Arico GmbH

Condition: new, Year of construction: 2025, Offer: New Chip Processing System – Complete HYDRAMAX 4 System For sale is a brand new HYDRAMAX 4 chip processing system from T&A Trenntechnik & Anlagenbau GmbH. The system has never been put into operation and comes with a 12-month manufacturer's warranty or 2,000 operating hours (whichever comes first). Technical Specifications & Component Overview: • Model: HYDRAMAX 4 • Application: Drying and deoiling of aluminum chips (e.g., EN-AW6082) • Throughput: Up to 1200 kg/h for steel chips, approx. 400 kg/h for aluminum chips • Suitable for: Chip volumes up to 870 tons/year in 3-shift operation System Components: 1. HYDRAMAX 4 Chip Deoiling Centrifuge • Hydraulic moving floor, drum with stainless steel screen, centrifugal force: 503 x g 2. HKG 500 Lifting and Tilting Unit • Load capacity: 500 kg, discharge angle: 150°, discharge height: 2200 mm 3. V600 Chip Crusher • Aluminum throughput: Up to 750 kg/h, safety slip clutch 4. Two Scraper Belt Chip Conveyor (KF 300/380/2 and KF 230/380/2) • Conveyor made of manganese steel, incline angle: 60° 5. Tank (180 liters) • With flushing and removal pump, level monitoring 6. Ultrasonic sensor • For level monitoring 7. Protective grille • Electrically locked, DGUV-compliant 8. Hydraulic unit • 3 kW motor, 130 L oil tank Klslhjwdt Upjcdw Her Warranty: The warranty is for 12 months or 2,000 operating hours – whichever comes first. It covers full functionality when used properly according to the operating instructions. Condition: The system is brand new, unused, and currently disassembled. It is ready for immediate use and is ideal for integration into existing production or disposal lines.

Condition: good (used), Year of construction: 2002, CNC LATHE MUPEM WIN 65 2002 Max. bar capacity: 65 mm Front spindle bearing diameter: 110/150 mm Collet clamping system up to Ø: 60 mm HAINBUCH collet system up to Ø: 65 mm Maximum spindle speed: 3000 rpm Main spindle motor power: 11/15 kW MAIN TURRET Number of tools: 8 VDI-30 Maximum working stroke in Z: 50 mm Rapid traverse speed: 15 m/min Feed force: 6790 N CROSS SLIDE Number of horizontal slides: 2 Maximum working stroke at X1/X2: 70 mm Feed force at X1/X2: 8000 at 50 bar Maximum working stroke at Z1: 230 mm ADDITIONAL LOWER TURRET Klolhcjwc Arujdw Hor Number of tools: 8 VDI-20 VERTICAL SLIDES Number of vertical slides: 2 Maximum working stroke in X3 / X4: 70 mm Manual length adjustment: 50 mm Rapid traverse speed: 15 m/min Feed force at X1 / X2: 8000 at 50 bar Machine height: 1700 mm Machine area: 2900 x 1700 mm Machine weight: 4100 kg

Condition: good (used), Year of construction: 1989, Thread rolling machine Kslhcdwswc Aq Re Hjlr ABELE + HÖLTICH RWT 30XG-22 1989

Condition: excellent (used), Year of construction: 1991, Multi-spindle & bar turning machines TRAUB TD 26 1991 * Spindle power 2.2 kW * Number of spindles 4 * Spindle bore 26 mm * Speeds 1.18 > 4750 mm * Total power 3.2 kW * Length L - R 1800 mm * Width V - H 1000 mm * Height 1400 mm * Weight 800 kg * Tool changer 6 tools Additional information Klelhewc Aqwocdw Hjr * Max. round: 26 mm, max. square: 18 mm, max. hexagon: 22 mm * * Bar loader available

Condition: excellent (used), Multi-spindle & bar-turning lathes TRAUB TK 42 * Spindle power 5.5 - 9 kW * Maximum workpiece length 206 mm * Spindle bore 42 mm * Length L - R 2500 mm * Width V - H 900 mm * Height 1700 mm * Tool changer holder 4 slides Kelhowc Aqdscdw Holr

Condition: good (used), Year of construction: 2013, BAR CUTTING MACHINE TRAUB A 25 2013 Turning length: 65 mm Total power requirement: 2 kW Machine weight: approx. 0.7 t Space requirement: approx. 1200 x 700 x 1600 mm Thread length: 40 mm Max. part length: 65 mm Motor speeds: 1400-2800 Bar loader available! Klelewc Amxehcdw Hor

