Condition: reconditioned (used), Year of construction: 2002, travel distance X-axis: 16,000 mm, travel distance Y-axis: 3,200 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 15,000 m/min, rapid traverse Y-axis: 15,000 m/min, rapid traverse Z-axis: 15,000 m/min, spindle speed (max.): 4,000 rpm, spindle speed (min.): 20 rpm, 100% Retrofit by Dornhöfer The Difference. Including installation and commissioning! Year of manufacture: 2002 Control: Heidenhain TNC 640 / TNC 7 Iaelhjv S Upfeccqler Travel: X-axis (mm) 16,000* (see below) Y-axis (mm) 3,200 Z-axis (mm) 1,500 Spindle speed range: 20–4,000 rpm Feed rates: X, Y & Z axes (mm/min): 2–12,000 Max. rapid traverse speed X, Y & Z axes (mm/min): 15,000 Milling head: Automatic milling head, orthogonal H10, 1° pitch Tool holder: ISO 50, DIN 69871 AD Main spindle drive power: 100% duty cycle KW37 - Automatic tool changer with 60 magazine positions - Coolant system with 20 bar & (IKZ) - Chip conveyor, floor ejection - Ergonomic operator platform - Hazardous area protection - 3D thermal expansion compensation - INA linear guides *Adaptive X-axis length: We supply the machine bed in the length you require, up to a maximum of 16,000 mm. 100% RetroFIT – our core business! For us, it means offering a machine that can only be compared to a new product, but also offers you many other advantages: Latest CNC control technology with proven machine stability Significant CO₂ savings compared to a new machine Shorter delivery times Often savings on complex foundation costs Significantly lower investment costs All mechanical components (e.g., ball screws, guides, rolling bearings, etc.) have been renewed. Our designers designed the entire electrical peripherals (such as the most modern drive, control, and regulation technology) using the most efficient technologies. This was implemented using new cabling and a completely new control cabinet, as well as the latest Heidenhain control system with a wide range of innovative options. The completely new and innovative hydraulic concept meets the most modern requirements and achieves maximum efficiency. The machine's visual appearance is in no way inferior to a new machine thanks to its refurbishment: The entire machine was first disassembled down to every screw, sanded, primed, and then painted with a robust 2K EP paint. We equipped the machine with a safety concept that is individually tailored to the needs of the operator. We offer the highest level of safety, flexibility, and ergonomics. You receive a state-of-the-art machine combined with significant CO₂ savings.

Condition: reconditioned (used), Year of construction: 2012, Functionality: fully functional, travel distance X-axis: 10,500 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 25,000 m/min, rapid traverse Y-axis: 25,000 m/min, rapid traverse Z-axis: 25,000 m/min, spindle speed (max.): 4,000 rpm, spindle speed (min.): 20 rpm, table length: 12,000 mm, table width: 1,350 mm, year of last overhaul: 2025, RepaitFIT by Dornhöfer The difference. Including installation and commissioning! Technical details of the machine: Year of manufacture: 2012 Control: Heidenhain iTNC 530 Travel range: X-axis (mm) 10,500 Y-axis (mm) 2,000 Z-axis (mm) 1,500 Table size: Length: 12,000 Width: 1,350 Spindle speed range: 20–4,000 rpm Feed rates: Max. rapid traverse speed X, Y & Z axes (mm/min): 25,000 Milling head: Orthogonal milling head, 1° pitch H41 Tool holder: ISO 50, DIN 69871 Form AD Main spindle drive power: 100% duty cycle 43 kW - Chip conveyor - Internal coolant system (Lubrix) - Automatic tool changer with 40 magazine positions - Portable HEIDENHAIN HR 410 electronic handwheel - 3D thermal expansion compensation Iaelhcev R Tpujcqljr - Heidenhain interpolation turning RepairFIT is our proven offering for a profitable entry into our product lines. The machines available in this line are procured by us following a rigorous selection process and subjected to a thorough inspection (deep dive check). After intensive cleaning, any obvious defects and faults identified are professionally repaired by our expert service team.

