Condition: used, Year of construction: 2017, working length: 3,000 mm, working height: 1,300 mm, total width: 1,450 mm, total length: 3,100 mm, total height: 1,000 mm, pressure (max.): -0.95 bar, pressure: -0.95 bar, No. 04494 Vacuum press / Membrane press BARTH VMP 3013 Used, year of construction 2017, mint condition Made in Germany (MSM Maschinenbau GmbH) The vacuum membrane press can be used for all gluing, bonding and layering applications Extra stable VMP class designed for continuous operation with high throughput The powerful units generate a vacuum of 98%, which corresponds to a pressure of 10 tons/m2 Short clamping times of 5 - 6 minutes Pressing area 3000 x 1300 mm LW Silicone membrane Tsdpfx Aaexr Ntbsced Vacuum pump BUSCH RA 0025 F Vacuum pressure max. -0.95 bar Storage volume vacuum tank 250 l Suction volume vacuum pump 25 m3/h Machine equipped with a cover plate (as membrane protection or storage surface) Press is mobile Technical documentation available Transport dimensions approx. 3100 x 1450 x 1000 mm LWH Weight approx. 500 kg To avoid possible misunderstandings, an on-site inspection is possible and recommended by appointment Sold as is Technical specifications, condition description, year of construction and scope of delivery according to manufacturer's brochure or previous owner, without guarantee Subject to prior sale For used machines, any warranty is excluded, the following applies: “sold as seen” Terms of payment: Prices plus VAT, payment before collection or dispatch Terms of delivery: ex warehouse

Condition: excellent (used), Year of construction: 2021, operating hours: 350 h, functionality: fully functional, The vacuum membrane press with a pneumatically lifted membrane is designed for heating and forming thermoformable materials such as PET felt, solid surface (CORIAN, HI-MACS, STARON, KERROCK, LG, PLEXIGLAS, and others), which can be molded into any shape after heat treatment. It is equipped with a heating system that shortens the bonding time and increases production efficiency. The TVG series vacuum presses are intended for both small and large manufacturing facilities. Manufacturing date 2021 Applications • Veneering flat and shaped elements with natural veneer (doors, frames, chairs, tables, furniture, coffins) • Laminating elements with HPL laminates in 2D format (kitchen countertops, window sills) • Pressing textured surfaces (stone veneer, decorative mats) • Manufacturing components using the sandwich method (columns, semi-circles, flat surfaces) • Wrapping car cockpit elements with leather (dashboard, gear shift lever, etc.) • Forming mineral-acrylic solid surface materials such as Corian, Staron, Hi-Macs, etc. • Forming thermoplastic plastics • Forming PET feltProduct Models – TVG Special Series Construction of the Press • Steel Frame: The press is built on a robust, welded steel frame ensuring stability and durability during operation. • Vacuum Table: The worktable is equipped with a vacuum system that securely holds the material in place during the forming process. • Membrane System: A flexible, heat-resistant membrane is pneumatically lifted and lowered, allowing precise pressure distribution on the material. • Heating System: Integrated heating elements (infrared or quartz heaters) provide uniform heat distribution, essential for effective thermoforming. • Control Panel: An intuitive control panel allows easy regulation of temperature, vacuum pressure, and membrane operation. • Vacuum Pump: A high-performance vacuum pump ensures efficient air evacuation for tight membrane adherence. • Safety Features: Equipped with safety sensors and emergency stop buttons to ensure operator protection. • Optional Components: Additional options may include programmable controllers (PLC), touchscreen interfaces, or automatic cycle control for improved process automation. • Tsdpfx Aoxqzzhjacjd Technical Specifications Parameter Working field size (length × width), mm: 3000 × 1500 Maximum height of the processed element with 500mm width in the center of the field: 550 mm Heating plate size, pneumatically lifted: 2000 × 1000 Silicone membrane 700%, max temperature: 230°C Heater power, kW: 6 kW + hot air circulation Pump power, kW: 1.25 Vacuum pump capacity, m³/h: 40 Working vacuum, kg/cm² (bar): – 0.85 Protection level: IP53 Noise level, dB: < 70 Voltage, V: 3P 400 50Hz Machine dimensions (mm): – Length 3500 – Width 1800 – Height (working) 2200 (3100) Weight, kg: 1250 The TVG Special models are equipped with a pneumatically lifted membrane, ensuring high precision and repeatability of forming processes. The reinforced structure and advanced control system guarantee reliable operation in continuous production environments.

