Condition: like new (used), Year of construction: 2005, Hardinge Quest 51 SP CNC lathe Super precision 2 axes Year: 2005 Control: FANUC Model: 21i-T Spindle speed range: 50–4200 rpm Spindle motor power: 15 kW X-axis travel: 189 mm Pedpfxjzak Ece Aprept Workpiece diameter above the bed: 520 mm Maximum turning diameter: 356 mm Through-hole bar capacity (round collet): 51 mm, spindle bore 60 mm Distance between centers (Z-axis travel): 610 mm Tool turret: 12 positions Square tool shank, max. 25 mm Tool diameter, max. 40 mm Tool change time (from station to station): 0.35 s Machine dimensions: width x depth x height: 1950 x 3860 x 1905 mm Machine weight: 5550 kg Accessories/options: - tool holders - chip conveyor - documentation Connected and available for inspection under power in our warehouse!

Condition: used, Year of construction: 2023, machine/vehicle number: IntNr231583, CNC Short-Turn Lathe – Citizen Miyano BNE-65 MYY Condition: Very good, ready for operation Availability: Short notice Technical Overview Manufacturer: Miyano Model: BNE 65 MYY Year of manufacture: 2023 Control: Mitsubishi M800 Equipment: - Main and counter spindle - 2 Y-axes - Driven tools - Multi-channel control - Chip conveyor - Bar feeder Travel paths: - X-axis: approx. 260 mm - Y-axis: approx. ±50 mm - Z-axis: approx. 800 mm Ppedjzaktmopfx Aprst Spindle speeds & power: - Main spindle: up to approx. 5,000 rpm, approx. 15–18 kW - Counter spindle: up to approx. 5,000 rpm, approx. 11–15 kW - Driven tools: up to approx. 6,000 rpm, approx. 3–5 kW The machine is fully operational both mechanically and electrically. Complete technical documentation is available. The machine can be inspected under power by prior appointment. Technical data and information subject to change, error, and prior sale.

Condition: good (used), Year of construction: 2011, 1 x CNC turning center Chiah Chyun CB-32 M Year of manufacture: 2011 Podpfszakrisx Aprjpt with chip conveyor Technical data can be found in the document. A total of 3 machines are available. The machines can still be inspected in operation and under power for approximately 3 weeks.

Condition: used, CNC Lathe TAKISAWA TMM 250 M1 CNC Model Fanuc Main spindle nose ASA 8 Main spindle power 22 Kw Main spindle bar passage 75 mm Swinnable diameter 350 mm Swinnable length 800 mm Main spindle rpm 4000 Number of Tool Turrets 2 Tool positions first turret 15 Motored positions first turret 15 X axis travel first turret 265 mm Y axis travel first turret + - 50 mm Z axis travel first turret 760 mm Tool positions second turret 15 Motored positions second turret 15 X axis travel second turret 228 mm Z axis travel second turret 760 mm Rapid traverses X Y Z 30 m/min High pressure coolant yes Counterspindle yes Nose spindle ASA 6 Counterspindle rpm 4000 Counter spindle power 18.5 Kw Counter spindle Z travel 800 mm The machine is visible operating in our warehouse in Gussago BS. Mimu machine tools Ppedpfozaklpox Aprst

