Used mounting technology for sale (155)

Year of construction: 2014, operating hours: 3,100 h, condition: excellent (used), functionality: limited functionality, MYDATA MY500JP Jet Printer 2014 in excellent condition with exceptionally low operating hours (approximately 3,100). Kept and used in a clean environment. Complete system supplied with offline programming PC, MYCAM JP software, 2D Inspection & Repair option, SMT Adhesive option, manual load tables and associated documentation. There are also some spares included which we can bundle into a sale deal for an appropriate price. Visits/Inspection are welcome by appointment. An excellent opportunity to acquire a MY500JP suitable for high-mix, low-to-medium volume SMT production. The machine exhibits an intermittent issue affecting movement on the X-axis during camera positioning. On occasion, a slight jitter or vibration is observed, which can prevent the vision system from reliably locating the PCB fiducial during initial board loading or machine initialisation. The fault is intermittent and does not occur consistently. Most of the time, reloading the PCB allows operation to continue normally. Occasionally, a machine restart is required. The root cause has not been determined, but the issue appears to be associated with the X-axis motion control system. Potential areas for investigation include the servo amplifier (drive), encoder, encoder cable or other associated motion control components. Despite this intermittent behaviour, the machine was used in active production of complex PCB assemblies, including fine-pitch BGA boards, for approximately 12 months prior to being replaced as part of an equipment upgrade. The machine is therefore offered for sale on the understanding that diagnosis and repair of this intermittent fault is outstanding. Included: MYDATA MY500JP (2014) Dedpszlx E Tsfx Anzjwa Approx. 3,100 operating hours MYCAM JP offline programming PC and software 2D Inspection and Repair option SMT Adhesive option Manual loading Technical documentation 4pcs AE04 ejectors Bundle of spare parts Not included: Solder paste Cassette (Holding Assembly), Solder paste, Purge Gel, Filter boxes Conveyors

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2024, DIVISIO 3100 - Inline - Returned from a lease due to factory closure! New price in 2024: €149,000.00 net! 42,680 circuit boards have been milled. - Milling cutter diameter control - Wear parts package for DIVISIO - Automatic transport width adjustment - SMEMA transport height - Separation module for shaft milling cutters, 500W Djdpfxozpytas Anzswa - Hardware module, camera - Software module, teach function for camera - Software module, fiducial mark recognition - Extension, 8-position tool changer - Suction hose, manual - Monitoring of suction power - ASYCAM CAD data conversion - A Adrep - Offset main switch - ESD energy chains and P-hoses, standard - Packaging size: Group 3 pallet Further information available upon request.

Year of construction: 2019, condition: like new (used), ASYS ACS 02 * Year of manufacture: 2019 * Serial number: 084939 * Machine length: 1,060 mm Dwedpfx Anozqcwwezsa * Supply voltage: 400 VAC / 50 Hz * Power connection: 3-phase * Rated current: 2.7 A * Connected power: 1.5 kW * Fusing: 16 A * Operating pressure: 6 bar * Condition: Used, operational

Condition: good (used), Year of construction: 2007, ASSCON Systemtechnik VP1000-56 * PCB size: 500 × 600 mm * Maximum component height: 50 mm * Machine weight: 400 kg * Supply voltage: 400 V / 50 Hz (3/N/PE) * Connected power: 10 kW * Average power consumption: 3.5 kW Dwsdpfx Anezqcmfozea * Standby power consumption: 1.9 kW * Compressed air supply: 5 bar, oil-free compressed air * Media consumption: approx. 2.5 m³/h * Galden® filling volume: 20–25 kg * Heat-up time: approx. 25 min * Machine dimensions (L × W × H): 1,430 × 1,385 × 1,350 mm * Loading/unloading height: 920 ± 20 mm * Cooling: Air/convection, open or closed cooling water circuit possible

Year of construction: 2011, condition: excellent (used), Essemtec Pantera XV Pick-and-Place Machine Year of manufacture: 2011 Excellent condition From small-batch production 0201 components Top-down image processing Intelligent tape feeder (8 to 56 mm) Dedpfx Asyxc I Ujnzswa Placement speed: 4,500 cph Easy-to-use graphical software Optical alignment “on the fly” Upward-vision system for component inspection Feeder package: 10 pieces 740i paper 8mm 30 pieces 740 blister 8mm 5 pieces 741 12mm 2 pieces 742i 16mm 10 pieces strip tape feeder

