Condition: ready for operation (used), Year of construction: 2004, travel distance X-axis: 650 mm, travel distance Z-axis: 800 mm, overall weight: 71,400 kg, spindle speed (max.): 105 rpm, spindle motor power: 100,000 W, number of axes: 2, Horizontal machining centre manufactured in 2004. This IRLE IRD 1600 CNC features a maximum pipe diameter processing capability of 1,625 mm and a maximum pipe length of 13,200 mm. It supports a maximum pipe wall thickness of 70 mm and can handle pipe weights up to 250 kN. If you are looking to get high-quality machining capabilities, consider the IRLE IRD 1600 CNC machine we have for sale. Contact us for further details. - Max. Pipe Diameter to be Processed: 1,625 mm- Min. Pipe Diameter to be Processed: 406 mm- Max. Pipe Length to be Processed: 13,200 mm- Min. Pipe Length to be Processed: 6,000 mm- Min. Pipe Wall Thickness: 12 mm- Max. Pipe Wall Thickness (Copying Process): approx. 40 mm- Max. Pipe Wall Thickness (CNC Operation): 70 mm- Max. Pipe Weight to be Supported: 25500 kg- Height between Hall Floor and Pipe Inlet: 800 mm- Total Machine Length: approx. 24,000 mm- Total Machine Width: approx. 4,100 mm- Total Height from Floor to Top of Clamping Vise: 5,000 mm- Total Machine Weight: approx. 71400 kg- Operating Voltage: 400 V, 3-phase, 50 Hz- Control Voltage: 220 V DC / 50 Hz- Nominal Operating Current: 400 A- Intermediate Bed - Bed Length: approx. 3,950 mm- Intermediate Bed - Bed Width: approx. 1,800 mm- Intermediate Bed - Bed Height (incl. chassis): approx. 600 mm- Intermediate Bed - Travel Speed on Foundation Rails: 500 - 5,000 mm/min- Intermediate Bed - Drive Motor Power: 5.5 kW- Headstock - Faceplate Speed Range: 7 - 105 min⁻¹- Headstock - Motor Speeds: 300 - 4,500 min⁻¹- Headstock - Motor Power: 100 kW- Headstock - Motor Power (S1 Duty Cycle): 105 kW- Headstock - Max. Faceplate Torque (S1 Duty): 33,000 Nm- Headstock - Characteristic Speed: 27 min⁻¹- Headstock - Main Spindle Diameter (Front Bearings): 300 mm- Faceplate (X-Axis) - Faceplate Diameter: approx. 1,950 mm- Faceplate (X-Axis) - NC Tool Support Travel Range: approx. 650 mm- Faceplate (X-Axis) - Tool Support Feed Rate (Infinitely Variable): 0.5 - 1,500 mm/min- Faceplate (X-Axis) - Max. Achievable Feed Force: 25 kN- Feed Gearbox (Z-Axis) - Headstock Feed Travel on Machine Bed: 800 mm- Feed Gearbox (Z-Axis) - Feed Rate (Infinitely Variable via AC Servomotor): 0.5 - 200 mm/min- Feed Gearbox (Z-Axis) - Rapid Traverse Speed: 1,500 mm/min- Feed Gearbox (Z-Axis) - Feed Force: 30 kN- Feed Gearbox (Z-Axis) - Feed Motor Torque: 27 Nm- Pipe Clamping Steady Rests - Clamping Range: 406 - 1,625 mm- Pipe Clamping Steady Rests - Pipe Weight Capacity per Steady Rest: 150 kN- Pipe Clamping Steady Rests - Adjustable Clamping Force: 10 - 200 kN- Pipe Clamping Steady Rests - Max. Adjusting Speed of Centrally Moving Clamping Crossbars: 600 mm/min Dksdpjzr Nmuefx Anzer

Condition: excellent (used), Horizontal machining center OKK Rotary pallet system Type HM600 CNC Fanuc series 310IS-Model A Dsdpfxjzr Ilvj Anzokr Tilting and fork-liftable chip conveyor from GOUBARD Tool holders, double-sided (60) Coolant tank

