Kazi-Tani S.a.s.

Condition: ready for operation (used), Technical characteristics Cutting capacity : 5300 x 2200 mm Cutting thickness : 80 mm Horizontal cutting height : 2100 mm Built-in suction device Manual or automatic feed 4 feed speeds Intermediate support along entire length of frame Leleu Hb D Ajhccqljri 2 reference stops liftable frame for horizontal cutting Power and Motors Voltage: 380 V Pluging: Three-phased Power: 5,5 Kw Overall dimensions

Condition: ready for operation (used), Technical characteristics Set of six plating frames Inside width : 1350 mm Max. plating height : 450 mm 5 pressers per frame Manual clamping of the pressers Chassis can be freely arranged according to length of parts to be veneered Power and Motors Lrelhccsutxndjqloi Overall dimensions

Condition: ready for operation (used), Technical characteristics Power and Motors Voltage: 380 V Pluging: Three-phased Power: 5 Kw Lrjlheutxnkeccqlsi Motor: 6,5 CV Overall dimensions

Condition: ready for operation (used), Technical characteristics Power and Motors Voltage: 380 V Lrjleutxnqohccqlsi Pluging: Three-phased Overall dimensions

Condition: ready for operation (used), Technical characteristics Power and Motors Voltage: 400 V Pluging: Three-phased Power: 12,5 Kw Overall dimensions Lenght: 4388 mm Width: 1165 mm Height: 1385 mm Weight: 1200 Kg Lrolhceupqb Uscqlsi

Condition: ready for operation (used), Technical characteristics Cast-iron frame Solid flywheel diameter 930 mm Max. cutting height : 550 mm Max. cutting width : 910 mm Blade dimensions : 6580 to 6670 x 90 x 0.9 mm Blade guide Cast-iron table dimensions : 860 x 1100 mm Table inclination : 0 to 20 degrees 11 kW (15 hp) motor Robust, enclosed machine 2 suction nozzles diameter : 140 mm Steel toothed feeder Power and Motors Voltage: 400 V Pluging: Three-phased Power: 12 Kw Motor: 15 CV Overall dimensions Lenght: 1880 mm Height: 2860 mm Weight: 990 Kg Lslhcceupbn Soqlori

Condition: ready for operation (used), Technical characteristics En cours de vérification Sanding motor : 4 hp 2 speeds : 14 and 28 m/sec Carriage length : 3000 mm Table width : 800 mm Vertical table travel : 535 mm Parallelogram sanding pad (width 150 mm) Belt length : 8000 mm Belt width : 150 mm Electric raising/lowering Suction outlets : 1 x ø 100 mm 1 x ø 140 mm Lolhccqjupbpcjljri Power and Motors Voltage: 380 V Pluging: Three-phased Power: 6 Kw Motor: 4 CV Overall dimensions Lenght: 4500 mm Width: 1600 mm Height: 1450 mm Weight: 549 Kg

Condition: ready for operation (used), Technical characteristics Radial table saw Table dimensions : 1150 x 1120 mm Motor power 2.9 kW (4 hp) Max. blade diameter : 350 mm Blade bore : 30 mm 90° cutting dimensions : 660 x 105 mm Cutting dimensions at 45° : 480 x 105 mm Cast-iron gooseneck : 1300 mm Suction nozzle : 120 mm Power and Motors Voltage: 380 V Pluging: Three-phased Power: 4 Kw Motor: 4 CV Lrjlsun Eg Ashccqlji Overall dimensions Lenght: 2070 mm Width: 1650 mm Height: 1730 mm Weight: 400 Kg

Condition: ready for operation (used), Technical characteristics 2 knives per head Maximum profile height : 110 mm Maximum crimping knife height : 90 mm 3 vertical pressers Lrslhccqjundfdjloi Table width : 830 mm Aluminium table extensions Length : 1100 mm Foot pedal control Power and Motors Voltage: 400 V Pluging: Three-phased Overall dimensions

Condition: ready for operation (used), Technical characteristics Upper vertical spindle 12000 rpm Pneumatic workpiece clamping Jig and copy finger 8 mm collet Stop in X and Y Useful strokes: X = 310 mm, Y = 120 mm, Z=175 mm Lrjlhccqeundg Ijlji Clamping 175 x 230 mm Spray nozzle Recent machine in perfect condition, first hand Power and Motors Voltage: 400 V Pluging: Three-phased Power: 0,75 Kw Motor: 1 CV Overall dimensions

