Grinding machines Offers
filling capacity:100 l
power capacity:0,75 kW
tank shape:rund
rotary speed of motor:1500 / 1000 U/min
Nkfd2
weight of the machine ca.:0,3 t
dimensions of the machine ca.:1,5 x 1,0 x 1,2 m
more
x-travel:400 mm
y-travel:250 mm
workpiece height:500 mm
grinding diameter:220 mm
table surface area:600 x 320 mm
throat:310 mm
range of angles:12 °
grinding wheel stroke - vertical:110 mm
stroke speeds:0 - 6 m/min
grinding spindle speed:bis 50000 U/min
peripheral speed:max. 35 m/sec
capacity:ca. 7 kVA
power capacity:6 kW
Dyo8y2u
weight of the machine ca.:2 t
dimensions of the machine ca.:3 x 3 x 3 m
rotary table d = 300 mm frequency changer more
Description:
Suitable for eroding PKD tools for the wood and metal industry, as well as for regrinding and remanufacturing wood and metal processing tools of all kinds.
Technical data:
X – axis longitudinal movement 460 mm, Y – axis vertical movement 320 mm, Z – axis cross-movement 660 mm, C-axis swivel range +/-200 °, workpiece recording ISO 50, workpiece diameter max. 320 mm, workpiece length during forehead processing 280 mm, workpiece length with circumference processing 350 mm, grinding di... more
Control: FANUC 21 GA
Table surface ground: 850 x 400 mm
Gvu80w
Table longitudinal movement: 950 mm
Table movement: 440 mm
Grinding height between table + new disc max .: 523 mm
Magnetic chuck: 800 x 400 mm
Table load including: 700 kgEquipped with:
NC overhead dresser with autom. compensation
Band filter
Magnetic table 800 x 400 mm
Space required: 3322 x 2310 x 2098 mm
Weight: 4000 kg more
General Data
Measurements width 1543 mm
Measurements depth 1600 mm
Measurements height 2400 mm
Machine weight 1700 kg
Machine serial number 742012
Workpiece
Workpiece X 600 mm
Workpiece Y 5000 mm
Workpiece Z 155 mm
Workpiece weight 200 kg
Table
Outer length 1600 mm
Outer width 600 mm
Movement
X-Axis Movement 600 mm
Y-Axis Movement 5000 mm
Z-Axis Movement 155 mm
Media
Main electronic connection 360W 32A
Power consumption 11 kVA
Bev2yemepb
Additional Equipment
Dust collector / dust filter
T... more
