D'Cunha Industriemaschinen GmbH

Condition: ready for operation (used), Year of construction: 2015, functionality: fully functional, turning diameter over cross slide: 290 mm, spindle speed (max.): 5,500 rpm, spindle bore: 73 mm, travel distance X-axis: 210 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 525 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 23 m/min, rapid traverse Z-axis: 30 m/min, spindle nose: FL 140h5, overall weight: 4,400 kg, Equipment: documentation/manual, rotational speed infinitely variable, This DMG MORI CTX alpha 500 V5 from 2015 is in very good condition and has 7,040 spindle hours on the clock. In 2020, the machine was fitted with a BMO automation system, type Iridium Ir 25F, but it has seen little production since then. The machine is very well equipped and has recently been fully professionally cleaned. This CTX alpha 500 is equipped with: - BMO Iridium Ir25F automation (2020) - LNS Quick Load Servo III bar feeder (2016) - Schunk Rota THW plus power chuck with quick-change jaw system - Various additional jaws - DMG CELOS software - Chip conveyor - Workpiece catcher/ejector - Tool measuring arm - Foot pedal for clamping/unclamping chuck - Various tooling (driven & static) - All original documentation in German Iedpfxjx Ah Ryo Adija

Condition: like new (used), Year of construction: 2019, functionality: fully functional, As-new DMG CTX 1250 TC 2nd Generation Siemens 840 sl Operate 21.5" Ergoline 5-axis simultaneous machining Counter spindle ISM 76 synchronized 48 tool positions HSK 63A DIN 69893 Year of manufacture: 2019 Iodpfjx Ah Edex Adioa Low operating hours (see photo) Max. turning diameter: 500 mm Max. turning length: 1200 mm Draw tube internal max. 77 mm main spindle Further technical specifications in PDF Blum TC 60 touch probe Bar feeder interface Turning/milling spindle with increased speed 20,000 rpm 19/22 kW Scraper-type chip conveyor incl. coolant tank 600 l 8 bar/20 l/min Centrotex clamping system incl. accessories. The machine is available immediately.

Condition: excellent (used), Mazak Super Quick Turn 200 MSY CNC Twin Spindle Multitasking Slant Bed Lathe With Mazatrol 640 T Control & Barfeeder Kitagawa B-208 3 Jaw Power Chuck, Sub Spindle Collet Chuck. Maximum Swing Ø525mm. Maximum Swing Over Carriage Ø350mm. Standard Machining Ø276mm. Standard Machining Ø300mm. Maximum Machining Length 541mm. Bar Working Capacity Ø51mm. Through Spindle Bore Ø51mm. Axis Travel 'X'=180mm, 'Z'=575mm, 'Y'=100mm (±50mm), 'B'=585mm, 'C'=Increment 0.001°. Rapid Traverse 'X'=30m/min, 'Z'=30m/min, 'Y'=12m/min, 'B'=18m/min, 'C'=400rpm. Main Spindle 35-5,000rpm (18.5kW Motor), Sub Spindle Speed Range 35-5,000rpm (18.5kW Motor). Driven Tool Spindle Speed Range 25-4,500rpm (3.7kW Motor). 12 Position Turret (12 Driven Positions). Turning Tool Dimension 25 x 25mm, Internal Turning Ø40mm, Maximum Rotary Drill/Milling Cutter Ø20mm. S/No. 155170 (2002). Hydrafeed MX-1B Barfeeder. With Cromar Chip Conveyor, Coolant System, Tool Setting Arm, Parts Catcher, Foot Switches, LNS Mobile Swarf Bin, Quantity Of Assorted Axial/Radial Driven Toolholders, Pratt Burnerd 3 Jaw Power Chuck, 3 Assorted Collet Chucks, Turning Tool Blocks & Manuals. Overall Dimensions L3,320 x W1,930 x H2,052mm. Weight 5,700kg. Ijdpfex Ag Ausx Adiea