Condition: ready for operation (used), Technical characteristics Lelhccqoundfkjleri table extention maximum crimping height 100 mm Power and Motors Overall dimensions

Condition: ready for operation (used), Technical characteristics AXIS TRAVEL X AXIS (longitudinal) (mm) 4300 Y AXIS (cross) (mm) 270 Z AXIS (vertical) (mm) 300 ELECTRO-SPINDLE Max. power rating (S1) (kW) 5,5 Max. power rating Lrsloundg Ujhccqlji Max. speed (rpm) 20000 Tool taper HSK 63F AUTOMATIC TOOL MAGAZINE Max. number of tools in the tool magazine 4 standard Max. number of angle machining heads loadable in the tool magazine 2 Max. blade diameter loadable in the tool magazine (mm) Ø 180 FUNCTIONS Multi-piece operation MACHINABLE FACES With straight tool (top face) 1 With angle machining head (side faces and ends) 2 + 2 With blade tool (side faces and ends) 2 + 2 TAPPING CAPACITY (with tap on aluminium and through hole) With compensating chuck M8 Rigid WORKPIECE CLAMPING Standard number of vices 4 Max. number of vices 6 Power and Motors Pluging: Three-phased Overall dimensions Lenght: 5000 mm Width: 1300 mm Weight: 2000 Kg

Condition: ready for operation (used), Technical characteristics Lslhccjundfqsqlsri inferior milling countour milling of interior angles with tilting and curved surfaces Power and Motors Overall dimensions

Condition: ready for operation (used), Technical characteristics fully automatic center type QUADRA ES205 V04 Bar loading magazine o Max bar length 7500 mm Lrslhcjundhfjcqlsi o Minimum bar length 3000 or 1550 mm o Load capacity with axis 100 mm : 20 bars o Load capacity with axis 200 mm: 10 bars o Maximum loadable weight: 500 kg Bar positioning unit o Max bar length : 7500 mm o Minimum length of manually loaded bar: 500 mm o Carriage translation speed: 0.60 m/min Milling section 4 machining units o Drilling o Milling o Tapping up to M8 on thicknesses up to 4 mm (aluminium) o Sawing (aluminium) cut 0/90° and +/- 45 Sawing machine Evacuation section Finished parts magazine Power and Motors Power: 35 Kw Overall dimensions Weight: 8420 Kg

Condition: ready for operation (used), Technical characteristics 2 straight welding heads, one mobile head CN command Adjustment for heating time, hardening, welding temperature, fusion and cutting pressure ascending heating plate rapid changing in function of elements width Power and Motors Power: 4 Kw Lrelhcsundfwecqlsi Overall dimensions

Condition: ready for operation (used), Technical characteristics Works with IDRACAM software Axis X, course 3550 mm Axis Y, course 1100 mm Axis Z, course 425 mm Electrospindle rotation : 0°/90°/180° Work capacity : Lroloundhljhccqlsi Axis X = 3500 mm Axis Y = 540 mm with electrospindle in vertical position at 90° Axis Y = 460 mm with electrospindle in horizontal position 0° or 180° Axis Z = 300 mm with electrospindle in vertical position at 90° Axis Z = 250 mm with electrospindle in horizontal position 0° or 180° Axis displacement : Axis X : 80 m/mn, acceleration 2,8 m/s Axis Y : 25 m/mn, acceleration 2,8 m/s Axis Z : 25 m/mn, acceleration 2,8 m/s Spindle : ISO 30 DIN 69871 Power : 4 kW Rotation speed : 12000 tr/mn 6 tool holder charger tool changing time : 8 secondes Maximum tool weight : 5 kg Max tool diameter : 220 mm Air Pressure : 7 bars Machine at CE normatives Power and Motors Power: 7 Kw Overall dimensions Lenght: 5000 mm Width: 1785 mm Height: 2470 mm

Condition: ready for operation (used), Technical characteristics knives and milling unit Ljlhcoundf Djcqlori Power and Motors Overall dimensions

Condition: ready for operation (used), Technical characteristics Lslhccoundhreqljri Designed for conventional drilling and milling processes, as well as copying operations on extruded aluminum profiles and other materials, including steel profiles up to 3 mm thick, steel-reinforced PVC 3-axis movement/machining Useful X travel: 4000 mm Usable Y travel: 360 mm Useful travel in Z: 295 mm 8-position tool loader 5 workpiece clamps PC control panel Power and Motors Voltage: 380 V Pluging: Three-phased Overall dimensions

