Condition: ready for operation (used), Gildemeister CNC lathe Model CTX 320 Linear Year : 2003 Working length : 600 mm. Max. working diameter : 245 mm. Spindle speeds : 6000 rpm. Spindle bore 80 mm Spindle speeds on the Sub spindle : 4000 rpm. Spindle borer : 65 mm. Number of tools : 12 pcs. No. of rotating stations : 12 pcs. Spindle speeds rotating tools : 5000 rpm. Ijdpfx Ajzu R E Djm Ueba X-axis travel : 160 mm. Z Travel : 450 mm. Y-axis travel : +/- 35 mm. Control : Siemens Cycle hours : 29000 Equipped with : -Subspindle -ECO LM 65 loader -2 straight rotating tool -2 angle rotating tool -6 holder -Chuck -Manuals

Condition: good (used), Year of construction: 2007, operating hours: 37,000 h, functionality: fully functional, Fanuc 31i-TA control system, two turrets, counter spindle, Nakamura CNC portal loader GR210, 14-position stack magazine, SMW-3 3-jaw chuck for HS and GS, Isdezut Izopfx Am Ujba fixed tool holders and automatic tool changer. Available immediately.

Condition: repair required (used), Year of construction: 1998, functionality: limited functionality, turning length: 330 mm, turning diameter: 248 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 190 mm, travel distance Z-axis: 370 mm, The machine’s control system is defective. TECHNICAL DETAILS Turning diameter: 248 mm Turning length: 330 mm Travel distance X-axis: 370 mm Travel distance Z-axis: 190 mm Spindle bore: 45 mm Spindle speed: 6,000 rpm Tailstock quill travel: 120 mm MACHINE DETAILS Transformer: 400 V / 200 V EQUIPMENT Integrated CNC control Machine and control as a closed transport unit Linear guides in the X and Z axes Continuously variable AC main spindle drive Programming for constant cutting speed Integrated cold light Power meter for the main spindle drive Controls for automatic, manual operation and CNC programming Central control panel on the right side of the machine High-dynamic three-phase servo motors for the X and Z axes Backlash-free, pre-tensioned precision lead screws for the X and Z axes Automatic central lubrication with electrical monitoring for bed, cross slide and ball screw drives Ibsdpozul Utefx Am Usa Coolant system with tank, pump, lines and nozzle Electric 12-station turret system MORI SEIKI with automatic direction logic Direct coolant supply through the turret Fixed hydraulic unit for the power chuck Full enclosure of the working area Front sliding door with large viewing window Electrical connection for chip conveyor prepared Data interface V.24 / RS-232-C Control cabinet Freestanding transformer 400 V / 200 V

Condition: defective spare-parts repository (used), Year of construction: 1996, turning length: 330 mm, turning diameter: 248 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 370 mm, travel distance Z-axis: 190 mm, TECHNICAL DETAILS Turning diameter: 248 mm Turning length: 330 mm Travel range X-axis: 370 mm Ibodpfx Amezul Umj Uea Travel range Z-axis: 190 mm Spindle bore: 45 mm Spindle speed: 6,000 rpm Tailstock travel: 120 mm

Condition: used, Gildemeister CTX 320 Linear V6 with Y axis New 2005. FANUC 18T . Collet chuck Supplied with no collets, the original 3 jaw chuck will be supplied. there is also the option to supply a bar feed unit (Imeca VIP 70CNC, year 2001) which is compatible for the machine, however currently not set up. VDI and Driven Tooling Supplied as per images - Note Filtermist Unit will not be supplied Ijdpsztb Tcefx Am Uoba

