Used Flood Lighting Poles for sale (15,858)

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2020, operating hours: 5,802 h, load capacity: 3,000 kg, lifting height: 4,950 mm, free lift: 1,520 mm, overall weight: 5,802 kg, Equipment: sideshift, TECHNICAL DETAILS Load capacity: 3,000 kg Gbodpfxox E S Nne Abdsg Lifting height: 4,950 mm Overall height: 2,270 mm Free lift: 1,520 mm Forks: 1,200 mm MACHINE DETAILS Drive type: Electric Battery: 80 V / 620 Ah (2018) Weight: 5,802 kg Front tires: 23x10-12 (10 %) Rear tires: 6.50-10 (80 %) Operating hours: 11,799 h EQUIPMENT 3rd hydraulic valve 4th hydraulic valve Rear work light Front work light Half-cab Heater Side shifter Fork positioner

Condition: like new (used), Year of construction: 2025, functionality: fully functional, controller model: DC241 EEC, workpiece height (max.): 3 mm, swivel angle A-axis (max.): 105 °, swivel angle B-axis (max.): 180 °, As-new Hexagon Global S Blue Coordinate Measuring Machine! TECHNICAL DETAILS Probe Interface (CMM): TKJ Probe Weight: 350 g Total Weight: 480 g Measuring Performance Probing Force: 5 µm Measuring Range: 2 mm Maximum Measuring Distance: 14 mm Resolution in Z-Axis: 66 nm Lateral Resolution: 6 µm Angular Acceptance: ±30 ° Max. Measurable Thickness: 3 mm Spot Diameter: 12 µm LED Area Light Illuminated Area: 780 × 780 mm Overall Dimensions: approx. 860 × 840 × 20 mm Weight: approx. 19 kg Load Capacity: max. 50 kg Stylus Shank Diameter: 3 mm Shank Length: 50 mm Ruby Ball Diameter: 5 mm Thread: M3 Angular Rotation Steps: 2.5° A-Axis: ±105° B-Axis: ±180° Rotation Speed: 90° in 2.5 s Max. Extension Length: 450 mm Recommended Drive Torque: max. 1.4 Nm Positioning Repeatability: 0.5 µm at 100 mm from the A-axis center MACHINE DETAILS Control System: DC241 EEC Control Compatibility: HH-C-V2.0, HH-CA-V2.0 with HR-R automatic probe changer rack Electrical Data Supply Voltage: DC 5 V to 6 V Current Consumption (normal): 50 mA Current Consumption (min): 30 mA Current Consumption (max): 150 mA (pulsed) Gjdpfx Abex Sx Nujdobg Protection Class: IP40 (IEC 60529) Temperature Range: 16 °C to 26 °C EQUIPMENT Windows 10 Operating System Interactive 3D Graphical Capability Computer-Simulated Measuring Machine Environment Bidirectional Interface to CAD Systems: IGES, VDA, DXF, and STEP Processing of 2D, 3D, wireframe, and surface models Curve and Surface Scanning (CurveAnalyzer) Includes PC-DMIS-SHEETMETAL Functions for measuring thin-walled components Automatic White Light Probe – TKJ 2.5 HP-OW-2.14 Sensor Kit, incl. controller and reference sphere, Ø 30 mm, ceramic matte HP-SX1H Scanning Probe Sensor LED area light for mounting on the coordinate measuring machine Reference price mechanical frame for supporting the area light HP-CTS5.10 Optical Sensor HP-S-X1C/H Stylus Holder (1× M3) HH-C-V2.1 Controller HR-OW-2.14 Short End Cap HR-R3 Sensor Acceleration HH-CA-V2.0 Interface Active Probe Rack, HR-RA-65 HR-X1-3P Stylus Rack Reference Sphere, Ø 60 mm, ceramic, with stand M3 Stylus (R-5-SS-3.50) Stylus Tray Computer & Software PC-DMIS CAD++ PC-DMIS Operator Interface with order system PC-DMIS CWS Interface PC-DMIS Probe Change Support Software PC-DMIS Vision for Tactile Sensors Touchscreen including computer system Desk for computer system

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: F876E01576L, Year of construction: 2013, operating hours: 16,860 h, load capacity: 12,000 kg, lifting height: 5,250 mm, fork length: 3,250 mm, fork width: 2,370 mm, empty load weight: 16,350 kg, TECHNICAL DETAILS Lifting capacity: 12,000 kg Lifting height: 5,250 mm Clearance height: 4,500 mm Fork length: 3,250 mm Maximum fork width: 2,370 mm Minimum fork width: 710 mm MACHINE DETAILS Fuel type: Diesel Number of wheels: 6 Attachment: Sideshift, fork positioner Dimensions & Weight Dimensions (L x W x H): 4,350 x 2,500 x 4,500 mm Unladen weight: 16,350 kg Operating hours: 16,860 h EQUIPMENT Pneumatic tyres Full cab Work lights License plate Heater Gbjdpfx Abjx Tqanodeg Documentation CE marking

