CNC Machining Center

AXA VSC 1

Condition: good (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 480 mm, rotational speed (max.): 6,000 rpm, spindle speed (max.): 3,500 rpm, type of input current: AC, Equipment: rotational speed infinitely variable, AXA VSC 1-1000 M/K – Vertical CNC Machining Center Technical Data Feature | Specification Manufacturer | AXA Entwicklungs- und Maschinenbau GmbH Model | VSC 1-1000 M/K Year of Manufacture | 1991 Machine Type | Vertical Traveling Column Machining Center Control | Siemens 810 M/GA3 Axes | 3 axes, prepared for 4th axis Tool Changer | Automatic Tool Interface | SK 40 DIN 69871 A / 69872 A Tool Magazine | 22-position chain magazine Travel X | 1,000 mm Travel Y | 350 mm Travel Z | 480 mm Table Size | 2,350 × 500 mm T-Slots | 3 × 14 H9 Table Load | 500 kg per 1,000 mm Working Area Height | 230 – 710 mm Distance Spindle Center – Column | 425 mm Spindle Speed | 30 – 3,000 min⁻¹ Spindle Power | 11 kW (100% ED) / 14 kW (60% ED) Torque | 150 Nm (100% ED) / 180 Nm (60% ED) Rapid Traverse X/Y | 15 m/min Rapid Traverse Z | 10 m/min Feed Rate Range | 1 – 999 mm/min Repeatability | ± 0.0075 mm Positioning Accuracy | ± 0.015 mm Measuring Systems | Direct linear measuring systems in all axes Axis Drives | Siemens AC servo motors Ball Screws | In all axes Coolant System | 100 l tank, 40 l/min at 2 bar Chip Conveyor | Hinged belt conveyor, discharge height approx. 1,200 mm Central Lubrication | Automatic Optional Axis | NC rotary table RTA 200, Ø 300 mm Equipment Itodpfx Agsxp Hmae Ush Siemens 810 M/GA3 CNC control 9" monitor with softkeys 48 tool offset pairs Drilling and milling cycles Subprogram technique Teach-in and playback function Programming possible during running machining Full enclosure with splash guard Automatic spindle orientation Operating hour counter Complete machine documentation available

Condition: excellent (used), Year of construction: 2008, operating hours: 35,598 h, functionality: fully functional, machine/vehicle number: 07400004031, spindle motor power: 20 W, spindle speed (min.): 3,250 rpm, spindle speed (max.): 5,000 rpm, bar passage: 90 mm, overall weight: 10,000 kg, bar capacity 90 mm - 2x12 position driven turrets - Y axis in upper turret - tail stock - Siemens 840D power line Control - machine in perfect condition that has always worked with oli - very very well tooled - Lns Sprint S2 barfeed. Itjdpsuyx Hzsfx Ag Ueh

Condition: excellent (used), Year of construction: 2008, x-travel 630 mm y-travel 560 mm z-travel 560 mm Control MillPlus HEIDENHAIN table dimension - longitudinal 1000 mm table dimension - cross 600 mm spindle turning speed range 12000 U/min Number of axles 4 St. Ijdpovwgp Ujfx Ag Usth rapid traverse 30 m/min tool change unit 24 -fach weight of the machine ca. 9 t The DMU 60 monoBlock is in very good condition and immediately available. Accessories: - Measuring probe

Condition: used, TECHNICAL DETAILS - Number of axes : 10 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 16 [mm] - Max. machining length : 184 [mm] - Spindle speeds : 10.000 [rpm] - C axis indexing precision : 0.1 [°] COUNTER-SPINDLE - Max. bar diameter : 16 [mm] - Spindle speeds : 10.000 [rpm] - C axis indexing precision : 0.1 [°] GUIDE BUSH HOLDER 1 - Number of positions : 5 - Number of motorized positions : 3 - Live tools speed : 8.000 [rpm] GUIDE BUSH HOLDER 2 - Number of positions : 5 - Number of motorized positions : 3 - Live tools speed : 8.000 [rpm] END ATTACHMENT - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 8.000 [rpm] SECONDARY OPERATION - Number of positions : 6 - Number of motorized positions : 3 - Live tools speed : 8.000 [rpm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 14 [kVA] MACHINE HOURS - Number of working hours : 54.035 [h] EQUIPMENT - CNC : Fanuc PNC DECO - Rotating tool motor on : S2, S3, S5,S6 - Rotating guide bush - Parts catcher - Coolant tank * with high-pressure pump - Bar loader : IEMCA GENIUS 118 / 32LL - Cooling unit : MARKSA CSW 200 - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. Ijdpfx Aeuhhp Seg Uoth - Number of turning tool holders : 3

Condition: used, Year of construction: 1987, x-travel 500 mm Itedpfet Hw H Eex Ag Uoh y-travel 380 mm z-travel 300 mm Control FANUC total power requirement 12 kW weight of the machine ca. 2300 kg dimensions of the machine ca. m

