SuS Schleiftechnik und Maschinenhandel GmbH

Condition: used, Year of construction: 2013, Suitable for automatic tooth flank grinding on both sides of carbide-tipped circular saw blades. Accesories: full fairing coolant system Automatic central lubrication. Measuring system for measuring saw blades. Control panel with LCD color display. DNC service. Alphanumeric keyboard. Grinding speed and grinding path depending on the tooth surface, can be adjusted as required. 2 grinding wheel mounts Coolant level monitoring Automatic grinding wheel compensation Prepared for robot operation with automatic loading door oil pan 2 x saw blade magnet holder >Ø 320mm, >Ø 180 mm 1 centering ring. Circular saw blade diameter: 200 - 840mm Circular Saw Bore Diameter: from 16 mm Tooth pitch: 6 - 180mm grinding path: up to 25 mm tangential relief angle: 0 to 10 degrees max. grinding wheel diameter: 125 mm Grinding wheel bore diameter: 32 mm Grinding spindle variable: 1600 - 5500 rpm, Connected load approx.: 8kVA (400V / 50Hz) Dimensions W x D x H =: 2770x1900x2045mm mass: approx. 4700 kg Lrolhsv Sbmqeccqlei colour: Gray

Condition: used, Year of construction: 2000, Suitable for automatic processing of PCD-tipped milling cutters, shank tools, disc-shaped tools such as Saws, milling cutters, etc. using the wire electro-erosion process. Accesories: Total enclosure, mist extractor Lelov Sa Aqjhccqlori Probe, Machine lamp, Automatic central lubrication, Coolant system dielectric fluid Measuring mandrel cutter outer diameter max: 250 mm cutting length max.: 200 mm shank tool diameter: 10 - 250 mm cutting length: 200 mm Outside diameter of disc-shaped tools max.: 250 mm tool weight max.: 20 kg X-axis travel: 220 mm Y-axis travel: 300 mm W axis travel: 200 mm A-axis rotation range: 60 ° A-axis taper: ISO 40 E-axis swivel range: 120 ° number of revolutions: 80 - 2000 rpm. Dimensions L x W x H: 2235x2630x2130mm mass: approx. 4500 kg Connected load approx.: 400V / 50Hz / 4.5KW colour: turquoise RAL 5021/grey RAL 9002

Condition: used, Year of construction: 1998, Suitable for automatic grinding of tooth face and tooth back on carbide-tipped circular saw blades in one clamping. All known tooth geometries (flat, alternating, trapezoidal, etc.) can be machined automatically and in one run be sanded. Accessories: Total enclosure Sawblade positioning device, Automatic central lubrication, Coolant system, Extractor, Halogen lamp, 1 sawblade mounting bolt including magnetic flange. Circular saw blade diameter without robot: 100-840mm Circular saw blade diameter with robot: 100 - 630mm Circular Saw Bore Diameter: 10 - 220 mm Sheet thickness without robots: up to 14 mm Sheet thickness with robot: up to 5 mm Tooth pitch: 6 - 120mm Lrolhsv Sayvsccqlei rake angle: -30° to +40° clearance angle: 5° - 45° Bevel cut on the back of the tooth: up to 45 ° Bevel cut on the negative tooth face: up to 45 ° Working speed for front and back grinding: up to 12 teeth/min., Grinding path and grinding speed per machining surface on the tooth: infinitely adjustable Dimensions loader L x W x H =: 6500 x 1900 x 2000 mm Dimensions machine L x W x H =: 2450 x 2050 x 2060 mm Weight approx.: 3000 kg Weight machine: 3000 kg weight loader: 1850 Connected load approx.: 5.6kW (400V / 50Hz) colour: telegrey RAL 7045 weight machine: 2000 kg

