Bendingroll Italy srl

Condition: good (used), Year of construction: 1990, Functionality: fully functional, machine/vehicle number: 4ROLL, sheet thickness steel (max.): 45 mm, sheet thickness aluminum (max.): 45 mm, sheet thickness copper (max.): 45 mm, sheet thickness (max.): 50 mm, roller (top) diameter: 470 mm, roller diameter: 470 mm, overall weight: 43,000 kg, total length: 7,700 mm, total height: 2,470 mm, total width: 2,410 mm, roller (bottom) diameter: 470 mm, bending length: 3,000 mm, type of input current: three-phase, working length: 3,050 mm, roller length: 3,050 mm, sheet width: 3,000 mm, working width: 3,050 mm, side roll diameter: 420 mm, working height: 1,800 mm, type of motor: three-phase motor, power: 37 kW (50.31 HP), input voltage: 380 V, Equipment: documentation/manual, emergency stop, PLATE BENDING MACHINE FACCIN - 4 ROLL HYDRAULIC 3000 X 40 MM MODEL 4HCI3-35/30 YEAR 1990 PLATE BENDING ROLL LINEAR GUIDEWAYS DOUBLE PINCH PRE-BENDING Iaslhccjwb Scmeqljr Machine in good working condition Bending capacity -Plate width : 3000 mm -Rolling plate thickness 40 mm - Prebend thickness 35 mm Rolls dimensions: -Useful length 3050 mm -central rolls upper/lower 470 mm -side rolls left/right 420 mm • Hardening of the 4 rolls high strength surface • 3 rolls driven powered with gear unit with hydraulic motor • Conical bending attachment side rolls tiltable to form cones, contrast pad roller type. • Opening front hydraulic drop-end to unload the closed shell. • Variable speed working roll bending rotation hydraulic speed fast/slow. • Console electric on wheels with centralized commands joysticks and 3 digital readout. • Digital readouts of the rolls position bending and pre-bending repeatability. • Hydraulic tank capacity oil 350 liters – power electric 37 Kw voltage 380 /50 • Dimension 7700 x2410 x H 2470 mm - weight 43000kgs

Condition: used, Year of construction: 2002, Functionality: fully functional, motor voltage: 380 V, shaft diameter: 80 mm, Equipment: documentation/manual, Limpet coil roller hydraulic to form half round pipe from flat metal strip and bending into wanted radius with spiral continuous. -Shafts output size 80 mm -Interchangeable set of rollers on the shafts for the different size of pipe -Coil holder for the reel metal strip with guide-way bench uncoiling and alignment the steel strip to the rolling machine -Pinching lower central roll adjustable to form the half pipe Isljwb A Rnshccqloar -Side roll with digital position readout to determine the bending diameter of the coil -hydraulic arm in 3 directions to set the pitch of the coil roll -Upper vertical support hydraulic operated to hold in position the formed diameter and collect the coils -Control panel electric with push buttons with digital position readouts for the coil length, the bending radius and the forming load. -Service manuals and operation books along with the machine.

Condition: like new (used), Year of construction: 2025, Functionality: fully functional, machine/vehicle number: AK335 PLATE ROLL, sheet thickness steel (max.): 35 mm, sheet thickness aluminum (max.): 45 mm, sheet thickness copper (max.): 45 mm, sheet thickness (max.): 35 mm, roller (top) diameter: 410 mm, roller diameter: 500 mm, overall weight: 15,000 kg, total length: 5,300 mm, total height: 2,100 mm, total width: 2,050 mm, roller (bottom) diameter: 380 mm, bending length: 3,000 mm, type of input current: three-phase, working length: 3,000 mm, roller length: 3,100 mm, sheet width: 3,000 mm, working width: 3,000 mm, side roll diameter: 380 mm, working height: 1,100 mm, warranty duration: 12 months, cone diameter: 600 mm, cone mount: 600 mm, type of motor: three-phase motor, power: 22.06 kW (29.99 HP), Equipment: documentation/manual, emergency stop, 3roll 3000x35 mm MG MODEL AK335 plate bending machine Pinch pyramid dual pre-bend Surface width 3100 mm -Top roll 410 mm -Side rolls 380 mm Capacity rolling -plate width 3000 mm -plate thickness 35 mm -pre-bend 26 mm Iajlhcewailcscqlor diameter bending minimum ID 500 mm Capacity increase for plate width 1500x45 mm Configuration -hardened surface high strength of the rollers -Hydraulic power rotation 3 rollers driven with planetary gear unit each roll Synchronized hydraulic speed between the 3 rollers -Cone forming plate rolling -Welded plates calibration rolling system -Electric panel of control with commands joysticks for all motion of the machine -Rollers position digital reading with memorize and repeat automatic, NC programmable. -Safety installations with emergency stop -Manuals of instruction DIMENSION 5300X2050XH2100 MM WEIGHT 15 TON POWER INSTALLED 30 Hp

