Used 4-Axis Horizontal Machining Center for sale (105,025)

Condition: used, Year of construction: 1976, functionality: fully functional, machine/vehicle number: 4218/ 12035, Axis height over bed: 1500 mm Speed: 0 - 315 rpm Range of diameters and length of drilling on one side:. D 35 – 45 mm L = 4000 mm D 46 – 65 mm L = 6000 mm D 66 – 85 mm L = 8000 mm D 86 – 105 mm L = 12,000 mm D 106 – 125 mm L = 16,000 mm Iedpfx Afewqk Umoheig D 126 – 200 mm L = 24,500 mm D 201 – 250 mm L = 24,500 mm D 251 – 555 mm L = 18,000 mm

Condition: excellent (used), Year of construction: 2025, functionality: fully functional, travel distance X-axis: 712 mm, travel distance Y-axis: 540 mm, travel distance Z-axis: 515 mm, rapid traverse X-axis: 36 m/min, rapid traverse Y-axis: 36 m/min, rapid traverse Z-axis: 36 m/min, controller manufacturer: Siemens und Heidenhain, workpiece height (max.): 400 mm, workpiece diameter (max.): 540 mm, workpiece weight (max.): 200 kg, total height: 3,360 mm, total length: 4,040 mm, total width: 2,770 mm, table load: 200 kg, rotary table diameter: 410 mm, spindle speed (max.): 12,000 rpm, coolant supply: 20 bar, number of spindles: 1, number of slots in tool magazine: 60, tool length: 280 mm, tool diameter: 76 mm, tool weight: 7,000 g, Equipment: chip conveyor, documentation/manual, Machine available with Siemens 828D Technical data 5-SIDE MACHINING • B/C-axis encoder • B-axis +30° to -120° • C-axis 360° • Media preparation table TOOL MAGAZINE CAPACITY • 60-position magazine (chain) • Tool diameter 76 mm • Tool length 280 mm • Tool weight 7 kg LARGE MACHINING AREA • Travel X: 712 Y: 540 Z: 515 • Swivel diameter 540 mm • Workpiece weight 200 kg • Workpiece size ⌀540 mm x 400 mm Iodpfx Afjzlhvhshoig USER-FRIENDLY DESIGN • Large work area doors • Short distance to the spindle • Good access to the machining area and tool magazine EQUIPMENT • CNC control Siemens 828D (15") or Heidenhain TNC 640 • MPG handwheel • 60-position tool magazine • 12,000 min⁻¹ (taper #40), coupling • Spindle cooler • Air blow-through through the spindle • 20 bar coolant supply • CAN filter for chip flushing/ring cooling • Automatic central lubrication system • Media preparation table (6 connections) • Glass scales X, Y and Z axis • Chip conveyor • Direct path measuring system C/B axis • Deublin rotary union • CE specification

Condition: new, Year of construction: 2026, P5 Retrofit CNC milling center for 5-axis machining of thermoformed parts. Working area (cube dimensions): X-axis: 600 mm Y-axis: 800 mm Z-axis: 400 mm, with a fixture height of 120 mm. All specifications are based on a tool length of 60 mm from the front edge of the collet nut. Max. shank diameter: 10 mm (ER16 mini collet). Table design: 1 piece aluminum flat table, size: 600 x 800 mm, with threaded bushings. Vacuum supply: 1 piece vacuum clamping circuit on the table, vacuum distribution pipe with 3 x quick-release couplings NW 7.2, digital pressure monitor. 1 piece vacuum pump, suction capacity approx. 40 m³/h. Milling spindle: 1 piece milling spindle (double spindle), air-cooled, 2 x ER16 mini collet chucks, power 2.5 kW, max. speed 27,000 1/min. Axis drives: Ball screw in the X / Y axis and Z axis; A / B axes with hollow shaft drives. Rapid traverse speeds X / Y axis => 45 m/min Z axis => 45 m/min Rotary / swivel axis => 12,000°/min. Acceleration (max.) => 2 m/sec² All axes are equipped with digital technology and absolute measuring systems. This eliminates the need for a reference run at the start of operation. Machine control: 1 piece BWO VEKTOR C Basic Plus Robot machine control. The complete unit is housed in an enclosure with a 15-inch capacitive touchscreen, which is mounted on the front of the machine. 64 MB NC memory USB interface Safety features: The machine is equipped with a robust sheet metal guard, with a separate access door for the rear of the machine; the guard is open at the top. 1 piece sliding door (manually operated), to demarcate the working area. Availability: The machine is operational and can be inspected immediately. Available from stock, delivery and installation can be arranged on short notice. Iodszzzrhopfx Afhjig Price on request, please request our offer.