Condition: reconditioned (used), Year of construction: 2007, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 1,000 mm, table width: 1,500 mm, table length: 3,750 mm, 100% Retrofit by Dornhöfer The Difference. Including installation and commissioning! Year of manufacture: 2007 Control: Heidenhain TNC 640 Travel: X-axis (mm) 3,500 Iajlhcsv R Hxpecqlsr Y-axis (mm) 1,400 Z-axis (mm) 1,000 Spindle speed range: 20–3,000 rpm Milling head: Automatic milling head, diagonal H26 2.5° x 2.5° Tool holder: ISO 50, DIN 69872 AD Main spindle drive power: 28 kW Maximum spindle speed: 3,000 -Chip conveyor -Cooling lubricant system -3D thermal expansion compensation -Automatic tool changer with 60 magazine positions -Movable control panel -Complete splash guard (fully enclosed) -NC rotary table 1,000 mm x 1000mm 100% RetroFIT – our core business! For us, it means offering a machine that can only be compared to a new product, but also offers you many other advantages: Latest CNC control technology with proven machine stability Significant CO₂ savings compared to a new machine Shorter delivery times Often savings on expensive foundation costs Significantly lower investment costs All mechanical components (e.g., ball screws, guides, roller bearings, etc.) have been renewed. Our designers designed the entire electrical peripherals (such as the most modern drive, control, and regulation technology) using the most efficient technologies. This was implemented using new cabling and a completely new control cabinet, as well as the latest Heidenhain control system with a wide range of innovative options. The completely new and innovative hydraulic concept meets the most modern requirements and achieves maximum efficiency. The machine's visual appearance is in no way inferior to that of a new machine thanks to its refurbishment: The entire machine was first disassembled down to every screw, sanded, primed, and then painted with a robust 2K EP paint. We have equipped the machine with a safety concept that is individually tailored to the needs of the operator. We offer the highest level of safety, flexibility, and ergonomics. You get a state-of-the-art machine combined with significant CO₂ savings.

Condition: reconditioned (used), Year of construction: 2015, Functionality: fully functional, travel distance X-axis: 10,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 25,000 m/min, rapid traverse Y-axis: 25,000 m/min, rapid traverse Z-axis: 25,000 m/min, spindle speed (max.): 4,000 rpm, RepaitFIT+ by Dornhöfer The difference. Including installation and commissioning! MAIN TECHNICAL DATA Year of manufacture: 2015 Capacities / Travel: Longitudinal (X): 10,000 mm Vertical (Y): 3,000 mm Transverse (Z): 1,500 mm Paint finish: Graphite gray RAL 7024 / Agate gray RAL 7038 Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Form A Taper: DIN 69871 Iaolhccqsv R Hwrjler Main drive: Motor / Make: Siemens Main spindle drive Tap: 1PH7 Maximum drive power: From 198 rpm 100% duty cycle KW41 Maximum torque: Constant up to 198 rpm 100% duty cycle 1920 Nm Speed control / Gearbox: 3-stage (oil-cooled) With automatic Switching Spindle speeds 4000 rpm: low range rpm 0 - 516 medium range rpm 460 - 1,288 high range rpm 1,200 - 4,000 Axis drives/axis feeds: Axis drive motors: Maximum rapid traverse: (X/Y/Z axis) 25,000 mm/min Maximum working feed: (X/Y/Z axis) 15,000 mm/min Maximum feed force: (X-axis) 35,000 N (Y/Z axis) 32,000 N Axis drive systems: X-axis (longitudinal) pinion/rack (Atlanta brand) Y-axis (vertical) ball screw (preloaded) Ø 63 x 20 Z-axis (transverse) Ball screw (preloaded) Ø 50 x 20 Weight: (without clamping table/plate area) approx. 49,500 kg Connection cable: approx. 60 kVA Innotrol HBG wireless handwheel Automatic tool changer with 60 magazine positions BIG Plus tool spindle Operator platform with height adjustment of 1800 mm and transverse adjustment of 800 mm Interface for adapter milling heads RepairFIT+ – what does it mean? With RepairFIT+, we offer you a profitable and safe entry into our product lines. Our machines undergo a rigorous selection process, undergo a comprehensive deep-dive inspection, and are thoroughly cleaned by our experts. All identified defects, both technical and cosmetic, are professionally repaired so that the machine is presented in perfect condition.

