Used Kellenberger 600 U for sale (84)

Condition: good (used), Year of construction: 1997, Ref. -No.: 10619 Manufacturer: KELLENBERGER Type: 600 U Nr. 35 Year of construction: 1997 Type of control: Konventionell Control: n/a Storage location: Halberstadt Country of origin: Switzerland Distance between center: 600 mm Center height (standard): 125 mm Height of centers by lifting work blocks head and tailstock: 175 - 250 mm Swing diameter with lifting blocks max.: 350 - 500 mm Table swivel / each side: 10 ° Dwell time of the table reversal: 0- 5 Sec Diameter / width / hole: 250 x 13 x 76 mm Speeds of the grinding wheel spindle: 1500 / 1700 / 2200 / 3600 Swiveling grinding wheel head: 360° ° Ihsdpjya Dayjfx Aadou Cross movement of the grinding wheel head: 285 mm Quickly pulling the wheel head back and forth: 40 mm Intermittent injection for each reversal of the table: 0,001 - 0,03 mm / dia Working speeds continuously adjustable (normal / special): 20-400 / 10-400 Max. Grinding length: 900 mm

Condition: good (used), Year of construction: 2003, Ref. -No.: 10618 Manufacturer: KELLENBERGER Type: 600 U Nr. 33 Year of construction: 2003 Type of control: Konventionell Ihodoya Dagepfx Aadeu Control: n/a Storage location: Halberstadt Country of origin: Switzerland Distance between center: 600 mm Center height (standard): 125 mm Height of centers by lifting work blocks head and tailstock: 175 - 250 mm Swing diameter with lifting blocks max.: 350 - 500 mm Table swivel / each side: 10 ° Dwell time of the table reversal: 0 - 5 Sec Diameter / width / hole: 250 x 13 x 76 mm Speeds of the grinding wheel spindle: 1500 / 1700 / 2200 / 3600 Swiveling grinding wheel head: 360 ° Cross movement of the grinding wheel head: 285 mm Quickly pulling the wheel head back and forth: 40 mm Intermittent injection for each reversal of the table: 0,001 - 0,03 mm / dia Micro-corrector of the feed, 1 division of the dial: 0,001 mm / Ø Working speeds continuously adjustable (normal / special): 20-400 / 10-400 Max. Grinding length: 900 mm

Condition: good (used), Year of construction: 2001, Ref. -No.: 10617 Manufacturer: KELLENBERGER Type: 600 U Nr. 36 Year of construction: 2001 Type of control: Konventionell Control: n/a Storage location: Halberstadt Country of origin: Switzerland Distance between center: 600 mm Center height (standard): 125 mm Height of centers by lifting work blocks head and tailstock: 175-250 mm Swing diameter with lifting blocks max.: 350 - 500 mm Table swivel / each side: 10 ° Dwell time of the table reversal: 0 -5 Sec Diameter / width / hole: 250 x 13 x 76 mm Speeds of the grinding wheel spindle: 360° Cross movement of the grinding wheel head: 285 mm Quickly pulling the wheel head back and forth: 40 mm Ihedpfjya Daasx Aadju Intermittent injection for each reversal of the table: 0,001 - 0,03 mm / dia Micro-corrector of the feed, 1 division of the dial: 0,001 mm / Ø Working speeds continuously adjustable (normal / special): 20 - 400 / 10-400 Max. Grinding length: 900 mm