Condition: excellent (used), Functionality: fully functional, machine/vehicle number: 4RI PLATE ROLL DUAL PREPINCH, sheet thickness steel (max.): 12 mm, sheet thickness aluminum (max.): 12 mm, sheet thickness copper (max.): 12 mm, sheet thickness brass (max.): 12 mm, sheet thickness (max.): 12 mm, roller (top) diameter: 240 mm, roller diameter: 240 mm, overall weight: 6,500 kg, total length: 4,000 mm, total height: 1,600 mm, total width: 1,500 mm, roller (bottom) diameter: 240 mm, bending length: 2,000 mm, type of input current: three-phase, working length: 2,000 mm, roller length: 2,050 mm, sheet width: 2,000 mm, working width: 2,000 mm, side roll diameter: 220 mm, working height: 800 mm, cone diameter: 350 mm, type of motor: three-phase motor, power: 10 kW (13.60 HP), Equipment: documentation/manual, emergency stop, Plate bending machine 4-roll 2000x12mm Bending capacity with pre-pinch plate width 2000 mm thickness 12 mm pre-bend 10 mm minimum bending rolling dia. Ø 350mm --- Max width on the rolls 2050 mm top roll size 240 mm lower rolls 240 mm / 220 mm Iolhccqsv Nq Uxsljar Power electric 10Hp voltage 380/50Vac --- Installed configuration Hardened rolls, very high surface resistance Driven central rolls rotation hydraulic with gear unit Pre-pinch pressure adjustable for best pre-bend Cone plate rolling hydraulic with contrast pad Drop-end open front hydraulic for unload Digital readout display position of rollers Safety and emergency systems installed Manuals and schematics originals Weight of the machine 6 ton Dimension 4 x 1,6 x H 1,5 mtr -weight 6,5 Ton

Condition: excellent (used), Year of construction: 2001, Functionality: fully functional, machine/vehicle number: 2050 x 6 mm, sheet thickness steel (max.): 6 mm, sheet thickness aluminum (max.): 6 mm, sheet thickness copper (max.): 6 mm, sheet thickness brass (max.): 6 mm, sheet thickness (max.): 6 mm, roller (top) diameter: 170 mm, roller diameter: 170 mm, overall weight: 1,600 kg, total length: 3,000 mm, total height: 1,000 mm, total width: 1,000 mm, roller (bottom) diameter: 160 mm, bending length: 2,000 mm, type of input current: three-phase, working length: 2,000 mm, roller length: 2,050 mm, sheet width: 2,000 mm, working width: 2,000 mm, side roll diameter: 150 mm, working height: 800 mm, Equipment: documentation/manual, emergency stop, PLATE ROLL 2000x6 mm INITIAL PINCH Rolls length 2050 mm -Top roll 170 mm -Side rolls 150 mm -Power electric 5,5 Hp Capacity -plate width 2000 mm -plate thickness 6 mm with prepinch Configuration on the machine -Rollers surface hardened high strength -Central rolls driven electric rotation on gearunit Iaolhccjv Nq S Reqler -side roll electric run with prepinch Pinch roll position with handwheel Front open manual drop-end -Readout gauge of side bending roll -Footpedal electric rollers rotation back/forth -Joystick electric control of side roll -Safety installations with emergency stop. -Machine in perfect conditions

