Used Maho Mh 800 C for sale (436)

Year of construction: 2001, condition: used, Technical details: x-travel: 400 mm y-travel: 300 mm Ncjdpfxoikbtnj Abvep z-travel: 500 mm table clamping surface:: 400 x 300 mm table load: 50 kg semi-automatic operated: LASERSOFT 3D laser capacity: 100 W total power requirement: 27 kVA weight of the machine ca.: 2,5 t dimensions of the machine ca.: 3 x 3,5 x 2,8 m CNC engraving/texturing/labeling/contouring-laser maschine, approx. 9.000h "machine on", approx. 5.500h "laser on" *

Condition: like new (used), Year of construction: 2006, operating hours: 51,775 h, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,000 mm, nominal power (apparent): 44 kVA, controller manufacturer: Heidenhain iTNC 530, workpiece weight (max.): 4,000 kg, total height: 3,500 mm, total length: 7,500 mm, total width: 7,700 mm, table length: 1,500 mm, overall weight: 35,000 kg, spindle speed (min.): 10,000 rpm, Year of construction: 2006 CNC controller: Heidenhain iTNC 530 Axes X-axis travel mm: 1600 Y-axis travel mm: 1250 Z-axis travel mm: 1000 C-axis degrees: 360º (0,001) B-axis degrees: 0-190º Feed rates m/min: 60 Rapid traverse m/min: 60 Nodpfxeyq Rm Is Abvocp Milling/turning table nc: Table dimensions mm: Ø1500x1250 Max. workpiece weight kg: 4000 Table rotation speed rpm: 10 Spindle Spindle speed rpm: 10000 Spindle drive power kW: 44/32 (40/100%ED) Spindle torque Nm: 288/187 (40/100%ED) Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 980 Tool system Tool holder: HSK-A 100 Tool magazine slots: 60 Tool changer: Double gripper With free neighboring places mm: 250 With occupied neighboring places mm: 130 Max. Tool Length mm: 650 Max tool weight kg: 30 Chip-to-chip time s: 6 Equipment Chip conveyor Infrared probe Rotating inspection windows Rinsing gun Operating mode 4 blowing air through spindle center selectable via M-function Machine running times Under power: 98398 Spindle Working: 51775 Rated power kVA: 96.2 Basic machine dimensions / weight Length mm: 7500 Width mm: 7700 Height mm: 3500 Weight kg: 35000

Condition: used, Year of construction: 2001, Deckel Maho DMC 60U Hi-dyn Machining Center Condition: Used Ncedou Rnlujpfx Abvop Year of manufacture: 2001 Power-on hours: 56,376 Spindle hours: 26,451 Technical specifications: Travel X/Y/Z: 600 / 700 / 600 mm Motor power: 15 kW (40% duty cycle); 10 kW (100% duty cycle) Spindle speed: 18,000 rpm Tool holder: HSK 63 Magazine capacity HSK 63: 60 tools Equipment: - 3D trajectory control MillPlus IT - Horizontal double gripper tool changer - Automatic swivel milling head - Rotating safety viewing window - NC rotary table with pallet support - Pallet changer - 2 pallets, 630 x 500 mm - Universal milling head with controlled B-axis HSK 63 (only in combination with HSK 63 motor spindle) - Tool holder for HSK-A63 according to DIN 69893 - Electronic handwheel - Operating mode 4: Extended manual intervention - Rinsing gun with pump - Tool breakage monitoring HSK 63, mechanical version, range: 63...310 mm / +/- 3 mm - Intermittent operation chip conveyor - Internal coolant supply switchable from 40 bar to 80 bar