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 1315/451, Completely overhauled: Mechanics, geometry, hydraulics, and electrical parts (checked and/or replaced) Wheelhead: Disassembled, parts cleaned, worn or defective components replaced, motor overhauled, bearings replaced, belts replaced, spindle disassembled, seals and O-rings replaced, adjustments made. Newly painted. Workhead: Disassembled, parts cleaned, worn or defective components replaced, motor overhauled, belts replaced. New spindle bearings. Newly painted. Tailstock: Disassembled, inspected, overhauled. Hydraulics: Disassembled, motor checked, hoses replaced, defective and worn parts replaced. Hydraulic block checked. X-axis: Disassembled, all worn parts such as O-rings, seals, segments, etc. replaced, hydraulic piston overhauled, table ground. Z-axis: Disassembled, table ground, worn or defective parts replaced, hydraulic piston overhauled, newly painted. Electrical cabinet: Completely checked, various relays replaced. Paintwork: Colors: White RAL 9003 and Grey RAL 7011 Geometry according to manufacturer's protocol. Various accessories checked and cleaned. Origin: CH Voltage: 380 / 50 / 3 Net weight: approx. 2,200 kg Customs tariff number: 8460.2920 TECHNICAL SPECIFICATIONS Nominal distance between centers: 600 mm Max. distance between centers (with extended headstock): 750 mm Center height, standard: 125 mm Center height with interchangeable pads for heads: 175–250 mm Max. workpiece diameter (125 mm center height): 250 mm Max. workpiece diameter with interchangeable pads: 350–500 mm Swiveling range of table in each direction: 10° Max. grinding length for flat surfaces (max. width = 200 mm): 900 mm Continuously variable hydraulic table speed: up to approx. 6 m/min Table reversal delay: 0–5 sec Grinding wheel for external grinding, diameter - width - bore: 400x50x127 mm Grinding wheel for flat surface grinding: 250x13x76 mm Wheelhead spindle speed: 1,500/1,700/2,200/3,600 rpm Wheelhead swiveling range: 270°, with indexing every 90° Vertical travel of wheelhead, center height: 125–350 mm Transverse travel of wheelhead: 285 mm Hydraulic rapid traverse stroke: 40 mm Intermittent infeed of wheel by table reversal: 0.001–0.03 mm/dia Continuous infeed for plunge grinding: 0–0.9 mm/dia Micrometric infeed stop, by division: 0.001 mm/dia Workhead swiveling range: 360° Workhead spindle speed, stepless: normal/special: 20–400 / 10–400 rpm Internal taper of workhead/tailstock: Morse 5/3 Wheelhead motor: approx. 4 HP Isdpfx Aaow U Ry Nodshu All technical specifications are given without obligation and subject to errors or omissions.

Condition: refurbished (used), functionality: fully functional, machine/vehicle number: 32461/2384, Manufacturing origin Swiss Voltage 380 / 50 / 3 Netweight 4900 lbs Dimensions 121 x 69 inches TECHNICAL DATA Nominal distance between centre 600 mm Max. distance between centres, headstock and tailstock projecting 750 mm Height of centres, standard 125 mm Height of centres by means of raising blocks for work head-and tailstock 175 =ᐳ 250 mm Max. swing diameter with 125 mm height of centres 250 mm Max. swing diameter with raising blocks 350 =ᐳ 500 mm Table swivels each side 10° Max. lenght for surface grinding (width=200 mm) 900 mm Table speed infinitely viable by hydraulic drive, approx. .. 6 m/min Dwell of table reversal 0 - 5 sec. Grinding wheel for cylinrical grinding (diameter x width x hole) 350/400x50x127mm Grinding wheel for surface grinding diameter x width x hole 250 x 13 x 76 Speeds of grinding wheel spindle 1500/1700/2200/3600 Iodjd Amifjpfx Aadohu Grinding wheel head swivels 270° with indexed stop each 90° Vertical movement of grinding wheel head, height of centres -350 mm Cross movement of grinding wheel head 285 mm Rapid advance and withdrawal of wheelhead 40 mm Intermittent infeed per reversal of table 0,001-0,03 mm/dia Infeed for plunge grinding 0-0,9 mm/dia Micro-corrector of infeed, 1 division of dial 0,001 mm/dia Swivel of work headstock 360° work speeds infinetely viable, normal/special 20-400/10-400 Internal taper of headstock/tailstock 5/3 Morse Grinding wheel motor, approx. 4 HP errors and omissions excepted data given without obligation Inventory Nr.2170089, machine equipped with : 1 Workpiece headstock MT5 1 sinus rule without comparator 1 Wheel headstock with 4 pulleys 1 Tailstock MT3 1 Collet clamping device with drawbar and reduction sleeve B32 1 Internal grinding device with quill Fischer UJ50x250 – pulley Ø 48 for 14000 min-1 1 Pivoting wheel trueing-up device with sole 50 mm 1 Table’s pivoting stop without comparator 1 Cooling device through decantation 1 extractor 1 balancing stake