Condition: used, Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Ppjdpfx Apszacc Tjrot Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: good (used), Year of construction: 2006, functionality: fully functional, Technical details turning diameter 660/275 mm turning length 1498 mm control Fanuc/Mori Seiki MSX 701 total power requirement 90 kVA weight of the machine ca. 26,6 t dimensions of the machine ca. 5301 x 2997 x 2788 mm Additional information 9-axis CNC turning and milling centre * Fanuc MSX-701 CNC control * Milling spindle at top (B axis), as full 4th axis, positioning 0.0001 deg. * 40-position tool magazine * 10-position turret at bottom, all positions driven * 2 x 3-jaw quick-change chuck KNCS-N 315/91 * KNOLL high-pressure coolant system, pressure setting 12/25/35/45/55/62 and 72 bar, with maintenance-free rotary filter system * Chip conveyor * Drain system for main spindle chuck (controlled via M function) * Drain system for tool cutting edge (controlled via M function) * Coolant gun incl. accessories * Oil mist extraction * Direct measuring system X1, X2, Y-axis * Bar loader interface * Double foot switch for both spindles * Islands and pocket programming for MAPPS * High-speed fixed cycle for MAPPS * Programm memory extension to 8 MB * Programm restart * 3-stage signal lamp * 512 MB memory card (CF card) Swing diameter over cross slide (tool spindle 1): 750 mm Swing diameter over cross slide (turret 2): 400 mm Max. turning diameter (tool spindle 1): 660 mm Max. turning diameter (turret 2): 275 mm Max. machined workpiece length: 1498 mm Max. bar material: 90 mm Travels: X1 axis (tool spindle): 750 mm Y axis (tool spindle): 420 (+/- 210) mm Z1 axis (tool spindle): 1635 + 100 mm for tool change Ppodezabltspfx Aprot B axis (tool spindle): +/- 120 deg., full B-axis 1 deg. indexed and 0.0001 deg. braked X2 axis (turret): 195 mm Z2 axis (turret): 1525 mm SZ axis (subspindle): 1610 mm Rapid traverse: (X1,Z1) 50 m/min. / (Y,X2,Z2,SZ) 30 m/min. Main and subspindle: Spindle speeds infinitely variable (spindle 1 + 2): 30-3000 rpm. C axis (spindle 1 + 2): 0.001 deg. Main spindle motor: 22/18.5 kW Subspindle motor: 22/18.5 kW Torque (spindle 1 + 2): 1000 Nm Disc turret: Number of tool positions: 10 Speed of driven tools: 6000 rpm. Drive power: 5.5/3.7 kW Milling spindle head: Tool holder: HSK A63 Max. speed: 12,000 rpm Drive power: 18.5/11 kW Torque: 120/44 Nm Tool changer: 40-stations Tool diameter 70/140 mm Tool length 400 mm Tool weight 8/10 kg Total power requirement 90 kVA Main dimensions Length x width x height 5301 x 2997 x 2788 mm Machine weight 26.6 t Accessories: Measuring arm (picture) tool measurement in machine Tool holder + box, reduction sleeves, driven tools Clamping jaws package Collets package

Condition: used, Year of construction: 2014, machine/vehicle number: S6F143651, FANUC 31iB control system, power 29 kW, main and counter spindle, spindle speed max. 5,000/7,000 rpm, travel distances X/Z = 260/610 mm, 12-position tool changer with powered tools (VDI 40), max. turning diameter/turning length = 320/550 mm, part ejector, operating hours approx. 400 hours. Pedpfx Apsy U R Nxjropt

Condition: used, Year of construction: 2016, machine/vehicle number: S4E163551, Control system: FANUC Oi-TD, remote control, single spindle, maximum speed 6,300 rpm, power 13 kW, 12-position tool changer with powered tools (VDI 25), chip conveyor, maximum turning length/diameter = 670/220 mm, maximum bore diameter 45 mm, control cabinet: RITTAL, stated B/h = 16,500. Podpfx Apsy U R Rierjpt

Condition: used, Year of construction: 2011, machine/vehicle number: S4BZ4751, FANUC 18i-TB control, twin spindle, travel ranges X/Y/Z = 160/+40/-30/510 mm, 12-position tool turret with driven tools VDI 25, maximum speed 6,000 rpm, chip conveyor, remote control, front-end bar feeder TOP etl 8-50, year of manufacture 2011, serial number 92230, L = 5,000 mm, control cabinet RITTAL, remote control. Podpfx Asy U R Rpeprept

Condition: like new (used), Year of construction: 2018, Swing over bed 641mm, 229mm max. machining diameter, 356mm cutting length, 6000rpm spindle, Pedpfey U Hpbex Aprept 44mm bar capacity, 12 station turret, 11.2kW spindle motor, +/-50mm Y axis, C axis & Milling, HAAS control, 3 jaw chuck, coolant, Tool Setter,

