Used Cnc Flat for sale (14,212)

Condition: ready for operation (used), Year of construction: 1991, functionality: fully functional, machine/vehicle number: 26BB2444, No minimum price – guaranteed sale to the highest bidder! MACHINE DETAILS Electrical Data Connection: 380 V / 50 Hz Iedjxliwyopfx Ag Neih Rated power: 10 kVA Fuse rating: 25 A Control voltage (AC): 220 VAC Control voltage (DC): 24 VDC EQUIPMENT Coolant tank

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, turning diameter: 320 mm, travel distance X-axis: 240 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 495 mm, bar passage: 51 mm, Lathe with LNS bar feeder & additional equipment! The machine has been completely inspected and geometrically measured by the seller. It is ready for immediate use! TECHNICAL DETAILS Travel X-axis: 240 mm Travel Y-axis: 100 mm Iiedpfjxg D Amsx Ag Njh Travel Z-axis: 495 mm Max. machining diameter: 320 mm Bar capacity: 51 mm Main spindle speed: 5,000 rpm Main spindle motor power: 22 kW Sub spindle speed: 5,000 rpm Sub spindle motor power: 22 kW MACHINE DETAILS Control: Mazatrol640T EQUIPMENT 2 x 12-station turrets with driven tools CNC option package EIA / ISO programming Tool eye Partition wall Automatic parts catcher with conveyor belt LNS short bar loader Quick Load Servo III High-pressure coolant 10 bar Chip conveyor Mayfran ConSep 2000 II

Condition: ready for operation (used), Year of construction: 2005, operating hours: 5,000 h, functionality: fully functional, turning length: 750 mm, turning diameter over cross slide: 250 mm, travel distance X-axis: 140 mm, travel distance Y-axis: 40 mm, travel distance Z-axis: 410 mm, TECHNICAL DETAILS Axis Travel X-axis travel: 140 mm Y-axis travel: +/- 40 mm Z-axis travel (1+2): 450 / 410 mm Turning Capacity Turning length: 750 mm Swing diameter over cross slide: 250 mm Turning diameter: 190 mm Distance between centers: 750 mm Maximum bar diameter: 52 mm Spindle Spindle speed (max.): 4,000 rpm Spindle bore: 91 mm Spindle bearing diameter: 95 mm Main spindle speed range: 60 - 6,000 rpm Main spindle drive power: 22 / 18.5 kW Maximum torque: 198 Nm Sub-spindle (B-axis) travel: 525 mm Feeds Feed rate X (1+2): 18,000 mm/min Feed rate Y: 6,000 mm/min Feed rate Z (1+2): 24,000 mm/min Feed rate B: 24,000 mm/min Turret Number of turrets: 2 Number of tool stations: 2 x 16 positions Square shank height: 20 mm Drill shank diameter: 25 mm Turret indexing time: 0.2 s Toolholder: VDI 30 Speed range - driven tool stations (max.): 6,000 rpm Drive power - driven tool stations: 5.5 / 3.7 / 2.2 kW Rapid Traverse Rapid traverse X (1+2): 18 m/min Rapid traverse Y: 6 m/min Rapid traverse Z (1+2): 24 m/min Isdpfx Agexgglke Njih Rapid traverse B: 24 m/min Rapid traverse C: 400 rpm MACHINE DETAILS Control: MSX 501 Dimensions & Weight Dimensions: 6500 x 3000 x 2500 mm Machine weight: approx. 5.1 t Total power requirement: 73.9 kVA Operating hours: 5,000 h EQUIPMENT LNS bar feeder