Condition: used, 3 flanges for type 600 U – available for sale individually or as a set Ihedpfxsx N Rytj Aadou

Condition: reconditioned (used), KELLENBERGER 600 U 175 is a cylindrical grinder of high precision, offering accuracy and reliability. Capacities: centre height 175 mm, between centres 600 mm; wheel Ø350×50 mm, bore 127 mm; wheelhead 270°. Specs: wheel speeds 1500–3600 t/min (4 steps); work spindle 20–400 t/min (stepless); table tilt 10°, up to 6 m/min; supply 3×380 V 50 Hz; wheel motor 4 CV; weight ≈2200 kg; dims 3000×1750×1600 mm. Accessories: digital readout (2 axes), tailstock fine adjust, internal grinding attachment, wheel guard, safety device, sliding door. Suited to tight tolerances in automotive, watchmaking, machine tools, aerospace and medical sectors. Isdpfsxx U H Tjx Aadohu

Condition: ready for operation (used), functionality: fully functional, center height: 125 mm, center width: 600 mm, grinding wheel diameter: 400 mm, grinding wheel width: 50 mm, grinding wheel bore: 127 mm, The motor and frequency inverter for the workpiece headstock have been replaced! Additionally, the control cabinet and wiring diagram have been renewed! TECHNICAL DETAILS Centre height: 125 mm (175 mm with riser blocks) Centre distance: 600 mm Grinding wheel diameter: 400 mm Grinding wheel width: 50 mm Grinding wheel bore: 127 mm Swivel range: 270° Workpiece headstock speed: 20 rpm to 400 rpm Spindle taper: 5 MT Tailstock taper: 3 MT Table swivel: 10° Table feed speed: up to 6.0 m/min MACHINE DETAILS External grinding wheel motor: 4.0 kW Workpiece spindle motor: 2.2 kW Dimensions & Weight Dimensions (L x W x H): 2,580 x 1,680 x 1,670 mm Machine weight approx.: 2,700 kg EQUIPMENT New control cabinet and new wiring diagram New motor and frequency inverter for the workpiece headstock 2-axis digital readout Coolant tank Geometry according to Kellenberger protocol Iodpfoyb R Nqjx Aadjhu Extensive accessories

Condition: used, TECHNICAL DETAILS - distance between centers : 600 [mm] Ihjdpfouhbywex Aadeu - center's height : 175 [mm] - table orientation : 11 [°] UNIVERSAL GRINDING WHEEL HOLDER HEADSTOCK - left grinding wheel dimension : 400 x 50 x 127 [mm] - right grinding wheel dimension : 225 x 20 x 76,2 [mm] - motor power : 3 [kW] - spindle speed : 1500 / 1700 / 2200 - grinding-wheel holder headstock orientation : 270 [°] PART HOLDER HEADSTOCK - part-holder headstock orientation : 360 [°] - spindle speeds : 20 - 400 [Rpm] - internal taper : Morse 5 - motor power : 0,9 [kW] TAIL STOCK - internal taper : CM4 - quill stroke : 30 [mm] DIMENSIONS - floor surface : 2580 x 1680 [mm] - height : 1670 [mm] - weight : 2200 [kg] EQUIPMENT - FISCHER internal spindle: 14,000 [rpm]

Condition: excellent (used), Year of construction: 1997, grinding diameter 80 - 250 mm grinding length 600 mm Ihjdpoyb S Rcefx Aadsu centre height 175 mm longitudinal feed 750 mm workpiece turning speeds 6 - 600 U/min grinding spindle speed 1500 - 3600 U/min cross movement - autom. and by hand 320 mm Control Kelco 80 weight of the machine ca. 4,4 t dimensions of the machine ca. 3,1 x 2,1 x 2,0 m