Condition: used, Year of construction: 1998, x-travel 600 mm y-travel 700 mm z-travel 600 mm Control Siemens type Millplus Table dimensions 630x500 mm tool taper ISO 40 Cooling through the spindle 40 bar Tool changer 60 Pos. no. of tables 2 Milling head automatically swivels horizontally/vertically The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More Njdpeyutv Tofx Abvocp than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: good (used), Year of construction: 2005, travel distance X-axis: 760 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 560 mm, feed rate X-axis: 30,000 m/min, feed rate Y-axis: 30,000 m/min, feed rate Z-axis: 30,000 m/min, total height: 2,450 mm, total length: 5,200 mm, total width: 4,500 mm, table width: 500 mm, table length: 630 mm, table load: 300 kg, overall weight: 12,000 kg, 5-axis CNC machine (VMC) DECKEL MAHO - DMC 60T MACH-ID 9443 Make: DECKEL MAHO Type: DMC 60T Control: HeidenHain iTNC530 Year: 2005 € 12.500,00 X - Travel: 760mm Y - Travel: 560mm Z - Travel: 560mm A - Axis: 360000° B - Axis: - 30 to + 120° Table Length: 630mm Table Width: 500mm Table load: 300 Feed rate X-Axis: 30000mm/min. Feed rate Y-Axis: 30000mm/min. Feed rate Z-Axis: 30000mm/min. Spindle Taper: 40ISO/Bt/Mk Power on spindle: 26kW Speeds / ranges: 18000Rpm ATC / revolver: 30 Coolant through spindle / Bar:15 Nedpfx Absym R Tgsvecp Number of controlled axis: 5 Chip conveyor: Yes Coolantsystem: Yes Length: 5200mm Width: 4500mm Height: 2450mm Weight: 12000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: ready for operation (used), Year of construction: 2007, operating hours: 23,663 h, travel distance X-axis: 560 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, controller manufacturer: SIEMENS, controller model: Sinumerik 840D, total height: 2,500 mm, overall weight: 10,600 kg, number of axes: 4, This 4-axis DECKEL MAHO DMC 55H duoBlock was manufactured in 2007. It features X, Y, Z movements of 560 mm, 600 mm, and 600 mm respectively, and a spindle speed of 12000 rpm. The machine includes a SK40 spindle taper, a 60-position tool magazine, and four 400x400 mm pallets with a 1-degree indexed 4th axis. Consider the opportunity to buy this DECKEL MAHO DMC 55H duoBlock horizontal machining centre. Contact us for more information about this machine. Additional equipment • 4 Pallets 400 x 400 included with machine, indexed 4th axis by 1 degree • Workpiece probe • Internal cooling • Large coolant tank with automatically coated filter paper Machine Benefits Technical Machine Benefits Ncsdpfx Aboytumdsvep • Table size: 400 x 400 mm • Tool magazine: 60 positions Extra Information Machine still under power Dimensions Machine Depth 6000 mm Technical Specification Through-spindle Coolant Yes

Condition: used, Year of construction: 2002, travel distance X-axis: 3,400 mm, travel distance Y-axis: 2,800 mm, travel distance Z-axis: 1,600 mm, spindle speed (min.): 10,000 rpm, Universal machining center Machine type: DMG DMC 340 U Control: Heidenhain iTNC 530 Year of manufacture: 2002 TECHNICAL DATA: Travel paths: X-axis: 2,800 mm Y-axis: 3,400 mm Z-axis: 1,600 mm B-axis C-axis Rapid traverse: (X/Y/Z): 60 / 30 / 40 m/min. Swivel head Speed range: 10,000 rpm. Drive power: 44/32 kW Torque: 288 Nm Tool holder: HSK 100 Tool positions: 120 Tool diameter: 130 / 250 mm Tool length: 650 mm Tool weight: 30 kg NC rotary table: 2500 x 2000 Pallet system Number of pallets: 2 Pallet size: 2,500 x 2,000 mm Top table: D. 2,800 Features: Internal cooling (IKZ): bar Coolant tank: l Chip conveyor Electronic handwheel Chip flushing gun Njdpfx Aex Uxc Tobvocp

