Condition: new, Year of construction: 2025, functionality: fully functional, pressing force: 125 t, Single-column press – Manufacturer: Durendus – 125 t servo press – Table 2200 × 750 mm For sale is a hydraulic C-frame servo press from Durendus with an adjustable pressing force of up to 125 t and integrated 50 t ejector. Thanks to modern servo-hydraulics, this machine offers up to 40% reduced energy consumption compared to conventional systems and is ideal for demanding assembly, forming, and production processes. ===== Technical data & information: Hydraulic servo press – C-frame – 125 t ==== General Specifications - Manufacturer: Durendus - Model: Single-column press / servo press - Design: C-frame press - Pressing force: 20 – 125 t (adjustable) - Machine weight: approx. 8,700 kg - Dimensions (W × D × H): approx. 2,400 × 2,000 × 3,300 mm - Table height: 870 mm - Installation height: max. 1,000 mm Lodpfx Absx Aqtqeveri ==== Table & Ram - Table area: 2,200 × 750 mm - Ram area: 980 × 750 mm - Guidance: 4 guide columns Ø 100 mm - Tool centering: 50 mm receptacle - Preparation: Vibration damping plates (30 mm) - Preparation: Robot interface ==== Ejector - Ejector force: 50 t - Ejector stroke: 200 mm ==== Hydraulic Cylinder - Stroke: 0 – 700 mm (adjustable) - Working pressure: max. 245 bar - Return speed: 300 mm/s - Idle speed: 300 mm/s - Pressing speed: - up to 25% load: 25 mm/s - up to 50% load: 14 mm/s - up to 80% load: 7 mm/s - up to 100% load: 6 mm/s ==== Hydraulic Unit - Servo hydraulic pump: Duplomatic, 143 l/min - Servo motor power: 15 kW - Pressure accuracy: ± 5 bar - Pre-fill valve: NG-160 ===== Assembly, forming technology, series production, automated manufacturing, toolmaking, energy-optimized pressing processes Servo press, single-column press, C-frame press, hydraulic press, industrial press, production press, energy-efficient press, die spotting press, tryout press, tool try-out press Are you looking for a hydraulic press tailored to your specific application? Contact us for a custom quote. Our hydraulic presses are manufactured in accordance with both German and European machinery directives (Directive 2006/42/EC), EC standards, and EU safety regulations. Furthermore, our presses exceed Canadian and European safety requirements as they fully comply with the Brazilian national safety standard NR 12, which builds upon those regulations. Our core expertise lies in special-purpose machine construction and press automation. We offer customized hydraulic presses at surprisingly competitive prices. We primarily use components from leading European manufacturers for the press hydraulics.

Condition: new, Year of construction: 2025, functionality: fully functional, pressing force: 20 t, Single-column press – Manufacturer: Durendus – 3–20 t hydraulic press – Table 1000 × 400 mm For sale is a hydraulic single-column press (C-frame) from Durendus with an adjustable pressing force of 3 to 20 t. This compact and robust machine is ideal for assembly, pressing, and light forming operations in the workshop and production environments. ==== Technical data & Information: Hydraulic Single-Column Press – 3–20 t ==== General Information - Manufacturer: Durendus - Model: assembly press / single-column press - Design: C-frame press - Pressing force: 3 – 20 t (adjustable) - Machine weight: approx. 1,200 kg - Paintwork: RAL 7035 (light grey) / RAL 2009 (orange) Ledpex Ap Utsfx Abvsri ==== Working Area - Max. distance table – ram: 500 mm - Stroke / travel: 500 mm - Table height: 940 mm ==== Table & Ram - Table plate: 1,000 × 400 × 40 mm - Ram: Ø 250 mm, round, interchangeable ==== Speeds - Downstroke speed: 2 – 10 mm/s (adjustable) - Upstroke speed: 20 mm/s ==== Hydraulics - Motor power: 2.2 kW - Oil tank capacity: 60 l - Pump: Agro-Hytos or equivalent ==== Equipment & Operation - Pressure adjustment via rotary knob - Robust machine frame - Control cabinet technology from renowned manufacturers - Emergency stop ==== Documentation & Delivery - CE declaration - German-language documentation - Installation, commissioning, and training available at extra charge ===== Assembly work, pressing operations, workshop applications, small series production, light forming operations Single-column press, C-frame press, hydraulic press, workshop press, assembly press, industrial press, die set-up press, tryout press, tool tryout press Are you looking for a hydraulic press tailored to your specific application? Contact us for an individual offer. Our hydraulic presses are manufactured in accordance with German Machinery Directives as well as European Machinery Directive (Directive 2006/42/EC), EC standards, and EU safety regulations. In addition, our presses exceed Canadian and European safety requirements, as they fully comply with the national Brazilian safety standard NR 12, which is based on these. Our major strength is in special-purpose machine construction and press automation. We supply custom hydraulic presses at surprisingly attractive prices. The hydraulic systems of our presses are equipped mainly with components from leading European manufacturers.