Condition: used, functionality: fully functional, Kellenberger cylindrical grinding machine in very good condition. Available at a favorable price. Price significantly reduced !!!!! Iedjw Dy Rqopfx Aadjhu

Condition: excellent (used), Year of construction: 1978, Machine can be inspected under power Isdpfxewz Emle Aadohu

Condition: used, grinding diameter 350 mm grinding length 600 mm centre height 175 mm grinding wheel diameter 400 mm grinding wheel width 50 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0-9,99 mm/Ø 0-9,99 mm/Ø ±10 ° longitudinal feed of the table 1100 mm table speeds 0,02-6 m/min 130 kg 130 inkl. Spannung kg cross travel max. 270 mm 80 mm tailstock quill taper MT 3 quill travel 30 mm total power requirement 6,5 kW weight of the machine ca. 3,05 t dimensions of the machine ca. 4 x 2 m Overhauled according to Kellenberger guidelines including new, modern and future-proof control system. Photo of already delivered machine in centre distance 1000mm. -Operation via the touch panel is extremely simple. -The symbols on the control panel are practically identical to the original original control system, so there is no need for familiarisation. -Diagnostic function with display of PLC messages and digital I/O -Dressing function can be extended or changed at the customer's request. Isdpfxouxft Es Aadehu -Orientated spindle stop of the workpiece spindle possible on request. -New maximum infeed of 40 mm can be extended on request. -Digital display in 2 axes. Resolution x-axis 0.5my Options: -Encoder with digital display in the workpiece headstock -Rotary encoder with digital display in the grinding headstock (no height adjustment with spindle possible) with spindle possible) -New stable internal grinding device diameter 80mm or 100mm with height adjustment. -Increase of the centre height to max. 225mm -Speed control for the grinding spindle Included: -Operating tool -Clamping tube for chuck Further accessories on request. The x-axis of the machine has an electronically controlled infeed system with stepper motor drive. Hydraulic longitudinal and rapid traverse table movement. Versatile application in production for external cylindrical and internal internal grinding or for external, face and internal grinding in one clamping clamping of individual parts. Possible options: -Semi-automatic dressing cycles for external and internal grinding -automatic dressing compensation. -Measuring control

Condition: reconditioned (used), KELLENBERGER KEL-VISTA UR 175X600 is a CNC cylindrical grinder engineered for precision, high accuracy and reliability. Capacity: centre height 175 mm; between centres 800 mm; grinding length 600 mm; max Ø 349 mm; max weight 100 kg. Key specs: Z 750 mm; X 320 mm; left wheel Ø400×80×127, right Ø300×40×127; wheel speeds 875–1900 rpm (stepless); wheel motor 5 kW; work spindle 8–800 rpm (stepless), taper 5 CM; rapid 12 m/min; air 6 bar; 3×400 V 50 Hz; machine ≈3000 kg; 3200×1700×2000 mm. Accessories: coolant, coolant-through-spindle (IKZ), paper filter, MARPOSS probe, MOVOMATIC measuring control, internal grinding attachment, balancing, RS‑232. Suited for tight tolerances in automotive, watchmaking, machine tools, aerospace, medical. Ihjdpfx Aajxx U Tajdsu

Condition: used, internal diameter 340/440 mm grinding depth 99999 mm grinding diameter 250,350,450 mm grinding length 600 mm centre height 125,175,225 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0,001-0,030 mm/Ø 0-0,95 mm/Ø ±10 ° longitudinal feed of the table 900 mm table speeds 0,02-6 m/min 130 kg 130 inkl. Spannugkg kg 70 mm total power requirement 6,5 kW weight of the machine ca. 2,2 t dimensions of the machine ca. 3,1 x 2,0 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your metrical overhauled and repainted with: -Neuem CE konformem Schaltschrank. -Neuem Werkstückspindelmotor und Regler in Drehstromtechnik. -Digitalanzeige in 2 Achsen. Auflösung x-Achse 0,5my Optionen: -Drehgeber mit digitaler Anzeige im Werkstückspindelstock -Drehgeber mit digitaler Anzeige im Schleifspindelstock (keine Höhenverstellung mit Spindel möglich) -Neue stabile Innenschleifvorrichtung Durchmesser 80mm oder 100mm mit Höhenjustierung. -Erhöhung der Spitzenhöhe auf max. 225mm -Drehzahlregelung für die Schleifspindel Inklusive: -Bedienwerkzeug -Spannrohr für Futter weiteres Zubehör auf Anfrage. Iheded Ih Dxjpfx Aadsu Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln.