Condition: new, Year of construction: 2008, Suitable for measuring and presetting all types of cutting tools as well as for measuring grinding wheel packages. The extensive and comprehensive software solution with intuitive graphical user guidance guides users quickly and safely to precise measurement results. Accessories: Upgrade to ZOLLER measuring device control »pilot 4.0« with 17” monitor, Autofocus/venturion 800, Rotary encoder (ROD=) for high-precision position determination, Tool inspection (incident image processing with centered LED lighting), High-precision spindle “ACE” concentricity 0.002 mm, Tool management standard, FORED 'manual measuring programs, 3 used attachment holders. Z-axis travel: 800 mm Traverse X-axis: 200 mm X axis travel: 200 mm Workpiece diameter: Max. 1000 mm workpiece length: Max. 800 mm Workpiece length: Max. 400 mm Max. snap gauge diameter: d = 200mm Max. Snap gauge diameter: d = 100mm Workpiece holder: SK 50 Tool weight: max. 10kg Repeatability: +/- 0.002mm, Display accuracy: 0.001mm Concentricity: 0,005 mm Connected load: 230 V / 50 Hz mass: about 600 kg Compressed air connection: approx. 6 bar Lelhccjv Sauteqlori Dimensions W x D x H: 2400 x 1650 x 2250 mm Weight: approx. 200 kg colour: silver gray / anthracite

Condition: used, The MP11 is a hard-wired probe ideal for small machine tools with manual tool changes. The probe is mounted in the machine spindle and the signal transmission cable is connected to the machine control. The MP11 turns off the illuminated LED every time the probe pin touches the workpiece. MP11 retrofit kit includes: MP11 probe with cable and connectors Remote socket kit Ceramic probe Case A shaft is not included in this kit. direction detection: ±X, ±Y, +Z Probe overflow X and Y:: ±17.5° Button overflow X and Y:: ±17.5° Probe trigger force X and Y: 50 gf – 150 gf Lrelhccjv Sat Neqlsi button trigger force X and Y: 50 gf – 150 gf Probe release force Z: 180 gf – 700 gf button release force Z: 180 gf – 700 gf Unidirectional repeatability: 1.0 μm (0.00004 inches)

Condition: used, Year of construction: 1999, Description: Suitable for regrinding and making new wood and metalworking tools of all kinds. Accessories: Pallet loader Software package Toolstudio 1.7 Standard Software package 1 (cylindrical tools with sharp edges, corner and full radius), Software package 2 (conical-spiral tools with sharp edges, corner and full radius), Software package 3 (drills and step drills), Software package 4 (step tools), Software package 6 (woodworking tools), Software package 8 (tap), Software package 16 (warm-up program), Software package 32 (contours), Electrostatic fume separator, Infinitely variable speed control, Automatic fire extinguishing system, Belt filter system 400 l, Measuring probe, Pneumatic workpiece clamping, Oil drip tray, 8 loader pallets, 2 grinding wheel holders. X - axis longitudinal movement: 490 mm Y-axis vertical movement: 320 mm Z-axis transverse movement: 660 mm C-axis rotary table: swivel range +/- 200 ° Workpiece holder: ISO 50 Center height (with / without upper table): 145/190 rpm. center height (with/without top table): 145/190 rpm Max. Workpiece diameter: 240 mm max. workpiece length: 350 mm Max. Workpiece length: 350 mm max. grinding wheel diameter: 200 mm, Drive power grinding spindle: 18 kW Grinding spindle speed continuously variable: 0 - 8500 rpm Max. Grinding wheel diameter: 200 mm, Connected load: 35 kVA (400 V / 50 Hz) Lrelhccqsv Satvolji Dimensions W x D x H: 2170 x 2650 x 2280 mm mass: approx. 3600 kg Grinding spindle speed stepless: 0-7000 rpm. colour: gray RAL 7035/7043 Weight: approx. 4200 kg

