Used Turning Tools for sale (39,477)

Condition: excellent (used), Year of construction: 1988, TECHNICAL DATA. Max. clamping length: 90 mm Tool clamping height with tapered shank: 50 mm Tool clamping height with straight shank: 45 mm Max. helix angle: 45° Number of clamping positions: 1 to 99 Max. slide travel: 550 mm Max. grinding wheel diameter: 350 mm Min. grinding wheel diameter: 150 mm Grinding wheel speed (variable): up to 2700 rpm Swivel range of grinding spindle axis: 0° to 15° Grinding slide feed rate (variable): 0.05 to 16 mm/min (with 3rd and 4th axis: 0.05 to 8 mm/min) Workpiece spindle taper: ISO Taper No. 40 Rsdpfx Aowwkacslcecf Grinding Wheel Data CBN and diamond cup grinding wheel: Ø200 mm → Min. DFF: 66 (3rd axis), 76 (4th axis) Ø250 mm → Min. DFF: 16 (3rd axis), 26 (4th axis) CBN-ES cone grinding wheel: Ø200 mm → Min. DFF: 50 (3rd axis), 60 (4th axis) Ø250 mm → Min. DFF: 0 (3rd axis), 10 (4th axis)

Condition: used, Year of construction: 2018, workpiece weight (max.): 35,000 kg, total length: 15,600 mm, total height: 6,000 mm, total width: 6,000 mm, overall weight: 155,000 kg, The Pittler WMZ PV4000 / 1-2 is a heavy CNC vertical turning machine with a portal design, featuring one workpiece spindle and two independently movable tool carriers. The machine enables turning, drilling, milling, and grooving. The right tool carrier is designed as a swiveling multifunction head with a B-axis and driven tools. Two separate chain magazines provide a total of 94 tool positions. Technical Data Machine Number: ZV029 Machine Concept: Portal machine with one workpiece spindle and two tool carriers Machining Processes: Turning, drilling, milling, and grooving Maximum Swing Diameter: 3800 mm Maximum Workpiece Diameter: 3800 mm Maximum Workpiece Speed: 100 min-1 Rated Speed: 36.7 min-1 Workpiece Clamping: Manual Chuck: Röhm Tool Holder: Capto C8 Tool Magazines: 2 chain magazines Tool Positions: 2 x 47 Total Number of Tool Positions: 94 Maximum Tool Diameter: 120 mm according to the operating manual Maximum Tool Diameter: 150 mm according to the order confirmation with appropriate magazine loading Maximum Tool Length: 400 mm Maximum Tool Weight: 20 kg Travel Paths X1-Axis Right Tool Carrier: 3200 mm X2-Axis Left Tool Carrier: 2800 mm Z1-Axis Right Tool Carrier: 1000 mm Z2-Axis Left Tool Carrier: 1000 mm Rapid Traverse X-Axes: up to 32 m/min Rapid Traverse Z-Axes: up to 20 m/min Workpiece Spindle Gear Reduction: 1 to 30 Maximum Speed: 100 min-1 Rated Speed: 36.7 min-1 Rated Power: 67.4 kW Short-Term Total Power: 202.2 kW Rated Torque: 52.65 kNm Maximum Drive Torque: 71.55 kNm Torque according to Order Confirmation: 67000 Nm at 40% duty cycle Motor Spindle Power according to Order Confirmation: 200 kW at 100% duty cycle Maximum Spindle Load Capacity including Chuck, Clamping Jaws, and Workpiece: 35000 kg Spindle Flange Diameter: 1900 mm Thrust Bearing Diameter: 1400 mm The workpiece spindle is designed as a water-cooled motor spindle with precision axial deep groove ball bearings. Tool Carrier and Multifunction Head The right tool carrier features a swiveling multifunction head with two Capto C8 holders for turning tools as well as drilling and milling tools. B-Axis for Stepless Positioning Swivel Range: 180 degrees Speed of Driven Tools: up to 6000 min-1 Tool Spindle Torque: approx. 120 Nm at 100% duty cycle Hydraulic Clamping Direct Measurement System Direct Coolant Supply High-Pressure Coolant Supply: up to 70 bar Tool Magazines Two chain magazines with 47 tool positions each Tool Holder: Capto C8 Maximum Tool Diameter: 120 mm Up to 150 mm with appropriate magazine loading Maximum Tool Length: 400 mm Maximum Tool Weight: 20 kg Tool Cleaning with Blowing Air Manual Magazine Loading Coolant and Chip Disposal Two Knoll Chip Conveyors Type 600 S-2/120 Knoll Band Filter Type KF400-2300 Additional Equipment Röhm Chuck Rcedpfx Aljzwa Rbjcef Spindle Cooling Hydac FLKS-4S Hydraulic Unit Hydac TBM20 Electrical Data Operating Voltage: 3 x 400 VAC Protection Class: IP55 Maximum Power Consumption: 280 kVA Component weight max.: 35,000 kg Swing: 3,800 mm Rotation height max.: 2,100 mm Weight approx.: 155,000 kg Dimensions (LxWxH) approx.: 15600 x 6000 x 6000 mm Table diameter: 3,800 mm Control: Siemens SINUMERIK 840D sl Year of construction: 2,018 Condition: good Terms of payment: 100% prepayment before pick-up Terms of delivery: EXW EX Works under power: Yes