Condition: good (used), Year of construction: 2007, Horizontal machining center OKK Djdpfx Ajzr Ik Ssnzjkr Rotopalette Type HM500 Year 2007 CNC Fanuc Series 310 IS-model Tool magazine with 60 tools Chip conveyor Approximately 26 tool holders with ISO 50 connection Tilting and forklift-compatible chip bin, GOUBARD Inspection points with shelves and lighting, fan Tool displays, double-sided (60) Buffer tank

Condition: like new (used), Year of construction: 2017, Horizontal machining center OKK Rotary pallet Type HM630 Year 2017 CNC Fanuc Series 310i-s model Chip conveyor Approximately 3 tool holders with ISO 50 mounting Dkjdpfxszr Iihe Anzsr Tilting and forklift-compatible chip bin by GOUBARD Inspection points with shelves and illuminated fan Double-sided tool displays Buffer tank

Condition: excellent (used), Year of construction: 2007, Horizontal machining center OKK Rotopalette Type HM600 Year 2007 Dksdpfszr Iibox Anzjr CNC Fanuc Series 310 IS-Model A 60-tool magazine Chip conveyor Approximately 30 tool holders with ISO 50 attachment Tilting and forkliftable chip bin, GOUBARD Inspection points with shelves and lighting, stool Fans Double-sided tool displays Buffer tank 1 platform with aluminum structure

Condition: like new (used), Year of construction: 2014, Horizontal machining center OKK Rotary pallet Type HM6300S Year 2014 CNC Fanuc series 31i-model B5 60-tool magazine Dedjzr Ih Dopfx Anzjkr Chip conveyor Approximately 30 tool holders with ISO 50 connection Tilting and forklift-compatible chip bin from GOUBARD Inspection points with shelves and lighting Double-sided tool display stands Buffer tank Aluminum structure platform

Condition: used, Year of construction: 2009, total height: 2,800 mm, total length: 3,500 mm, total width: 1,800 mm, Empty weight: 13.000 kg - Year: 2009 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 675002 - Drive system: CNC - Number of axes [pcs]: 3 - X-axis travel [mm]: 650 - Y-axis travel [mm]: 1100 - Z-axis travel [mm]: 500 - C-axis rotation [°]: 360 - Options: Chip conveyor, Tool magazine, Probe - └ Tool magazine [pcs.]: 32 Djdpfx Anezry E Iszskr - Transport dimensions: 3500mm x 1800mm x 2800mm (l x w x h) - Transport weight [kg]: 13000kg - Transport packages [pcs.]: 3 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 2012, CNC machining center, horizontal Manufacturer: Spinner Type: H500-A Year of manufacture: 2012 Control system: Fanuc Oimd Travel range: X/Y/Z: 700 x 650 x 650 mm; 36 m/min. Milling spindle 12,000 rpm with “In-Line” direct drive Tool taper size 40 Air blow-out system for spindle taper 4th axis: rotary table 2-position pallet changer: 2 x 500 x 500 mm High-speed automatic tool changer as a dual-arm changer for 60 tools Dkodpfjzqva Sox Anzer Horizontal milling and drilling Multi-sided machining in conjunction with a rotary table as the 4th axis Linear guide in all three axes Glass scales in all axes Laser tool measurement, workpiece measuring probe RENISHAW IKZ 40 bar Splash guard enclosure High-pressure flushing system Work area lighting 3826

Condition: excellent (used), Year of construction: 1998, Mori Seiki SH630 Horizontal Machining Centre Year 1998 Spindle speed - 10,000rpm CNC Control - Fanuc drives / Mori Seiki MSC control 4 Axis Table Length 630mm Table Load 1000kg Table Width 630mm Y axis travel - 760mm Djdpfx Aszp Rftjnzskr Z axis travel - 840mm X axis travel - 840mm Tool magazine with capacity for 60 tools 2 Tombstones Comes with Metal standing frame