Condition: used, Year of construction: 1961, pressure 025 t table-size 450 x 500 mm stroke 500 mm dayligth 550 mm throat 200 mm table height over floor 800 mm hole in the table 130 mm Lrjdpfx Asxukpcebvei

Condition: used, Year of construction: 1980, throat 350 mm stroke ca. 400 mm ram diameter 95 mm press capacity 25 t table depth 450 mm table width 1.500 mm table height 900 mm weight of the machine ca. 2,5 t dimensions of the machine ca. 2,0 x 2,0 x 2,3 m Straightening Press - Single Column MÜLLER - CR 25.2.1 - Power-On Hours: 543h Lrjdpfsxgu Itsx Abvji - incl. working lamp

Condition: good (used), functionality: fully functional, total height: 2,700 mm, pressing force: 25 t, table width: 500 mm, table length: 500 mm, overall weight: 2,000 kg, distance table to ram: 800 mm, stroke length: 500 mm, Equipment: documentation/manual, Available for sale: 1 used hydraulic press Manufacturer: VEB Werkzeugfabrik Zeulenroda WMW Model: PYE25/1 Lsdpfxexfzdlo Abvori Total weight: 2 t Nominal pressing force: 25 MP Ram stroke: 500 mm Maximum distance between table and ram: 800 mm Table: 500 x 500 mm Documentation included

Condition: good (used), Year of construction: 1988, machine/vehicle number: 053-019/35, Offer 24591 Technical specifications: - Maximum press force 25 t - Maximum ram stroke 500 mm Ljdpewd Nybefx Abvsri - Stroke speed 0 - 40 mm/s - Return stroke 0 - 200 m/min - Installation height 800 mm - Throat to ram center 360 mm - Ram clamping area 440 x 360 mm - Ram clamping pin 40 mm - Table size 630 x 500 mm - Table height above floor 710 mm - Deep drawing force 10 t - Maximum deep drawing depth 160 mm - Drive 400 V / 4 kW - Space requirement approx. W 800 x H 2720 x D 1150 mm - Weight approx. 2500 kg

Condition: used, Year of construction: 2000, pressure 25 t stroke 150 mm throat 420 mm dayligth 450 mm table surface area 700 x 820 mm table height over floor 850 mm ram surface 600 x 600 mm feed down 370 mm/s feed up 370 mm/s working feed 18 - 33 mm/s oil volume 300 l Ledpfx Ajvut N Nebvjri power requirement 5,5 kW Weight 5,8 t dimensions of the machine ca. 1,1 x 2,0 x 2,4 mxmxm permitted for manual loading according to the CE-norm with oil-hydraulic drive, controllable dependent on pressure/time and way, cutting impact cushioning, mechanical depth stop, two-hand operation

Condition: new, Year of construction: 2025, functionality: fully functional, total height: 23,000 mm, total width: 7,800 mm, total length: 10,400 mm, pressing force: 25 t, table width: 780 mm, table length: 200 mm, operating speed: 13 mm/s, reverse speed: 24 mm/s, stroke length: 480 mm, operating pressure: 230 bar, oil tank capacity: 20 l, power: 3 kW (4.08 HP), MULTI-PURPOSE workshop / press Lrjdpfot A Dznjx Abvji Available in both 20 and 25 tons. BAR-MAN 20: 3,450 euros BAR-MAN 25: 3,990 euros The BAR-MAN can be used for a wide range of applications. Examples include maintenance work, cutting keyways, pressing bearings in and out, and much more. With this powerful machine, you can tackle almost any task, all while maintaining maximum operator comfort.