Condition: used, Year of construction: 2010, Suitable for flexible circular and profile grinding of blanks, step tools, micro tools, drill pins and Punching tools made of carbide and HSS. Equipment: Full cladding, charging system, control FANUC 160-iMB, Software: Grinding: End mills, full radius and radius cutters Cone tools, full radius and radius taper cutters Drills/Step Drills, Step Tools Drills (Industrial, Aluminium, Surgical, Dental) Routers Medical/Surgical Components Simulation: VirtualGrind PC programming system/simulation FluteCalc 2D simulation of groove shapes 3DCalc 3D simulation of any tools BurCalc 2D and 3D simulation of drills TaperCalc 2D and 3D simulation of conical tools ISO programming with Rollomatic coordinate system, including 3D simulation probing routines (grooves and coolant holes) Teach-in (disk shapes and machine calibrations) Graphic disk representation with zero point shifts Various control diagnoses measuring probe, Automatic central lubrication, 8 sets of V-block for grinding support lunette, Hydraulic bezel with 8 inserts 12 pallets, 2 grinding wheel holders, 2 chucks with 7 collets. Workpiece diameter for manual loading and unloading: 1 - 20 mm X axis travel: 280 mm Y axis travel: 245 mm overall length: 30 - 350 mm Z-axis travel: 355 mm Grinding diameter: 2 - 32 mm power of the grinding spindle: 4,1 kW Traverse X-axis: 30 mm number of revolutions: 2000-7200 rpm Dimensions L x W x H: approx. 2060 x 2032 x 1880 mm Y-axis travel: 350 mm Weight approx.: 3500 kg Connected load: (400 V / 50Hz) colour: blue / gray Lrelhsv Satijccqlei V-axis travel: 22 mm A-axis (rotation of grinding head): 240° resolution 0.0001° workpiece spindle speed: 60 rpm swivel range B-axis: 135 ° Resolution B-axis max.: 0.001 ° C-axis spindle resolution: 0,0001° grinding spindle speeds: 0-8,000 rpm, rapid traverse X-axis: 20 m/min. rapid traverse Y-axis: 15 m/min. rapid traverse Z-axis: 20 m / min. grinding spindle motor: 20 kW connected load: 400 V / 50 Hz Dimensions W x D x H =: approx. 2640 x 2380 x 2270 mm mass: approx. 8200 kg Color: : blue/white Roughing motor: 8.5 kW Finishing motor: 1.4 kW directly driven grinding spindle with integrated cooling: Ø 100 mm Grinding spindle performance: 4,1 kW Grinding wheel diameter: 200 mm Workhead motor: 0,70 kW

Year of construction: 2012, Condition: used, Description: external data input station for use with Vollmer ND brand saw blade handling systems. Serves for individual input of the various processing steps of a saw blade. The data input station with integrated router takes over the interface between the machines, to the customer's own server or PC Lrjlhov Sarxsccqlsi

Condition: used, Description: external data input station for use with Vollmer ND brand saw blade handling systems. Serves for individual input of the various processing steps of a saw blade. The data input station with integrated router takes over the interface between the machines, to the customer's own server or PC Lrelhjv Saqzjccqloi

Condition: used, Year of construction: 2023, Description: Specifications: Magnetic chuck length 1000 mm, magnetic chuck width 155 mm, swivelling through 360°, grinding height approx. 120 mm, grinding width 275 mm, grinding spindle speed 1500 rpm, grinding motor 7,5 kW, grinding wagon speed stepless adjustable 0,02 - 30 m/min., grinding ring diameter 200 mm, connected load approx. 15 kW (400 volts / 50 Hz), weight approx. 3000 kg, dimensions w x d x h = 4533 x 1500 x 1600 mm, colour blue / grey. Accessories: Quick change device for the grinding motor Paper band filter with automatic paper transport 10 kg coolant additive 120 plus 2 pc. intermediate flange for diamond wheels 1 hand lapping stone D7/G78 1 pc. knife clamping fixture, for planer knives (drawing G40-28Z57) Type Tersa L=650 mm 1 pc. knife clamping fixture, for planer knives Type Tersa L=750 mm 2 fixed magnets 400 x 90 x 20 mm for TC – plates NC-A axis Adjustment via servo motor, hydr. Clamping, angle preselection via control panel Resolution: 0,01° Frequency converter for grinding motor 1000 -2800 RPM 1 pc. diamond wheel, Art. 007212 Special options: Blum measuring head for checking and compensating of the wheel wear. Measuring finger to determine the exact position of the cutting edge and the work piece height by the table zero position. Lslhev Sapwoccqlsri Grinding Dust filter - Accordion covers over the machine bed with bed extension and 2 openings to connect airfilter Version 56 elT, linear guide ways grinding length: 1000 mm magnet width: 155 mm swivel range: 360° grinding height: about 120 mm Grinding width: 275 mm Grinding spindle speed stepless: 1500 rpm grinding motor: 7,5 kW Grinding carriage speed stepless: 0.02 - 30 m/min Slip ring diameter: 200 mm Connected load approx.: approx. 15 kW (400 V / 50 Hz) Weight approx.: 3000 kg Dimensions W x D x H =: 4533 x 1500 x 1600 mm colour: Blue / Grey