Condition: used, grinding diameter 250,350,450 mm grinding length 600 mm centre height 125,175,225 mm grinding wheel diameter 400 mm grinding wheel width 50 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0,001-0,030 mm/Ø 0-0,95 mm/Ø ±10 ° longitudinal feed of the table 900 mm table speeds 0,02-6 m/min 130 kg 130 inkl. Spannugkg kg Ihsdpfx Aajd Ih D Nsdeu 70 mm total power requirement 6,5 kW weight of the machine ca. 2,2 t dimensions of the machine ca. 3,1 x 2,0 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your rhauled with geometric KELLENBERGER protocoll -2-axis DRO -Paper filtration Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln.

Condition: used, grinding diameter 250,350,450 mm grinding length 600 mm centre height 125,175,225 mm grinding wheel diameter 400 mm grinding wheel width 50 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0,001-0,030 mm/Ø 0-0,95 mm/Ø ±10 ° longitudinal feed of the table 900 mm table speeds 0,02-6 m/min 130 kg 130 inkl. Spannugkg kg 70 mm total power requirement 6,5 kW weight of the machine ca. 2,2 t dimensions of the machine ca. 3,1 x 2,0 m Compete overhauled machine according to Kellenberger new machine protocoll Ihsdpfx Aasd Ih D Rjdou -Digitalanzeige in 2 Achsen. Auflösung x-Achse 0,5my Optionen: -Drehgeber mit digitaler Anzeige im Werkstückspindelstock -Drehgeber mit digitaler Anzeige im Schleifspindelstock (keine Höhenverstellung mit Spindel möglich) -Neue stabile Innenschleifvorrichtung Durchmesser 80mm oder 100mm mit Höhenjustierung. -Erhöhung der Spitzenhöhe auf max. 225mm -Drehzahlregelung für die Schleifspindel Inklusive: -Bedienwerkzeug -Spannrohr für Futter -Spitze MK3 -Spitze MK5 -Futterflansch weiteres Zubehör auf Anfrage. Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln.

Condition: used, grinding diameter 350,450 mm grinding length 600 mm centre height 175,225 mm grinding wheel diameter 400 mm grinding wheel width 50 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0,001-0,030 mm/Ø 0-0,95 mm/Ø ±10 ° longitudinal feed of the table 900 mm table speeds 0,02-6 m/min 130 kg 130 inkl. Spannugkg kg 70 mm total power requirement 6,5 kW weight of the machine ca. 2,2 t dimensions of the machine ca. 3,1 x 2,0 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your machines. Foto von bereits gelieferter Maschine mit eventuell anderen Optionen. Maschine hat Zentralschmierung und Rollenführung in der Flachbahn der x-Achse sowie Luftabhebung im Schleifspindelstock serienmäßig. BEMA Standard serienmäßig: -Digitalanzeige in 2 Achsen. Auflösung x-Achse 0,5my -Drehzahlanzeige Schleifspindel -Stufenlose Drehzahl Schleifspindel 70-100% -Stufenlose Drehzahl Innenschleifspindel 70-100% -Werkstückspindelantrieb durch Drehstrommotor stufenlos regelbar über Frequenzumrichter Mögliche Optionen gegen Aufpreis: -Drehgeber mit digitaler Anzeige im Werkstückspindelstock -Drehgeber mit digitaler Anzeige im Schleifspindelstock (keine Höhenverstellung mit Spindel möglich) -Sinuslineal -Neue stabile Innenschleifvorrichtung Durchmesser 80mm oder 100mm mit Höhenjustierung. -Erhöhung der Spitzenhöhe auf max. 225mm -Drehzahlregelung für die Schleifspindel Inklusive: -Bedienwerkzeug -Spannrohr für Futter Ihsdpfx Aod Ih D Eoadsu Natürlich erhalten Sie auf unsere generalüberhalten Maschinen 12 Monate Gewährleistung. (Nur Anrainerstaaten) weiteres Zubehör auf Anfrage. Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln

