Used Cnc Baz Vertikal for sale (9,005)

Condition: used, ZEISS Multisensory CNC Coordinate Measuring Machine O-INSPECT 442 Professional coordinate measuring machine for optical and tactile precision measurements in industry, research, and quality assurance. For sale is a used multisensory coordinate measuring machine from the manufacturer Carl Zeiss IMT GmbH. The ZEISS O-INSPECT 442 combines highly precise optical and tactile measurement technology in a CNC coordinate measuring machine. The installed ZEISS CALYPSO measurement software enables convenient evaluation of measurement data as well as the display of the actual state, target profile, and deviations. The system is ideal for quality assurance, toolmaking, precision engineering, medical technology, as well as research and development. Technical data: Manufacturer: Carl Zeiss IMT GmbH Model: O-INSPECT 442 Type: Coordinate measuring machine Measuring range X: 400 mm Measuring range Y: 400 mm Measuring range Z: 200 mm Max. workpiece weight: 20 kg Noise level: < 70 dBA Measurement system: Multisensory measurement system Optical and tactile measurement CFS measuring head system CALYPSO measurement software CNC-controlled measurement sequences Djdjzii Dhspfx Apmocp Electrical data: Supply voltage: 100 / 110 / 120 / 125 / 230 / 240 V AC (±10 %) Current type: 1 / N / PE Frequency: 50–60 Hz (±3.5 %) Power consumption: max. 1500 VA Dimensions: Width: 1,055 mm Depth: 1,351 mm Height: 1,770 mm Weight: Coordinate measuring machine: approx. 800 kg Max. workpiece weight: 20 kg Equipment: Integrated control Control panel Computer with peripherals ZEISS CALYPSO Software 5.2 Documentation CFS measuring head system Reference probe Calibration standard Calibration template Applications: Coordinate measuring technology Optical measuring technology Tactile measuring technology Quality assurance Toolmaking Precision engineering Medical technology Research and development Scope of delivery: ZEISS O-INSPECT 442 coordinate measuring machine Integrated control Control panel Computer with peripherals ZEISS CALYPSO Software 5.2 Documentation Measuring head system Reference probe Calibration standard Calibration template Accessories as shown in the pictures Condition: Used Optical condition as shown in the pictures. Normal signs of wear and tear due to age. The table shown in the photos or other items not explicitly mentioned are not included in the sale. Due to its size and weight, shipping is possible via a freight forwarder. Subject to changes, errors and prior sale. We would be happy to answer any further questions by telephone.

Condition: used, CITIZEN CINCOM R 04 VI is a CNC automatic lathe / Swiss-type lathe designed for high precision, accuracy and reliability. It features 6 axes and 2 spindles, max. turning diameter 4 mm, max. turning length 40 mm, internal spindle diameter 9 mm, max. threading diameter 3 M. Main specs: up to 20000 t/min, spindle power 0.5/0.75 kW; tool-holder count 3 with 15 stations; turning tools 5, drilling tools 4, transverse tools 2; tool shank 8 mm; counter-operation 4 tools. Voltage 50 Hz 3x400 V; machine weight ≈850 kg; dimensions L1485×W560×H1410 mm. Accessories: LNS TRYTON 107 Hybrid bar feeder, parts catcher, coolant system, lamp. Ensures tight tolerances; suited to watchmaking, medical, automotive, aerospace and precision components. Dcedpjzv I D Hsfx Apmep

