/Z SLIDE .. Z-axis travel: 180 mm .. X-axis travel: 830 mm .. traverse velocity Z (max): 3000 mm/min .. traverse velocity X (max): 60000 mm/min .. number of tool positions (total): 12 B2Bacfp29A ELECTRICAL SPECIFICATIONS .. mains voltage: 24 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 4300 mm .. space requirements -front/back-: 2550 mm .. total height: 3000 mm .. total weight approx.: 15000 kg ATTACHMENTS (TURNING) .. chip conveyor: yes .. band filtration unit: yes .. coolant through turret: yes .. through spindle coolant attachment: yes .. hydraulic system: yes .. European CE standards: yes Technology: Double spindle vertical turning center - 2 x main spindle (left + right) - max. chuck Ø 215mm - Knoll chip conveyor - Machine-centered feed belt with robot gripper

Condition: used, Year of construction: 2005, coil weight: 15,000 kg, coil outer diameter: 1,800 mm, coil width: 1,000 mm, load capacity: 15,000 kg, material width: 1,000 mm, CONTROLS B03Cvsrd0G .. electronic controls DECOILER .. design: single reel .. sheet width max.: 1000 mm .. coil weight max.: 15 to .. max. diameter of coil: 1800 mm .. mandrel expansion range from: 480 mm .. mandrel expansion range up to: 540 mm

Year of construction: 2002, Condition: used, power: 230 kW (312.71 HP), heating capacity: 225 kW (305.91 HP), temperature: 1,000 °C, usable height: 50 mm, usable length: 5,750 mm, usable width: 650 mm, CHARACTERISTICS HEAT TREATMENT EQUIPMENT .. operation modus: continuous .. heating method: gas+electric .. Heating capacity: 225 kW .. temperature max.: 1000 °C HEAT TREATMENT COMPARTMENT / ZONE .. length: 5750 mm .. width: 650 mm .. Height: 50 mm ELECTRICAL SPECIFICATIONS .. total power consumption: 230 kW .. mains voltage: 400 V .. mains frequency: 50 Hz Dre0Sb Application: Production of friction linings for clutches Sintering of steel, copper and brass powder materials onto non-ferrous metal/steel sheet Cooling in an oxidation-free atmosphere Complete system with powder application, furnace, cooling section, cleaning Design: Continuous furnace with belt conveyor with heating and cooling section Natural gas and electric heating Heating temperature contro zones 6 Fuel gas (natural gas) approx. 5 Nm3/h Purge gas N2 approx. 30 Nm3/h Process gas H2/N2 60/40% approx. 40 Nm3/h Electrical heating Zone 1: 2 x 27.5 kW Zone 2: 2 x 27.5 kW Zone 3: 2 x 27.5 kW Zone 4: 55 kW Zone 5: 5 kW

Condition: used, Year of construction: 2001, power: 120 kW (163.15 HP), pressing force: 175 t, installation height: 500 mm, ram stroke: 300 mm, controller manufacturer: SIEMENS, lifting height: 300 mm, worktable length: 1,500 mm, table length: 1,500 mm, table width: 810 mm, tool height: 500 mm, CONTROLS .. SIEMENS PRESS DESIGN .. drive system: hydraulic .. frame design: H-frame, monoblock .. openings in uprights: yes .. number of suspensions: 3 PRESS FORCES .. total force (nominal): 175 to PRESS TABLE .. table surface (left-right): 1500 mm .. table surface (front-back): 810 mm SLIDE .. slide force: 25 to .. table surface (left-right): 480 mm .. table surface (front-back): 480 mm .. stroke: 300 mm SLIDE EJECTOR / CUSHION .. stroke: 100 mm DIE CUSHION (TABLE CUSHION) .. cushion force: 2 to .. stroke: 40 mm EJECTOR (TABLE EJECTOR) .. nominal force: 0.2 to .. stroke: 40 mm SLIDE .. slide force: 25 to .. table surface (left-right): 480 mm .. table surface (front-back): 480 mm .. stroke: 300 mm B03Bxy2Rj3 SLIDE EJECTOR / CUSHION .. stroke: 100 mm DIE CUSHION (TABLE CUSHION) .. cushion force: 10 to .. stroke: 100 mm EJECTOR (TABLE EJECTOR) .. nominal force: 0.2 to .. stroke: 40 mm TOOL ASSEMBLY DIMENSIONS .. shut height (stroke down, adjustment up), BDC: 500 mm .. distance between columns (H-frame): 1550 mm .. passline opening (free passage in side columns): 700 mm .. free passage between side columns (height): 640 mm SLIDE .. slide force: 125 to .. table surface (left-right): 480 mm .. table surface (front-back): 480 mm .. stroke: 300 mm SLIDE EJECTOR / CUSHION .. stroke: 100 mm DIE CUSHION (TABLE CUSHION) .. cushion force: 2 to .. stroke: 40 mm EJECTOR (TABLE EJECTOR) .. nominal force: 0.2 to TRANSFER SYSTEM .. number of tool stations: 3 .. distance between tools, stroke X max.: 500 mm .. distance between tools, stroke X min.: 0 mm .. stroke Y max.: 80 mm .. stroke Y min.: 0 mm .. stroke Z max.: 30 mm .. stroke Z min.: 0 mm .. distance press table - transfer rail min.: 168.5 mm ELECTRICAL SPECIFICATIONS .. total power consumption: 120 kW .. mains voltage: 400 V .. mains frequency: 50 Hz ATTACHMENTS (PRESSES) .. gripper transfer system: yes Hydraulic 3-slide press with transfer device Defects: Crack in the upright, without affecting the current application, monitored by press force monitoring system