Condition: ready for operation (used), Year of construction: 2006, operating hours: 12,280 h, functionality: fully functional, machine/vehicle number: NL201FH1430, turning length: 510 mm, turning diameter: 356 mm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 260 mm, travel distance Z-axis: 590 mm, TECHNICAL DETAILS Turning diameter: 356 mm Turning length: 510 mm Swing diameter: 755 mm Standard turning diameter: 275 mm Bar diameter: 65 mm Travel X-axis: 260 mm Travel Z-axis: 590 mm Spindle drive: 15 kW Spindle speed: 5,000 rpm Turret stations / with drive: 12/12 Rapid traverse - longitudinal/flat: 30 m/min MACHINE DETAILS Control: MSX 850 3 Electrical Data Phases: 3 Frequency: 50 Hz Voltage: AC 200 V Rated current: 110 A Rated spindle motor current: 131 A Total power requirement: 32 kW Dimensions & Weight Installation space: approx. 2,320 x 1,783 x 1,819 mm Machine weight: approx. 5.8 t Operating Hours Spindle hours: 12,280 h Machining hours: 13,579 h EQUIPMENT Chip conveyor Extraction unit Tool setting arm Parts catcher Iodexhf Efopfx Ag Noih Double foot switch

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 15135, grinding length: 800 mm, grinding width: 600 mm, grinding height: 500 mm, grinding wheel diameter: 400 mm, control type: NC control, TECHNICAL DETAILS Control: NC Ergomatic Grinding length: 800 mm Grinding width: 600 mm Grinding height: 500 mm Grinding wheel diameter: 400 mm EQUIPMENT Iiedpfxjxl Sifj Ag Neh Electromagnetic chuck Coolant purification system

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: AH00000267, overall weight: 3,000 kg, Equipment: CE marking, MACHINE DETAILS Electrical Data Rated voltage: 400 V Rated current: 37.5 A Frequency: 50 Hz Weight: 3,000 kg Iijdpfx Agexmguxs Njh EQUIPMENT CE marking

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, turning length: 900 mm, turning diameter: 300 mm, spindle bore: 86 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 270 mm, controller model: FANUC 31i-B, TECHNICAL DETAILS Swing diameter over bed: 780 mm Swing diameter over slide: 700 mm Maximum turning diameter: 300 mm Maximum turning length: 900 mm Bar capacity: 76 mm Spindle Chuck size (main/sub-spindle): Ø254 mm Spindle bore (main/sub-spindle): Ø86 mm Spindle speed: 4,000 rpm Spindle motor (max./continuous): 26 / 15 kW Spindle drive: integrated motor Spindle flange: A2–8 C-axis indexing: 0.001° Travel axes X1/X2 axis: 270 / 190 mm Z1/Z2 axis: 920 mm Y axis: ±120 mm Rapid traverses Iiodpjxltbcsfx Ag Noh Rapid traverse speed X/Y/Z axes: 24 / 24 / 24 m/min Rapid traverse speed ZB axis: 12 m/min Guideway system: Box Guide Turret Tool stations: 2 × 12 External tool size: Ø25 mm Internal tool size: Ø40 mm Indexing time: 0.2 s/step Turret system: Wedge type Driven tools Motor power (max./continuous): 5.5 / 2.2 kW Tool speed: 4,000 rpm Collet size: Ø20 ER32 Tool type: BMT65 MACHINE DETAILS Control: FANUC 31i-B Tank and supply system Coolant tank: 230 l Lubrication tank: 8 l Electrical data Power consumption: 69 kVA Line voltage: 220 / 400 V Dimensions & weight Dimensions (L × W x H): 3,670 × 2,170 x 2,601 mm Weight: 11,000 kg EQUIPMENT LNS bar feeder

Condition: excellent (used), Year of construction: 2018, Model: Alpha 1550 XS Year: 2018 Control: FANUC Oi-TF Iiodpoxphwaefx Ag Nsh Swing Over Bed: 554mm Swing Over Cross Slide: 370mm Swing in Gap: 830mm Distance Between Centres: 2000mm Spindle Bore: 104mm dia. Spindle Speeds: 1 to 2000 RPM Machine with: Quick Change Toolpost Boring Bar attachment

