Condition: used, Year of construction: 2002, functionality: fully functional, CNC lathe Gildemeister Type: CTX 420 V6 Linear Year of manufacture: 2002 Technical data: Working area: Max. swing diameter over X-axis guide 680 mm Swing diameter over X-axis guide 565 mm Chuck diameter 200/250 mm Z-axis travel 260 mm X-axis travel 635 mm Spindle head: Spindle head (flat flange) 170 main spindle, 140 counter spindle Spindle diameter in the front bearing 120/90 mm Spindle bore 79/57 mm Main drive: Power of the AC main drive (100% duty cycle) 25 kW Torque max. 270 Speed range 25-5000 rpm Counter spindle Drive power AC 25 kW Torque max. 7000 Nm Speed range 35-7000 rpm Tool holder Number of tool stations 12 Tool shank according to DIN 69880 Cylindrical shank diameter 40 mm Indexing time 30°, 0.15 sec. Number of driven tools 12 Drive power 13.2 kW Torque 28 Nm Speed max. 4500 rpm C-axis, main spindle/counter spindle Speed range 0-250 rpm Torque 200/120 Nm Speed at point positioning 0.025 degrees Y-axis, vertical travel +/- 40 mm Csdpfx Ajz I T Avspbsrh Hydraulics Capacity, total approx. 25 l Pressure max. 80 bar Pressure for clamping device max 70 bar

Condition: like new (used), Year of construction: 2021, operating hours: 1,400 h, CNC turning machine MT RENT T25FSY Year of manufacture: 2021 Control: SIEMENS 828 D Operating hours: 1400 h Technical data: * Year of manufacture: 2021 * Control: Siemens Sinumerik 828D * Operating hours: approx. 1,400 h * Max. swing diameter over bed: 600 mm * Max. turning diameter: 460 mm * Max. turning length: 558 mm * X-axis travel: 310 mm * Z-axis travel: 620 mm * Y-axis travel: 110 mm / ±55 mm * B-axis travel / counter spindle: 650 mm * Spindle bore: 77 mm * Max. bar diameter: 65 mm * Main spindle speed: max. 4,500 rpm * Counter spindle speed: max. 4,500 rpm * Main spindle motor: 23 kW * 12-station BMT-60 tool turret * 12 driven tool stations * Tool shank: 25 × 25 mm * Max. drilling bar diameter: 40 mm * Hydraulic working pressure: 40 bar Equipment: * Y-axis * C-axis * Counter spindle * Driven tools * BMT-60 turret * WTO / QuickFlex tool holder * Bar loader * Chip conveyor * Hydraulic 3-jaw chuck Cjdpfxjz I R Sbo Apbsrh * Coolant system * Workpiece/part catcher * Foot pedals * Flat guides

