Condition: used, Year of construction: 1998, functionality: fully functional, machine/vehicle number: MT90-9118, input voltage: 400 V, PARPAS MT90 / 2500 TG 7-Axis CNC Machining Center (5-Axis Simultaneous) Cedpfx Alez In Uae Aehc The machine is in fully operational, trouble-free, and active working condition. It is of German origin (previously located/imported from Germany) and has been meticulously maintained. All periodic maintenance, inspections, and technical checks have been completed regularly and without exception. The system offers high flexibility for complex operations thanks to its 7-axis configuration and 5-axis simultaneous machining capability coupled with a fully rotatable 360° milling head. • Currently under power and can be inspected in production upon request. • Available immediately. Technical Specifications • Manufacturer: PARPAS • Model: MT90/2500 TG • Year of Manufacture: 1998 • Type of Machine: 7-Axis CNC Machining Center • Control Unit: HEIDENHAIN • X-Axis Travel: 2500 mm • Y-Axis Travel: 750 mm • Z-Axis Travel: 190 mm • Table Size: 1800 x 1800 mm • Machining Capability: 5-Axis simultaneous machining • Milling Head: 360° rotatable / pivoting head

Condition: like new (used), Year of construction: 2025, functionality: fully functional, type of input current: AC, grinding wheel diameter: 30 mm, rotational speed (max.): 24,000 rpm, grinding spindle speed: 24,000 rpm, input voltage: 400 V, New saw blade grinding machine – chip breaker groove grinding machine (demonstration machine) Grinding range approx. 100-630 mm diameter Tooth pitch of saw blade max. approx. 20 mm Control: Siemens PLC with automatic end shut-off after the grinding process Grinding spindle: High-frequency spindle, 24,000 1/min. Power 800 watts! Cooling: Minimum quantity lubrication Bebeqpdi Rerqbnfboln Saw blade clamping: pneumatic Gearbox: running in an oil bath Adjustment of saw blade thickness: via a pre-tensioned ball screw drive with no play Grinding stroke: via heavy-duty linear roller guide Grinding speed continuously adjustable (minimum to maximum) Accessories: - 1 set of reducing rings 16x22, 25, 32, 40, 50 mm - Circuit diagrams - Grinding wheel 30x0.3x6 mm, CBN Operating voltage: 400V, 50 Hz Chjdpjz Ikp Hofx Al Aoc Compressed air connection: required for saw blade clamping and minimum quantity lubrication (very low air consumption)

Condition: used, Tool slide mounting surface 500 x 180 mm Max. tool diameter between centers 130 mm Max. tool length between centers 270 mm 190 mm Tool slide cross-adjustment 100 mm Vertical adjustment of grinding head 325 mm Grinding spindle longitudinal adjustment 5 mm Condition: Used Accessories, tools, and clamping devices shown are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data and specifications, and prior sale. Chodpfx Aez Hfa Rol Asc

Condition: excellent (used), Year of construction: 2014, operating hours: 12,340 h, functionality: fully functional, spindle speed (max.): 10,000 rpm, type of input current: three-phase, grinding wheel diameter: 250 mm, overall weight: 8,100 kg, feed rate X-axis: 20 m/min, feed rate Y-axis: 5 m/min, feed rate Z-axis: 20 m/min, travel distance X-axis: 380 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 280 mm, grinding spindle motor power: 14,000 W, table length: 500 mm, table width: 330 mm, input voltage: 400 V, CNC Tool grinding machine SCHNEEBERGER Gemini DMR Codpfx Aloz Hcg Ie Aohc TECHNICAL CHARACTERISTICS: Year of manufacturing: 2014 CNC control: FANUC 31i B5 Software installed: Quinto Qg1 Colour touchscreen: Yes Number of axes: 5 Stroke X axis: 380 [mm] Max. Stroke speed X axis: 20000 [mm/min] Resolution X axis: 0.0001 [mm] Stroke Y axis: 300 [mm] Max. Stroke speed Y axis: 5000 [mm/min] Resolution Y axis: 0.0001 [mm] Stroke Z axis: 280 [mm] Max. Stroke speed Z axis: 20000 [mm/min] Resolution Z axis: 0.0001 [mm] Table length: 500 [mm] Table width: 330 [mm] Grinding spindle attachment: HSK-50 Max. grinding wheel speed: 10000 [rpm] Grinding spindle motor power: 14 [kW] Max. diameter grinding wheel: 250 [mm] Internal workpiece spindle nose: ISO 50 Number of running hours: 12340 [h] Supply voltage: 400 [V] Rated current: 63 [A] Weight: 8100 [Kg] EQUIPMENT INCLUDED: x1 8-position grinding wheel changer x8 coolant supports x1 tool probe x1 FANUC LR Mate 200iC 5L 6-axis tool-loading robot x1 set of robot grippers x1 pallet for robotic tool loading/unloading x3 HEIDENHAIN linear scales on the X, Y and Z axes x1 electrical cabinet air-conditioning unit x1 spindle chiller x1 fire suppression system (to be inspected by the buyer through a qualified organization) x1 set of 4 lifting brackets x1 set of technical manuals x1 parameter backup on USB flash drive *The SCHUNK collet holder and the 2 grinding wheel holders shown in the photos are not included Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Machine for sharpening/grinding tools such as milling cutters, taps and drills. Machines similar to the following brands: Blohm, ELB, Ewag, Favretto, Fenix, GER, Jones & Shipman, Jung, Karstens, NUMAFFUT, Okamoto, Okuma, Saacke, SMP, Studer, Vollmer and Walter. Also consider cylindrical and surface grinding machines, lathes, machining centres and milling machines.