Condition: used, Year of construction: 1980, Functionality: fully functional, machine/vehicle number: plate roll 2500x45 mm, sheet thickness steel (max.): 45 mm, sheet thickness (max.): 50 mm, roller (top) diameter: 500 mm, roller diameter: 500 mm, overall weight: 40,000 kg, roller (bottom) diameter: 500 mm, bending length: 2,500 mm, type of input current: three-phase, working length: 2,500 mm, roller length: 2,550 mm, Equipment: emergency stop, 3 roll mechanical plate bending machine 2500 x 45 mm brand Ferro Italy model CIT-23 Capacity: Plate width 2500 mm Plate thickness 45 mm Prebend 38 mm Diameter of bending 2000 mm Capacity 2500 x 35 mm for diameter 750 mm mechanical plate roll with pre-pinching upper roller size 500 mm side rollers size 500 mm left/right side independent vertical pinching prebend power installed to run each of the side roller 40 Hp electric motor rollers rotation centralized gear unit powered electric Hp 45 dual speed rotation fast/slow voltage 3 phase 380/50 Machine weight 40 Ton open front drop-end hydraulic to unload the closed shells Ijlhccsv Eyrroqljar top roll hydraulic tilt-up wide opening to unload the formed plate console with push buttons electric to control the machine position readout of bending rollers for repeatability of rolling works emergency stop buttons and safety shut down system all around the machine Electric power units with all wiring new rebuilt. Overhauled new bushings and bearing fully controlled and replaced

Condition: good (used), Year of construction: 1992, Functionality: fully functional, machine/vehicle number: MCO2522, sheet thickness steel (max.): 10 mm, sheet thickness aluminum (max.): 10 mm, sheet thickness copper (max.): 10 mm, sheet thickness (max.): 10 mm, roller (top) diameter: 220 mm, roller diameter: 200 mm, overall weight: 4,500 kg, total length: 4,000 mm, total height: 1,200 mm, total width: 1,000 mm, roller (bottom) diameter: 200 mm, bending length: 2,500 mm, type of input current: three-phase, working length: 2,500 mm, roller length: 2,550 mm, sheet width: 2,500 mm, working width: 2,500 mm, side roll diameter: 200 mm, working height: 700 mm, type of motor: three-phase motor, power: 4.05 kW (5.51 HP), Equipment: documentation/manual, emergency stop, 3roll 2500x10 mm DAVI MODEL MCO3022 plate bending machine USED PLATE ROLL YEAR 1992 Iaelhjv Eantjccqler Surface width 2500 mm -Top roll 220 mm -Side rolls 200 mm -Power electric 5,5 Hp -Weight 4,5 ton Capacity -plate width 2500 mm -plate thickness 10 mm -pre-bend 8 mm Configuration complete for use: -hardened rollers high strength -All driven hydraulic 3 rolls rotation dragging synchronized rolling speed hydraulic -re-rolling system for seam welded shells -EXTENDED SHAFTS TO TAKE ADD-ON ROLLERS FOR PROFILE BENDING -console centralized with hydraulic commands -Digital position readout to repeat bending with accuracy -Safety installations with emergency stop. -Manuals of instruction Machine in good conditions

Condition: excellent (used), Year of construction: 1999, Functionality: fully functional, machine/vehicle number: MG07100H, sheet thickness steel (max.): 100 mm, sheet thickness aluminum (max.): 100 mm, sheet thickness (max.): 100 mm, roller (top) diameter: 480 mm, roller diameter: 600 mm, overall weight: 20,000 kg, total length: 3,600 mm, total height: 2,760 mm, total width: 2,500 mm, roller (bottom) diameter: 450 mm, bending length: 700 mm, type of input current: three-phase, working length: 700 mm, roller length: 750 mm, sheet width: 700 mm, working width: 700 mm, side roll diameter: 450 mm, working height: 1,800 mm, cone diameter: 600 mm, type of motor: three-phase motor, power: 36.77 kW (49.99 HP), Equipment: documentation/manual, emergency stop, 3roll plate bending machine year 1999 make MGsrl model 750x100 mm Thickness bending capacity 100 mm Width max 750 mm planetary hydraulic roll bending machine with pre-pinching Top roll size 480 mm Side rolls size 450 mm Voltage 380/50 Vac, 50 Hp motor electric power installed on hydraulic unit Configuration: hardened surface of the 3 rolls 3 rolls power driven planetary gearbox and hydraulic motor each roll independent Calibration system for the re-rolling of welded shells. Set of rings to clamp on rolls for align and guide the plate sheet Console electric on wheels with centralized commands joysticks and digital readout. Opening front side hydraulic drop-end to unload closed shells. Iasljv A Iwqjhccqlsr Variable speed working slow/fast Emergency stop and safety systems installed in compliance with regulation. Dimension 3600x2500 mm v height 2760 mm Weight 20 Ton Machine in good working condition , controlled and tested.