Condition: reconditioned (used), Year of construction: 2006, turning diameter over cross slide: 700 mm, turning length: 3,000 mm, turning diameter: 1,000 mm, spindle bore: 104 mm, total height: 2,600 mm, total length: 7,800 mm, total width: 2,300 mm, overall weight: 14,000 kg, Swing over bed Ø: 1000mm Dcjdpfjz R Nrbex Apmjp Swing over cross slide Ø:700mm DBC Turning Length: 3000mm Spindle bore: 104mm Bed width: 900mm Tailstock spindle Ø: mk5Ø Stroke pinole: 300mm Workpiece weight: 4800 Power: 35A Speeds / ranges: 1600Rpm Length: 7800mm Width: 2300mm Height: 2600mm Weight: 14000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, HAUSER S 50 CNC 311 is a CNC jig grinder delivering precision, high accuracy and reliable performance for demanding grinding tasks. 2‑column execution, table 1020×860 mm, X travel 900 mm, Y 600 mm, vertical slide travel 635 mm, spindle‑to‑table clearance 750 mm, passage between columns 950 mm; max grinding diameter 230 mm (360 mm with intermediate plate); taper grinding up to 16°. Key specs: Z stroke 0–170 mm stepless, stroke speed 1–12000 mm/min, stroke frequency 6 Hz, U‑axis fine feed 6 mm, planetary C motion 5–300 t/min, grinding spindle 4500–80000 rpm (air turbine up to 160000 rpm); supply 3×400 V 50 Hz, total power 9 kVA; weight ≈6300 kg; size 3000×2500×2870 mm. Fitted with retrofitted control, set of grinding arbors, grinding motors 45 S/45 ST and C‑axis; refurbished 2016. Achieves tight tolerances; suitable for automotive, watchmaking, machine tools, aerospace and medical sectors. Dcodpj Afc Tlsfx Apmop

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Dcodpfx Aj Ad Izrepmop Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: used, Year of construction: 2005, CNC Machining Center Manufacturer: IMA Type: BIMA 300 Year of manufacture: 2005 Technical data Work area - Machining area X-axis: 4,300 mm - Machining area Y-axis with main spindle and 20 mm tool: 1,400 mm - Machining area Y-axis with drilling unit (all vertical drilling spindles): 1,100 mm - Max. clamping height above the vacuum suction surface: 125 mm - Max. workpiece thickness: depends on equipment and application - Working height: approx. 950 mm - Two-zone work area without pendulum machining: 2 x 2,050 mm - Average clearance without pendulum machining: 200 mm - Two-zone work area with pendulum machining: 2 x 1,750 mm - Average clearance with pendulum machining: 800 mm Main spindle - Spindle power: 7.5 kW - Tool holder: HSK-F63 - Taper diameter: 38 mm - Automatic tool clamping - Clamping force: 11,000 N - Release force: 20,400 N - Max. tool weight: 6 kg Dsdpfxj Adyhwo Apmscp - Spindle speed: continuously variable, 1,500 - 18,000 rpm - Direction of rotation: programmable, clockwise and counterclockwise - Drive: Three-phase motor with frequency converter - Spindle lubrication: permanently lubricated at the factory - Spindle cooling: air-cooled - Integrated CNC rotary axis for tool positioning over 360°, with torque support and pneumatic connection Axis speeds - Max. rapid traverse X-/Y-axes: 60 m/min - Max. rapid traverse Z-axis: 30 m/min Vacuum, extraction, and compressed air - Required compressed air pressure: 7 bar - Extraction port diameter: 250 mm - Required extraction air velocity: 28 m/s - Required extraction volume flow: 4,950 m³/h - Vacuum pump capacity: 90 m³/h Dimensions and weight - Machine length: approx. 5,750 mm - Machine width: approx. 3,830 mm - Machine weight: approx. 6,000 kg Accessories - 90-degree angle drilling unit - 3 x HSK tool holders Note: The technical data and descriptions are copies of the original order confirmation. The information is provided for informational purposes only and is not binding.

Condition: used, BOEHRINGER / VDF NV 250 T is a CNC vertical turning machine designed for precision machining, high accuracy and reliability. Total axes 4; spindle hole 65 mm; travels Z 260 mm, X 760 mm, Y ±50 mm; rapid traverse X 120 m/min, Z 40 m/min; turret 12 positions VDI 40/DIN 69880. Spindle head A6; stepless up to 4500 t/min; spindle power 31 kW; voltage 50 Hz 3x 400 V; machine weight approx. 8500 kg. Equipment: 3-jaw chuck Ø250 mm with automatic centering, lamp, coolant system, oil mist extractor, automatic loading/unloading unit. Achieves tight tolerances; typical for automotive, aerospace, medical and machine tool sectors Dsdpfx As Adzhljpmocp

Condition: ready for operation (used), Year of construction: 1989, turning diameter over cross slide: 340 mm, turning length: 560 mm, turning diameter: 560 mm, spindle bore: 63 mm, overall weight: 5,500 kg, Fanuc OT Length capacity: 560 mm Dcodszbam Espfx Apmep Diameter over slide: 340 mm, turning diameter: 560 mm Turret: 10 stations Spindle: 11 kW Chip conveyor

Condition: good (used), Year of construction: 2003, functionality: fully functional, Voortman V603 / VB750 CNC Drilling / Sawing Line – Year 2003 Dcjdpfx Apsz Hd Sfemsp Three Spindle. 18 metres In-Feed. 13.5 metres Out-Feed. Pusher Unit Feed. In-Feed Cross Transfers. Out-Feed Cross Transfers. 750mm Section Capacity.