Condition: excellent (used), Year of construction: 2021, operating hours: 150 h, functionality: fully functional, machine/vehicle number: 47/11/21, type of input current: three-phase, The VPF series vacuum press is designed for laminating with PVC foil as well as veneering with natural wood veneer. It is suitable for both small and large manufacturing facilities. The VPF Vacuum Press is fully automated and features three operating modes: - Automatic Mode: After pre-setting the working parameters on the PLC controller, the press automatically performs all actions (heating, pressing, cooling). - Manual Mode: The operator manually carries out all operations. - Membrane Mode: Intended for use with a membrane for veneering and laminated bending (also available in automatic mode). Working area: 1400x3000 mm Max temperature: 140°C Power: 30 kW Power supply: 3P 400V 50Hz Dimensions: 3500x1700x2200 mm Weight: 1150 kg APPLICATIONS: - Laminating flat components with PVC foil (kitchen fronts, window sills) - Veneering straight and shaped elements with natural wood veneer (doors, frames, chairs, tables, furniture, coffins) - Laminating components with HPL laminates in 2D format (kitchen countertops, window sills) - Pressing of structured surfaces (stone veneer, decorative mats) CONSTRUCTION: - Robust welded frame, powder-coated - Infrared heating system with carbon heaters Tedexpqt Depfx Aacsd - Three heating zones with adjustable temperature - Pneumatic cylinders for lifting the heating dome - All-round access to the working table - Integrated PLC controller for automated operation - Equipped with an electronic vacuum control system - Working table surface made from HPL board - Built-in oil-lubricated vacuum pump (100 m³) – 0.9-0.95 bar (9000-9500 kg/m²) - Integrated 100-litre buffer tank - Upper heating dome made of aluminum

Year of construction: 2012, condition: excellent (used), COLUMBUS Vacuform Standard Todpexgg Tbofx Aaced High-performance vacuum pump BECKER Vacuum tank 200 l Digital pressure regulation Digital vacuum gauge Highly elastic natural rubber membrane Sturdy worktable Swivel castors with brakes Working dimensions approx. L x W 2900 x 1300 mm Pressing pressure max. 0.85 kg/cm2 = approx. 29 t Connected load 0.75 kW, 400 V 50 Hz Tank capacity 200 l CE Transport dimensions approx. L x W 3100 x 1550 mm Weight approx. 400 kg

Year of construction: 2025, condition: new, functionality: fully functional, The vacuum bag for professionals and handymen - DIRECTLY FROM THE INVENTOR Vacuflex is the ideal vacuum bag for professional users who want to profitably produce exceptional workpieces made of wood or wood-like materials. The robust and fabric-reinforced material guarantees longevity even when used at the highest level. Thus, the vacuum bag fits perfectly into professional production processes. With Vacuflex, you are able to extend your product range extremely, achieve better results in the production process significantly and inspire your customers with short production times. Vacuflex is the number one choice when it comes to manufacturing very large workpieces in the fastest way possible. For this reason, it is also ideal as a complement to vacuum presses and gives you the certainty that you can always cover the widest possible range of production processes cost-efficiently without suppliers. With this system, which has been tried and tested for over 40 years, hundreds of users have already been able to achieve extraordinary results in production and sustainably increase their success through the use of vacuum technology. It is ready for use very quickly and amortizes itself in a short period of time, even at low utilization. Tjdpfxsxfz H Ho Aacod