Year of construction: 2009, Condition: used, controller manufacturer: SIEMENS, controller model: S7 300, temperature: 1,140 °C, usable height: 15 mm, usable length: 3,636 mm, usable width: 300 mm, CONTROLS .. PLC SIEMENS S7 300 Dre0Rx CHARACTERISTICS HEAT TREATMENT EQUIPMENT .. temperature max.: 1140 °C HEAT TREATMENT COMPARTMENT / ZONE .. length: 3636 mm .. width: 300 mm .. Height: 15 mm ELECTRICAL SPECIFICATIONS .. mains power supply: 173 kVA Application: Production of friction linings for clutches Sintering of steel, copper and brass powder materials onto non-ferrous metal/steel sheet Cooling in an oxidation-free atmosphere Use for small series or pilot plant Design: Continuous furnace with belt conveyor with heating and cooling section Fuel gas: Natural gas Forming gas: H2, N2 Inert/protective gases: N2, argon

Condition: used, Year of construction: 2013, travel distance X-axis: 1,200 mm, travel distance Y-axis: 950 mm, travel distance Z-axis: 1,200 mm, total height: 4,150 mm, table width: 630 mm, table length: 630 mm, overall weight: 25,000 kg, spindle speed (max.): 6,000 rpm, spindle motor power: 50 W, spindle diameter: 100 mm, space requirement length: 8,100 mm, space requirement width: 5,350 mm, WORKING RANGE -CUBIC- B0Advrqh73 .. number of processing axes (excl parallel axes): 4 .. X-axis travel: 1200 mm .. Y-axis travel: 950 mm .. Z-axis travel: 1200 mm .. rotating range B-axis up to: 360 ° TABLE .. table surface (left-right): 630 mm .. table surface (front-back): 630 mm .. workpiece load (max): 1500 kg .. rotation axis: B .. - mode of operation: automatic .. - positioning/indexing: 0.001 ° .. spindle revolutions (max): 70 /min .. spindle torque: 8000 Nm SPINDLE / HEAD .. spindle type: horizontal .. spindle revolutions (max): 6000 /min .. tool fixture: HSK A100 .. drive power: 50 kW .. spindle torque: 1210 Nm .. spindle diameter: 100 mm AXIS DRIVES .. feed velocity (max): 60000 mm/min TOOL MAGAZINE .. magazin type: chain magazine .. number of positions: 80 .. tool diameter max.: 125 mm .. - with free neighbour positions: 325 mm .. tool length max.: 800 mm .. tool weight max.: 35 kg AUTOMATIC WORKLOAD EQUIPMENT .. store type: pallet changer .. number of store positions: 2 .. workpiece height (max): 1200 mm .. pallet length: 630 mm .. pallet width: 630 mm ELECTRICAL SPECIFICATIONS .. mains power supply: 90 kVA DIMENSIONS / WEIGHTS .. space requirements -left/right-: 8100 mm .. space requirements -front/back-: 5350 mm .. total height: 4150 mm .. total weight approx.: 25000 kg Extensive clamping material included

