Used Lodi Surface Grinding Machine for sale (67,108)

Condition: new, BRAND NEW HYDRAULIC SURFACE GRINDING MACHINE WITH INDUCTION MAIN MOTOR "Your Next Reliable Production Machine Starts Here" Iedpfxszupq Eo Afhobb

Condition: good (used), Year of construction: 1989, grinding length: 400 mm, grinding width: 200 mm, Grinding area: 400 x 200 mm Magnetic area: 400 x 175 mm Vertical adjustment: 410 mm Grinding wheel dimensions: 225 x 25 x 50.8 mm Grinding wheel speed: 1420 / 2840 rpm Complete with: - Coolant system - Hydraulic unit - Documentation Country of origin: Germany Motor power: 1.5 kW Machine dimensions (L x W x H): 2200 x 1500 x 2100 mm Iedpfx Afsv Tcy Ushebb Machine weight: 1100 kg

Condition: good (used), grinding length: 400 mm, grinding width: 150 mm, Table length 400 mm Table width 150 mm Grinding length 400 mm Grinding width 150 mm Design: hydraulic Max. distance from table to spindle center line 350 mm Table speeds: continuously variable from 0.00 m/min up to 0.0 m/min Automatic vertical feed: from 0.000 mm up to 0.013 mm Diameter of grinding wheel 00 mm Width of the grinding wheel 16 mm Grinding wheel speeds: from 800 rpm Ibedpevga Suefx Afhjb Voltage 50 Hz 3x 380 Volt Grinding spindle motor 0.30 HP Machine weight approximately 900 kg Overall dimensions of the machine: Length 1300 mm Width 1000 mm Height 1500 mm

Condition: good (used), Year of construction: 1994, Grinding length max. 650 mm Grinding width 390 (max. 450) mm Distance from spindle center to table 600 mm max. Workpiece weight 350 kg Grinding area 650 x 390 mm Ibodpfxovz A Sto Afheb Travel paths: X-axis 840 mm Y-axis 500 mm Z-axis 410 mm Total power requirement 15 kVA Machine weight approx. 3.0 t Space requirement approx. 4.0 x 3.0 x 2.5 m

Condition: ready for operation (used), functionality: fully functional, Grinding length: 600 mm Grinding width: 250 mm Workpiece height: 450 mm Electromagnetic clamping table: 600 x 250 mm Grinding wheel diameter: 300 x 50 x 76.2 mm Spindle speed - stepless: 800 - 4200 rpm Ibsdpez Ayrvofx Afhjb Total power requirement: 4 kW Machine weight: approx. 2.9 t

Condition: ready for operation (used), functionality: fully functional, grinding length, max. 600 mm Table clamping surface 600 x 200 mm Iedpfsz Ayqxox Afhobb Magnet dimensions 500 x 200 mm Maximum distance between table surface and center of the grinding spindle 495 mm Grinding wheel dimensions (D x b x d) 250 x 25 x 51 mm Grinding spindle drive 5.5 kW

Condition: ready for operation (used), functionality: fully functional, grinding length 500 mm grinding width 200 mm workpiece height 250 mm Ibedpfxjz Aynwj Afhjb table surface 600 x 200 mm grinding wheel dimensions 225 x 20 x 51 mm grinding spindle drive 1.5 kW table feed 1 - 20 m/min total power requirement 2.6 kW machine weight approx. 2 t machine dimensions approx. 2.6 x 1.6 x 1.8 m

Condition: used, Year of construction: 2001, functionality: fully functional, OKAMOTO ACC 64 DX Surface Grinding Machine Year: 2001 TBC Servo Automatic Downfeed 600 x 400.0mm WALKER HAGOU MAGNET Iedpfx Afezv Ef Uehjbb Electromagnetic chuck Paper coolant filtration system

