Used Biesse Skipper V 31 for sale (37,895)

Condition: used, machine/vehicle number: 008370, X axis working area: 5055 mm Y axis working area: 1930 mm Working Table: Pod and Rail Lredpfxex A Tk Ss Ac Aen Main Electrospindle power: 19 KW Number of controlled axes: 5 axes Maximum edge height: 60 mm Total number of drilling spindles: 28 Total number of tool changer positions: 31

Condition: used, machine/vehicle number: 008480, X axis working area: 4600 mm Y axis working area: 1550 mm Working Table: Pod and Rail Main Electrospindle power: 18 KW Number of controlled axes: 5 axes Total number of drilling spindles: 31 Lrsdoy Edqkopfx Ac Aen Total number of tool changer positions: 58

Condition: used, machine/vehicle number: 008184, X axis working area: 8200 mm Y axis working area: 1600 mm Working Table: Pod and Rail Main Electrospindle power: 13 KW Number of controlled axes: 5 axes Lsdpfeyxmv Nsx Ac Ajrn Total number of tool changer positions: 22

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, CNC machining center X working area: 3855 mm Y working area: 1650 mm Z working area: 245 mm 5-axis electrospindle, 13 kW power, HSK63F interface, liquid-cooled 12-position turret tool changer mounted on carriage 16-position tool changer mounted on X carriage Vertical drilling heads: 20 Horizontal drilling heads X: 4 Horizontal drilling heads Y: 4 Saw blade unit for grooving 8-rail worktable Software: bSolid Heat exchanger for coolant 250 m3/h vacuum pump Safety photocells Chip conveyor Only 3377 hours of program execution Lrsdpfx Aoyuuw Ejc Aen with EPS for automatic positioning of rails and suction cups Suction cups and Uniclamps included Available in July

Condition: excellent (used), C.N.C. WORKING CENTER with 4 axes (X-Y-Z-C) for routering, boring, cutting and edge banding Goose-neck type Numerical Control Type ?? / Software Biesse Works Lrjdpfsy Nk R Eex Ac Aen N. 1 Working table with N. 10 supports ATS (L = mm 1800) Automatic Tools Changing System (Store /14 folds-positions) Useful working area (X - Y - Z) mm 6735 x 1650 x 290 Useful working area (X - Y - Z) in edge banding mm 5780 x 1650 x 60 N. 2 Working areas n. 1 Vacuum pump (capacity m3/h) 250 Front emergency carpets - Motorized carpet to evacuate the wastes from the working process Total power installed KW 31.13 Working group (top): N. 20 Independent vertical boring spindles N. 8 Independent horizontal boring spindles N. 1 Circular Saw N. 1 Vertical electro-spindle HSK F63 (Kw 13,2) Edge Banding group on board, with Glueing Unit (Hot Melt glue) Edges (tape) thickness in rolls (min/max) mm 0,4 - 3 Edge coils supporting unit (N. 4 reels)

Condition: used, machine/vehicle number: 008338, X axis working area: 4500 mm Y axis working area: 1600 mm Ljdpfox A Tkxex Ac Asrn Working Table: Pod and Rail Main Electrospindle power: 15 KW Number of controlled axes: 5 axes Total number of drilling spindles: 41 Total number of tool changer positions: 37

Condition: used, machine/vehicle number: 008389, X axis working area: 8417 mm Y axis working area: 1930 mm Working Table: Pod and Rail Main Electrospindle power: 13.2 KW Lodpfx Ajyqxxrec Ajrn Number of controlled axes: 4 axes Maximum edge height: 60 mm Total number of drilling spindles: 40 Total number of tool changer positions: 22

Condition: used, Year of construction: 2017, machine/vehicle number: 1000025340, functionality: fully functional, travel distance X-axis: 6,735 mm, travel distance Y-axis: 1,650 mm, travel distance Z-axis: 245,290 mm, workpiece height (max.): 60 mm, controller manufacturer: Biesse BH 660, bSolid, bEdge, rapid traverse Z-axis: 30 m/min, rapid traverse X-axis: 85 m/min, rapid traverse Y-axis: 85 m/min, Assembly of the the machine could be done by our subcontractor on the agreed price. Ljdpfxjycvcxe Ac Asrn