Condition: like new (used), Year of construction: 2017, Horizontal machining center OKK Rotary pallet Type HM630 Year 2017 CNC Fanuc Series 310i-s model Chip conveyor Approximately 3 tool holders with ISO 50 mounting Iedpezr Iihofx Afhjig Tilting and forklift-compatible chip bin by GOUBARD Inspection points with shelves and illuminated fan Double-sided tool displays Buffer tank

Condition: good (used), Year of construction: 2002, Heckert CWK 400 D, year 2002, Siemens 840 D control, X/Y/Z travel 650/650/650 mm, 240-position tool changer, HSK 63 spindle taper, spindle speed up to 10,000 rpm, internal coolant supply 30 - 50 bar, NC rotary table Ø 460 mm, six-pallet changer 500 x 400 mm, chip conveyor, new spare spindle, 25 HSK holders. Iisdpfx Afjw Uf Hkshjg

Condition: used, Year of construction: 2010, operating hours: 2,000 h, functionality: fully functional, travel distance X-axis: 8,500 mm, travel distance Y-axis: 480 mm, travel distance Z-axis: 320 mm, nominal power (apparent): 8 kVA, workpiece length (max.): 8,500 mm, total height: 3,100 mm, total length: 11,500 mm, total width: 3,000 mm, rotational speed (max.): 15,000 rpm, overall weight: 6,000 kg, spindle speed (min.): 15,000 rpm, spindle motor power: 5,500 W, input voltage: 400 V, type of input current: three-phase, Equipment: documentation/manual, Elumatec SBZ 130 CNC 3-axis steel processing center, TOP condition Processes steel, stainless steel, aluminum, PVC, etc. The machine can mill, drill, tap, cut, and notch. All machining operations are performed while the profile is stationary. 8-position tool changer on a turret. Iijdpfx Aeziy Idefhjg Max. milling cutter diameter: 80 mm Max. disc cutter diameter: 200 mm Tools and accessories, including special wrenches, as shown in the picture. Tool holder: BT 30 Max. machining length: 850 cm, with stringer-side machining: 838 cm, y-axis: 48 cm, z-axis: 320 cm Year of manufacture: 2010, spindle speed: 15,000 rpm, spindle power: 5.5 kW Weight: approx. 6 tons. Includes laser and partition, protective mat, machining accuracy: x-axis, y-axis, z-axis +/- 0.1 mm Air consumption: approx. 75 liters, with spray nozzles. Inspection is possible by appointment. The machine is located in 91629 Weihenzell.

Condition: ready for operation (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 900 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 900 mm, controller manufacturer: Siemens, controller model: 840D Solutionline, spindle speed (max.): 10,000 rpm, coolant supply: 70 bar, spindle nose: HSK63, number of spindles: 1, number of slots in tool magazine: 60, Equipment: chip conveyor, documentation/manual, Hüller Hille NBH500 Condition: Functionally refurbished by the professionals at GSN Maschinen-Anlagen-Service GmbH (Pallet changer, guideways and ball screw drive, measuring system) Spare parts, repairs, modifications, retrofits, relocation, commissioning, and much more – all from a single source. Technical data and highlights: Pallet size: 500x500mm (Additional pallets available) Year of manufacture: 2013 Tool interface: HSK63 Control system: Siemens 840D Solutionline Main axes: X/Y/Z/B Spindle type: Motor spindle Spindle speed: 10,000 rpm Tool magazine: 60-position chain magazine Axis travels (X/Y/Z): 900/800/900mm Coolant: 600l coolant tank incl. chip conveyor Rotary table (B): NC type, 0.001mm Isdpfxszzqwge Afheig Options: Renishaw measuring probe, work area extraction, internal coolant supply 60 bar, 6-position hydraulic clamping system on the setup station.