Year of construction: 2025, condition: new, Exclusive to Columbus: the digital master manual with user knowledge from +45 years Modular system - can be upgraded at any time with a vertical opening mechanism and heating system for plastic panels! Directly from the manufacturer - including warranty! PIONEER Basic L - high-precision vacuum press incl.: • Membrane fast-change system • Gas springs for flap opening • Highly elastic natural rubber membrane (up to +130 °C) Tedpjxfz Hyofx Aacjd • Stable phenolic resin worktop (up to +120 °C) • 40 m³ high-performance vacuum pump (up to 900 mbar (9 t / m²)) from BECKER • Analog vacuum pressure gauge • Connection for external vacuum bag • Feet including smooth-running swivel castors • Mounting fixture for vertical opening system • FESTO pneumatics and SIEMENS electrics Technical data: • Voltage: 400 V • Power: 1,3 kW • Supply frequency: 50 Hz Dimensions: • Usable area: approx. 3050 x 1350 mm • Dimensions inside the frame: approx. 3130 x 1430 mm • Max. workpiece height: approx. 600 mm • Overall dimensions: approx. 3700 x 1640 x 1080 mm

Year of construction: 2025, condition: new, Exclusively from Columbus: the digital master manual with user knowledge from +45 years enables safe use of the press Modular system: Vacuum press with flap opening - can be upgraded at any time with a vertical opening mechanism for high workpieces and better usability AND heating for forming plastic panels (such as Corian) 3 different sizes available Tedpjxfz Htsfx Aacsd Austrian, ISO-certified mechanical engineering quality with the exclusive use of branded components guarantees many years of use

Year of construction: 2025, condition: new, INFINITY - the vacuum press system in special lengths The Columbus INFINITY is the new and groundbreaking vacuum press system that can be constructed in the length desired by the user on request. The specially created and eponymous Infinity Principle, according to which the usable area in terms of length can be increased very cost-effectively almost to infinity, is used in each individual component. The system offers both maximum flexibility and maximum efficiency, because where the Infinity Vacuum Table and the Rolling Membrane System offer infinity, the Multi-Zone Suction guarantees maximum control. Thanks to this Multi-Zone Suction, only that section of the usable area that is currently in use is vacuumized. INFINITY is perfect for all users who value an infinite usable area for a wide variety of special pressing with maximum yield volume. Tedpoxfz Hmefx Aaced Directly from the manufacturer - including warranty! Execution: Length and width on customer request! Table base made of stable, welded metal construction, adjustable table feet. The table material is a 21 mm thick birch plywood board. An approx. 15 mm wide vacuum suction groove is milled on the table surface to seal the membrane. The membrane is wound onto a reel and is manually unrolled onto the table surface using a very smooth-running linear slide. The cavities of the table frame serve as vacuum buffer storage. The vacuum pump has an output of 100 m³/hour. The table surface has several suction grooves, these are divided into 5 suction zones. The table load is about 200 kg / m

Year of construction: 2025, condition: new, functionality: fully functional, MOVE — the high-precision vacuum press with a gigantic usable area for vacuum shape bonding and vacuum veneering of curved workpieces. With extensive flexibility, due to absolute mobility and revolutionary folding mechanism, to reduce the floor space to 45 % when folded. High-precision vacuum press with flap opening incl. - Revolutionary folding mechanism (reduction of the floor space to 45 %) - 40 m³ high-performance vacuum pump (up to 900 mbar (9 t / m²)) - optional, automatic switch-off when pressure is reached (with large vacuum volume) - Pressure regulation 400 to 900 mbar, analog vacuum pressure gauge - Highly elastic natural rubber membrane (up to +130 °C) - Membrane fast-change system - Stable phenolic resin worktop (up to +120 °C), glued 15 times - Gas springs for flap opening - Vacuum pressure gauge - Connection for external vacuum bag - Smooth-running swivel castors - FESTO pneumatics and SIEMENS electrics Technical data and dimensions: - Usable area: approx. 3050 x 1350 mm - Overall dimensions: approx. 3700 x 1700 x 1100 mm - Overall dimensions (folded): approx. 3650 x 770 x 1780 mm - Dimensions inside the frame: approx. 3130 x 1430 mm - Voltage: 230 V - Power: 1,2 kW Todsxfz Haepfx Aacod - Supply frequency: 50 Hz - Weight: 670 kg