Condition: excellent (used), Year of construction: 2005, CNC Turning and Milling Center MORI SEIKI NL 2500Y/700 Klslhcdwewcdu Rs Hor 2005 MSX 850 Control Technical Specifications: Turning diameter 275 mm Turning length 705 mm MAPPS II MSX 850 Control Swing over bed 923.8 mm Swing over cross slide 755 mm Max. turning diameter 356 mm Max. bar diameter 80 mm Main spindle Speed range - main spindle 4,000 rpm Drive power - main spindle 26 / 22 kW Spindle nose JIS A2-8 Spindle bore 91 mm Spindle bearing diameter 140 mm C-axis 0.001 ° Travel X-axis 260 mm Z-axis 795 mm Y-axis 100 (+/-) 50 mm Turret Tool positions: 12 positions Shaft height for square tool: 25 mm Shaft diameter for boring bar: max. 50 mm Turret indexing time: 0.25 sec. Speed range of driven tools: 6,000 rpm Drive power - driven tools: 5.5 / 3.7 kW Feed rate: Rapid traverse X-axis: 30 m/min Rapid traverse Z-axis: 30 m/min Rapid traverse Y-axis: 10 m/min Tailstock: Tailstock travel: 564 mm Quill diameter: 80 mm Taper: MT 4 Rapid traverse 7 m/min Total power requirement: 37 kVA

Condition: excellent (used), Traub CNC Lathe Type TND 160 Kljlhcdwswa N Rrs Hjr CNC Control TX 8 F Center height 180 mm Bed travel 360 mm Slide travel 180 mm Aperture 42 mm Chuck diameter 140 mm 8-station turret Tailstock

Condition: excellent (used), Year of construction: 2011, CNC Machining Center SPINNER VC 750 Kslhcdowa Alcsw Hslr 2011 SIEMENS 840 D SHOPMILL Technical Specifications: Travel X 760 mm Y 460 mm Z 460 mm Clamping Area 900 x 410 mm Spindle Speed 12,000 rpm Tool Holder SK40 24-Station Tool Changer Max. Workpiece Weight 350 kg

Condition: excellent (used), Year of construction: 2007, CNC Machining Center DECKEL MAHO DMC 835 V 2007 Heidenhain iTNC 530 Technical Specifications: X-AXIS MOVEMENT: 835 mm Y-AXIS MOVEMENT: 510 mm Kjlhcdjwa Ahkow Helr Z-AXIS MOVEMENT: 510 mm WORKTABLE OUTER LENGTH: 1000 mm OUTER WIDTH: 560 mm TABLE LOAD: 800 kg

Condition: excellent (used), Year of construction: 2004, CNC Machining Center Wagner VMC 1100 Year of manufacture: 2004 Control: Siemens 810D Technical specifications: Travel paths: - X-1100, Y-650, Z-600mm Main spindle: - Max. 8000 rpm Tool changer: - 24 magazine positions Klslhcdwswaz Ddj Hor BT 40 Work table: - 1300mm x 600mm - Table load capacity: 500kg

Condition: excellent (used), Year of construction: 2009, Turning diameter 350 mm Turning length 650 mm Swing over bed 385 mm Swing over cross slide 350 mm Distance spindle nose to tailstock 902.5 mm Main spindle: Speed range - main spindle 0 - 4,000 rpm Drive power - main spindle 15.3 / 11.5 kW Max. torque 430 Nm Spindle diameter in front bearing 100 mm Spindle bore 87 mm Max. bar diameter 52 mm Usable bar diameter 52 (45) mm Max. chuck diameter 250 mm Klelov Umldohcdw Hor Chuck diameter 165 mm Spindle head 170 h5 C-axis 0.04 ° Tool turret: Number of tool positions: 12 positions Shank diameter DIN 69880: 30 mm Driven tool stations: Number of driven tool stations: 6-position Speed range - driven tool stations max. 4,500 rpm Drive power of driven tool stations: 5.5 kW Travels: X-axis 255 mm Z-axis 800 mm Tailstock: Tailstock travel 680 mm Tailstock mount MT 4 Clamping pressure 6.8 kN

Condition: excellent (used), Year of construction: 2007, CNC MACHINING CENTER YCM XV 1020 A 2007 FANUC CONTROLL Technical Specifications: Klelhev S Unbscdw Hor Travel: X: 1020 mm Y: 520 mm Z: 540 mm Table Clamping Area: 1120 x 520 mm Work Spindle: 10,000 rpm Tool Changer: 24 Stations

Condition: excellent (used), Year of construction: 2008, CNC MACHINING CENTER YCM XV 1250 A 2008 FANUC CONTROLL Technical Specifications: Travel: X: 1250 mm Y: 520 mm Z: 540 mm Table Clamping Area: 1345 x 520 mm Work Spindle: 10,000 rpm Kelhjv S Ulyscdw Hslr Tool Changer: 24 Stations

Condition: excellent (used), Year of construction: 1996, CNC LATHE MORI SIEKI SL25 C Kelsv N Hu Ishcdw Helr 2-AXIS NO TAILSTOCK