Condition: like new (used), functionality: fully functional, * Mori Seiki NMV 5000 DCG. * Year: 2008. * Equipment value, including zero points, chucks, BT taper chucks, turning tool chucks, and pallets: 50,000–55,000 euros. * 5-axis continuous machining center. * High-precision Heidenhain linear guides. * Interface for connecting a pallet loader and robot. * Table with turning function. * Independent high-pressure cooling system at 40 bar. * Spindle oil cooling system. * BT 40 tool magazine. * Magazine capacity: 60 tools. * Maximum tool diameter: 125 mm. * Maximum tool length: 300 mm. * Maximum tool weight: 8 kg. * Travel on the X-axis: 730 mm. * Travel on the Y-axis: 510 mm. * Travel on the Z-axis: 510 mm. * Table with turning function. * Maximum workpiece diameter in turning mode: 450 mm. * Maximum turning diameter in turning mode: 700 mm. * Mori Seiki Mapps 4 conversational control. * Spindle speed: 20,000 rpm. * Spindle motor power: 18.5 / 15 kW. Dkjdpfxszp Emfo Anzor * Maximum cutting torque: 135 Nm. * C-axis table: 360,000 x 0.001 * B-axis rotation: +160 / -180 * Rapid traverse X/Y/Z: 50 / 50 / 50 m/min * Renishaw tool measurement system. * Renishaw workpiece measurement system. * Automatic zero-point adjustment. * Automatic cutting power control. * Program memory: 2 MB. * Dynamic zero-point correction (up to 8 points). * Pre-check of tool availability. * Custom macro (999 variables). * Rear chip conveyor. * Tool life management (128 x 2 groups). * Electrical transformer. * Documentation, parts list, electrical diagrams, programming, and instruction manual. * Weight: 13,500 kg. * Machine is currently in operation. * Available for inspection by an authorized Mori Seiki technician. * Immediate delivery, subject to immediate sale.

Condition: refurbished (used), Year of construction: 2012, functionality: fully functional, Year of manufacture: 2012 Control system: Siemens 840D SL Spindle: SC63, 16,000 rpm, 40 kW, 96 Nm Tool clamping system: HSK 63 Dodpfx Anszpyg Tjzokr Tool magazine / positions (options): Chain / 54 Rotary table: 360,000° x 0.001° Coolant system: KNOLL, VRF 250, IKZ 50 bar, (work area flushing) Working area XYZ (mm): 630 / 630 / 630 Pallet size (mm): 500 x 400 Workpiece clamping: Hydraulic, 60 bar Additional options, special features: Infrared receiver for measuring probe (RENISHAW); SBBK; Pneumatic support control at the workpiece setup station; Status indicator light; Chip conveyor for wet machining;

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 560 mm, workpiece weight (max.): 600 kg, number of slots in tool magazine: 60, swivel angle C-axis (max.): 360 °, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Spindle mount: SK40 Travel range X-axis: 600 mm Travel range Y-axis: 560 mm Travel range Z-axis: 560 mm Swivel range B-axis: 360° Number of tool positions in the magazine: 60 MACHINE DETAILS Control system: Siemens Dsdpfx Anozpxd Rezskr Number of pallets: 2 Pallet size: 400 × 500 mm Permissible pallet load: 600 kg Machine weight: 10,500 kg

Condition: used, Year of construction: 2002, x-travel 650 mm y-travel 650 mm z-travel 650 mm Dkjdpfxszmy Tuo Anzor Control Siemens 840 D weight of the machine ca. 12 t

Condition: used, OKK PVC-60 X-axis 960mm, Y-axis 610mm, Z-axis 600mm Table dimensions: 48.03" x 25.20" Maximum table load: 1,760 lbs. Travel ranges: (X) 40.16", (Y) 25", (Z) 20.47" Distance table surface – spindle nose: 7.87" – 28.35" Distance spindle center – column: 33.07" Spindle speed: 100–6,000 RPM Spindle taper: CAT-50 Spindle motor: 15/10 HP Rapid traverse: (X, Y) 630 ipm, (Z) 472 ipm Feed rate: 157 ipm Tool capacity: 20 positions (ATC), dual-arm swivel system Dodpfxjzmqdwe Anzekr Tool change time: 3 seconds Tool selection: Random principle (any order), bidirectional Integrated, hardened and ground flat guideways (box ways) Coolant unit Fully enclosed, spacious splash guard Machine weight: 13,640 lbs.