Condition: new, Year of construction: 2024, functionality: fully functional, HYUNDAI-WIA SE2200M CNC LATHE WITH FANUC 0IT PLUS CONTROL AND C-AXIS MACHINE CONSTRUCTION & FEATURES  8” STANDARD CHUCK SIZE.  30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY.  HIGH PERFORMANCE ROLLER LM GUIDEWAYS.  12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET - BMT45. [24 POSITION INCLUDED]  4,500 RPM HIGH POWER MAIN SPINDLE.  30 X 36 M/MIN RAPID TRAVERSE RATES - X & Z AXES.  C-AXIS MAIN SPINDLE.  ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET. MACHINE CAPACITIES Swing Over the Bed Ø 600 MM Swing Over the Carriage Ø 390 MM Maximum Turning Diameter Ø 300 MM Maximum Turning Length 288 MM Bar Capacity - Main Ø 65 MM MAIN SPINDLE Chuck Size 8” Ø 203 MM Spindle Bore Ø 75 MM Spindle Speed (Rpm) 4,500 RPM Motor (Max / Cont.) 15.0 / 11.0 KW Godpfxsx Trgco Abdjbg Torque (Max.) 167 NM Spindle Type BELT Spindle Nose A2-6 C-Axis Indexing 360° (0.001°) FEED Travel X 210 MM Travel Z 340 MM Rapid Speed X 30 M / MIN Rapid Speed Z 36 M / MIN Slide Type ROLLER LM GUIDE TURRET Number of Tools 12 [24 POSITION INDEX] Tool Size - OD 20 MM² Tool Size - ID Ø 32 MM Indexing Time 0.15 SEC / STEP LIVE TOOL Motor (Max / Cont.) 2.75 / 1.85 KW Milling Tool Speed 6,000 RPM Torque (Max.) 26.2 NM Collet Size ER 20 - Ø 13 Type BMT45 TAILSTOCK HYDRAULIC NC TAILSTOCK (STD LIVE CENTRE) Taper MT 4 Quill Diameter Ø 56 MM Tailstock Travel 580 MM TANK CAPACITY Coolant Tank 150 L Lubricating Tank 0.7 L POWER SUPPLY Electric Power Supply 18 KVA Thickness of Power Cable OVER 16 MM² Voltage 415V / 50HZ / 3PH MACHINE Floor Space (L x W) 2,220 X 1,610 MM Height 1,700 MM Weight 3,250 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CONVEYOR SIDE HINGED WITH CHIP BOX HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO (RENISHAW) HYDRAULIC TYPE NC TAILSTOCK TURRET UPGRADE - 12 STATION 24 POSITION BMT45, LIVE TOOLS 6K RPM, 2.75 KW STANDARD FACTORY FITTED MACHINE OPTIONS CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC FOR STANDARD CNC SPECIFICATION - SEE MANUFACTURER'S BROCHURE HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) MANUAL VIEWER OPERATION MEMO PREMIUM TOOL OPERATION SCHEDULING SMART GUIDE-i (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 150 LITRES FRONT DOOR INTERLOCK FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (15 LITRES) CALL LIGHT (1 COLOUR) BACK SPIN TORQUE LIMITER TOOLBOX STANDARD TOOLING PACKAGE

Condition: excellent (used), Year of construction: 2010, The XYZ 200TC is a CNC lathe known for its precision and versatility. It features a Siemens 810D Shopturn control system, a 12-station VDI turret. Key Features and Specifications: Control System: Siemens 810D Shopturn. Turret: 12-station VDI turret. Chuck: Hydraulic 200mm 3-jaw chuck. Bar Capacity: 52mm. Swing Over Bed: 420mm. Maximum Machining Diameter: 200mm. Maximum Machining Length: 550mm. Godpfx Ajxrvcvsbdobg Spindle Speed: 4800 rpm. Spindle Bore: 62mm. Spindle Motor Power: 14.9kW. Other Features: Automatic tool setting arm, swarf conveyor, parts catcher, hydraulic tailstock, remote electronic handwheel, and through-tool and flood coolant. Weight: 4100kg. The XYZ 200TC is a slant-bed CNC lathe, which means the lathe bed is angled, allowing for better chip evacuation and access to the workpiece. It can be equipped with a multi-feed barfeed for automated feeding of bar stock. The machine is typically used in small to medium-sized workshops and production environments. Complete with bar feed, swarf conveyor and tooling.

Condition: excellent (used), functionality: fully functional, Year of construction: 2006, Kingsland HACO ERMS 30 – 100 CNC Pressbrake Gbedpfx Aewwvx Dobdjg Model: ERMS 30 – 100 Year: 2006 Control: ATS 560 Capacity: 100 Ton x 3100mm Max. Bending Length: 3100mm Distance Between Columns: 2550mm Machine with: Light Guards Full length top and bottom tooling

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2013, operating hours: 10,901 h, load capacity: 3,000 kg, lifting height: 2,900 mm, construction height: 2,100 mm, overall weight: 5,504 kg, Equipment: sideshift, TECHNICAL DETAILS Load capacity: 3,000 kg Lift height: 2,900 mm Overall height: 2,100 mm Fork length: 1,200 mm Godpfxex E S Hyj Abdsbg MACHINE DETAILS Drive type: Electric 80 V Battery: 80 V/620 Ah (2019) Weight: 5,504 kg Operating hours: 10,901 h EQUIPMENT 3rd valve Rear work lights Front work lights Heater Load guard Full cabin Side shifter