Condition: not inspected (used), Year of construction: 2003, turning diameter: 175 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 125 mm, travel distance Z-axis: 120 mm, CNC Lathe Manufacturer: MURATEC Model: MZ 60 Year of manufacture: 2003 Control system: Fanuc Technical details Turning diameter: 175 mm Dcsdszz S Rzjpfx Apmsp Spindle speed: 6,000 rpm Number of tool stations: 12 positions X-axis travel: 125 mm Z-axis travel: 120 mm Used; sold without warranty Machine transport dimensions (LxWxH) approx.: 1900 x 3100 x 2500 mm Accessories, tools, and workholding devices shown are included in the scope of delivery only if specified in the additional information. Subject to technical changes, errors, and prior sale.

Condition: good (used), Year of construction: 2012, CNC Turning / Millingcenter Machine type: DMG CTX beta 500 V6 Control: Siemens 840 D Shopturn Year: 2012 Working hours: 42.067 h Spindle running time: 20.209 h SPECIFICATIONS Max. turning length: 500 mm Turningdiameter: 410 mm Max. swing over bed: 700 mm Spindle bore: 87 mm Bar capacity: 77 mm C-Axis: 0,01° Main Spindle: ISM 76 Max. revolution: 5.000 rpm Dodpfx Ajz D Ug Ijpmocp Spindle power: 25 / 34 kW Torque: 280 Nm Collet chuck: Hainbuch Spantop Nova 65 Subspindle: ISM 52 Max. revolution: 5.000 rpm 3-jaw chuck: Berg KHL 200 mm Travel Y-Axis: mm Amount of turrets: 1 Tool: VDI 40 Driven Tools: 12 revolution driven tools: 4.000 drive power driven tools : 11,3 kW Equipment Chip conveyor Short Bar Loader: LNS QLS 80 S2 Direct linear scales: X,Y High pressure pumps Toggle filter Tool setter

Condition: used, Year of construction: 2019, Used machine Year of manufacture: 2019 Video available at: Base machine - Dynestic 7535-R Automatic 12.7 Dynestic table For classic nesting machining with wear plate Machining length: 3700 mm Working direction: from right to left Machine frame in welded construction with ground and hardened prism guides for the traversing carriage, aggregate head and consoles Traversing carriage in gantry design Rack and pinion drive, helical, in X and Y direction, Ball screw spindles Z-axis for precise positioning Technical data: Machining dimensions: Max. load on nesting table X = 3700 mm Y = 2200 mm Max. travel distances X = 5295 mm Y = 2935 mm Z = 565 mm Max. clearance height DYNESTIC table Z = 250 mm from the top of the table (without wear plate) Maximum programmable speed Vector speed: 128.0 m/min X = 80 m/min, Y = 100 m/min, Z = 25 m/min 4-stage extraction hood with pneumatic height adjustment and viewing window Voltage 400 V, 50/60 Hz CONTROL: Dual-core processor Operating system: Windows XP 80 GB hard drive / 1 GB RAM RJ45 network connection 10/100 Base-T Fast Ethernet US keyboard and Microsoft IntelliEye mouse (optical) CD-ROM / CD-RW drive (CD burner) Remote maintenance Integrated network card for data transmission of control and program data. Data transmission via high-speed internet connection Requirement: High-speed internet connection to the machine. DYNESTIC table Solid, continuous machining table with grid spacing, continuous grooves in X and Y direction, Groove spacing: 50 mm with 25 meters of sealing cord for securing the wear plate 1 machining field with stop strips / stop Height: 30 mm, pneumatically lowerable 2 stop strips in Y direction and 1 stop in X direction on the right (when viewed from the front of the machine) Vacuum fields 1-circuit vacuum system Drilling unit 7881-R, 24 spindles Drive power 3.0 kW, incl. saw unit 18 vertical spindles individually selectable Arrangement in L-shape, 11+2 in X and 6 in Y direction 32 mm grid Dedpozt Twyefx Apmecp Max. drill diameter: 35 mm Total drill length: 70 mm from the mounting end (depending on plate thickness) Spindle extension stroke: 70 mm Rotation direction: alternating clockwise / counterclockwise n(max.) 1000 - 5710 min-1, infinitely variable Mount: M 10 thread - clearance fit 11 mm without tool, without mount 6 horizontal spindles 2 twin drill spindles in X direction (distance 32 mm between 1st and 2nd horizontal drill spindle) 1 twin drill spindle in Y direction Mount: M 10 thread, clearance fit 11 mm Total drill length max. 70 mm from the mounting end without tool, without mount Pressure booster, increases the standard pressure from 6 to 8 bar 5-axis milling unit 7844, Power: 10.0 kW (S6) cardanic, C-axis rotatable +/- 360°, A-axis rotatable +/- 180° n(max.) = 0 - 24000 min-1, infinitely variable, max. power at 12000 min-1 to 24000 min-1 Liquid cooling (cooling unit included) with HSK-F 63 tool holder with right-hand thread (for right-hand cutting tools) with collet chuck with HSK shank Ceramic ball bearings (hybrid bearings) Tool weight max. 6 kg (incl. holder) Tools:

