Mobile star screen system

Lindner Zeta Star 75DK

Condition: like new (used), functionality: fully functional, power: 94 kW (127.80 HP), fuel type: diesel, overall weight: 34,000 kg, Year of construction: 2022, operating hours: 1,238 h, Output capacity up to: approx. 500 t/h Maximum feed size: 800 x 500 x 300 mm Feed height: approx. 3,570 mm Feed height with rear wall folded down: 2,830 mm Hopper volume: 9.1 m³ Hopper discharge belt width x length: 1,400 x 4,500 mm Screening type: double-deck heavy-duty screen Screen area upper deck: 1,550 x 4,880 mm (W x L) Screen area lower deck: 1,550 x 4,500 mm (W x L) Fine material conveyor width x length: 1,200 x 4,380 mm Fine material discharge conveyor width / length / discharge height: 900 x 7,760 / 2,960 to 3,980 mm Fodpfsxl Szzox Adcjgc Medium grain discharge conveyor width / length / discharge height: 900 x 7,760 / 2,310 to 3,630 mm Oversize discharge conveyor width / length / discharge height: 1,400 x 6,065 / 2,650 to 4,050 mm Drive concept: diesel-hydraulic Engine manufacturer: John Deere Drive unit power: 94-98 kW Transport dimensions: 15,840 x 3,000 x 3,400 mm (L x W x H) Transport weight: 34,000 kg

Year of construction: 2025, condition: new, functionality: fully functional, machine/vehicle number: ESS B2 - *M 0--.10*, Mobile starscreen on trolley Fgjdpfx Adsirnrpocsc Suitable for material: soil, compost, topsoil, wood chips, building rubble, bark mulch Weight: 2700 kg Grain size: 12 to 40 mm (according to material requirements) Power supply: 3 phases, 400V, current 32A, frequency 50Hz, total power 11,25kW throughput: 40 to 60 m³/h depending on material and grain size Delivery time after order approx. 14 weeks

Condition: reconditioned (used), Year of construction: 2007, operating hours: 22,605 h, functionality: fully functional, pressing force: 100 t, filling opening width: 1,100 mm, filling opening length: 1,600 mm, bale width: 1,100 mm, bale height: 1,100 mm, bale weight: 1,400 kg, overall weight: 36,000 kg, oil tank capacity: 1,300 l, year of last overhaul: 2025, For sale is a overhauled baler, with 100 tonnes pressing force, large format 1100 x 1100 mm, 75 kW drive power and 10-fold cross binding Technical data baler: Manufacturer Bollegraaf Typ HBC 110 K / 75 kW Year of construction 2007 Press power main press 100 tons Press power of pre-press 50 tons Operating hours 22,605 hours Feed channel 1,600 x 1,100 mm Capacity per cycle time 3,15 m³ Theoretic cycle time 19 sec. Bale size 1,100 x 1,100 mm Driving motor 75 kW Connected load 126 kW Full load current 238 A Tying system 5-fold vertical, 5-fold horizontal, fully automated Throughput rate at a bulk weight of 30 kg/cbm approx.16 tons/h bulk weight of 50 kg/cbm approx. 25 tons/h bulk weight of 100 kg/cbm approx. 47 tons/h Bale weight up to 1400 kg, depends on material and bale lenght Volume oil tank approx. 1,300 l SPS controller Telemecanique TSX Micro Operating panel Schneider MAGELIS Touch Baler dimensions built up with hopper 11,750 x 5,000 x 7,105 mm (l x w x h) Transport dimensions only baler 11.750 x 2.500 x 3.450 mm (l x w x h) Machine weight baler approx. 36 tons Comments: The press was partially overhauled and serviced in our workshop and tested and stored after completion of the work. The machine is available at short notice and can be inspected in our warehouse by appointment. The following overhaul work was carried out: Rust removal and partial painting of the press. Remaining hydraulic oil tank drained, oil filter and air filter replaced. New hydraulic oil topped up. All hydraulic hoses replaced. Main hydraulic cylinder, two cylinders of the prepress flap and the cylinder of the press channel dismantled, disassembled, checked, cylinder tubes honed, all seal sets replaced and a final pressure test carried out. Fgedpfx Aevf E Avsdcec Disassembly of the prepress flap with bearings and bearing blocks. 1st and 3rd circular arc segmet cut out and a new one welded in again. Both bearings of the shaft of the prepress flap replaced. Upper material deflector on the frame of the prepress flap replaced. Press ram dismantled, checked and both front rollers replaced. Material deflectors and wear profiles on the sides and base of the press ram cut off and new ones welded in. Horizontal and vertical needle and tying unit dismantled, disassembled, checked, plastic sliding plates, bearings of the drill shafts and wire deflection rollers with bearings in the needle heads replaced. Both bronze slide rails on the left and right in the frame cover to the press ram replaced. Both wire deflection units on the left and right, with bale retaining clamps, completely renewed. Wire insertion unit including hydraulic cylinder under the needle feedthroughs completely renewed. Wire entry marks in the floor and side walls of the bale chamber welded shut and smoothed. General maintenance and service work carried out in accordance with the manufacturer's specifications. Press was tested in manual and automatic mode, accepted and stored after completion of overhaul work. We accept no liability for the technical specifications or any errors.