Condition: used, Year of construction: 2004, travel distance X-axis: 630 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 670 mm, controller manufacturer: MORI SEIKI, controller model: MSX-501, table width: 500 mm, table length: 500 mm, table load: 500 kg, overall weight: 11,400 kg, Features a double pallet system, Mori Seiki MSX-501 control unit, but lacks the pallet lifting motor and the door guide. Workholding fixtures and tools are not included. Ijdpfxozxr U Ie Afhsig COLLECTION MUST TAKE PLACE BY SEPTEMBER 2026.

Condition: excellent (used), Year of construction: 2004, Year 2004 With 8 station Fastem pallet loading system with tombs Tooling & manuals 12,000rpm 40 ATC DIN40 / Renishaw probing Iijdpfx Aezxr Twjfheg Pallet size 400mm x 400mm

Condition: good (used), Year of construction: 2017, Traverses X Y Z: 1067mm x 610mm x 610mm, Table size 1270mm x 610mm, 600mm C axis Table (360 degrees) +/- 90-degree head (B axis), 37kW Spindle Motor, 40 station side arm ATC, din 40 spindle taper, 12,000rpm spindle, Hurco Winmax 5 control, Ijdpfezh Nczjx Afhsig through spindle coolant, swarf conveyor, spindle probe.

Condition: used, Year of construction: 2011, operating hours: 5,051 h, functionality: fully functional, machine/vehicle number: 20, travel distance X-axis: 730 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 800 mm, controller model: PRO 5, spindle speed (max.): 12,000 rpm, number of spindles: 1, number of slots in tool magazine: 60, Equipment: chip conveyor, documentation/manual, Makino A61nx, 4-axis horizontal machining center, fully functional and can be inspected while powered on. 11,324 hours of power-on time 5,051 hours of operating/runtime 3,253 hours of machining time 4,188 hours of spindle runtime A Travels  X-axis travel (frame) ..... 730 mm  Y-axis travel (spindle) ..... 650 mm  Z-axis travel (table) ..... 800 mm  Distance from pallet surface to spindle center ..... 80 ~ 730 mm  Distance from pallet center to spindle nose ..... 100 ~ 900 mm Iijdpfx Aszw Dzdofhsg  Linear guides, heavy-duty design, size (roller bearing) ..... #55  Size of ball screws (X, Y-axis / Z-axis) ..... #45 / #50 B NC rotary table (DD motor) C1 Spindle 14,000 rpm (240 Nm)  Tool holder ..... HSK-A63 D Feed drives  Rapid traverse speed ..... 60,000 mm/min  Feed speed ..... 1 ~ 50,000 mm/min  Feed speed (jog mode) ..... 1 ~ 8,000 mm/min Tool magazine  Storage capacity ..... 60 tools  Maximum tool diameter with space allocation ..... 170 mm  Maximum tool diameter without restrictions ..... 70 mm  Maximum tool length ..... 510 mm  Maximum tool weight ..... 12 kg Tool change time increases for tool weights over 8 kg.  Maximum imbalance relative to the gripper groove ..... 11.7 Nm  Maximum total weight of all tools in the magazine ..... 180 kg  Tool-to-tool change time (without door movement) ..... 0.9 s  Chip-to-chip time (ISO method) ..... 2.8 s  Tool ready time in the magazine (min./max.) ..... 3.1 / 6.1 s Drives  Main drive ..... AC15 kW  Feed drives (XYZ axes) ..... AC4 kW  Table (indexing table) ..... AC0.9 kW

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, Control system: Siemens 840D-SL Tool positions: 160 Tool holder: HSK 63 Spindle speed: 10,000 rpm / 242 Nm Pallet size: 630 x 500 mm Iedpfx Aszrl Dpsfhsig Number of pallets: 2 X-axis: 800 mm Y-axis: 800 mm Z-axis: 1000 mm Table load capacity: max. 1000 kg