Condition: ready for operation (used), Year of construction: 2006, operating hours: 17,450 h, travel distance X-axis: 835 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, controller manufacturer: SIEMENS, controller model: 840D with ShopMill, table width: 560 mm, table length: 1,000 mm, table load: 800 kg, overall weight: 4,200 kg, number of axes: 4, This 4-axis DMG DECKEL MAHO DMC 835V was manufactured in 2006. Ideal for precision vertical machining, this used machine maintains robust functionality despite its years. Consider the opportunity to buy this DMG DECKEL MAHO DMC 835V vertical machining centre. Contact us for more information. Additional equipment • Linear Encoder Measuring System • A-axis • Electronic Handwheel • Internal Coolant – 25 bar / 30 l/min • Cabin Roof • New Spindle Bearings Machine Benefits Technical Machine Benefits Nsdpfx Abjyrd Hwjvscp • Tool mountings: sk 40 Extra Information Machine still under power Dimensions Machine Depth 2100 mm

Condition: ready for operation (used), Year of construction: 2007, operating hours: 22,729 h, travel distance X-axis: 635 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 460 mm, total height: 2,650 mm, table load: 600 kg, overall weight: 5,500 kg, spindle speed (max.): 10,000 rpm, number of axes: 3, This 3-axis DMG DECKEL MAHO DMC 635V was manufactured in 2007. It's a vertical machining centre equipped with a measuring probe and a 3D button, ideal for precise machining tasks. If you are looking to get high-quality milling capabilities, consider the DMG DECKEL MAHO DMC 635V machine we have for sale. Contact us for more information about this machine. Nsdpfox D Epcjx Abvscp • Tool magazine: 20 stations • Table size: approx. 790 × 560 mm Additional equipment • 3D probe • Coolant: external coolant supply only (no through-spindle/internal coolant) • Chip conveyor: not included Dimensions Machine Depth 2050 mm

Condition: ready for operation (used), Year of construction: 2013, travel distance X-axis: 630 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 850 mm, controller manufacturer: SIEMENS, controller model: 840 D, table width: 500 mm, table length: 500 mm, spindle speed (max.): 18,000 rpm, spindle motor power: 20,000 W, number of slots in tool magazine: 303, number of axes: 4, This DMG DMC 60H Linear Horizontal Machining center was manufactured in the year 2013 and has 46048 production hours. It is equipped with a Siemens 840 D control unit and has 4 axis. The machine has a spindle speed of 18000 rpm. See original delivery note as PDF (German) attached to see all technical positions. Nedpfsyi Ekfsx Abvecp Additional equipment • Scraper belt chip conveyor with coolant system 980 liter, paper belt filter, discharge height 950 mm, width 380 mm, IKZ 80 bar / 14 l/min through spindle center (AD), pressure infinitely programmable, selectable via NC program, Roof flushing of the working area 180 l/min via flushing nozzles with a ripple valve • Rotating viewing window / work area door • Flushing gun with pump • Double gripper • Wheel magazine • NC rotary table Ø 630 mm • 3D path control Machine Benefits Qualitative Machine Benefits • Mcis tdi tool management (module tdi machine) - overview , tool handling, planning • Extraction mechanical and electrical preparation for oil mist extraction • Tool breakage check mechanical design Technical Machine Benefits • Number of pallets: 12 // round pallet storage: rs 12 • Rotary pallet changer // work table with pallet support // permissible load: 600 kg // 2 pallets 500 x 500 mm with t-slots // pallet management // pallet changer cladding // claw flushing pallet • Cooling through the spindle center: 80 bar • Tool magazine: wheel magazine (5 wheels) with 303 magazine slots hsk a63 • Infrared measuring probe renishaw pp60 optical (omp60) hsk-a 63 • Mpc machine protection control (machine protection through rapid shutdown) • Laminated glass safety pane for right-hand cabin door window Extra Information Documentation and Electrical circuit diagram (German) available