Condition: good (used), CNC lathe with short bar loader and NC tailstock! Available immediately! Year of manufacture 2011 – first commissioning 2015; Low operating hours, Fanuc control with Manual Guide i; 250 mm chuck, 65 mm spindle bore, turning length approx. 750 mm; Box guideways in X and Z; Chip conveyor; Tool setter; LNS short bar loader; Parts catcher with belt; Various tool holders, fixed and driven; Fully equipped for turning; Iedjx Agxcjpfx Adiea

Condition: good (used), Year of construction: 2008, Index G200 CNC Twin Spindle Turn/Mill Centre With Index C200-4D Control & LNS Quick Load Servo 65 Barfeeder Maximum Swing Ø420mm. Maximum Turning Ø200mm. Maximum Machining Length 400mm. Bar Capacity Ø60mm. Axis Travel 'X1'=120mm, 'Z1'=400mm, 'X2'=105mm, 'Z2'=400mm, 'Y'=± 65mm, 'B'=445mm. Main Spindle Maximum Speed 6,000rpm (13kW Motor), Sub Spindle Maximum Speed 5,000rpm (22kW Motor). (2) 14 Position Turrets (14 Positions Driven). Maximum Driven Tool Speed 6,000rpm (5.5kW Motor). Tooling VDI 25. LNS Quick Load Servo 65 Barfeeder Length 1,700mm. S/No. 512020. Ijdpfxsx Agnks Adija With Knoll Coolant Filtration System, Knoll Chip Conveyor, Workpiece Unloader, Workpiece Conveyor, Foot Switches, Filtermist FX4002 Mist Extraction Unit, Bar Feeder Liners & Manuals.

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, spindle speed (max.): 5,000 rpm, travel distance X-axis: 165 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 678 mm, bar passage: 70 mm, controller model: Fanuc 310i, No reserve price – guaranteed sale to the highest bidder! TECHNICAL SPECIFICATIONS Main Spindle - Max. speed: 5,000 rpm - Max. bar capacity: 70 mm - Draw tube bore: 75 mm - Torque: 191 Nm - Power: 20 kW Sub-Spindle - Max. speed: 5,000 rpm - Draw tube bore: 42 mm - Torque: 108 Nm - Power: 17 kW Turrets 1 & 2 - Tool stations per turret: 12 driven Ijdpfxjx Af Dkj Adisa - Driven tools: 4,000 rpm Travel Axes - X1 axis travel: 165 mm - Y1 axis travel: 80 mm (+50 / -30 mm) - Z1 axis travel: 678 mm - X2 axis travel: 165 mm - Z2 axis travel: 640 mm MACHINE DETAILS - Year of manufacture: 2007 - CNC controller: Fanuc 310i - Number of controlled axes: 8 - Machine dimensions: 4.40 m x 2.00 m x 2.30 m - Machine weight: 8.8 t - Chip conveyor weight: 750 kg EQUIPMENT - Chip conveyor - 2 x collet chucks - Parts conveyor belt - Extraction unit - Bar feeder (FMB Turbo 8-80 / 3200)

Condition: new, Year of construction: 2025, functionality: fully functional, Traub TFT Monitor/Screen TX8D, TX8F, TX8H Replacement Monitor Replacement Screen Type: TFT (1) Item No.: 222549 (2) Item No.: 10892558 Condition: new Traub TFT monitor/screen TX8D, TX8F, TX8H Isdpfxex Adb Is Adiea Includes frame and cable, 1:1 interchangeable, 12" Plug and Play solution Not an original Traub spare part – 100% tested and compatible Manufactured by cnc-markt GmbH

