Used Cnc Turning Center for sale (22,828)

Condition: ready for operation (used), Year of construction: 2019, operating hours: 2,808 h, functionality: fully functional, machine/vehicle number: NL257181158, turning length: 705 mm, travel distance X-axis: 260 mm, travel distance Y-axis: 50 mm, travel distance Z-axis: 795 mm, swing diameter over cross slide: 742 mm, swing diameter over bed slide: 920 mm, New auction due to buyer's payment default! TECHNICAL DETAILS Working Area Swinging diameter over bed max.: 920 mm Swinging diameter over cross slide max.: 742 mm Turning length max.: 705 mm Bar capacity: 80 mm X-axis travel: 260 mm Y-axis travel: 50 mm Z-axis travel: 795 mm Main Spindle Power: 18.5/15 kW Speed max.: 4,000 rpm Chuck size: 10 inches Spindle bore: 91 mm Front bearing diameter: 140 mm Counter Spindle Power: 11/7.5 kW Speed max.: 4,000 rpm Chuck size: 6 inches Spindle bore: 45 mm Front bearing diameter: 85 mm Turret and Axes Tool stations: 12 Arbor cross-section: 25 mm Speed of driven tools max.: 10,000 rpm Rapid traverse X-axis: 30,000 mm/min Rapid traverse Y-axis: 10,000 mm/min Rapid traverse Z-axis: 30,000 mm/min Rapid traverse B-axis: 30,000 mm/min MACHINE DETAILS Control: M730UM with CELOS Dimensions & Weight Lodezck Txepfx Ac Ajrn Machine height: 2,000 mm Footprint: 3,347 x 2,106 mm Weight: 5,820 kg Operating hours: 2,808 h Power-on hours: 11,311 h EQUIPMENT Y-axis Counter spindle Main spindle with 10-inch chuck Counter spindle with 6-inch chuck Chip conveyor High-pressure coolant system Tool measuring device Parts catcher Workpiece ejector Interface for bar loader

Condition: ready for operation (used), Year of construction: 2005, operating hours: 60,683 h, functionality: fully functional, turning length: 1,524 mm, turning diameter: 820 mm, spindle speed (max.): 3,300 rpm, rapid traverse X-axis: 40 m/min, milling spindle speed (max.): 10,000 rpm, The following work was carried out on the machine: Repair/overhaul of the gearbox of the B-axis (2025) Complete maintenance (2025) Motor magazine renewed (2025) Replacement of the linear guides of the X and Y axes (2024) Renewal of the ball screws of the X and Y axes (2024) Repair of the milling spindle (2024) Lrodezcwylepfx Ac Asn Including approximately 120 tools, SK 50 TECHNICAL DETAILS Turning length: 1,524 mm Turning diameter: 820 mm Travel range, X-axis: 870 mm Travel range, Y-axis: 500 mm Travel range, Z-axis: 1,598 mm Main spindle Spindle speed (max.): 3,300 rpm Drive power of main spindle: 30 kW / 22 kW Max. torque of main spindle: 588 Nm Spindle nose of main spindle: A2-11" Spindle bore: 104 mm Indexing: 0.0001 Counter spindle Spindle speed (max.): 3,300 rpm Drive power of counter spindle: 30 kW / 22 kW Max. torque of counter spindle: 588 Nm Spindle nose of counter spindle: A2-11" Indexing: 0.0001 Milling spindle Drive power of milling spindle: 37 kW Max. torque of milling spindle: 260 Nm Milling spindle speed range: 0-10,000 rpm Rapid traverse, X-axis: 40 m/min Rapid traverse, Y-axis: 40 m/min Rapid traverse, Z-axis: 40 m/min MACHINE DETAILS Control system: Mazatrol 640M PRO Tool holder: SK50 Number of tool positions: 120 Operating voltage: 400 V / 50 Hz Connected load: 104 kVA Required installation area (L x W): 7 x 3.5 m Operating hours: 60,683 h EQUIPMENT Approx. 120 tools, SK 50 Variable speed adjustment Tool magazine, 120 positions High-pressure coolant, 70 bar Renishaw probe (new in 2025) Laser measuring system for rotating tools Interface set Air/water cooling through the spindle Overload monitoring system Chip conveyor, Mayfran Consep 2000 Quick-change tool holder, SMW

