Pahlke Kunststoffmaschinen GmbH

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, Make Illig Cjdoxp H Nujpfx Aacohd Model RV 74 Year 1999 Hours Approx TBC Delivery Date Immediately Stations Forming, Cutting and Stacking Maximum Forming Area 700 x 500 mm Minimum Forming Area 400 x 250 mm Depth of Draw Above-Below 120 / 40 mm Maximum Material Thickness 2.0 mm Maximum Cycle Rate 20 / min Total Weight 6,600 kg All details are subject to change and/or errors. All equipment is subject to availability and/or prior sale.

Condition: used, Year of construction: 2014, Cannon/Breyer Combined extrusion thermoforming line for producing of continous 6-layer PE plate to thermoform automotive tanks Max. plate size: 1500x1600mm min. plate size to be precessed: 500 x 500mm max. plate thickness: 10mm min. plate thickness: 4,0mm max. plate weight: approx. 24kg (bei 1600x1500x10 mm) processing height: approx. 700mm max. capacity: 1.100 to 1.170 kg/h Comprising: Breyer Extrusion Line composed of - Breyer Extruder 105mm for HDPE and Master batch - Breyer Extruder 120mm for HDPE Regrind Csdoxpxfbjpfx Aacshd - Breyer Co-Extruder 45mm for HDPE ADMER - Breyer Co-Extruder 45mm for HDPE EVOH LDPE - Breyer Extruder 105mm for HDPE Cannon thermoforming press (7x) Kuka Industrial robots for plate supply to press, feeding of internal tank parts, unloading from press, edge trimming, loading/unloading to calibration station FDM/Piovan batch supply Vacuum supply Tempering units for tooling Condition: Good

Condition: used, Year of construction: 2017, Cannon/Breyer Combined extrusion thermoforming line for producing of continous 6-layer PE plate to thermoform automotive tanks Chjdpfx Asxpxc Teacsd Max. plate size: 1500x1600mm min. plate size to be precessed: 500 x 500mm max. plate thickness: 10mm min. plate thickness: 4,0mm max. plate weight: approx. 24kg (bei 1600x1500x10 mm) processing height: approx. 700mm max. capacity: 1.100 to 1.170 kg/h Comprising: Breyer Extrusion Line composed of - Breyer Extruder 105mm for HDPE and Master batch - Breyer Extruder 120mm for HDPE Regrind - Breyer Co-Extruder 45mm for HDPE ADMER - Breyer Co-Extruder 45mm for HDPE EVOH LDPE - Breyer Extruder 105mm for HDPE Cannon thermoforming press (8x) Kuka Industrial robots for plate supply to press, feeding of internal tank parts, unloading from press, edge trimming, loading/unloading to calibration station FDM/Piovan batch supply Vacuum supply Tempering units for tooling Condition: Good

Condition: good (used), functionality: fully functional, A Thermobend 2000 is a bending machine used for bending plastic sheets such as PMMA (acrylic glass) and methacrylate. The machine operates with heating wires to heat and bend the sheets at specific locations. Key features Capacity: The machine has a usable length of 2000 mm. Functionality: Can bend sheets with a thickness of 1 mm to 20 mm. Configuration: Equipped with 2 bending beams heated both from above and below. The distance between the wires is adjustable, with 3 wires above and 3 below per group. Dimensions: Length: 3200 mm x Width: 1000 mm x Height: 1600 mm Please note: The information on this page has been obtained and compiled to the best of our knowledge, but accuracy cannot be guaranteed. Accordingly, it does not constitute a representation or contract, and we recommend verifying all relevant details. Financial information VAT/margin: Margin: The listed price includes VAT (VAT is non-deductible for businesses). Codpfx Aasxn T Nrscjhd

Condition: excellent (used), COTEC Type: HCS 100 P-UH COTEC HCS 100 P-UH – Hydrophobic Coating System / PVD Unit For sale is a COTEC HCS 100 P-UH, a fully automatic hydrophobic coating system for industrial applications. The unit is ideal for producing high-quality, abrasion-resistant, and transparent hydrophobic and oleophobic coatings on glass, plastic, or metal. Fields of application: • Optics (e.g., eyeglass lenses, precision optics) • Display and electronics industry • Medical technology • Automotive and supplier industry • Consumer goods and decorative surfaces Technical data & features: Model: COTEC HCS 100 P-UH Process duration: approx. 12 minutes per batch Capacity: up to 110 substrates Ø 70 mm (2 racks) Internal chamber: Ø 600 × 540 mm Heatable chamber up to 65 °C Codpfx Aew Tbvroacshd Fully automatic process control (PLC) with 19'' operator panel Vacuum system with integrated evaporator for DURALON materials Uniform coating, even on complex 3D geometries No post-treatment required Weight: approx. 300 kg Condition: used Scope of supply: (See image) (Subject to change and error in technical data and information!) For further questions, we are happy to assist you by phone.