Condition: used, Year of construction: 1997, functionality: unexamined, total height: 2,500 mm, total length: 33,223 mm, total width: 2,000 mm, table width: 700 mm, input frequency: 60 Hz, input voltage: 460 V, table length: 5,000 mm, table height: 1,200 mm, control cabinet width: 600 mm, control cabinet length: 1,500 mm, control cabinet height: 2,500 mm, compressed air connection: 5.5 bar, Stud & Track Rollforming Machine With 4.5 Tonnes Decoiler & Crane 5 Tonnes Capacity - Fully Dismantled - Ready to be transported MACHINE MANUFACTURER: BRADBURY UK GENERAL SPECIFICATIONS STUD LINE MATERIAL : GALVANIZED COLD ROLLED STEEL MATERIAL STRENGTH : 85.000 PSI MAX YIELD STRENGTH 55.000 PSI MIN· YIELD STRENGTH THICKNESS: 20 GA. TO 16 GA.-"HEAVY GAUGE" 22 GA. TO 25 GA.-"LIGHT GAUGE" ENTRY COIL WEIGHT: 10.000 LB MAX ENTRY STRIP WIDTH: 12" MAX C APPROX. 5" MIN C APPROX. ENTRY COIL I .D: 20" MAX ENTRY COIL O.D: 72" MAX EFF. LINE SPEED : l20-150 FPM-"HEAVY GAUGE" 175-250 FPM-"LIGHT GAUGE" ROLLFORMER SPEED: 120-250 FPM PASS LINE HEIGHT: 51" Gbodpfx Aoxya Hzobdsg LINE DIRECTION : RIGHT TO LEFT MODE OF OPERATION : PREPUNCH/POSTCUT CUT LENGTH : 20' MAX. 5· MIN GAUGE" : 90 % C APPROX. ) OF PRODUCT iON < i 6' LENGTH TOLERANCE : •/- 1/16" AT 250 FPM MAIN POWER : ELEC : 460 VOLTS 60 HERTZ 3 PHASE 192.2 FLA : AIR : 80 PSI MIN. CLEAN 6 DRY : HYO : 1500 PSI WORKING PRESSURE CONTROL : 115 VOLT AC AIR CONSUMPTION: 2 CFM MAX. AT 80 PSI

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 516216E01248, Year of construction: 2014, operating hours: 6,341 h, load capacity: 2,000 kg, lifting height: 3,250 mm, free lift: 1,640 mm, fork length: 1,590 mm, fork width: 890 mm, TECHNICAL DETAILS Lifting capacity: 2,000 kg Gbsdpfx Aex Tp T Hsbdog Lift height: 3,250 mm Free lift: 1,640 mm Fork length: 1,590 mm Maximum fork width: 890 mm Minimum fork width: 370 mm MACHINE DETAILS Dimensions & weight Dimensions (L x W x H): 2,051 mm x 1,149 mm x 2,160 mm Weight: 3,448 kg Number of wheels: 4 Drive: Electric Battery type: 625 Ah, 48 V Battery test result: 52% Year of manufacture (battery): 2017 Operating hours: 6,341 h EQUIPMENT Fork adjustment Side shift Work lights Free lift

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA HD2200 FANUC 0IT PLUS CNC LATHE MACHINE CONSTRUCTION & FEATURES ▪ 8” STANDARD CHUCK SIZE. ▪ 45° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET. ▪ 4,500 RPM HIGH POWER MAIN SPINDLE. ▪ 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. ▪ ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET. Swing Over the Bed Ø 550 MM Swing Over the Carriage Ø 390 MM Maximum Turning Diameter Ø 380 MM Maximum Turning Length 565 MM Bar Capacity Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” – 203 MM 10” - [254] MM Spindle Bore Ø 76 MM Spindle Speed (rpm) 4,500 RPM Motor (Max/Cont.) 18.5 / 15.0 KW Torque (Max/Cont.) 206 / 125.3 NM Spindle Type BELT Spindle Nose A2-6 FEED Travel X 215 MM Travel Z 580 MM Rapid Speed X 24 M/MIN Rapid Speed Z 30 M/MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 12 Tool Size - OD 25 MM² Tool Size - ID Ø 40 MM Indexing Time 0.12 SEC / STEP TAILSTOCK Taper MT 4 Quill Diameter Ø 65 MM Quill Travel 80 MM Travel 513.7 MM TANK CAPACITY Coolant Tank 150 L Lubricating Tank 1.8 L POWER SUPPLY Electric Power Supply 23 KVA Thickness of Power Cable Over 16 MM² Voltage 415V / 50Hz / 3Ph MACHINE Floor Space (L x W) 2,925 x 1,650 MM Height 1,820 MM Weight 4,100 KGS INCLUDED MACHINE OPTIONS CONVEYOR SIDE HINGED WITH CHIP BOX COOLANT GUN HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD OIL SKIMMER BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO PROGRAMMABLE TAILSTOCK IN LIEU OF STD STANDARD FACTORY FITTED MACHINE OPTIONS CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" TOUCH SCREEN MONITOR FOR FANUC (SMART GUIDE i) HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) Gbedpfxjx Tqpps Abdog SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 150 LITRES FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (15 LITRES) CALL LIGHT (1 COLOUR) MACHINE MANUALS & OPERATOR HANDBOOKS TOOLBOX STANDARD TOOLING PACKAGE QUILL TYPE TAILSTOCK - 4MT WITH STD LIVE CENTER