Condition: used, Year of construction: 2006, operating hours: 32,615 h, functionality: fully functional, machine/vehicle number: R7S017, spindle bore: 65 mm, spindle speed (max.): 5,000 rpm, type of input current: three-phase, Colchester Tornado T8MSY CNC Turning Centre TOTAL PRICE: £15,000 +VAT Manufacturer: Colchester / 600 Lathes Model: Tornado T8MSY Year of Manufacture: 2006 Ibjdpfx Amszr Ngno Uja Control: FANUC CNC Control 18i-TB Serial No: R7S017 Location: Dynomec, Castleford, West Yorkshire Max Bar Capacity: 65mm Diameter Machine Overview & Specification • Configuration: CNC Turning Centre with Driven/Live Tooling, Sub-Spindle, and Y-Axis • Max Spindle Speed: 5,000 RPM • Electrical Requirements: 415V / 3 Phase / 50 Hz / 53 Amps • Power On Hours: ~32,615 Hours (see control screen image for exact breakdown) • Cutting Hours: ~7,781 Hours (see control screen image for exact breakdown) • Total Parts Count: 307,051 (as shown on control screen) NOTE ON MACHINE HOURS & PARTS COUNT: The screen readings pictured were taken prior to listing. The machine was operated for a couple of days after the photos were taken, so the current power-on hours, cutting hours, and total parts count will be slightly higher than shown. Included Package • Bar Feeder: Tornado MBF1000T 1-Metre Short Magazine Bar Feeder • Tool Holders: Comprehensive assortment of static and live VDI tool holders (as shown in photos) • Collets: Assortment of collets included • Jaws: Assortment of chuck jaws included IMPORTANT NOTE ON TOOLING: Sale includes the tool holders only. Any cutting inserts, drills, end mills, or boring bars pictured fitted inside the tool holders are shown for demonstration and are excluded from the sale. Payment, Collection & Transport Terms • Cleared Funds: Machine will not be released, loaded, or dismantled until full payment has cleared into our account. • Transport & Rigging: The buyer is fully responsible for all machine rigging, lifting equipment, transport, and loading logistics. • Collection Timeframe: The machine must be collected and removed from site within 14 days (2 weeks) of purchase. Additional Terms & Viewings • Pricing & VAT: Price includes VAT. A full VAT invoice will be provided. • Returns Policy: Returns are not accepted. Sold as seen. • Viewings: Viewing under power on site at Dynomec Ltd, West Yorkshire, is heavily recommended prior to committing to purchase so buyers can fully inspect and satisfy themselves with the machine's condition. Viewings are strictly by prior appointment. • Warranty: Sold with no implied or given warranty. • Availability: This item is listed elsewhere; we reserve the right to remove this listing at any time. Contact: For any further information, please contact us directly. A VAT Invoice is able to be supplied with the machine

Condition: used, Year of construction: 2004, functionality: fully functional, turning length: 307 mm, turning diameter: 250 mm, spindle bore: 51 mm, travel distance X-axis: 185 mm, travel distance Z-axis: 370 mm, Key figures at a glance: 250 mm maximum turning diameter, 420 mm swing over bed, 307 mm maximum turning length, 51 mm spindle bore, 4000 rpm maximum spindle speed, 5.5/7.5 kW main motor, an 8-station turret, 185 mm X-axis travel and 370 mm Z-axis travel. The year of manufacture is 2004 and the control system is a Fanuc Series 21i-TB. The machine plate states a supply of 220 V, three phase, 50/60 Hz, 42 A and a maximum power supply of 16.1 kVA, with control voltages of 100 V AC and 24 V DC. Isdpfx Amszr Ir Ae Uoba Buyers on a 400 V network should plan for a matching transformer. The approximate footprint is 1600 x 1280 x 1890 mm at a weight of around 2800 kg