Condition: repair required (used), Year of construction: 1995, machine/vehicle number: VM40067E, travel distance X-axis: 560 mm, travel distance Y-axis: 410 mm, travel distance Z-axis: 410 mm, overall weight: 6,000 kg, spindle speed (min.): 8,000 rpm, Brand / Manufacturer: HITACHI Model: SEIKI VM 40 II Year: 1995 Taper: BT40 Serial number: VM40067E Control unit: SEICOS MY II DIMENSIONS Table dimensions: 760 x 400 mm. TRAVEL X-axis traverse: 560 mm. Y-axis traverse: 410 mm. Z-axis traverse: 410 mm. SPINDLE Spindle speed: 8,000 rpm. Spindle power: 5.5 / 7.5 kW. WEIGHT AND DIMENSIONS Machine weight: 6,000 Kg. ACCESSORIES 30-station automatic tool changer / ATC Capacity: 30 Tools Dsdpfx Ajzl S I Uonzskr Nikken 4th axis CNC rotary table (REQUIRES REPAIR) The machine is complete and includes documentation and manuals. The mechanical part is in good condition. The electronics need repair; likely the power supply. (NEEDS TO BE REPAIRED) The machine is complete. It also has documentation and manuals. The mechanical part is good. The electronics need repair. Probably the power supply.

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, We offer you: Manufacturer: GGF / MAG Type: SPECHT 500 DUO Year of manufacture: 2011 Control system: Siemens 840D sl Technical data: Travel ranges: x-axis: 750 mm y-axis: 650 mm z-axis: 560 mm Main spindle: Spindle speed: max. 16,000 rpm Drive power: 40 / 26 kW Table dimensions: Working diameter: max. 1,100 mm Workpiece/fixture width: max. 1,520 mm Load capacity: max. 2 x 365 kg Dedpfxjzl D N Re Anzokr Tool changer: Tool holder: HSK-A63 Feed rates: Axis speed: max. 60 m/min A total of 16 identical machines are available. In addition, there is a 3-axis machine with HSK-A100, suitable for extremely long tools. Accessories, tools and clamping devices shown in the images are only included in the scope of delivery if this is stated in the additional information. Subject to change and errors in the technical data and specifications, as well as prior sale!

Condition: like new (used), Year of construction: 2017, operating hours: 10,000 h, functionality: fully functional, travel distance X-axis: 730 mm, travel distance Y-axis: 730 mm, travel distance Z-axis: 830 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, Base Machine - SH-5000P - Demonstration Machine Like New • Basic machine, 4-axis • Control: Siemens 840D sl • Table size: 500x500mm • Max. table load: 500kg • X/Y/Z travels: 730/730/830mm • X/Y/Z rapid traverse: 60/60/60 m/min Dkjdpezluqlefx Anzjr • Milling spindle: • HSK63 • 30/50kW • 18,000 rpm • Tool magazine with 40 stations • Automatic pallet changer • Automatic loading door • Hydraulic unit • Oil separator • Oil mist extraction • Air conditioning unit for electrical cabinet • External measuring systems, linear axes • Media feed under pallets • Central lubrication • Door interlock • Coolant unit • Internal cooling with 70 bar high pressure • Coolant and compressed air gun • Chip conveyor • Documentation in German, digital