Condition: good (used), Storage location: 3143 Manufacturer: Jakob Schmid Oberkochen Year of manufacture: 1993 Type: RS 1000 Machine number: 1093 1165 Longitudinal travel of the worktable: 200 mm Transverse travel of the worktable: 180 mm Swivel range of the motor: 350° Vertical adjustment: 350 mm Grinding wheel arbor with centering cone: 10 / 20 mm Grinding wheel speed: 6,000 rpm Arbor with dividing head: SK 30 Swivel range of the dividing head: 360° Grinding wheel diameter: 80 mm Connection power: 0.2 kW Condition: good Accessories/equipment: 6-jaw chuck, Additional attachment, MK5 arbor Cedez E U Arspfx Al Ashc Dimensions with table: 600 x 800 x 1,500 mm Weight of the machine with table: 150 kg

Condition: excellent (used), Year of construction: 2014, 2014 Schneeberger Sirius HPM 6-Axis Tool Grinding Machine With Fanuc Series 31I-Model A5 CNC Control Csdpfsz E R T Hox Al Aehc Gear Tooth Production Steptec GFQ 170E Swivel Spindle Workhead. Travel: 'X' Axis = 420mm, 'Y' Axis = 310mm, 'Z' Axis = 340mm. 'A' Axis (Rotation) = 2,400°/S. ISO40, Centre Height 150mm. Swivel Axis 'B' = 90°, Swivel Axis 'C' = 180°. (1) Hitema Stand Alone Air Cooled Liquid Chiller Type ENR.018/CX.SST.WP.HW.RV.DD.GALV (340kg, 2020). (1) Hyfra Pedia Sigma 13-S Stand Alone Water Cooling Chiller (200kg, 2014). VAS 7041, 400 Litre Stand Alone Filtration System (800mm x 1,300mm x 600mm, 400kg). Sirius S/No. 21828. Quantity of Assorted Arbors, Collets, Grinding Attachments & Associated Tooling to Suit. Probe, Machine Light & Signal Tower. New Battery Fitted 2025. Kraft Bauer Fire Extinguishing System. Elbaron Ronia 100 DV Electrostatic Air Cleaner/Mist Collector. Cosmotec EVE10082207000 7035 Air Conditioner (2013). Power Supply 415 Volt, 3 Phase. Full Catalogues & Manuals Available. Weight of Machine Approx 8,100kg. Dimensions of Machine Approx 1,700mm x 2,270mm x 2,215mm. Note: Client will arrange for the machine to be disconnected and drain the oil (if required) and move to the Exit for collection. During viewing, Client is willing to demonstrate the machine capabilities.