Condition: used, Year of construction: 2007, Suitable for cleaning cooling oil for grinding hard metal. Accessories: 1 filter tower automatic backflushing container content: 500 l flow capacity max: 50-60L/min. Lrelov Sapdohccqloi Flow rate max: 50-60 l/min. Filter fineness:: greater than 0.003 mm Connected load approx.: 400 V / 50 Hz Dimensions W x D x H: 1950 x 1000 x 1370 mm Weight approx.: 400 kg colour: Purple

Condition: used, Year of construction: 2005, Suitable for automatic grinding or re-toothing and chamfering of HSS and segment saw blades as well as solid carbide saws with ceramic grinding wheels and deep grinding using CBN or diamond grinding wheels. Accessories: Device for automatic chamfering of regular-tooth saw blades, Program for standard curved and pointed teeth, CAD program for creating 250 custom tooth shapes, Automatic sawblade diameter adjustment, Full enclosure including 400 L coolant system with tank, Automatic fire extinguishing system including explosion flap and pressure switch, Automatic central lubrication, Machine lamp. Saw diameter: 40-710mm saw diameter: 40-710 mm Tooth pitch: 1 - 55 mm Number of teeth: 2 - 998 number of teeth: 2 - 998 Saw blade thickness: max. 8 mm Ljlhjv Sanyjccqljri saw blade thickness: max. 8 mm Grinding wheel diameter: 200 x 32 mm Connected load: 7.5 kW (400 V / 50 Hz) mass: about 2000 kg Dimensions: W x D x H = 1616 x 2565 x 2200 mm colour: blue/grey

Condition: used, Year of construction: 2015, Suitable for automatic cutting of HSS, solid carbide, and ceramic tools/materials. Accessories: Total enclosure Automatic parting-off infeed, Coolant system (100 L tank), Three-point double clamping system for cylindrical tools 3–50 mm, Grinding wheel flange Ø 64 mm DIA/CBN, special longitudinal stop, Measuring range up to 300 mm, Electronic dial indicator with digital display and data output, splash-proof, Fire extinguishing system, Mist extractor. Cutting range up to: 50 mm cutting disc diameter: 200 mm cutting wheel diameter: 200 mm Drive motor: 1,5 kW Cutting speed: 0.1–1 mm/s weight: about 400 kg Connected load approx.: (400 V / 50 Hz) Lslhov Rbnxjccqlori Dimensions L x W x H: 950 x 820 x 1950 mm mass: about 200 kg colour: light gray

Condition: used, Year of construction: 2014, Suitable for cleaning cooling lubricant and oil-based grinding mist. Fan power: approx. 2400 m³ / h Suction power up to: 1200 m³ / h Noise level: 75 dB A Lrslhcsv Rbf Rscqlji Pressure difference: 840 Pa Connected load approx.: 3.4 A (230 V / 50 Hz) Dimensions L x W x H: 1130 x 625 x 610 mm Weight approx.: 130 kg colour: Gray

Condition: used, Year of construction: 2000, Suitable for cleaning cooling oil used in carbide grinding. Accessories: 6 filter towers, automatic backflushing, magnetic separator. container content: 4000 l Flow rate max: approx. 360 l/min. Filter fineness:: greater than 0.003 mm Connected load approx.: 9.0 kW (400 V / 50 Hz) Dimensions W x D x H: 6000 x 1200 x 1650 mm Weight approx.: 2000 kg Lolhccsv N Iuieqlsri colour: light grey

Condition: used, Year of construction: 2008, Balancing machine for balancing tool holders in 1 level. Accesories: Dial gauge holder, Dial gauge. max. tool length: 360 mm Max. Workpiece diameter: 340 mm max. tool weight: 15 kg measurement accuracy: < 0.5mm Measurement accuracy: < 1 gmm compressed air: 6 bar Lrjlhccqsv N Ip Telji Power consumption: 0,4 kW Power supply: 230 V / 50-60 Hz Dimensions W x D x H =: 500 x 680 x 820 mm mass: 200 kg colour: black-and-white