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 750 mm, travel distance Y-axis: 750 mm, travel distance Z-axis: 725 mm, controller model: SIEMENS Sinumerik 840D, spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Travel range X-axis: 750 mm Travel range Y-axis: 750 mm Travel range Z-axis: 725 mm B-axis: 360° Spindle mounting: HSK 63A Spindle speed: 50-10,000 rpm Spindle drive power 40/100% duty cycle: 37/24 kW Tool positions: 320 Feed rate: 60,000 mm/min Rapid traverse: 60 m/min Djdpozi Edkofx Anzskr MACHINE DETAILS Control system: SIEMENS Sinumerik 840D Machine length with chip conveyor: 6,100 mm Width (with control and additional magazine): 4,500 mm Installation dimensions internal cooling: 2,450 x 1,700 mm Installation dimensions spindle cooler: 800 x 900 mm Machine weight: approx. 15,000 kg EQUIPMENT NC rotary table with B-axis Magazine for 320 tools Pallet changer, 2 pallets 500mm x 500mm Internal coolant supply (80 bar) Chip conveyor Coolant system

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 650 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 680 mm, controller model: SIEMENS Sinumerik 840D, spindle speed (max.): 24,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 650 mm Travel range, Y-axis: 650 mm Travel range, Z-axis: 680 mm B-axis: 360° Spindle speed (max.): 24,000 rpm Spindle taper: HSK 63A Tool positions: 80 MACHINE DETAILS Control system: Sinumerik 840D Machine weight: approx. 13,000 kg Dkodezi Ealopfx Anzsr EQUIPMENT NC rotary table with B-axis Magazine for 80 tools Pallet changing system, 2 pallets 400 mm x 400 mm Internal coolant supply (ICS) Chip conveyor Coolant system

Condition: good (used), Year of construction: 2009, Horizontal machining center Machine type: DMG DMC 65 H duoBlock Control: Siemens 840D Solutionline Year: 2009 new spindle: 2026 SPECIFICATIONS Travel X-Axis: 700 mm Y-Axis: 700 mm Z-Axis: 700 mm Spindle speeds: 12.000 rpm Tool: CAT 40 Toolchanger Tool capacity: 45 Amount of paletts: 2 Palett size: 500 x 500 mm Equipment Chip conveyor Chip rinsing pistol Internal cooling: 40 bar Cooling tank: 960 l Caliper: Renishaw Tool setter: Blumlaser 3D Quickset Electronical handwheel New in 2026 Spindle bearing Rotary union Dedpfx Anjzi Dz Iszjkr All pneumatic lines All oil and air filters All oils and fats Laser serviced Various wearing parts

Condition: refurbished (used), Year of construction: 2000, functionality: fully functional, Equipment: chip conveyor, documentation/manual, We offer this refurbished (REBUILT SPINDLE) Heller MC 16 horizontal machining center, manufactured in 2000. 4 axes Working range: Longitudinal travel of axis X 630 mm Vertical travel of axis Y 630 mm Transverse travel of axis Z 630 mm Pallet size 400 x 500 mm Max. workpiece size Ø x height 720 x 800 mm Max. workpiece weight 500 kg 6 pallets Pallet change time 9 sec. NC rotary table, tilt of axis B 360,000 x 0.001 ° Rotation speed of axis B 40 rpm Tool holder taper SK 63 Tool size Ø x length x weight 150 x 227 x 12 mm/kg Spindle speeds, stepless adjustment 45 - 24,000 rpm Feeds / rapid feeds XYZ 1 - 60,000 mm/min Feed force 10,000 nm Spindle torque 48/72 nm Spindle drive 30 kW Total electrical load, approx. 60 kW - 400 V - 50 Hz Total weight, approx. 12,500 kg Dedpfx Ajzi A Awonzskr Control: Unipro Manufacturer: Heller Model: MC 16 Year of manufacture: 2000 Condition: refurbished ID category: 1455 Type ID: 4161 Machine type: horizontal machining center If you have any questions or require additional information, please send a message or contact us by phone.