Condition: excellent (used), Year of construction: 2015, Functionality: fully functional, machine/vehicle number: AK316, sheet thickness steel (max.): 16 mm, sheet thickness aluminum (max.): 16 mm, sheet thickness copper (max.): 16 mm, sheet thickness (max.): 20 mm, roller (top) diameter: 300 mm, roller diameter: 350 mm, overall weight: 8,000 kg, total length: 4,500 mm, total height: 1,500 mm, total width: 1,300 mm, roller (bottom) diameter: 270 mm, bending length: 3,000 mm, type of input current: three-phase, working length: 3,100 mm, roller length: 3,100 mm, Equipment: documentation/manual, emergency stop, 3roll 3000x16 mm MG MODEL AK316 plate bending machine Surface width 3100 mm -Top roll 300 mm Iajlov Agkpjhccqlsr -Side rolls 270 mm -Power electric 10 Hp -Weight 8 ton Capacity -plate width 3000 mm -plate thickness 16 mm -pre-bend 12 mm Rolling diameter from 350 mm and above Configuration complete for use: -the 3 rolls hardened high surface strength -the 3 rolls driven hydraulic with axial planetary gear individual each roll synchronized rolling speed hydraulic automatic balance -conical bending attachment for cone bending -re-rolling system for seam welded shells -console centralized with hydraulic commands -Digital position readout to repeat bending with accuracy -Safety installations with emergency stop. -Manuals of instruction DIMENSION 4500X1300XH1500 MM Machine in very good conditions

Condition: as good as new (ex-display), Year of construction: 2024, Functionality: fully functional, machine/vehicle number: 3roll 3000x25 mm, sheet thickness steel (max.): 25 mm, sheet thickness aluminum (max.): 25 mm, sheet thickness copper (max.): 25 mm, roller diameter: 350 mm, overall weight: 9,000 kg, bending length: 3,100 mm, type of input current: three-phase, working length: 3,000 mm, roller length: 3,100 mm, Equipment: documentation/manual, emergency stop, 3ROLL MODEL 3100x25mm -top roll mm. 360 -Power electric 20 Hp Capacity -plate width 3000 mm -plate thickness 25 mm -pre-bend 16 mm Small bending diameter 450 mm -the 3 rolls hardened high surface strength -the 3 rolls driven hydraulic with axial planetary gear individual each roll synchronized rolling speed hydraulic automatic balance -conical bending attachment for cone bending -re-rolling system for seam welded shells Iaslhjvtykqsccqljr -console centralized with electric commands -Digital position readout programmable to repeat bending -Safety installations for emergency stop. -Manuals of instruction Available tooling can be added NC programmable 3 axis controller - network connect to comply Industry 5.0 Lateral hydraulic arm support to hold in place thin plates formed into large diameters Upper central support 2 ton capacity to hold the shell formed hydraulic run up to ID 3200 mm

Condition: as good as new (ex-display), Year of construction: 2024, Functionality: fully functional, machine/vehicle number: 3ROLL3000X50MM, sheet thickness steel (max.): 50 mm, roller (top) diameter: 500 mm, roller diameter: 500 mm, overall weight: 26,000 kg, roller (bottom) diameter: 460 mm, bending length: 3,000 mm, type of input current: three-phase, working length: 3,000 mm, roller length: 3,100 mm, Equipment: documentation/manual, emergency stop, model 3 roll planetary with pre-pinch 3000x50 mm upper roll size 500 mm CAPACITY plate width 3000 mm plate thickness 50 mm prebending 36 mm diameter rolling 2200 mm performance on plate quality 355 MPa ---- reducing plate width 2000 mm capacity thickness 55 mm --- minimum diameter of rolling 600 mm all the accessories installed Iolevr S S Rohccqloar hardened rolls conical attachment digital position readout power installed 50 Hp weight of the machine 26Ton