Condition: used, empty load weight: 8,576 kg, maximum load weight: 30,424 kg, overall weight: 39,000 kg, axle configuration: 3 axles, first registration: 12/2019, next inspection (TÜV): 10/2025, loading space length: 13,403 mm, loading space width: 2,490 mm, loading space height: 2,600 mm, loading space volume: 86 m³, suspension: air, tire size: 385/65 R22,5, wheelbase: 7,600 mm, color: white, Year of construction: 2019, Equipment: ABS, Tare weight: 8576kg, GVW: 39000kg, Loading area (L W H): 13,403 mm x 2,490 mm x 2,600 mmTyre size: 385/65 R22.5, Loading area volume: 86 m³, 1st axle: , 2nd axle: , 3rd axle: , Air suspension, Rear underrun, Electronic Brake System EBS, Toolbox, Ferry lashings, 1x15 and 2x7 pin plug, Antispray, 2 LED reverse (Banksman) lights on rear. 5 Bar tread plate floor. Pair of V7 load securing rails. LED side marker lights coupled with indicators. Ultra bright interior lighting without rotary switch., Please find an overview of all vehicles available on our website . Finance required? We offer individual financing solutions, full service contracts and telematic-services. We would be glad to advise you personally. Gbsdpfsx Sz Adsx Abdjg

Condition: good (used), Year of construction: 1991, functionality: fully functional, product width (max.): 2,500 mm, working width: 2,500 mm, roll diameter: 1,500 mm, year of last overhaul: 2024, We have available for sale a Cobden Chadwick pre-print press line- 2500mm wide- see photographs. This is a fantastic opportunity and is the best conditioned pre-print press we have ever offered for sale/relocation. The machine controls were upgraded by Pre-Print Technology Ltd in 2017 – new servo control deck positioning + downstream register system. Please kindly let us know as soon as possible if you would like to visit the site to inspect the press line. Cobden Chadwick Linerflex press - manufactured 1991 Machine location: United Kingdom Cobden Chadwick Linerflex press consisting of the following 6 colour C.I 1 colour pre-tint unit with cantilever 1 colour downstream unit with cantilever Twin Wood & Stirling unwind Marquip splicer Warburton rewind Drive system for pre-tint, chill rollers, varnish unit and rewind Drying: IR cassettes by Waverley Fife web guiders Sero motors for print deck positioning Original press performance parameters; Maximum speed: 300 metres per minute Repeat range: 700mm to 2000mm all units Gear pith: 10mm Gbodpfxet Uc Iqj Abdsg Maximum print width: 98” PLC: Mitsubishi Main press frames: Light blue azure Ancillary equipment Heaford Cobra mounter proofer AV Flexologic Mounter proofer Print roll stock (120 off) including print gear and sleeve attachments Anilox roller stock (17off) including anilox gear and clutch attachments. Cantilever print sleeves (12off) Print roller and anilox storage racking system with overhead hoist C.I temperature control unit Chiller unit for chill rolls Print unit doctor chambers with related inking system Mobile operator trolley for print deck access Mobile Print roller and anilox roller trolleys C.I hoist lifting attachment bar Machine voltage: 415V, 50hz

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2018, operating hours: 6,503 h, load capacity: 6,000 kg, lifting height: 3,400 mm, construction height: 2,880 mm, overall weight: 11,250 kg, TECHNICAL DETAILS Load capacity: 6,000 kg Lift height: 3,400 mm Overall height: 2,880 mm Fork length: 1,200 mm MACHINE DETAILS Drive type: 6-cylinder diesel Front tires: 355/65-15 (100%) Rear tires: 250-15 (40%) Weight: 11,250 kg Operating hours: 6,503 h EQUIPMENT 3rd hydraulic valve Gbodpox E S D Eefx Abdjg Rear working lights Front working lights Heater Full cabin

Condition: ready for operation (used), Specifications of NEUE Herbold SB 60/145 S7-3 Motor Power: 70kw Feed Opening: (approximately 620 mm x 565 mm) Rotor Configuration: 5-knife open rotor staggered Gjdjw R Un Aopfx Abdsbg Bed Knives: 2 Installed Screen: 3/16" (approximately 4.76 mm) Additional Equipment: Control panel with soft-start feature Voltage: 460V / 3-phase / 60 Hz Extras: Includes seven extra screens We supply a wide range of granulators designed for plastics recycling, manufacturing, and waste reduction. Whether you need compact units for light-duty use or heavy-duty machines for high-output production, we have the right solution.

Condition: good (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: NVLA7K0128, travel distance X-axis: 480 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 330 mm, controller manufacturer: Fanuc, controller model: 0i-MC, total length: 1,575 mm, total width: 2,168 mm, table width: 400 mm, table length: 600 mm, overall weight: 3,000 kg, spindle speed (max.): 10,000 rpm, spindle motor power: 7,500 W, spindle nose: BT40, number of spindles: 1, number of slots in tool magazine: 16, Equipment: rotational speed infinitely variable, BRIDGEPORT HARDINGE GX480 Vertical Machining Centre. New 2007 Gbodjxgqwdjpfx Abdsg With Coolant, Interlocked guards, Low Volt Light FANUC 0i-MC Control Machine Dimensions: 1575 x 2168 mm Machine Weight 3000 kg Spindle Motor Power 7.5 kW Spindle Speed 10000 rpm Table Size 600 x 400 mm Tool Change Capacity 16 Station Tool Size BT40 Traverses XYZ 480 x 400 x 330 mm

