Used Gildemeister Gmx for sale (234)

Condition: like new (used), Year of construction: 2001, Gildemeister NEF 320 K Cycle-Controlled Lathe Siemens Sinumerik 810 DL Control Year of Manufacture: 2001 Very Good Original Condition Technical Specifications: Year of manufacture: 2001 Swing diameter over bed: 320 mm Swing diameter over cross slide: 150 mm Centre distance: 750 mm Cross travel: 185 mm Feed X: 4 m/min Feed Y: 4 m/min Rapid traverse X: 8 m/min Rapid traverse Y: 10 m/min Spindle nose DIN 55027 size 6 Spindle bore: 52 mm Drive power (100%): 7 kW Speed range: 14–3550 rpm (2 ranges) Tailstock quill diameter: 70 mm Tailstock quill stroke: 120 mm Tailstock taper: ISO MK 5 Dimensions: 2600 x 1440 x 1440 mm Hnjdpfowx Rbpox Aadjh Machine weight approx.: 2.0 t Accessories and Equipment: About the Machine: Offered here is a Gildemeister NEF 320 K cycle-controlled lathe with cycle control, year 2001, in very good original condition. The machine is, of course, fully operational. The slides run very smoothly and evenly. Even at high speeds, the Gildemeister operates very quietly. This latest generation of lathes is very user-friendly and allows for surface finishes similar to grinding. The machine comes from a training workshop of a large industrial company. Take the opportunity to inspect this machine under power on site and convince yourself of its condition.

Condition: ready for operation (used), Year of construction: 2008, operating hours: 20,130 h, functionality: fully functional, machine/vehicle number: 02260008351, turning length: 600 mm, turning diameter: 324 mm, travel distance X-axis: 185 mm, travel distance Y-axis: 40 mm, travel distance Z-axis: 620 mm, No minimum price – guaranteed sale to the highest bidder! The payment deadline for the machine is November 20, 2025! Placing a bid obligates you to collect the machine within the scheduled collection period between December 1, 2025 and December 5, 2025! TECHNICAL DETAILS Turning length: 600 mm Swing diameter: 324 mm Travel X-axis: 185 mm Travel Y-axis: 40 mm Travel Z-axis: 620 mm Rapid traverse X-axis: 4 m/min Rapid traverse Y-axis: 7 m/min Rapid traverse Z-axis: 7 m/min Spindle bore: 72 mm Spindle speed (max.): 5,000 rpm Bar capacity: 45 mm Counter spindle speed (max.): 7,000 rpm Counter spindle bore: 57 mm Number of magazine tool stations: 12 Hsdpsxm Sxisfx Aadenh Tool holder: VDI 40 Driven tool power: 12 kW Torque: 10.5 Nm Speed: 4,500 rpm MACHINE DETAILS CNC control: HEIDENHAIN iTNC 530 Dimensions & Weight Dimensions (L x W x H): 4,890 x 2,460 x 2,080 mm Total weight: 6,500 kg Operating Hours Spindle hours: 20,130 h Power-on hours: 50,305 h EQUIPMENT Documentation / manual 12 driven tools Tool package Belt filtration system Bar loader MKE HL 12 PN, year of manufacture 2008

Condition: good (used), Year of construction: 2001, Gildemeister NEF 520 CNC Lathe TECHNICAL DATA Working Area Swing over bed: 500 mm Swing over cross slide: 290 mm Chuck diameter: 250 mm Cross travel: 260 mm Center distance: 850 / 1350 mm Turning Spindle Spindle head DIN 55027 Size: 8 Spindle bore diameter: 70 mm Spindle mount: metric 80 Spindle diameter in front bearing: 120 mm Main drive AC Drive power: 12 kW Max. torque: 920 Speed range: 10 – 3000 rpm Gear ratios: 2 Switchable speeds: Continuously variable Feed drive Hjdpfewftviox Aadjnh X-feed force: 5000 N Z-feed force: 10000 N X-rapid traverse: 8 m/min Z-rapid traverse: 10 m/min Multifix tool carrier; Size: C Tailstock Quill diameter: 80 mm Quill stroke: 180 mm Quill mount: MK5 Dimensions L x W x H: 2900 x 1953 x 1825 mm Weight: 2700 kg SCOPE OF OFFER INCLUDES (list not exhaustive): Gildemeister lathe SMW Autoblok Hi-Grip high-precision chuck Chuck jaws Multifix tool holder Complete operating documentation Exact scope of offer as shown in the photo gallery We assume no liability for the accuracy, completeness, or timeliness of the information provided.