Condition: excellent (used), Year of construction: 1995, Maximum height 330 mm Distance between centers 2000 mm Working range: Maximum turning diameter over the bed cover 650 mm Rodpfex Sx Htex Alcecf Maximum turning diameter over the bed slide 360 mm Main spindle: Spindle diameter in the front bearing 140 mm Spindle bore 107 mm Main drive 58.5 kW 2-stage speed range 4 – 750 rpm / 750 – 3060 rpm Feed drive: Rapid traverse X/Z axis 10/10 m/min Drum turret: Number of tool positions 12 Of which, driven tool positions 6 Cylindrical shank holder VDI 50 mm Dimensions / Weight: Footprint L x W x H approx. 6400 x 2150 x 2000 mm Weight 9400 kg Accessories / Special Features: • CNC path control HEIDENHAIN TurnPlus EP 90 with color screen • Spindle orientation C-axis • 12-position turret, VDI 50, of which 6 positions with driven tools in the turret, manufacturer SAUTER DIN 5482 B 20x17, max. speed 3000 rpm • Hydraulic 3-jaw chuck Ø 315 mm with various clamping jaws • Hydraulic tailstock with drag device • Hydraulic quill actuation • Air extraction system, manufacturer LTA • Various tool holders VDI 50 • CE compliant In 08/2025, GILDEMEISTER Service replaced the following parts: 1 servo motor, 1 AC servo controller power module for 2 axes, 1 power module Simodrive, 1 feed-in/feed-out module, 1 control module for 1 axis, 1 control module for 2 axes, inverter servo drive, 1 Simodrive power module (1-axis motor) Total repair costs: EUR 17,000.00 net Important NOTE: In this very well-maintained CNC turning and milling center GILDEMEISTER CTX 600-2000 (year of manufacture 1995), the C-axis positioning does not function. Otherwise, the machine is in perfect condition. Demonstration under power is possible at any time by prior appointment. Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: excellent (used), Year of construction: 1998, operating hours: 17,260 h, Table size: 1000 x 500 mm Tool holder: ISO 40 Travel paths: X-axis: 800 mm Y-axis: 500 mm Z-axis: 420 mm Rjdpfx Alsxtu H Njcecf Distance between horizontal spindle axis and table: 210 – 630 mm Distance between vertical spindle nose and table: 130 – 550 mm Table load capacity: max. 500 kg Speed range: 50 - 4000 rpm Feed rate (infinitely variable): 5 - 2000 mm/min Rapid traverse in all axes: 8 m/min Vertical milling head, swiveling: ± 90° Manual quill stroke adjustment: 100 mm Drive power: 7.5 kW Dimensions (L x W x H): approx. 3000 x 2400 x 1975 mm Weight: approx. 3000 kg Accessories / Special features: • CNC contouring control HEIDENHAIN TNC 410 • Electronic handwheel HEIDENHAIN HR 410 • SIEMENS AC servo drives • Data interface V 24 / RS 232 • Swiveling vertical milling head ± 90° right & left with 100 mm quill adjustment • Hydraulic tool clamping, vertical & horizontal, ISO 40 • Swivel-away device for the vertical milling head • Very wide speed range up to 4,000 rpm • Vibration-free operation thanks to rigid and heavily ribbed cast iron guideways • Ball screws for X, Y, and Z axes • All electrical control elements on one side, in a movable control panel • Fixed angle table with foldable chip guard • Coolant system integrated in the machine base • Hydraulic unit • Central lubrication • CE compliant Operating hours: 17,256 Spindle hours: 3,816 Image: shows brochure photo Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany

Condition: ready for operation (used), Year of construction: 1984, Immediately available from training center: MAHO Tool Milling Machine Rcedpezwud Aefx Alcjf Model MH 600 Year of manufacture: 1984 Table: 700 x 400 mm Travel X/Y/Z: 500/400/400 mm Speeds: 40 – 2500 rpm SK 40 Spindle stroke: 80 mm Coolant system Drive: 4 kW Feeds: 8 – 400 mm/rev Head swivels 90/90 degrees Weight: 1900 kg Price: EUR 2,250.-- plus VAT, ex location.