Condition: ready for operation (used), Year of construction: 2012, operating hours: 41,280 h, travel distance X-axis: 165 mm, travel distance Z-axis: 700 mm, total height: 2,200 mm, total width: 1,630 mm, overall weight: 9,000 kg, controller manufacturer: FANUC, controller model: Series 31i-MODEL A, product length (max.): 2,800 mm, number of axes: 8, This 8-axis DOOSAN PUMA TT 1800 SY was manufactured in 2012. It features a maximum turning diameter of 230 mm and a maximum workpiece length of 700 mm. The machine is equipped with two spindles and two turrets, providing enhanced machining capabilities. If you are looking to get high-quality turning and milling capabilities, consider the DOOSAN PUMA TT 1800 SY turn-mill centre we have for sale. Contact us for further details. - Operating Hours: 41,280 h (as of Spindle Hours: 24,632 h (as of Total Machined Parts (TEIL GESMT): 14,162 pcs- Number of Spindles: 2 (Main Spindle & Counter/Sub Spindle)- Main Spindle Speed Range: 50 - 5,000 rpm- Counter Spindle Speed Range: 50 - 6,000 rpm- Number of Turrets: 2 (Tool holders)- Powered/Driven Tools: Yes- C-Axes: 2- Y-Axes: 1 (Upper turret)- Max. Turning Diameter: 230 mm- Max. Workpiece Length: 700 mm- Power Supply Voltage: AC 200/220V, 3-Phase (PE, 50/60 Hz) / 400 V, 50 Hz- Rated Power (Nennleistung): 75.21 kVA- Full Load Current (Volllaststrom): 197.37 A- Interrupting Capacity (Unterbrechungsstrom): 13 kA- Short-Circuit Current (Kurzschluss-Strom): 25 kA- Schematic Output (Schaltplan-Ausgabe): PT1H31AA02- Additional Equipment & Accessories: * FMB turbo 8-80/3200 bar feeder * Chip conveyor * Coolant system with belt filter * Internal coolant supply (IKZ) & supply via turret head * Hydraulic power unit * Large selection of tool holders, collet chucks (REGO-FIX / ER), and turning inserts Cjdpjz I Rbvefx Apbjrh Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: ready for operation (used), Year of construction: 2010, Make: SPINNER Type of machine: TC 400-52 MC Year of manufacture: 2010 Control system: Siemens SINUMERIK 840D SolutionLine Machine's weight: 4.000 kg Tool holder: VDI 30 / DIN 69880 x-travel: 200 mm y-travel: nicht vorhanden z-travel: 515 mm Speed range: bis 5.000 U/min Spindle lock: A6 Cutting diameter: 280 mm Driven tool: Ja Turning length: 500 mm Chip removal device: Ja Tailstock: Ja, hydraulisch / MK4 Overall dimensions: 2.100 × 1.350 × 1.800 mm (ohne Stangenlader) Crodpsz I Nawefx Apbjh Chuck size: 210 mm Chuck size: 210 mm Traverse Z-axis: 515 mm Tool turret - slots: 12 Counter spindle: Nein C-axis: Ja Spindle opening: 52 mm

Condition: as good as new (ex-display), Year of construction: 2024, functionality: fully functional, turning length: 1,073 mm, turning diameter: 380 mm, spindle speed (max.): 3,500 rpm, travel distance X-axis: 255 mm, travel distance Y-axis: 110 mm, travel distance Z-axis: 1,100 mm, bar passage: 81 mm, total height: 1,960 mm, total length: 3,805 mm, total width: 2,100 mm, overall weight: 5,800 kg, Equipment: documentation/manual, Hyundai WIA SE2600LSY is a high-performance CNC turning centre equipped with a Y-axis and sub-spindle for complete machining of complex components in a single setup. The machine features a FANUC i-Series control, BMT55 live tooling with speeds up to 6,000 rpm, and a maximum turning diameter of 380 mm. It is equipped with a 10" main spindle and 6" sub-spindle, providing excellent flexibility for both turning and milling operations. Optional equipment included: Crjdoz Izngopfx Apbjh Automatic tool setter 15 bar high-pressure coolant pump Chip conveyor with chip container Bar feeder interface Parts catcher Standard set of tool holders, including 2 + 2 live tool holders

Condition: used, Year of construction: 2015, functionality: fully functional, NAKAMURA NTJ-100, CNC turning and milling center with FANUC 31i-B control • C-axis on the left spindle • C-axis on the right spindle • Milling drive on the upper turret • Milling drive on the lower turret • B-axis on the upper turret +/-91° • Y-axis +/- 40 mm on the upper turret • Y-axis +/- 32.5 mm on the lower turret • Bar capacity left 42mm A2-5, 6000 rpm • Bar capacity right 42 mm A2-5, 6000 rpm • 12/24 + 6 stations under 45° turret, top • 12/24 stations turret, bottom Crjdpfx Apsz Iy Urobeh • 90° inclined bed • Interface for bar loader magazine, Hommel • Air blow-out, right spindle • Drive power left, FANUC AC11/7.5kW • Drive power right, FANUC AC 11/7.5KW • Chuck pressure monitoring, right and left • 19" touch monitor • Door lock • Clamping force control • Helical interpolation • NT-Nurse 2 • NT-Work navigator • Feed rate and rapid traverse adjustment switch • Transformer • CE marking • Memory capacity 2560 meters • Tool offset memory 99 items • Program management 2000 programs • Extended editor function • Background editor • Macro B • Direct input of drawing dimensions • G52-G59 • Polar coordinate interpolation • Cylindrical interpolation • Current documentation • Machine color RAL 9002, light gray • Door color RAL 7011, iron gray • Chip conveyor RAL 7024, graphite gray Machine options NTJ-100 Air and coolant blow-out through the right spindle Ø 65mm NTJ-100 Chuck blow-out, left spindle NTJ-100 Intelligent handwheel NTJ-100 Polygon turning function Manual tool probe, removable for left and right Workpiece unloading NTJ-100 Unloading with gripper hand on the upper turret for parts up to Ø 65 mm x length 150 mm / 3.0 kg NTJ-100 Material collection tray type A with enclosed collection box, left, for material remnants and finished part ejection, part size up to spindle bore 65 mm NTJ-100 enlarged main spindle, left, Ø 65 mm, spindle nose A6 NTJ-100 enlarged counter spindle, right, Ø 65 mm, spindle nose A6 Chip disposal Hinged belt chip conveyor for NTJ-100, discharge right. Manufacturer: AME. Color: RAL 7024. Motor right, in the direction of travel.