Condition: used, functionality: fully functional, Walter HMC 500 WWM 5-axis tool grinding machine A-axis: 750 mm X-axis: 290 mm Y-axis: 320 mm Z-axis: 660 mm Tool diameter: 200 mm The machine is equipped with linear scales on 3 axes. Chjdpfx Asz E N Upol Aec

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, ISOG Deckel S11, manufactured in 2011. - Grinding diameter, max. 238-620 mm - Grinding length: 190 mm Chjdez E H I Hopfx Al Asc - Workpiece length: 380-940 mm - Spindle speeds: 2000-12000 rpm including accessories: such as video camera Rotary back grinding attachment

Condition: excellent (used), Year of construction: 2005, CNC-controlled gear hob sharpening machine SOLITEC AFS 250 - Complete rebuild of a KLINGELNBERG AGW231 by SOLITEC - - Clean and like-new condition Year of manufacture: 2005 Machine no.: 109/05 Control: SM 300 Technical data: Chsdpfxjz E H His Al Aec Spindle taper: ISO 40 Max. cutter diameter, helical: 230 mm Max. cutter diameter, straight: 250 mm Number of grindable flutes: 1-99 Max. grinding slide stroke: 464 mm Min. / Max. grinding wheel diameter: 150/250 mm Max. grinding depth: 50 mm Setting accuracy, roughing: 0.005 to 0.2 mm Setting accuracy, finishing: 0.005 to 0.1 mm Hydraulic pressure: 12 bar Weight approx. 4,600 kg with coolant band filter system

Condition: good (used), Year of construction: 2010, functionality: fully functional, 5-axis CNC tool grinding machine, Anca RX7 - Year of manufacture: 2010 Chjdpfoz E Hzasx Al Ajc - Software: ToolRoom RN32 - Spindle speed: 10,000 rpm - Double disc changer, capacity up to 8 discs - PLX tool loader

Condition: used, Year of construction: 1965, Technical details: grinding length: 250 mm centre height over plate: 120 mm workpiece length - max.: 600 mm grinding spindle - swivable: 350 ° grinding head adjustable: 230 - 250 mm grinding diameter: 200 mm spindle revolutions per minute : 2200/3500/5200 U/min work table:: 120 × 950 mm table movement: 500 mm table - inclinable: 45 Grad dimensions of grinding wheel: 160 mm total power requirement: 0,5 kW weight of the machine ca.: 0,65 t dimension machine approx.LxWxH: 1.5 × 1.2× 1.65 m The SWU 250 is designed for sharpening and grinding various types of tools. Thanks to the adjustable tool holders and the swivelling grinding head, different tool geometries can be machined. Chsdpsz E Hdzjfx Al Aoc *

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, VOLLMER QXD 250, 6 CNC axes, Vpulse EDM, automatic workpiece loading. Disc eroding machine for complete machining of PCD-equipped rotary tools – measuring, eroding, grinding, and optionally polishing in a single clamping. Technical data QXD 250 + HC 11 CNC axes: 6 Max. workpiece diameter: 320 mm Max. workpiece length: 250 mm Max. workpiece weight: 25 kg HC-11 capacity: 64 workpieces Max. HC-11 loading: 1,200 kg Erosion/grinding wheel diameter: max. 200 mm Main spindle: 4,500 min⁻¹ Torque: 6 Nm X1 / Y1 / Z1: 520 / 970 / 420 mm Coolant tank: 310 liters Machine connection power: approx. 8.7 kVA / 6.8 kW Machine weight QXD 250: approx. 7,200 kg net Dimensions QXD 250 + HC 11 approx. 4,012 × 3,730 × 2,400 mm Chedpez Eympjfx Al Aoc

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: 642, We are selling a polishing machine for polishing and rounding the cutting edges of precision cutting tools. It is primarily designed for carbide tools, including various types of drills and milling cutters. The machine allows for easy replacement of the container for coarse or fine polishing. The machine is in regular use, easy to operate, and consistently performs flawlessly. Cedpfxsz Eib Nj Al Ashc

Condition: used, Year of construction: 2010, functionality: fully functional, grinding spindle speed: 8,000 rpm, grinding spindle motor power: 12 W, Machine in functional condition and can be under power and tested. Codpez Ea Hpjfx Al Ajhc