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA SE2200LY WITH FANUC 0i-T PLUS CONTROL CNC LATHE WITH Y AXIS. TURRET UPGRADE - 12 STATION 24 POSITION BMT45, LIVE TOOLS 6K RPM, 2.75 KW MACHINE CONSTRUCTION & FEATURES ▪ 8” STANDARD CHUCK SIZE. ▪ 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ HIGH PERFORMANCE ROLLER LM GUIDEWAYS. ▪ 12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET - BMT45. [24 POSITION OPTION] ▪ 4,500 RPM HIGH POWER MAIN SPINDLE. ▪ 30 X 36 M/MIN RAPID TRAVERSE RATES – X & Z AXES. ▪ C-AXIS SPINDLE & WEDGE TYPE Y-AXIS. Swing Over the Bed Ø 600 MM Swing Over the Carriage Ø 600 MM Maximum Turning Diameter Ø 300 MM Maximum Turning Length 508 MM Bar Capacity – Main Spindle Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” - 203 MM Spindle Bore Ø 75 MM Spindle Speed 4,500 RPM Motor (Max / Cont.) 15.0 / 11.0 KW Torque (Max / Cont.) 167 [150.3] NM Spindle Type BELT Spindle Nose A2-6 FEEDS Travel X 210 MM Travel Y 110 (± 55) MM Travel Z 560 MM Rapid Speed X 30 M / MIN Rapid Speed Y 10 M / MIN Rapid Speed Z 36 M / MIN Slide Type ROLLER LM GUIDEWAYS TURRET Number of Tools 12 [24 POSITION INDEX] Tool Size - OD 20 MM² Tool Size - ID Ø 32 MM Indexing Time 0.15 SEC / STEP Y-Axis Type WEDGE TYPE Milling Tool Speed 6,000 RPM Motor (Max / Cont.) 2.75 / 1.85 [2.8 / 3.8] KW Torque (Max / Cont.) 26.2 [27.0] NM Collet Size ER 20 - Ø 13 Type BMT45 HYDRAULIC NC TAIL STOCK (STD. LIVE CENTER) Taper MT#4 Quill Diameter Ø 56 MM Travel 580 MM Coolant Tank 200 L POWER SUPPLY Electric Power Supply 18 KVA Thickness of Power Cable OVER 16 MM² Voltage 415V / 50HZ / 3PH Floor Space (L x W) 2,960 X 1,730 MM Height 1,920 MM Weight 4,200 KGS STANDARD FACTORY FITTED MACHINE OPTIONS SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3-JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC FOR STANDARD CNC SPECIFICATION - SEE MANUFACTURER'S BROCHURE Gedpox Tqkmefx Abdjbg HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) MANUAL VIEWER OPERATION MEMO PART PROGRAM STORAGE - 2MB (1,000 REGISTERABLE PROGRAMS) PREMIUM TOOL OPERATION SCHEDULING SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 200 LITRES FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (15 LITRES) CALL LIGHT (1 COLOUR) BACK SPIN TORQUE LIMITER FRONT DOOR INTERLOCK TOOLBOX MAIN SPINDLE - 4,500 RPM, 15.0 / 11.0 KW, 167 NM BELT DRIVEN STANDARD TOOLING PACKAGE - SEE MANUFACTURER'S BROCHURE HYDRAULIC TYPE NC TAILSTOCK - MT#4 56 MM QUILL, STD LIVE CENTER 12 STATION BMT45 TURRET, LIVE TOOLS 6K RPM, 2.75 KW, 26 NM INCLUDED FACTORY FITTED MACHINE OPTIONS CHIP - BUCKET STANDARD CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO QUILL FORWARD / REVERSE CONFIRMATION DEVICE

Condition: used, empty load weight: 8,576 kg, maximum load weight: 30,424 kg, overall weight: 39,000 kg, axle configuration: 3 axles, first registration: 12/2019, next inspection (TÜV): 10/2025, loading space length: 13,403 mm, loading space width: 2,490 mm, loading space height: 2,600 mm, loading space volume: 86 m³, suspension: air, tire size: 385/65 R22,5, wheelbase: 7,600 mm, color: white, Year of construction: 2019, Equipment: ABS, Tare weight: 8576kg, GVW: 39000kg, Loading area (L W H): 13,403 mm x 2,490 mm x 2,600 mmTyre size: 385/65 R22.5, Loading area volume: 86 m³, 1st axle: , 2nd axle: , 3rd axle: , Air suspension, Rear underrun, Electronic Brake System EBS, Toolbox, Ferry lashings, 1x15 and 2x7 pin plug, Antispray, 2 LED reverse (Banksman) lights on rear. 5 Bar tread plate floor. Pair of V7 load securing rails. LED side marker lights coupled with indicators. Ultra bright interior lighting without rotary switch., Please find an overview of all vehicles available on our website . Finance required? We offer individual financing solutions, full service contracts and telematic-services. We would be glad to advise you personally. Gbjdsx Sz Akepfx Abdog

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2016, operating hours: 16,765 h, load capacity: 8,000 kg, lifting height: 5,450 mm, free lift: 1,700 mm, construction height: 3,210 mm, TECHNICAL DETAILS Load capacity: 8,000 kg Lift height: 5,450 mm Overall height: 3,210 mm Free lift: 1,700 mm Fork length: 2,400 mm MACHINE DETAILS Godpfjx E Sv Isx Abdobg Drive type: 6-cylinder LPG engine Front tyres: 4 x 8.25-15 (80%) Rear tyres: 315/70-15 (80%) Operating hours: 16,765 h EQUIPMENT 3rd valve 4th valve Rear working lights Front working lights Heater Full cabin Triple side shift Side shift Air conditioning Camera system Dual pedal Double LPG tank Additional crossbeam for auxiliary lights and camera