Condition: used, Year of construction: 2005, grinding length 5200 mm grinding width 1000 mm workpiece height 320 mm Control Siemens 840D Passage width 1300 mm grinding height 320 mm grinding motor 306 kW grinding motor turning speeds up to 320 U/min grinding motor feed, infinitely variable 0,5-35 m/min grinding motor adjustment in steps 0,002-1 mm Ibodoz Alafjpfx Afhsb grinding motor adjustment, continuously stepless bis/upto 5 mm/min dimensions of the machine ca. 11,21 x 3,2 x 3,85 m CNC production surface grinding machine with segment head Equipment / Accessories: - with segment head, diameter 1400 mm segment head dimensions: 120/106 x 41 x 250 mm number of segments: 1 set = 26 pieces - with electro-magnetic table 5200 x 1300 mm - Marposs measuring control travel (Z1 axis), vertical: 420 mm - coolant flow rate 2000 l/min lifting station 2x pump for 1000 l/min

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, Machining diameter: 3,000 mm Machining height: 500 mm Z-axis travel, left support: 551 mm Z-axis travel, right support: 350 mm W-axis travel: 1,100 mm Rotation speed, left/right: 2,000 min-1 Max. table load: 6,000 kg 2x grinding supports – swiveling 2x diamond dressing tools Magnetic clamping plate by SAV Ibjdoz Difxopfx Afhob Control system update in 2004 Control system: R&D MTC 2x-G

Condition: used, JONES SHIPMAN 1307 EIT CYLINDRICAL GRINDING MACHINE MAKE JONES AND SHIPMAN, MADE IN ENGLAND MODEL 1307 EIT CENTRE HEIGHT 185.0 mm MAX DIAMETER 370.0 mm MAX GRINDING LENGTH 1016.0 mm MAX GRINDING WHEEL 350.0 mm x 40.0 mm GRINDING SPEED 40 – 320 RPM TABLE ROTATION 16 DEGREE TO – 12 DEGREE MAX INTENAL SPINDLE SPEED 24,000 RPM PLUS VARIABLE SPEED WORK HEAD INTERNAL SPINDLE. DOUBLE SWIVEL WHEEL HEAD. METRIC DIALS RANGE OF MAGNETIC CHUCKS Ibjdsy Hi Epepfx Afhjb PENDANT CONTROL HYDRAULIC PACK PAPER FILTRATION SYSTEM REBUILT BY ANDMAR EXTENSIVE RAGE OF TOOLING AND ACCESSORIES HYDRAULIC PACK

Condition: good (used), Year of construction: 2007, functionality: fully functional, Technical details grinding length 600 mm grinding width 400 mm workpiece height 375 mm workpiece weight 400 kg table longitudinal travel 650 mm table speeds 2 - 28 m/min table cross travel 400 mm speed 100 - 1000 mm/min grinding wheel size 300 x 50 x 76,2 mm grinding spindle drive 3,7 kW peripheral speed 10 - 32 m/sec total power requirement 11 kW weight of the machine ca. 2,1 t dimensions of the machine ca. 2,95 x 2,65 x 2,47 m Additional information CNC Precision Surface Grinding Machine Table drive: hydraulic Cross-axis drive: electromechanical Electromagnetic plate: 600 x 400 mm with holding force control and automatic magnetic pole reversal for demagnetizing Isdpfx Afezzw Rtshsbb Features: Partially enclosed, open-topped loading compartment with a sliding door Cleaning kit for cleaning the work area with hand-held impulse nozzle Holder for prism arm with single-point diamond, MK 0 Grinding spindle speed control with V-constant controller Universal paper filter unit UPF 100, tank capacity approx. 280 liters Coolant pump: 20 liters/minute at 1.5 bar Machine light Without grinding wheels and flanges.

Condition: good (used), Year of construction: 1990, Year of manufacture: 1990 Control type: CNC Grinding length: 600 mm Grinding width: 200 mm Workpiece height: 375 mm Table load: 100 kg Ibsdpfji Hn U Uex Afheb Grinding wheel dimensions: 250x25x51 mm Operating speed: 1-24 m/min Speed: 4200 rpm Drive motor: 5 kW Total power consumption: 7.5 kW Machine weight: approx. 3.2 t Space requirement: approx. 3.7 x 2.1 x 2.1 m

Condition: used, Control Siemens In our assessment, the machine is in good used condition and can be inspected under power by appointment. Ijdpfjzzrhtex Afhobb Accessories, tools, and clamping devices shown are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data and specifications, and prior sale.