Condition: used, Year of construction: 2012, machine/vehicle number: 51357, overall weight: 14,000 kg, No minimum price – guaranteed sale to the highest bidder! Ijdpfx Aezy Ui Rofheig The machines are still assembled but disconnected from the power supply. An 11-ton forklift is available on-site for loading. For sale is a horizontal machining center manufactured by Samag, model: SM. TECHNICAL DETAILS Type of machining: Internal machining MACHINE DETAILS Total weight: 14,000 kg

Condition: like new (used), Year of construction: 2014, Horizontal machining center OKK Rotary pallet Type HM6300S Year 2014 CNC Fanuc series 31i-model B5 60-tool magazine Chip conveyor Approximately 30 tool holders with ISO 50 connection Tilting and forklift-compatible chip bin from GOUBARD Iodezr Ih Depfx Afhsig Inspection points with shelves and lighting Double-sided tool display stands Buffer tank Aluminum structure platform

Condition: good (used), Year of construction: 2020, 5-axis CNC machining center - universal - Manufacturer: MAZAK Machine model: Variaxis J-500 Control system: Mazatrol SmoothG Year of manufacture: 2020 Number of controlled axes: 5 TECHNICAL DATA Travel ranges - X-axis: (mm) 350 - Y-axis: (mm) 550 - Z-axis: (mm) 510 - Swivel range A-axis: (degrees) -120 / +30 Iodjzr Uudjpfx Afhoig - C-axis (rotary and swivel table): (degrees) 360 Feed rate X/Y/Z: (mm/min) 8,000 Rapid traverse rates - X-axis (mm/min) 30,000 - A-/C-axis: 10,800 degrees/min Spindle - Spindle speed max.: (rpm) 12,000 - Drive power (ED) 100 / 40: (kW) 7.5 / 11.0 Tool magazine - Tool holder: BT40/CAT40 - Pull stud: Yamazaki ANSI type - Tool positions: 30 - Tool diameter: (mm) 90 - Tool length: (mm) 300 Machine table Swivel rotary table Pallet system - Pallet changer: 2-position - Clamping table dimensions: (mm) 500 x 400 Swivel rotary table - Rotary table diameter: (mm) 500 x 400 - Max. workpiece weight: (kg) 200 EQUIPMENT FEATURES + Internal cooling system 70 bar + Chip conveyor with scraper band + Oil mist extraction + Tool length measurement and tool breakage monitoring + Additional interior lighting + Signal light (3-color) Subject to changes and errors in the technical data and specifications.

Condition: used, Year of manufacture 1997 2 grid tables Working area X 3,900 mm Working area Y 1,600 mm Working area Z 200 mm Additional images available Isdpfxew Uf N Ss Afhjig

Condition: good (used), Year of construction: 2011, functionality: fully functional, Horizontal machining center MAZAK Model: HCN 6000 Year: 2011 Control unit: MAZATROL MATRIX 2 X-axis travel: 800 Y-axis travel: 800 Z-axis travel: 800 Table length: 500 Table width: 500 Maximum workpiece size (length x width x height): D.900 x H.1000 Table surface: Tapped holes Maximum workpiece weight: 1000 Spindle speed: 7000 Spindle connection: ISO 50 Torque (continuous / 10 min): 680 Nm Rapid traverse rate X-axis: 60000 Rapid traverse rate Y-axis: 60000 Rapid traverse rate Z-axis: 60000 Number of tools: 60 Maximum tool diameter: 250 Maximum tool length (from reference line): 500 Iiodpfx Aoz Apacsfheg Tool selection method: Fixed Maximum tool weight: 30 Kg Tool change time: 5 sec. Pressure: 50 BAR Height: 3350 Width: 2820 Depth: 6755 Weight: 14700 Tool kit included