Condition: used, Year of construction: 2012, operating hours: 20,000 h, machine/vehicle number: IntNr231536, High-end CNC turning centre with 2 turrets, 2 Y-axes and IRCO bar feeder Control: SIEMENS 840D SolutionLine with ShopTurn interface Year of manufacture: 2012 Spindle hours: 20,000 Ppedpfxoy U Hkfs Apret Maximum turning diameter: approx. 390 mm Maximum turning length: 1,250 mm Bar capacity: 76 mm (standard) X-axis travel: 300 mm Z-axis travel: 1,250 mm Y-axis travel: +/- 60 mm (both turrets) Spindle specifications: Speed: up to 5,000 rpm Drive power: 34 kW (40% duty cycle) Torque: up to 380 Nm 4-axis kinematics 2 x 12-position turrets (all stations suitable for driven tools) Speed up to 6,000 rpm, power 11.3 kW Gear cutting software, including specialised tool holders for gear hobbing/cutting. IRCO MUK short bar loader Hinged belt chip conveyor 20 bar high-pressure coolant system with paper belt filter Subject to prior sale. Specifications subject to change and errors excepted!

Condition: good (used), Year of construction: 2020, CNC turning and milling center Machine type: Mori Seiki NLX 3000 Y / 3000 Control system: CELOS with MAPPS V Year of manufacture: 2020 TECHNICAL DATA: Max. turning length: 3,123 mm Turning diameter: 310 mm Max. turning diameter over bed: 420 mm Bar diameter: 90 mm Chuck: 300 mm C-axis Max. spindle speed: 3,000 rpm Drive power: 22 / 18.5 kW Travel distances: X-axis: 280 mm Y-axis: 60 +/- mm Z-axis: 3,170 mm Rapid traverse: (X/Y/Z): 30 / 10 / 30 m/min. Number of turrets: 1 Tool holder: Tool positions: 12 Powered tools: 12 Spindle speed of powered tools: 6,000 rpm Tailstock: 3,164 mm Connection value: 54 kW Machine weight: 14,200 kg Space requirement (L x W x H): 8.3 x 3.5 x 2.41 m Equipment features: Chip conveyor Coolant pump: 5 bar 3-jaw chuck mm Psdpfx Ajy U E Nyeprspt Chip flushing gun Automatic doors Steady rest

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, bar passage: 65 mm, overall weight: 9,500 kg, 3 TURRETS – Y-AXIS IN THE UPPER TURRET – 2 X-AXES – LNS SERVO 3 SHORT BAR FEEDER – EXCELLENT TOOLING – FANUC 310 CONTROL – IMMEDIATELY AVAILABLE Pjdpfx Aey Uxx Ijprspt

Condition: good (used), Year of construction: 2015, HAAS ST 30 SSY Turning-milling center Year of manufacture: 2015 Control system: HAAS ONLY approx. 9,950 operating hours (as of March 25, 2026) Equipment: Turning-milling center with C/Y axis Travel distances of max. 406 mm x 584 mm Swinging diameter of 806 mm Y-axis travel ±50.8 mm Vector drive (22.4 kW) A2-6 spindle, 4,500 rpm 10-inch chuck (254 mm) Hybrid turret with 24 tool stations (12 VDI/12 BOT) Driven tools with higher torque with C-axis 15" LCD color screen Memory lock key switch Spindle orientation USB port Synchronized thread drilling Automatic tool pre-setting system Hinged belt chip conveyor Parts catcher Programmable hydraulic steady rest Ethernet interface "Visual Quick Code" programming system VectorCam Turning Special Haas Edition HAAS bar feeder Ø 76 mm Hainbuch collet chuck combo, pull-stud size 80 Chip guard for GR80 Vario Quick - Standard clamping system, size 80 Included in delivery: BOT/VDI – holders / turret Turning tools Hainbuch collets Collets for tools Driven tools Wing-door tool cabinet Ppodey Uwt Ropfx Apret Machine setting elements Chip cart Operating manual/documentation Machine parameters on USB stick Technical data, manufacturer's brochure, and machine layout – see PDF. All technical specifications, images and content are non-binding and without guarantee. Subject to change and errors. All other accessories shown in the pictures and video are not included in the scope of delivery and are therefore not part of this sale. The scope of delivery only includes the accessories that are explicitly listed here, in the order confirmation and invoice. FCA (Free Carrier, Truck) D-32457 Porta Westfalica Excluding packaging Delivery time: immediately Subject to prior sale / Payment immediately upon completion of purchase