Condition: reconditioned (used), Year of construction: 2015, Functionality: fully functional, travel distance X-axis: 8,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,500 mm, feed rate X-axis: 15,000 m/min, feed rate Y-axis: 15,000 m/min, feed rate Z-axis: 15,000 m/min, spindle speed (max.): 6,000 rpm, coolant supply: 20 bar, RepaitFIT+ by Dornhöfer The difference. Including installation and commissioning! Ijlhov R Hqreccqlear MAIN TECHNICAL DATA Year of manufacture: 2015 Capacities / Travel: Longitudinal (X): 8,000 mm Vertical (Y): 3,000 mm Transverse (Z): 1,500 mm Main spindle drive: Motor / Make: Siemens main spindle drive type: 1PH7 Maximum drive power: 41 kW Maximum torque: 1,055 Nm Speed control / Gearbox: 3-stage (oil-cooled) with automatic switching Spindle speeds 6,000 rpm: Low range: 0-918 rpm Medium range: 919-2,404 rpm High range: 2,405-6,000 rpm Axis drives / axis feeds: Axis drive motors: SIEMENS (digital) Drives) Maximum rapid traverse: (X/Y/Z axis) 25,000 mm/min Maximum working feed: (X/Y/Z axis) 15,000 mm/min Maximum feed force: (X-axis) 35,000 N (Y/Z axis) 35,000 N Drive systems: X-axis (longitudinal) pinion/rack (Atlanta brand) Y-axis (vertical) ball screw (preloaded) Ø 63x20 Z-axis (transverse) ball screw (preloaded) Ø 50x20 Machine weight: Weight FBF-M 8000 kg 41,000 without clamping table/plate array Connected load: KVA approx. 60 Paint finish: sky blue RAL 5015 / light gray RAL 7035 Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Form A HEIDENHAIN iTNC 530 HSCI Automatic MTE Diagonal milling head Automatic tool changer Cooling lubricant system with 20 bar & (internal coolant supply) Frequency control for coolant pump Air cooling through the spindle Operator platform with height adjustment of 2,300 mm and transverse travel of 800 mm Heidenhain HR 550 FS wireless handwheel Special operating mode (operating mode 4) RepairFIT+ – what does that mean? With RepairFIT+, we offer you a profitable and safe entry into our product lines. Our machines undergo a rigorous selection process, undergo a comprehensive deep-dive check, and are thoroughly cleaned by our experts. All identified defects, both technical and visual, are professionally repaired so that the machine is presented in perfect condition.

Condition: reconditioned (used), Year of construction: 2005, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 1,200 mm, rapid traverse X-axis: 20,000 m/min, rapid traverse Y-axis: 20,000 m/min, rapid traverse Z-axis: 20,000 m/min, feed rate X-axis: 10,000 m/min, feed rate Y-axis: 10,000 m/min, feed rate Z-axis: 10,000 m/min, spindle speed (max.): 4,000 rpm, spindle speed (min.): 20 rpm, table width: 3,860 mm, table length: 1,200 mm, RepairFIT by Dornhöfer The Difference. Including installation and commissioning! Technical details of the machine: Year of manufacture: 2005 Control: Heidenhain iTNC 530 Travel range: X-axis (mm) 3,500 Y-axis (mm) 1,400 Z-axis (mm) 1,200 Table size: Length: 3,860 Width: 1,200 Spindle speed range: 20–4,000 rpm Feed rates: X, Y & Z axes (mm/min): 2–10,000 Max. rapid traverse speed X, Y & Z axes (mm/min): 20,000 Milling head: Automatic milling head, diagonal H200 Tool holder: ISO 50, DIN 69871 Form AD Main spindle drive power: 100% duty cycle 28 kW - Chip conveyor - Cooling lubricant system 15 bar & IKZ - Automatic tool changer with 30 magazine positions RepairFIT is our proven offering for a profitable entry into our product lines. Ielhev Rxbveccqlear The machines available in this line are procured by us following a rigorous selection process and subjected to a thorough inspection (deep dive check). After intensive cleaning, any obvious defects and faults identified are professionally repaired by our expert service team.

