Condition: excellent (used), Year of construction: 2006, functionality: fully functional, Claimant: Kläger VBS 405 S Vertical Bandsaw / Metal Bandsaw Manufacturer: Kläger Type: VBS 405 S Condition: used, very good Year of manufacture: 2006 Cutting width: 400 Table tilt right/left: 45°/15° Table size: 607 x 607 mm Saw band width: 3-20 mm Saw band length: 3300-3400 mm Band speed: 15 – 300 m/min Length: 1120 mm Width: 740 mm Height: 1930 mm Dcjdpfx Afezmh Ugs Hok Weight: 510 kg – Ideal saw band welding device – Original documentation – Machine feet

Condition: ready for operation (used), Year of construction: 1992, Bandsaw with infeed. Dodpfozl Tiyjx Af Heck

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, cutting height (max.): 530 mm, cutting width (max.): 800 mm, rotational speed (max.): 120 rpm, overall weight: 3,500 kg, Automatic bandsaw with mitre function Dcodpfxezkrqts Af Hek Cutting range: 90° round 530 mm 90° flat 530 x 800 mm 45° flat 530 x 520 mm 30° flat 530 x 320 mm Cutting angle: 45°-0°-60° Saw motor: 3.0 kW Band speed: 20 - 120 m/min, infinitely variable Feed length: 1500 mm Features: Machine stand with chip collection tray, hydraulic cutting pressure adjustment Infinitely variable band speed, hydraulic guide arm adjustment Minimum quantity lubrication, shut-off at the end of the cut Chip brush, hydraulic mitre adjustment, hydraulic clamping device Hydraulic saw band tension, operating manual

Condition: ready for operation (used), Year of construction: 1975, functionality: fully functional, Band saw Wespa AS4 Vertical band saw WESPA, type AS 4 Year of manufacture approx. 1975 Wheel diameter 400 mm Overhang 380 mm Table size 610 x 610 mm Cutting height max. 245 mm Saw blade length min. 2800 - max. 3000 mm Saw blade speed 25-550 m/min, continuously variable Mains connection 400 volts, 50 Hz - Continuously variable saw blade speed via 2 gear stages and continuously variable belt drive - Saw table with longitudinal adjustment via handwheel with threaded spindle - Saw table tiltable - Adjustable fence for the saw table - Saw blade butt welding machine IDEAL BS 0-16 - Saw blade shear Dedpfszi Tphjx Af Hsck - Grinding wheel for grinding the weld seam - Air compressor with blow nozzle - Machine lamp Space requirement L x W x H 1100 x 800 x 1810 mm Weight 530 kg Good condition

Condition: used, roll diameter 400 mm throat 400 mm Dodpfx Afezhn U Ne Heck table-size 610 x 500 mm saw band length 2780 - 2980 mm turning speeds 22 - 147 m/min weight of the machine ca. 0,4 t dimensions of the machine ca. 0,6 x 0,8 x 1,9 m Bandsaw with - Ideal welding unit - Grinding unit - Machine light

Condition: excellent (used), Year of construction: 1960, roll diameter 250 mm throat 3380 mm throat 500 mm Dcodpfszd Hgcex Af Hjk cutting speed 15 - 900 m/min table surface area 600 x 600 mm total power requirement 1,1 kW weight of the machine ca. 0,8 t dimensions of the machine ca. 1,0 x 0,8 x 2,1 m 4 rolls of 30 m saw band included.

Condition: excellent (used), Saw blade length 3450 - 3640 mm Cutting height max. 325 mm Projection/cutting width 405 mm Table size 615 x 615 mm With Ideal BS0/16 saw blade welding device with blade shears and grinding stone Angle-adjustable machine table Cutting speed 16 - 2200 m/min Dedpfx Aszdqg Tjf Hock Very well maintained condition

Condition: good (used), Year of construction: 1997, 1 used vertical band saw Manufacturer: Jaespa Type: MSP 4 Year of manufacture: 1997 Roller diameter: 420 mm Cutting height: 280 mm Dcodpfx Afezb Izko Hsk Cutting width (overhang): 405 mm Cutting speed: 25-280 m/min Table size: 600 x 600 mm Tiltable: 15° / 45° Material support height: 955 mm Band length min/max: 3200/3400 mm Dimensions and weights Length: 1250 mm Width: 1000 mm Height: 2030 mm Net weight: 470 kg

Condition: used, functionality: fully functional, Used HESKA vertical bandsaw ESU 4 Overhang: 400 mm Table size: 650 x 650 mm Maximum band length: 3400 mm Minimum band length: 3200 mm Includes bandsaw blade welding machine IDEAL, with grinding motor and machine light. Dsdpfszb Ircsx Af Hock Delivery time: available from stock; the machine can be inspected by appointment in 71334 Waiblingen-Beinstein.