Condition: excellent (used), functionality: fully functional, KELLENBERGER PRECISION UNIVERSAL CYLINDRICAL GRINDING MACHINE MODEL: 1000 U YEAR OF MANUFACTURE: 2000 PARTIAL OVERHAUL: 2026 Centre height: 175 mm Grinding length: 1000 mm Equipment: - Standard accessories - Standard workpiece headstock MK5 with adapter flange DIN 55027, size 5 - Splash guard hood for the above - Tailstock with fine adjustment, MK4 - Internal grinding attachment with protective cover for grinding spindle D:80 mm for belt-driven spindles - FISCHER internal grinding spindle type HJN 842, incl. grinding mandrels (4 pieces, choice) Ijdpfx Aajyf E Suodshu - HJNZ 42 collet chuck - Oil mist lubricator for HJN spindles - STREULI magnetic paper band filter system, type: SPB 2 - Coolant supply through the workpiece spindle - HEIDENHAIN digital length measuring system on X and Z axes - Sine bar on the workpiece headstock incl. alignment arbor MK5 - Permanent magnetic chuck, D:200 mm - Three-jaw chuck, D:160 mm - Four-jaw chuck, D:160 mm - Collet attachment for Schaublin collets B32 - Set of B32 collets, D: 1.0–30.0 mm, increment 0.5 mm (59 pieces) - Dial indicator stop for table swivel with indicator 0.01 mm - Table fixed stop - Dressing stop for internal grinding - LED machine lamp - Various grinding wheel flanges, left (2 pieces) - Pneumatic table load relief - Swiveling dressing device for external, face, or internal grinding operations - Set of vibration damping pads - New three-color paint finish (light grey RAL 7035 / blue RAL 5012 / dark grey RAL 7016) - New acceptance protocol according to KELLENBERGER standard - Documentation - CE conformity The machine is currently being overhauled, sample photos shown!

Condition: excellent (used), Kellenberger 1000U cylindrical grinding machine with many accessories available at a low price. This machine is in very good condition and is fully functional. It was purchased as a completely overhauled unit in 2019. Price greatly reduced!!!!! Isdpfowkt Eusx Aadjhu

Condition: excellent (used), Year of construction: 1999, grinding length: 1,000 mm, Internal / External spindel Collet device Schaublin with inserts Steady rest 5 - 80 mm Steady rest 3 - 120 mm Coolant system Iodpfx Aoxy I Tvoadehu Filtration system Speeds head 1500 / 1700 / 2200  Centre height: 175mm Grinding Ø: 350mm Grinding length: 1000mm Grinding stone dimensions:400 x 50 x 127mm Grinding stone speeds: 1500 / 1700 / 2200Rpm Table inclasement: 9° Tailstock: 4Mk Cooling system: Yes Filtration: Yes Length: 2860mm Width: 1680mm Height: 1670mm Weight: 2500kg