Condition: ready for operation (used), Year of construction: 1995, Available immediately ex location: CNC tool milling machine Deckel, type FP 5–80, year of manufacture 1995, CNC control Dialog 12, universal table 750 x 520 mm. Travels X/Y/Z: 800/550/500 mm. Drive power: 9 kW. Quill stroke: 80 mm. Electronic handwheel. Spindle speeds: 32–5000 rpm. Feeds: 0–6000 mm/min. Weight: 4.5 t. Price: EUR 2,750 plus VAT, ex location. Rcodjzwuc Espfx Alcef

Condition: used, Year of construction: 1970, total height: 1,700 mm, total length: 1,400 mm, total width: 900 mm, Colour: Grey Empty weight: 500 kg - Year: 1970 Rcedjzry I Ajpfx Alcsf - Documentation available: No - CE certificate present: No - Serial number: CH - Control: Conventional - Motor power: 1.4kW - Transport dimensions: 1400mm x 900mm x 1700mm (l x w x h) - Transport weight [kg]: 500kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 1998, total height: 1,500 mm, total length: 1,200 mm, total width: 110 mm, Colour: Cream Empty weight: 750 kg Price: On request Rcedpfx Aljzry Ivecjf - Year: 1998 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: 84915 - Control: Conventional - Transport dimensions: 1200mm x 110mm x 1500mm (l x w x h) - Transport weight [kg]: 750kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 2015, Technical details: max. turning diameter: 255 mm turning length: 500 mm control: FANUC 31i manual guide swing dia.: 270 mm centre distance: 639 mm bar material dia.: 66 mm travel -x axis: Rev. 1+2:: 190 mm travel -y axis: Rev. 1+2: +- 40 mm travel -z axis: Rev. 1+2: 500 mm spindle turning speed - stepless: S1 / S2: 4000 / 5000 1/min spindle nose: A2-8 / A2-6 spindle bearing diameter: 120 / 100 mm C-Axis: 0,001 ° Turret No.1 stations / rotary tools: 12/12 Turret No.2 stations / rotary tools: 12/12 Driven Tools: 6000 1/min rapid traverse X-axis: 16 m/min rapid traverse Y-axis: 12 m/min rapid traverse Z-axis: 20 m/min spindle drive: S1: 15/11, S2: 7,5/5,5 kW Rsdpfxjzv Tmte Alcocf Driven Tools: 18 kW total power requirement: 65 kVA weight of the machine ca.: 9,6 t dimensions of the machine ca.: 2,85 x 2,2 x 2,05 m CNC-turning-center with 2 turrets, 2x 12-pockets (24 position) turret with 12 live-tools, Y-axis on both turrets. subspindle travel 635mm, rapid feed 30 m/min, chipconveyor, approx. ? h "machine on", approx. ?h "spindle on" *

Condition: excellent (used), Mazak Quickturn Nexus 300 CNC Lathe Rcedpezh Ndxofx Alcef Capacity Maximum bar size diameter - 77mm Maximum cutting dia - 420mm Maximum swing - 680mm Spindle Main spindle speed : Max 4,000rpm / Min 35rpm Main spindle workpiece weight ( including chuck) 450kg Spindle bore - 88mm Spindle centre line - 1080mm Spinel nose - A2-8 Axis Travel X axis 225mm Z axis 680mm Cutting feedrates (x axis max) 8m/min (z axis max ) 8m/min Rapid traverse X axis (max) 30m/min Z axis (max) 25m/min Turret Toolsize turning tool shank - 25 x 25 Turret indexing time 1/2 full turn 0.8 secs single step 0.2 secs No of stations on drum turret 12 Tailstock (not chucker) Body movement motor driven Body stroke 645mm Mounting taper No5 Standard centre supplied No5 Chucking systems Chuck cylinder S2078-15Y Chuck Type B210A815X Jaw stroke on diameter 8.8mm Main chuck diameter 10" Mazatrol PC Fusion CNC 640T Nexus CNC Control

Condition: excellent (used), Webster Bennett 48" Elevating Rail Vertical Turning Lathe With Copying attachment Redpfxezh Ndrj Alcjcf 48" diameter table Can be shown demonstrating at our premises if you wish to view.