Condition: used, Year of construction: 2017, MURATEC MT100, 2017 CNC machine with gantry loader 2 spindles 2 Y axes Max. chuck size: 165 mm (6″) 2 turrets: 15 x 2 Bar capacity: 51 mm Spindle speeds: 50 rpm – 5,000 rpm Cedjz Ix Tajpfx Apberh 60 rpm – 6,000 rpm

Condition: used, Year of construction: 2019, operating hours: 9,000 h, machine/vehicle number: IntNr231662, A high-performance and versatile Doosan LYNX 2100 LSYB CNC turning/milling center, manufactured in 2019, with approximately 9,000 operating hours, is for sale. Technical data Manufacturer: Doosan Machine Tools Model: LYNX 2100 LSYB Control: Doosan-FANUC i Machine type: CNC turning/milling center Year of manufacture: 2019 Operating hours: approx. 9,000 h Working area Max. turning diameter: approx. 300 mm Max. turning length: approx. 510 mm Cedpfx Asz Itiijpberh Swinging diameter over bed: approx. 600 mm Swinging diameter over cross slide: approx. 400 mm Bar capacity: approx. 65 mm Travel distances X-axis: approx. 205 mm Y-axis: approx. 105 mm / ±52.5 mm Z-axis: approx. 560 mm Travel distance of counter-spindle / B-axis: approx. 560 mm Main spindle Spindle speed: up to approx. 4,500 rpm Spindle power: approx. 15 kW Spindle taper: ASA A2-6 Spindle bore: approx. 76 mm Bar capacity: approx. 65 mm C-axis: included Counter-spindle Max. speed: approx. 6,000 rpm Power: approx. 5.5 kW C-axis: included Automatic workpiece transfer between main and counter-spindle Tool turret Turret: BMT45P Tool stations: 12 Powered tools: available Max. speed of powered tools: approx. 6,000 rpm Rapid traverse rate X-axis: approx. 30 m/min Z-axis: approx. 36 m/min Dimensions and weight Machine weight: approx. 4,200 kg Dimensions L × W × H: approx. 2,880 × 1,710 × 1,920 mm The machine can be inspected by appointment. Subject to changes, errors and prior sale!

Condition: excellent (used), Year of construction: 2019, Vertical CNC lathe – 3 axes Brand: HYUNDAI WIA Type: LV 800 RM Year: 2019 (575 cutting hours) CNC: FANUC 32iB + manual guide Codpfx Ajz Iqlnjpborh Specifications: Turning capabilities: Maximum swing diameter: 890 mm Maximum turning diameter: 800 mm Maximum turning height: 800 mm Horizontal travel: 440 mm Vertical travel: 800 mm C-axis: 360,000 positions 3-jaw hydraulic chuck: Diameter: 530 mm Rotation speed: 2000 rpm Main motor power: 37/30 kW Dimensions (width x depth x height): 2000 x 2877 x 3300 mm Weight: 11 tons Equipped with: 12-tool turret C-axis 0.001° Rotating tool spindles 7.5 kW, 3000 rpm Through-tool coolant supply 20 bar Renishaw Quickset Rotating tool holders: 3 x axial, 3 x radial Turning tool holders Set of chuck jaws Manual 3-jaw chuck, dia. 630 mm Chip conveyor

