CLOOS QIROX QRC-350-E

CLOOS QIROX QRC-350-E

Condition: ready for operation (used), Year of construction: 2019, total height: 2,110 mm, total width: 1,413 mm, overall weight: 640 kg, product length (max.): 1,413 mm, number of axes: 6, This CLOOS QIROX QRC 350-E was manufactured in 2019. It features a maximum payload of 15 kg and a working range up to 4500 mm. Equipped with a QC 2 Master control system, it includes a handheld programming device with an 8.4" touchscreen. The robot supports expansion up to 12 axes and comes with integrated welding software and a digital interface. Consider the opportunity to buy this CLOOS QIROX QRC 350-E welding robot. Contact us for more information about this machine. Extra Information • Robotics and Control Unit • Max. payload: 15 kg • Working range: 0–4500 mm • Digital inputs/outputs: 16 • Serial interface: Yes • CAN bus: Yes • USB interfaces: 2 • Flash memory: 8 GB • Buffer module: 24 V Ledpfx Aijx D Hdhoferp • Expandable to up to 12 axes • Welding Technology Power source: Included • Welding interface: Integrated • Welding and function test: Included • Torch cleaning: CMR-8-C torch cleaning device • upright Robotic welding torch: Included • Sensors Tactile sensor: Yes • Arc sensor: Included Technical Data of Workpiece Positioner • Load capacity: 10 kN • Nominal torque: max. 1600 Nm • Tilting moment: max. 8800 Nm • Mass moment of inertia: 900 kgm² • Rotation range: +,- 360° • Swivel range: 370° • Welding Fume Extraction capacity: 3000 - 4320 m³/h • Motor power: 5.5 kW • Connection voltage: 3 x 400V/50 Hz • Noise level: 65 dB(A) • Weight: 640 kg • Dimensions (W x D x H): 1413 x 1413 x 2110 mm

Condition: used, Year of construction: 2008, machine/vehicle number: 0-411-49-1873, Technical data: - Manufacturer: Bütfering - Type: Optimat SGO 211/RC - Number of grinding units: 2 - Year of manufacture: 2008 Lrsdpfxjyh Hwue Aifjp - Working width: 1.100 mm - Grinding belt width: 1.120 mm - Grinding belt length: 1.900 mm - Workpiece thickness: 3-160 mm - Feed speed: 2,5-13 m/min. - Table height adjustment Standard equipment: - Automatic workpiece thickness adjustment - Stepless feed speed via requency converter. - 125 grinding programs can be stored - Wear-free braking system 1. Grinding unit (R) - Calibration roller - Profiled steel contact roller - Diameter 160 mm - Drive motor: 15 kW 2nd grinding unit (C) - Combination unit with roller and grinding shoe - Rubberized contact roller 65 Shore - Contact roller diameter 160 mm - Electronic link pressure bar with segment width 35 mm. - Belt speed: 12 and 21 m/s - Tolerance compensation up to 1 mm - Suitable for veneered surfaces and solid wood. - Drive motor: 11 kW - Total connected load: approx. 28 kW - Operating voltage: 400 V / 50 Hz. - Compressed air consumption at 6 bar, 20 L/min. - Belt blow-off device per pressure surge 440 L/min. - Extraction volume: approx. 2,880 m3/h/ at 20 m/s - Extraction connection: Dedusting: 1 x Ø 160 mm (grinding unit, roller) 1 x Ø 160 mm (grinding unit, shoe) Dimensions: - Length: 1,700 mm - Width: 1,850 mm - Height: 2,100 mm - Location: not in stock - Available from April 2026

Condition: new, Year of construction: 2025, functionality: fully functional, The CNC BAYKAL Hybrid Press Brakes combines all the benefits of both hydraulic and all-electric press brake systems into one. If you’re looking for press brakes that are fast, accurate, and energy-efficient, BAYKAL is the way to go. The CNC BAYKAL Hybrid Press Brakes can significantly save energy, save fuel, improve bending efficiency, reduce the risk of oil leakage, reduce installation costs, extend the service life of consumables, improve bending accuracy, reduce noise, and improve the working environment. The CNC BAYKAL hybrid press brakes system are designed with an individual electro-hydraulic servo drive system and servo pumps to control the for each of the left and right cylinders. The servo motor controls the output flow of the oil pump according to the program setting, and then controls the movement speed and position positioning of the slider, and there is no throttling phenomenon in the whole process. Therefore, all the energy output by the oil pump is supplied to the left-right oil cylinder. This control method does not have any energy loss, and the energy-saving effect is very prominent. With this system the hydraulics run on demand when the foot pedal is activated, rather than having a pump running continuously. This results in lower energy usage than a standard hydraulic machine as well as faster cycle times and extremely high accuracy. The flow and pressure of Y1 and Y2 oil cylinders are respectively controlled by two sets of servo bidirectional pump systems, and the oil in the upper chamber of the oil cylinder is directly pumped into the lower chamber of the oil cylinder through the oil pump to realize the lifting of the beam. Lrjdpfx Asrq D Nijifep The reverse rotation of the oil pump pumps the oil in the lower chamber of the oil cylinder directly into the lower chamber of the oil cylinder to realize the pressing and bending of the upper die. Applicable between from 100 Tons to 1250 Tons, the synchronization of the left and right of the upper beam of the CNC BAYKAL hybrid press brakes is controlled separately by two sets of servo bidirectional pumps.