Condition: used, CNC control, Numeric Control, from MAX MÜLLER GILDEMEISTER MD 5S, type Eltropilot M Year of manufacture approx. 1980 Rack with 20 module slots – 12 modules installed Installed modules: 1 pc 0.651.406-19.3 UNI Universal Interface Hjdpfx Aeflrtxeadonh 1 pc 0.650.847-56.1 O32 Output Card 2 pcs 0.651.708-57.3 I32 Input Card 1 pc 0.652.138-36.1 APC 1 pc 0.651.928-25.3 LAB Axis Controller 1 pc 0.651.400-22.3 1 pc 0.860.204-59.1 B32 1 pc 0.652.128-35.0 RE4 1 pc 0.651.269-26.0 ITY Serial Interface 1 pc 0.651.974-23.2 ABS Termination Board 1 pc 0.651.298-18.3 CPU Central Processor Dimensions (W x H x D): 480 x 260 x 220 mm Weight: 7 kg Individual cards available on request.

Condition: used, Tool presetter GILDEMEISTER-DE VLIEG Type EGS 5045 / Microset DPS 100 Serial No. 83-10-102 Year of construction 2002 Travel distance X-axis approx. 400 mm Travel distance Z-axis approx. 400 mm Tool holder in mounted rotary table: Ø 50 mm Pitch circle diameter of the tool holders in the mounted rotary table Ø 340 mm Inner cone in the mounted rotary table Ø 245 mm Tool mounting plate as rotary table with 8 mounting holes Ø 50 mm Centering diameter of the mounted tool holder plate: Ø 102 mm Swivel-mounted flange holder with centering diameter: Ø 102 mm Swivel-mounted flange holder with outer diameter: Ø 155 mm Swivel-mounted flange holder with 3x M10 mounting holes, bolt circle: Ø 130 mm Mains connection 230 Volt, 50 Hz - Microset DPS 100 measuring electronics - Rotary table with 8 tool positions - Interfaces: 1x RS232, 2x measuring system (X/Z) - Profile projector with screen Ø 100 mm magnification 20x and two circular screens - Fixed focusing screen with crosshairs - Axis movement via manual quick adjustment with pneumatic clamping - Fine adjustment via hand wheels - Rotatable rotary table with pneumatic clamping - Metal substructure with 3 drawers Hnjdpfxshbal Ds Aadoh Space requirement L x W x H 1100 x 1000 x 800 mm Weight 400 kg good condition

Condition: good (used), Year of construction: 2006, Gildemeister Twin 42, Year of manufacture 2006, Siemens 840 D control, Turning length up to 210 mm, Spindle bore 56 mm, Main spindle, Hnedjwcyhtopfx Aadoh Counter spindle, 1 x Y axis, 2 x C axis, 2 12-station turrets / all stations driven, Shaft diameter 25 mm, Driven tools up to 6,000 rpm, FMB Turbo 10-72 loading magazine, Main spindle collet chuck, Counter spindle collet chuck

Condition: good (used), Year of construction: 1999, Machine has 12,300 operating hours Gildemeister NEF 320 / cycle lathe, Year of manufacture: 1999, Control: Manual Plus, Centre distance: 750 mm, Swing diameter over bed: 320 mm, Spindle speed up to 4,000 rpm, 2 gearbox stages, Multifix toolholder, Hnsdpew Rm Tdofx Aadoh Tailstock, 2 steadies, Accessories,

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, CNC Lathe Manufacturer: Gildemeister Model: CTX 420 linear V3 Year of Manufacture: 2003 Control Unit: Heidenhain Plus IT Swing diameter over bed: 680 mm Swing diameter over cross slide: 565 mm Hnjdpfoxc Uq Tsx Aadjh Cross travel: 260 mm Longitudinal travel: 635 mm Drive power (40/100%): 25/37 kW Speed range: 20 – 5000 rpm Weight approx.: 6500 kg Equipment: Driven tools: 12 stations Tool turret: 12-position Sauter turret VDI 30 Partly hollow clamping chuck Tailstock Automatic quill travel Quill taper: Mk 5 Chip conveyor Measuring arm Oil mist extraction unit Subject to prior sale and errors.