Condition: refurbished (used), Year of construction: 2009, functionality: fully functional, Available from Q1/2027, or upon agreement. Equipment can be further adjusted to meet specific needs. Universal 5-axis retrofitting grinding machine, directly from the manufacturer. Also available with the latest Horizon grinding software, tailored to the requirements of the tools and components. For re-sharpening hammer jaws, helical milling cutters, bevel gear cutters, cutting rotors, form cutters, industrial knives, circular knives, hobbing wheels, skiving tools, and other workpieces and components. Work area: X-axis 700 mm Y-axis 410 mm Z-axis 500 mm C-axis rotation angle 320° X3 auxiliary axis: Optional Work area 600 mm Grinding spindle: Interface HSK 80 E Power 100% 28.8 kW Speed Standard 12,000 rpm Measuring system and feed: Chjdpfx Alsz Dilfj Aoc Resolution linear axes 0.0001 mm Rapid traverse linear axes 30,000 mm/min Resolution rotary axes 0.001° Speed C-axis 150 rpm Rotary axis: (A-axis SK50) Center height Standard 175 mm Speed as a spindle 1,000 rpm Optional 2,600 rpm Control system: Siemens 840 DSL Tool changer: Double wheel Coolant system: Available upon request Extraction system: LTA Extinguishing system: Kraft & Bauer Dressing unit Additional accessories/clamping devices from the extensive A. Haas clamping device catalog are possible. Individual, customer-specific training. Includes pre-acceptance at the manufacturer's plant, IBN (Initial Batch Numbering), training, and final acceptance at the customer's site. Financing also available upon request.

Condition: refurbished (used), Year of construction: 2010, operating hours: 34,850 h, functionality: fully functional, Available from Q1/2027; equipment can still be adjusted to meet specific requirements. Universal 5-axis retrofitting grinding machine, directly from the manufacturer. Also available with the latest Horizon grinding software, tailored to the requirements of the tools and components. For re-sharpening hammer jaws, helical milling cutters, bevel gear milling cutters, cutting rotors, form cutters, industrial knives, circular knives, hobbing wheels, skiving tools, and other workpieces and components. Working area: X-axis: 700 mm Y-axis: 410 mm Z-axis: 500 mm C-axis: Rotation angle 320° X3 auxiliary axis: Working area: 600 mm Grinding spindle: Interface: HSK 80 E Power: 100% 28.8 kW Speed: Standard 12,000 rpm Measuring system and feed: Resolution, linear axes: 0.0001 mm Rapid traverse, linear axes: 30,000 mm/min Chedpfsz Dhdysx Al Aoc Resolution, rotary axes: 0.001° Speed, C-axis: 150 rpm Rotary axis: (A-axis SK50) Center height: Standard 175 mm Speed as a spindle: 1,000 rpm Optional: 2,600 rpm Control system: Siemens 840 DSL Tool changer: Dual-wheel Coolant system: Optional Extraction system: LTA Fire extinguishing system: Kraft & Bauer Dressing unit Additional accessories/clamping devices available from the extensive A. Haas clamping device catalog. Individual, customer-specific training programs. Includes pre-acceptance at the manufacturer's plant, IBN (installation, commissioning, and handover), training, and final acceptance at the customer's site. Financing options available upon request.

Condition: used, Year of construction: 1998, Walter Heli-Power Production 5-Axis CNC Tool Grinder. Serial No. 6802 (1998). Country of Origin: Germany Chsdpfx Ajz Ar Ebol Aec Centralised Cutting Oil Tank and Eclipse Automag Oil Filtration/Separation System (2016) Please note: This item will be awarded to the highest bid from Lot 1, Lot 1A or Lot 2 Location: These lots are located in Sheffield, UK. Unfortunately, there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser

Condition: ready for operation (used), functionality: fully functional, total height: 1,840 mm, total length: 1,700 mm, total width: 1,750 mm, type of input current: three-phase, overall weight: 1,850 kg, travel distance X-axis: 490 mm, travel distance Y-axis: 130 mm, travel distance Z-axis: 115 mm, grinding spindle motor power: 2,200 W, input voltage: 400 V, spindle nose: HSK 63, Tool grinding machine EWAG RS15 TECHNICAL CHARACTERISTICS: Stroke X axis: 490 [mm] Stroke Y axis: 130 [mm] Stroke Z axis: 115 [mm] Grinding spindle motor power: 2.2 [kW] B axis swivelling stroke: 260 [°] Workpiece spindle nose: HSK 63 Variable power feeding: Yes Digital read out: RSF-Elektronik Number of axes Digital Read Out: 3 Lubrication tank capacity: 100 [l] Centralized lubrication: Oui Supply voltage: 400 [V] Dimensions: 1700 x 1750 x 1840 [mm] Weight: 1850 [Kg] INCLUDED EQUIPMENT: x1 EWAG dividing head (HSK63 tapper) x1 cross table x1 FR15 adjustable-speed grinding spindle drive x1 OR15 adjustable X-axis oscillator (oscillation frequency: 0–68 min⁻¹) x1 mounting unit for PRO15M metric projector (measuring travel: 150 mm) Codpszz Rtujfx Al Ashc x1 MARCEL AUBERT Ø150 mm profile projector Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Machine for sharpening tools, milling cutters, taps and drills. Machine similar to brands Blohm, Elb, Ewag, Favretto, Fenix, Ger, Jones & Shipman, Jung, Karstens, NUMAFFUT, Okamoto, Okuma, Saacke, SMP, Studer, Vollmer, Walter; also consider cylindrical or surface grinding machines, lathes, machining centres and milling machines.