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, For sale is a high-quality CNC turning and milling center, a Spinner TC77-SMCY with Siemens Sinumerik control. The machine is equipped with: Y-axis C-axis Counter spindle Powered tools Chip conveyor Extensive tool package Technical data: Bar diameter 77 mm 12-position VDI50 turret Ppsdjy Uwmwopfx Aprjt Main spindle ASA 8 Counter spindle ASA 6 Speed up to 4000 rpm Turning diameter approx. 500–690 mm Turning length approx. 800–900 mm Y-axis ±60 mm Main and counter spindle Weight approx. 6000–7000 kg

Condition: ready for operation (used), Year of construction: 2005, operating hours: 53,201 h, spindle speed (max.): 4,000 rpm, travel distance X-axis: 550 mm, travel distance Y-axis: 220 mm, travel distance Z-axis: 1,585 mm, controller manufacturer: SIEMENS, tool weight: 10,000 g, number of axes: 7, This 7-axis Gildemeister GMX 400 Linear was manufactured in 2005. It features a maximum turning diameter of 640 mm and a turning length of 1585 mm. The machine is equipped with a Siemens Sinumerik 840D Powerline CNC control and offers rapid traverse speeds of 40 m/min in the X-axis. If you are looking to get high-quality turning and milling capabilities, consider the Gildemeister GMX 400 Linear turn-mill centre we have for sale. Contact us for further details. • B-axis swivel range: ±120° • C-axis resolution: 0.001° • Rapid traverse (X/Y/Z): 40 / 24 / 60 m/min • Maximum turning diameter: 640 mm • Standard turning diameter: approx. 400 mm • Maximum turning length: 1585 mm • Bar capacity: approx. 90–92 mm • Chuck diameter: 250 mm • Counter spindle speed: 4000 rpm • Maximum torque: approx. 600–730 Nm • Milling spindle: Integrated motor spindle (ISM) with B-axis • Milling spindle speed: 12,000 rpm • Milling spindle power: 13.2 / 22 kW • Milling spindle max. torque: approx. 100 Nm • Turret: 12-position driven turret • Tool shank: 40 mm, DIN 69880 • Tool length limits: 200–350 mm • Maximum tool diameter: 80–140 mm • Maximum tool projection: 60–70 mm Pedpoy Uvxxefx Apropt • Connected load: 100 kVA • Additional notes: Linear drive technology; Made in Germany; Machine under power and available for inspection Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: used, Year of construction: 2016, 2016 CMZ TA-20TM Fanuc controlled, driven tool C-Axis CNC lathe with Ballscrew driven tailstock, direct drive 22KW main spindle, direct drive 15KW driven tool motor , parts catcher, swarf conveyor, tool arm and suite of driven and static tool holder. Super condition! Specification Control Type: Faniuc Control Model 32i Max. Turning Diameter 400mm Max. Turning Length 640mm Swing Over Bed 685 mm Max Turning Dia: 510mm Spindle Bore: 73mm Bar Capacity 66 mm Spindle Nose BoreA2-6 Psdpfsy Ukf Tsx Aprspt Spindle Speed 4,000 RPM Main Spindle Power 22KW Driven Tool Motor Power 15KW Turret Positions 12 Driven Station: 12 Driven Tool Speed 12,000 RPM Machine Dimensions: 3500 X 1950 X 190mm Machine Weight Approx. 5,500 kg More Photo's to follow once received Control Type: Faniuc Max Turning Dia: 510mm Spindle Bore: 73mm Driven Station: 12 Bar capacity: 66mm