Condition: good (used), Year of construction: 2017, Horizontal machining center Machine type: DMG MORI NHX 5000 Control: M730UM mit Celos Year: 2017 SPECIFICATIONS Travel X-Axis: 730 mm Y-Axis: 730 mm Z-Axis: 880 mm Dkedpfx Aozinbxsnzer Rapid motion: (X/Y/Z): 60 m/min. Feed: (X/Y/Z): 60 m/min. Spindle speeds: 15.000 rpm Spindle motor: 37 kW Torque: 250 Nm Toolchanger Tool: HSK 63 Tool capacity: 60 Work piece diameter: 70 / 140 mm Tool lenght: 550 mm Tool weight: 12 kg Palett system Amount of paletts: 2 Palett size: 500 x 500 mm B-Axes: 0,001° Max. Table Load: 500 kg Equipment Chip conveyor Filtration system: Knoll KF 110/700 Internal cooling: 70 bar

Condition: ready for operation (used), Year of construction: 2013, travel distance X-axis: 600 mm, travel distance Y-axis: 525 mm, travel distance Z-axis: 400 mm, controller manufacturer: SIEMENS, controller model: SINUMERIK 840D sl, total height: 3,300 mm, overall weight: 12,500 kg, spindle speed (max.): 6,000 rpm, spindle motor power: 6,000 W, This 4-axis SW BX 621 horizontal machining center was manufactured in 2013. It features a robust SINUMERIK 840D sl CNC control system and dual liquid-cooled motorized spindles, each offering up to 6,000 rpm and 26 kW power. The machine supports a maximum tool diameter of 115mm and a tool length of 300mm, with a rapid traverse speed of up to 60 m/min. Ideal for precision machining, the SW BX 621 machine we have for sale. Contact us for more information. Additional equipment • Liquid-cooled motorised spindle in AC synchronous technology Machine Benefits Technical Machine Benefits • Swivelling table (a-axis): direct-driven, horizontal nc rotary table with counter bearing • Max. Fixture / workpiece dimensions: Ø 630 mm x 1420 mm • Max. Fixture / workpiece weight: 600 kgmax. Fixture / workpiece weight: 600 kgmax. Fixture / workpiece weight: 600 kg • Spindle arrangement: horizontal, side by side • Spindle distance: 600 mm Dksdpfx Anszh Uqdozsr Extra Information Machine still under power Dimensions Machine Depth 5800 mm

Condition: used, Year of construction: 1995, Fanuc MSC 516 2 pallets, 500x500mm BT40 spindle Spindle speed: 12,000 RPM 20-tool changer Coolant pressure: 20 bar Dsdpozgrzkjfx Anzokr Renishaw

Condition: excellent (used), Year of construction: 2007, Quaser MK603HPD horizontal machining center, 2-pallets Year: 2007 Technical details: Work range Pallet size (mm) 500 x 500 Max. work swing diameter (mm) Ø680 Max. work piece height 710 Table load capacity (kg) 500 Travel X / Y / Z (mm) 710 / 610 / 610 B-axis minimum indexing (degree) 0.001 Table surface to spindle center (mm) 105 ~ 715 Position accuracy With Linear encoder X/Y/Z (mm) 0.004 Tool changer Tool selection Random Magazine positions 60 Max. tool diameter w/o adjacent tool (mm) Ø80 (Ø150) Max. tool length (mm) 350 Max. tool weight (kg) 10 Tool to tool time (sec.) 1.5 Chip to chip time (sec.) 4.9 Pallet changer Number of pallet 2 Method of pallet changer Swing Arm type Pallet change time (sec.) 8 Pallet changing repeatability (mm) 0.008 Control Fanuc 18iM-B Main spindle 15000 rpm , direct coupling SKF Heavy duty & high speed Coolant system Coolant tank capacity (Liter) 580 (200+380) - Nozzle coolant pump capacity 60 L/min - Through spindle coolant pump capacity 25 L/min. , 20 bar - Wash down pump capacity 60 L/min. - Celling wash down pump capacity 60 L/min. Machine size Height (mm) 3100 Floor space W x D (mm) 3675 x 4510 Weight (kg) 13000 Accessories/options: Dkjdpfozf Rp Rsx Anzer - Spindle oil chiller - 60 position tool magazine - 2 pallet station - Linear encoder (Absolute 0.0001mm) - Coolant system - 20 bar through spindle coolant - Celling wash down coolant - Base, Saddle wash down coolant - Coolant wash gun - Chip augers (2 sets) - Chip conveyor - Work light - Machine status light - CE & EMC Tool holders and clamping plates which shows on the pictures are not including.