Condition: used, Year of construction: 2005, 2005 BIESSE ROVER B 4.40 FT 3-axis CNC machining center Ljdpfey Ud Sgsx Ac Ajrn Technical features in the last photo Engine hours on: 45,343 Machine hours in automatic operation (work): 27,267

Condition: used, machine/vehicle number: 008470, X axis working area: 4300 mm Y axis working area: 2205 mm Ledpfx Aceyzyrve Aorn Working Table: Flat table Main Electrospindle power: 11 KW Number of controlled axes: 5 axes Total number of drilling spindles: 46 Total number of tool changer positions: 22

Condition: ready for operation (used), Year of construction: 2021, travel distance X-axis: 4,140 mm, travel distance Y-axis: 1,270 mm, travel distance Z-axis: 275 mm, number of axes: 5, This 5-axis BIESSE Rover A 1242 was manufactured in 2021. It features a working range of 4140 mm in the X-axis, 1270 mm in the Y-axis, and 275 mm in the Z-axis. The machine is equipped with brushless motors and a PC-based control system for enhanced performance. If you are looking to get high-quality CNC wood machining capabilities, consider the BIESSE Rover A 1242 machine we have for sale. Contact us for further details. • Working range • Y (5-axis): 1270 mm • Y (4-axis): 1260 mm • Z (with H=74 mm vacuum modules): 230 mm • Z (with H=29 mm vacuum modules): 275 mm Lrjdpfoyt Rrvsx Ac Asn • Axes and drives • X & Y: Rack and pinion drive; accuracy class 6 • Z: Ball screw with preloaded nut; accuracy class ISO C7 • Motors: Brushless motors with digital drives via Mechatrolink system • Control system and PC hardware • Control: BH660 (PC-based) with WRT (Windows Real Time) technology • CPU: Intel Core i5 or higher • RAM: 16 GB • Storage: 256 GB SSD or higher • Monitor: 21.5-inch LCD color screen • Operating system: Windows with real-time process management extension • Connectivity: Ethernet card; USB ports • Electrical and pneumatic • Power supply: 380 / 400 / 415 V – 50/60 Hz • Control voltage: 24 V DC (stabilized power supply) • Cabinet cooling: Air conditioning system for operation up to 40°C (104°F) • UPS (uninterruptible power supply): 7–10 minutes runtime for data protection • Workpiece support (ATS system) • Workpiece supports: 8 ATS aluminum supports on linear guides • Module carriers: 24 carriers (132 × 132 × H41.5 mm) with pneumatic clamping • Set-Up Assistant (SA): Manual positioning with LED indicators; ±1.5 mm precision • Vacuum zones: 2 independent work areas in X; 2 independent clamping areas in X • Software and licensing • Primary software: NC-HOPS 7 MacroCAM • Safety and maintenance • Safety system: Bumper system (front and rear) for immediate stop upon collision • Protection: Polycarbonate transparent front plate and sound-absorbing cover • Lubrication: Automatic lubrication system for linear guides and rack/pinion Additional equipment • Vacuum pumps (supported/optional): Up to two units, 90/100 m³/h or 250 m³/h each

Condition: ready for operation (used), Year of construction: 2017, travel distance X-axis: 2,400 mm, travel distance Y-axis: 1,200 mm, number of axes: 3, overall weight: 1,700 kg, spindle speed (max.): 24,000 rpm, This 3-axis BIESSE ROVER J FT 1224 was manufactured in 2017, featuring a working area of 2400 mm by 1200 mm. It includes a CNC electrospindle with a maximum speed of 24,000 rpm, and a flat vacuum table ideal for routing, drilling, and panel machining. Consider the opportunity to buy this BIESSE ROVER J FT 1224 CNC Wood Machining Centre. Contact us for more information about this machine. • Axes: 3 CNC-controlled (X, Y, Z) • Capabilities: routing, drilling, pocketing, panel machining • Air supply: 7.5 bar Lrsdpfxsyfnp Ae Ac Aen • Suction air speed: 30 m/s Additional equipment • Flat vacuum table with suction cups