Condition: good (used), Year of construction: 1993, Functionality: fully functional, machine/vehicle number: HCU3000, sheet thickness steel (max.): 2 mm, sheet thickness aluminum (max.): 3 mm, sheet thickness copper (max.): 3 mm, sheet thickness brass (max.): 3 mm, sheet thickness (max.): 3 mm, roller (top) diameter: 100 mm, overall weight: 5,000 kg, total length: 4,500 mm, total height: 1,600 mm, total width: 1,000 mm, roller (bottom) diameter: 380 mm, bending length: 3,000 mm, type of input current: three-phase, working length: 3,000 mm, roller length: 3,000 mm, Equipment: documentation/manual, emergency stop, Plate rolling machine one-pass full rolling with rubber coated roll 2-roll pinch pre-bend system -Plate sheet width max. 3000 mm Ielhccqjvr S D Hjlear -Plate thickness max 2 mm depending on the material hardness -fully hydraulic operated with power unit self enclosed - 9 Kw electric power 400Vac/50 Top shaft size 110 mm -Lower roll size 380 mm urethane coated rubber -Hydraulic front opening for the unloading of closed shells. -Upper beam with adjustable pre-load to compensate the deflection of the top roll under load. -Console electric manual/automatic work sequence with digital readout. - ADDITIONAL EQUIPMENT INSTALLED WITH THE MACHINE -plate loader automatic - -unloading cradle system to receive the rolled plate -complete rubber coating to protect the plate surface from scratches.

Condition: ready for operation (used), Year of construction: 1985, Functionality: fully functional, machine/vehicle number: 3ROLL 4000 X 6 MM, sheet thickness steel (max.): 6 mm, sheet thickness aluminum (max.): 6 mm, sheet thickness copper (max.): 6 mm, roller diameter: 310 mm, overall weight: 11,000 kg, total length: 5,700 mm, total height: 1,700 mm, total width: 1,500 mm, roller (bottom) diameter: 300 mm, bending length: 4,000 mm, type of input current: three-phase, working length: 4,000 mm, roller length: 4,050 mm, Equipment: documentation/manual, emergency stop, 3 ROLL PLATE BENDING MACHINE WITH PREPINCHING Iolsvn I Hcohccqloar capacity plate roll 4000 x 6 mm Plate width 4000 mm Thickness plate rolling 6 mm Pyramid 3 rolls with pre-pinch cylindrical plate rolling Conical plate rolling Rollers surface length 4050 mm Top roll 310 mm Side rolls 300 mm Datasheet power rollers rotation 15 Hp -3 rolls driven rotation with gear unit power bending- prebend side lower rollers 7,5+7,5 Hp Cene bending attachment rollers tiltable for plate conical forming - hardened contrast pad roller type Hydraulic open front drop-end , top-roll tilt-up wide opening for unloading Console electric on wheels, electric push buttons commands remote Digital readouts rollers position repetability safety and emergency installiton machine in working condition dimension 5700 x1500 x H1700 mm weight 11 Ton

Condition: as good as new (ex-display), Year of construction: 2023, Functionality: fully functional, machine/vehicle number: SP1506, number of straightening rollers: 20, sheet width: 1,500 mm, sheet thickness copper (max.): 6 mm, sheet thickness (max.): 6 mm, sheet thickness aluminum (max.): 6 mm, sheet thickness brass (max.): 6 mm, sheet thickness steel (max.): 6 mm, type of input current: three-phase, input voltage: 400 V, plate width: 1,500 mm, straightening roller diameter: 50 mm, roller levelling machine for metal plate flattening and plate sheet parts straightening after cutting or stress relieving. Levelling performance from 0.1 thickness up to 6 mm of plate thickness Sheet plate width up to 1500 mm Multi-rollers levelling system with very accurate and fast adjustable setting upon the metal part thickness for flattening. The machine is provided with Input and output roller tables to load and unload the metal parts straightening Programmable controller touch screen digital readout to memorize and repat the flattening sequence Quick and easy system for rollers change upon the various metal parts straightening requirement Quality machine for precision accurate flattening Iasljvbzyiehccqlsr Machine as new year 2023