Condition: excellent (used), Webster & Bennett 72" Elevating Rail Vertical Turning Lathe with copying attachment 72" diameter table Rcsdpozh Ndfefx Alcjf Can be shown demonstrating at our premises if required.

Condition: used, Year of construction: 2015, functionality: fully functional, Model: OKUMA MULTUS U3000 2SW 1500 (CNC turning and milling center) Control: OKUMA OSP-P300S Turning length: approx. 1,500 mm Max. turning diameter: up to 650 mm Tool system / interface: HSK-A63 Main spindle: Drive power: 22 kW Torque: 427 Nm Max. speed: 5,000 rpm (2 gear stages) Spindle nose: Short taper size 6 Spindle front bearing: Ø 120 mm Spindle bore: Ø 80 mm 3. Counter spindle (Okuma motor spindle) Travel: Traversable on the W-axis Drive power: 22 kW Torque: 427 Nm Max. speed: 5,000 rpm Spindle nose: Short taper size 6 Spindle front bearing: Ø 100 mm Spindle bore: Ø 62 mm Tool spindle / Milling spindle (Okuma motor spindle) Drive power: 22 kW Torque: 120 Nm Max. speed: 12,000 rpm Tool holder: HSK-A63 Axes & Travel Ranges C-axis: 360° (Indexing / Positioning in 0.001° increments) Y-axis: Stroke +125 mm / -125 mm (Total stroke 250 mm) B-axis: 240° (Indexing / Positioning in 0.001° increments) Rcsdpfszu I U Asx Alcof Tool magazine & Turret Tool Magazine (ATC): 120 positions Lower turret: 12 stations with direct mounting system "radial" Turret guides: ZB-axis with cylindrical roller linear guide XB-axis with slide guide Coolant supply / Internal coolant supply (ICS): max. 20 bar (including bag filter) External cooling for tool spindle: max. 8 bar Accessories: Short loader LNS Quick Load Seri O III

Condition: excellent (used), Item description: Assortment of SK40 collet chucks, 45 pieces, HAIMER, Garant, etc. ----- Item condition: The goods come from a company liquidation. Rjdpfxezwvrne Alcscf Condition: used Internal number: 26.527

Condition: used, Year of construction: 1982, machine/vehicle number: 18613, KUNZMANN universal tool milling machine, model UF 6 NR Year of manufacture 1982, 2 gear stages, 1400/2800 rpm, Rcsdpfjiqkc Ijx Alcof Table size 860x240mm, 3 T-slots 14mm, spindle mount SK30, Travel ranges: X/Y/Z = 450/200/430mm, horizontal speeds: 18 stages from 32-1342 rpm, vertical: 18 stages from 72-2988 rpm, 12 feeds in the X-axis, separate coolant tank, chip guard, machine lamp, 3 horizontal milling arbors each with a milling cutter, 2 overarm milling arbor bearing blocks, 1 collet chuck with wrench. 1 machine vise with crank.

Condition: used, Year of construction: 2008, control Siemens 840D powerline swing diameter 640 mm turning diameter 640 mm spindle distance 1.930 mm x1 axis 550 mm y1-axis 220 mm z1 axis 1585 mm b-axis 240 ° x2-axis 225 mm z2-axis 1.400 mm z3-axis 1.500 mm chuck diameter 250 - 400 mm Redpfx Aljzupqrscocf bar material dia. 90 mm spindle head 220 h5 spindle bore diameter 107 mm diameter in the front bearing 150 mm chuck diameter 400 mm bar material dia. 90 mm spindle head 220 h5 spindle bore diameter 107 mm diameter in the front bearing 150 mm turning speeds 3.200/4.000 U/min tool taper HSK63-A spindle tunring speed 12.000 U/min drive capacity - main spindle 100/40% ED 13,2/22 kW Torque (100% ED / 40% ED) 60/100 Nm bearing diameter 80/55 mm Number of working hours ca. 96.571 h spindle hours ca. 43.720 h In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and work-holding devices shown are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data and specifications, and prior sale.