Condition: new, Year of construction: 2019, machine/vehicle number: G3171-0100, This machine is only available to customers in the United Kingdom & Republic of Ireland HEAVY DUTY 3-AXIS SLANT BED, EXTRA LENGTH CNC TURNING CENTRE WITH C-AXIS & DRIVEN TOOLS, HARDENED & GROUND BOX GUIDEWAYS, BMT65 TURRET & 10" STANDARD CHUCK SIZE MACHINE CAPACITIES Swing Over the Bed - Ø 750 MM Swing Over the Carriage - Ø 480 MM Maximum Turning Diameter - Ø 410 MM Maximum Turning Length - 1,280 MM Bar Capacity - Ø 76 MM SPINDLE Chuck Size - Ø (10”) 254 MM Iodpfjhtq Abjx Ag Noih Spindle Bore - Ø 95 MM Spindle Speed (Rpm) - 3,500 RPM Motor (Max / Cont.) - 22.0 / 18.5 KW Torque (Max / Cont.) - 493.2 / 414.7 NM Spindle Type - BELT Spindle Nose - A2-8 C-Axis Indexing - 360° (0.001°) FEED Travel X - 290 MM Travel Z - 1,350 MM Rapid Speed (X) - 20 M / MIN Rapid Speed (Z) - 24 M / MIN Slide Type - HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools - 12 Tool Size (OD) - Ø 25 MM² Tool Size (ID) - Ø 50 MM² Indexing Time - 0.3 SEC / STEP LIVE TOOL Motor (Max / Cont.) - 5.5 / 3.7 KW Milling Tool Speed - 4,000 RPM Torque (Max / Cont.) - 35.0 / 23.5 NM Collet Size - Ø 20 – ER 32 Type - BMT65P TAILSTOCK Taper - MT 5 Quill Diameter - Ø 100 MM Quill Travel - 120 MM Travel - 750 MM TANK CAPACITY Coolant Tank - 270 L Lubricating Tank - 1.8 L POWER SUPPLY Electric Power Supply - 27 KVA Thickness of Power Cable - OVER 35 MM² Voltage 415 V / 50 HZ / 3PH MACHINE Floor Space (L x W) 4,171 X 2,002 MM Height 1,997 MM Weight 7,700 KGS FANUC 0IT CNC

Condition: used, Year of construction: 1996, MAZAK SUPER QUICK TURN 10 MS CNC LATHE MAKE MAZAK, MADE IN JAPAN MODEL SUPER QUICK TURM 10 MS YEAR 1996 CONTROL MAZATROL T PLUS MAX SWING 435mm SWING OVER CARRIAGE 370mm MAX. MACHINING DIA 230mm MAX. BAR WORK DIA 42mm MAX DISTANCE BETWEEN SPINDLES 705mm SPINDLE MOTOR AC11kw (15HP) SPINDLE SPEED 6000rpm 2ND SPINDLE MOTOR AC5.5kw (7.5HP) 2ND SPINDLE SPEED 6000 rpm ROTARY TOOL MOTOR AC2.2kw (3HP) ROTARY TOOL SPEED 3000 rpm TURRET TOOL CAPACITY 12 TOOLS STATIONS RAPID TRAVERSE RATE X,Z:30m/min (1180IPM),C: 400rpm MACHINE DIMENSION L x W x H, 2705mm x 1465mm x 1835mm MACHINE WEIGHT 3850kg PLUS C-AXIS Isdoxnpp Ijpfx Ag Nsih SUB SPINDLE DRIVEN TOOLS (3 NO.S) PARTS CATCHER SWARF CONVEYOR TOOL SETTING PROBE COLLET CHUCK BUILT IN TRANSFORMER FULL SET OF MANUALS GOOD WORKING ORDER

Condition: good (used), Ecoca MT-312/750 CNC Lathe FANUC 21iTB, 12″ Chuck, 2006 Year: 2006 Control: FANUC 21iTB Chuck Size: 12″ (305 mm) – 3-Jaw Swing Over Bed: 600 mm Swing Over Cross Slide: 330 mm Max Turning Diameter: Over Bed: 450 mm (17.7″) Over Cross Slide: 330 mm (12.99″) Z-Axis Travel (Turning Length): 730 mm (28.74″) Spindle Power: 24.8 HP (18.5 kW) Spindle Speed: Up to 3,200 RPM Tool Turret: 12-station Iiedjxpnl Dopfx Ag Njh Tailstock: Included Tool Arm: Included