Condition: good (used), Year of construction: 2007, Functionality: fully functional, sheet thickness steel (max.): 18 mm, sheet thickness aluminum (max.): 18 mm, sheet thickness copper (max.): 18 mm, sheet thickness brass (max.): 18 mm, sheet thickness (max.): 18 mm, roller (top) diameter: 280 mm, roller diameter: 260 mm, overall weight: 7,000 kg, roller (bottom) diameter: 260 mm, bending length: 2,500 mm, type of input current: three-phase, working length: 2,500 mm, roller length: 2,550 mm, sheet width: 2,500 mm, working width: 2,500 mm, cone diameter: 10 mm, power: 10 kW (13.60 HP), Equipment: documentation/manual, emergency stop, Hydraulic plate bending machine 4-roll capacity 2500x18 mm thickness Iaolou Ecq Iehccqler Brand MG model MH2518 Year 2007 Bending capacity with pre-pinch plate width 2500 mm thickness 18 mm pre-bend 14 mm --- Max width on the rolls 2600 mm top roll size 280 mm lower roll 260 mm minimum bending rolling dia. Ø 330mm Power electric 15Hp voltage 380/50 Vac --- Installed configuration Hardened rolls, high surface resistance Driven central rolls rotation hydraulic with gear unit Rolls parallelism lifetime with torsion bar Pre-pinch pressure adjustable for best pre-bend Conical plate rolling hydraulic with contrast pad Drop-end top roll front hydraulic opening unload Re-rolling calibration system for welded shells Digital readout display position of rollers Safety and emergency systems installed Manuals and schematics originals

Condition: excellent (used), Year of construction: 2012, Functionality: fully functional, machine/vehicle number: MG 3220 model 3roll prebending, sheet thickness steel (max.): 220 mm, sheet thickness aluminum (max.): 220 mm, sheet thickness (max.): 220 mm, roller (top) diameter: 1,130 mm, roller diameter: 1,000 mm, roller (bottom) diameter: 1,000 mm, type of input current: three-phase, working length: 3,100 mm, roller length: 3,100 mm, cone mount: 1,000 mm, type of motor: three-phase motor, power: 330.97 kW (449.99 HP), rotational speed (distance/time): 5,000 mm/min, Equipment: documentation/manual, emergency stop, Hydraulic Plate Bending machine 3 roll 3000x220 mm planetary pinch pyramid model MG3220 3 roll year of make 2012 Capacity : Plate width mm. 3000 Rolling thickness mm. 220 Pre-bend thickness mm. 180 -3 rolls driven hydraulic motorized with axial gear unit on each roll independent -Synchronized hydraulic rotation of the 3 rolls with variable speed. -Planetary design with pre-pinch fully hydraulic -Digital position readouts of the bending rolls -Rolls installed on bearings double crown heavy duty. -Overload safety hydraulic operation protection of the 3 rolls -High pressure hydraulic power pack with multi-pumps oil feed -Power installed total 450 Hp voltage Vac 380/50 -Hydraulic reservoir 2500 liters of oil, Hydraulic oil chiller refrigerator, stand alone cooling system in automatic -Centralized console electric movable on wheels with joysticks and digital readouts -Emergency stop with safety system active and passive , hydraulic and electric. Capacity chart steel plate grade yield 280MPa / 360 MPa width - ID- thickness mm mm mm 3000 5800 220 Iajlhcouwdwaocqljr 3000 4500 205 3000 3400 200 3000 2800 190 3000 2200 180 3000 1600 140 Rolls surface length mm. 3100 Top roll size mm. 1130 Side rolls size mm. 1000 Configuration & accessories installed with the machine: -Hardened surface of the 3 rolls, very high resistance to wear. -Conical plate bending, rolls tiltable to angle of the cone & hardened pad -Centralized operator panel with directional joysticks electric. -Digital position readout of the bending rolls. -Emergency and safety installations, -User manuals and service books

Condition: excellent (used), Year of construction: 2016, Functionality: fully functional, machine/vehicle number: Angle roll 250 mm, shaft diameter: 250 mm, roller diameter: 660 mm, type of input current: three-phase, Equipment: documentation/manual, emergency stop, Profile bending machine hydraulic -output shafts size 250 mm Equipped with traction tooling for H-beam HEB IPE UPN capacity chart see enclosed model AR250 MG brand make year 2016 Configuration -pyramid dual pinch side rolls independent hydraulic -3 rolls driven hydraulic and gear units each shaft. -Rollers size 660 mm adjustable opening to seat and bend the profiles -set of rolls for HEB IPE up to 300 mm - flat bar 200 mm square bar 125 mm , angle roll 200 mm legin / legout -Lateral correctors left/right side hydraulic operated in 3 directions Iaoljtpc Aiehccqler -Traction tool hydraulic operated tensioning for HEB-IPE – UPN bending -Set of heads for tensioning HEB – IPE - UPN beam bending on the hard side -Add-on rollers angle bending & T-section leg-in / leg-out -Control panel console electric joysticks manual operate with Digital readouts -Electric power supply 3phase Vac -60HP hydraulic power unit with high pressure multi pumps 260Bar -Working speed variable slow-fast. -Emergency and safety shut-down devices -CE quality certificate. -Service manuals and operation books along with the machine.