Condition: reconditioned (used), Year of construction: 2008, Functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,000 mm, rapid traverse X-axis: 25,000 m/min, rapid traverse Y-axis: 25,000 m/min, year of last overhaul: 2025, RepairFIT by Dornhöfer The Difference. Including installation and commissioning! Technical details of the machine: Year of manufacture: 2008 Control: Heidenhain iTNC 530 Travel range: X-axis (mm) 2,500 Y-axis (mm) 1,250 Z-axis (mm) 1,000 Rotary table size: Length (mm) 1,000 Width (mm) 1,000 Spindle speed range: 15,000 rpm Feed rates: X, Y & Z axes (mm/min): 10 - 10,000 Max. rapid traverse speed X, Y & Z axes (mm/min): 25,000 Milling head: Automatic milling head, vertical Tool holder: HSK 63 A Main spindle drive power: 100% duty cycle KW25 - Chip conveyor - Cooling lubricant system - 3D thermal expansion compensation - Portable electronic handwheel Heidenhain HR 410 with 3m spiral cable - INA RUE 45 linear guideway system on all linear axes with central lubrication - Complete splash guard enclosure Iaolhccov Rw Uusqlor RepairFIT is our proven offering for a profitable entry into our product lines. The machines available in this line are procured by us following a rigorous selection process and subjected to a thorough inspection (deep dive check). After intensive cleaning, any obvious defects and faults identified are professionally repaired by our expert service team.

Condition: reconditioned (used), Year of construction: 2005, Functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, rapid traverse X-axis: 10 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 10 m/min, feed rate X-axis: 4 m/min, feed rate Y-axis: 4 m/min, feed rate Z-axis: 4 m/min, table width: 1,000 mm, table load: 5,000 kg, table length: 3,000 mm, overall weight: 16,500 kg, year of last overhaul: 2024, RepairFIT by Dornhöfer The Difference. Including installation and commissioning! MAIN TECHNICAL DATA Year of manufacture: 2005 Capacities / Travel: Longitudinal (X): 3,000 mm Vertical (Z): 1,000 mm Transverse (Y): 1,000 mm Table size: Length: 3,200 mm Width: 1,000 mm Number of T-slots on the table surface: 7 T-slot width: 22H12 mm Max. table load: 5 t/m² Paint finish: RAL 5010 and RAL 9002 Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Form A Main drive: Drive power: 100% duty cycle KW30 Spindle speed range: Iaolhouq Epioccqlor Spindle speed: min-1 20-3,000 Speed control: via gear box Feed rates: X, Y, and Z axes mm/min 4,000 Max. Rapid traverse speed: X, Y, and Z axes mm/min 10,000 Weight: approx. 16,500 kg BASIC MACHINE EQUIPMENT: HEIDENHAIN iTNC 530 HSCI Manual diagonal head Chip conveyor Cooling lubricant system with 20 bar & (IKZ) RepairFIT is our proven offering for a profitable entry into our product lines. The machines available in this line are procured by us following a rigorous selection process and subjected to a thorough inspection (deep dive check). After intensive cleaning, any obvious defects and faults identified were professionally repaired by our expert service team.

Condition: refurbished (used), Year of construction: 2007, Functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,200 mm, rapid traverse X-axis: 25 m/min, rapid traverse Y-axis: 25 m/min, rapid traverse Z-axis: 25 m/min, feed rate X-axis: 10 m/min, feed rate Y-axis: 10 m/min, feed rate Z-axis: 10 m/min, spindle speed (max.): 4,000 rpm, spindle speed (min.): 20 rpm, table width: 850 mm, table load: 5,000 kg, table length: 2,700 mm, overall weight: 15,500 kg, year of last overhaul: 2024, RefurbishmentPLUS by Dornhöfer The difference. Including installation and commissioning! MAIN TECHNICAL DATA Year of manufacture: 2007 Capacities / Travel: Longitudinal (X): 2,500 mm Vertical (Y): 1,250 mm Cross (Z): 1,200 mm Table size: Length: 2,700 mm Width: 850 mm Number of T-slots on the table surface: 6 T-slot width: 22H12 mm Reference slot: 22H8 mm Distance between slots: 140 mm Max. table load: 5 t/m² Paint finish: RAL 5011 (steel blue) and RAL 7035 (light gray) Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 form A Main drive: Drive power: 100% duty cycle KW24 Spindle speed range: Spindle speed: 20-4,000 rpm Torque: 479 Nm Feed rates: X, Y, and Z axes mm/min 10-10,000 Max. rapid traverse speed: X, Y, and Z axes mm/min 25,000 Weight: approx. 15,500 kg BASIC MACHINE EQUIPMENT: Heidenhain iTNC 530 HSCI Automatic milling head, diagonal H200 Chip conveyor Coolant system STANDARD EQUIPMENT: - Portable electronic handwheel HR 510 with 3m spiral cable - Hydraulic counterbalance acting directly on the vertical slide - 3D thermal expansion compensation for Heidenhain CNC contouring controls - Complete splash guard enclosure consisting of two front doors and one rear door for operating the machine from the front and rear. All doors are equipped with viewing windows. - Heidenhain AC drive motors in all axes with diagonal drive technology - INA RUE 45 linear guideway system in all axes with central lubrication - Ball screws (IT5) in all axes - Heidenhain direct linear measuring system in all axes - Telescopic covers for the X-axis guideways - Automatic cyclic lubrication for all axes and motion components Ielhccqjun Nnqeloar - Work area lighting Refurbishment+ – what does that mean? The RefurbishmentPLUS line offers you a machine that has been uncompromisingly restored to its original technical and visual condition. All assemblies have been completely disassembled, repainted, and rebuilt with new, original spare parts. Cables, hydraulics, guides, spindles, rolling bearings – everything new!