Condition: excellent (used), Year of construction: 1977, functionality: fully functional, total height: 27,500 mm, total width: 10,500 mm, total length: 16,500 mm, pressing force: 25 t, table width: 630 mm, table length: 500 mm, operating speed: 200 mm/s, overall weight: 2,400 kg, reverse speed: 450 mm/s, ram plate width: 450 mm, ram plate length: 360 mm, distance between stands: 800 mm, stroke length: 500 mm, power: 12.5 kW (17.00 HP), PYE 25 SS hydraulic press. Year of manufacture 1977. manufacturer VEB Wema Zeulenroda (Germany). Parameters: Maximum pressing force 25 tons. Working pressure 16 MPa. Upper table 450 x 360 mm. Lower table 630 x 500 mm. Ground clearance 800 mm. Cylinder stroke 500 mm. Down speed 200 mm/sec. Upward speed 450 mm/sec. Lodpfxotzxvwo Abveri Power requirement 12,5 kW. Weight 2400kg. Height 2750mm, length 1650mm, width 1050mm. Technical condition of the machine very good. The machine after a general overhaul. It is possible to make a visual inspection and check the machine in motion.

Condition: used, Year of construction: 1976, pressure 20 t throat 185 mm stroke 100 mm table surface area 380 x 350 mm dayligth 250 mm table height over floor 840 mm total power requirement 4 kW weight of the machine ca. 1,3 t Lrodpfx Astqqwujbvoi

Condition: used, Single-column hydraulic press HYDRAP type HPSK 25 No. 6312 Year of construction 1989 Ledpohrakvsfx Abvori Pressure force 25 ton. Ram stroke 500 mm throat depth 300 mm Installation height 700 mm Table surface 1000 x 500 mm Table bore Ø 210 mm Plunger surface 400 x 360 mm Clamping pin bore Ø 40 mm Table height above floor 855 mm Feed speed in rapid traverse 280 mm/sec. Pressing speed 3.5 mm/sec. to 25 mm/sec. Return speed 280 mm/sec. Hydraulic tank capacity 240 liters Drive power 7.5 kW Mains connection 400 Volt, 50 Hz. - Operation and programming via SIEMENS S5 with OP1 control system - Measuring system for stroke adjustment - Pressing speed infinitely variable via potentiometer - Pressure setting infinitely adjustable manually via pressure regulator - Short stroke device - Mechanical tool clamping on ram with T-slots and clamping pin hole - Switch cabinet with electrical control on the machine - Two-hand operation and electrical connection for foot control - Control provided for electrical mold monitoring - Hydraulic diagram and electrical diagram available Space requirement L x W x H 1800 x 1200 x 2930 mm Weight approx. 4 tons good condition

Year of construction: 1986, condition: like new (used), Used PJ Hare ltd C frame hydraulic press for sale: Pj Hare Limited hydraulic press for sale PRESS MODEL: 25HP Overall Height MM: 2425 Overall Width MM: 1120 Overall Depth MM: 1470 Weight KG: 2000 Fixing Hole dio. MM: 18 Fixing Hole Centres MM x MM: 610 x 1108 Fixing Pad Size: MM x MM: 120 x 250 Oil Capacity L: 50 Air Supply Pressure Max bar: 6 Air Supply Pressure Min bar: 4 Main Motor Power kw: 7.5 Motor Fuse Rating A: 20 Complete with cushion Electrical Supply Details: Minimum Fuse Rating A: 35 Minimum Conductor Size mm: 2.5 PAGE 2: Model 25HP: Capacity Tons: 25 Capacity KN: 250 Ram Force Tons: 3.1 Ram Advance Speed: 425 Ram Pressing Speed: 35.1 Ram return Speed;289 Motor Racing KW:7.5 Weight KG Approx: 2000 Max Stroke: 150 Guard Aperture Width: 680 Guard Aperture Height: 300 Min. Shut Height: 200 Max. Daylight: 450 Shut Height Adjustment: 100 Throat Depth: 250 Bed Height: 900 Lrodehcfyujpfx Abvji Bed Width: 650 Bed Depth: 480 Front to Centre Line: 250 Clearance hole dia: 150 Clearance under bed: 350/ 250 Tee Slot Details: 18,15,34,33 Bed Thickness: 95 Side Chute Width: – Vert Chute Width: 255 Hole in Throat Width: 250 Hole in Throat Height: 250 Top Platen Width: 420 Top Platen Depth: 220 Top Platen Fixing Hole Details: 370, 170, 13 Tool Holder dia: 40 Tool Holder Length: 65 Fixing Hole dia: 18 Overall Depth: 1400 Overall Width: 900 Overall Height: 2450 Fixing Hole Centres: 1110 Hare presses for sale New c and h frame hydraulic presses for sale

