Pvc Alu Creation

Condition: used, Year of construction: 2005, functionality: fully functional, The machines are in working condition and are still in daily use. Under Pressure in Bulgaria. STURTZ SE-HSM Compact + JC243 + SE-4AS-CNC Welding/Cleaning Production Line German-engineered CNC cleaning and welding production line for PVC windows. Suitable for medium to large production environments and compatible with all PVC window profiles. Depending on the product mix, up to 120 windows with one element per welding cycle can be welded in a diagonal or parallel joining process within an 8-hour shift. PC-based control technology with LCD process-reliable display of production and machine data, featuring easy-to-operate intuitive menu navigation and a visual representation of machining processes on the touchscreen display. STURTZ SE-HSM Compact Multi-Point (4-Head) Horizontal Welding Machine CNC simultaneous high-temperature welding of four corners at a 90° angle with parallel welding feed. With electronic positioning of welding heads, PC control, weld seam limitation of 2mm, and automatic outfeed. Bedpfx Ae Agfwbodhjlp Specifications: • Max. frame or sash size: 4000 x 2600 mm • Min. frame or sash size: 320 x 320 mm • Working direction: Right to Left • Line capacity: Standard 120 units / 8-hour shift. 1 unit = 1 frame + 1 sash • Min. profile depth: 45 mm • Max. profile depth: 120 mm • Min. profile sight line: 25 mm • Max. profile sight line: 130 mm Features: Quick change of the fixtures through a screwless back stop system ensures a flexible production process. Clamping cylinders adjust automatically to the required profile height. Automatic adaptation of fusing time to the different profile cross-section. Compensation welding system allows welding of profile bars with a cutting tolerance. Central control panel, electronic positioning. Dimensions: 5500 x 5000 x 2000 mm Weight: 4500 kg STURTZ Transport / Cooling Table The powered automatic table transports the elements from welding to cleaning positions, during which time the welds are allowed to "cool". STURTZ SE-4AS- 4-Axis CNC Corner Cleaner CNC corner cleaning machine with (4) interpolating axes for complete machining of corners of uPVC window frames. Fully automatic cleaning of visible surfaces, outer corners, seal grooves, and inner corners on uPVC window frames and sashes. Specifications: Features: The SE-4AS has a 4-axis freely programmable LCD control unit. Equipped with: Top and bottom horizontal and vertical scarfing knives; top and bottom vertical router, frequency-controlled cutter disc for outside contour cleaning. 4-Axis CNC upper and lower tool units, profile recognition system. Due to the pressure in Bulgaria, the machines can be dismantled and removed immediately.

Year of construction: 2010, condition: used, Double-head PROFTEQ SA 22 welding machine, manufactured in 2010, designed for welding PVC profiles used in the production of windows, doors, frames and sashes. The machine is equipped with two welding heads, one fixed and one movable, allowing both right-angle and variable-angle welding operations. The fixed head performs welding at 90°, while the movable head allows variable-angle welding from 45° to 180°, providing greater versatility in window and door manufacturing. The welding cycle is automatic and includes the heating, melting, joining and cooling phases of the profiles. Bjdpfx Aj Abbbasdholp Technical Specifications Manufacturer: PROFTEQ Model: SA 22 Year of manufacture: 2010 Machine type: Double-head welding machine for PVC profiles Number of welding heads: 2 Fixed head: 90° welding Movable head: Variable-angle welding from 45° to 180° Welding cycle: Automatic Minimum weldable profile height: 35 mm Maximum weldable profile height: 190 mm Maximum weldable profile width: 150 mm Power supply: 380 V Frequency: 50 Hz Installed power: 4 kW Pneumatic pressure: 8 bar Weight: 1,000 kg Overall Dimensions Length: 3,800 mm Depth: 1,100 mm Height: 1,900 mm Features and Equipment Two welding heads for processing PVC profiles. Movable welding head for variable-angle welding operations. Pneumatic profile clamping system. Heating plates for melting the surfaces to be welded. Welding bead limitation system. Dedicated control panels for each welding head. Adjustable welding parameters, including temperature and processing times. Automatic welding cycle.