Condition: used, Year of construction: 2006, functionality: fully functional, TECHNICAL DETAILS Components ADVANTAGE C transverse loader: automatic ROTATING DEVICE (flipper): available BIESSE FTT: with 4 heads, drilling and milling, automatic tool change BIESSE FHT: 2 WORKING UNITS horizontal drilling and dowel insertion WANDRES: brush cleaning from top ADVANTAGE SC transverse unloader: automatic Plate dimensions Plate length: 240 - 3,200 mm Single panel width: 140 - 1,550 mm Plate width: 140 - 800 mm Plate thickness: 12 - 60 mm Drilling units Drill heads FTT 800: Ljdsy Ui Rnopfx Ac Aern 2 machining centres with 4 boring units - 5 working tables Vertical spindles (X-direction): 14 independent per head Vertical spindles (Y-direction): 18 independent per head Horizontal spindles (X-direction): 3 independent, with double output Horizontal spindles (Y-direction): 3 independent, with double output Tool change system Revolver cartridges: 2 Positions per cassette: 56 Application: Automatic tool change of the vertical spindle centers on 4 drilling units of the two machining centers A and B. Milling spindles Electro spindle 1: 3.7 kW (5 HP), ISO 30, with inverter and 3-way tool change rack Electro spindle 2: 3.7 kW (5 HP), ISO 30, with inverter and 3-way tool change rack Lateral positioning units Workstations: 2 for parallel processing of identical or mirror-inverted panels left positioning element: fixed for lateral reference Right positioning element: movable in X-direction, on lower supports, linearly guided Adjustment: automatic according to the X-dimension of the panel Drive: Brushless with digital control Function: Detection of the actual X Length in the machining center, automatic correction of the drilling positions Max. travel speed: 120 m/min Loading and unloading Infeed system: 1 belt conveyor with cross feed, single drive Unloading system: 1 belt conveyor with cross feed, single drive Additional: Cleaning fan in the unloading area Drill heads FHT (horizontal): machining centres with 2 working units (1 LH unit / 1 RH unit) - 3 working tables. HORIZONTAL BORING UNITS with 24 independent spindles to be installed onto 2 operating units HORIZONTAL INSERTING UNITS WITH 5+5 GLUE INJECTORS AND 8 mm. DIAMETER DOWEL INSERTERS TOOL-HOLDER ADAPTOR for the quick change spindles of the boring units. GLUE INJECTION AND DOWEL INSERTING UNIT for 8 mm. dia. dowels to be added to the standard ones. The unit is prearranged for the insertion of 8 mm. diameter and 25-35 mm. long dowels.* The 8 mm. diam. dowel inserting units are required. NOTE: Dowel inserting unit was never used and not tested. Not possible to be tested ADVANTAGE C 3200 TRASV. 1 POS - loading ADVANTAGE SC 3200 TRASV. 1 POS - unloading Security features Standards: CE compliant Safety equipment: Extensive protective enclosures

Condition: excellent (used), Working center with edgebanding unit in very good condition. Lredpfjylcgpsx Ac Aen Technical data will be updated soon.

Condition: good (used), Clamping cylinder, hydraulic clamping cylinder, hydraulic clamp, pneumatic clamp, air cylinder, clamping cylinder for power chuck, hydraulic cylinder -Manufacturer: WV Lenze, clamping cylinder stroke 25 mm -Type: 63 TGL 30-7312 -Shaft Ø 32 mm -Number: 4x clamping cylinders available -Price: per piece Ledpjwzia Asfx Ac Aorn -Dimensions: Ø 90 x 160 mm -Weight: 5.2 kg/piece

Condition: excellent (used), Year of construction: 2015, For sale: 4 units of CNC ROVER BIESSE 2231. Years of manufacture: 2013, 2014, 2015, 2016. In very good condition. Lrjdpfx Acsx Tbk Rj Aen

Condition: used, machine/vehicle number: 007087, X axis working area: 4300 mm Y axis working area: 2200 mm Working Table: Flat table Main Electrospindle power: 12 KW Number of controlled axes: 4 axes Total number of drilling spindles: 40 Total number of tool changer positions: 30 Lsdpfx Acsy Nkrve Aern

Condition: used, machine/vehicle number: 008112, X axis working area: 3390 mm Y axis working area: 1535 mm Working Table: Pod and Rail Main Electrospindle power: 15 KW Ledpfxow Idgvj Ac Aern Number of controlled axes: 5 axes Total number of drilling spindles: 21 Total number of tool changer positions: 14