Condition: excellent (used), Year of construction: 2008, travel distance X-axis: 3,000 mm, travel distance Y-axis: 825 mm, travel distance Z-axis: 1,100 mm, rapid traverse X-axis: 48,000 m/min, rapid traverse Y-axis: 80,000 m/min, rapid traverse Z-axis: 48,000 m/min, table width: 835 mm, table length: 3,500 mm, table load: 3,500 kg, 1 Axis CNC Swivel head, infinitely variable Axis drive with ball screw drive Roller linear guides in all axes Direct path measuring systems Full work area encosure with roof Chip conveyor Coolant unit X - Travel: 3000mm Y - Travel: 825mm Z - Travel: 1100mm B - Axis: - 3 to + 105° Table Length: 3500mm Table Width: 835mm Table load: 3500 Feed rate X-Axis: 48000mm/min. Feed rate Y-Axis: 80000mm/min. Feed rate Z-Axis: 48000mm/min. Spindle Taper: HSK 100ISO/Bt/Mk Ijdpfxjwyv Nze Ag Ujth Power on spindle: 37kW Speeds / ranges: 8000Rpm ATC / revolver: 40 Coolant through spindle / Bar:25 Number of controlled axis: 4 Chip conveyor: Yes Coolantsystem: Yes Length: 8000mm Width: 3800mm Height: 3800mm

Condition: used, Year of construction: 2006, functionality: fully functional, travel distance X-axis: 1,060 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 610 mm, controller model: Ultimax, total height: 2,800 mm, total length: 2,200 mm, total width: 2,400 mm, table width: 610 mm, table length: 1,270 mm, spindle motor power: 18,000 W, number of spindles: 1, number of slots in tool magazine: 24, Equipment: chip conveyor, documentation/manual, 3 axes Tool holder SK 40 Internal coolant Iodpfx Aswtdzrjg Ujth 35 kVA approx. 7550 kg Comprehensive tool package available separately

Condition: used, Year of construction: 2001, Technical details: x-travel: 2500 mm y-travel: 1000 mm z-travel: 750 mm table surface area: 3220 x 1000 mm Workpiece weight approx.: 3000 kg spindle taper ISO: 50 milling spindle turning speeds: 20 - 5000 U/min feed speeds: 1- 30000 mm/min rapid traverse: 30 m/min total power requirement: 40 kW dimensions of the machine ca.: 6,9 x 4,1 x 3,7 m weight of the machine ca.: 21 t with CNC HEIDENHAIN TNC 426 30-pockets autom. toolchanger Iodsvptmwspfx Ag Uoth RENISHAW measuring probe coolant attachment with TSC and chip conveyor diverse toolholders *

Condition: new, ZEATZ NC rotary tables, PHV series – available for short-term delivery The ZEATZ NC rotary tables of the PHV series stand for the highest precision, stability, and flexibility in modern machining. Ideal for positioning, turning, and simultaneous machining in a wide range of applications. Iodpfjm Tvz Djx Ag Usth Your advantages at a glance: ✔ Integration into existing machines (HEIDENHAIN / SIEMENS) ✔ Service & technical support directly from JMT ✔ Individual designs and customer-specific solutions ✔ High load capacity for heavy workpieces Why ZEATZ: ZEATZ represents innovative NC rotary table solutions with the highest precision and reliability. Thanks to their robust design, backlash-free drive systems, and state-of-the-art control technology, these rotary tables are ideal for demanding machining processes. Technical features: Working position: Vertical / Horizontal Applications: Precise positioning, stepless rotation, and interpolative machining in a single setup Sizes: Table diameter: 500 / 600 / 800 / 1,000 / 1,200 mm (optional also with square clamping surfaces) Max. workpiece weight: Horizontal: up to 20,000 kg Vertical: up to 4,000 kg Positioning accuracy: ± 3" Integration: Compatible with HEIDENHAIN and SIEMENS controls Your advantages as a JMT customer: ✔ Official distribution partner for ZEATZ in Germany ✔ On-site technical support and service ✔ Fast spare parts supply ✔ Support with integration and commissioning ✔ Numerous reference projects available in Germany

Year of construction: 1980, condition: good (used), A used very well preserved cycle controlled lathe from Weisser Heilbronn with SIEMENS control. centre distance 2000 mm centre height 295 mm Swing over bed 600 mm Swing over cross slide 260 mm Swing diameter in the bend 800 mm Total length of the crank 375 mm Bed width 450 mm Plan travel X-axis 350 mm Longitudinal travel Z-axis 1850 mm Spindle nose DIN 55022 size 8 Ijdpfogyy I Aox Ag Uoth Spindle speed Number 18 14 - 1400 rpm spindle bore 71,5 mm Diameter of front bearing 110 mm feed range 0,01 - 40,95 mm/rev rapid traverse 8 m/min Direct current drive 15 kW 400V 50Hz Max. permissible torque at the spindle 2500 Nm Tailstock quill 80 mm quill stroke 250 mm inner taper quill MK 5 Length x width x height Weight of the machine 5500 kg Accessories Tailstock Pneumatic three-jaw chuck with interchangeable jaws 315mm Quick change holder "MULTIFIX "in front of the center size "C Quadruple turret behind the center Tool holder Coolant device Pneumatic steady rest Technical data and dimensions: Errors excepted. Videoconference via whatsapp possible by appointment