Condition: excellent (used), Year of construction: 2003, CNC Turning and Milling Center GILDEMEISTER - GMX 400 linear Year of manufacture: 2003 Siemens control - Milling spindle Kolhcdwev I Sa Hs Holr - Counter spindle - Tool turret - Y-axis - B-axis Technical specifications: Working area Swing diameter: 640 mm Turning diameter: 640 mm Turning length: 1585 mm Main drive (left) Maximum drive power: 45 kW Maximum speed: 4000 rpm Maximum torque: 750 Nm C-axis torque: 600 Nm Main spindle (left) Chuck diameter: 200-400 mm Bar diameter: 90 mm Top slide Rapid traverse speed X/Y/Z: 40/24/70 m/min Slide travel X1/Y1: 550/110 mm Direct position measuring system Turning/milling spindle Tool holder: HSK 63 A Max. spindle speed: 12,000 rpm Spindle axis indexing: 1° B-axis Swivel travel B1: 120° Resolution: 0.001 Tool magazine Number of tools: 60 Tool length / max. number: 200/38-350/22 mm Tool weight: G1/G2: 6/10 kg Tool diameter: 80-140 mm Tool turret: Number of tool positions: 12 positions Tool holder: 40 mm DIN 69880 Number of driven tool stations: 12 positions

Condition: excellent (used), Year of construction: 2018, CNC MACHINING CENTER MTCUT V110y-12TH 2018 Heidenhain 640 Travel mode: X: 1100 mm Y: 710 mm Z: 610 mm Table dimensions: 1250 x 610 mm Spindle speed: 12,000 rpm Klslhcdwsv Iycps Her Spindle mount: SK40

Condition: excellent (used), Year of construction: 2007, CNC machining center (horizontal) TOYODA FH 550 S Kjlhev Ewgtecdw Holr Year of manufacture 2007 Control: Fauna 31i Technical data Travel paths: X: 750mm Y: 800mm Z: 850mm Number of pallets: 2 Size: 550 x 550 mm Max. pallet load: 800kg Spindle speed: 15,000 min-1 Videos available!

Condition: excellent (used), Year of construction: 2002, CNC machining center HEDELIUS CB 60-2000 2002 Technical data: Kolhov A Tlgscdw Hslr X-AXIS TRAVEL 2000 mm Y-AXIS TRAVEL 620 mm Z-AXIS TRAVEL 520 mm RAPID TRAVERSE X-Y-Z 30 - 30 - 30 m/min TABLE SIZE 2500 x 600 mm MAX LOAD CAPACITY 2000 Kg WEIGHT 10500 Kg

Condition: excellent (used), Year of construction: 2008, CNC MACHINING CENTER DECKEL MAHO DMC 64 V 2008 CONTROL SYSTEM: FANUC Technical data: x-travel: 640 mm y-travel: 600 mm Kelhcsvz Updodw Hjlr z-travel: 500 mm Table size: 850 x 630 mm Max. table load 600 kg Spindle taper SK 40

Condition: excellent (used), Year of construction: 2007, Vertical 5-axis machining center Matsuura MAM72-63V Year of manufacture: 2007 FANUC 30iM New spindle 2023 (documents available) Special accessories for the machine: Tool magazine capacity 120 places Pallet changer with 2 pallets HSC. main spindle 40-20,000 min-1 Spindle holder HSK 63 Direct position measuring system Klelsvzzzgjhcdw Hsr KNOLL high-performance coolant system Mentalster REINSHAW OMP 60 Technical data: X-axis: 760mm Y-axis: 845mm Z-axis: 660mm A -120º ~ +30º C 360º Table (pallet) 500 X 500 mm

Condition: excellent (used), Year of construction: 2000, Kondia CM 2500 Year of manufacture 2000 Control Heidenhain TNC 426 Technical data: Travel path X/Y/Z 2500/500/610 mm, 30-way tool changer, Klolhcdwjvzxmae Hjr SK 40, Spindle speed up to 6,000 rpm, Hydraulic unit with 6 connections - electrically operated, IKZ 20 bar, Chip conveyor, Machine weight 13,000 kg, Dimensions 5000 x 2400 x 2700 mm (L x W x H)

Condition: excellent (used), Year of construction: 2000, CNC 5-axis universal machining center DECKEL MAHO DMC 80 U YEAR OF CONSTRUCTION: 2000 CONTROL: HEIDENHAIN New spindle 2023 Technical data: x-travel 800 mm y-travel 700 mm z-travel 600 mm Spindle speed: 0 - 12000 rpm Kelhcjvv Uy Ejdw Holr Milling spindle drive: 10.0 KW Tool holder: ISO 40 Table size: 800 x 635 mm Machine weight approx.: 11 tons

Condition: excellent (used), CNC vertical lathe Kslhcsvuqm Sjdw Helr Gildemeister CTV 250 Working area: Chuck diameter: 250mm X-axis: 800mm Z-axis: 300m Spindle head: 170 h5 Spindle diameter in the front bearing: 120mm Spindle bore: 79mm C-axis Number of work stations: 12 Videos available!!

Condition: excellent (used), Year of construction: 2003, CNC machining center MORI SEIKI NH 5000/40 2003 Technical data: x-travel 630 mm Klolevuql Ujhcdw Hor y-travel 600 mm z-travel 670 mm Tool holder BT 40 Spindle speeds - continuously variable 14000 rpm Pallet change with rotary indexing table 360x1 degree 2 Max. workpiece weight 500 kg Tool change device 60-way Table size 500 x 500 mm Total power requirement 56 kW