Condition: excellent (used), functionality: fully functional, total height: 1,760 mm, total length: 1,100 mm, total width: 800 mm, type of input current: three-phase, grinding wheel diameter: 125 mm, overall weight: 520 kg, input voltage: 400 V, spindle nose: ISO 40, Tool grinding machine DECKEL S11 TECHNICAL CHARACTERISTICS: Grinding wheel diameter: 125 [mm] Workpiece spindle nose: ISO 40 Paper filtration unit: No Supply voltage: 400 [V] Total power required: 2 [kVA] Dimensions: 1100 x 800 x 1760 Weight: 520 [Kg] EQUIPMENT INCLUDED: x1 universal index head - Part N°: 255X0X x10 dividing inserts for universal index head x1 tailstock with transverse adjustment - Part N°: 2621000 x1 tailstock with vertical adjustment - Part N°: 2624000 x1 swivel bracket assembly - Part N°: 2626000 Codjzz Hk Nopfx Al Aohc x1 universal wheel dresser - Part N°: 2628000 x1 universal setting gauge - Part N°: 2570000 x1 spiral and relief grinding attachment - Part N°: 2580000 x1 relief grinding slide - Part N°: 2673000 x1 machine vice - Part N°: 2635000 x1 opto-electronic measuring unit with miscroscope - Part N°: 2650012 x2 digital readouts RSF-Elektronik x1 radius grinding attachment - Part N°: 2601X00 x1 LED lamp x3 feet pads Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Machine for sharpening tools, milling cutters, taps, and drills. Similar to brands such as Blohm, Elb, Ewag, Favretto, Fenix, Ger, Jones & Shipman, Jung, Karstens, NUMAFFUT, Okamoto, Okuma, Saacke, SMP, Studer, Vollmer, Walter. Also see cylindrical or surface grinders, lathes, machining centers, and milling machines.

Condition: ready for operation (used), functionality: fully functional, total height: 1,840 mm, total length: 1,700 mm, total width: 1,750 mm, type of input current: three-phase, overall weight: 1,850 kg, travel distance X-axis: 490 mm, travel distance Y-axis: 130 mm, travel distance Z-axis: 115 mm, grinding spindle motor power: 2,200 W, input voltage: 400 V, Tool grinding machine EWAG RS 15 TECHNICAL CHARACTERISTICS: Stroke X axis: 490 [mm] Stroke Y axis: 130 [mm] Stroke Z axis: 115 [mm] Grinding spindle motor power: 2.2 [kW] B axis swivelling stroke: 260 [°] Workpiece spindle nose: HSK 63 Variable power feeding: Yes Digital read out: RSF-Elektronik Number of axes Digital Read Out: 3 Lubrication tank capacity: 100 [l] Centralized lubrication: Yes Supply voltage: 400 [V] Dimensions: 1700 x 1750 x 1840 [mm] Codpfezzyrtox Al Ajhc Weight: 1850 [Kg] Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Machine for sharpening tools, milling cutters, taps and drills. Machine similar to brands Blohm, Elb, Ewag, Favretto, Fenix, Ger, Jones & Shipman, Jung, Karstens, NUMAFFUT, Okamoto, Okuma, Saacke, SMP, Studer, Vollmer, Walter; also consider cylindrical or surface grinding machines, lathes, machining centres and milling machines.