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, turning diameter: 460 mm, spindle speed (max.): 3,500 rpm, spindle bore: 86 mm, bar passage: 78 mm, controller model: Fanuc 32iTB iHMI, center width: 689 mm, CMZ turning and milling center including GL20II gantry loader! TECHNICAL DETAILS Turning diameter over bed: 760 mm Turning diameter over cross slide: 600 mm Maximum turning diameter: 460 mm Distance between centers: 689 mm Travel distance tailstock: 640 mm Travel distance X-axis: 310 mm Travel distance Z-axis: 640 mm Travel distance Y-axis: +70/-50 mm Travel distance B-axis: 640 mm Rapid traverse rates: 30/30/15/30 m/min Spindle speed max.: 3,500 rpm ASA 8" A2 Spindle bearing outer diameter: 200 mm Spindle bearing inner diameter: 130 mm Spindle bore: 86 mm Bar passage: 78 mm Number of tool stations: 12, all driven, 12,000 rpm Tool holder: 25x25 (50) MACHINE DETAILS Ljdpfxjzdrzxo Ac Aorn Operating hours: 43,712 h Total operating hours: approx. 35,000 h Control system: Fanuc 32iTB iHMI Dimensions & Weight Machine dimensions (L x W x H): 2,542 x 1,760 x 1,880 mm Machine weight: 6,500 kg EQUIPMENT Gantry loader

Condition: excellent (used), Year of construction: 2020, 2020 Vulcan TC250M CNC Turn/Mill Slant Bed Lathe With Fanuc Series Oi-TF Plus Control Auto Strong N-210 Ø250mm 3 Jaw Power Chucks. Swing Over Bed Ø600mm. Maximum Turning Ø316mm. Working Length 435mm. Spindle Bore Ø77mm. Bar Capacity Ø65mm. Axis Travel 'X'=185mm, 'Z'=490mm. Rapid Traverse 'X'=30m/min, 'Z'=30m/min. Cutting Feed Rate 0.001-500mm/rev. Speed Range 25-3,000rpm (11/15kW Motor). Spindle Nose A2-6. Driven Tool Speed Range 25-4,000rpm. Sauter 12 Position Turret, Turning Tool Shank 25 x 25mm. Internal Turning Tool Shank Ø40mm. Tailstock Travel 380mm, Quill Ø75mm, Quill Stroke 85mm, MT4 Taper. Run Hours 2,139. S/No. 25S1001 (2020). NOTE: This item will be loaded to buyer's vehicle, a loading charge of £250 + VAT will be added to the buyer's invoice. Lrodpfx Aezfqflsc Asn With Coolant System (190L Tank), Chip Conveyor, Filtermist S800 Mist Extraction Unit, Programmable Tailstock, Parts Catcher, Tool Setting Arm, Quantity Of Assorted Driven Tool Unit, Turning Tool Holders, Foot Switch, Signal Tower & Manuals. Overall Dimensions L3,160 x W1,805 x H1,935mm. Approx Weight 5,000kg. NOTE: This item will be loaded to buyer's vehicle, a loading charge of £250 + VAT will be added to the buyer's invoice.

Condition: excellent (used), Year of construction: 2018, 2018 Haas ST-25 CNC Slant Bed Lathe Ledpfxjzc Id Uo Ac Aern Samchully MH-212 Ø250mm 3 Jaw Power Chuck. Maximum Swing Ø806mm. Maximum Swing Over Cross Slide Ø527mm. Swing Over Tailstock Ø584mm Maximum Cutting (Varies With Turret) Ø381mm. Maximum Cutting Length (Without Workholding) 826mm. Bar Capacity Ø102mm. Distance Between Centre 762mm. Axis Traverses 'X'=318mm, 'Z'=660mm. Rapid Traverses 'X'=24m/min, 'Z'=24m/min. Spindle Bore Ø117.3mm. Maximum Spindle Speed 3,200rpm (29.8kW Motor). Spindle Nose A2-8. 12 Station Turret. S/No. 3112177 (2018). With Coolant System (Tank Capacity 208L), Tool Setting Arm, Tailstock, Jorgensen Chip Conveyor, Footswitch & Signal Tower.