Condition: used, Year of construction: 2007, turning diameter 65 mm turning length 150 mm control Siemens 840D spindle passage 75 mm turning length 150 mm c-axis 2x 0,001 ° gripping station 65 mm speeds 5000 U/min rapid traverse 30 m/min turret (x-stations) 3x12 Number of axles 10 St. number of toolholder-holes 36 chip conveyor ja / yes kW coolant filtering unit ja / yes kW Number of working hours 35000 h total power requirement 22 kW weight of the machine ca. 9 t dimensions of the machine ca. 4,4 x 2 x 2,3 + Iemca m DMG Sprint 64 Linear CNC lathe, built in 2007, 10 axes, 2 spindles, 3 turrets with Iemca Master 880 loading magazine Accessories: a large number of tool holders in total 104 off, 24 of them are driven tool holder Rcsdpezdk Evjfx Alcef

Year of construction: 1988, condition: used, diameter different mm weight 200 kg Type different 0 14 pieces arbors for milling tools and 4 steadies, 2 for FU 400 (84 mm hole Rcodpsipyybefx Alcjf dia.), 1 for FU 315 (70 mm hole dia.) and one small one (35 mm hole dia.).

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, Monforts RNC 500 MultiTurn, year of manufacture 2007 The machine was last serviced by Monforts Werkzeugmaschinen GmbH in July 2025 and is in excellent condition. Rodpfxexcwdvo Alcecf All tools and accessories are included. Inspection possible by appointment.

Condition: good (used), Lot of diamond grinding tools for jig grinding machines. Some are new and unused, while others are in good condition. Make an offer. See also: HAUSER , MOORE , EXERON , FEHLMANN , KERN ... Rcedpfx Alszxfbhocof

Condition: ready for operation (used), Year of construction: 1993, swing diameter 1400 mm faceplate diameter 1500 mm Control Sinumerik 850T Rcedpfxovxa Tpj Alcef work height max. 1400 mm Tool changer 12 stck. workpiece weight 5 t YEAR OF CONSTRUCTION: 1993 Mechanical overhaul: 2010

Condition: used, Year of construction: 2001, turning diameter 390 mm Rodpfsx Tu Susx Alcecf centre distance 1850 mm swing diameter 610 mm control SINUMERIK 840D turning speeds 20-4000 U/min spindle bore 79 mm bar capacity 65 mm weight of the machine ca. 18000 kg total power requirement 33 kW Control System Siemens Sinumerik 840D Bed Design: 4-rail bed Guideways: Roller guides Working Area Maximum swing diameter: 610 mm Standard turning diameter: 390 mm Distance between spindles: 1850 mm Traverse travel cross/longitudinal – Slide 1: 605 / 1470 mm Y-axis – Slide 1: 210 mm B-axis – Slide 1: 240° Traverse travel cross/longitudinal – Slide 2: 227 / 1440 mm Longitudinal travel – Slide 3: 1460 mm Turning and Milling Spindle – Slide 1 Number of tools: 80 Tool holder: HSK-A63 Max. spindle speed: 12,000 rpm Max. drive power 40/100% duty cycle: 10 / 15 kW Indexing unit: 1.0° Clamping torque (locking): 500 Nm Spindle 1 – Left Max. bar capacity: 65 mm Spindle nose faceplate: 220 h5 Spindle bore: 79 mm Internal draw tube: 68 mm Front bearing diameter: 140 mm Spindle 2 – Right Max. bar capacity: 65 mm Spindle nose faceplate: 220 h5 Spindle bore: 79 mm Internal draw tube: 68 mm Front bearing diameter: 140 mm Main Drive 1 and 2 – Left / Right Max. drive power 40/100% duty cycle: 25 / 33 kW Speed range: 20 – 4000 rpm Rated speed: 700 rpm Max. torque 40/100% duty cycle: 840 / 460 Nm Drive type / design: AC / 1 Design: Integrated spindle motor C-axis speed (rapid traverse): 100 rpm C-axis torque (holding torque): 350 Nm C-axis indexing accuracy: 0.025° Slide 1 Rapid traverse speed X/Ys/Z: 46 / 24 / 60 m/min Feed force X/Ys/Z: 11 / 16 / 11 kN Position resolution X/Y/Z: 0.001 mm Ball screw X (d × p): Ø40 × 15 mm Ball screw Ys (d × p): Ø40 × 10 mm Ball screw Z (d × p): Ø50 × 25 mm Slide 2 Rapid traverse speed X/Z: 24 / 60 m/min Feed force X/Z: 7.5 / 11 kN Position resolution X/Z: 0.001 mm Ball screw X (d × p): Ø32 × 15 mm Ball screw Z (d × p): Ø50 × 25 mm Slide 3 Rapid traverse speed Z: 60 m/min Feed force Z: 12 kN Position resolution Z: 0.001 mm Ball screw Z (d × p): Ø50 × 25 mm Tool Changer – Turret Head Gripper type: Double gripper Control type: Cam-controlled Tool change time G1/G2: 1.3 / 2.6 s Tool Spindle Speed 4000 rpm Coolant Unit 180 liters