Condition: ready for operation (used), Year of construction: 2007, operating hours: 19,478 h, travel distance X-axis: 635 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 460 mm, controller manufacturer: SIEMENS, controller model: 840D powerline, table load: 600 kg, spindle speed (max.): 10,000 rpm, number of axes: 3, This 3-axis DMG DECKEL MAHO DMC 635V was manufactured in 2007. It features a Siemens 840D control unit, a spindle speed of 10,000 rpm, and a tool changer with 20 positions. The table measures 790 x 560 mm with a maximum load of 600 kg. Rapid traverse rate is 30 m/min. Consider the opportunity to buy this DMG DECKEL MAHO DMC 635V vertical machining centre. Contact us for more information about this machine. Ncedpfxsyca Npj Abvjp • Operating hours: 19,478 h • Table size: 790 x 560 mm • Rapid traverse: 30 m/min • Tool changer: 20 positions • Condition: Both machines are in good working condition Technical Specification Taper Size SK 40

Condition: ready for operation (used), Year of construction: 2008, operating hours: 17,641 h, travel distance X-axis: 635 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 460 mm, controller manufacturer: SIEMENS, controller model: 840D powerline, table load: 600 kg, spindle speed (max.): 10,000 rpm, number of axes: 3, This 3-axis DMG DECKEL MAHO DMC 635V was manufactured in 2008. It features a Siemens 840D control unit, a spindle speed of 10,000 rpm, and a tool changer with 20 positions. The machine offers a table size of 790 x 560 mm and a maximum table load of 600 kg. If you are looking to get high-quality milling capabilities, consider the DMG DECKEL MAHO DMC 635V machine we have for sale. Contact us for more information. • Operating hours: 17,641 h • Table size: 790 x 560 mm • Rapid traverse: 30 m/min Ncsdpfxsyca I Sj Abvep • Tool changer: 20 positions • Condition: Both machines are in good working condition Technical Specification Taper Size SK 40

Condition: ready for operation (used), Year of construction: 2001, operating hours: 16,799 h, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller manufacturer: HEIDENHAIN, spindle speed (max.): 12,000 rpm, number of axes: 5, This 5-axis DECKEL MAHO DMC 80 U hi-dyn was manufactured in 2001. It features a rotary speed of up to 12,000 rpm, a B-axis automatic swivel milling head, and a C-axis NC rotary table measuring 900 x 630 mm. The machine includes a 60-position tool magazine, Heidenhain control system, dual pallet changer, and an internal coolant supply at 40 bar. Consider the opportunity to buy this DECKEL MAHO DMC 80 U hi-dyn universal machining centre. Contact us for more information. • B-axis automatic swivel milling head • C-axis NC rotary table: 900 x 630 mm • Tool magazine: 60 positions • Heidenhain control system Additional equipment Njdpfxox H U D Rj Abvocp • Dual pallet changer • Coolant temperature control system • Chip conveyor • Internal coolant supply 40 bar • Paper belt filter • Rotating viewing window • Cleaning gun • Oil and emulsion mist separator Technical Specification Taper Size SK 40

Condition: ready for operation (used), Year of construction: 2012, operating hours: 14,297 h, travel distance X-axis: 735 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 560 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, spindle speed (max.): 18,000 rpm, number of axes: 5, This 5-axis DECKEL MAHO DMU 65 monoBlock was manufactured in 2012. It features a vertical machining center with an 18000 rpm spindle and a 3D infrared probe. The machine dimensions are X: 735mm, Y: 650mm, Z: 560mm. Ideal for complex and precise machining tasks, the DECKEL MAHO DMU 65 monoBlock machine we have for sale. Contact us for further details regarding this vertical machining center. Additional equipment • Magnetic plate • 3D infrared probe Machine Benefits Qualitative Machine Benefits Njdox D N Nmepfx Abvocp • Robust and precise with significant spindle time indicating reliability Technical Machine Benefits • High spindle speed (18000 rpm) for efficient machining • Large travel ranges for versatile machining operations • Hours machine on: 33358h / working hours: 14393h • Tool changer number = 30 magazine positions Extra Information Machine still under power