Condition: excellent (used), Year of construction: 2017, Maximum turning diameter 300mm, maximum turning length 510mm, spindle speed 6,000rpm, milling speed 6,000rpm, sub-spindle speed 6,000rpm, main spindle bar capacity 42mm, 2 X 12 station turrets, spindle power 11Kw, Lredpfozcy S Rjx Ac Asn Y axis + /- 32mm, swarf conveyor, coolant., Fanuc OI-TF. barfeed unit.

Condition: good (used), Year of construction: 2015, Maximum turning diameter 255mm, distance between collet chucks 639mm, swing over bed 270mm, spindle speed 4,000rpm, milling speed 6,000rpm, sub-spindle speed 5,000rpm, main spindle bar capacity 66mm, sub spindle bar capacity 52mm, 3 X 12 station turrets, Ledpszcy Ilofx Ac Ajrn spindle power 15Kw, Y axis + /- 40mm, swarf conveyor, coolant., Fanuc 31i.

Condition: used, Year of construction: 2000, Hardinge VMC 600 II CNC Vertical Machining Centre with Fanuc Series O-MD CNC Control, Table Size 750mm x 500mm, 20 Tool ATC, BT40 Spindle Taper, Manuals & BT40 Spindle Tools. S/No. NVAAOF0060 (2000) Location: This lot is located in Burton on Trent, UK. A charge of £300 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser. Ljdpfx Aozdtkhoc Ajrn

Condition: good (used), Year of construction: 2012, maximum machining diameter 380mm, maximum machining length 508mm, bar capacity 74mm, spindle speed 4,000rpm, spindle power 18.5Kw, milling speed 4,500rpm, Lredjzaz Uzjpfx Ac Aon milling power10Kw, sub-spindle speed 6,000rpm, sub-spindle power 5.5Kw, Y axis -51/+51mm, 12 station turret, Mazatrol Matrix Nexus control, swarf conveyor, parts catcher , tool setter, 3 jaw chuck and Barfeed unit.

Condition: ready for operation (used), Year of construction: 2010, operating hours: 5,002 h, functionality: fully functional, machine/vehicle number: NT100JG0126, turning length: 424 mm, turning diameter: 370 mm, travel distance X-axis: 380 mm, bar passage: 52 mm, controller model: FANUC FS-31iA5 (MAPPS 4), TECHNICAL DETAILS Turning length: 424 mm Maximum turning diameter: 370 mm (270 mm with turret 2) Bar capacity: 52 mm Turning-milling spindle Full indexing capabilities: Yes X-axis travel: 380 mm Y-axis travel: ± 105 mm Z-axis travel: 460 + 155 mm (ATC) B-axis: ± 120º Spindle speed: 12,000 rpm Drive power: 9/5.5 kW Tool magazine Number of magazine positions: 38 Tool holder: Capto C5 Maximum tool length: 250 mm (210 mm for tools under Ø70 mm) Maximum tool diameter: 70 mm / Ø130 mm (with/without adjacent tools) Maximum tool weight: 5 kg Lower turret X-axis travel: 155 mm Z-axis travel: 610 mm Ljdpfx Acezf H Ezj Asrn Number of tool slots: 10 Tool speed: 6,000 rpm Drive power for driven tools: 1.5/1.2 kW Main spindle Spindle speed: 6,000 rpm Drive power: 11/7.5 kW Spindle bore: 73 mm Chuck type: Hollow chuck (8") Manufacturer: KITAGAWA Spindle nose: JIS A2-5 Maximum torque: 223 Nm Counter spindle Spindle speed: 1,000 rpm B-axis: 4 fixed positions, 0º, -30º, -180º (-225º for overhang onto conveyor, if available) MACHINE DETAILS Control: FANUC FS-31iA5 (MAPPS 4) Potential rated power: 39.24 kVA Dimensions & Weight Dimensions (L x W x H): 2,705 x 2,425 x 2,385 mm Weight: 8,800 kg Operating Hours Power on: 54,061 h Spindle 1 operating hours: 9,813 h Spindle 2 operating hours: 5,002 h EQUIPMENT Chip conveyor Signal lamp High-pressure pump Air blow nozzle outside the spindle Foot switch (dual) for main and counter spindle