Condition: used, functionality: fully functional, tank capacity: 30,000 l, total height: 7,200 mm, inner diameter: 2,500 mm, outer diameter: 2,900 mm, overall weight: 6,000 kg, wall thickness: 10 mm, wall structure: single-walled, number of chambers: 1, manhole diameter: 600 mm, pressure (max.): 3 bar, Buffer Storage Tank – 30,000 L, Vertical, Insulated Volume: 30,000 liters Internal diameter: approx. 2,500 mm External diameter (with insulation): approx. 2,900 mm Cylindrical height: approx. 5,520 mm Overall height: approx. 7,200 mm Empty weight: 6,000 kg Fedpjxdknksfx Adcegc Operating pressure: +3.00 bar Operating temperature: -10 / +900 °C Medium: Water Density: 1,000 kg/m³ Bottom wall thickness: approx. 11 mm Shell/cylinder wall thickness: approx. 10 mm Material / Characteristics Shell material: P265GH / S235JR Insulation: 200 mm mineral wool Cladding: smooth aluminium sheet (weatherproof) Mineral wool will be newly installed, i.e., insulation thickness can be chosen freely. Equipment Mounting: Feet Number: 4 Attachment: fixed Top/base type: dished end (Klöpper head) Bottom/base type: dished end (Klöpper head) Connections: - 1 manhole DN 600 with blind cover - 7x 1/2'' sockets for temperature sensors - 2 lifting lugs on the shell - 2 lifting lugs on the top head - 2 lifting lugs at the tank feet - 1 drain 2'' at the tank bottom, routed to the outside and terminating in a 2'' ball valve - 1 vent Ø33.7 x 3.6 mm, routed downwards laterally within the insulation and ending in the manhole cover enclosure - 1 connection DN 125, flanged externally, ending internally in a 90° bend in the tank center - 1 connection DN 125, flanged externally, ending internally in a 90° bend in the tank center Documentation: Drawing

Condition: good (used), Year of construction: 2022, operating hours: 2,806 h, functionality: fully functional, Equipment: Basic Package Inventhor Type 6 Load-sensing system Fuel tank 500 liters Longitudinal conveyor: length 2,900 mm, width 800 mm Centrally arranged lubrication strips 24V electronic control – additional electric pump to operate the following functions when the engine is off: "raise/lower/fold rear conveyor, open/close comb flap, open/close comb, raise/lower folding hopper" Complete radio remote control Large side GRP maintenance doors Maintenance-friendly engine compartment LED lighting package: engine compartment and rear Hydraulically reversible fan Three-sided loading protection Folding hopper Fire extinguisher Service ladder Toolbox Acoustic start-up warning Doppstadt telematics system Paintwork: RAL2011 deep orange Special Equipment: Powertrain 310 kW - EV 3-axle drawbar trailer chassis unit Shredding system Size L 600/4 - 30 Z Additional hydraulic connections 35 - 80 l/min Hydraulic drive Rear conveyor 4.9 m Overband magnet neodymium Fodpfxswnfwqj Adcsgc Frame for overband magnet

Year of construction: 2010, condition: good (used), 2 SICON shredders Year 2010 The electrical cabinet is missing Price 15 000€ each Fgjdpfx Adoiz Tm Iscsc 4 densimetric tables : 8 000€ each

Year of construction: 2021, condition: ready for operation (used), functionality: unexamined, Basic package Selector 800 Lower belt BB 1350 mm AA 6.4m -profiled belt- SPIRAL SHAFT SCREEN COVER AA254-150 - 16 shafts Fgsdpfx Ajvm Upnedcec

Condition: new, functionality: fully functional, power: 5 kW (6.80 HP), fuel type: electric, empty load weight: 4,200 kg, Year of construction: 2024, filling bunker with bunker gutter Fsdpfsuqynmox Adcogc bunker capacity 10.5m³ S355 / St52-3 vibratory feeder with 10mm Hardox 450 wear plate gutter fully stress relieved annealed 2 x imbalance motors 2,5kW NEW

Condition: used, functionality: fully functional, Year of construction: 2020, operating hours: 14,300 h, Metso Nordberg HP200 – Cone Crusher for Sale Operating hours: 14,300 Condition: Fully operational, currently in use, regularly serviced Machine Description We offer a Metso Nordberg HP200 cone crusher – one of the most proven and efficient machines in its class. The crusher is still in daily operation, maintained according to manufacturer recommendations and kept in very good technical condition. Ideal for producing high-quality aggregates in both stationary and mobile installations. Key Features - High crushing efficiency and consistent product quality - Excellent performance on hard and medium-hard materials - Hydraulic closed side setting (CSS) adjustment - Stable operation and low wear costs - Reliable, robust design commonly used in European quarries Fodoxyi Rispfx Adcjgc Technical Specifications (HP200) - Head diameter: 940 mm - CSS range: 6–38 mm (depending on configuration) - Maximum feed size: 185 mm - Motor power: 132 kW - Capacity: up to approx. 250 t/h (depending on application and settings) - Crusher weight: approx. 12,000 kg Details of the Offered Unit - 14,300 operating hours - Fully operational, in continuous use - Regular maintenance and service records available - Inspection of the machine in operation is possible

Year of construction: 1963, condition: ready for operation (used), Load: 18t, lifting height: 10,750mm, span: 23,000mm, weight: 35.1t, machine was regularly maintained and inspected. Fsdpsh I Edvofx Adcsgc