Year of construction: 2015, condition: good (used), ASYS TRM01 with excavation * Dimensions (L × W × H): 530 × 800 × 1,205 mm * Transport height: 950 mm * Fixed stop: 145 mm * 1 belt segment, belt length 530 mm * PCB size: 70–460 × 50–460 mm * PCB support: 3 mm * SMEMA infeed and outfeed * Mains connection: 230 V / 50 Hz * Power consumption: 0.75 kW * Pneumatics: 5 bar, air consumption 3–8 l/min Dwedpfx Aezqbnhonzsa English ASYS TRM01 PCB Lift Station * Dimensions (L × W × H): 530 × 800 × 1,205 mm * Transport height: 950 mm * Fixed stop: 145 mm * 1 conveyor segment, conveyor length 530 mm * PCB size: 70–460 × 50–460 mm * PCB edge support: 3 mm * SMEMA infeed and outfeed * Power supply: 230 V / 50 Hz * Power consumption: 0.75 kW * Pneumatic supply: 5 bar, air consumption 3–8 l/min

Year of construction: 2018, condition: good (used), ASYS TDM 06 * Year of manufacture: 2018 Dodpfx Ajzqbkvenzjwa * Dimensions (L × W × H): 1,590 × 1,000 × 950 mm * Transport height: 850 mm * Overall height including signal light: 2,050 mm * Weight: 235 kg * Passageway width: 790 mm * PCB size: 70–460 × 50–460 mm * PCB thickness: 0.8–4.5 mm * PCB weight: 0–3 kg * Maximum component height: ±40 mm * Power connection: 230 V / 50 Hz * Pneumatics: 6 bar supply pressure, 5 bar working pressure, oil-free compressed air * Sound pressure level: < 75 dB(A) * Complete documentation available

Condition: good (used), Year of construction: 2017, Equipment: documentation/manual, * Dimensions (L × W × H): 1,000 × 1,038 × 950 mm * Transport height: 950 mm * Overall height including signal light: 2,050 mm * Conveyor segment: 1 × 1,000 mm * PCB size: 100–430 × 50–350 mm * PCB edge distance: 3 mm Dwsdpfx Anezqbfmezsa * Interface: SMEMA * Power connection: 230 V / 50 Hz * Pneumatics: 5 bar, air consumption 3–8 l/min * Electrically adjustable width via stepper motor

Condition: good (used), * Manufacturer: Panasonic * Type: Feeder Cart / Feeder Trolley * Part Number: KXFX036PA00 Dwjdpfxozqbako Anzja * 27 feeder positions * Compatibility: Panasonic CM602, CM402 * Design: Gear Change Type Feeder Cart * Larger quantities available.

Year of construction: 2011, condition: excellent (used), functionality: fully functional, Rigid machine structure with large access doors. Integrated 600 dpi printer. Designer 2 user license. Slide-out mechanism (rear-side) for easy and fast label or ribbon replacement. Label rotation programmable in 1° increments. Vacuum sensing of the label from pick-up to placement. CCD camera to read the label before pick-up. Controlled by an industrial PC. Conveyor width adjustment using a hand crank. PCB side clamping. Active support base including 4 magnetic pins. Quick product change-over. Selectable by-pass operation. Uninterruptible power supply (UPS). SATO bar code printer EX2 Tower light display for machine status. CE certified. SPECIFICATIONS Printer type: SATO (600 dpi) Minimum label size: 6 x 6 mm Label creation software: ZebraDesigner 2 Cycle time: 2.5 sec. per label (6 x 6 mm) Labelling area: 460 x 460 mm Conveyor type: 3 mm ESD edge belt Conveyor speed: 24 m/min System software: Windows Network interface: Ethernet Monitor: 21” high-density flatscreen PCB transfer height: 950 mm ± 25 mm* Component clearance: Top 30 mm, bottom 30 mm* Machine interface: SMEMA* Colour: RAL9002* Power supply: 230 VAC/50 Hz/1 Ph Power consumption: 700 VA max. Air supply: 6 bar Air consumption: 70 ltr/min max. Noise level: Max. 65 dB * or specify MACHINE SIZES Machine L x W x H (mm): 850 x 1680 x 1440 Weight (Kg): 750 Applicable PCB Length (mm): 80 - 508 Applicable PCB Width (mm): 65 - 460 PCB thickness (mm): 0.6 - 4 Fixed rail to front (A) (mm): 335 Dedpfezmxytex Anzswa

Condition: used, EROWA UPC clamping system – pallet holder Dodpfx Aozpxkdonzowa ER 016093