Condition: ready for operation (used), Year of construction: 2005, travel distance X-axis: 780 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 630 mm, number of axes: 5, This DMG DECKEL MAHO DMC 60T was manufactured in 2005. A Universal machining centre, it offers robust construction and reliable performance for precision machining tasks. Consider the opportunity to buy this DMG DECKEL MAHO DMC 60T Universal machining centre. Contact us for more information. Machine Benefits Technical Machine Benefits • Machine with nc rotary table and tool magazine for 60 tools: approximately 9610 kg Njdpfx Asx Hbmfebvocp • Belt filter system 900 l: approximately 850 kg • Installation weight of machine with max weight for workpiece, tools, and operating materials, belt filter system: maximum 11500 kg • B-axis complelty overhauled Extra Information Machine still under power // Contril unit: Heidenhain: MILL PLUS 2-fold pallet change. IKZ spindle with 12000 rpm, 40 bar Operating mode 4 for working with open door. Blum laser, with tool measurement and tool breakage control. Preparation for Blum 3D probe. Probe is not included in the scope of delivery. 900 liter cooling water tank with belt filter

Condition: ready for operation (used), Year of construction: 2008, controller manufacturer: SIEMENS, controller model: 840D Powerline, number of axes: 4, This 4-axis DECKEL MAHO DMC 70H duoBlock was manufactured in 2008. A robust horizontal machining centre, it offers advanced capabilities for complex machining tasks. Consider the opportunity to buy this DECKEL MAHO DMC 70H duoBlock horizontal machining centre. Contact us for more information. Additional equipment • Pallet changer: RS4 Nsdpfx Asx D Hl Eebvscp • Tool magazine: Omron Extra Information Machine still under power

Condition: ready for operation (used), Year of construction: 2005, operating hours: 42,339 h, travel distance X-axis: 730 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, number of axes: 3, This 3-axis DMG DECKEL MAHO DMU 60 monoBlock was manufactured in 2005. It features a chip conveyor and a coolant system, ideal for complex machining tasks. If you are looking to get high-quality milling capabilities, consider the DMG DECKEL MAHO DMU 60 monoBlock machine we have for sale. Contact us for more information. • Heidenhain TNC530 • 24 tool positions • SK-40 chuck • Spindle speed: 18,000 • measuring probe Nodpex D Nwkefx Abvocp Technical Specification Through-spindle Coolant Yes

Condition: ready for operation (used), Year of construction: 2011, operating hours: 2,265 h, travel distance X-axis: 635 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 460 mm, controller manufacturer: SIEMENS, controller model: Sinumerik 810D Powerline, total height: 2,650 mm, table load: 600 kg, overall weight: 5,500 kg, spindle speed (max.): 10,000 rpm, number of axes: 3, This 3-axis DMG DECKEL MAHO DMC 635V eco was manufactured in 2011. It features a Siemens Sinumerik 810D Powerline control system, a tool holder SK 40, and a tool magazine with 20 positions. The machine offers a spindle speed of up to 10,000 rpm and a rapid traverse speed of 25 to 30 m/min in X/Y/Z axes. Consider the opportunity to buy this DMG DECKEL MAHO DMC 635V eco vertical machining centre. Contact us for more information about this machine. • Tool magazine: 20 positions • Table size: approx. 790 × 560 mm • Notes/condition: Screen may be defective • Error message during tool change (see images) & contours/drilling patterns can no longer be programmed Additional equipment • 3D probe • Chip conveyor & coolant & miscellaneous: No chip conveyor & no internal cooling, only normal external coolant supply Nedex D D Htepfx Abvecp Dimensions Machine Depth 2050 mm