Condition: ready for operation (used), Year of construction: 2019, functionality: fully functional, machine/vehicle number: AA100001570, travel distance Z-axis: 180 mm, table width: 1,620 mm, table length: 5,510 mm, rapid traverse X-axis: 56 m/min, rapid traverse Y-axis: 56 m/min, TECHNICAL DETAILS Processing table dimensions (L x W): 5,510 x 1,620 mm Z-axis travel distance: 180 mm Maximum vectorial rapid traverse speed X/Y-axis: 56 m/min Spindle unit speed: 4,000 rpm Tool changer slots: 44 Connection diameter: 250 mm MACHINE DETAILS Dimensions & Weight Dimensions: 9,700 x 5,020 x 2,650 mm (LxWxH) Net weight: 5,000 kg Spindle unit motor power: 5.5 kW Air consumption: 4,430 m³/h Air velocity: 25 m/s Voltage: 400 V / 50 Hz EQUIPMENT PRO-Speed safety system TEPCAD control panel with touchscreen color display Linear tool changer TBR14 Linear tool changer FAST14 Air blower on the electrospindle XY-axis safety guard Vacuum pump 150/300 m³/h 5-axis unit ‘JQX’ version 13.5 kW Fixed pedestal: 145 x 145 H=75 mm Rotatable gondola: 145 x 55 H=75 mm Clamp for 8 rails TV FLEX / TV FLEXDRIVE / TV FLEXMATIC MULTIGRIP 90 round clamp (H83) for TV FLEX / TV FLEXMATIC Iedpfxexmgr Rj Ag Noih Maestro connect 1 year (including Gateway Kit plug & play) SCM DIGITAL SOLUTIONS: MAESTRO CONNECT MAESTRO ACTIVE software for human-machine interface (HMI) Maestro software for CNC programming Hardware key for Maestro CNC Advanced Maestro 3D module Additional key for Maestro CNC (USB connection) Windows 10 embedded 64-bit operating system Console with integrated PC eye-M PRO

Condition: used, machine/vehicle number: L2SIH0236, turning diameter over cross slide: 700 mm, turning length: 1,500 mm, spindle bore: 80 mm, Leadwell LTC 30 BPL, CNC Turning Centre with Fanuc OT Control, fitted with 300mm dia 3 jaw chuck Made in Japan, approx 700mm swing x 1500mm centre distance, spindle bore 80mm,  operators foot pedal, Serial Number L2SIH0236, swarf conveyor, Iedpfx Aew A Rqrjg Nsih

Condition: excellent (used), Year of construction: 2019, Model: Alpha 1460 XS Year: 2019 Swing Over Bed: 460mm Swing Over Cross Slide: 270mm Swing In Gap: 730mm Distance Between Centres: 1500mm Spindle Speeds: To 2200 RPM (Variable) Spindle Bore: 78mm Machine With: 300mm 3 Jaw Chuck 8 Station Indexing Turret (VDI 30) Various Tooling Iisdexphv Nopfx Ag Nsh

Condition: like new (used), Year of construction: 1987, Used Giddings and Lewis Model MC 50 Twin Pallet Horizontal Machining Centre with Live Spindle, 60 ATC and G&L 8000A Control System. Serial # 445-1052.Year of Manufacture: 1987 Machine Formerly Installed at Rolls Royce Plc In Derby UK. Immediately for Sale and now Located in Belgium where it can be Inspected. Spindle Diameter - 130 MM Spindle Taper - 50 ISO Spindle Travel (Z Axis) - 915 MM Spindle Speeds (4 Ranges) - 5 to 1500 RPM Isdpeu Dahnsfx Ag Nsih Main Motor - 30 HP Pallet Size - 1219 x 1245 MM Pallet Rotation Increments - 0.001 DEG (360,000 POSITIONS) Pallet Changer Max Load - 5000KGS Pallet Max Load Without APC - 9000 KGS Longitudinal Travel (W) - 1700 MM Vertical Travel Of Head (Y) - 1500 MM Cross Travel (X) - 1800 MM Feed Rates Per Minute - 1.00MM/MIN TO RAPID RATE Rapid Traverse Rate Per Minute (X And Y) - 4500 MM / MIN Rapid Traverse Rate Per Minute (Z And W) - 3000 MM / MIN Auto Tool Changer - 60 POSITIONS Electrical Supply - 415V, 3PH, 50HZ FEATURES AND EQUIPMENT High Pressure (25 Bar) Through Spindle Coolant, High Tolerance Machine. Accurate Machine which was well Maintained and Regularly Calibrated by Manufacturer. Renishaw Probing. Length - 11679 MM Width - 6502 MM Height - 4423 MM Weight - 40329 KGS