Year of construction: 1987, condition: used, machine/vehicle number: 7.0176, Note: We have 6 pieces of this machine in stock! Manufacturer: Gildemeister Type: GS 36 - 6 A/C Machine No.: 7.0176 Year of manufacture: 1987 Weight: 11t General / technical data: Portal-6Spindle automatic lathe spindle pitch circle: 300mm number of longitudinal slides: 6 number of cross slides: 2 large cross slide stroke: 60mm largest longitudinal slide stroke: 125mm Spindle speeds: Stepless 562 - 3373 rpm Main time range: Stepless 1,95 - 78 sec. Secondary time range: 0,79 - 2,13 sec. Drive power: DC motor spindles 20kW; feeds 8kW footprint: approx. 1720 x 4700mm Remark: The machine is not convertible for bar work. Equipment: - 1 creep feed drive for set-up operation - 1 automatic central lubrication device - 1 coolant device with pipes and pump - 1 cross slide, position 3 (without curves) - 1 cross slide, position 5 - 6 longitudinal slides (without drive, without curves) - Feed for independent longitudinal slide, flexible, position 1-6 - Programmable logic controller IPC 620 - Noise protection 80db - Automatic feed restart with electrical protection of the side door - Schanier belt chip conveyor Hnjdpoin Ub Tefx Aadeh - Design of the machines with DC drives for speed and feed - KIENZLE terminal 2450-07 with signal interface and data transmission control. Accessories: Electrical version: The electrical equipment consists of a DC main drive with power 20 kW for the spindle drive and a three-phase servo motor for the feed drive with power 8kW (protection class IP 54) and corresponding switchgear and control devices as well as the necessary installation. Total connection of the machine 32kW/h.

Condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 800 mm, travel distance Z-axis: 300 mm, TECHNICAL DETAILS Chuck diameter: 250 mm X-axis: 800 mm Z-axis: 300 mm Spindle Spindle head: 170 h5 Spindle diameter at front bearing: 120 mm Spindle bore: 79 mm Hedpfx Ajwrr T Toadonh C-Axis Number of tool stations: 12

Condition: used, Year of construction: 1996, turning diameter over bed 710 mm turning dia. over face-slide 420 mm turning length 2000 mm control Manual Plus 3110 Heidenhain spindle bore 92 mm main spindle speeds: 16 - 1800 U/min cross movement 385 mm spindle head DIN 55027 - Size 11 spindle diameter in front bearing 140 mm Hnsdpfx Aajxxmiysdeh power capacity at 100 % load 22,00 kW 2750 Nm feed x/z-axis 1 - 5000 mm/min rapid traverse X-axis 6,00 m/min rapid traverse Z-axis 8,00 m/min tailstock quill taper MT 5 quill stroke 210 mm diameter of quill 110 mm total power requirement 40,00 kW weight of the machine ca. 5,60 t dimensions of the machine ca. 5,00 x 3,00 x H2,50 m

Condition: ready for operation (used), operating hours: 31,819 h, turning diameter over cross slide: 290 mm, turning length: 600 mm, travel distance X-axis: 210 mm, travel distance Z-axis: 645 mm, rotational speed (max.): 5,000 rpm, - CNC lathe with EPL 2 control, equipped with round magnet. It was last used for fine contour turning of hardened components. (without chuck, tailstock and chip conveyor) Technical data Swing diameter over bed: 300 mm Swing diameter over face: 290 mm Travel path X: 210 mm Travel path Z: 645 mm Speed range: 25 - 5000 rpm Tool carrier: universal disk turret Tool positions: 12 Hnedpfx Aajqcu Uvjdjh Tool holder: 30 mm (DIN 69 880)

Condition: used, Year of construction: 2003, max. Spindle speed 5000 U/min. travel -x axis 160 mm travel -z axis 450 mm numbers of turret head positions 12 tool taper VDI 30 Control Heidenhain iT Plus Dimensions (L x W x H) 4,5 x 2,5 x 2,5 m weight of the machine 3700 kg CNC Turning- and Milling Center | DMG GILDEMEISTER - CTX 310 Additional equipment: - C-Axis Hsdpov Ehawefx Aadenh The machine is in good condition. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: CTX310 | CTX-310

Year of construction: 2008, condition: ready for operation (used), Control Unit Brand FANUC Model Fanuc 310 Hjdpox D Ekgofx Aadenh This 4-axis Gildemeister SPEED 32/10 linear was manufactured in 2008. It features a CNC Fanuc 310iS control, a main spindle with a bar capacity of 33 mm, and a maximum speed of 8,000 rpm. The machine offers robust multitasking capabilities with a total of 16 driven tool stations and a turret for efficient processing. If you are looking to get high-quality turning capabilities, consider the Gildemeister SPEED 32/10 machine we have for sale. Contact us for more information. Application Types Turning