Condition: reconditioned (used), Year of construction: 2002, Functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 1,200 mm, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 15 m/min, feed rate X-axis: 12 m/min, feed rate Y-axis: 12 m/min, feed rate Z-axis: 12 m/min, spindle speed (max.): 3,000 rpm, table width: 1,200 mm, tool mount: 50 mm, power: 0.028 kW (0.04 HP), SORALUCE TR-25 included installation and commissioning Year of manufacturing: 2002 Capacities / travel: Axis (X): mm 2.500 Vertical (Y): mm 1.600 Ram (Z): mm 1.200 Table size: Length: mm 2.860 Width: mm 1.200 Painting: RAL 5005 and RAL 7035 Tool taper: ISO 50, DIN 69871 Form AD Main Spindle Drive: Power: 100 % ED KW28 Spindle speed range: Spindle speed: rpm-1 20-3.000 Feeds: X-, Y- und Z-Axis mm/min 2 – 12.000 Ijljrp H D Tshccqljar Max. rapid traverse speed: X-, Y- und Z-Axis mm/min 15.000 Weight: kg 22.200 Heidenhain 426 Heidenhain CNC control 426M with digital drive technology, electronic handwheel HR410 Automatic Milling Head, Diagonal H26 Automatically indexing Soraluce "Diagonal" milling head, type H26 including a long spindle for internal coolant supply. 2.5° division in both joints and speeds up to 3000 rpm. Clamping via Hirth serration in both joints. Repeatability of +/-3 sec. or 0.002mm. FAG spindle bearing with steel balls. Includes air lock. Chip Conveyor Automatic Tool changer: Maximum Tool Diameter: 125 mm Max. Tool Diameter with Adjacent Slots Free: 250 mm Maximum Tool Length: 400 mm Maximum Tool Weight: 20 kg Number of Magazine Slots: 40 Coolant lubrication system internally cooling 3D thermal expansion compensation Splash guard Our product line: RepairFIT RepairFIT is our proven offer for a profitable entry into our product lines. The machines available in this line have been procured by us following a strict selection process and have undergone a thorough examination (Deep-Dive-Check). After intensive cleaning, any detected and obvious defects or errors have been professionally repaired by our expert service team. What does this mean for you? A RepairFIT offer is ideal for you if you're looking for a used machine while also wanting guaranteed process safety. With this option, you receive a high-quality CNC milling machine that is immediately ready for error-free operation. With our professional service technicians, we implement the commissioning in your premises in the shortest possible time. You can start production right away. This is a clear difference from an ordinary used machine purchase. This solution offers you guaranteed process and planning reliability at an attractive fixed price Project Execution: Benefit from our turnkey project execution, which is included in all lines: Our team of experts provides comprehensive support in optimally determining the machine's location, creating a professional layout, and fully integrating it into your manufacturing process. We ensure that your CNC milling machine is expertly installed, commissioned, and precisely aligned according to the manufacturer's specifications! All from a single source, in the end, simply a process-reliable machine that does what it's supposed to do.