Condition: used, KELLENBERGER KEL‑VISTA UR 175/1000 is a CNC cylindrical grinder, engineered for precision, high accuracy and reliability. Capacities: centre height 175 mm, distance between centres 1000 mm, max workpiece 100 kg; grinding wheel Ø400×63 mm, bore 127 mm; tailstock travel 50 mm, max table tilt 9°. Specs: wheel peripheral speed 35 m/s, spindle speeds 8–800 t/min (stepless), grinding spindle motor 5 kW, rapid feed 12 m/min, spindle taper ASA5/MK5, overall L3200×W1700×H2000 mm. Accessories: coolant system, paper filtration, set of grinding wheels. Delivers tight tolerances; ideal for automotive, aerospace, machine tools and medical sectors. Dcjdpfx Apez Dvzajmsp

Condition: used, TORNOS DECO 2000/13 is a CNC automatic lathe engineered for precision machining, high accuracy and dependable reliability. Key capacities: 10 axes; max workpiece length 180 mm; internal spindle diameter 13 mm; spindle speeds 100-12000 t/min; back spindle 100-8000 t/min. Main specs: 50 Hz 3x400 V supply; spindle motor 2.2 kW; total power 11 kVA; weight approx. 2550 kg; footprint L2000×W1260×H1950 mm. Equipment: bar feeder IEMCA GENIUS 226/32, chip conveyor, coolant system, oil mist extractor. Achieves tight tolerances; typical applications: automotive, watchmaking, machine tools, aerospace, medical. Dcsdpoz Dvztsfx Apmsp

Condition: excellent (used), Year of construction: 2004, operating hours: 22,146 h, functionality: fully functional, machine/vehicle number: 107.44.00.035, travel distance X-axis: 800 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 500 mm, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, controller manufacturer: Heidenhain, controller model: iTNC 530, workpiece length (max.): 300 mm, workpiece width (max.): 140 mm, total height: 2,900 mm, total length: 3,500 mm, total width: 2,400 mm, table load: 500 kg, rotary table diameter: 600 mm, overall weight: 9,900 kg, spindle speed (max.): 20,000 rpm, operating hours of spindle: 4,192 h, spindle motor power: 12,000 W, number of spindles: 1, number of slots in tool magazine: 30, input voltage: 380 V, type of input current: AC, Equipment: chip conveyor, documentation/manual, Here is a CNC vertical 5-axis machining center from the manufacturer Mikron for sale. The machine is in very good condition and can be inspected and tested at any time. Manufacturer: Mikron GF Type: UCP 800 Duro Year of manufacture: 2004 Control system: Heidenhain iTNC 530 Technical data: Travel distances X-Y-Z: 800x650x500 mm Max. rapid traverse rate: 30 m/min Max. feed force X- and Y-axis: 7000 N Max. feed force Z-axis: 9000 N Rotary table C-axis: 360° Rotational speed: 20 rpm at 30% duty cycle, 8 rpm at 100% duty cycle Swivel range A-axis: -30° to +120° Dcsdpfx Apj Afy Ilemjp Swivel speed: 15 rpm at 30% duty cycle Table area: 600x600 mm Max. table load: 500 kg Magazine capacity: 30 positions, fixed Tool holder: HSK-63 Max. tool length: 300 mm without taper Max. tool weight: 8 kg Tool diameter: 90 mm fully loaded / 140 mm partially loaded Spindle speed: 20,000 rpm Power: 16 kW at 44% duty cycle, 12 kW at 100% duty cycle New spindle installed in 2021. Since then, 4,192 spindle hours. Operating hours (program runtime): 22,146 h Machine dimensions: 3500x2400x2900 mm Weight: 9,900 kg Included in the scope of supply: 1x KSS system 1x Chip conveyor with coolant tank 1x Renishaw measuring probe OMP60