Condition: as good as new (ex-display), Year of construction: 2023, Functionality: fully functional, sheet thickness steel (max.): 45 mm, sheet thickness aluminum (max.): 50 mm, sheet thickness copper (max.): 60 mm, sheet thickness brass (max.): 60 mm, sheet thickness (max.): 40 mm, roller (top) diameter: 450 mm, roller diameter: 410 mm, overall weight: 23,000 kg, total length: 58,000 mm, total height: 25,000 mm, total width: 21,000 mm, roller (bottom) diameter: 410 mm, bending length: 3,000 mm, type of input current: three-phase, working length: 3,100 mm, power: 22.06 kW (29.99 HP), outer diameter: 520 mm, Equipment: documentation/manual, model capacity 3000x40 mm Digital readout Hydraulic 4 roll plate bending machine plate thickness rolling 40 mm pre-bend 32 mm minimum rolling diameter ID 520 mm plate max width on the rollers 3100 mm top roll size 450 mm Power on hydraulic unit 30Hp Vac 400/50 -480/60 Installed configuration Hardened rolls Iolhccjq Uk A Toqlsar Conical plate rolling with digital position bending readout Electric control joysticks roll bending Digital position readout rolling save & repeat Hydraulic rotation central rolls driven parallelism lifetime with torsion bar. ( no electronic ) Pre-pinch load adjustable for pre-bending . Drop-end top roll front open for unloading Re-rolling system for welded shells calibration. Safety and emergency stop Manuals and schematics – CE declaration of quality nr.1 Vertical Support hydraulic run 3 ton capacity to support large shell dia up to 4 meters ( see photo ) ----- Predisposed ready add-on accessories: CNC controller programmable 4 axis automatic plate roll, digital touch screen readout position of the 4 rolls for use manual-semiautomatic-fully automatic programmable with storage memory, network connect predisposed industry 4.0

Year of construction: 2023, Condition: as good as new (ex-display), plate roll 1500 x 6 mm • Hydraulic 4 roll plate bending machine with prebend • Model MG • Plate width up to 1500 mm • Capacity thickness 6 mm • Pre-bend 4 mm • Fully hydraulic operated dual initial pre-pinch • Linear guideways technology best prebend • Top roll 130 mm - lower roll 120 mm • Centralized hydraulic power unit 4 hp • Hardened rolls highest resistance surface Iaolhccoizi Edjqlsr • Conical plate bending with rolls tilt and contrast roller. • Drop end open hydraulic - unloading closed shells. • Mobile control console electric operated with digital readout • Programmable digital controller save & repeat automatic NC • 300 programs memory storage – industry 4.0 network connect • Safety installation and emergency stop • Manuals of service and schematics

Year of construction: 2004, Condition: like new (used), Profile bending machine hydraulic heavy duty -output shafts 360 mm Equipped with traction tooling for H-beam HEB IPE INP rolling on the hard-side Configuration -pyramid dual pinch side rolls independent hydraulic Iaolhccqoiwa Hcoler -3 rolls driven hydraulic and gear unit -synchro. -set of rolls for HEB beam – INP beam - flat bar square bar. -Set of heads for traction the HEB – INP beam bending on the hard side -Set of rolls for pipe bending. Pipe 20 inches max capacity. -Lateral correctors left/right side hydraulic operated in 3 directions -Add-on rollers angle bending & T-section leg-in / leg-out -Control panel console electric joysticks manual use & program automatic -Digital readout screen display 8 axis position reading of the rolls - 8 axis automatic programmable bending works -Electric Vac 400/50 ( rewirable on request ) -weight total of the machine approx. 65 Ton. -Hydraulic reservoir oil 1200 liters -High pressure hydraulic power unit multi pumps run on 100Hp electric motor . -Working speed variable slow-fast. -Emergency shut-down devices in compliance with safety requirement. -CE quality certification, Made in Italy manufacturing. -Service manuals and operation books along with the machine On request we supply additional set of rolls interchangeable to seat and bend the wanted profiles. Capacity table max.: – HEB 500 -INP 600 *-ANGLE 200 MM *-T300 MM *-20″ PIPE SIZE *-UNP 500 MM *-FLATBAR 300X80 MM *-SQUAREBAR 200 MM *-PIPE/TUBE UP TO 508MM see capacity chart in enclosed