Condition: good (used), Year of construction: 2004, functionality: fully functional, Technical details turning diameter 210 mm turning length 700 mm control Okuma OSP-E 100 L total power requirement 35,7 kVA weight of the machine ca. 7,1 t dimensions of the machine ca. 2660 x 2000 x 2330* mm Additional information CNC turning and milling center with C-axis and Y-axis, 2 turrets, and subspindle. The machine is being sold partially overhauled. CNC control: Okuma OSP-E 100 L Maximum turning diameter: 210 mm Swing over bed: 400 mm Distance between spindle noses: 960 mm Main spindle: Spindle bore: 53 mm Speed range: 50 to 6000 rpm Motor power: 11/7.5 kW Subspindle: Spindle nose: JIS A2-6 Speed range: 38 to 5000 rpm Motor power: 11/7.5 kW Z-axis: Travel: 700 / 700 mm (ZA + ZB) Rapid traverse: 40000 mm/min W-axis: Travel: 940 mm Rapid traverse: 40000 mm/min X-axis: Travel: 167 / 192 mm (XA + XB) Rapid traverse: 30000 mm/min Y-axis: Travel: 92 mm (+50/-42 mm) Rapid traverse: 15000 mm/min C-axis: Indexing: 360 x 0.001 deg. Rapid traverse: 400 rpm Disc turret: 2 x 12 stations Tool holder mount: VDI 30 mm Power of driven tools: 4 kW Total connected load: 35.7 kVA Machine weight: 7100 kg Machine dimensions: 2660 x 2000 x 2330 mm* Plus swarf conveyor and bar loader Accessories FMB Turbo 5-42/6200/A bar loader, year of manufacture 2005 Chip conveyor Coolant system Collet chuck for main and subspindle Both turrets equipped with tool holders Machine documentation. Ibjdpfx Amszru Uks Uja

Condition: used, Year of construction: 2002, functionality: fully functional, Equipment: documentation/manual, CMZ Turning Center 2 Axes: X, Z Model: TBI-520 CNC: Fanuc Year: 2002 Ibjdpfx Amezqbkcs Uea Without Tailstock

Condition: used, Year of construction: 2015, CMZ TX 66 Y2 Quattro Year 2015 Ibjdpfxozp Itus Am Uoa Fanuc 31i control Maximum turning diameter (mm): 255 Distance between spindle centers (mm): 639 Maximum speed (rpm): 4000 Maximum bar diameter: 66 mm X-axis: 190 mm Y-axis: +- 40 mm Z-axis: 500 mm Chuck: 210 mm 2 BMT 55 tool heads 2 spindles 2 Y-axes Spindle bore: 66 mm Tool probe Chip conveyor Tooling included Documentation

Condition: used, Year of construction: 2006, machine/vehicle number: IntNr231573, A used MORI SEIKI NL 2500/1250 CNC lathe, year of manufacture 2006, is available for sale. The machine is equipped with a MORI SEIKI MSX 850III / MAPPS III control system and an IRCO SIMAG bar feeder for automatic bar loading. Technical data Control: MORI SEIKI MSX 850III / MAPPS III Origin: Japan Design: Slant-bed CNC lathe Centre distance: 1,250 mm Maximum turning length: 1,298 mm Iedpfx Ajzp Ig Ijm Usba Maximum turning diameter: 356 mm Standard turning diameter: 275 mm Swing diameter over bed: 923 mm X-axis travel: 260 mm Z-axis travel: 1,345 mm Spindle speed: up to 4,000 rpm Spindle bore: approx. 80 mm Turret: 12 stations Number of turrets: 1 Chip conveyor Driven tools C-axis Y-axis Machine weight: 7,600 kg Machine dimensions (L x W x H): 5,000 x 2,300 x 2,400 mm The machine can be inspected under power by prior appointment. Technical data and specifications subject to change and error. Sale subject to prior sale.

Condition: used, Year of construction: 2005, machine/vehicle number: IntNr231574, Machine Specifications Control: MORI SEIKI MSX-850 Design: Slant-bed turning center Version: SY with Y-axis Turret: 12-position with driven tools Working Area Max. turning diameter: 356 mm Standard turning diameter: 275 mm Iedpfx Amezp Ifwj Ujba Max. turning length: 705 mm Traverse Travels X-axis: 260 mm Y-axis: ±50 mm / total approx. 100 mm Z-axis: approx. 795 mm Rapid traverse X/Y/Z: 30 m/min Counter spindle LNS Quick Load Servo 2 bar feeder Max. bar length: approx. 1,500–1,600 mm / 63" The machine can be inspected under power by appointment. Specifications and technical details are subject to change and error. Prior sale reserved.