Condition: good (used), Year of construction: 1999, - Control system: Heidenhain CNC Pilot 3190/4290 - Turn-Plus software update - Turning diameter: 500 mm - Turning length: max. 635 mm - Spindle speed: 25-5000 rpm Lrodpfxjzggahj Ac Asn - 12-station turret, no driven tools - Tool holder VDI 30 - Tailstock - Chip conveyor

Condition: good (used), Year of construction: 1989, operating hours: 64,136 h, Centre height: 350 mm Turning length: 1000 mm Max. swing diameter over bed cover: 600 mm Max. swing diameter over cross slide: 360 mm Spindle bore: 107 mm Speed range: 16 – 3150 rpm Feed range longitudinal & face: 0.5 – 5000 mm/min Rapid traverse longitudinal & face: 9 m/min Main drive: 30 kW Dimensions of machine with chip conveyor (L x W x H): 5400 x 2200 x 2000 mm Weight: 6400 kg Accessories / Special features: • CNC control GILDEMEISTER EPL 2 with TFT display Lredpjvr Eh Ejfx Ac Ajn General description: CNC manual input control system with program entry via function and numeric keypad. All information is entered in dialogue with the screen. Integrated menu technology with plain text display of all functions. Operator keypad, display, and electronic handwheel located within a separate chip guard housing. The EPL control offers the following capabilities: • Direct interactive program entry and editing by the operator through the EPL control without manual technological preparation • NC programs in ISO/EIA format can be entered, output, or manually keyed in via the RS 232 serial interface Machining cycles: • Removal cycles for longitudinal, facing, and contour turning, including with allowance • Thread cutting • Undercuts as per DIN 509-Form E and F and DIN 76; grind stock programmable • Axial and radial grooves as per DIN 471 and 472, including bottom finishing • 90° radii and 45° chamfers • Automatic cutter radius compensation for cycles, undercut, groove, radius, chamfer Programming: • Block-orientated, metric/inch, diameter for absolute entry, radius for incremental entry • Full circle programming, subroutine technology, hide levels for program sections, zero point offset, mode selection via menu Program entry and output: • Interactive via guided menu or direct in dialogue • Hydraulic 3-jaw chuck Ø 315 mm with through spindle bore Ø 80 mm • Hinged chip conveyor • 12-position tool turret VDI 40, 6 standard stations + 6 driven tool stations • Coolant system • RS 232 interface • Electronic handwheel • Electric foot switch for 3-jaw chuck and tailstock quill • Lighting • 12 various standard toolholders (to be finalized on site) Overhauled servo drive for main spindle, 06/2025 Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, turning length: 500 mm, turning diameter over cross slide: 290 mm, spindle speed (max.): 5,500 rpm, spindle bore: 73 mm, travel distance X-axis: 210 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 550 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 22 m/min, rapid traverse Z-axis: 30 m/min, rotational speed (max.): 6,000 rpm, chuck outer diameter: 225 mm, swing diameter over cross slide: 290 mm, spindle nose: FL 140h5, overall weight: 4,300 kg, Equipment: documentation/manual, rotational speed infinitely variable, A complete DMG MORI CTX alpha 500 V6 model, fully equipped! This machine features a C-axis, powered tooling, Y-axis, sub-spindle, and more. We acquired this machine in working order from production, and it can be inspected in working condition by appointment. Additional options & accessories: - Band filter system including high-pressure pump - DMG CELOS software - 3-jaw chuck (SMW Autoblok KNCS-N-225-66) on the main spindle - 3-jaw chuck (SMW Autoblok KNCS-N-170-43) on the sub-spindle - Chip conveyor - Coolant gun - Various VDI-30 tool holders (6 powered, 4 static) - Original DMG mist extraction system - All original documentation Ledpfx Acozc Nlao Asrn Weight & dimensions: 4,300 kg 4066x2583x1829 mm (LxWxH)