Condition: as good as new (ex-display), Year of construction: 2022, Profile bending roll shafts output 80 mm -Machine complete with 6 set of rollers for pipe bending from 3/8" - tru 3" inch -Lateral correctors left and right side hydraulic operated in 3 direction. -Machine with 3 rolls driven system with individual hydraulic motor and axial gear-unit on each shaft. -The 3 shafts working on bearings, heavy duty type with sealed lubrication. -Centralized control panel movable on wheels with all electric commands. -Dual rolling speed up to 7 mtr/min with automatic synchro speed system between the 3 rolls. -Safety devices in compliance with European regulation. CE mark. -Digital position readout of the bending rolls Iaolhccqeivt N Esler -CNC programmable controller EVOlution 3 /6 axis autocalculation of the bending shape upon input of the drawing from CAD station - multiradius bending shape elliptical, coil spiral forming, oval shape, cylindrical roll can take the installation of the set of rollers for standard profile bending like angle-ironbars-tubular-etc ( not included )

Condition: as good as new (ex-display), Year of construction: 2024, Functionality: fully functional, Capacity plate width 3000 mm plate thickness 22 mm prebend 18 mm minimum rolling diameter ID 400 mm and above. dual initial pinch planetary technical data: -length of rolls 3100 mm -top roll dia. 350mm -lower roll dia. 330mm -Hydraulic power unit with 20Hp motor -Electric supply Vac 400/50 – 480/60 Configuration complete: -Hardened surface of the 4 rolls -Conical plate bend hydraulic attachment. -driven rolls rotation powered with gear unit axial hydromotor -Synchronized hydraulic power dragging . -front open drop-end to remove closed shells. -Calibration re-rolling feature for welded shells Safety configuration in compliance. Control console electric commands with digital readout ----- Predisposed ready add-on accessories: -NC controller programmable 4 axis automatic plate roll, digital 7" touch screen readout position of the 4 rolls for use manual-semiautomatic-fully automatic programmable with storage memory, network connect predisposed industry 4.0 -nr. 1 central hydraulic support for large diameters up to 4 mtrs ID -nr. 1 side arm hydraulic to hold in place the plate sheet being formed Iaolhcceid Al Njqler

Year of construction: 2022, Condition: new, 4 ROLL HYDRAULIC MODEL M2008 EVO_4.0 CNC GRAPHIC CAD-CAM Machine serial number 2022 PLATE BENDING ROLL PLANETARY DESIGN DOUBLE PINCH PRE-BENDING Capacity -Width of plate: 2000 mm -Thickness of plate rolling 8 mm -Thickness of plate pre-bending 6 mm -top roll 190 mm -lower roll 170 mm Iaolhccohm Eqwjqljr minimum rolling shell ID 220 mm -Power 5,5 Hp to run the hydraulic unit Voltage 400/50 – 480/60 -Weight of the machine 3400 Kg Configuration installed • Surface hardening of the four rolls, smooth finishing suitable for stainless plates rolling • Dual pre-pinch, with adjustable force upon the input of plate thickness ad yield, cnc controlled programmable. • Conical plate bending hydraulic attachment hardened pad. • Power driven rolls rotation top/bottom gearbox axial direct drive hydraulic each roll. • Calibration system re-rolling welded shells rounding. • Console electric independent with centralized commands joysticks and CNC screen readout. • CNC graphic controller on touch screen 15” , CAD/CAM 5 axis auto calculation software package. • Variable working speed stepless axis interpolation. • Opening front side hydraulic drop-end to unload closed shells. • Predisposed mechanical attachment for future add-on tooling for plate supports top and side.

Condition: excellent (used), Year of construction: 2023, Functionality: fully functional, Helical forming machine - auger flights -Capacity range thickness 2 mm up to 12 mm helix pitch from 40 to 400 mm Ielhccegpxbioqljar outer dia from 100 to 1000/1200 mm interchangeable heads and dies to cover wide range of production interchangeable blades for the different pitch. All tooling core hardened high resistance to wear Machine hydraulic operated with electric digital control programmable for repeatability memorize 100 programs. spring-back plate compensation for the wanted pitch. Voltage Vac 380 /50 - Hp 20 on centralized hydraulic power unit