Condition: used, machine/vehicle number: 008139, X axis working area: 2500 mm Y axis working area: 920 mm Main Electrospindle power: 10.3 KW Iisdpfx Aew R R Ufog Noh Number of controlled axes: 3 axes Total number of drilling spindles: 15 Total number of tool changer positions: 4

Condition: excellent (used), Harrison Alpha 1550 XS Manual / CNC Lathe Year: 2018 Control: FANUC Oi-TF Swing Over Bed: 554mm Swing Over Cross Slide: 370mm Swing in Gap: 830mm Distance Between Centres: 2000mm Spindle Bore: 104mm dia. Spindle Speeds: 1 to 2000 RPM Iiodpexpnk Tofx Ag Neh Quick Change Toolpost Boring Bar attachment

Condition: good (used), Year of construction: 2015, Swing over bed 720mm, maximum machining diameter 420mm, maximum machining length 1274mm, bar capacity 77mm, Iedjvgz D Espfx Ag Njih spindle speed 4,000rpm, milling speed 4,000rpm, 12 station turret, Mazatrol smart control, swarf conveyor, parts catcher, tool setter, and 3 jaw chuck, magazine barfeed unit.

Condition: used, Year of construction: 1989, Studer Type S40-4 CNC Cylindrical Grinder with Studer Siemens Control, Centre Height 225mm, Centre Distance 1600mm, Wheel Head Slide Max Travel 275mm, Marpass E39 Gauge, Wheel Size 400mm x 80mm x 127mm, Speeds 2 100rpm, Filter Mist. S/No. 7234.22 (1989). Country of Origin: Switzerland Ijdpfx Agjxnlg Ne Nsih A charge of £750 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser. Please Note: This lot is located in Birmingham, UK

Condition: good (used), Year of construction: 2006, functionality: unexamined, machine/vehicle number: 784, Machine Name - CMZ Machine Model - TL25 Y.O.M 2006 S.N 784 Description - Control Fanuc 31i Chuck size 250mm Swing 400mm 76mm spindle bore Max.turning diameter 676mm 12 Station turret Live tooling Sub spindle Swarf conveyor Tool setting probe Iiedpsv A Ey Aofx Ag Noh Gantry loader Manuals