Condition: used, Year of construction: 2006, travel distance X-axis: 1,040 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, controller manufacturer: HEIDENHAIN, controller model: TNC 530, total height: 2,500 mm, table length: 1,250 mm, overall weight: 9,940 kg, spindle speed (max.): 12,000 rpm, spindle motor power: 40 W, space requirement length: 2,650 mm, space requirement width: 2,700 mm, CONTROLS .. CNC controls HEIDENHAIN TNC 530 WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 3 .. X-axis travel: 1040 mm .. Y-axis travel: 600 mm .. Z-axis travel: 500 mm TABLE .. table surface (left-right): 1250 mm SPINDLE / HEAD .. spindle revolutions (max): 12000 /min .. tool fixture: ISO SK 40 .. drive power: 40 kW AXIS DRIVES .. rapid traverse X: 70000 mm/min .. rapid traverse Y: 40000 mm/min .. rapid traverse Z: 40000 mm/min TOOL MAGAZINE .. number of positions: 30 .. tool diameter max.: 100 mm .. - with free neighbour positions: 140 mm .. tool length max.: 300 mm .. tool weight max.: 7 kg Bz3Rd2Sdho DIMENSIONS / WEIGHTS .. space requirements -left/right-: 2650 mm .. space requirements -front/back-: 2700 mm .. total height: 2500 mm .. total weight approx.: 9940 kg ATTACHMENTS .. chip conveyor: yes .. coolant unit: yes .. through spindle coolant attachment: yes .. closed cabin: yes .. European CE standards: yes -13000 operating hours -Tool clamping device including 3 vices -chip conveyor -belt filter

Condition: used, Year of construction: 1990, total height: 3,200 mm, installation height: 455 mm, pressing force: 100 t, table width: 560 mm, table length: 710 mm, overall weight: 8,500 kg, ram stroke: 320 mm, controller manufacturer: SIEMENS, controller model: S5, lifting height: 320 mm, worktable length: 710 mm, material thickness: 20 mm, material width: 300 mm, sheet thickness (max.): 20 mm, sheet thickness steel (max.): 20 mm, space requirement width: 2,100 mm, tool height: 455 mm, CONTROLS .. electronic controls SIEMENS S5 PRESS DESIGN .. drive system: hydraulic .. frame design: C-frame, single sided .. openings in uprights: yes .. table cushion: yes .. opening in table: yes PRESS FORCES .. total force (nominal): 100 to PRESS TABLE .. table surface (left-right): 710 mm .. table surface (front-back): 560 mm SLIDE .. slide force: 100 to .. table surface (left-right): 560 mm .. table surface (front-back): 450 mm .. spigot hole diameter: 50 mm .. stroke: 320 mm .. thickness of bolster plate: 150 mm SLIDE (HYDR. PRESS) .. approximation velocity max.: 340 mm/s .. working velocity max.: 32 mm/s .. return velocity max.: 330 mm/s SLIDE EJECTOR / CUSHION .. stroke: 40 mm DIE CUSHION (TABLE CUSHION) .. stroke: 80 mm TOOL ASSEMBLY DIMENSIONS .. shut height (stroke down, adjustment up), BDC: 455 mm STRIP-FEEDER .. feeder type: roll feeder Bzmbb8Hegi .. sheet width max.: 300 mm .. sheet thickness max.: 20 mm .. speed max.: 120 m/min ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -front/back-: 2100 mm .. total height: 3200 mm .. total weight approx.: 8500 kg ATTACHMENTS (PRESSES) .. decoiler: optional .. leveller unit: optional .. strip feeder: yes .. 2-hand engagement: yes Equipment: - Cutting impact dampening - Hydraulic die cushion and ejector - CNC - gripper feed (200x900x1700) - Soprem belt system (optional) see article no. 3-49541