Condition: used, Year of construction: 2000, controller manufacturer: Siemens, controller model: 840D - Powerline, _____ Description: Year of manuf. : 2000 Control : Siemens 840D - Powerline Turning diam. : 150 mm Mainspindle: Speed:5.000 rpm Power (max.):25 kW Torque (max.):263 Nm Barcapacity:65 mm Subspindle: Speed:5.000 rpm Power (max.):25 kW Torque (max.):263 Nm Toolcarrier I (X/Z): Technology:Turret with 12 stations Taper:VDI 30 Tooldrive:4.500 rpm Movement in X/Z:170/445 mm Rapid travers in X/Z:24/30 m/min Toolcarrier II (X/Z): Technology:Turret with 12 stations Taper:VDI 30 Tooldrive:4.500 rpm Movement in X/Z:170/445 mm Rapid travers in X/Z:24/30 m/min Equipment/Accessory: Chipmanagement:Chip conveyor Coolingmanagement:Coolant pumps Rawmaterialfeed:Interface Barloader Ibedpfx Aozpczmjm Uja : Attention:Displayed Clamping devices and tools are NOT included in our offer!

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, MAZAK QUICK TURN NEXUS 250-II M 500U Max. machining diameter: 380 mm Ibodpfx Aeznnl Iom Uja Max. machining length: 504 mm Max. milling speed: 4,500 rpm Max. spindle speed: 4,000 rpm Max. bar diameter: 74 mm Machine is equipped with: - CNC control: Mazatrol Matrix - KITAGAWA 3-jaw chuck, B-210, diameter 254 mm - Tool Eye - C-axis - NC tailstock - reinforced coolant pump - chip conveyor, discharge to the side - 8 pcs. fixed tool holders - 2 pcs. driven tool holders

Condition: good (used), Year of construction: 2005, Parts shown by hand not come. Ibjdpfxjzmx I Do Am Usa Technical details are in attachment. Measurement arm not come with machine. Please see photos marked with red cross.

Condition: good (used), Year of construction: 2003, CNC: GE Fanuc Series 18i-TB No. 02 motorized turrets Y-axis on rear turret Sub-spindle TOP loader Iedpfx Amjzmgh Eo Uoba

Condition: refurbished (used), Year of construction: 2018, functionality: fully functional, turning diameter over cross slide: 270 mm, turning length: 639 mm, turning diameter: 255 mm, spindle bore: 66 mm, spindle speed (max.): 5,000 rpm, spindle speed (min.): 4,000 rpm, travel distance X-axis: 190 mm, travel distance Z-axis: 500 mm, spindle motor power: 15 W, rapid traverse X-axis: 16 m/min, rapid traverse Y-axis: 12 m/min, rapid traverse Z-axis: 20 m/min, total height: 2,030 mm, total length: 2,840 mm, total width: 2,190 mm, overall weight: 9,300 kg, Equipment: documentation/manual, This CNC lathe has been fully inspected and overhauled directly by the manufacturer, CMZ. The work included replacing the main components subject to wear, restoring the geometries, and completely realigning the machine, bringing it back to a condition of high precision and reliability. Key features: - CNC FANUC 31iTB iHMI - Main and secondary spindles - Double turret with Y-axis - Removable tool presetter - Chip conveyor with lateral discharge - Second high-pressure coolant pump (8 + 15 bar) - Used IEMCA MASTER 80 bar loader available upon request Main overhaul operations: - Replacement of the B-axis slides - Replacement of the belts and seals of the main and secondary spindles - Installation of a new complete secondary spindle assembly - Overhaul of the B and lower Z axis guards - Restoration of the machine's geometries Isdpfx Amszlymxe Usba - Realignment of the S1 and S2 spindles - Realignment of the turrets - Complete check of the powered tools Upon request, we can provide a complete list of the operations performed and photographic documentation of the main stages of the overhaul carried out by the manufacturer. For over 30 years, Otto Machine has been selecting and selling used machine tools in Italy and abroad. The machines can be viewed at our showroom or via video call. Contact us to receive the complete technical data sheet, photographs, videos, and all information about the machine. It is possible to arrange a visit to our showroom or a video call to view it remotely.