Condition: used, Year of construction: 1977, roll diameter 420 mm throat 410 mm workpiece height 265 mm width of saw-band 3 - 25 mm cutting speed 12 - 375 m/min table surface area 600 x 600 mm Dcsdpsy T Sdbsfx Af Hjk total power requirement 1,7 kW weight of the machine ca. 0,6 t dimensions of the machine ca. 1,0 x 0,9 x 1,9 m

Condition: as good as new (ex-display), Year of construction: 2024, Universal machines for a wide range of applications Dodpfx Afsy T N Nnj Heck Reliable and robust band sawing machines, machines for a long service life

Condition: used, For sale: MEP PH 261-1HB band saw for metal. The machine is used, in good condition and fully operational. Inspection and testing on site is possible. The MEP PH 261-1HB is a professional manual gravity band saw for metal, designed for cutting tubes, profiles, and solid materials. The HB system enables automatic descent cutting without operator intervention. Specifications: Model: MEP PH 261-1HB Mitre cutting range: 0° to +60° Cutting capacities: 0° – Ø225 mm, 200 x 200 mm, 240 x 160 mm +45° – Ø160 mm, 140 x 140 mm, 155 x 115 mm +60° – Ø90 mm, 90 x 90 mm Maximum vise opening: 245 mm Blade dimensions: 2450 x 27 x 0.9 mm Blade speed: 46 / 92 m/min Motor power: 0.94 / 1.1 kW Working table height: 950 mm Dcsdsy R Sgwjpfx Af Hjk Machine weight: approx. 240 kg Cast iron construction for reduced vibration and increased cutting precision Quick mitre adjustment Suitable for cutting steel, stainless steel, aluminium, and other metals For more information: MEP PH 261-1HB Professional Italian machine for workshops, production, and metalworking companies. If you have any further questions, we will be happy to assist you.

Condition: used, Technical details: dimensions of saw-band: 5750 mm throat: 605 mm workpiece height: 460 mm max. table load: 250 kg table - inclinable: 15 -30 Grad band speed: 27 - 2200 m/min table height: 1125 mm Table dimensions: 740 x 785 mm motor capacity: 5,5 kW Dcsdey Rm T Espfx Af Hok machine weight approx.: 1750 kg dimension machine xH: 1,82 x 0,97 x 2,55 m

Condition: good (used), Year of construction: 1980, Bandsaw blade dimensions: recommended size 3400 / 3200 mm Cutting width: 400 mm Bandsaw blade length min./max.: 3200 / 3400 mm Bandsaw blade width: 20 x 3 mm Cutting speed: 10 - 2150 / 8 steps (manual) m/min Table size: 670 x 670 mm Table height above floor: 1020 mm Table tilting +/-: left 10° and right 30° Table movement horizontal: 270 mm Dsdpfxey H Iiae Af Hjck Total power requirement: approx. 1.5 kW Machine weight approx.: 650 kg Machine dimensions (LxWxH): 1.2 x 1.05 x 2.0 m

Condition: used, Year of construction: 2014, Vertical band saw machine Brand: JAESPA Model: MSU 4 Machine No. 23690.14 – workshop tested Year of manufacture: 2014 Infinitely variable band speed from approx. 16 to 2,200 m/min Saw band length: 3,450 – 3,640 mm Saw band width: up to max 20 mm Accessories: - IDEAL band welding unit with electronic annealing current regulation with shear and grinding motor Dsdpfxsy E Iwus Af Heck - Chip blow-out device with stepless adjustment - Brass chip cleaning brush new and included as spare - CE conformity declaration - Operating manual Safety equipment: - Main emergency stop switch - Emergency stop switch - Band wheel doors electrically secured - Saw blade guard - Limit switch for saw band breakage Used as seen, without warranty The machine technically conforms to current safety regulations.

