Fitting Team Facilities GmbH

Year of construction: 2025, condition: new, New machine Year of manufacture: 2025 Features and technical specifications: Fully equipped in standard version with: - Robust, torsion-free steel frame, welded and bolted construction - Lamella pressure beam TOP with 6 elements, lamella pressure beam SIDE with 5 elements - Lamella pressure beams with proven tolerance compensation system (Ganner system) for tightly compressed carcass joints - Counter-pressure surfaces (side pressure wall, base) are 38 mm thick, coated, continuous support plates - Continuous pressing surface, height 95 mm, on lower vertical pressure beam - Electromechanical adjustment of both pressure beams via precision trapezoidal thread spindles (with increased lead and concentricity accuracy) and high-performance ball nuts with grease reservoir - The pressing process is carried out electromotorically, via 2 independent worm gear motors (2 x 0.75 kW) - Pressing force of the pressure beams is infinitely variable and electronically controlled by 2 potentiometers, regulated via frequency inverter, ensuring absolutely wear-free force control - Pressing force for horizontal pressure beam: min. 500 daN (kg), infinitely adjustable up to max. 2200 daN (kg) - Pressing force for vertical pressure beam: min. 300 daN (kg), infinitely adjustable up to max. 2200 daN (kg) - Pressing and adjustment speed of the beams with fine positioning, using 3-stage selector switch: 5 / 10 / 25 mm/second - Jog mode for precise positioning of both pressure beams, e.g. for low pressing forces, drawers, and carcasses at 45° - Simplest operation via 6 separate push buttons, 8 movement cycles selectable via control panel - Freely adjustable press time preselection 0-30 min (switchable to seconds or hours), with individually programmable opening dimensions for both pressure beams - Re-pressing function to increase or decrease the pressing force during the pressing process Kedsw Nafkjpfx Adyjnc - Working height/loading height: 300 mm - Working dimensions: Length min: 150 mm, max: 2500 mm; Height min: 150 mm, max: 1400 mm; Depth: 700 mm Including surcharge for rapid traverse speed, for fast positioning of the pressure beams, controlled via automatic workpiece detection with sensors in the pressure beams, pressing speeds 5 / 10 / 25 mm/sec and rapid traverse speed 50 mm/sec, the sensors can be deactivated for pressing special components Including a set of machine feet for 500 mm working height Location: Flörsheim Availability: Short-term

Year of construction: 2025, condition: new, New machine Year of manufacture: 2025 Features and technical data: Standard configuration: - Robust machine base - Dowel system for: Dowel diameter 8 mm, Dowel length 35 mm (factory setting, adjustable from 30 to 40 mm), Dowel protrusion 12 mm (factory setting, adjustable from 7 to 20 mm) - Recoil-free gun - Vibratory feeder for dowel transport - Dowel diameter and length control with Auto-DL-Select system - Water supply system for pre-glued dowels - Water tank (stainless steel, 7.5 l) - Closed water system with 6 bar water pressure and spray nozzle - Electronic control with: - Main switch On / Off - Program selector switch Water / Water + Feeding - Potentiometer for dowel feed via vibratory feeder - Potentiometer for adjusting water injection quantity Knsdpfswx Aadjx Adyjc - Control lamp for indicating minimum water level in the water tank - Mobile base - Compressed air: 6 bar / Electrical: 230V, 1Ph, 50Hz HoKuTech DübelJet with option for opposing hole processing: 1 unit HoKuTech | DübelJet with upgrade kit for LeimJet including fixtures for attaching/connecting to the DübelJet including height-adjustable suspension for glue hose including: 1 HoKuTech | LeimJet Glue dispensing unit for opposing hole processing Viscosity for PVAc glues up to 75,000 mPas Includes dowel nozzle for Ø 8 mm, pointed nozzle Location: Flörsheim Availability: Immediately

Year of construction: 2016, condition: used, Various aluminum cutting machines in stock. Kedpfx Adjf Rihvoyjnc