Condition: good (used), Year of construction: 2005, functionality: fully functional, The machine was serviced annually under a maintenance contract with Okuma. Okuma Mac Turn 550 W / 9-axis turning-milling center Year of manufacture: 2005, Control system: OSP-E 100 L / Expansion Kit “M” Kit One Touch IGF Milling spindle carriage X/Y/Z/B, Counter spindle W-axis, Main spindle with C-axis, Counter spindle with C-axis, Turret carriage below X/Z axis, Max. turning diameter: 720 mm, Turning length: 2,000 mm, Distance between tailstock center and spindle center: 2,505 mm, Y-axis: 250 mm / +/- 125 mm, Main spindle speed: up to 3,500 rpm, Spindle power: 30 kW Turret below: 12-station without driven tool stations, Nco Dmnbyeyt Nvtoujt Turret below with steady rest, therefore only 9 stations instead of 12, Self-centering steady rest: 35 - 240 mm, Milling spindle: infinitely variable B-axis 0.001°, Magazine: 80-station, Mount: HSK 100, New Forkhart three-jaw chuck Ø 400 mm, value 12,000 €, Counter spindle without chuck, currently with arbors / delivery without arbors, Ppsdpfxoy Uhfkj Aprst Enlarged main spindle: 110 mm Ø 150/110 mm, Spindle nose: Size 11, 2-stage clamping pressure, Counter spindle as a hollow shaft motor, speed up to 3,800 rpm, Ethernet LAN interface, Renishaw in-process measurement, Additional measuring system for Y-axis, Tool length: 450 mm instead of 350 mm, Door automation for both doors, Chip conveyor, Gravity belt filter with clean tank 900 liters, Supply pump, frequency-controlled up to 20 bar, The machine was serviced annually under a maintenance contract with Okuma. In 2023, the cable carrier for the W-axis, including all hoses, was replaced. In October 2024, the linear guides X/Y/Z were replaced. Work performed by Okuma. Machine cleaned. Sheets and covers removed. 8th axis removed. Travel stand removed and lifted out of the machine. ATC removed and lifted out of the machine. All linear guides removed. Mounting surfaces of the Z-axis cleaned. New linear guide for Z-axis including shoes installed and tightened with the specified torques. New ball screw for Z-axis including bearing mounted and installed. Base plate of the travel stand installed and tightened with the specified torques or screwed onto the shoes. Lubrication lines connected. ATC including attachments installed and connected. New linear guides YA and XA installed and tightened with the corresponding torques. New ball screw YA including bearing installed. Travel stand installed and lubrication lines connected. Base plate XA placed and aligned. 8th axis placed and aligned. H1 turret installed - Install drive motor for the 8th axis - Assembly of 8th axis + new H1 and adjust geometry - Functional test of 8th axis and H1 - Run-in program for B-axis approx. 12 hours, then drain old oil from the 8th axis - Run-in program for H1 and create defect report for OEG - Install left door, adjust various sheets - Install chuck - Adjust zero points - Check tool change

Condition: good (used), Year of construction: 2004, functionality: fully functional, CNC turning and milling center with 9 CNC axes, Okuma MacTurn 350 W, Year of manufacture 2004, OSP-E 100L, Additional magazine, Magazine with 80 tool positions, Main spindle with C axis, Counter spindle with C axis, Y-axis slide above / milling spindle, HSK 63 tool holder, Infinitely adjustable B-axis as milling spindle, Distance between centers 1500 mm, Spindle bore 80 mm, Max. turning diameter 550 mm, Turning diameter 350 mm, Lower turret with 12 tool positions and powered tools, Interlite compact filter system 900 l, Extraction system, Spindle running time approximately 18,300 hours, Chip conveyor, Tool changer gripper arm completely renewed, High-pressure cooling, WZG measuring arm, Ppsdpfx Apjy Uhccjrot Tool changer overhauled, Main spindle Kitagawa B - 210, Counter spindle Kitagawa B - 208.