Condition: like new (used), Year of construction: 2008, operating hours: 1,900 h, functionality: fully functional, * Mori Seiki NL 2500 SY. * Included equipment value: €20,000–25,000. * Year of manufacture: 2008. * Only 1,900 cutting hours. * 5-axis machine. * Sub-spindle. * 12-station turret, all stations powered (live tooling). * Y-axis travel: ±60 mm. * C-axis on both spindles. * Main spindle integrated motor: 18 kW. * Sub-spindle integrated motor: 15 kW. * Direct drive for live tools: 5.5 kW. * Spindle start-up torque: 640 Nm. * Beltless, step-less drive motors. * Main spindle nose size: A2-8. * Sub-spindle nose size: A2-6. * Bar capacity: 80 mm. * Main spindle chuck: Kitagawa B-210, 250 mm, metric system. * Sub-spindle chuck: Kitagawa B-208, 210 mm, metric system. * Box guideways on all axes. * Main spindle speed: 4,000 rpm. * Live tool speed: 6,000 rpm. * Daikin oil chiller for both spindles. * Conversational automatic programming system: Mapps 4. * Automatic overload control and tool consumption monitoring. * Rapid traverse speed: 30 m/min on X and Z axes. * Turret indexing time: 0.2 seconds. * Two Renishaw automatic tool measurement arms. * Communication ports: USB, PCMCIA card, and RS-232. * Bar feeder installation interface. * Automatic parts catcher. * Dual foot pedal for independent opening and closing of main and sub-spindle chucks. * Side-mounted hinged belt chip conveyor. * Comprehensive set of static and powered toolholders. * Electrical transformer. * Documentation: parts list, electrical diagrams, programming, and operations manual included. * Machine weight: 5,800 kg. Ijdpfx Adex Ab R Toioa * Machine currently in operation. * Essential to check precision and demonstration videos. * Only aluminum components machined. * Cutting hours: 1,900. * Immediate delivery unless sold beforehand.

Condition: like new (used), Year of construction: 2009, operating hours: 1,800 h, functionality: fully functional, * Mori Seiki NZ 2000 T2Y. * APPROXIMATE VALUE OF INCLUDED EQUIPMENT: €40,000–45,000. * Both spindles equipped with two Hainbuch high-precision collet chucks. * Opposed-spindle machine configuration. * 9-axis turning and milling center with CNC control. * Twin spindles. * Spindle size: A2-6. * 2 stacked turrets. * 2 C-axes. * 1 Y-axis. * Two integrated 22 kW motors. * Milling spindle power: 7.5 kW. * Two Renishaw automatic tool measurement arms. * Mapps 4 conversational automatic programming system. * Automatic load control and tool consumption monitoring. * Tool life management and consumption monitoring. * Double foot pedal for chuck open/close operation. * Oil chiller for both spindles. * Cutting torque: 340 Nm. * Both turrets feature 16 stations each, all stations driven. * Possibility to set up with up to 32 tools per turret. * Interface for bar feeder installation. * Rear automatic parts catcher with special gripper for long workpieces. * Large set of external and internal toolholders. * Large assortment of axial and radial driven tool blocks. * MQ tool clamping system. * Maximum turning diameter: 320 mm. * Turning length: 810 mm. * Mori Seiki MSX-701 III CNC control. * Maximum distance between main and sub-spindle: 1,130 mm. * Main spindle speed: 5,000 rpm. * Sub-spindle speed: 5,000 rpm. * Driven tool speed: 6,000 rpm. * Maximum bar capacity: 65 mm. * X1 travel: 210 mm. * Y1 travel: +65 / -45 mm. * Z1 travel: 300 mm. * X2 travel: 210 mm. * Z2 travel: 810 mm. * Sub-spindle travel: 920 mm. * Rapid traverse X1, X2: 30,000 mm/min. * Rapid traverse Y1: 20,000 mm/min. * Rapid traverse Z1, Z2: 50,000 mm/min. * C-axis resolution: 0.001°. * Hinged belt side chip conveyor. * Communication ports: USB, PCMCIA card, RS232. * Machine weight: 8,300 kg. * Inspections under power possible. * Supplied with electrical transformer, documentation, parts list, electrical diagrams, programming and operation manuals. Iedpfx Adox Ab Nijisa * IMPORTANT: Never used with bar feeder; only used for machining aluminum prototypes. * VERY few cutting hours. * Immediate delivery unless sold prior.