Condition: excellent (used), Year of construction: 2008, Table size 600 x 300 mm Max. grinding area 600 x 300 mm Dimensions of the grinding wheel 406 x 50 x 127 mm Min. / max. distance table / spindle center 500 mm Table speed, hydraulically adjustable 5 - 25 m/min. Crossfeed 0.1 – 20 mm Cross travel rate 900 mm/min. Handwheel, cross 1 revolution 5 mm 1 division mark 0.02 mm Automatic vertical feed 0.001 - 0.999 mm/cycle Handwheel, vertical 1 revolution 2 mm 1 division mark 0.01 mm With AD 5 (automatic feed) 0.005 mm Grinding wheel spindle speeds 1450 / 2900 rpm Grinding motor 1.5 / 3.7 kW Hydraulic pump motor 0.75 kW Drive motor, cross 1.1 kW Drive motor, vertical 1.1 kW Machine dimensions L x W x H approx. 2300 x 1800 x 2100 mm Weight 1700 kg Accessories / Special features: • 2-axis digital display • Automatic vertical feed with spark-out and subsequent lift • Electro-magnetic clamping plate L x W 600 x 300 mm Ibsdpfxjizka Ie Afhsb • Manual grinding wheel dressing device • Grinding wheel speed, 2 stages • 1 piece grinding wheel with flange • Control panel • Lighting • Coolant system with belt filter and magnetic separator • Machine feet • CE compliant Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 11-153 D - 44143 Dortmund - Wambel

Condition: used, Year of construction: 2014, Surface grinding machine, Geibel + Hotz, type FS 420 SD. Ibjdpfx Afez Affuohsb

Condition: used, Year of construction: 2007, Control SIEMENS 840D powerline Iodpfxszy Sine Afhebb spindle drive 11 kW grinding wheel diameter 400 mm grinding wheel width 100 In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data and specifications, and prior sale.

Condition: like new (used), Year of construction: 2017, functionality: fully functional, operating hours: 2,600 h, controller model: Fanuc 32 C, control type: CNC control, Equipment: documentation/manual, Standard programs such as parameter settings Dressing settings Speed settings Program management settings Limitation of travel distances x + y Basic parameter settings Grinding wheel management program Warming-up cycle program Surface plunge grinding program Measuring program 15 kVA transformer Full enclosure Meister G3 Ibedpfx Afew I Tt Ssheb Spindle upgrade to 3.7 kW, disc 225 mm ETHER interface for network connection Control module with extended memory Fanuc Macro B option Program creation for batch programs Programmable spindle speed WinWop program for contour creation (Windows) WINWop program for error compensation WinWop postprocessor CGS Complete Grinding Solutions software Option Dressing Swiveling profile dressing device Diamond dressing wheel Pre-dressing device VPA 100 L Diamond wheel 100 mm for pre-dressing device Regrinding package diamond wheel G3 / W Option – Clamping and Balancing Magnetic chuck 400 x 200 400 mm stop bar with prism Fully automatic balancing device, size 1 Grinding wheel flange for G3, bore 51 mm Option Filter Systems Belt filter system 175 l Extraction unit for emulsion mist 500 Inquiries only from Europe, preferably the EU.

Condition: excellent (used), PERFECT PFG-70150AHRD Surface Grinding Machine Year 2014 Table size 700 x 1500 mm Maximum longitudinal travel 1650 mm Maximum cross travel 760 mm Maximum distance table surface to spindle centre 600 mm Table speed 5 – 25 m/min Magnetic chuck size 700 x 1500 mm Spindle speed 1450 rpm Spindle motor 7.5 kW (10 HP) Grinding wheel size 355 x 40 x 127 mm Floor space required 4810 x 2550 mm Weight 7800 kg Supplied with: Ibjdpozuxt Aefx Afheb Automatic Downfeed System, 1500 x 700 mm Electromagnetic Chuck, Demagnetising Unit, 2 Axis Digital Readout, Remote Handwheel, Spindle Motor Speed Inverter Control, Automatic Paper Strip Filter & Magnetic Separator, Machine Pads & Levelling Bolts, Low Voltage Work Light. For sale with Jet Machinery Ltd Jet Machinery Stock No: #27039 Machine Serial Number: 1485022 Cost: £49,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: used, Year of construction: 2003, grinding width 600 x 2000 mm table surface area ca. 600 x 2400 mm x-travel 2100 mm y-travel 550 mm z-travel 560 mm Ijdpfx Afjzxt T Eehebb max. dia. of grinding wheel 400 mm weight of the machine ca. ca 7,8 t