Condition: used, turning diameter over cross slide: 250 mm, rotational speed (max.): 3,500 rpm, CNC Lathe Brand: Biglia Model: B131/S1 Maximum turning diameter: Ø250mm Distance between centers: 400 mm Spindle bore: Ø49 mm Maximum spindle speed: ±3500 RPM Isdszlfqvopfx Am Ueba Digital readout

Condition: like new (used), Year of construction: 2022, MAZAK QUICK TURN 250MY SmoothG Iedpfszk I Tqsx Am Uoba Max. turning diameter: 380 mm Max. turning length: 504 mm Max. milling speed: 5,000 rpm Max. spindle speed: 4,000 rpm Max. bar diameter: 80 mm The machine is equipped with: - CNC control: Mazatrol SmoothG - KITAGAWA 3-jaw chuck, BB-210, diameter 254 mm - Tool Eye - C-axis - Y-axis - Interface for bar feeder - Automatic parts catcher - NC tailstock - Reinforced coolant pump - Chip conveyor - 8 pcs. fixed tool holders - 2 pcs. powered tool holders The machine has only 900 hours of pure machining time!!!

Condition: good (used), Year of construction: 1998, Swing diameter 248 mm Iodpfxozk D N Ij Am Ueba Turning length 330 mm Travel – z-axis 190 mm Travel – x-axis 370 mm Spindle bore 45 mm Quill stroke 120 mm Spindle speed 6,000 rpm

Condition: used, Year of construction: 1993, CNC Lathe REALMECA type T400 Travel X: 200 mm Travel Z: 600 mm Numerical Command: NUM 750 Between points distance: 700 mm Max machining diameter: Ø 210 mm Spindle speed: from 100 to 4000 RPM 12 tools Turret VDI 20 3-jaws chuck Ø 140 mm Year of construction: 1993 Spindle motor: FANUC Tailstock: CM4 Hydraulic Tailstock + Chuck Lubrification Voltage: 380 V Dimensions (L x W x H): 2500 x 1500 x 1700 mm Iedjzku I Uspfx Am Uoba Weight: approx 3 T

Condition: used, Year of construction: 2002, turning diameter over cross slide: 260 mm, turning diameter: 200 mm, spindle speed (max.): 500 rpm, travel distance X-axis: 160 mm, travel distance Z-axis: 450 mm, rapid traverse X-axis: 20 m/min, rapid traverse Z-axis: 30 m/min, total height: 2,377 mm, total length: 4,165 mm, total width: 1,594 mm, overall weight: 3,200 kg, bar diameter (max.): 50 mm, For sale is a CNC turning machine with 6 driven tool positions, manufactured by Gildemeister, model CTX 310, from the year 2002. The machine is in good condition; of particular note are the low spindle hours and the measuring system. Technical data: Year of manufacture: 2002 Max. spindle speed: 5,000 rpm Speed at constant power: 833-3890 rpm Spindle power: 7.5 kW Chuck diameter: 210 mm Spindle bore: 68.5 mm Distance between centers: 581 mm Center height: 190 mm Isdezkr Skepfx Am Ujba Diameter over machine bed: 330 mm Diameter over slide: 260 mm Swinging diameter: 200 mm Bar capacity: 50 mm Z-axis travel: 450 mm X-axis travel: 160 mm Rapid traverse Z: 30 m/min Rapid traverse X: 20 m/min Rapid traverse C1: 100 rpm Torque C1: 112 Nm Feed force Z: 4500 N Feed force X: 4500 N Number of axes: 2 Turret with tool drive from Sauter Tool positions: 12 Driven tool positions: 6 Cross-section of tools: 20*20 mm Speed of driven tools: 4200 rpm Power of driven tools: 4.2 kW Footprint (installed): 4,165 * 1,594 * 2,377 mm Footprint (transport): 3,190 * 1,600 * 1,700 mm Weight: approx. 3,200 kg Upon request, transport and loading can be arranged throughout Europe for an additional charge. Prices are plus VAT. Inspection is possible by appointment. Contact us, our team will be happy to assist you. Trade-in or exchange is possible! Machine buying and selling PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES, ETC. Do you need a high-quality but affordable metalworking machine for your production? Or do you want to sell yours? For more information or contact options, visit our website.