Condition: used, machine/vehicle number: 008359, X axis working area: 2500 mm Lrjdpfxjx Swcae Ac Ajn Y axis working area: 1320 mm Working Table: Pod and Rail Main Electrospindle power: 13 KW Number of controlled axes: 4 axes Total number of drilling spindles: 16 Total number of tool changer positions: 22

Condition: excellent (used), Flexible N.C. automatic line for drilling, routing and inserting (hardware). Numerical control with Albatros software. Consisting of: KZ2046) Infeeder with hedgehog (buffer) store (18 positions) KZ2047) Transfer with motorised conveyoring belt Lrodpfeidmkrjx Ac Aon KZ2048) CNC Mod. Vector GLR-X 30-13 KZ2049) Transfer with motorised conveyoring belt KZ2050) CNC Mod. Vektor XK 40-13 KZ2051) Transfer with motorised conveyoring belt KZ2052) CNC Mod. Idrak 3 KZ2053) Transfer with motorised carpet with 90° inclination on a rollers table KZ2054) Rollers conveyor with also motorised belts (to move panels at 180° to the assembly lines)

Condition: excellent (used), CNC Flexible Automatic through-feed ROUTERING, DRILLING and DOWELS INSERTING LINE Min/Max workpieces (panels) width (X axis) with FTT: mm 240 / 3100 Min/Max workpieces (panels) thickness (Z axis) with FTT: mm 12 / 60 Min/Max workpieces (panels) length-depth (Y axis) with FTT: mm 140 /1550 (or 800+800) A) Loader (Bridge Frame) "RBO" Double Station, Mod. Advantage C B) Motorized Roller table "RBO" with turning device 90° (length to crosswise) C) Gantry (Portal) CNC (Routering and Drilling) machine "BIESSE" FTT 800 Lsdpfjgvdkgex Ac Asrn Centre A: No. 2 Electro-spindles ISO 30 (Kw 3,7 each) with tool-holder magazine with 3 places each. Centre B: No. 2 predispositions for the installation of other 2 electro-spindles No. 2 tool-holder magazines (revolver) with 56 positions each. No. 4 upper drilling units (total 128 vertical spindles + 36 horizontal spindles) D) Connection transfer, with upsidedown turning machine (180°) "RBO" Mod. Ribaltatore E) Gantry (Portal) CNC (Routering and Drilling) machine "BIESSE" Mod. FTT 800 R8 No.2 horizontal units(1 left+1 right)with 4 BH18 heads with 18 spindles(36 right + 36 left),total 72 Centre A: No. 2 Electro-spindles ISO 30 (Kw 4,5 each) with 3 tool-holder magazine each. Centre B: No. 2 predispositions to install another 2 electro-spindles No. 2 tool-holder magazines (chain) with 60 positions each. No. 4 upper drilling units (total 128 vertical spindles + 36 horizontal spindles) F) "BIESSE" RD dowel insertion unit No.2 horizontal units(1 right+1 left)with 5 insertion nozzles each (5 left + 5 right), tot. 10 nozzles G) Stacker (Bridge Frame) "RBO" Double Station, Mod. Advantage SC