Condition: used, Year of construction: 2012, functionality: fully functional, Spinner TC 600 65 SMCY with C-Y axis and sub-spindle Technical data: max. swing diameter ~600 mm max. turning diameter ~400 mm max. turning length ~650 mm Travel X/Y/Z: X 275 / +50/-40 / Z 700 max. rapid traverse X/Z 15/24 max. speed 4500 rpm spindle power 22 kW torque 250 Nm max. speed sub-spindle: 6000 rpm chuck 165 mm spindle power sub-spindle: 10 kW tailstock 8 taper socket MK4 Number of tools: 16 tool holder: VDI 30 max. speed rotating tools: 5000 rpm Cedpfxoz Iqf Us Apbsrh power (60%): 6 kW torque (60%) ~30 Nm Weight: 5,000 kg Dimensions: 2.5 m × 1.6 m × 2 m Accessories: chip conveyor tool holders extraction system

Condition: good (used), Year of construction: 2003, functionality: fully functional, turning length: 600 mm, turning diameter: 324 mm, travel distance X-axis: 260 mm, travel distance Z-axis: 635 mm, rotational speed (max.): 5,000 rpm, bar passage: 65 mm, GILDEMEISTER CTX 420 linear V3 Year of manufacture: 2003 Control system: Heidenhain Plus IT / DataPilot Machine type: CNC turning machine Design: C-axis and driven tools Working area: Swinging diameter over bed: 680 mm Swinging diameter over cross slide: 565 mm Max. turning diameter: 324 mm Max. turning length: approx. 600–635 mm Travel in X-axis: 260 mm Travel in Z-axis: 635 mm Main spindle: Speed range: 20–5,000 rpm Drive power: 37 / 25 kW Max. torque: approx. 390 / 270 Nm Bar diameter: approx. 65 mm Spindle bore: approx. 79 mm Tool turret: 12-position Sauter tool turret Tool holder: VDI 30 Driven tool stations: up to 12 Speed of driven tools: up to approx. 4,500 rpm Power of tool drive: approx. 12.2 kW C-axis: C-axis available Rapid traverse rates: Rapid traverse rate X-axis: up to 60 m/min Rapid traverse rate Z-axis: up to 45 m/min Tailstock: Tailstock available Arbor mounting: MK 5 Tailstock travel: approx. 580 mm Machine data: Machine weight: approx. 6,000–6,500 kg Dimensions L x W x H: approx. 3,500 x 2,460 x 2,100 mm Typical equipment: Driven tools C-axis 12-position turret Tailstock Chip conveyor Cjdpfx Apoz Iqc Hobsrh Coolant system

Condition: refurbished (used), functionality: fully functional, turning diameter: 200 mm, rotational speed (max.): 6,000 rpm, Control system: Siemens 840 Dsl General Bar diameter (HS): 60 mm Bar diameter (GS): 60 mm Credpez Ip Iusfx Apbsh Milling spindle Milling spindle: HSK D-50 Tool holder I (X/Y/Z/B) Technology: Tool turret with 14 stations Tool holder: HSK D-50 Tool drive: 6,000 rpm X-axis: 155 mm Y-axis: +/- 60 mm Z-axis: 590 mm B-axis: 360° swiveling Tool holder II (X/Z) Technology: Tool turret with 14 stations Tool holder: VDI 25 W-shank Tool drive: 6,000 rpm X-axis: 105 mm Z-axis: 400 mm Equipment Chip management: Hinged belt chip conveyor Coolant management: Switchable coolant pump, 8/80 bar Bar loader: UNIMAG interface Control function: “Guide unit” for cross slide 2 Warranty: 12 months