Condition: ready for operation (used), Year of construction: 2005, total length: 600 mm, total width: 600 mm, 600x300mm travel range Ibodpfx Afezz N A Iehob 600x300mm magnetic table fully automatic

Condition: good (used), Year of construction: 2008, 1 used surface grinding machine Manufacturer: STÖCKEL Type: FX 60/30 SPS Year of manufacture: 2008 Grinding area: approx. 600 × 300 mm Magnetic chuck: approx. 600 × 250 mm Speed: 1900 rpm Grinding height: 400 mm Drive power: 9 kW Operating voltage: 400 V / 50 Hz Table load: 250 kg Control: PLC Ibedpfsz Dkuuox Afheb Weight: 3000 kg

Condition: ready for operation (used), Year of construction: 1991, functionality: fully functional, Internal grinding machine | Brand: VOUMARD | Type: 5A LP 1000 Year of manufacture: 1991 Range of parts: Gear wheels, guide rollers, centring bushings. The machine can be inspected under power by appointment. Condition: In working order, ready for use. TECHNICAL SPECIFICATIONS: Working area - Internal grinding diameter: 5 mm - Internal grinding diameter max.: 200 mm - Max. Grinding depth: 250 mm - Peak height: 180 mm - Peak distance: 1.000 mm Working spindle - Spindle bore: Ø 80 mm - Swivelling capability: 0° Sliding spindle carriage - Minimum and maximum swivel range: 25 degree - Minimum longitudinal movement: 3 mm - Maximum longitudinal movement: 600 mm - Table speed, continuously adjustable: 0 - 10 m/min - Workpiece weight: 0,25 tons Grinding wheel / disc - Diameter max.: Ø 60 mm - Width max.: 25 mm - Borehole: Ø 12 mm - Rotational speed: 3.600 - 40.000 rpm - Operating voltage: 380 V, 50 Hz - Control voltage: 24 V - Total power requirement: 8,7 kW - Machine weight approx.: 2,7 tons Dimensions: - Machine (L x W x H): 2,9 x 1,2 x 1,9 m - Water tank (L x W x H): 1,4 x 0,8 x 0,65 m - Motor (L x W x H): 0,8 x 0,4 x 0,65 m ACCESSORIES: - 4-jaw chuck, Ø 250 mm - 1 steady rest and various spindles Ijdpfozzcmysx Afhebb No guarantee is given for the completeness and accuracy of the technical data and equipment. - Subject to prior sale -

Condition: used, Year of construction: 1998, grinding length 600 mm grinding width 400 mm workpiece height 525 mm table surface area 960 x 400 mm dimensions of grinding wheel 350 mm 600 x 400 mm grinding spindle speed 3000 U/min Ibjdozzd Thjpfx Afhob table load capacity 1100 kp total power requirement 8,0 kW weight of the machine ca. 2,1 t dimensions of the machine ca. 2,4 x 1,9 x 2,1 m Surface grinding machine - Magnetic chuck - Coolant system with filter

Condition: good (used), > JONES & SHIPMAN 540 AP GRINDER - 1983 - Dual view > HEIDENHAIN > J&S 540 AP automatic surface grinder, 450x150 magnetic table. > 1983, in good condition, with dual Heidenhain visualization (Z and transverse). > Automatic feeds, coolant system, grinding wheel. Magnetic table. > 400V - 1100kg - Operational, removed from a precision mechanical workshop. > *Specifications:* > - Capacity: 450 x 150 mm magnetic > - Grinding wheel: 200 x 20 x 51 mm > - Longitudinal travel: 500 mm Ibjdpfxezxiwge Afhsb > - Spindle motor: 1.5 kW > - Weight: ~1100 kg > - 400V