Condition: used, Year of construction: 2018, operating hours: 2,900 h, functionality: fully functional, Perfect machine, for example, for the production of artillery shell housings according to NATO standards or ideal for industries like oil and gas, construction, aerospace and shipbuilding. Very good condition and immediately available. The machine has seen very little use and is in absolutely like-new condition. 21" Doosan Puma 600L 3200 CNC lathe with steady rest (automatically adjustable steady rest) Year of manufacture: 2018 Including steady rest Machine operating hours: 2,036 hours Technical specifications: CNC control: Fanuc 32i-MA Max. turning diameter: 900 mm Max. turning length: 3,200 mm Chuck size: 21" Spindle bore: 152 mm Number of tool stations in turret: 12 X / Z travels: 940 mm / 3,200 mm All further information available on request. Iedpfx Asxz Hbuodija The machine can be demonstrated under power at any time on site.

Condition: like new (used), Year of construction: 2008, functionality: fully functional, Working Area Max swing diameter over bed: 500 mm Swing diameter over cross slide X: 375 mm Max turning diameter: 246 mm Iedpfx Ajxz E Uyjdija Max turning length: 445 mm Chuck diameter: 210 mm Bar capacity: 65 mm Cross travel (X): 213 mm Longitudinal travel (Z): 450 mm Feeds Rapid traverse X/Z: 24 / 30 m/min Main Spindle Spindle nose (flat flange): 140 h5 mm Front bearing inner diameter: 100 mm Spindle motor power (40/100% ED): 16 / 12 kW Torque (40/100% ED): 153 / 115 Nm Spindle speed: 25–6000 rpm Tool Turret Number of tool stations: 12 Motorized stations: 12 Shank diameter (DIN 69880): 30 mm Motor power (40% ED): 9 kW Max torque (40% ED): 20 Nm Max speed: 4500 rpm Tailstock Automatic tailstock travel: 450 mm Center taper: MT 4 Max tailstock thrust: 400 daN Year of construction: 2008 Machine equipment: • Chip conveyor • Preparation for fume extractor • Various fixed and driven tool holders • Instruction manuals

Condition: used, Year of construction: 1995, Technical details: turning diameter: 340 mm turning length: 530 mm control: MSD 516 TB 2 Dialog swing dia.: 520/350 mm rapid power traverse in X-and Z direction: 12/15 m/min chucking diameter: Kitagawa B 210 (250 mm) bar material dia.: 65 mm spindle drive: 18,5 / 15 kW spindle speed:: 35-3500 1/min max. torque on the spindle: 490 spindle nose: JIS A2-6 turret stations / rotary tool stations: 12/6 RPM of rotary tools: 80-2000 1/min Iodpfx Aoxz Ehtsdioa tailstock quill taper MT: MK5 tailstock quill stroke: 110 mm tailstock quill diameter: 100 mm Tailstock Travel: 491 mm total power requirement: 40 kVA weight of the machine ca.: 4,4 t dimensions of the machine ca.: 4x1,7 m Accerories Chip conveyor manual tool eye Very solid CNC turning center. Machine is in good condition. Several tool holders, static and rotary come with the machine. *

Condition: used, Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Isdpfx Adsxz D Sqeija Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: used, Year of construction: 2001, Technical details: turning diameter: 500 mm turning length: 1000 mm control: Siemens 840 D Isdpfxjxz Drdj Adija spindle: 42 / 28 kW spindle turning speed - stepless: 31 - 4000 1/min max. torque on the spindle: 345 Nm c-axis: 360000 x 0,001° feeds -stepless-: mm/min rapid traverse: mm/min turret stations / rotary tool stations: 12/12 VDI 40 RPM of rotary tools: 2000 1/min diameter of quill: 90 mm quill stroke: 80 mm tailstock quill taper ISO: SK 30 Tailstock Travel: 600 mm Power rotary tools: 3,5 kW : 22,5 Nm Rotary tool holders: 4 ax./ 4 rad. spindle passage: 66 mm total power requirement: 30 kW weight of the machine ca.: 7,5 t dimensions of the machine ca.: 8x 3 x 4 m Accerories Power Chuck Programmable Tailstock Chip conveyor