Condition: good (used), Year of construction: 2004, functionality: fully functional, turning length: 511 mm, turning diameter: 380 mm, travel distance X-axis: 230 mm, travel distance Z-axis: 575 mm, rotational speed (max.): 5,000 rpm, bar passage: 65 mm, MAZAK QUICK TURN NEXUS 200 MS Year of manufacture: 2004 Control system: Mazatrol 640T Nexus Machine type: CNC turning machine Configuration: Main and counter spindle, C-axis, driven tools Working area: Max. swing diameter: 675 mm Max. turning diameter: 380 mm Max. turning length: 511 mm Max. bar diameter: 65 mm Main spindle: Speed range: 35 – 5,000 rpm Drive power: 26 kW Continuous power: 22 kW Max. torque: 350 Nm Spindle bore: 76 mm Spindle nose: A2-6 C-axis resolution: 0.001° Counter spindle: Speed range: 35 – 6,000 rpm Drive power: 10 kW Continuous power: 7.5 kW Max. torque: 75 Nm C-axis resolution: 0.001° Tool turret: Tool positions: 12 Crsdpfxjz Ipvxe Apbjh Driven tools: available Speed of driven tools: 25 – 4,500 rpm Drive power: 5.5 kW Max. torque: 35 Nm Travel distances: X-axis: 230 mm Z-axis: 575 mm Rapid traverse X-axis: 30 m/min Rapid traverse Z-axis: 33 m/min Machine data: Total connected load: approx. 46.2 kVA Machine weight: approx. 5,100 kg Dimensions L x W x H: approx. 2,800 x 1,800 x 1,850 mm

Condition: new, Three-jaw chuck for DMG MORI NLX 2500 – A8 taper according to DIN/ISO 702-1 Power chuck with adapter ring and threaded ring for NLX 2500 High-quality three-jaw chuck for the DMG MORI NLX 2500, designed for precise and reliable workpiece clamping in demanding turning operations. The clamping system includes a matching adapter ring with an A8 taper according to DIN/ISO 702-1, as well as a threaded ring that fits the drawtube of the NLX 2500. Scope of delivery Three-jaw power chuck Adapter ring with A8 taper according to DIN/ISO 702-1 Threaded ring to fit the NLX drawtube Design adapted to the machine interface Precise clamping technology from Geiger + Haag Geiger + Haag develops and manufactures power chucks and custom clamping devices for demanding machining tasks. Since its foundation in 1947, precision, reliable clamping technology, and application-specific solutions have been the focus. Through the close connection between design, manufacturing, and customer support, even individual clamping tasks can be implemented quickly and in a practical manner. Crjdpfxsz Ipmwo Apboh Our clamping solutions are used, among other applications, in multi-spindle lathes, rotary transfer machines, special machines, and transfer lines. Your individual clamping solution Do you need a chuck for a specific machine, a special taper, or a custom drawtube connection? We develop and manufacture the right solution – tailored to the machine, workpiece, and machining process. Geiger + Haag – Clamping technology for demanding machining tasks.

Condition: good (used), Year of construction: 2007, Machine is in good condition. Parts shown by hand not come. Crjdpfx Apez Inqnjbjh Additional toolholders will come with machine.

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 138616, turning length: 1,000 mm, turning diameter: 580 mm, spindle speed (max.): 5,000 rpm, controller model: Mazatrol Fusion 640 MT, milling spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Max. turning diameter: approx. 580 mm Max. machining diameter: approx. 520 mm Crsdpfsz Inaiox Apbjh Max. turning length: approx. 1,000 mm Main spindle speed: up to 5,000 rpm Milling spindle speed: up to 12,000 rpm MACHINE DETAILS CNC control: Mazatrol Fusion 640 MT EQUIPMENT Main spindle Milling spindle with B-axis Y-axis C-axis Chip conveyor Documentation, if available Coolant system Tool changer: automatic

Year of construction: 2020, condition: excellent (used), functionality: fully functional, USED YAMAZAKI MAZAK HORIZONTAL MILLING AND TURNING CENTER INTEGREX J-200 X 500 with Smooth G CNC - 36-tool magazine package (500U) - 15 kW AC turning spindle power - B-axis with mechanical locking every 1° - 15 bar coolant through the milling spindle and onto the flange - Lateral chip conveyor with belt (500U) - High/low pressure selection (requires opening/closing of the chucks with the spindle stopped) - Radio probing system - Renishaw RMP60 (complete system including probe and Mazatrol probing cycles, excluding the Renishaw "Inspection Plus" software) Crodpfxoz Ihmps Apboh - SEI FILTRATION system - Tooling and mandrel kit Complete with operating manuals, CE certification, and standard accessories.