Condition: ready for operation (used), Technical characteristics CNC motorized vertical tilt 22.5-30° external and 90° internal CNC motorized movement of THK sliding head Intermediate workpiece support Blade diameter : 500 mm 2 x 2.2 kW motors, 2800 RPM Minimum cutting length at 90° : 225 mm Minimum cutting length at 22° : 310 mm Maximum cutting length : 5000 mm Mobile control panel Sawing speed (peripheral blade speed) : 66 m/s (with 450 mm blade) and 74 m/s (with 500 mm blade) Carriage translation speed : 20 m/min Power and Motors Voltage: 400 V Pluging: Three-phased Power: 5,3 Kw Motor: 2 x 3 CV Overall dimensions Lolhcsundf Rscqljri Weight: 1400 Kg

Condition: ready for operation (used), Technical characteristics Lolhccjundhxeqleri double copying pneumatical tightening Power and Motors Overall dimensions

Condition: ready for operation (used), Technical characteristics Blade Ø 550 mm Useful length : 5000 mm Mobile head with motorized movement and electronic management of angles and length Double inclination of the two heads at 45° (internal) and 15° (external) Automatic and semi-automatic cutting with cutting list and intermediate angles PC control panel WINDOWS XP and 10 inches screen Horizontal and vertical pneumatic presses Integral protection Power and Motors Lrjlhccqjundgbjloi Pluging: Three-phased Power: 3 Kw Overall dimensions Lenght: 6600 mm Width: 1900 mm Height: 1830 mm Weight: 2000 Kg

Condition: ready for operation (used), Technical characteristics Lelhccjundghjqljri Oleo-pneumatic blade feed Vertical pressure cylinders Adjustable blade exit height Pneumatic rotation lock -30°/90°/+25 Protective housing Cutting Ø 130 mm max Section 20 x 220 at 90° or 120 x 100 at 90 Roller tables available Ideal for verandas and special cuts Diamètre lame400 mm Power and Motors Power: 3 Kw Overall dimensions

Condition: ready for operation (used), Technical characteristics cutting group on central motorized beam, 2 speeds cutting height 50 mm with water jet mobile pusher and support 200 mm for small width parts (200 mm) ideal machine for securite and foliated glazing Longueur de coupe6000 mm Hauteur de coupe3700 mm Diamètre lame340 mm Lelhoundgnjccqlori Power and Motors Overall dimensions

Condition: ready for operation (used), Technical characteristics Welding machine: Welding of a frame (4 x 90° angles) in one automatic work cycle for the positioning of the profiles and digital positioning of the welding heads Fully automatic evacuation system of the welded frames The machine complies with CE safety standards and the four welding heads are equipped with a cover to ensure perfect protection of the operator All types of profiles (programmed KBE and PROFIALIS) Welding capacity: height 200 mm - width 140 mm Dimensions: inside 150 x 250 mm - outside 3150 x 3600 mm Welding parameters are individually adjustable on each welding head Electronic adjustment and control of the welding parameters on the screen Electronic temperature control of the welding plates and the limiting knives with digital display and alarm on the control panel Automatic adaptation of the welding time to the profile section Lrslhcjundd Hecqlsi Compensation system per profile piece to eliminate cutting tolerances (+5 / -2 mm) Perfect bead limitation for white, colored or structured profiles Automation - error-free production File from your frame program, barcode reader "Desired size = welded size" allows for optimized cutting of the panels Possibility to generate a production report per period Machine control by PLC - PC of the latest generation Diagnostic system on screen (text and figures) Deburring machine : All types of profiles and combinations Speed and automation: high precision of the tool guides on 4 axes Automation of the control system Electronic recognition of the profile type Selection of the profile type by means of barcode label or online Automatic detection of crossbars High-frequency motors, adjustable speeds without interval All movements and speeds are adjustable from the control panel Selection of grooving or flat finishing as standard on the machine PLC control - PC of the last generation with INTEL processor Diagnostic system on screen Easy programming of new machining and profiles Power and Motors Overall dimensions

Condition: ready for operation (used), Technical characteristics Double loading Advance by pneumatical tightening 2 motors Double blade : 250 and 175 mm Lrolhccqoundguelsi Tables Power and Motors Voltage: 380 V Pluging: Three-phased Power: 3,5 Kw Overall dimensions