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 1845/455, Completely refurbished: Mechanics, geometry, hydraulics, and electrical components Wheelhead Disassembly, cleaning of parts, replacement of worn and defective components, motor overhaul, replacement of bearings, replacement of belts, spindle disassembly, replacement of seals and O-rings, plus adjustment. New paintwork. Workhead Disassembly, cleaning of parts, replacement of worn and defective components, motor replacement, replacement of belts. New spindle bearings. New paintwork. Tailstock Disassembly, cleaning of parts, replacement of worn and defective components, motor replacement, replacement of belts. New spindle bearings. New paintwork. Internal grinding attachment Disassembly, cleaning of parts, replacement of worn and defective components, installation of the support and geometry alignment. New paintwork. Hydraulics Disassembly, motor replacement, hose replacement, defective and worn parts replaced. Hydraulic block checked. X-Axis Disassembly, replacement of worn items such as O-rings, seals, rings, etc., overhaul of hydraulic piston, regrinding of tables. Z-Axis Disassembly, regrinding of tables, replacement of worn and defective parts, overhaul of hydraulic piston, scraping of V and flat guides. New paintwork. Measuring system Digital 2-axis display included. Electrical cabinet Replacement of motor contactors and relay controls. New wiring. New variable speed drive (frequency inverter) for the workhead. TECHNICAL SPECIFICATIONS Distance between centers: 1500 mm Distance between centers (workhead to tailstock overhang): 1650 mm Center height, standard: 125 mm Center height with riser blocks: 225/250 mm Maximum grinding diameter: Ø 250 mm Maximum grinding diameter with riser blocks: 450/500 mm Table Usable surface: 2060 x 140 mm Ihjdpfsxt Ilfjx Aadou Max. length and width for surface grinding: 1750 x 200 mm Longitudinal travel, manual or hydraulic: 1750 mm Manual table movement, 1 handwheel revolution – coarse: 20.006 mm Manual table movement, 1 handwheel revolution – fine: 2.457 mm Table speed, continuously via hydraulics: up to 6 m/min Table swivelling: 6° Stop and return: 0–5 sec. Workspindle Workpiece speeds, continuously variable (electric): 20–400 rpm Swivelling: 360° Workspindle taper (internal): MT5 Tailstock Internal taper, tailstock spindle: MT3 Spindle retraction, manual or hydraulic: 30 mm Diamond dresser taper (internal): MT0 Universal grinding head Cross slide travel for wheel: 285 mm Rapid traverse for wheel slide, front and rear: 40 mm Grinding spindle speeds: 1500 – 1700 – 2200 – 3600 rpm Vertical grinding spindle movement, center heights: 125–330 mm Max. wheel for cylindrical grinding: 400 x 50 x 127 mm Max. wheel for surface grinding: 250 x 20 x 76 mm Head swivelling with locking at every 90°: 270° Wheel feed 1 division of the micrometer drum: 0.005 mm/Ø Automatic wheel feed, max.: 0.9 mm/Ø Motors Grinding spindle motor: 2,900 rpm / 4.0 hp Workspindle motor: 3,000 rpm / 2.0 hp Coolant pump motor: 2,850 rpm / 0.12 hp Internal grinding attachment Bore: 70 mm Internal grinding spindle speed Ø70 mm: 14,000 rpm Internal grinding spindle speed Ø50 mm: 21,000 rpm Subject to error or omission, the technical information is provided without obligation.

Condition: used, grinding diameter 250 mm grinding length 600 mm centre height 125 mm grinding wheel diameter 500 mm grinding wheel width 80 (100) mm bore 203,2 mm MK5 work piece spindle speed 20-400 U/min workpiece spindle swivable +/- 360 ° grinding head swivellable +/- 0 ° 0-9,99 mm/Ø 0-9,99 mm/Ø table swivelabel +/- 10 ° longitudinal feed of the table 700 mm table speeds 0,02-6 m/min 130 kg max. workpiece weight -without tailstock 130 inkl. Spannung kg cross travel 270 mm tailstock quill taper MT 3 quill travel 30 mm total power requirement 5,5-7,5 kW weight of the machine ca. 2,7 t As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your machines. Überholt nach Kellenberger Richtlinie inklusive neuer, moderner sowie zukunftssicherer Steuerung. Foto von bereits gelieferter Maschine. -Die Bedienung über das Touch-Panel ist denkbar einfach. -Die Symbolik auf der Steuertafel ist praktisch identisch mit der ursprünglichen Steuerung somit entfällt die Einarbeitung. -Diagnosefunktion mit Anzeige von SPS Hinweisen und den digitalen I/O -Abrichtfunktion auf Kundenwunsch erweiterbar bzw. änderbar. -Auf Wunsch orientierter Spindelhalt der Werkstückspindel möglich. -Neuer Maximaler Zustellbetrag 40mm auf Wunsch noch erweiterbar. -Digitalanzeige in 2 Achsen. Auflösung x-Achse 0,5my Optionen: -Drehgeber mit digitaler Anzeige im Werkstückspindelstock -Drehgeber mit digitaler Anzeige im Schleifspindelstock (keine Höhenverstellung mit Spindel möglich) -Neue stabile Innenschleifvorrichtung Durchmesser 80mm oder 100mm mit Höhenjustierung. -Erhöhung der Spitzenhöhe auf max. 225mm -Drehzahlregelung für die Schleifspindel Inklusive: -Neuer DGS Papierbandfilter -Bedienwerkzeug -Spannrohr für Futter weiteres Zubehör auf Anfrage. Maschine verfügt in der x-Achse über ein elektronisch gesteuertes Zustellsystem mit Schrittmotorantrieb. Hydraulische Tischlängs- und Eilgangbewegung. Vielseitige Einsatzmöglichkeit in der Produktion beim Aussenrund- und Innenschleifen oder für das Aussen-, Plan- und Innenschleifen in einer Aufspannung von Einzelteilen. Mögliche Optionen: -Halbautomatische Abrichtzyklen für das Aussen- und Innenschleifen -automatischer Abrichtkompensation. Ijdpfx Asd Ih Ehsadshu -Messsteuerung Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln.