Year of construction: 2002, condition: good (used), functionality: fully functional, 3 Main spindle with 70mm bar passage FUNCTIONS The raw bar is machined in spindle 1 and 2 with a 12-position star turret. At the same time, a 2-station front turret can work on this spindle (for drilling or internal boring). After machining, the drum cycles. The pre-turned part is finished in spindle 3 with a 12-position star turret and tapped. The part is then finished in the counter spindle and unloaded by the unloading gripper (monitoring available). The bar is retracted and the drum cycles. TECHNICAL DETAILS Bar passage: 70 mm counter spindle tool turret: 5 pieces, VDI30 (CNC cross slide) High pressure internal cooling: two turrets Measuring system: direct, high resolution in all X-axes Control system: Siemens 840 D Powerline tool monitoring: Artis Collet chuck: 4x Hainbuch SK65 Number of parallel tools: 5 Main spindle 1: Roughing of the turned part Tool holder: star turret with 12 positions Other: Possibility for additional work by 2-fold frontal turret Main spindle 2: Finishing of the turned part Tool holder: 12-position star turret Other: Possibility for finishing by 2-fold frontal turret Main spindle 3: Finishing, parting and backworking of the turned part Tool holder: star turret with 12 positions Hnodjn Uum Hjpfx Aadeh EQUIPMENT Bar feeder for 1500mm long bars

Condition: repair required (used), Year of construction: 2011, operating hours: 8,545 h, functionality: not functional, turning length: 310 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 190 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 370 mm, mount diameter: 30 mm, Condition: Non-functional. The machine has an unknown malfunction in the turret, making referencing and axis movement impossible. The machine requires repair! TECHNICAL DETAILS Turning length: 310 mm Swing diameter over bed: 500 mm Swing diameter over cross slide: 290 mm Distance between centers: 500 mm X-axis travel: 190 mm Z-axis travel: Z1: 335 / Z3: 370 mm Y-axis travel: 80 mm Control: Heidenhain CNC Pilot 4290 Spindle speed: 6,000 rpm Spindle bore: 73 mm Bar capacity: 50 mm Main spindle torque: 95 Nm at 100% and 127 Nm at 40% Hsdpow T Srdjfx Aadsnh Tool turret - number of stations: 12 Tool holder: VDI 30 mm Rapid traverse X + Z axes: 30 m/min MACHINE DETAILS Total power requirement: 20 kVA Chip conveyor dimensions (LxWxH): 3.2 x 0.45 x 1.5 m Operating hours (on-time): 36,443 h Spindle hours: 8,545 h Interface: yes EQUIPMENT - 160 mm 3-jaw chuck with matching flange - 2 sets of spare jaws - 12-station turret with driven tooling - Sauter disc turret (C-axis = 300 rpm) - Chip conveyor 450 K-1/250; year of manufacture 2000 - Manual chuck fitted – no hydraulic chuck - Electrical cabinet with Rittal cooling

Condition: good (used), Year of construction: 2013, functionality: fully functional, Gildemeister SPRINT 65 Linear IRCO Breuning bar feeder Chip conveyor High-pressure unit with integrated paper belt filter system and cooling unit Fanuc 310 control Operating hours: approx. 61,550 Production hours: approx. 46,400 The machine can be inspected under power Immediately available Hnjdpfx Ajwwa U Aeadsh

Condition: good (used), Year of construction: 2002, operating hours: 33,328 h, functionality: fully functional, machine/vehicle number: 04780000151, turning length: 1,850 mm, turning diameter: 610 mm, spindle speed (min.): 3,200 rpm, travel distance X-axis: 605 mm, travel distance Y-axis: 210 mm, travel distance Z-axis: 1,470 mm, rapid traverse X-axis: 46 m/min, rapid traverse Y-axis: 24 m/min, rapid traverse Z-axis: 60 m/min, 5-axis, 12" CNC lathe with double chuck. Siemens control system. Spindle operating hours: 1891 hours. Transport at buyer's expense. Hjdpfx Aoyiy Sdoadjnh

Condition: used, Year of construction: 1985, core drilling diameter max. 18 mm bore depth 320 mm swing diameter mm Hjdpfxst Hwvao Aadenh total power requirement 33 kW weight of the machine ca. 6 t dimensions of the machine ca. m

Condition: used, Year of construction: 1991, turning diameter 42 mm turning length 250 mm control total power requirement kW weight of the machine ca. t dimensions of the machine ca. m CNC-lathe with bar feed with Sameca bar feed Hnodot Hwz Ajpfx Aadjh