Condition: used, Year of construction: 1992, machine/vehicle number: 12/7, No minimum price – guaranteed sale to the highest bidder! The machines are still assembled, but disconnected from the power supply. An 11-ton forklift is available on-site for loading. For sale is a tool grinding machine from the manufacturer Schütte, model: WU 750 CN. Chsdpfxezy Ulfe Al Aoc TECHNICAL DETAILS Rated operating voltage: 380 V Phases: 3 Frequency: 50 Hz Rated current: 25 A

Condition: good (used), Tool grinding machine Stock number: 3141 Manufacturer: Walter Year of manufacture: 1984 Machine number: 025 Type / Model: Helitronic 30 NC Control system: Grinding wheel diameter: 75 to 125 mm Maximum grinding wheel diameter: 200 mm Grinding wheel arbor: 20 mm Maximum workpiece diameter: 265 mm Maximum workpiece length between centers: 430 mm Maximum workpiece length between spindle nose and tailstock: 535 mm Work table: 890 x 130 mm Swivel range: 135° Chjdpfx Ajzy Iyvjl Asc Speed: 1,400 / 2,500 / 2,800 / 5,000 rpm Spindle power: 1.4 kW Longitudinal travel (x-axis): 360 mm Grinding head, vertical axis swivel range: 360° Horizontal axis swivel range: 220° Vertical adjustment: 230 mm Cross travel (z-axis): 180 mm Workpiece carrier (a-axis) Arbor: ISO 50 Maximum number of teeth: 999 Smallest pitch: 1 mm Center height: 135 mm Swivel range around the vertical axis: 360° Swivel range around the horizontal axis: +90° / -25° Equipment: Condition: good Total connection power: 7 kW Weight: 0.5 t Machine dimensions: 1,000 x 1,000 x 1,600 mm Control cabinet dimensions: 550 x 450 x 1,700 mm

Condition: ready for operation (used), functionality: fully functional, Universal tool grinding machine DECKEL S 11 with accessories & tool cabinet -Grinding stroke 190mm -Grinding stroke during orbital grinding 190mm -Longitudinal adjustment of the grinding spindle approx. 5mm -Vertical adjustment of the grinding head approx. 320mm -Transverse adjustment of the tool slide approx. 100mm -Adjustment ranges: -Grinding head carrier approx. 800mm -Tool carrier approx. 215mm -Universal / dividing head approx. 330mm -Swivel angle / grinding head carrier 360 degrees / grinding head 360 degrees / tool carrier 360 degrees -Clamping surface of the tool slide approx. 500x180mm -Max. workpiece diameter between centers 130mm -Max. workpiece diameter / overhanging clamping (universal dividing head) 620mm -Digital display -Measuring optics Chodpfxezx R Awo Al Aoc -Further accessories (SEE PICTURES) -Documentation -Tool cabinet Errors and omissions excepted.

Condition: good (used), Universal tool grinding machine Stock number: 3136 Manufacturer: WMW (Gotha) Year of manufacture: 1976 Type: SWU 250-I Machine number: 201/76 Working area Maximum workpiece length: 600 mm Maximum workpiece diameter: 250 mm Maximum disc cutter diameter: 360 mm Maximum grinding length: 450 mm Table Chodpfozx D U Tox Al Asc Table travel, longitudinal, manual: 500 mm Table travel, longitudinal, automatic: - Table swivel: 0-90° Working surface: 120 x 950 mm Taper in the universal chuck: MK 5 Taper in the tailstock: MK 2 Grinding spindle Grinding spindle head height adjustment: 250 mm Cross travel: 230 mm Rotatable: 350° Tiltable: 15° Maximum disc diameter: 160 mm Grinding spindle speeds: 2200/3500/5200 rpm Power consumption: 1.8 kW Condition: good Accessories/Equipment: extensive accessories – see pictures Dimensions and weights Space requirement: 1,300 x 2,000 mm Machine weight: 0.9 t

Condition: used, Year of construction: 2007, functionality: fully functional, machine/vehicle number: 6043, Year 2007 with Fanuc Series 16Oi Country of origin: CH Voltage: 3x400V/50Hz Dimensions: 216x160x216 cm Net machine weight: 3200 kg TECHNICAL SPECIFICATIONS X-axis: 300 mm Y-axis: 220 mm Z-axis: 180 mm Resolution: 0.0001 mm Clamping capacity: 0.5 – 20 mm Grinding wheel diameter: 0.1 – 16 mm Maximum clamping length: 270 mm Cjdpfx Aezxz R Eol Ashc Grinding wheel diameter: 150 mm A-axis (grinding wheel rotation): -195 / +30° B-axis (grinding head rotation): -75 / +135° C-axis (spindle indexing): 0.001° W-axis: 620 mm U-axis: 500 mm Grinding wheel speeds, continuous: from 2000 min-1 to 7200 min-1 Spindle power: 7 kW Fire extinguishing system – CO₂ Kraft & Bauer – Not verified and no guarantee of functionality. To be serviced by you. Unless otherwise indicated, the technical data is provided without any commitment.