Condition: excellent (used), Complete factory for the production of furniture cabinets, composed by: KZ2207) “BIESSE” FDT - CN Drilling and Dowels Inserting Line, composed by: Loader "RBO" Tornado, 2 x CN Multi-Borers "BIESSE" FDT, 1 x CN Multi-borer and dowels inserter "BIESSE" SDT CN, Stacker "RBO" Tornado Lsdpfxoh T Dvte Ac Aern KZ2205) 4-sides Sizing and Edge Banding LINE "HOMAG", composta da Double-station portal Loader "ESSE2", 1st Double-side Sizing and Edge banding machine "HOMAG" PowerLine KF 20/20/QA/15, Turning station at 90° "HOMAG" TD 31/30/12, 2nd Double-side Sizing and Edge banding machine "HOMAG" PowerLine KF 20/21/QA/35, 2nd Turning station at 90° "ESSE2", Double-station portal Stacker "ESSE2" KZ2210) 'BREMA (BIESSE)' Mod. Vektor CNC-LINE for Drilling-Routering-Inserting: Hedgehog (18 positions), CNC Vektor GLR 30-13, Vektor XL 40-30, Idrak-3, various Transfers KZ2090) Sander (Veneer Sanding machine) "COSTA LEVIGATRICE" SN TR TT TT TR 1350 KZ2045) Gantry-CNC with edge banding unit "MORBIDELLI" Planet HP6018 (2 Tables, 6 reels) KZ2033) Edge bander "HOMAG" KAL 310 with Loader-feeder "ESSE2" KZ2075) Furniture assembling LINE "TERMOPAK" with carcasse press (through-feed) KZ2203) Sawing LINE "SALVADOR" (panels cross-cutter + splitter) with Loader "ESSE2" KZ2009) VENEER Department (double-knife guillotine "MONGUZZI", cross-cut shear "MONGUZZI"; splicing machine "KUPER", guillotine shear "TAGLIABUE", ecc) KZ2201) Short-cycle Pressing LINE "WEMHONER" useful size mm 1300x6200 KZ2215) Automatic panels storage System "ESSE2" Mod. MAGAZZINO N° 3 Saw-dust Filtering Stations "MION" (1st of Kw 132, 2nd of Kw 55, 3rd of Kw 22) Various vehicles (truck, van, etc.) And many other machines (i.e. CNC "BIESSE" Skipper 130, small multi-borers "VITAP" and MORBIDELLI", circular saws, etc.), rollers ways, shelvings, fork-lift, transpallets, etc. Machines still installed at the end-user's factory. They can be inspected by appointment.

Condition: excellent (used), LINE (half line) of Double-side Sizing-Milling & Edge Banding, with automatic handling system. Composed of the following machines: A) LOADER (Portal) with double station "RBO" Mod. Advantage C 3200 and central motorized rollers table. B) Infeeding Rollerway, with double-cone TURNING Device "RBO" Mod. GPK-1 Lredpfx Acohvah Ne Ajn C) Double-side SIZING and EDGE BANDING machine "BIESSE" Mod. Stream SB2 11.0 D) UPSIDE DOWN 180° TURNING MACHINE "RBO" Mod. Ribaltatore E) Outfeeding Rollerway, with double-cone TURNING Device "RBO" Mod. GPK-2 F) STACKER (Portal) with double station "RBO" Mod. Advantage SC 3200, with central motorized rollers table.

Condition: excellent (used), C.N.C. WORKING CENTER 3 axes (X-Y-Z) Movable panel (workpiece), movable working head. Vertical position of the panel (workpiece) Numerical Control TPA - Software Albatros Safety cabin (enclosure) of the working head Panels feeding by motorized chain/track Rubber-coated vertical rollers as fence and feeders during workpieces process In-feeding table (with motorized belts) - Out-feeding table (with motorized belts) With workpiece return system to the operator (180°) Min. useful working area (X - Y - Z) mm 260 x 40 x 10 (ca.) Max. useful working area (X - Y - Z) mm infinite x 1300 x 80 (ca.) Lredpjihfiisfx Ac Asn Separate electric and command cabinet Total installed power (Kw) 35 WORKING GROUPS: Drilling heads with vertical spindles (No.) 1 Independent vertical boring spindles (No.) 24 (7 in X + 17 in Y) Drilling heads with horizontal spindles (No.) 2 Independent horizontal boring spindles (No.) 36 (9 LEFT + 9 RIGHT = 18 x 2) Drilling head motor-power (Kw) 3 x 3 (ca.) Vertical electro-spindle (No.) 1. Vertical electro-spindle motor power (Kw) 7,5 (ca.) Automatic Tools Changing System Revolver, with Tools storage plate (No. of folds-positions) 10

Condition: excellent (used), Year of construction: 2023, functionality: fully functional, Working area X: 3280 mm Working area Y: 1620 mm 5-axis electro-spindle, power 11 kW Drilling heads for vertical drilling: 10 Drilling heads for horizontal drilling X: 4 Drilling heads for horizontal drilling Y: 2 1 grooving blade in the X direction Linear tool changer with 12 positions Work table with 6 stops Software: bSolid Control panel Lrjdpfx Acjy Ukv So Ajn BUSCH vacuum pump, 245 m3/h Safety mats Protective screens Approximate weight: 3400 kg. Electro-spindle used for only 8 hours, condition like new.