Year of construction: 2008, condition: ready for operation (used), functionality: fully functional, * Wemhöner Basic 1000 Plus - Year of manufacture 2008 * Type KT-MB-28/15-240 * With automatic pin system and inline turner * 2 tables with automatic vario-pin system * With Teflon coating for pre-glued foil * Foil laying system for pin table (pre-glued foil) * Heating plate size: 2800 x 1500mm * Max. workpiece size: 2,540 x 1,250mm * Membrane: yes * Cutting station * Foil storage carousel, 3.2m high with 14 suspension rods * Siemens S7 PLC control * Siemens TP 270 (touchscreen) operating unit for PLC control Tjdoxbcudepfx Aacsd * Automatic membrane tensioning * Installed power supply 38.5 kW * Max. chamber pressure 6 bar * Max. press opening 150mm * 6 cylinders with Ø 125mm * Operating voltage 400V 50/60Hz * Press chamber height 40/60mm * Max. pressing force 2400 kN * Operating pressure of the hydraulic system 320 bar

Condition: like new (used), Year of construction: 2023, functionality: fully functional, machine/vehicle number: VAKP0004, travel distance X-axis: 4,100 mm, travel distance Y-axis: 2,180 mm, travel distance Z-axis: 160 mm, workpiece length (max.): 4,000 mm, workpiece width (max.): 4,180 mm, workpiece height (max.): 160 mm, total height: 1,465 mm, total length: 4,550 mm, total width: 2,992 mm, input voltage: 400 V, Equipment: documentation/manual, As-new large-format gantry vacuum press 4.0 x 2.18 m BESSLER HOLZFRAESE, year 2023 For sale: As-new large-format vacuum press for laminating large panels or manufacturing curved components. Very large pressing surface of 4.0 x 2.18 m. Excellent, near-new condition (used in a single-person operation), very little use. Includes complete accessories (vacuum hoses, vacuum pump). Vacuum pump VT 4.25 from Becker Tedpfx Aexaufxoacjd Dimensions approx. 4550 x 2992 x 1465 mm (LxWxH), approx. 800 kg Max. pressing format: 4000 x 2180 x 160 mm (LxWxH) Year of manufacture: 2023 The machine has been function-tested, disassembled, and is packed ready for shipping. Additional photos and videos available on request. Original net price: €36,250 plus VAT.

Condition: used, Membrane press Orma PM/AFT for coating single-sided profiled workpieces with automatic loading and unloading system. Todpfsw Na Ulsx Aacod Max. workpiece size: 2,320 x 1,010 mm power: 33 kW Available: 2

Condition: good (used), Year of construction: 1997, functionality: fully functional, Bürkle Multifoiler, membrane press Model BTF 1628/60 Year of manufacture 1997 Tsdsw Enl Sepfx Aacsd System for coating smooth and shaped MDV parts with thermoplastic films from a roll or as cut-to-size, for PVC, PP, high-gloss PVC, ABS film. Suitable for the thermoforming or membrane process. Max. part size 1250x 2550 mm/ Part thickness 6-35 mm Heating plate dimensions 1600 x 2800 mm Max. heating temperature 140° Stroke 230 mm Control Siemens Total connection 38 Kw with 2 aluminum tables and reserve table Weight 16.5 t Press length: 2,550 mm Press width: 1,250 mm Max. workpiece thickness: 35 mm

Condition: used, Membrane press with double work surface Cutter for cutting the sheet to be applied - Working length: mm 2350 - Working width: mm 1100 - Maximum workable thickness: mm 35 - Installed power: 38 kW - Weight: 13200 kg Tsdpew Dfkcjfx Aacsd

Condition: used, SECOND-HAND BENDING PRESS Tsdpswr Alysfx Aacod - Platens dim. mm. 2500X1000 - Opening 1000 mm. - 4 cylinders mm. 80

Condition: used, SECOND- HAND BENDING PRESS FORGIARINI - Platens dim. mm. 1400X800 - Light 900 mm. - 2 cylinders mm. 100 Tsdswr Ah Uepfx Aaced