Condition: used, Year of construction: 2024, Suitable for cleaning grinding mist containing coolant and oil. Suitable for CNC-controlled Walter Helitronic machines. flow: 1800 m³ Volumetric flow: 1800 m³ Temperature: 45° engine power: 1.3/1.15 kW Connected load approx.: 1.9 kW (230/400 V / 50 Hz) Lrjlhev N Hz Ujccqloi Dimensions W x D x H =: 177 x 1280 x 510 mm colour: light grey RAL 7035

Condition: used, Year of construction: 2012, Suitable for fully automatic grinding, re-toothing, and beveling of HSS and segmented circular saw blades, as well as solid carbide circular saw blades, chamfering saw blades/thin-cutting saws with chip breakers (diameters from 200-500 mm, tooth pitch from 8-30 mm), using a deep grinding process with CBN or diamond grinding wheels. Accessories: Fully enclosed, Automatic central lubrication, Coolant system with pump, Automatic grinding wheel threading, including blade diameter and tooth pitch check, Device for fully automatic chamfering of regular-toothed saw blades, Programs for all standard curved and pointed teeth, Automatic peripheral speed switching between CBN and diamond grinding wheels, Integrated modem for remote diagnostics and maintenance, as well as online application support, Machine light, 1 F1730 saw blade holder for grinding saw blades from 130 mm to 850 mm. Saw diameter: (40) 130 - 850 mm saw diameter: ( 40 ) 130 – 850 mm Tooth pitch: 1 - 55 mm Number of teeth: 2 - 998 number of teeth: 2 - 998 Saw blade thickness: max. 8 mm saw blade thickness: max. 8 mm Grinding wheel diameter: 200 x 32 mm Coolant pressure: approx. 6 bar coolant pressure: approx. 6 bar Coolant tank: approx. 300 l Grinding motor: 3 kW grinding motor: 3 kW Connected load: approx. 5.5 kW (400 V / 50 Hz) Lolhcjv N Huzscqljri mass: about 1600 kg Weight: approx. 1600 kg Dimensions: L x W x H = 1250 x 1870 x 2250 mm colour: dove blue/grey

Year of construction: 2008, Condition: used, Universal machine for eroding and grinding various PCD tools up to 250 mm in diameter and 200 mm in length in production and service. Accessories: Full enclosure Measuring probe for complete measurement of the tools Workpiece carrier adaptation A-axis from SK 50 to HSK 63 A Loader for up to 6 eroding disk sets (tool changer) Alphanumeric keyboard Standard programs for measuring, eroding Cooling and cleaning device for dielectric Automatic fire extinguishing device Extraction N183 1 exchange element 1 flushing set 1 measuring mandrel 1 mounting flange for rotating electrodes X axis travel: 440 mm B-axis: +/- 15° Y axis travel: 876 mm Z-axis travel: 420 mm E-axis swivel range: 210° A-axis rotation range: 360° workpiece carrier base: SK 50 workpiece length max.: 200 mm Workpiece diameter max.: 250 mm workpiece weight: 15 kg Ljlhsvy Uttoccqleri Connected load approx.: 6.7 kW 400V/50 Hz Weight approx: 7000 kg Dimensions W x D x H =: 1987 x 3141 x 2275 mm colour: RAL 7047 Telegray 4/ Color RAL 7045 Telegray 1

Condition: used, Year of construction: 2018, Suitable for fully automatic grinding or re-toothing and beveling of HSS and segment circular saw blades as well as solid carbide circular saw blades, cutting saw blades/thin-cutting saws with chip breaker (diameter of 200-500 mm, tooth pitch of 8-30 mm), using deep grinding techniques with CBN or diamond grinding wheels. Accessories: Special program for grinding circular saws with variable tooth pitch, Prepared for later installation of a device for grinding chip separator grooves, Coolant system with 300 l tank, Centering rings 32/40/50 mm, Power clamping nut for reliable fixing of the saw blade on the saw blade holder Ø 115 mm, Automatic central lubrication, Automatic threading of the grinding wheel, including checking the diameter and tooth pitch, Device for fully automatic chamfering of regularly toothed saw blades (from saw blade diameter 145 mm and larger with standard saw blade holder F1730 (Min = 120 mm with saw blade holder F 1755)), Automatic movement of the saw blade holder to the entered saw blade diameter, Programs for all standard arch and pointed teeth, Circular grinding of sawblades to grind down the existing teeth, Automatic switching of the peripheral speed between CBN and dia grinding wheels, Extractor, Machine light, 1 saw blade holder F1755, 1 saw blade holder F1730, Operater tools. saw diameter: ( 40 ) 130 – 850 mm Tooth pitch: 1 - 50 mm number of teeth: 2 - 998 saw blade thickness: max. 8 mm Grinding wheel diameter: 200 x 32 mm coolant pressure: approx. 6 bar Lslhsvyzfpjccqlori Connected load: approx. 7.3 kW (400 V / 50 Hz) Weight: about 1600 kg Dimensions: L x W x H = 1250 x 1870 x 2250 mm colour: Gray