Condition: excellent (used), Year of construction: 2018, operating hours: 10,035 h, functionality: fully functional, Emco Hyperturn 45 Machine with few operating hours and in very good condition! Only small parts were manufactured; it was never used for truly heavy work. The machine has a very extensive range of equipment: - Spindle bore 46 mm - Y-axis in the upper turret - Turret VDI 25 with driven tool stations - Part ejector and part collection tray - Part conveyor belt - Higher coolant pressure (14 bar) - 2x Hainbuch collet chuck Mini SK 52 - Tool measurement - Emco bar feeder - Chip conveyor - LED status indicator Software: Siemens 840D-sl with Shopturn + Tool breakage and wear monitoring + 4-axis turning/balance cutting + Shopturn expansion package (residual material detection) + Energy management / automatic shutdown Ppedpfxsy Udv Ss Apret The machine is fully functional and is still in production; inspection is possible at any time. The machine is available immediately. All scrapers and wiper blades are in very good condition! The control cabinet is very clean, with no oil mist deposits.

Condition: good (used), functionality: fully functional, !!!ON-SITE SALE, D-74219 MÖCKMÜHL!!! 2-axis CNC turning machine NAKAMURA SUPERTURN ST-2 with automatic tailstock Ppjdpfx Asy Ucideprst Control system: Fanuc Machine is fully functional.

Condition: new, Original accessory case for DMG CTX machines, from Horn. Podpfxoy Ucbye Apropt

Condition: new, Accessory case for DMG CTX beta/gamma TC. Pjdpfxey Ub Sds Aprspt

Condition: used, Year of construction: 2010, turning diameter 700 mm turning length 1250 mm control Siemens 840 G Ergoline spindle passage 104 mm spindle speed: 4000 spindle motor 35/45 kW max. torque on the spindle 600/700 Nm Spindlespeed subspindle 4000 U/min milling head -swivable ° turning speed range - milling 00 U/min tool taper Capto C6 tool magazin: 36 y-axis +/- 200 mm mm weight of the machine ca. 18,5 t Used CNC- Lathe with sub- spindle and milling head - milling head full axis + 1° clamping - chipconveyor - aircondition for elextric box - new milling spindle in 2025 - absolute scale X/Y/Z1 axis Pjdpfxjy T R Rmo Apropt - Shop Mill dialig programming - 8/20 bar coolant programmable - band filter system - Bar package (Partscatcher, prepared for ba magazin) Machine sold without jaws.

Condition: ready for operation (used), Year of construction: 2020, operating hours: 19,990 h, functionality: fully functional, turning length: 2,100 mm, turning diameter: 560 mm, spindle motor power: 37,000 W, spindle speed (max.): 2,000 rpm, spindle bore: 117 mm, travel distance X-axis: 320 mm, travel distance Z-axis: 2,200 mm, rapid traverse X-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, overall weight: 11,000 kg, Hyundai WIA L400LMC – Heavy-Duty Long-Bed Turning Center Ppsdpfx Apoy T Ixboret The Hyundai WIA L400LMC is a robust and powerful turning center designed for machining large and heavy workpieces with high stability and precision. With its high torque spindle, large machining capacity, and integrated automation-ready features, this machine is ideal for demanding industrial applications. With box guide design – the most rigid solution used in turning centers. Key technical specifications: • Main spindle power: 37 kW • Maximum torque: 3,073 Nm • Maximum spindle speed: 2,000 rpm • Maximum turning length: 2,100 mm • Chuck size: 15” • Maximum bar capacity through spindle: Ø117 mm Machine configuration: • 12-position turret with BMT75 interface • C-axis for advanced machining operations • High-pressure through-tool coolant system – 15 bar • Bar feeder interface • Automatic Q-SETTER tool measuring system • FANUC control system • Hydraulic steady rest, programmable via M-code • Large programmable tailstock, controlled via M-code • Coolant spray gun • Wide machine door opening (>2000 mm) for easy loading of large parts • Oil mist / emulsion extraction system Additional equipment included: • 4 driven tools included • SMW-Autoblok SLUB-5-ZS-050310 self-centering steady rest o Monitoring of open/closed position o Clamping range: 50–310 mm The machine was commissioned in 2020 and has been in regular industrial use. The equipment remains in good working condition and offers a powerful solution for heavy-duty turning applications requiring high torque and long part capacity.