Condition: used, SECOND- HAND BENDING PRESS FORGIARINI Tjdpfx Aaowr Advjcjd - Platens dim. mm. 1400X800 - Light 900 mm. - 2 cylinders mm. 100

Condition: used, SECOND-HAND BENDING PRESS - 4 cylinders - Platens dim. mm. 3200X1100 - H=1800 Tedewrz Umjpfx Aacsd

Condition: used, Year of construction: 2005, machine/vehicle number: 05-05, SECOND-HAND PREBENDING PRESS VECCHIATO MOD. SN2000/120 Tjdpfx Aaowrz H Aocod - Working table length 2000 mm - Thrust 57 Ton - Min / max working length 500/1500 mm - Maximum working thickness 40 mm - Lower bench of flexible steel sheets - KW 2.2 - Volt. 380/50 - S/N 05-05 - CE rules year 2005

Year of construction: 1999, condition: used, Membrane press Orma PM/AIR Year of construction 1999 Serial number 52850199 Dimensions 2300*900mm Max panel size 2200x800mm Max panel thickness 40mm 8 cylinders diameter 100mm Stroke 150mm Pressure 160T Tsdpfx Aaswnhicscjd Pressure pressure 6 kg/cm² Heating 13kW Total power 17.3kW 380V, 35Amp Dimensions: 3900x1800xH2100mm, weight 5900kg - Year: 1999 - Documentation available: No - Serial number: 52850199 - Main motor power [kW]: 17.3 - Max. workpiece length [mm]: 2200 - Max. workpiece width [mm]: 800 - Max. workpiece height [mm]: 40 - Number of cylinders [pcs.]: 8 - Cylinder diameter [mm]: 100 - Total working pressure [Ton]: 160 - Working pressure [kg/cm²]: 6 - Heating boiler present: Yes Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Year of construction: 2018, condition: excellent (used), functionality: fully functional, Wemhöner VARIOPRESS Vacuum Membrane Press Basic 1000 S Technical Specifications: Heating platen size (mm): 2850 x 1550 Electric heating platen design: Aluminum, top heating platen Tedpfx Aajv Np H Hocjd Total pressing force (kN): 2400 Max. chamber pressure (bar): 6 Max. operating temperature: 180 degrees Celsius Max. batch or workpiece size (mm): approx. 2460 x 1180 Thermoplastic film in roll form: Film width: approx. 1430 mm Film thickness (mm): approx. 0.25 - 1 Pressure chamber height (mm): max. up to 180 Connected loads: Installed power (kW): approx. 46 Required air pressure (bar): approx. 8

Year of construction: 2025, condition: new, Dimensions (L/W/H) 3150x4000x1900 mm Weight 1500 kg Todev A E N Repfx Aacjd Total power requirement 36 kw

Year of construction: 2025, condition: new, Dimensions (L/W/H) 3500x1600x2000 mm Weight 1720 kg Total power requirement 26,5 kw Tsdpfx Aajv A E N Dscjd

Year of construction: 2025, condition: new, Dimensions (L/W/H) 3000x3000x1650 mm Weight 850 kg Todpfx Asv A E Nwoacsd Total power requirement 16 kw

Condition: good (used), Code: 0037 Brand: OMC - ITALY Model: PL/CONVERSION-S - CE Standard Membrane press with loading on the front side - CE Standard Multifunctional air membrane press, allows extreme versatility in one machine only of all types of finishing of the panel It can be operated as: Cold press Hot press Membrane press for Pvc coating or veneer of shaped panels form one side only Membrane press for Pvc coating or veneer of indentations in the wood from both sides Technical data: Todov Ab Dwopfx Aacsd Work platens dimensions 2500 x 1300 mm Perforated steel platens Useful tank dimensions 2350 x 1180 x 50 mm N° 10 pistons - stroke mm 400 Pressure kg/cm2 6.5 Overall dimensions mm 3200 x 1800 x 2700 Weight kg 8000