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD3100L FANUC 0IT PLUS CNC LATHE MACHINE CONSTRUCTION & FEATURES 12” STANDARD CHUCK SIZE. 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. 10 STATION HIGH SPEED RIGID SERVO TURRET. 2,800 RPM 26.0 /18.5 KW HIGH POWER MAIN SPINDLE. 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET. MACHINE CAPACITIES Swing Over the Bed Ø 750 MM Swing Over the Carriage Ø 500 MM Maximum Turning Diameter Ø 500 MM Maximum Turning Length 1,300 MM Bar Capacity Ø 102 MM MAIN SPINDLE Chuck Size Ø 12” – 305 MM Spindle Bore Ø 115 MM Spindle Speed (rpm) 2,800 RPM Motor (Max/Cont.) 26.0 / 18.5 KW Torque (Max/Cont.) 1,123 / 657 NM Spindle Nose A2-11 FEED Travel X 265 MM Travel Z 1,350 MM Rapid Speed X 24 M/MIN Rapid Speed Z 30 M/MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 10 Tool Size - OD 25 MM² Tool Size - ID Ø 50 MM Indexing Time 0.15 SEC / STEP TAILSTOCK Type QUILL TYPE TAILSTOCK [PROGRAMMABLE TAILSTOCK] Taper MT5 [MT4] Quill Diameter Ø 100 MM Quill Travel 120 MM TANK CAPACITY Coolant Tank 220 L Lubricating Tank 1.8 L POWER SUPPLY Electric Power Supply 27 KVA Thickness of Power Cable Over 16 MM² Voltage 415V / 50Hz / 3Ph MACHINE Floor Space (L x W)4,405 x 1,978 MM Height 1,850 MM Weight 7,200 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CONVEYOR SIDE HINGED WITH CHIP BOX SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT GUN HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO STEADY REST PREPARATION - PROGRAMMABLE CLAMPING & TRAVEL PROGRAMMABLE TAILSTOCK IN LIEU OF STD QUILL TYPE TAILSTOCK - MANUAL TYPE MT#5 100 MM DIA QUILL, 120 MM QUILL TRAV STANDARD FACTORY FITTED OPTIONS CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 12 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC FOR STANDARD CNC SPECIFICATION - SEE MANUFACTURER'S BROCHURE HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) Gbodjx Tiggspfx Abdog STANDARD COOLANT SYSTEM 0.5 BAR FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) TOOLBOX STANDARD TOOLING PACKAGE - SEE MANUFACTURER'S BROCHURE STANDARD LIVE CENTER

Condition: used, empty load weight: 8,576 kg, maximum load weight: 30,424 kg, overall weight: 39,000 kg, axle configuration: 3 axles, first registration: 12/2019, next inspection (TÜV): 10/2025, loading space length: 13,403 mm, loading space width: 2,490 mm, loading space height: 2,600 mm, loading space volume: 86 m³, suspension: air, tire size: 385/65 R22,5, wheelbase: 7,600 mm, color: white, Year of construction: 2019, Equipment: ABS, Tare weight: 8576kg, GVW: 39000kg, Loading area (L W H): 13,403 mm x 2,490 mm x 2,600 mmTyre size: 385/65 R22.5, Loading area volume: 86 m³, 1st axle: , 2nd axle: , 3rd axle: , Air suspension, Rear underrun, Electronic Brake System EBS, Toolbox, Ferry lashings, 1x15 and 2x7 pin plug, Antispray, 2 LED reverse (Banksman) lights on rear. 5 Bar tread plate floor. Pair of V7 load securing rails. LED side marker lights coupled with indicators. Ultra bright interior lighting without rotary switch., Please find an overview of all vehicles available on our website . Finance required? We offer individual financing solutions, full service contracts and telematic-services. We would be glad to advise you personally. Godpfxsx Sthxj Abdebg