Condition: used, TECHNICAL DETAILS - distance between centers : 1000 [mm] - centers height : 125 [mm] - table orientation : -/+ 8 [°] - universal wheelhead - grinding wheels dimensions : 400 x 50 x 127 [mm] - motor power : 3 [kW] Ihsdpeuhbx Tsfx Aadju - spindle speed : 1500 / 1700 / 2200 - orientation of grinding wheel holder headstock : 270 [°] (3 x 90°) - boring for internal spindle : 90 [mm] - orientation of part holder headstock : 180 [°] - spindle speed : 20 - 400 [Rpm] - spindle internal cone : Morse 5 - motor power : 0,9 [kW] - inner cone tailstock : Morse 4 - tailstock sleeve travel: 30 [mm] - dimensions : 2860 x 1680 x 1670 [mm] - weight : 2 500 [kg] EQUIPMENT - automatic cycle work (rough part, finishing and reverse) - tail stock - sinus ruler for part holder headstock - head UR : 2 external and 1 internal grinding wheel - lubricating tank with pump - 1 internal grinding spindle SFJ UJ70 : 14.000 [rpm] - 1 fixed diamond grinding device holder on tail stock - 1 chuck 4 jaws - 1 magnetic chuck - 1 set of driving tocs - 2 rests 2 points - spacer to increase centre height to 175 mm - various grinding wheel holders - various grinding wheels

Condition: reconditioned (used), functionality: fully functional, center height: 250 mm, center width: 1,500 mm, grinding diameter: 500 mm, tailstock quill stroke: 30 mm, Equipment: documentation/manual, The machine has been partially overhauled and includes, among other things, new geometry and a new control cabinet. The bearings have been replaced. TECHNICAL DETAILS Working Area Centre distance: 1,500 mm Centre height: 250 mm Max. grinding diameter: 500 mm Table swivel range: ± 8° Grinding Head Grinding wheel dimensions: 400 x 50 x 127 mm Spindle speeds: 1,500 / 1,700 / 2,200 rpm Bore for internal grinding spindle: 90 mm Workpiece Headstock Workpiece headstock orientation: 180° Spindle speed: 20 - 400 rpm Spindle taper: Morse 5 Tailstock Tailstock taper: Morse 4 Tailstock quill stroke: 30 mm MACHINE DETAILS Drives Grinding head motor power: 3 kW Ihedpfsxgrd Sex Aadsu Tailstock motor power: 0.9 kW Machine Data Dimensions: 2,860 x 1,680 x 1,670 mm Weight: 2,500 kg EQUIPMENT Automatic working cycle Coolant tank with pump Internal grinding spindle External grinding wheels Dressing device Documentation Note: A digital readout can optionally be purchased for €3,600.