Condition: excellent (used), Year of construction: 2010, Used Hankook model 7NB x 4000 2 axis CNC lathe Year 2010, serial number 41L09117 Manufacturer Hankook Country of Origin South Korea Model Protec 7NB x 4000 mm Machine Type Description 2 Axis CNC flat bed turning Centre CNC Control Fanuc 21- iT with MG-i MACHINE CONSTRUCTION & FEATURES  Heavy Cast iron Construction  Heavy Duty Hardened & Ground Solid Slideways  Large Spindle Bore  Full Length Rear Chip Guard  Automatic Lubrication to All Critical Areas MACHINE CAPACITIES Swing Over Bed Ø 750 mm Swing Over Carriage Ø 480 mm Max. Turning Dia. Ø 750 mm Distance Between Centres 4,000 mm Load Capacity 3,000 Kg SPINDLE Spindle Bore Ø 176 mm Nose A2-11 Spindle Centre Taper MT #6 Spindle Speed 3 – 1,000 RPM Spindle Speed Range Manual 2 Step AUTOMATIC V8 TURRET Number of Tools 8 Holder Diameter Ø 60 mm Mechanism Electric FEEDS Rapid Traverse X 3 m/min Z 6 m/min Travel X 425 mm Z 2070 mm TAILSTOCK Taper/Diameter MT #6 Ijdpfx Aev Rqftog Neih Quill Diameter Ø 112 mm Max. Quill Travel 200 mm MOTORS Spindle 15/18 Kw X - Axis 1.2 Kw Z - Axis 3 Kw WEIGHT Weight 5,520 Kgs STANDARD MACHINE FEATURES • CNC System • Single Front Door • Coolant System • Foundation Bolts and Liners • Work Light • Work Light • Centre Sleeve MT #6 x Taper 1/10 • Tool Box • Centre MT #6 • Full Length Rear Guard • Live Centre MT #6 STANDARD FITTED MACHINE OPTIONS • Fanuc 21-iT • Transformer for 415V, 3Ph, 50Hz HANKOOK 7NB x 4000mm with Fanuc 21-iTB Modified guarding for long boring bars 20” Chuck Steady rest 50 - 250mm Steady rest 250 - 450mm Algra Automatic 8 station Turret Boring Bar attachment 100mm diameter 60mm diameter boring bar toolholder (1 off) Inch Metric conversion Custom Macro B Additional Block Skip G Code System B/C Programmable Data Input Actual Spindle Speed Output tool offsets 32 Pairs Extended Part Program Edit Manual Guide i External i/o device control External data Input High Skip ADDITIONAL ACCESSORIES INCLUDED • Special Revolving Centre (TBC) • Marposs TT30 Removable Tool setting Arm • Short LNS swarf conveyor and coolant / swarf trays • Sandvik damped/tuned boring bar of size 100mm dia x 1500mm length supplied with the boring attachment. • Filtermist filtration • Additional door guarding.

Condition: used, Year of construction: 1996, MAZAK SUPER QUICK TURN 10 MS CNC LATHE MAKE MAZAK, MADE IN JAPAN MODEL SUPER QUICK TURM 10 MS YEAR 1996 CONTROL MAZATROL T PLUS MAX SWING 435mm SWING OVER CARRIAGE 370mm MAX. MACHINING DIA 230mm MAX. BAR WORK DIA 42mm MAX DISTANCE BETWEEN SPINDLES 705mm SPINDLE MOTOR AC11kw (15HP) SPINDLE SPEED 6000rpm 2ND SPINDLE MOTOR AC5.5kw (7.5HP) 2ND SPINDLE SPEED 6000 rpm ROTARY TOOL MOTOR AC2.2kw (3HP) ROTARY TOOL SPEED 3000 rpm TURRET TOOL CAPACITY 12 TOOLS STATIONS RAPID TRAVERSE RATE X,Z:30m/min (1180IPM),C: 400rpm MACHINE DIMENSION L x W x H, 2705mm x 1465mm x 1835mm MACHINE WEIGHT 3850kg PLUS C-AXIS Iisdpfx Agjxgnzms Neh SUB SPINDLE DRIVEN TOOLS (3 NO.S) PARTS CATCHER SWARF CONVEYOR TOOL SETTING PROBE COLLET CHUCK BUILT IN TRANSFORMER FULL SET OF MANUALS GOOD WORKING ORDER

Condition: ready for operation (used), sheet thickness steel (max.): 25 mm, back gauge: 1,500 mm, power: 66 kW (89.73 HP), total length: 3,390 mm, total width: 3,000 mm, total height: 3,500 mm, empty load weight: 25,000 kg, workpiece length (max.): 2,100 mm, CNC Elgo backgauge Iodpfxoxpkkie Ag Nsih Adjustable cuttingedge: 0,3 > 3°30"

Condition: good (used), Year of construction: 2010, Bar capacity 50.8mm, maximum cutting diameter 279mm, Isdpfx Agexlch Ss Neih maximum cutting length 274mm, Spindle power 11Kw, Spindle speed 6,000rpm, 12 station turret, fitted with collet chuck, tool setter and magazine barfeed unit.

Condition: ready for operation (used), Fanuc + 3 Breton machining centers Max longitudinal travel X-axe: 18 000 mm Iedpfx Agoxpkhuo Neih