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD2200Y FANUC 0IT PLUS CNC LATHE WITH Y AXIS. MACHINE CONSTRUCTION & FEATURES ▪ ONE PIECE HEAVY DUTY CAST IRON BED CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ 4,000 RPM MAIN SPINDLE. ▪ 6,000 RPM LIVE TOOLING SPEED. ▪ HEAVY DUTY CUTTING WITH EXCELLENT PERFORMANCE. ▪ WEDGE TYPE Y-AXIS. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET - BMT55P ▪ HARDENED & GROUND BOX GUIDEWAYS Swing Over the Bed Ø 820 MM Swing Over the Carriage Ø 650 MM Maximum Turning Diameter Ø 300 MM Maximum Turning Length 610 MM Bar Capacity – Main Spindle Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” - 203 MM Spindle Bore Ø 76 MM Spindle Speed (Rpm) 4,000 RPM Motor (Max / Cont.) 18.5 / 15.0 [22.5 / 15.0] KW Torque (Max / Cont.) 206.2 / 125.4 [215.0 / 143.3] NM Spindle Type BELT Spindle Nose A2-6 Travel X 215 MM Travel Y 110 (± 55) MM Travel Z 680 MM Rapid Speed X 24 M / MIN Rapid Speed Y 10 M / MIN Rapid Speed Z 30 M / MIN HARDENED & GROUND BOX GUIDEWAYS Number of Tools 12 [24] Tool Size - OD 25 MM² Tool Size - ID Ø 20 MM Indexing Time 0.2 SEC / STEP Y-Axis Type WEDGE TYPE LIVE TOOL Motor (Max / Cont.) 5.5 / 3.7] KW Milling Tool Speed 6,000 RPM Torque (Max / Cont.) 52.5 / 26.5 NM Collet Size Ø 16 – ER25 Type BMT-55P TAILSTOCK Taper MT 4 Quill Diameter Ø 80 MM Quill Travel 120 MM Travel 680 MM TANK CAPACITY Coolant Tank 200 L Lubricating Tank 2.0 L Electric Power Supply 27 KVA Thickness of Power Cable OVER 25 MM² Godpfxsx Th Nyo Abdobg Voltage 415 V / 50 HZ / 3PH Floor Space (L x W) 3,380 x 1,800 MM Height 1,950 MM Weight 4,700 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CHIP - BUCKET STANDARD CHIP - CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 6.0 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE 30 KVA TRANSFORMER AND CABLE QUICK TOOL SETTER - AUTO PROGRAMMABLE TAILSTOCK IN LIEU OF STD TURRET UPGRADE - 12 STATION 24 POSITION BMT55P, LIVE TOOLS 6K RPM, 5.5 KW STANDARD FACTORY FITTED MACHINE OPTIONS SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) FRONT DOOR INTERLOCK TOOLBOX STANDARD TOOLING PACKAGE QUILL TYPE TAILSTOCK WITH STD LIVE CENTER

Condition: used, empty load weight: 8,576 kg, maximum load weight: 30,424 kg, overall weight: 39,000 kg, axle configuration: 3 axles, first registration: 12/2019, next inspection (TÜV): 05/2025, loading space length: 13,403 mm, loading space width: 2,490 mm, loading space height: 2,600 mm, loading space volume: 86 m³, suspension: air, tire size: 385/65 R22,5, wheelbase: 7,600 mm, color: white, Year of construction: 2019, Equipment: ABS, Tare weight: 8576kg, GVW: 39000kg, Loading area (L W H): 13,403 mm x 2,490 mm x 2,600 mmTyre size: 385/65 R22.5, Loading area volume: 86 m³, 1st axle: , 2nd axle: , 3rd axle: , Air suspension, Rear underrun, Electronic Brake System EBS, Toolbox, Ferry lashings, 1x15 and 2x7 pin plug, Antispray, 2 LED reverse (Banksman) lights on rear. 5 Bar tread plate floor. Pair of V7 load securing rails. LED side marker lights coupled with indicators. Ultra bright interior lighting without rotary switch., Please find an overview of all vehicles available on our website . Finance required? We offer individual financing solutions, full service contracts and telematic-services. We would be glad to advise you personally. Godpjx Sth Sjfx Abdebg

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD3100M FANUC 0IT PLUS CNC HIGH POWER TURNING CENTRE WITH HARDENED & GROUND BOX GUIDEWAYS, HIGH SPEED SERVO TURRET, C-AXIS & DRIVEN TOOLS & 12" STD CHUCK Swing Over the Bed Ø 750 MM Swing Over the Carriage Ø 500 MM Maximum Turning Diameter Ø 420 MM Maximum Turning Length 740 MM Bar Capacity - Main Ø 102 MM MAIN SPINDLE Chuck Size Ø 12” – 305 MM Spindle Bore Ø 115 MM Spindle Speed (Rpm) 2,800 RPM Motor (Max. / Cont.) 26.0 / 18.5 KW Torque (Max. / Cont.) 1,123 / 657 NM Spindle Type BELT [GEARLESS] Spindle Nose A2-11 C-Axis Indexing 360° (0.001°) Travel X 265 MM Travel Z 830 MM Rapid Speed X 24 M / MIN Rapid Speed Z 30 M / MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 12 Tool Size - OD 25 MM² Tool Size - ID Ø 40 MM Indexing Time 0.15 SEC / STEP LIVE TOOLS Motor (Max / Cont.) 5.5 / 3.7 KW Milling Tool Speed 5,000 RPM Torque (Max. / Cont.) 70.0 / 35.4 NM Collet Size ER32 - Ø 25 Type BMT65P QUILL TYPE TAILSTOCK [PROGRAMMABLE BUILT IN TAILSTOCK] Taper MT5 [MT4] Quill Diameter Ø 100 MM Quill Travel 120 MM Tailstock Travel 830 MM TANK CAPACITY Coolant Tank200 L Lubricating Tank 1.8 L POWER SUPPLY Electrical Power Supply 27 [30 GEARLESS] KVA Voltage 415V / 50HZ / 3PH MACHINE Floor Space (L x W) 3,885 x 1,800 MM Height 1,850 MM Weight 6,050 KGS STANDARD FEATURES SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 12 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE Gbsdpfx Asx Thzvsbdog STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" TOUCH SCREEN MONITOR FOR FANUC (SMART GUIDE i) HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) PART PROGRAM STORAGE - 2MB (1,000 REGISTERABLE PROGRAMS) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) TOOLBOX MAIN SPINDLE - 2,800 RPM, 26.0 / 18.5 KW, 1123 NM BELT DRIVEN TOOLING PACKAGE QUILL TYPE TAILSTOCK WITH STD LIVE CENTER 12 STATION BMT65P SERVO TURRET, LIVE TOOLS 5,000 RPM, 5.5 KW, 47.0 NM FACTORY FITTED MACHINE OPTIONS CHIP BUCKET STANDARD CHIP CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD (RATED AT 60HZ SUPPLY) BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE 30 KVA TRANSFORMER AND CABLE QUICK TOOL SETTER - MANUAL PROGRAMMABLE TAILSTOCK IN LIEU OF STDMACHINE CONSTRUCTION & FEATURES 12” STANDARD CHUCK SIZE. 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. 12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET – BMT65P. 2,800 RPM 26.0 / 18.5 [35.0 / 25.0 GEARLESS] KW HIGH POWER MAIN SPINDLE. 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. C-AXIS MAIN SPINDLE. ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET.