Condition: used, Year of construction: 2008, functionality: fully functional, Single-head welding machine Bljdpszpyfcefx Adhjp

Condition: used, Year of construction: 2007, functionality: fully functional, SE-HSM-40/26-COMPACT-PLUS Horizontal four-head welding machine 2MC Horizontal CNC corner edging machine, motion control WST-30 Horizontal turning station Minimum element size 320 × 320 mm Maximum element size 4,000 × 2,600 mm Bedpfszm N Nrox Adhelp Maximum element weight 80 kg Minimum working area 320 × 320 mm Maximum working area 4,000 × 2,600 mm

Condition: excellent (used), Year of construction: 2021, machine/vehicle number: 390701, For sale: a two-head welding machine, URBAN model AKS 3900. The machine is in perfect working order. It was used in a single-shift production environment. Bedpfxszd Ra Ts Adholp Year of manufacture: 2021. Purchase invoice date: 2022.

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: 091600214, total width: 7,744 mm, total length: 8,408 mm, total height: 2,000 mm, feed length X-axis: 4,561 mm, feed length Y-axis: 6,856 mm, type of cooling: air, Seamless V-perfect technology welding machine, graphic representation of 19 axes, CNC controlled. No more need for edge finishing. 139,545 welded elements. Bjdezdr D Tspfx Adhslp External maximum welding dimensions: 4000x2800mm. Calibrated for Schüco CT70/Living 82; welding blocks not included.

Year of construction: 2019, condition: like new (used), functionality: fully functional, For sale: SCHTEC WM740 four-head automatic welding machine, rarely used and in like-new condition, including WM620 corner cleaning automaton, cooling station, and automatic turning arm. If purchased together with the SMC350 machining center and Pressta two-head automatic screwing unit, which are also listed in your advertisements, the package price is EUR 180,000. Bsdpfx Adsyzimcohslp For further information, please feel free to contact me.

Condition: good (used), functionality: fully functional, Year of construction: 2005, It is important to know that a total of two welding machines and two CNC corner cleaning machines are available, comprising two complete production lines. The machines are operational and still in daily use. Blsdpfsyyavrex Adhjp CE Conformity: Yes (CE marking on the machine) Power supply: 400 V Frequency: 50 Hz Current connection: 25 A Main switch: Industrial main switch with safety interlock Operating air pressure: 7 bar Main components - 4 welding heads - Linear motion system - Profile clamping units - Welding plate system - Pneumatic press units - Electronic temperature control - Central control unit - Safety light curtain Operation Profile clamping – Insertion of the heated welding plate – PVC melting – Application of welding pressure – Welding cooling – Removal frame The system operates semi-automatically/automatically. ``` Includes: - Automatic head positioning - Pneumatic clamping system - Digital temperature control - PLC control - Operator panel and industrial PC Control system Industrial PC control Safety system - Light curtain - Emergency stop button - Safety covers - CE conformity Powered up in Hungary, the system can be dismantled and delivered in approximately June.

Year of construction: 2013, condition: excellent (used), Welding and cleaning line GRAF, year 2010 The direction of work from left to right Welder four-head SL4Q, max. welding dimension 2800 x 3200 mm, 0.2 mm flash, gasket formates Cooling station WPCNC4 4-axis cleaner with a turning station, equipped with knives for cleaning flat surfaces with a groove and smooth The line was servised in the end of 2022 y. with part replacement for over 10000 Euro (total cost of service). It is in very good condition. Currently is working. Bedpsvr U Sysfx Adhslp

Condition: new, Year of construction: 2026, functionality: fully functional, machine/vehicle number: SÇ 101 S PVC Tek Köşe Kaynak Makinası, - Conforms to CE standards. - Weldable angle : All angles between 25 - 180 degrees. - Welded profile maximum height 150 millimeters - Minimum height of welded profile 40 millimeters - Upper pistons are individually compressible - Left moving table system available - Profile clamping is practically done with the pedal Bjdpfx Adjra Niaehelp - PLC control system available - The heating unit has thermostatic control - The degree of the heating plate can be easily changed via the digital display - Heat temperature, welding time and pressure can be adjusted for different profile types - Time saving thanks to easy mold change system.