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, turning length: 300 mm, TECHNICAL DETAILS Turning length: 300 mm Distance between centers: 800 mm MACHINE DETAILS Iedoxz Apbjpfx Adisa Control: FANUC 16T EQUIPMENT 3 turrets Sub-spindle

Condition: excellent (used), Year of construction: 2008, HYPERTURN 665 MCplus - B-PowerMill Multi-Axis CNC Turning Center with automatic tool changer, Y-axis and B-axis, for complete machining of turned-milled parts. Integrated spindle motors (ISM) on main and sub-spindle with thermocompensation system (liquid cooled). Drive power: Main spindle - 29 kW Sub-spindle - 22 kW Speed range: Main spindle 0-5000 rpm Sub-spindle 0-7000 rpm Ijdpfsxz Ab Rsx Adiea Spindle interface (DIN 55026): Main spindle KK 6 (bore 65 mm) Sub-spindle KK 6 Y-axis: travel range +/- 50 mm The Y-axis is designed so that the resulting cutting forces are distributed over two axes, providing extremely high rigidity for all machining operations. B-PowerMill: For machining inclined surfaces and bores, a motor-driven milling spindle with a 24-position tool magazine is integrated into the upper slide system. The swivel range of 210° is infinitely adjustable and can be interpolated. Preloaded roller guides in all linear axes, digital drive system, integrated spindle encoder, state-of-the-art SINUMERIK 840D control technology, includes: * Hollow clamping cylinder incl. draw tube * Part ejector and coolant supply through the sub-spindle * 12-position VDI 30 radial tool turret with directional logic for up to 12 driven tool stations Swivel speed adjustable with feed switch. Performance data: Max. 6.7 kW at 2650 rpm Constant torque 25 Nm Speed range 0-5000 rpm - C-axis for main and sub-spindle - TRANSMIT software for easy C-axis programming * Parts catcher for finished parts * Sinumerik 840D * Chip conveyor with a programmable discharge height of 1200 mm (hinged belt type) * Coolant system integrated in the chip conveyor: 1 high-pressure pump with 14 bar 1 high-pressure pump with 14 bar incl. 20 µm fine filter 2 flushing pumps with 3.7 bar * Control cabinet air conditioning unit * Electrostatic oil mist separator * Hydraulic unit * Machine lamp * Interface for foot switch * Documentation Included: - Handwheel - PC keyboard - Network preparation - Tool monitoring - Swing-out window - Cleaning gun - Signal lamp Year of manufacture: 2008 Machine No.: R7AW0401

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, turning length: 480 mm, turning diameter: 200 mm, controller model: FANUC 31, TECHNICAL DETAILS Turning length: 480 mm Turning diameter: 200 mm MACHINE DETAILS Iodpfxexzz U No Adiea Control: FANUC 31 EQUIPMENT 3 turrets Sub spindle

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, machine/vehicle number: 804500648E, CNC Lathe Manufacturer: Gildemeister Model: CTX 510 ecoline Machine No.: 8045000648E Year of Manufacture: 2014 Control System: Siemens 840D ShopTurn Chuck Diameter: 315 mm Bar Capacity: 90 mm Drive Power (100% DC/40% DC): 22 kW / 33 kW; 420 Nm / 630 Nm Max. Spindle Speed: 3250 rpm Weight approx.: 7500 kg Equipment: Axes: X, Z, C, and Y axes Tool Turret: Sauter disk turret VDI 40 Tailstock: Yes Quill Stroke Automatic: Yes Chip Conveyor: Yes Measuring Arm Iedpfx Asxzznisdiea C-Axis Y-Axis +60/-60 mm Driven Tools VDI 40/12 stations (all driven) 315 mm 3-jaw chuck Schunk 90 mm bar capacity Subject to prior sale and errors excepted.