Condition: used, Year of construction: 2018, functionality: fully functional, Standard configuration: Control and operation: • Control system: HEIDENHAIN TNC 640 - Handwheel: HEIDENHAIN HR510 - Swiveling control panel with two 19" monitors - 3 potentiometers (feed rate, rapid traverse, speed) - 3-color status indicator light - HEIDENHAIN DCM; collision monitoring between the machine and the tool Standard configuration: Machine: - Travel range, X-axis = 1,000 mm - Travel range, Y-axis = 1,100 mm - Travel range, Z-axis = 810 mm - NC rotary table 1,000 x 800 mm with T-slots 18H7 / 100 mm, driven by a pre-loaded worm gear drive - Swivel range 1,350 mm - Direct measuring systems on all axes, manufactured by HEIDENHAIN, connected to the pneumatic system - Micro-Epsilon "Spindle Growth System" for detecting and dynamically compensating for thermally induced spindle growth - Full enclosure with a large angled door for crane loading and a quick-access door - View windows in the working area made of laminated safety glass - Coolant nozzle - Oil collection pan made of chrome steel sheet - Leveling elements - Machine paint: Blue and light gray Milling head: - Automatic horizontal/vertical swiveling milling head as a full-fledged, stepless NC axis from -1° to +90° - Speed: 16,000 min-1 - Main drive: 38 kW (100% duty cycle) - Torque: 105 / 135 / 155 Nm (100% / 40% / 25% duty cycle) - Tool holder: HSK 63-A Coolant supply: - Internal coolant supply: 30 bar, Form A, paper band filter and high-performance filter with integrated chip extraction system - Milling head external cooling via nozzle ring Tool changer: - Rack magazine with 85 positions - 5-position tool loading station - Dialog-based operating panel Chip removal: - Scraper conveyor for chip removal at the front along the machine bed, chip discharge height 1,100 mm Documentation: - Acceptance test report for circularity test, laser inspection - Technical documentation in duplicate - CE declaration of conformity Milling head: Compressed air through the spindle center The compressed air can be selected via an M-function. Internal coolant supply with paper band filter: - Internal coolant supply with 80 bar (Form A) with 20 l/min, incl. paper band filter, coolant nozzle, and additional fine filter, particle size minimal 40 µm. Pressure regulation for each tool via tool table or a switch on the control panel during operation. Measuring probe and tool measurement: - Radio measuring probe BLUM TC60 incl. software adaptation, fully set up, incl. KinematicsOpt and calibration sphere on magnetic stand - TRS2 tool breakage detection system non-contact. Only suitable for tools with a solid core from 2 mm, e.g. drills, tapping drills. Additional machine options: - Oil and emulsion mist extraction Mechanical air filter 1,800 m3/h suction capacity - DXF converter - HEIDENHAIN AFC "Adaptive Feed Control" adaptive feed rate control - HEIDENHAIN ACC Iodpfx Ajzzp Tasfheig "Active Chatter Control" active chatter suppression

Condition: good (used), Year of construction: 2009, Ref. -No.: 10662 Manufacturer: STARRAG HECKERT Type: HEC 1250 Athletic Year of construction: 2009 Type of control: CNC Control: Siemens 840D Storage location: Halberstadt Country of origin: Germany Machine-No.: 221XXX X-Travel: 2200 mm Y-Travel: 1600 mm Z-Travel: 1850 mm Spindle Diameter: 100 mm Iodpfxjz Adt Rj Afhjig Max. Tool Weight: 35 kg Max. Tool Length: 800 mm Max. Tool Diameter: 250 mm Clamping Area: 1000 x 1250 mm Tool Piece Magazine With: 60 Pcs./pcs. Max. Torque: 25.000 Nm Turning Speed Range - Stepless: 40000 mm / min Rapid Traverse: 40 m / min Numbers Of Pallets: 2 pallet change time: 47 s Weight Of The Machine Ca.: 26,5 t Position uncertainty P: 0,008 mm Position deviation Pa: 0,006 mm Positional dispersion Ps: 0,005 mm Maximum table rotation: 10 RPM Further information: - Design: Thermally symmetrical column design with optimal chip flow for machining castings. - Applications: Mechanical engineering, energy technology, and the machining of large gearboxes and engine components. - Powerful motor spindle (up to approx. 82 kW, depending on the model) for heavy-duty machining. - The Heckert HEC 1250 Athletic (built in 2009) is a high-performance, modular 4-axis large-scale machine for the precise complete machining of heavy workpieces. The machine can be viewed while powered on by prior arrangement.