Condition: as good as new (ex-display), Year of construction: 2025, functionality: fully functional, turning length: 520 mm, turning diameter over cross slide: 360 mm, turning diameter: 310 mm, spindle speed (min.): 60 rpm, spindle speed (max.): 4,200 rpm, spindle bore: 73 mm, travel distance X-axis: 210 mm, travel distance Z-axis: 610 mm, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 24 m/min, total height: 1,880 mm, total length: 2,852 mm, chuck outer diameter: 210 mm, total width: 1,722 mm, collet bore: 73 mm, spindle nose: KK6, overall weight: 4,300 kg, Equipment: documentation/manual, rotational speed infinitely variable, The machine is new and has only been used for demonstrations up to now; it has not yet produced any chips. Lodpfx Ajzcplyoc Aern The machine is set up and operational, and can therefore be inspected. Additional options & accessories: - Preparation for a bar feeder. - Tool measuring arm. - Chip conveyor (available upon delivery, not currently included). - 10 bar high-pressure coolant pump. - Rohm KFD-HE 210/3-KK6 3-jaw chuck. - Approx. 9 VDI-30 tool holders (7 static, 2 powered).

Condition: used, Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle Ljdpfxszfni Ie Ac Asrn with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: excellent (used), functionality: fully functional, Fixed tool holders Machine: MORI SEIKI SL2000 Turret manufacturer: SAUTER ---- Lodsynb E Nopfx Ac Aern 2x→ No. 444-119 Turning Tool Holder 25 mm steel holder Fixed turning tool holder Price: on request ----- 1x→ No. 444-201 Double Turning Tool Holder for main spindle and sub spindle with 1x clamping bar for 25 mm tool steels Fixed turning tool holder Price: on request ----- 1x→ No. 444-210 Boring Bar Holder Cylindrical mount ø 32 mm second mount ø 32 mm; 57 mm to the rear Price: on request ----- 1x→ No. 444-205 Turning Holder Mount 25 mm steel holder Price: on request

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD2200Y FANUC 0IT PLUS CNC LATHE WITH Y AXIS. MACHINE CONSTRUCTION & FEATURES ▪ ONE PIECE HEAVY DUTY CAST IRON BED CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ 4,000 RPM MAIN SPINDLE. ▪ 6,000 RPM LIVE TOOLING SPEED. ▪ HEAVY DUTY CUTTING WITH EXCELLENT PERFORMANCE. ▪ WEDGE TYPE Y-AXIS. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET - BMT55P ▪ HARDENED & GROUND BOX GUIDEWAYS Swing Over the Bed Ø 820 MM Swing Over the Carriage Ø 650 MM Maximum Turning Diameter Ø 300 MM Maximum Turning Length 610 MM Bar Capacity – Main Spindle Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” - 203 MM Spindle Bore Ø 76 MM Spindle Speed (Rpm) 4,000 RPM Motor (Max / Cont.) 18.5 / 15.0 [22.5 / 15.0] KW Torque (Max / Cont.) 206.2 / 125.4 [215.0 / 143.3] NM Spindle Type BELT Spindle Nose A2-6 Travel X 215 MM Travel Y 110 (± 55) MM Travel Z 680 MM Rapid Speed X 24 M / MIN Rapid Speed Y 10 M / MIN Rapid Speed Z 30 M / MIN HARDENED & GROUND BOX GUIDEWAYS Ljdpfx Aox Th Nyoc Ajrn Number of Tools 12 [24] Tool Size - OD 25 MM² Tool Size - ID Ø 20 MM Indexing Time 0.2 SEC / STEP Y-Axis Type WEDGE TYPE LIVE TOOL Motor (Max / Cont.) 5.5 / 3.7] KW Milling Tool Speed 6,000 RPM Torque (Max / Cont.) 52.5 / 26.5 NM Collet Size Ø 16 – ER25 Type BMT-55P TAILSTOCK Taper MT 4 Quill Diameter Ø 80 MM Quill Travel 120 MM Travel 680 MM TANK CAPACITY Coolant Tank 200 L Lubricating Tank 2.0 L Electric Power Supply 27 KVA Thickness of Power Cable OVER 25 MM² Voltage 415 V / 50 HZ / 3PH Floor Space (L x W) 3,380 x 1,800 MM Height 1,950 MM Weight 4,700 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CHIP - BUCKET STANDARD CHIP - CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 6.0 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE 30 KVA TRANSFORMER AND CABLE QUICK TOOL SETTER - AUTO PROGRAMMABLE TAILSTOCK IN LIEU OF STD TURRET UPGRADE - 12 STATION 24 POSITION BMT55P, LIVE TOOLS 6K RPM, 5.5 KW STANDARD FACTORY FITTED MACHINE OPTIONS SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) FRONT DOOR INTERLOCK TOOLBOX STANDARD TOOLING PACKAGE QUILL TYPE TAILSTOCK WITH STD LIVE CENTER