Condition: ready for operation (used), Year of construction: 2021, operating hours: 13,392 h, Control Unit Brand SIEMENS Model 840D with ShopTurn 3G Main Drive Tool taper ISM 52 Synchro Spindle Speed 6000 RPM Spindle motor power 13 kW Number of axis 3 Media Chip conveyor Yes Additional Equipment CELOS Products DMG MORI Service Agent DMG MORI NetService DMG MORI IoT Connector DMG MORI Messenger V2 SERVICE Camera Tail Stock Iodpexzvtaofx Adisa the 2 SMW-Autoblok BBD17/52 which can also be seen on the machine chuck. and the addition of the software (tccentric turning and milling cycle, as well as a deburring toothing cycle). This 3-axis DMG MORI CTX Alpha 500 V6 was manufactured in 2021. A versatile turn-mill centre featuring a Siemens 840D controller, ERGOline interface, and CELOS manufacturing support. It offers a 470 mm machining length, 6000 rpm max speed, and a 12-position Sauter turret with live tooling. Ideal for complex machining tasks. Contact us for more information about this machine. Application Types Turning

Condition: ready for operation (used), Year of construction: 2022, General Data Machine weight 620 kg Main Drive Number of axis 6 Spindle Speed 5000 RPM Ijdpexzvttefx Adija Spindle motor power 29 kW This 6-axis EMCO Hyperturn 65 Powermill G2 was manufactured in 2022. A highly productive CNC turn-mill center, it features a main spindle and subspindle both with a max torque of 250 Nm and speeds up to 5000 rpm. The milling spindle offers up to 12000 rpm. Includes a 40-position tool magazine, 12-position turret, and advanced Sinumerik ONE control system. If you are looking to get high-quality turning and milling capabilities consider the EMCO Hyperturn 65 Powermill G2 machine we have for sale. Contact us for more information. Application Types Turning

Condition: used, Year of construction: 2010, longitudinal traverse (z-axis) 6870 mm cross movement. (x-axis) 920 mm centre distance 6500 mm swing diameter over slide rest 900 mm Control Siemens Sinumerik 840D tool taper CAPTO C8 7352 mm max. workpiece weight 9000 kg tools in tool magazin 72 total power requirement 145 kW weight of the machine ca. 47 t dimensions of the machine ca. 11 x 3,2 x 3,5 m Rotary spindle -Spindle diameter - 320 mm -Spindle bore - 245 mm Main drive: -Max. spindle speed - 1600 rpm -Max. torque at the spindle - 4472 Nm C-axis servo-controlled main spindle: -Max. speed - 20 rpm -Max. torque at the spindle - 3000 Nm -Holding torque of the disc brake - 6000 Nm Tailstock: -Quill diameter - 180 mm -Quill stroke - 200 mm Ijdpsxzuvtjfx Adioa -Quill force (adjustable) - 5400 to 40000 N Tool holder: -AC drive power - 30 kW -Max. spindle speed - 6000 rpm -Max. torque at the spindle - 315 Nm -Travel perpendicular to the X/Z plane (y-axis) - 500 mm [-200/+300]mm -Milling spindle diameter in the front bearing - 100 mm Equipment/accessories: -with internal coolant supply -chip conveyor -paper belt filter system -boring bar with device -measuring equipment -clamping sleeves -tool holders -spare parts -technical documentation

Condition: good (used), Year of construction: 2006, Parts shown by hand not come. Ijdjxztv Espfx Adija