Condition: ready for operation (used), Year of construction: 2004, travel distance X-axis: 600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller manufacturer: HEIDENHAIN, spindle speed (max.): 12,000 rpm, spindle motor power: 25,000 W, number of axes: 5, This 5-axis DMG DECKEL MAHO DMC 60U RS5 was manufactured in 2004. Ideal for precision vertical machining, this used machine represents a valuable addition to any workshop. Consider the opportunity to buy this DMG DECKEL MAHO DMC 60U RS5 vertical machining centre including a Schuler automation. Contact us for more information. Additional equipment • Tool Changer & Magazine: Horizontal Double Gripper / Magazine Type: Chain Magazine / Capacity: 60 Tool Places / Tool Clamping: According to DIN 69872 / Tool Breakage Control: Mechanical Version • Schuler automation • Coolant Tank: 900 L • IKZ: Form AD with Paper Band Filter • Measuring Probe: Heidenhain TS 641 (Infrared) • Tool Measurement: Blum Laser for Tool Length & Diameter Measurement Horizontal/Vertical • Rotating Viewing Window Machine Benefits Technical Machine Benefits • Production hours: 54347 operating hours, spindle hours 26748 (new spindle has 3,500 hours) • Universal milling head with controlled b-axis • Very well maintained machine operated for high-end applications Ncjdpfxjyaam Ao Abvep • Spindle replacement in 2021 at a cost of approximately 40000 euros • Checkbook maintained Extra Information Disc changer and 4 pallets are included Control 3D Haidenhein contouring control "Millplus IT with Millplus IT handwheel"Optional: more palletsServiced regularlyGeometry protocol dated 5 February 2026Regrinding of the spindle cone: €1,500–€3,000

Condition: ready for operation (used), Year of construction: 2000, operating hours: 48,804 h, travel distance X-axis: 600 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 560 mm, controller manufacturer: SIEMENS, controller model: Sinumerik 840D, table load: 350 kg, overall weight: 3,400 kg, spindle speed (max.): 8,000 rpm, number of slots in tool magazine: 90, tool weight: 10,000 g, number of axes: 4, This 4-axis DECKEL MAHO DMC 60H hi-dyn was manufactured in 2000. It features a Siemens Sinumerik 840D control, a spindle speed up to 8000 rpm, and a 90-position tool magazine. The machine includes a pallet changer with 4 storage locations and a rapid traverse rate of 60 m/min. Ideal for high precision horizontal machining. Contact us for more information about this machine. Additional equipment • Coolant Type/Content: Emulsion (internal & external) / approx. 1100L • Coolant Unit: Knoll with drum filter 30, 40, 50 bar via M-command • Machine Accuracy: VDI / DGQ 3441 • Renishaw Measuring Probe Nodpfx Abex D H S Ejvocp • Tool Breakage Detection • Drum filter • Pallet Sequential Operation • Enclosed Work Area Enclosure • Network Connection • Technical Documents and Layout Plan available Machine Benefits Qualitative Machine Benefits • Some hydraulic and pneumatic hoses replaced • Lt module replaced in the control cabinet • Drum on the knoll system replaced • Regular maintenance performed • High operational efficiency with rapid pallet and tool change times • Comprehensive maintenance records ensuring reliability and accuracy • Equipped with a pallet storage space (4 spaces) • Enhanced safety features with accident prevention regulations compliance Technical Machine Benefits • Torque 100% / 40% duty cycle: 124 nm • Motor power 100% / 40% duty cycle: 13 kw • B-axis (360 x 0. 001°) 60 rpm • Table/pallet size (lxw): 6 pallets 500x400 mm • Table/pallet type: t-slots according to din 55201 • Pallet changer / setup station / storage location: yes / yes / yes (4 storage locations) • Pallet change / tool change time: 6 seconds / 5 seconds • Tool magazine type: chain magazine • Total power requirement: 20 kw • Hydraulic system motor and pump replaced Extra Information Machine still under power Dimensions Machine Depth 5000 mm