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA HD3100YA FANUC 0IT PLUS CNC LATHE WITH Y AXIS MACHINE CONSTRUCTION & FEATURES ▪ ONE PIECE HEAVY DUTY CAST IRON BED CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ 3,500 RPM MAIN SPINDLE. ▪ 5,000 RPM LIVE TOOLING SPEED. ▪ HEAVY DUTY CUTTING WITH EXCELLENT PERFORMANCE. ▪ WEDGE TYPE Y-AXIS. Ledjx Thu Nspfx Ac Aorn ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET – BMT55P ▪ HARDENED & GROUND BOX GUIDE WAYS MACHINE CAPACITIES Swing Over the Bed Ø 800 MM Swing Over the Carriage Ø 670 MM Maximum Turning Diameter Ø 420 MM Maximum Turning Length 760 MM Bar Capacity – Main Spindle Ø 81 MM MAIN SPINDLE Chuck Size Ø 10” - 254 MM Spindle Bore Ø 91 MM Spindle Speed (Rpm) 3,500 RPM Motor (Max / Cont.) 26.0 / 18.5 KW Torque (Max / Cont.) 734 / 522 NM Spindle Type BELT Spindle NoseA2-8 FEED Travel X265 MM Travel Y120 (± 60) MM Travel Z830 MM Rapid Speed X24 M / MIN Rapid Speed Y10 M / MIN Rapid Speed Z30 M / MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools12 Tool Size - OD25 MM² Tool Size - IDØ 20 MM Indexing Time0.2 SEC / STEP Y-Axis Type WEDGE TYPE LIVE TOOL Motor (Max / Cont.) 5.5 / 3.7 KW Milling Tool Speed 5,000 RPM Torque (Max / Cont.) 70/0 / 35.4 NM Collet Size Ø 16 – ER25 Type BMT-65P TAIL STOCK Taper MT 5 Quill Diameter Ø 100 MM Quill Travelb120 MM Travel b830 MM Voltage 415 V / 50 HZ / 3PH Floor Space (L x W) 3,630 X 1,910 MM Height 1,960 MM Weight 6,200 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CONVEYOR & CHIP BOX HELICAL INTERPOLATION FUNCTION HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO MAIN SPINDLE - 3,500 RPM, 26.0 / 18.5 KW, 734 NM BELT DRIVEN PROGRAMMABLE TAILSTOCK IN LIEU OF STD QUILL FORWARD / REVERSE CONFIRMATION DEVICE QUILL TYPE TAILSTOCK - MANUAL TYPE MT#5 100 MM DIA QUILL, 120 MM QUILL TRAV STANDARD FEATURES SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 10 INCH 3 JAW HYDRAULIC CHUCK CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE HYDRAULIC CHUCK PRESSURE INTERLOCK - MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) PART PROGRAM STORAGE - 2MB SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 180 LITRES FULL SPLASH GUARDING SYSTEM CALL LIGHT TOOLBOX TOOLING PACKAGE QUILL TYPE TAILSTOCK 12 STATION BMT65P SERVO TURRET, LIVE TOOLS 5,000 RPM, 5.5 KW, 47.0 NM