Condition: used, Technical details: max. turning diameter: 320 mm turning length: 1040 mm control: OSP E 100 L Dialog Fanuc greates pass round over bed: 530 mm standard turning dia.: 350 Max. distance between centres: 1200 mm max. workpiecediameter: 525 mm Traverse X-Axis 1: 500 Traverse X-Axis 2: 350 mm Traverse Y-Axis 1: 160 (+80/-80) mm Traverse Z-Axis 1: 1200 mm Traverse Z-Axis 2: 1200 mm Spindle 1 Power: 22 kW Spindle 1 RPM: 3800 1/min spindle nose: JIS A2-8 spindle bore: 80 mm bar material dia.: 65 mm C-Axis: 0,001° Number of Turrets: 2 Turret No.1 stations / rotary tools: 12/12 Turret 1 tool RPM: 4500 1/min Turret No.2 stations / rotary tools: 12/12 rapid traverse X-axis: 20 m/min rapid traverse Z-axis: 25 m/min total power requirement: 33 kVA weight of the machine ca.: 10 t dimensions of the machine ca.: 6,0 x 2,5x 2,3 m High pressure coolant system: INterlit 8/20 bar Accerories Chip conveyor Cjdpfx Apez Ig Swebjrh part counter total counter tool setting Signal lamp 3 colors spindle load monitor B Spindle 1 Chuck SMW 300 mm CNC Turning-and Milling Center The Okuma LT 300 MY has 2 turrets, the upper turret has Y-axis with milling function, the lower turret has milling function. It has main- and subspindle. This allows synchronized machining using 2 turrets. There is an Interlit paperfilter/high pressuire system with the machine with coolant cooler. There are 7 identical machines available, all in very good and well maintained condition. *

Condition: used, Year of construction: 2008, Technical details: max. turning diameter: 350 mm turning length: 1040 mm control: OSP E 100 L Fanuc greates pass round over bed: 550 mm Max. distance between centres: 1200 mm max. workpiecediameter: 550 mm Traverse X-Axis 1: 270 Traverse X-Axis 2: 230 mm Traverse Y-Axis 1: 120 (±60) mm Traverse Z-Axis 1: 930 mm Traverse Z-Axis 2: 920 mm Spindle 1 Power: 22 / 15 kW Spindle 1 RPM: 5000 1/min spindle nose: JIS A2-8 bar material dia.: 65 mm C-Axis: 0,001° Number of Turrets: 2 Turret No.1 stations / rotary tools: 12/12 VDI 40 Turret 1 tool RPM: 4500 1/min Turret 1 power rotary tools: 7.0 / 3,3 kW Turret No.2 stations / rotary tools: 12/12 VDI 40 Crsdjz Ig Sqjpfx Apboh Turret 2 tool RPM: 4500 1/min Turret 2 power rotary tools: 7.0 / 3,3 kW rapid traverse X-axis: 30 m/min rapid traverse Y-axis: 26 m/min rapid traverse Z-axis: 40 m/min total power requirement: 33 kVA weight of the machine ca.: 10 t dimensions of the machine ca.: 7,0 x 2,3 x 2,3 m Accerories Chip conveyor part counter total counter tool setting Signal lamp 3 colors spindle load monitor B Spindle 1 Chuck 300 mm CNC Turning-and Milling Center The Okuma LT 300 MY has 2 turrets, the upper turret has Y-axis with milling function, the lower turret has milling function. It has main- and subspindle. This allows synchronized machining using 2 turrets. There is an Interlit paperfilter/high pressuire system with the machine with coolant cooler. There are 7 identical machines available, all in very good and well maintained condition. *