Condition: used, Year of construction: 2008, turning length: 2,000 mm, turning diameter: 520 mm, spindle speed (max.): 4,000 rpm, travel distance Y-axis: 250 mm, bar passage: 77 mm, workpiece weight (max.): 1,000 kg, bar diameter: 77 mm, controller manufacturer: SIEMENS, controller model: 840 D SL, center width: 2,000 mm, distance between centers: 2,000 mm, machining diameter: 520 mm, number of spindles: 1, CONTROLS .. CNC controls SIEMENS 840 D SL BASIC FUNCTIONS .. number of spindles: 1 .. live positions: yes .. number of c-axes: 1 .. number of y-axes: 1 .. number of b-axes: 1 WORKING RANGE TURNING .. swing diameter (max): 520 mm .. turning diameter (max): 520 mm .. bar diameter (max): 77 mm .. worpiece length max.: 2000 mm .. workpiece weight max.: 1000 kg MAIN SPINDLE .. spindle revolutions (max): 4000 /min .. drive power S6 40%: 33 kW .. drive power S1 100%: 45 kW .. spindle torque S6 40%: 630 Nm .. c-axis: yes X/Z SLIDE .. Y-axis travel: 250 mm .. rotating range B-axis up to: 220 ° .. rapid traverse Z: 40000 mm/min .. rapid traverse X: 30000 mm/min .. rapid traverse Y: 15000 mm/min .. tool fixture: Milling Spindle .. number of tool positions (total): 80 .. number of live positions: 80 .. - rotation speeds (max): 9000 /min X SLIDE .. X-axis travel: 600 mm TAILSTOCK .. distance betw. centers (max): 2000 mm STEADY .. design: offen .. diameter (min): 45 mm .. diameter (max): 310 mm ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz ATTACHMENTS (TURNING) .. tailstock: optional Dreicz .. chip conveyor: yes .. European CE standards: yes Machines in good condition and still in operation B-axis overhauled in 2023(50k EUR) SMW steady rest SR5-ZSW (45-310) new i.e. in use since 2024 Operating hours: - NC program runs: 28620h - Spindle running: 21900h

Condition: used, Year of construction: 1984, number of straightening rollers: 9, coil weight: 500 kg, coil outer diameter: 1,000 mm, sheet thickness steel (max.): 4 mm, coil width: 350 mm, total height: 2,200 mm, sheet thickness (max.): 4 mm, load capacity: 500 kg, material width: 350 mm, overall weight: 1,500 kg, power: 10 kW (13.60 HP), controller manufacturer: SIEMENS, controller model: S7, space requirement length: 4,200 mm, space requirement width: 1,800 mm, CONTROLS .. electronic controls SIEMENS S7 DECOILER .. design: twin reel .. sheet width max.: 350 mm .. max. diameter of coil: 1000 mm .. mandrel expansion range from: 360 mm .. mandrel expansion range up to: 530 mm .. feed velocity min.: 0 m/min .. feed velocity max.: 60 m/min .. coil weight max.: 0.5 to LEVELLER UNIT .. sheet width max.: 350 mm .. sheet thickness max.: 4 mm .. sheet thickness min.: 0.5 mm .. material cross section max. (450 N/mm2): 750 mm² .. number of leveller rolls: 9 .. diameter of leveller rolls: 45 mm .. distance between leveller rolls: 47 mm Bygjekt7A8 .. number of infeed-/outfeed rolls: 2 .. diameter of feed rolls: 45 mm ELECTRICAL SPECIFICATIONS .. total power consumption: 10 kW .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 4200 mm .. space requirements -front/back-: 1800 mm .. total height: 2200 mm .. total weight approx.: 1500 kg

Condition: used, Year of construction: 2007, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 770 mm, controller manufacturer: HEIDENHAIN, controller model: ITNC 530, total height: 3,700 mm, table width: 1,000 mm, table length: 3,220 mm, overall weight: 22,000 kg, spindle speed (max.): 7,000 rpm, distance table center to spindle nose: 890 mm, spindle motor power: 40 W, space requirement length: 6,500 mm, space requirement width: 5,000 mm, CONTROLS .. CNC controls HEIDENHAIN ITNC 530 WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 3 .. X-axis travel: 2500 mm .. Y-axis travel: 1000 mm .. Z-axis travel: 770 mm .. distance spindle nose - table surface (max.): 890 mm TABLE .. table surface (left-right): 3220 mm .. table surface (front-back): 1000 mm .. workpiece load (max): 3500 kg SPINDLE / HEAD .. spindle revolutions (max): 7000 /min .. drive power: 40 kW TOOL MAGAZINE .. number of positions: 50 Byddt3D2O3 AUTOMATIC WORKLOAD EQUIPMENT .. store type: magazine ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V DIMENSIONS / WEIGHTS .. space requirements -left/right-: 6500 mm .. space requirements -front/back-: 5000 mm .. total height: 3700 mm .. total weight approx.: 22000 kg