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA SE2200LY WITH FANUC 0i-T PLUS CONTROL CNC LATHE WITH Y AXIS. TURRET UPGRADE - 12 STATION 24 POSITION BMT45, LIVE TOOLS 6K RPM, 2.75 KW MACHINE CONSTRUCTION & FEATURES ▪ 8” STANDARD CHUCK SIZE. ▪ 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ HIGH PERFORMANCE ROLLER LM GUIDEWAYS. ▪ 12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET - BMT45. [24 POSITION OPTION] ▪ 4,500 RPM HIGH POWER MAIN SPINDLE. ▪ 30 X 36 M/MIN RAPID TRAVERSE RATES – X & Z AXES. ▪ C-AXIS SPINDLE & WEDGE TYPE Y-AXIS. Swing Over the Bed Ø 600 MM Swing Over the Carriage Ø 600 MM Maximum Turning Diameter Ø 300 MM Maximum Turning Length 508 MM Bar Capacity – Main Spindle Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” - 203 MM Spindle Bore Ø 75 MM Spindle Speed 4,500 RPM Motor (Max / Cont.) 15.0 / 11.0 KW Torque (Max / Cont.) 167 [150.3] NM Spindle Type BELT Spindle Nose A2-6 FEEDS Travel X 210 MM Travel Y 110 (± 55) MM Travel Z 560 MM Rapid Speed X 30 M / MIN Rapid Speed Y 10 M / MIN Rapid Speed Z 36 M / MIN Slide Type ROLLER LM GUIDEWAYS TURRET Number of Tools 12 [24 POSITION INDEX] Tool Size - OD 20 MM² Tool Size - ID Ø 32 MM Indexing Time 0.15 SEC / STEP Y-Axis Type WEDGE TYPE Milling Tool Speed 6,000 RPM Motor (Max / Cont.) 2.75 / 1.85 [2.8 / 3.8] KW Torque (Max / Cont.) 26.2 [27.0] NM Collet Size ER 20 - Ø 13 Type BMT45 HYDRAULIC NC TAIL STOCK (STD. LIVE CENTER) Taper MT#4 Quill Diameter Ø 56 MM Travel 580 MM Coolant Tank 200 L POWER SUPPLY Electric Power Supply 18 KVA Thickness of Power Cable OVER 16 MM² Voltage 415V / 50HZ / 3PH Floor Space (L x W) 2,960 X 1,730 MM Height 1,920 MM Weight 4,200 KGS Lrjdpfxjx Tqkme Ac Asn STANDARD FACTORY FITTED MACHINE OPTIONS SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3-JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC FOR STANDARD CNC SPECIFICATION - SEE MANUFACTURER'S BROCHURE HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) MANUAL VIEWER OPERATION MEMO PART PROGRAM STORAGE - 2MB (1,000 REGISTERABLE PROGRAMS) PREMIUM TOOL OPERATION SCHEDULING SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 200 LITRES FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (15 LITRES) CALL LIGHT (1 COLOUR) BACK SPIN TORQUE LIMITER FRONT DOOR INTERLOCK TOOLBOX MAIN SPINDLE - 4,500 RPM, 15.0 / 11.0 KW, 167 NM BELT DRIVEN STANDARD TOOLING PACKAGE - SEE MANUFACTURER'S BROCHURE HYDRAULIC TYPE NC TAILSTOCK - MT#4 56 MM QUILL, STD LIVE CENTER 12 STATION BMT45 TURRET, LIVE TOOLS 6K RPM, 2.75 KW, 26 NM INCLUDED FACTORY FITTED MACHINE OPTIONS CHIP - BUCKET STANDARD CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO QUILL FORWARD / REVERSE CONFIRMATION DEVICE