Condition: excellent (used), Year of construction: 2006, Manufacturer Gabler Model M92 L Chodpfew Rpzqox Aacod Year 2006 Condition Very Good Stock Number 00006 Max forming area 750 x 436 mm Depth of draw 150 mm Max material width 835 mm Max cycles / min 44 Max mould closing force 350 kN Max top heater output 81.90 kW Max bottom heater output 54.60 kW Operating air pressure 8 bar Power Supply 230V 50Hz Total Connected Load 138.66 kW Approx Dimensions 7,925 x 5,320 x 3900mm (LxWxH) Approx Weight 10,400 kg Notes All details are subject to change and/or errors. All equipment is subject to availability and/or prior sale.

Condition: used, We are selling a well-maintained generator from Kiefel. The generator and tubes have few operating hours. The rotary table shown in image 1 is no longer available. Cjdpfxsw Hdzls Aacehd

Condition: excellent (used), Year of construction: 2024, functionality: fully functional, machine/vehicle number: KG/F75-24-76/6, film width: 800 mm, type of input current: three-phase, pressure: 8 bar, input voltage: 400 V, 2024 model year with 300 kW 40-die mould with 75 mm diameter Operating speed: 25 cycles/minute The machine, mould, and stacker will be sold together. Chedpfxow Dfa Do Aaced Our machine is currently in active operation.

Condition: ready for operation (used), Year of construction: 1993, functionality: fully functional, machine/vehicle number: 1594, TECHNICAL DETAILS Machine number: 1594 Year of manufacture: 1993 Voltage: 3~220 V, 50 Hz Motor power: 3.52 kW Heating capacity: 216.0 kW Rated operating current: 86.5 A Permissible air pressure: 10 bar Cedpfx Asww Igyjacjhd

Condition: ready for operation (used), Year of construction: 2000, Recirculating air thermal cabinet / warming oven / drying cabinet / drying oven Alltherm WS 3750 - 1.5 - E - 24l The heated cabinet is equipped with two separately controllable chambers. Maximum temperature per chamber: 250 degrees Celsius Approximate dimensions: Cjdpfx Aowuqvreacshd Left chamber: Height 167 cm x Width 131 cm x Depth 91 cm Right chamber: Height 167 cm x Width 145 cm x Depth 96 cm Approx. external dimensions of the entire oven: Length 380 cm x Height 250 cm x Depth 128 cm The left chamber is additionally fitted with a viewing window. Location: Siegen ____ Our general terms and conditions apply. The seller assumes no liability for typographical or data transmission errors. The information and images were provided by the owner and released for publication. The appearance of the items on offer corresponds to their age and the photos shown. The technology and wear and tear of the items offered are age-appropriate. Used machines are sold exclusively to commercial customers and without warranty.

Condition: ready for operation (used), Year of construction: 1990, functionality: fully functional, machine/vehicle number: 1531, operating temperature: 650 °C, plate length: 1,000 mm, plate width: 700 mm, TECHNICAL DETAILS Film width: 700 mm Type of input current: AC Input voltage: 400 V Sheet thickness: 10 mm Sheet dimensions: 1,000 x 700 mm Operating temperature: 650°C Pump capacity: 100 l/min Vacuum pump power: 3,000 W Csdpfowr Ab Usx Aacjhd Compressed air connection: 6 bar Form height (min.): 300 mm MACHINE DETAILS Overall width: 700 mm Overall length: 3,500 mm Overall height: 3,500 mm Control cabinet width: 1,000 mm EQUIPMENT - Top heating 3 pilot burners, bottom heating 1 pilot burner - Motorized adjustable height of counterform - Quick clamping of upper and lower frame - Quick tool clamping on the lower table - Quick tool clamping on the upper table - Control of underfilm sag - Bubble formation with electric photocell - Storable bubble and demolding intensity, pneumatic valves in cascade - BUSCH vacuum pump 100 meters/cubic meter