Condition: new, Year of construction: 2021, pressing force: 17 t, Here are the technical data of the offered machine: If the press does not exactly match your requirement profile, please click to request an individual offer exactly according to your needs: Contact us for an individual offer HIDROBRASIL manufactures presses exactly according to your requirements at surprisingly low prices! Technical data + information: Hydraulic 17 T single column press Single column press with 17 T capacity, suitable for continuous shift operation, with these basic data: a) Traversing speed 10 mm/sec. downwards, b) opening speed up to 25 mm/sec c) starting pressing speed 10 mm/sec. d) table size 400x400 mm e) ram size 200x200 mm, with T grooves and central cylinder clamping f) Overall size approx. 1150x800x1750 mm g) oil temperature display on oil tank h) pressure adjustment from 5 T to 17 T ( adjustable by knob ) i) Hand lever operation with two speeds j) Machine body powder-coated, or double-painted k) Control cabinet supply line from above with 3000 mm cable and 16 Ampere plug l) assembly, commissioning, instruction against separate calculation Press design Single column press Thermally neutral 80 - 120 °C Number of operating sides 1 side Forces Press force max. ( at 250 bar ) 170 kN Free ripping force max. 10 kN Pressure build-up time Closed die Steel to steel Max. 2 sec. Dimensions Max. Opening width 250 mm Stroke and min. opening 100 mm Table height above floor 850 mm Height above floor (headroom) approx. 2200 mm Hall height min. 2.500 mm parallel deviation at 20°C +/- 0,1 mm Deflection Determined at max. clamping force with 70% occupancy < = 0.3 mm/m Weight Total weight of press without operating materials approx. 1 to Speeds Fast closing with 10 mmSec. Press speed 10 - 0 mmSec Sound pressure Sound pressure level, measured at 1.5m height at the control panel according to DIN 45635-T16-KL3 max. 78 db(A) Hydraulics Number of pressing cylinders 1 pcs. Operating pressure max. 250 bar Pressing pressure build-up time . 2 sec. Pressure accuracy during pressing stroke +/- 5 bar Main pump Gear pump approx. 6 L/min Oil volume approx. HLP 46 MW 100 liters Ambient temperature max. 40 °C Oil temperature max. 55 °C Flow temperature °C Electrical system Main supply 400 V AC Control voltage hydraulic pumps 24 24 V DC V DC Frequency 50 Hz Hydraulic connection Main motor 2.2 kW Total connection Approx. 3 kW Lrjdpjgrki Sjfx Abvoi Design The press is designed as an oil-hydraulic single-column press. The hydraulic system and the tank are located on the top and inside of the press, respectively. Hydraulic unit The hydraulic system is mounted on the top of the press. Safety devices For the scope of delivery described, the press complies with the valid safety regulations according to UVV, as well as with the standards and directives valid for the EU, in each case in the latest version. Electrical system / control system The control cabinet with control, power and safety components is located on the right side of the press. The press is operated by a hand lever control.

Condition: new, Year of construction: 2019, machine/vehicle number: DF0287, pressing force: 25 t, pressure:25 t passage width:1000 mm stroke:800 mm Weight of machine approx.:4 t dimensions:ca. 2054 x 2200 x 3126 mm return capacity:2 t :5 kW Max Working height:800 mm :80 mm/sec :10 mm/sec. :80 mm/sec Lodpefxyiksfx Abveri :800 mm pestle plate:400 x 400 mm table plate:1000 x 800 mm table height over floor:850 mm Table cut-out:650 x 150 mm :200 l pestle is stabilized by 4 per ø 50 mm chrome-plated linear guides:Bronzeführungen pestle strength:122 mm Steel plate on spring rolls:600 x 400 x 15 mm :S7 1200 Lightcurtains by Schmersal:1800 mm ab Boden Monitor:SIEMENS 10 Zoll Installation table on the left of the machine body with 10mm thick plage-milled steel plates:1000 x 800, 850 hoch mm

Condition: excellent (used), Year of construction: 1990, Force 25tons Throat 160mm Daylight 500mm Table size 650x650mm Lrodofcw Apspfx Abvsi Ram size round 140mm Stroke 130mm requested power 4 KW Weight 2000Kg height 2100mm width 1100mm depth 1500mm