Condition: good (used), Year of construction: 2005, functionality: fully functional, Technical details x-travel 1040 mm y-travel 600 mm z-travel 500 mm Control Heidenhain iTNC 530 Ncedjyml U Sjpfx Abvop table surface area 1250 x 600 mm table load 600 kg tool taper SK 40 spindle turning speed range 1 - 8000 U/min max. torque on the spindle (S1/S6) 140/200 Nm feed range 40000 mm/min rapid power traverse in X-and Z direction 70 m/min rapid motion - y-axis 40 m/min spindle drive (100/40 % ED) 13/19 kW total power requirement 39 kVA weight of the machine ca. 8,9 t Additional information Operating hours 70278 Spindle hours 23335 Please note the enclosed geometry measurement report with the tool pull-in force measurement. Equipment: CNC control Heidenhain iTNC 530 Electronic handwheel Heidenhain HR 410 Motor spindle with increased torque Direct path measuring system in Y-Z axis Preparation for measuring probe 30-station tool changer, tool diameter 100/140 mm, length 300, weight 7 kg ROTOCLEAR Production package 2 Internal coolant supply through the spindle 20 bar Coolant system with paper belt filter Cooling device blown air through the spindle center selectable via M function Chip conveyor Bed flushing Linear drive in the X-axis Operating mode 4 Program check with extended manual intervention Machine documentation Transport dimensions: 4100 x 2500 x 3000 mm

Condition: used, x-travel 630 mm y-travel 500 mm z-travel 500 mm weight of the machine ca. 4500 kg Ncsdjynnuqopfx Abvjp

Condition: excellent (used), Year of construction: 2002, Control Siemens Sinumerik 840D Travel paths X/Y/Z: 560 x 560 x 510 mm Spindle speed 15,000 min-1 2-fold pallet changer 400 x 400 mm Tool magazine for 40 tools, SK 40 Paper filter Ncedpfx Abjyrir Sovjp Chip conveyor

Condition: excellent (used), Year of construction: 2011, Heidenhain TNC 620 control system Travel X/Y/Z: 1035/560/510 mm Nedpeyrir Esfx Abvscp Spindle speed: 12,000 rpm Tool magazine for 30 tools, SK 40 Through-spindle cooling: 12 bar Chip conveyor

Condition: like new (used), Year of construction: 2013, operating hours: 39,945 h, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 580 mm, travel distance Z-axis: 400 mm, controller manufacturer: Heidenhain iTNC 530, total height: 2,900 mm, total length: 5,500 mm, total width: 2,650 mm, spindle speed (min.): 28,000 rpm, coolant supply: 40 bar, Year of construction: 2013 CNC controller: Heidenhain iTNC 530 Axes X-axis travel mm: 450 Ncsdpfx Ajxv Av Rjbvsp Y-axis travel mm: 580 Z-axis travel mm: 400 C-axis degrees: 360º (0,0001) A-axis degrees: +10 / -110º Feed rates m/min: 80 Rapid traverse m/min: 80 Acceleration in the axes m/s2: 13 Milling/turning table nc: Number of pallets: System 3R (21 pallets type GPS 240, 30pallets type GPS 120 and 24 pallets type ITS50) Table dimensions mm: baseplate for root pallet Maximum workpiece size (D x H) mm: for pallet GPS 240 (275x275x200mm); for pallet GPS 120 (150x150x200mm) and for pallet ITS50 (ø70x200mm) Max. workpiece weight kg: 150 (pallet + workpiece) Spindle Spindle speed rpm: 28000 Spindle drive power kW: 35/25 (40%ED/cont) Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 600 Tool system Tool holder: HSK-A 63 Tool magazine slots: 120 Tool changer: Double gripper Equipment Electronic Handwheel Chip conveyor Infrared probe Internal cooling lubricant supply Rotating inspection windows Rinsing gun blowing air through spindle center selectable via M-function Laser tool measurement for measuring tool length and diameter 3D quickSET Arrangement for external pallet management Accuracy package Internal coolant supply Electrical cabinet active cooling unit Spindle active cooling unit Toolholders are not included Tools are not included Paper band filter Machine running times Under power: 62983 Spindle Working: 39945 Rated power kVA: 60 Basic machine dimensions / weight Length mm: 5500 Width mm: 2650 Height mm: 2900 Weight kg: 9500 + system 3R