Condition: ready for operation (used), Year of construction: 1990, operating hours: 45,353 h, functionality: fully functional, machine/vehicle number: 1537, product height (max.): 10 mm, plate length: 1,000 mm, plate width: 700 mm, Hybrid machine for thermoforming films or coils TECHNICAL DETAILS Maximum width: 700 mm Maximum plate: 1,000 x 700 mm Maximum sheet thickness: 10 mm Heating power: 31.1 kW Motor power: 5.59 kW EQUIPMENT - Plate loader type BE without preheating - Coil unwinding device type PR - Upper and lower table - Schleicher PDPF control director - Quick clamping of reduction frames and tools Cedswr Abzspfx Aacjhd

Condition: refurbished (used), Year of construction: 2017, Was overhauled in 2017, with documentation. Cjdpfx Aaswqd Adjcjhd

Condition: good (used), Year of construction: 1991, functionality: fully functional, Oven for plastic processing The oven can process thermo-plastics. Manufacturer: Reinhardt Model : VL Year of manufacture : 1991 No. : 8182 Connected load 50.2 kW Chodpfx Aewp Em Uoacjd Voltage 380 Volt Operating temperature 50 - 200 °C Carriage approx.: 2000 x 1200 mm W x D x 500 mm opening

Condition: good (used), Year of construction: 1985, functionality: fully functional, machine/vehicle number: 191, type of input current: three-phase, pressure: 10 bar, total width: 3,050 mm, total length: 2,400 mm, total height: 3,480 mm, control cabinet width: 850 mm, control cabinet height: 1,800 mm, control cabinet length: 600 mm, This machine was overhauled in 2020 and installed at a customer and was not or hardly used. Machine is in excellent condition. Has been professionally disconnected and transported. Chedpowpfrkefx Aaced

Condition: used, Year of construction: 2014, functionality: fully functional, machine/vehicle number: F.24442.03.03, Unique opportunity for serial manufacturers We are offering you here an immediately available, top thermoforming linear system with automatic tool change, rotary table, powerful lower table with spindle drive, tool change station, maintenance platform, hotmelt extraction, heating enclosure, and many other special functions directly from the manufacturer FRIMO. The system was most recently used for the production of automotive door panels. The film itself was coated with hotmelt. The system can also be used for dispersion adhesives (adhesive on the carrier parts). Very large components are possible, forming area up to 800 x 2,000 mm. The maximum forming part height is 250 mm. Very fast cycle times of under 60 seconds are easily possible. The system was regularly maintained and was in operation up to its dismantling. Currently, the system is properly stored at our facility in Hungary. We have locations worldwide and can assist you directly at your site. We can deliver this system worldwide as needed, install it at your factory, train your personnel, and advise you in all technical matters. Any modifications and modernization are also possible. Chsdpfx Aaswpd Rrocjd Just ask us with your individual project request!

Condition: new, Year of construction: 2022, functionality: fully functional, Make Kiefel Natureformer Model KFT 90 Speed Year 2022 Condition New - Machines are unopened and still in original packaging from Kiefel. Forming Area 900 x 600 mm (35.5 x 23.5 in) Max Height of Formed Part 120 mm (4.75 in) Punching Force 600 kN Shot Weight Max. 300g (10.5 oz) Cycle time 15 seconds +/- Chodewkkpqjpfx Aaced Machine picture shown is for example only. Machine has not been installed.

Condition: ready for operation (used), Year of construction: 1975, An Illig thermoforming machine is available. Form dimensions X/Y: 500mm/380mm, max. film width: 540mm, draw depth range: -120mm/+120mm, max. feed length: 360mm, cycle rate: 30 cycles/min, punching area X/Y: 500mm/390mm, punching force: 50000daN, machine dimensions X/Y/Z: approx. 4500mm/2200mm/2200mm, weight: approx. 4500kg. Documentation available. On-site inspection is possible. Chedpjwixynsfx Aacsd

Condition: ready for operation (used), Year of construction: 1965, Form dimensions X/Y: 475mm/250mm, max. material width: 495mm, max. infeed length: 280mm, max. negative draw depth: 100mm, max. roll diameter: 1200mm, max. material thickness: 2.3mm, max. cycle output: 48 cycles/min, forming output: approx. 6500 cups/min, machine dimensions X/Y/Z: approx. 5500mm/2200mm/2100mm, weight: approx. 2000kg. Documentation available. On-site inspection is possible. Chjdpfjwixyzex Aaced

