Condition: good (used), Year of construction: 2009, Universal Machining Center Machine type: DMG HSC 105 Linear Control: Heidenhain iTNC 530 Year of manufacture: 2009 TECHNICAL DATA: X-axis: 1,050 mm Y-axis: 800 mm Z-axis: 560 mm Rapid traverse: (X/Y/Z): 90 m/min Max. speed: 28,000 rpm Tool holder: HSK 63 Tool positions: 30 Swivel head Swivel range: +10 / -110° B-axis: 0.001° NC rotary table Table size: 950 mm Max. table load: 800 kg C-axis: 0.001° Features: Cbxbaopuze No internal cooling (ICS) Direct position measuring system Chip conveyor Measuring probe: Heidenhain Tool measurement: Blum Laser 3D quickSET Electronic handwheel Operating mode: 4

Condition: good (used), Year of construction: 2018, Vertical machining center Machine type: Doosan DNM 4500 Control system: Siemens 828 D Year of construction: 2018 TECHNICAL DATA: Travels: X-axis: 800 mm Y-axis: 450 mm Z-axis: 510 mm Rapid traverse: (X/Y/Z): 36 / 36 / 30 m/min. Distance table surface - spindle nose: 150 - 775 mm Speed range: 12,000 1/min. Tool holder: SK 40 Tool positions: 30 Max. Tool weight: 8 kg Tool length: 300 mm Tool diameter: 80 / 125 mm Drg82B Table size: 1,000 x 450 mm Max. Table load: 600 kg Space requirement (LxWxH): 2.158 x 2.615 x 2.985 m Machine weight: 5,000 kg Equipment features: Chip conveyor Coolant system Internal cooling (IKZ): 20 bar Electronic handwheel All machines also optionally available with STENZEL all-round carefree package consisting of dismantling, loading, transportation, unloading, installation and commissioning. If you have any further questions, please do not hesitate to contact us. We look forward to your inquiry. Yours sincerely Joseph Stenzel

Condition: good (used), Year of construction: 2013, Vertical Machining Center Machine type: MTcut V110 T Control: Heidenhain iTNC 530 Year of manufacture: 2013 Commissioned: 2014 TECHNICAL DATA: Travel paths: X-axis: 1,100 mm Y-axis: 610 mm Z-axis: 610 mm Rapid traverse: (X/Y/Z): 32 m/min. Feed rate: (X/Y/Z): 12 m/min. Distance from table surface to spindle nose: 120 - 730 mm Max. speed: 10,000 rpm. Torque: 332 Nm Drive power: 13 kW Tool holder: SK 40 Tool positions: 30 Table size: 1,250 x 610 mm Max. table load: 900 kg Cbhrrtx7S3 Connected load: 35 kW Machine weight: 7,500 kg Features: Chip conveyor Internal cooling (IKZ): 22 bar Coolant tank: 250 l Air through spindle center Electronic handwheel Measuring probe: TS640 Optional options (surcharge): Rotary table: Lehmann EA520, faceplate: 350 Counter bearing Heidenhain CC422, additional axis

Condition: good (used), Year of construction: 2008, Universal machining center: Moving column Machine type: AXA VHC 2 - 1760 XTS Control: Siemens 840 D ShopMill Year of construction: 2008 TECHNICAL DATA: Travels: X-axis: 1,760 (2 x 630) mm Y-axis: 600 mm Z-axis: 800 horizontal or 770 vertical mm Drg80D A-axis B-axis: +/- 100°, hydraulically clamped, infinitely variable interpolation Rapid traverse: (X/Y/Z): 40 / 40 / 30 m/min. Number of controlled axes: 5 Speed range: 30 - 6,000 1/min. Drive power: 30 kW Torque: 143 Nm Tool holder: SK 40 Tool changer Tool positions: 36 NC rotary table: AXA RTA 4L-520 Faceplate: Ø 520, for vertical & horizontal setup mm Tailstock: manual, center height 280 mm Machine weight: 12,000 kg Space requirement (LxWxH): 5.2 x 3.4 x 3.3 m Equipment features: Internal cooling (IKZ): 30 bar Chip conveyor: Discharging to the left, integrated 200 l coolant tank Coolant system Coolant tank: 400 l Measuring probe: 3 D, Renishaw RMP 60 with RMI receiver (wireless version) Optional use of external cooling with compressed air or emulsion Direct path measuring system: Heidenhain Operating mode: 4 Separating plate for work table for pendulum machining Hardened flat guides Counter guides coated with sliding surface (Turcite) Renewal of the sliding surface of the basic slide X/Y in 2022.

Condition: used, Year of construction: 2006, Horizontal machining center Dprhxf Machine type: DMG DMC 100 H Control: Siemens 840D powerline + Shopmill Year of construction: 2006 TECHNICAL DATA: Travels: X-axis: 1,000 mm Y-axis: 1,000 mm Z-axis: 1,000 mm Speed range: 8,000 1/min. Gear stages: 2 Tool holder: HSK 100 Tool positions: 270 / 360 Number of pallets: 2 Pallet size: 800 x 800 mm B-axis: 0.001° Equipment features: Electronic handwheel Operating mode: 4 Oil mist extraction Internal cooling (IKZ): 40 bar Paper band filter Measuring probe: Renishaw OMP 60 Chip flushing gun