Condition: used, Year of construction: 2005, turning length: 705 mm, turning diameter: 356 mm, travel distance X-axis: 260 mm, travel distance Z-axis: 795 mm, controller model: MORI SEIKI MSX-850, TECHNICAL DETAILS Turning diameter: max. 356 mm Standard turning diameter: 275 mm Turning length: max. 705 mm Travel in X-axis: 260 mm Travel in Y-axis: ±50 mm Total travel in Y-axis: approx. 100 mm Travel in Z-axis: approx. 795 mm Rapid traverse rate X/Y/Z: 30 m/min Tool stations: 12 Rsdpfxezwgwze Alcecf MACHINE DETAILS Design: SY with Y-axis Control system: MORI SEIKI MSX-850 Bar feed magazine: LNS Quick Load Servo 2 Bar length: max. approx. 1,500–1,600 mm / 63″ EQUIPMENT Tailstock Driven tools Y-axis LNS Quick Load Servo 2 bar feed magazine

Condition: used, Year of construction: 2013, operating hours: 10,322 h, functionality: fully functional, machine/vehicle number: NL254130510, We are offering this used DMG MORI NLX 2500 SY/700 CNC turning and milling center, manufactured in 2013, complete with a short bar loader magazine ILS-MKU 70/100, manufactured in 2015. Turning diameter max. 366 mm Turning length 705 mm Swinging diameter over bed 920 mm Swinging diameter over cross slide 742 mm Spindle speed range - main spindle 3,500 rpm Drive power - main spindle 18.5 / 15 kW Spindle nose JIS A-8 Spindle bearing diameter 140 mm Spindle bore 90 mm Max. usable bar diameter 80 mm Spindle speed range - counter spindle 6,000 rpm Drive power - counter spindle 11 / 7.5 kW Spindle nose JIS A2-5 Spindle bearing diameter 85 mm Spindle bore 43 mm Max. usable bar diameter (-) mm X-axis travel 260 mm Z-axis travel 795 mm Y-axis travel +/- 50 mm Rapid traverse (X / Y / Z) 30 / 10 / 30 m/min Number of tool positions 12 Tool holder BMT 60 Spindle speed range - driven tools max. 10,000 rpm Drive power - driven tools 5.5 / 3.7 kW Total power consumption 40 kVA Machine weight approx. 6.4 t Short bar loader magazine ILS-MUK 70/100 Type: MUK 10016-II Year of manufacture: 2015 Material diameter: 6-100 mm Rodpfx Alszwvv Tocecf Material length: 250-1650 mm Length: 2400 mm Width: 1600 mm Outreach: 330 mm Weight: approx. 680 kg If you have any questions or require further information, please feel free to send us a message or call us.

Condition: good (used), Year of construction: 1982, functionality: fully functional, Tool milling machine with 3D control, manual handwheels, and a universal table adjustable in three axes. Control: Deckel Dialog Control 4: 3D contouring control, including drilling and milling cycles Monitor, electronic handheld control panel Terminal for program input and output Technical specifications: Travel range X/Y/Z 300 x 220 x 400 mm Speed 31.5 - 3,150 rpm with 21 gear stages Feed rate 4-2,000 mm/min Rapid traverse 4 m/min Drive power 1.6-2.0 kW SK 40 tool holder Hydraulic tool clamping Universal milling table with digital display: Clamping area 600 mm x 320 mm Table load 180 kg C-axis rotation range 360° A-axis tilt range 15°/45° B-axis swivel range +/- 45° Vertical milling head: Manual quill stroke - horizontally 65 mm, vertically 60 mm Additional equipment: Manual machine handwheels with scale Direct travel measurement of the NC axes Cooling water system Special accessories: Approx. 33 tool holders (without tools) - see photo High-speed milling spindle Rcsdjwid Spspfx Alcjf Machine data: Machine weight approx. 1,380 kg Space requirement including accessories L approx. 2,940 mm, W approx. 1,900 mm, H approx. 1,960 mm Power supply: 380 V, 50 Hz, 12 kVA The machine is in good, fully functional condition. It can be inspected with power and chippings by appointment.