Year of construction: 2008, condition: defective spare-parts repository (used), functionality: unexamined, power: 5 kW (6.80 HP), number of previous owners: 1, noise level: 69 dB, machine/vehicle number: 070523, Current operating hours of the tube: unknown Maximum PCB width: 450 mm x 400 mm Inline X-ray imaging + AOI History from the previous owner is available We acquired the machine as "functional," but it was likely used as a source of spare parts by the previous owner. Therefore, it cannot be guaranteed that all components are present. We have never put the machine into operation and cannot provide any information about its condition during operation. Dwjdpfx Anszhwvpszja You are welcome to inspect the machine in 72108 Rottenburg and form your own opinion. Since we are selling the machine as defective/in need of repair, the goods are sold with the exclusion of any warranty and any liability for defects.

Year of construction: 2014, condition: used, curb weight 2.500 kg Max. load weight 2.500 kg total wight 3.000 kg In our assessment, the machine is in good used condition and can be inspected under power by appointment. Technical features & accessories: Dwjdpfjzkbp Sox Anzsa - 1x Quick-Point mounting plate for the machine - 20x centering vises (77mm steel version) Accessories, tools, and clamping devices shown are included in the scope of delivery only if specified in the additional information. Subject to technical changes, errors, and prior sale.

Year of construction: 2006, condition: good (used), functionality: fully functional, Machine width: approx. 1.90 m with track/transport path approx. 1.25 m without track/transport path Machine depth: approx. 1.35 m incl. main switch approx. 1.20 m without main switch Machine height: approx. 2.00 m with superstructures/signal light approx. 1.50 m without superstructures Note: The dimensions are measured manually and may differ from official manufacturer specifications. 2. Work area / component placement area Work area in the component placement area: approx. 600 × 600 mm Note: This is the measured mechanical area in the machine room or in the component placement area. The maximum processable printed circuit board size may differ from this and must be confirmed separately via machine data and software settings. Dwodpfx Aszl R R Ionzja

Year of construction: 1989, condition: ready for operation (used), An industrial etching machine from a printed circuit board manufacturing facility for the alkaline development of photoresists is offered. Process sequence: infeed, etch chamber, replenisher, 3-stage rinse, drying and outfeed, max. working width: 550mm, printed circuit board thickness range: 0.2mm-4.0mm, conveyor speed: 0.4m/min-2.5m/min. Including a Nubal unstacker, a drip tray X/Y: 3900mm/1600mm and a 200l dosing unit with agitator. Machine dimensions X/Y/Z: approx. 4000mm/1300mm/1400mm. An on-site inspection is possible. Dwjdsznx Igjpfx Anzea

Year of construction: 2008, condition: ready for operation (used), An industrial Pill micro-etching machine for the micro-etching of printed circuit boards (PCBs) from a PCB manufacturing facility. is offered. Process steps: infeed, micro-etching, rinsing, drying and outfeed, max. working width: 650mm, PCB thickness range: 0.1mm-3.2mm, feed speed: 0.5m/min-3.5m/min, machine dimensions X/Y/Z: approx. 2600mm/1400mm/1300mm. Including a Dataco stacking unit. Documentation available. On-site inspection is possible. Dwedpfx Aoznx Iasnzsa

Year of construction: 2009, condition: ready for operation (used), Industrial Pill etching machine from a printed circuit board manufacturing facility. Process stages: infeed section, etching chamber, replenisher, 4-stage cascade rinse, drying and outfeed section, max. working width: 650mm, PCB thickness: 0.1mm-3.2mm, conveyor speed: 0.5m/min-5.0m/min, max. process temperature: 55°C. Including a magnetic centrifugal pump for the etching chamber, one tank X/Y: 3500mm/2200mm and one Lantronic stacker. Machine dimensions X/Y/Z: approx. 3400mm/2000mm/1300mm. An on-site inspection is possible. Dedpfxjznx Imo Anzswa

Year of construction: 2006, condition: good (used), For sale are 3 Siemens component placement machines, consisting of: 1 unit X 2 (year of manufacture 2006), serial number B 348 = €13,000 + VAT 1 unit X 2 (year of manufacture 2006), serial number B 251 = €13,000 + VAT Both machines have been inspected and tested for full functionality in our workshop. All machines have a valid maintenance report. An on-site inspection is possible and welcome. Please refer to the photos for the technical data and configuration of each machine. We will also be happy to answer any questions you may have about the machines in person. Dodeyrm E Aopfx Anzswa Upon request, a reference run video is available for each machine. We can also carry out modifications for your specific application for an additional charge. The machines are sold without placement tables or MTC (material transfer cabinet). Location of the machines: Zollner Elektronik AG / Warehouse Roding / Buchenstraße 18 - 20 / 93426 Roding

Condition: used, functionality: unexamined, Year of construction: 2012, Available for shipment. Machine is operational condition. Dedoyup R Tepfx Anzowa Ask for additional information including photos and pricing!