Condition: like new (used), Year of construction: 2019, operating hours: 3,500 h, functionality: fully functional, bar passage: 117 mm, overall weight: 8,500 kg, The Hyundai WIA L400MC is in like-new condition. Inspection under power is possible at any time. Model: Hyundai WIA L400MC Design: Standard Bore Swinging diameter over bed: Ø 780 mm Swinging diameter over slide: Ø 535 mm Max. turning diameter: Ø 560 mm Max. turning length: 1,180 mm Bar capacity: Ø 117 mm Chuck size: Ø 381 mm (15") Max. spindle speed: 2,000 rpm Spindle motor power (max./continuous): 37 / 30 kW Spindle torque (max./continuous): 3,073 / 2,490 Nm Spindle drive: Belt drive with 2-speed gearbox Spindle taper: A2-11 C-axis: 0.001° Travel distances X-axis: 320 mm Z-axis: 1,200 mm Rapid traverse X/Z: 20 / 25 m/min Guideways X/Z: Box guide / Flat guideways Number of tool stations: 12 Tool holder, outer diameter (OD): □ 32 mm Tool holder, inner diameter (ID): Ø 63 mm Turret indexing time: 0.2 s Mount: BMT75P Driven tools Motor power (max./continuous): 7.5 / 5.5 kW Max. speed: 4,000 rpm Torque (max./continuous): 44.7 / 35 Nm Collet size: Ø 26 mm (ER40) Tailstock Tailstock taper: MK5 (integrated) Quill diameter: Ø 150 mm Quill stroke: 132 mm Crodpfx Aez Ibaiepbsh Tailstock travel: 1,100 mm Additional technical data Coolant tank: 300 liters Lubricant tank: 2 liters Electrical connection: 46 kVA Recommended cable cross-section: > 50 mm² Voltage / Frequency: 220 V / 60 Hz or 200 V / 50 Hz Footprint (L x W): 4,202 x 2,207 mm Machine height: 2,153 mm Machine weight: approx. 8,500 kg Control: HYUNDAI WIA FANUC i Series / FANUC 32i-B

Condition: used, Year of construction: 2007, operating hours: 21,999 h, turning length: 170 mm, turning diameter: 140 mm, spindle speed (max.): 8,000 rpm, controller model: Mitsubishi Meldas, TECHNICAL DETAILS Turning diameter: 42 / 140 mm Turning length: 170 mm Spindle speed: 80–8,000 rpm C-axis: 0.001° Number of turrets: 2 Tool positions per turret: 12 Tool holder: VDI 20 Spindle speed for driven tools: 45–4,500 rpm Sub-spindle distance: 42 mm Spindle power: 1 kW Spindle speed: 60–6,000 rpm C-axis: 0.001° MACHINE DETAILS Control system: Mitsubishi Meldas Number of controlled axes: 8 Simultaneously machinable axes: 7 Collet chuck: 48 DIN 6343 Dimensions & Weight Footprint: approx. 2.4 × 1.6 × 2.2 m Machine weight: approx. 3.3 t Operating hours: 21,999 h EQUIPMENT Various tool holders, see images 5 axial driven tool holders Crodpfez Ia Rgjx Apbeh Collet chuck for pressure collets, type 173E 15 pressure collets, type 173E Additional coolant cooler Chip conveyor Knoll, year of manufacture 2018 Simultaneous operation with 7 axes on main and sub-spindle Note: Complete battery replacement on 22.12.2025

Condition: excellent (used), Year of construction: 2003, Sub-spindle, Y-axis, B-axis, C-axis SIEMENS 840D ShopMill Csdpfxsz Iaqgj Apbjrh Turning diameter max 246mm Turning length -445mm Spindle speeds main & sub-spindle -6'000 rpm Turret head: 12 driven positions B-Axis 440 mm Tool presetting device Tool catching attachement Misc. accessories MARCELS MASCHINEN CH