Condition: used, roll diameter 420 mm throat 420 mm workpiece height 300 mm table-size 610 x 610 mm saw band length 3150 - 3260 mm turning speeds 12 - 750 m/min weight of the machine ca. 0,4 t dimensions of the machine ca. 1,2 x 0,8 x 2,0 m Dodsy Ezzgjpfx Af Hjck Band saw with - Ideal welding machine - Grinding machine

Condition: new, roll diameter / mm throat / mm Dodjy Eh A Depfx Af Hsck workpiece height / mm Vertical band saw – Model P70.110 Capacity 90° (mm) Height: 700 mm Width: 1100 mm Length: 6000 mm Motors Main motor (saw blade drive): 5.5 kW Hydraulic motor: 1.5 kW Coolant pump: 0.25 kW Feed servo motor: 1.5 kW Chip conveyor: 1.1 kW Further technical data Saw blade size: 7770 × 54 × 1.6 mm Material feed height: 1440 mm Hydraulic oil tank capacity: 40 l Coolant tank capacity: 190 l Machine dimensions (H × W × L): 4500 × 4000 × 8700 mm Weight: 20,000 kg Standard equipment - Hydraulically driven chip brush - Speed control device (belt speed adjustable via frequency converter) - Servo feed system (1–500 mm/min) - Hydraulic saw blade tensioning - Saw blade break detection and stop system - Touchscreen user interface - Laser line display (laser marking) - Scraper-type chip conveyor - Hydraulically movable arm (automatic) - Chip trolley / chip container - Material alignment piston (for aligning the material) The images are for guidance only and are not a true-to-scale representation of the machine.

Condition: used, Year of construction: 1982, Technical details: dimensions of saw-band: 3920 - 4050 mm throat: 500 mm workpiece height: 400 mm table - inclinable: 15 - 30 Grad Cutting height: 400 mm band speed: 15 - 940 m/min Table dimensions: 800 x 820 mm mm Dsdpfxsyzpkno Af Hsck machine weight approx.: 1000 kg dimension machine xH: 1,3 x 1,3 x 2,2 m

Condition: good (used), Internal item no.: 25123 Bandsaw Mössner Rekord Type: SSF / 420 Dcodpfx Ajyxpa Rof Hjk + Saw blade welding device + Feed mechanism + Spare saw blades Blade length: min. 3150mm / max. 3300mm Table: 600 x 500mm (tilting) Cutting width: max. 410mm Cutting height: max. 230mm Dimensions (LxWxH): 80 x 100 x 185cm Weight: approx. 800kg

Condition: used, Year of construction: 1992, hollow 770 mm 450 mm 800 mm Table dimensions 900 x 900 mm table height 1000 mm Table tiltable 15 Grad cutting speed 2500 - 3600 m/min sawblade width 35 mm Dodpfx Aoyv I Rpjf Hsck sawblade length 5450 - 5600 mm weight of the machine ca. 1250 kg dimensions 1900 x 1200 x 2470 mm

Condition: excellent (used), Year of construction: 2020, machine/vehicle number: 06220420, functionality: fully functional, operating hours: 100 h, power: 7 kW (9.52 HP), input voltage: 380 V, input frequency: 50 Hz, cutting width (max.): 460 mm, control type: NC control, actuation type: hydraulic, rotational speed (max.): 80 rpm, rotational speed (min.): 20 rpm, total height: 1,900 mm, total length: 2,820 mm, total width: 2,200 mm, overall weight: 2,300 kg, Equipment: documentation/manual, Double-column structure, with a round-section main sliding column and a rectangular-section secondary column. CNC with touch-screen for programming the head lift, clamping, and piece feeding, inverter-controlled blade speed adjustment, and a feed repeater settable from 1 to 9 times. Blade descent controlled by a probe, workpiece feed roller conveyor. Carbide blade guides and bearings, hydraulically locking clamps, auger chip conveyor, coolant system, lighting system, motorized blade cleaning brush, hydraulically adjustable belt tension. Djdpsyvh Nxofx Af Hsck Operation and maintenance manual. With Extra 2m roller table 1pc (500mm width) NO CE mark, NO CE declaration of conformity