Condition: used, Year of construction: 2013, Doosan Puma 480 Turning Centre with Fanuc Series 32i - Model A CNC Control, 600mm Diameter Powered 3 Jaw Chuck, 10 Position Tool Turret, Tailstock, LNS Swarf Conveyor, Filtermist FX6002 Oil Mist Filter Extractor, Machine Weight 10100kg. S/No. ML0144-000404 (2013) Includes Various Tool Holders and Sleeves in Tool Turret and Boxes Location: These lots are located in Scotland, UK. Unfortunately there are no loading facilities on-site, dismantling and loading will be at the cost of the Purchaser. All/Any tooling is being offered as specifically described. Isdpfxsxztl Hj Adija

Condition: used, Year of construction: 2006, Mazak Quick Turn Nexus 350m CNC Turning Centre with Mazatrol 640T Nexus CNC Control, Max Swing 750mm Diameter, Standard Machining Diameter 336mm, Max Machining Diameter 420mm, Bar Work Capacity 102mm, Spindle Speeds Max 4000rpm, 12 Tool Turret, Kitagawa Powered 3 Jaw Chuck, Tailstock, Filtermist FX4002 Oil Mist Extractor, Machine Weight 7500kg. S/No. 184642 (2006) Includes Various Tool Holders in Turret, Driven Tool Holders and Sleeves Ijdpfx Adjxzth Ujisa Location: These lots are located in Scotland, UK. Unfortunately there are no loading facilities on-site, dismantling and loading will be at the cost of the Purchaser. All/Any tooling is being offered as specifically described.

Condition: good (used), Year of construction: 2008, functionality: fully functional, UniCen Series - for large complex components With the Monforts machine tools from the UniCen Series 1000 you can work with large, complex components up to 1500 mm diameter and 1000 mm swing diameter entirely, process capably and cost effectively in one set-up. Great flexibility results from the five interpolating axis. The B axis swivelling drill-mill head with a swivel range of 190 deg. directs the tools to the workpiece in almost every position and every angle. Additionally, the tool head can be loaded fully automatically by 60 tools from a separate chain magazine. Thus, even complex freeform surfaces with high surface finish quality are possible. Advantages > Wear free Monforts Hydrostatic > Optimal vibration damping > Long-term accuracy > Long life and highest machining performance > Complex five axis machining via the B axis swivelling drill-mill head > Turning, drilling, milling and thread-cutting on one machine > Precision ball-screw with preloaded double nut Extensive partial overhaul since November 2023: - All ball screws including bearings overhauled: X1/X2/Y1/Z1/Z2 - All cylinders overhauled - All Siemens motors overhauled: main spindle, tailstock, magazine, tool 1+2, X/Z/Y/B/C/U/W - Siemens control panel replaced, control module and LT module repaired - Clamping elements/ATC renewed: Ortlieb collet, clamping package incl. pull rod - Tailstock quill renewed - All wipers replaced and covers reworked - Drive belts and safety windows renewed - Various cables renewed * CNC Control SIEMENS 840 D * Swivelling milling head at the top (B axis), interpolating, HSK-A 63 * Y axis * C axis * 8-station turret at the bottom, for driven tools * 60-station tool changer * NC-controlled tailstock, quill diameter 150 mm, max. quill stroke 180 mm * Hydrostatic longitudinal guide in the Z-axis * Coolant system with paper belt filter * Chip conveyor * Oil-cooler, make SCHIMPKE * Extraction system Isdpfx Adexztbzjisa * Power chuck, make FORKARDT, diameter 500 mm Technical details turning diameter 800 mm turning length 1500 mm control Siemens 840 D swing over bed 1000 mm swing diameter over slide rest 800 mm max. workpiece weight between centres 2000 kg main spindle speeds: 2000 rpm main drive 62 kW transmission ratio 4 milling spindle drive 37 kW milling spindle turning speed range: 25 - 10000 rpm total power requirement 82 kVA weight of the machine ca. 28 t dimensions of the machine ca. 8,2 x 5,3 x 3,6 m