Year of construction: 2005, condition: good (used), functionality: fully functional, INTEGREX E-1550 V/10 2P MACHINE AVAILABLE FROM DECEMBER, CURRENTLY VIEWABLE IN PRODUCTION. Mazatrol Fusion 640M Pro control Table dimensions (without pallet/plate) 1000 x 1000 mm Turning diameter Ø 2,000 mm Maximum machining diameter Ø 2,000 mm Maximum workpiece height 1,440 mm (with 1000 x 1000 mm pallet) Maximum workpiece weight (including pallet) 5,000 kg Milling spindle power (30 min. rated / 100% continuous duty) 37/30 kW Maximum torque 458 Nm Milling spindle speed 35 / 10,000 rpm Tool clamping, B-axis indexing X-axis travel 1,875 mm Y-axis travel 1,550 mm Z-axis travel 1,345 mm B-axis tilting angle 150° (-30° to +120°) C-axis rotation (continuous) 360° Rapid traverse rate of X, Y, Z axes 40 m/min C-axis speed 18 min⁻¹ • Tool magazine for 160 tools (SK50) • B-axis, 0.0001° (continuous via ETA/ISO, interpolation possible) • Handwheel (mobile) • e-Tower • Main spindle, «High Torque» version, torque 8,000 Nm Cedpez H Axkjfx Apbsrh • Linear measuring system for X and Y axes. • Provision for spindle cooling via a 70 bar cooler, including M functions • Automatic shutdown. • 3 rotating lamps for displaying machining status. • Mazak Monitoring System B, Renishaw MP10 probe, optical; probe and function included under MAZATROL. • 3 pcs. plates (1 x Ø 1250 mm / 2 x 1000 mm MAZAK) CONSEP 2000 chip conveyor, lateral discharge. • High-pressure pump, type RKP-32-5.5 kW; pump adjustment from 20 to >70 bar

Condition: used, DMG Gildemeister GMX 400 linear multi-tasking twin spindle CNC lathe with Siemens 840D control & pneumotec gantry parts loading system with coolant paper filtration system, chip conveyor, IFM mist extraction unit, oil chiller, automatic doors, foot switches, wash gun, handwheel, signal tower & manuals. Overall dimensions: L9,347mm x W4,646mm x H3,018mm. Weight 24,000kg. With dual rohm KUBF-400/4 Ø400mm power chucks. Swing Ø640mm. Maximum turning Ø640mm. Maximum turning length 1,500mm. Axis travel 'X1'=550mm, 'Y'=220mm, 'Z1'=1,585mm, 'X2'=225mm, 'Z2'=1,400mm, 'Z3'=1,500mm, 'B'= ±120°. Rapid travere 'X'=40m/min, 'Y'=24m/min, 'Z'=60m/min. Spindle bore Ø107mm. Maximum bar capacity Ø92mm. Crsdpsz Hzuwsfx Apboh Maximum main spindle speed 4,000rpm (45kW Motor). Maximum sub spindle speed 4,000rpm (45kW Motor). Maximum rotary spindle speed 12,000 (22kW Motor). Rotary spindle taper capto C6. 60 position ATC. 12 position sauter turret. 20 position loading station with air blast cleaning tank.

Condition: ready for operation (used), Year of construction: 2014, operating hours: 31 h, travel distance X-axis: 285 mm, travel distance Z-axis: 560 mm, number of axes: 4, This 4-axis Hurco TMX8MYS was manufactured in 2014. It features a tool turret and includes a main spindle chuck, sub-spindle chuck, and parts catcher. With a robust design, this turn-mill centre is ideal for complex machining tasks. If you are looking to get high-quality turning and milling capabilities, consider the Hurco TMX8MYS turn-mill centre we have for sale. Contact us for further details. Crjdpsz Hy Hlofx Apboh - AC Voltage: 400 V (3 Phase)- Frequency: 50 Hz- Full Load: 53 KVA- Largest Motor: 28 KVA- Interrupt Capacity: 10000 AMPS- Short Circuit Current: 5 kA RMS Symmetrical- Max Ambient Temp: 35 DEG. C- Max Volts: 400 V- Inventory / Asset Number: Inv.-Nr.: 441007- Machine Power-On Time: 31h : 31m : 2s- Main Spindle Operating Time: 0h : 10m : 28s- Driven Spindle Operating Time: 0h : 0m : 25s- Counter Spindle Operating Time: 0h : 0m : 0s- Additional Equipment: Tool turret, main spindle chuck, sub-spindle chuck, parts catcher, driven tools Technical Specification Counter Spindle Yes Driven Tools Yes