Condition: used, Year of construction: 2021, functionality: unexamined, Metal Band Saw Automatic Daiß + Partner HBA 320 SG Power-Line, HBA 320 SG Power-Line, Year of complete overhaul: 2021, mitre saw in 2-column design, drive power: 240/400 Volt, 2.2 kW frequency motor, cutting speed: 15 - 105 m/min, reinforced gearbox for high cutting performance, hydraulic system flow rate l/min, electrics: 240/400 Volt, 50 Hz three-phase power, control voltage: 24 Volt DC, automatic feed length: 8,400 mm (in combination with PS 210: 600 mm), multiple feed standard: 2-fold, maximum workpiece support weight: 2000 kg, maximum transport force: 1000 kg, transport frame repeat accuracy: approx. 0.02 - 0.04 mm, mitre cut angle accuracy: approx. 0.05 mm at 100 mm diameter for St 37 material, saw blade dimensions: 4400 x 34 x 1.1 mm, blade tension: constant tension via spring set, weight: 2330 kg. Dimensions (L x W x H), Features: - 1 control cabinet opposite - 1 CNC control PS 95 - 2600 x 2200 x 1950 mm - 2-axis control for feed and mitre adjustment Dodpfx Afeyr Ifwo Hsck - 1 frequency drive 2.2 kW - 1 Daiß+Partner Power-Box - 1 motor-driven chip brush - 1 stepless drive via frequency converter motor - 1 micro-cooler instead of coolant unit - 1 hydraulic blade tensioning - 1 saw blade breakage monitoring - Inspection under power possible

Condition: ready for operation (used), Year of construction: 2007, cutting diameter 320 mm saw band length 3400 x 27 x 0.9 mm capacity 90 degrees: flat 320 x 400 mm capacity 45 degrees: flat LI 320 x 280 mm capacity 45 degrees: flat RE 320 x 260 mm capacity 60 degrees: flat RE 320 x 140 mm band speed 35 + 70 m/min work height max. 930 mm voltage 400 V total power requirement 2.67 kW weight 950 + 250 kg well-maintained condition (!!) current new price incl. accessories ~ 40.000 Euro special price on request - in checked conditions - machinevideo - ?v=AHgMDxAcpgE Equipment: - electro-hydraulic vertical mitre bandsaw - with large cutting range and small footprint - Robust material support table - miter cuts are carried out fully automatically Dcedpfx Afoym D Drs Hek * electro-hydraulic miter adjustment left right - Up to 99 cutting programs - Central operation of all machine functions from the front - Loading also possible from above - Precise positioning thanks to accurate measuring system - electro-hydraulic miter adjustment left right - Electro-hydraulic material clamping - electro-hydraulic infeed from the saw arm * steplessly adjustable (cutting pressure control) - Operating instructions (PDF) * Special accessories included : - BAUER material feed unit - Micro-dosing device (spray oiler)

Condition: good (used), Stock number: 3077 Manufacturer: Ruhla Year of manufacture: Machine number: Type / Model: SgMB 400 Table: 550 x 570 mm Throat: 400 mm Dcjdsyk Hdvjpfx Af Hsk Clearance height: 200 mm Roller diameter: 400 mm Table: tiltable and swiveling Band length min/max: approx. 3,000 mm Band speed: 16 to 710 m/min Accessories/Equipment: without welding unit Condition: good Weight: 0.62 t Dimensions: 700 x 1,000 x 1,900 mm

Condition: used, Year of construction: 2025, cutting diameter max. 225 mm saw band length 2.480 mm width of saw-band 27 mm dimensions of saw-band 2.480 x 27 x 0,9 mm cutting angle 0 - 60 ° band speed 20 - 90 m/min Cuttingrange 90° max. 225 mm capacity 90 degrees: square 190 mm capacity 90 degrees: flat 150 x 245 mm capacity 60 degrees: round 90 mm Djdpfjykb Enex Af Heck capacity 60 degrees: square 90 mm capacity 60 degrees: flat 120 x 90 mm capacity 45 degrees: round 145 mm capacity 45 degrees: square 150 mm capacity 45 degrees: flat 190 x 150 mm total power requirement 1,5 kW weight of the machine ca. 185 kg dimensions of the machine ca. 1,5 x 1,2 x 1,6 m Metal Bandsaw OPTIMUM - OPTIsaw S 275 PV