Condition: used, empty load weight: 8,576 kg, maximum load weight: 30,424 kg, overall weight: 39,000 kg, axle configuration: 3 axles, first registration: 12/2019, next inspection (TÜV): 09/2025, loading space length: 13,403 mm, loading space width: 2,490 mm, loading space height: 2,600 mm, loading space volume: 86 m³, suspension: air, tire size: 385/65 R22,5, wheelbase: 7,600 mm, color: white, Year of construction: 2019, Equipment: ABS, Tare weight: 8576kg, GVW: 39000kg, Loading area (L W H): 13,403 mm x 2,490 mm x 2,600 mmTyre size: 385/65 R22.5, Loading area volume: 86 m³, 1st axle: , 2nd axle: , 3rd axle: , Air suspension, Rear underrun, Electronic Brake System EBS, Toolbox, Ferry lashings, 1x15 and 2x7 pin plug, Antispray, 2 LED reverse (Banksman) lights on rear. 5 Bar tread plate floor. Pair of V7 load securing rails. LED side marker lights coupled with indicators. Ultra bright interior lighting without rotary switch., Please find an overview of all vehicles available on our website . Finance required? We offer individual financing solutions, full service contracts and telematic-services. We would be glad to advise you personally. Gjdpfxjx Sth Es Abdobg

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA HD3100YA FANUC 0IT PLUS CNC LATHE WITH Y AXIS MACHINE CONSTRUCTION & FEATURES ▪ ONE PIECE HEAVY DUTY CAST IRON BED CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ 3,500 RPM MAIN SPINDLE. ▪ 5,000 RPM LIVE TOOLING SPEED. ▪ HEAVY DUTY CUTTING WITH EXCELLENT PERFORMANCE. ▪ WEDGE TYPE Y-AXIS. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET – BMT55P ▪ HARDENED & GROUND BOX GUIDE WAYS MACHINE CAPACITIES Swing Over the Bed Ø 800 MM Gbjdpfx Abox Thu Nsdog Swing Over the Carriage Ø 670 MM Maximum Turning Diameter Ø 420 MM Maximum Turning Length 760 MM Bar Capacity – Main Spindle Ø 81 MM MAIN SPINDLE Chuck Size Ø 10” - 254 MM Spindle Bore Ø 91 MM Spindle Speed (Rpm) 3,500 RPM Motor (Max / Cont.) 26.0 / 18.5 KW Torque (Max / Cont.) 734 / 522 NM Spindle Type BELT Spindle NoseA2-8 FEED Travel X265 MM Travel Y120 (± 60) MM Travel Z830 MM Rapid Speed X24 M / MIN Rapid Speed Y10 M / MIN Rapid Speed Z30 M / MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools12 Tool Size - OD25 MM² Tool Size - IDØ 20 MM Indexing Time0.2 SEC / STEP Y-Axis Type WEDGE TYPE LIVE TOOL Motor (Max / Cont.) 5.5 / 3.7 KW Milling Tool Speed 5,000 RPM Torque (Max / Cont.) 70/0 / 35.4 NM Collet Size Ø 16 – ER25 Type BMT-65P TAIL STOCK Taper MT 5 Quill Diameter Ø 100 MM Quill Travelb120 MM Travel b830 MM Voltage 415 V / 50 HZ / 3PH Floor Space (L x W) 3,630 X 1,910 MM Height 1,960 MM Weight 6,200 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CONVEYOR & CHIP BOX HELICAL INTERPOLATION FUNCTION HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO MAIN SPINDLE - 3,500 RPM, 26.0 / 18.5 KW, 734 NM BELT DRIVEN PROGRAMMABLE TAILSTOCK IN LIEU OF STD QUILL FORWARD / REVERSE CONFIRMATION DEVICE QUILL TYPE TAILSTOCK - MANUAL TYPE MT#5 100 MM DIA QUILL, 120 MM QUILL TRAV STANDARD FEATURES SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 10 INCH 3 JAW HYDRAULIC CHUCK CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE HYDRAULIC CHUCK PRESSURE INTERLOCK - MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) PART PROGRAM STORAGE - 2MB SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 180 LITRES FULL SPLASH GUARDING SYSTEM CALL LIGHT TOOLBOX TOOLING PACKAGE QUILL TYPE TAILSTOCK 12 STATION BMT65P SERVO TURRET, LIVE TOOLS 5,000 RPM, 5.5 KW, 47.0 NM