Year of construction: 2005, condition: excellent (used), functionality: fully functional, Number of controlled axes: 4, digital Iijdpszczwujfx Afhjg Axis X travel (longitudinal): 6500 mm Axis Y travel (transversal): 1095 mm Axis Z travel (vertical): 800 mm Axis A rotation (vertical rotation): 0° to 180°, continuous Maximum axis X speed: 80 m/min Maximum axis Y, Z speed: 64 m/min Maximum axis A speed: 10,000 °/min Electric spindle power in S1: 7.5 kW, 20,000 Maximum electric spindle speed with standard HSK-F Configurable, independent work areas on the axis 9-position tool changer Jaw positioning Number of standard stops: 4

Condition: excellent (used), Year of construction: 1987, functionality: fully functional, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,120 mm, Toshiba BMC80 with 4-axis control Year of manufacture: 1987 Iiedpfx Ajz Ahtnofhjg CNC control: Tosnuc Travel ranges: X = 1,600 mm, Y = 1,000 mm, Z = 1,120 mm 2 pallets, each 800 × 800 mm B-axis: 360° Max. table load: 2,000 kg Max. spindle speed: 4,500 rpm CAT 50 Automatic tool changer with 60 positions Renishaw Tool measurement

Condition: good (used), Year of construction: 2012, Ref. -No.: 10558 Manufacturer: YOU JI Type: HMC 1200 BP Year of construction: 2012 Type of control: CNC-Steuerung Control: FANUC Series 18i-MB Storage location: Halberstadt Country of origin: Taiwan X-Travel: 1800 mm Y-Travel: 1500 mm Z-Travel: 1360 + 990 mm B-Axis: 360 ° W-Axis: 700 mm Table Dimensions (Lengthxwidth): 1200 x 1400 mm Iodjxxpbxjpfx Afhsig Table Load: 5.000 kg Max. Tool Weight: 25 kg Max. Tool Length: 400 mm Max. Tool Diameter: 125 mm Spindle Speed: 30 - 3.500 RPM Numbers Of Pallets: 2 Further information: 4-axis simultaneous machining IKZ (internal spindle cooling) AKZ (external spindle cooling) Synchronized walking (rigid thread cutting) Renishaw RMP60 workpiece probe (radio) Number of pallet changers for automatic pallet change: 2 Size: 1200 x 1400 mm Tool magazine, number of tools: 60 The machine is currently in production and can be viewed by appointment.

Condition: good (used), Year of construction: 2008, Traverses X Y Z: 1020 x 550 x 560mm, Table 1250 x 660mm, workpiece load 1,000kgs Iodpfx Afeu Hyuaohjig Spindle speed 8,000 rpm, Spindle taper BT40, Spindle Motor 11kw, FANUC Oi-MC Control, 24 Station ATC, through spindle coolant.

Condition: good (used), Year of construction: 2013, Traverses X Y Z; 500 x 450 x 400mm, table size 630 x 500mm, table load 200 kgs, Isdpfezicmpex Afheig B axis -5/+110 degrees, C axis 360 (0.001 degrees), spindle speed 12,000rpm, spindle taper Iso 40, 30 station ATC, Siemens 840D control, swarf conveyor.

Condition: good (used), Year of construction: 2007, Horizontal machining center OKK Rotopalette Type HM500 Year 2007 CNC Fanuc Series 310 IS-model Tool magazine with 60 tools Chip conveyor Approximately 26 tool holders with ISO 50 connection Tilting and forklift-compatible chip bin, GOUBARD Inspection points with shelves and lighting, fan Tool displays, Iodpfxszr Ik Se Afhjig double-sided (60) Buffer tank