Condition: good (used), Year of construction: 1997, operating hours: 38,000 h, functionality: fully functional, 1 used CNC lathe Ibodpfozh Ea Nox Am Uoa Manufacturer: Gildemeister Model: CTX 200 Control: Heidenhain Elekto Pilot 1190 Year of manufacture: 1997 Operating hours: approx. 38,000 hours Swinging diameter over bed: 440 mm Swinging diameter over slide: 210 mm Turning length: 305 mm Bar capacity: 42 mm Spindle speed: 5000 rpm Turret: 12 stations Tool holder: 20 VDI Machine dimensions L x W x H: 2800 x 1651 x 1771 mm Machine weight: approx. 3000 kg Accessories: Coolant system Tailstock Documentation -- Used machine, no warranty -- -- Subject to prior sale and errors --

Condition: good (used), Year of construction: 2010, operating hours: 5,750 h, functionality: fully functional, turning length: 393 mm, turning diameter: 200 mm, spindle bore: 51 mm, MSX 853 cnc control 3-jaw chuck diameter 210mm 12-fold revolver C-axis driven tools tail stock Ibjdpfx Amozd S S Rs Uja coolant device chip conveyor Technische Daten: / technical details Drehdurchmesser / turning diameter 200 mm Drehlänge / turning lenght 393 mm X-Weg / X-travel 160 mm Z-Weg / Z-travel 450 mm max. Drehzahl Spindel / max. spindle speed 50-3000 UpM /rpm Eilgang X/Z / rapid feed X/Z 24/30 Anzahl der Revolverplätze / number of tool places 12 max. Stangendurchmesser / max. bar diameter 51 mm Antriebsleistung Spindel / drive capacity spindle 13,5 kW Gewicht ca. / weight ca. 3500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: like new (used), Year of construction: 2015, machine/vehicle number: TXLT5096, turning diameter over cross slide: 220 mm, turning length: 454 mm, turning diameter: 340 mm, spindle bore: 51 mm, spindle speed (max.): 3,200 rpm, travel distance X-axis: 185 mm, travel distance Y-axis: 30 mm, travel distance Z-axis: 530 mm, rapid traverse X-axis: 24 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 24 m/min, Equipment: rotational speed infinitely variable, TAKISAWA TCY 200 YL5 LATHE • Type: TAKISAWA TCY 200 YL5 Lathe Iedpfxozc Edrj Am Uoba • Year: 2015 • CNC: FANUC 32iB • Travel: X/Z/Y/A 185/530/30/580 mm • C-axis • Machinable length: 454 mm • Maximum workpiece diameter above the machine bed: 340 mm • Maximum workpiece diameter above the carriage: 220 mm • Bar capacity: 51 mm • Spindle speed: 3200 rpm • Spindle power: 7.5/5.5 kW • Spindle nose: A2-6 • Turret: 12 stations • Live tool speed: 6000 rpm • Live tool power: 3.7/2.2 kW • Digital tailstock • Rapid traverse X/Z/Y/A: 20/24/10/20 m/min • Dimensions: 2880 x 1795 x 1700 mm • Weight: 4.1 t • 200 mm diameter chuck with automatic control • Chip conveyor • 11 tool stations • 2 axial turning tool stations • 2 radial turning tool stations • 1 live center • Documentation • Machine available for inspection in ARDENNES.