Condition: ready for operation (used), Year of construction: 1995, Make: GILDEMEISTER Type of machine: NEF Plus 500 Year of manufacture: 1995 Control system: Gründig Machine's weight: 2650 kg Speed range: 8 - 2800 1/ min Cutting diameter: 500 mm Turning length: 1000 mm Overall dimensions: 2500 x 1750 x 1850 mm Hsdpfx Ajtpn S Ieadsnh Spindle opening: 70 mm

Condition: not inspected (used), Year of construction: 2009, operating hours: 24,854 h, functionality: unexamined, machine/vehicle number: 00410002771, turning diameter over cross slide: 380 mm, turning diameter: 410 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 300 mm, travel distance Z-axis: 850 mm, Equipment: documentation/manual, No minimum price – guaranteed sale to the highest bidder! Placing a bid obligates you to collect the machine within the period from 28.07.2025 to 31.07.2025. Including a comprehensive tool package TECHNICAL DETAILS Swing diameter over bed: 700 mm Max. swing diameter over cross slide: 380 mm Max. turning diameter: 410 mm Centre distance: 975 mm Turning length: 800 mm X-axis travel: 300 mm Hsdpowvhunjfx Aadsnh Z1-axis travel: 850 mm Z3-axis travel: 800 mm Max. spindle speed: 4,000 rpm Main spindle: ISM 102 C-axis torque: 600/770 Nm Spindle flange height from floor: 1,040 mm Spindle flange diameter: 220h5 mm Chuck diameter: 315 mm Bar diameter: 102 mm Spindle bore diameter: 118 mm Front bearing diameter: 160 mm C-axis angular resolution: 0.001° Turret with driven tools Tool holders: VDI 40 Number of tools: 12 pcs. Tailstock: travel 800 mm, Morse taper 5 MT MACHINE DETAILS Serial number: 00410002771 Operating hours: 71,843 h Spindle hours: 24,854 h Dimensions: 5,000 x 2,800 x 2,000 mm Weight: 7,500 kg EQUIPMENT - With technical documentation

Condition: used, TECHNICAL DETAILS - Number of spindles : 2 - Number of axes : 2 MAIN SPINDLE - Spindle speeds : 6500 [rpm] - Max. bar diameter : 42 [mm] - Max. turning diameter : 120 [mm] - C axis indexing precision : 0.1 [°] COUNTER-SPINDLE - Spindle speeds : 6500 [rpm] - Max. bar diameter : 42 [mm] - C axis indexing precision : 0.1 [°] POWER SUPPLY - Supply voltage : 230 [V] - Total installed power : 7.5 [kW] WEIGHT & DIMENSIONS - Machine floor space : 5.400 x 1.900 [mm] - Machine height : 2.000 [mm] - Machine weight : 5.000 [kg] MACHINE HOURS - Number of hours under power : 33912 [h] - Number of working hours : 21069 [h] EQUIPMENT - CNC : FANUC 160i - Coolant tank - Chips conveyor - Parts catcher Hjdsu E U Ufepfx Aadsnh - Parts conveying strip

Condition: used, Year of construction: 2006, Technical data: Working area: Max. swing diameter: 680 mm Swing diameter over X-guideways: 565 mm Chuck diameter: 250 / 315 mm Cross travel (X): 315 mm Longitudinal travel (Y): 1350 mm Headstock: Spindle diameter in front bearing: 150 mm Spindle bore: 107 mm Main drive: Main three-phase drive power: 36 / 45 kW Torque (100% duty cycle / 40% duty cycle): 600 / 750 Nm Speed range (100% duty cycle): 20 - 3200 rpm Speed range (40% duty cycle): 20 - 4000 rpm Tool turret: Number of tool stations: 12 Shank diameter: 50 mm Indexing time for 30°: 0.16 sec Hsdpowym Inofx Aadonh Tailstock: Tailstock quill travel: 1200 mm Quill stroke: 120 mm Quill diameter: 120 mm Quill taper: MT 5 Coolant system: Capacity: approx. 220 l Pump output: 1.7 kW Delivery rate at 6 bar: 20 l/min Connected load: approx. 65 kVA Dimensions (LxWxH), approx.: 5560 x 2115 x 2050 mm Weight without chip conveyor, approx.: 9500 kg Equipment/features: - CNC control SIEMENS SINUMERIK 840D powerline with Shop Turn - Single-row turret with 12 fixed tool stations - Hinged belt chip conveyor

Year of construction: 2006, condition: like new (used), With machine come 5 live tool holders and 5 normal tool holders. Hnsdpfx Aajlbmy Usdjh Parts shown by hand not come.