Condition: reconditioned (used), functionality: fully functional, Technical Specifications: - Maximum material size: 2500 x 1500 mm - Maximum forming area: 2450 x 1450 mm - Maximum tool height: 600 mm - Maximum material thickness: 12 mm Equipment: Forming Station - Schleicher P03 control system - Automatic setup function - Top heater: ceramic emitters (500 W) with 4-zone control - Individual selection of upper heating elements, including lowering - Bottom heater: ceramic emitters (300 W) with 4-zone control - Individual selection of lower heating elements, including lowering - Program and heating settings storage - Clamping frame with quick-change system - Parallel upper frame, longitudinal runners for use of fixed format frames - Lower clamping frame for frame installation from below, central clamping via E-motor - Pneumatic lower table with rapid/creep speed, adjustable in 15 steps via control panel - Upper punch with rapid/creep speed, adjustable in 7 steps - Vacuum pump with cascade control, adjustable in 15 steps via control panel - Pre-blow automation, percentage adjustable - Pre-vacuum adjustment, percentage adjustable - Automatic demolding, percentage adjustable - Plate sag control via light barrier with support air Csdpfowf Eb Rox Aacjhd - 8-fold cooling fan with spray nozzle cooling - Large front opening for tool change Loading - Automatic sheet loading system - Centering table for precise positioning of sheets in the feeder - Motorized sheet lifter - Motorized sheet positioning adjustment - Motorized transport lifter - Motorized adjustment of transport width

Condition: reconditioned (used), functionality: fully functional, Plate size: 2000 x 1000 mm Forming area: 1960 x 960 mm Chedpfx Aowf Ebwoacod Drawing depth: 600 mm If you would like further details or a quote, please contact us.

Condition: reconditioned (used), functionality: fully functional, Plate size: 1250 x 1500 mm Forming area: 1200 x 1460 mm Csdswf Ea Tepfx Aacshd Drawing depth: 700 mm If you would like further details or a quote, please contact us.

Condition: reconditioned (used), functionality: fully functional, Plate size: 1000 x 1500 mm Chjdpfx Ajwf D S Uoacsd Forming area: 960 x 1460 mm Drawing depth: 600 mm If you would like further details or a quote, please contact us.

Condition: reconditioned (used), Plate size: 1000 x 1500 mm Chedpjwf D R Rsfx Aaced Forming area: 960 x 1460 mm Drawing depth: 600 mm If you would like further details or a quote, please contact us.

Condition: reconditioned (used), Max. forming area: 960 x 660 mm Min. forming area: 210 x 170 mm Max. sheet size: 1000 x 700 mm Min. sheet size: 310 x 210 mm Max. sheet thickness (manual feeding): 12 mm Max. sheet thickness (automatic feeding): 10 mm Max. tool height: 490 mm Max. draw depth: 300 mm (positive/negative) Total power consumption: approx. 64.0 kW / 115 A Technical features: - Siemens Simatic S7-300 control, OP 37 panel - Air-conditioned control cabinet - Top heater with 5 temperature control circuits via pilot emitters - Bottom heater with 5 temperature control circuits via pilot emitters - Individually switchable top heating elements Chsdpfxowf Dvas Aacod - Individually switchable bottom heating elements - Parallel clamping frame - Pneumatic motor locking for the upper reduction frame - Cylinder locking for the lower reduction frame - 4 cooling fans - Adjustable vacuum for the lower table via cascade control - Pre-blow and demolding adjustable via cascade control - Large front opening for tool change - Film sag control by photocell with support air - Automatic tool change system Lower table: 1. Tool clamping via vacuum 2. Tool change via pneumatically operated ball rollers Upper punch: 1. Motorized remote adjustment for stroke limitation 2. Pneumatic quick-change system for tools Sheet feeding: - Automatic motorized lifting of the film transport chain - With pneumatic quick-clamping system for vacuum plates - Motorized centering of plastic sheets - Separate vacuum pump for grained material Optional preheating retrofit: - Pneumatically moved top heater, complete zone control, each emitter individually switchable via toggle switch - Pneumatically moved bottom heater, complete zone control, each emitter individually switchable via toggle switch - Temperature control of top and bottom heating via separate heating controllers in the BE control cabinet (temperature setting not via UA control panel) Optional retrofit for roll processing: - Cross cutter and feeding rollers in feed area - RO 800 roll stand