Condition: good (used), Year of construction: 2013, Main and counter spindle C-axis on main and counter spindle 2 x 12-position turret VDI 40 Y-axis Chuck flushing device Tool monitoring Brankamp Coolant system 980 liters with belt filter Conveyor belt Oil mist separator Chip conveyor Ljdpfx Aoy Ivyiec Aorn without bar feeder

Condition: used, Year of construction: 2000, max swing 700 mm, X/Y 255/520 mm, 12-position upper tool turret and 8-position lower tool turret with driven tools, measuring head, tailstock, CNC SIEMENS SINUMERIK 840D, 400V 50Hz 45kW, weight 15 t Lredpfxoym Sx Ds Ac Asn

Condition: excellent (used), Year of construction: 2019, CNC lathe DOOSAN Puma 2600SY II with Siemens control system; Thermal sensors for maximum precision; Y-axis; Subspindle with collet chuck; Spindle bore 80 mm (main spindle); All axes with box ways – suitable for heavy-duty machining; Chip conveyor, tool setter, parts catcher with belt, coolant gun, extraction system; 70 bar high-pressure coolant system; Various fixed and driven tool holders included; Ledjzggh Sopfx Ac Aern Robot loading by Halter available upon request! Photo attached. An automatic door can be retrofitted for this purpose. In Germany, complete commissioning upon request. All at additional cost!

Condition: like new (used), Year of construction: 2024, MAZAK QUICK TURN 200 MSY Max. machining diameter: 380 mm Max. machining length: 575 mm Max. milling speed: 5,000 rpm Max. spindle speed: 5,000 rpm Max. bar diameter: 65 mm Machine is equipped with: - CNC control: Mazatrol SmoothG -Hydr. KITAGAWA 3-jaw chuck BB-208 for main spindle, diameter 210 mm -Hydr. KITAGAWA 3-jaw chuck B-206 for 2nd spindle, diameter 169 mm Lrjdpfezgw Icex Ac Aen - Tool Eye - C-axis - C-axis counter-spindle, input accuracy 0.0001° - Y-axis - Interface for bar feeder - Autom. parts catcher - Robot interface - Reinforced coolant pump - MAYFRAN chip conveyor - 8 pcs. fixed tool holders - 2 pcs. driven tool holders

Condition: not inspected (used), Year of construction: 2001, operating hours: 31,782 h, functionality: unexamined, overall weight: 5,500 kg, Without tools Lrsdozbqg Njpfx Ac Aon

Condition: used, Year of construction: 2022, turning diameter 420 mm turning length 1350 mm spindle passage 101 mm control Siemens SL 828D ShopTurn number of controlled axis 4 turning speed range 3000 U/min power requirement 22/18,5 kW rapid speed 30 m/min number of tapers in turret head 12/24 BMT 65 number of driven tools in turret 12 BMT 65 Spindel speed of driven tools 5000 U/min Spindelpower on driven tool 7,5/5,5 kW y-axis +/- 65 mm tail stock MT-5 weight 8,0 t dimensions 5,7 x 2,3 x 2,32 m Heavy CNC- lathe with driven tools and Y- Axis in very good condition. Lrsdpfx Acjzfqf Sj Aon First instalation: 03/2023 Appr. 5400 h Power on. - 2x 3-jaw chuck Ø 325 + 400 mm - some fixed tool holders - Tool pre- setter - chip conveyor - 4x driven tool holders - 2 + 2 driven toolholders with Capto C4 - oildust collector - band filter system with appr. 1000 ltr. - hydr. steady moveable wit turret SMW Autoblock SLU-X3.1 (Ø 20- 165 mm) - 3 colour signal lamp - coolant gun - some jaws - external programming system MCS40501/2 - build in spindle