Condition: used, functionality: fully functional, Year of construction: 2017, Operational condition 3D AOI machine. Dwjdjw Ty Hcopfx Anzsa Ask for specification!

Year of construction: 2012, condition: ready for operation (used), Two identical Ekra stencil printers, both fully overhauled in 2026, are available. Year of manufacture: 2009/2012, overhaul: 2026/2026, min. printing area X/Y: 80mm/50mm, max. printing area X/Y: 508mm/508mm, substrate thickness range: 0.5mm-6mm, max. substrate weight: 2kg, min. stencil dimensions X/Y: 450mm/450mm, max. stencil dimensions X/Y: 740mm/740mm, repeat accuracy at 6 Sigma: +/-12.5µm, squeegee speed: 200mm/s, squeegee pressure: 10kN-250kN, snap-off min./max.: -1.5mm/6mm, separation distance: 0mm-3mm, separation speed: 100mm/s, transport height range: 830mm-950mm, machine dimensions X/Y/Z: approx. 1150mm/1900mm/1550mm, weight: approx. 750kg. Including operator computer, steel squeegees, accessories, EVA Vision System and automatic stencil cleaner. Documentation available. On-site inspection is possible. Dwedpfx Anjzmyk Tezsa

Year of construction: 2017, condition: ready for operation (used), Offered for sale is a Mycronic SMT placement machine. Max. placement capacity: 16000components/h, IPC net throughput: 13800components/h, placement system: HYDRA, placement tools: 8, max. component dimensions X/Y/Z: 56mm/56mm/15mm, max. component weight: 140g, min. PCB size X/Y: 70mm/50mm, max. PCB size with T3 X/Y: 443mm/508mm, min./max. PCB thickness: 0.4mm/6mm, max. PCB weight with T3: 5kg, feeder capacity with T3: 112 × 8mm feeder positions, conveyor height range: 880mm-975mm, operating hours: approx. 6871h, placement time: approx. 2983h. Machine dimensions X/Y/Z: approx. 2690mm/2229mm/1446mm, weight: approx. 1400kg. Inspection possible by appointment. Dsdpozl U Nnofx Anzjwa

Condition: good (used), Year of construction: 2018, ASYS TRM 03 Workstation * Dimensions (L × W × H): 1,590 × 800 × 1,055 mm * Transport height: 950 mm (±50 mm) * Weight: 200 kg * PCB size: 70–460 × 50–460 mm * PCB thickness: 0.8–4.5 mm * PCB weight: 0–3 kg * Maximum component height: ±40 mm * Power supply: 230 V / 50 Hz Dwjdpfx Aozivt Nenzja * Pneumatic supply: 6 bar (operating pressure 5 bar), oil-free compressed air * Sound pressure level: < 75 dB(A)

Condition: good (used), Year of construction: 2017, functionality: fully functional, Technical Data * Dimensions (L × W × H): 612 × 1,140 × 1,678 mm * Transport height: 950 ± 50 mm * Fixed stop: 250 mm * Magazine capacity: max. 250 mm stack height * PCB size: 70 × 70 mm to 460 × 460 mm * PCB thickness: 0.8 – 4.0 mm Dedpozivq Isfx Anzowa * PCB overhang during transport: 3 mm * Infeed interface: SMEMA * Outfeed interface: SMEMA * Automatic width adjustment via stepper motor * Automatic tracking via IC-Net * Continuous operation available * Power supply: 230 V / 50 Hz * Power consumption: approx. 0.75 kW * Secondary voltage: 24 V DC * Pneumatic connection: 5 bar * Air consumption: approx. 5 l/min * Complete documentation available

Condition: new, 1 lot Eaton distribution cabinet and accessories - CI48-200 78896 32 pieces - CI43-150 95506 17 pieces Dedpfx Aow U Suhonzowa - IM4-CI48 093200 4 pieces - FL4-4 19609 8 pieces - 3 pallets, shipping possible at extra cost