Year of construction: 2011, condition: excellent (used), Cloos welding robot Qirox QRC 320 incl. control system V 6, stand base for vertical arrangement, Cloos welding machine Quinto II 603 (600 A), wire feeder, welding torch, torch hose package, mechanical cleaning, pressure amplifier 1 tilting and rotating table WPK 5000, load capacity 500 kg, 1 start pre-selection, 1 control unit for customer-supplied sliding door Gas nozzle sensor, arc seam tracking, point editor System will be completely overhauled and serviced before delivery. Lodpfx Aijizwv Njferp A second station with another identical tilting and rotating table is possible.

Condition: new, pressure: 600bending length: 6050column width: 5100daylight: 680stroke lenght (max.): 455column throat depth: 450messurements (LxWxH): 7100x3275x3910weight approx.: 50.2004 axes (Y1, Y2, X, R): Ja alle Achsen über die Esa S630 (2D Grafik Steuerung)CNC crowning system by control: ja über die Esa S630 (2D Grafik Steuerung)motor power: 45Standard Equipment:KK Kletzer Europa Ledpfxod Ehh Ro Aiforp We have developed a high-quality model specifically for the European market:The CNC press brake by KK Industries, made in Turkey. Model: KK Kletzer EUROPA XL The powerful EUROPA XL press brake stands out for its high precision, accuracy, and versatile offers a very large open height, resulting in a long cylinder stroke, and an extra-large throat depth to provide maximum flexibility during operations. We focus on delivering quality—reflected also in the control system:As standard, the machine comes equipped with the ESA S640 2D graphic controller. Additionally, the KKI EUROPA XL is equipped with CNC-controlled Y1, Y2, X, and R axes via the wning is also included and fully CNC-controlled through the same ESA S640. When it comes to tooling, we make no machine is fitted with premium top tools and dies from EUROSTAMP Italy. Naturally, a machine is only as good as the service behind t’s why we rely on highly qualified staff with many years of experience in CNC sheet metal processing. Technical Highlights: CNC axes: Y1, Y2, X, and R Controller: ESA S640 (2D graphical interface) Backgauge with double linear guides and ballscrews Motorized CNC-controlled crowning system Heavy-duty height adjustment with handwheel(from 175 tons: on linear guides) Laser safety system on the upper beam CE-compliant safety equipment Various options available Optional Controllers: ESA S640 – 15” 2D Touchscreen: ¤ 4,520.00 ESA 675 W – 21” 3D Touchscreen (Windows-based): ¤ 6,485.00 DELEM DA-66T – 17” 2D Touchscreen (Windows-based): ¤ 10,165.00 DELEM DA-69T – 17” 3D Touchscreen (Windows-based): ¤ 16,350.00

Condition: as good as new (ex-display), Year of construction: 2026, sheet width 1550 mm plate thickness 6.5 mm pre-bending 4.5 mm diameter of upper rolls 150 mm side roll diameter 130 mm diameter of lower rolls 150 mm distance max. OW zu UW 20,0 mm total power requirement 2.2 + 1.5 kW weight of the machine ca. 2370 kg. range L-W-H 3300 x 1150 x 1110 mm Exhibition machine - NEW not yet in use (!!) Special price on request Equipment: - electro-hydraulic 4-roller round bending machine * with driven top roller + bottom roller * stable welded construction - Area of application: * light to heavy sheet metal processing (steel/aluminum/stainless steel) - electro-hydraulic adjustment of the bottom + side rollers - linear guidance of the side rollers - top roller driven by robust electric motor + planetary gear - freely movable, separate control panel - hardened rollers SAE 1050 (CK 45) + crowning - conical bending device - 3x axis digital display for precise roller positions - electro-hydraulic folding bearing - operating instructions (PDF) Lsdsxabkbepfx Aiferp

Condition: excellent (used), Year of construction: 2006, Technical data: - working width 1350mm - pneumatic oscillation - vacuum table - Stand alone machine ( Table raise/fall ) 1 Combi unit: - motor power 18,5kW - steel calibrating roller - stepless adjustment of the belt speed - sectional pad (52 sections of 26mm each) 2 Combi unit: Ledpsvdtxisfx Aiforp - sectional pad (52 sections of 26mm each) - motor power 7,5kW - stepless adjustment of band speed - brush on the exit of the material - stepless regulation of feed speed - pneumatic cleaning of belts

Year of construction: 2010, condition: ready for operation (used), For sale is a CNC laser cutting machine from TRUMPF. laser power: approx. 3000W (3kW), working area: X/Y/Z 3000mm/1500mm/115mm. Additionally, a suitable Liftmaster from the year 2015 is offered, which can also be purchased separately. Lredpfoxxa Ucex Aifep

Condition: new, pressure 40 t throat 225 mm stroke 8-84 mm Table dimensions 580 x 450 mm ram adjustment 55 mm no. of strokes 130 Hub/min ram surface 185 x 180 mm Ljdsb U Hwmopfx Aiferp ram hole 40 H7 mm hole in the table 210 x 170 mm T-slots 22 clamping plate 570 x 450 x 65 mm total power requirement 3,5 kW weight of the machine ca. 2,7 t dimensions of the machine ca. 1,4 x 1,1 x 2,1 m

Condition: new, pressure 25 t throat 200 mm stroke 4 - 80 mm table-size 520 x 400 mm no. of strokes 160 Hub/min work capacity during endurance run 1370 Nm force 2740 Einzelhub Lodjb U Hwnjpfx Aifsrp adjustment of stroke 4 - 80 mm ram adjustment 40 mm ram surface 160 x 160 mm hole in the table 200 x 150 mm clamping plate 500 x 380 x 60 mm hole in the table 80 mm weight of the machine ca. 1,9 t