Condition: used, Year of construction: 2001, Suitable for cleaning cooling lubricant and oil-containing grinding mist. Fan power: approx. 2400 m³ / h Suction power up to: 1200 m³ / h Noise level: 75 dB A Pressure difference: 840 Pa Connected load approx.: 6.0 / 12 KV (230 V/50/60 Hz) Dimensions L x W x H: 1130 x 625 x 610 mm Weight approx.: 65 kg colour: Gray air flow rate: approx. 500 m³/h Lolhjvdb A Aeccqljri Performance : 140 A noise level: 75 dB A

Condition: used, Year of construction: 2003, Suitable for cleaning cooling oil for grinding hard metal. Accessories: 1 filter tower automatic backflushing container content: 500 l flow capacity max: 50-60L/min. Lelhccevbz A Djqleri Flow rate max: 50-60 l/min. Filter fineness:: greater than 0.003 mm Connected load approx.: 400 V / 50 Hz Dimensions W x D x H: 1950 x 1000 x 1370 mm Weight approx.: 400 kg colour: Purple

Condition: used, Year of construction: 2010, Suitable for cleaning cooling oil for grinding hard metal. Accessories: 2 filter towers, Automatic backflushing, Chiller container content: 800 l flow capacity max: 60 l / min. Lelhccjvbf R Ejqlori Flow rate max: 60 l / min. Filter fineness:: greater than 0.003 mm Connected load approx.: 9.0 kW (400 V / 50 Hz) Dimensions W x D x H: 1700 x 1100 x 2400 mm Weight approx.: 710 kg colour: light grey

Condition: used, Year of construction: 2001, Suitable for manual grinding and pointing of HSS or HM twist drills, step drills, reamers, countersinks, taps and milling cutters etc., both left and right cutting. Accessories: 1 six-jaw chuck, automatic feed, 3 cams. Lslhou Dmrasccqljri Grinding area: 12 - 80 mm grinding area: 4-50 mm Point angle 50 ° - 180 °: Number of cutting edges tip angle: 40° - 180° Point angle: 50 ° - 180 ° number of cutting edges: 1, 2, 3, 4, 5, 6 Number of cutting edges: 2, 3, 4 or 6 Dimensions W x D x H: 1100 x 1100 x 1600 mm feed: continuously from 0.4 - 4 mm / min. Connected load approx.: 1.3 kW (400 V / 50 Hz) Grinding wheel diameter: 300 x 70 x 127 mm mass: about 350 kg Grinding wheel speed: 1420 rpm., colour: blue/white Connected load approx. 3.2 kW (400 V / 50 Hz): Weight approx. 1050 kg

Condition: used, Year of construction: 1997, Suitable for manual grinding of tooth flanks on carbide-tipped circular saw blades. Accesories: wet grinding device, 1 locating bolt, 1 set of centering rings, 1 stop finger Circular saw blade diameter: 60 - 700mm circular saw blade bore diameter: 10 - 150mm Tooth pitch: from 8 mm rake angle: 0° to 30° tangential relief angle: 0°- 17° radial relief angle: 0 -3° grinding path: up to 15 mm Grinding wheel diameter: 100 mm Connected load approx.: 0.75 kW ( 400 V / 50 Hz) Weight approx: 105 kg Lelhju Dlbmsccqljri Dimensions W x D x H =: 800 x 700 x 580 mm