Condition: used, Year of construction: 2015, axis stroke (X,Y,Z) 6175x1550x300 mm Number of spindle head vertical 20 St. Number of spindles head horizontal 10 St. Number of milling agregates 1 St. Speed 24.000 U/min. Capacity 300 kg/h Sawing unit ja_yes 0 Control Homag PC85 CNC powerTouch HOMAG BMG 511 /60/12/F/K Profi ----- Machine already professionally dismantled and stored at our warehouse in Oberkochen: - 5-axis CNC processing center - Moving gantry machine (dual-drive gantry system) - 1 HOMAG DRIVE 5 C+ routing spindle, 5-axis, HSK-F63, 15 kW, max. 24,000 rpm - 1 HOMAG Multi Processing Unit Drilling head with 30 spindles: V20 / H10 / S360° "MPU" MultiProcessingUnit with C-axis +/- 185° - 1 Chain tool changer, 30-position - Includes SL laser projector - Includes vacuum suction cups (as available) - Spare parts and accessories as shown in photos - Last HOMAG 5-axis service: 2024 - Last HOMAG service: 2025 - Price includes professional dismantling and loading onto customer's truck - Costs for loading frames/transport securing devices NOT included; see note at the end of the description Technical Data ----- Max. workpiece lengths: All aggregates: Single 6,000 mm; Pendulum min. 1,550 mm, max. 3,200 mm Tool dia. 25 mm: Single 6,175 mm; Pendulum min. 1,550 mm, max. 3,200 mm Max. workpiece width: All aggregates, front stop 1,100 mm Milling operation tool dia. 25 mm: Front stop 1,325 mm, rear stop 1,550 mm Workpiece thickness: Max. 300 mm including clamping devices Routing spindle and drilling head ----- 2 independent Z-axes 1 HOMAG DRIVE 5 C+ routing spindle, 5-axis, HSK-F63, 15 kW, max. 24,000 rpm Liquid-cooled routing spindle, DRIVE5C+ aggregate interface with 3-point torque support 1 HOMAG Multi Processing Unit Drilling head with 30 spindles: V20 / H10 / S360° "MPU" MultiProcessingUnit with C-axis +/- 185° for drilling and sawing operations at any angle 1 motor 2.3 kW, frequency-controlled, max. speed 7,500 rpm selectable via program for rapid processing even with small diameters 20 vertical HIGH-SPEED spindles 10 horizontal spindles 1 grooving and parting saw Includes Z-axis module Includes extraction hood Tool changer: ----- 1 Pick-up station for 350 mm saw blade for DRIVE5(C)+ 1 Chain tool changer, 30-position, D=80 For tools and aggregates with HSK-F63 Chain changer with 30 tool/aggregate positions for use with machines featuring 1 main spindle 1 upstream double gripper for rapid tool changing Console table with ----- 12 consoles, Y=1,500 mm for K-table 6 lifting rails (HPL), lift 100 mm Additional accessories: ----- SPEED PACK: Increase in... Max. traverse speed of X-axis: 80 m/min; vector speed = 110 m/min Contour laser positioning aid 1 vacuum pump (300 m³/h) Chip conveyor belt with extension Vacuum clamping system SL-Laser Energy-efficient 5-axis extraction hood Dcsdezqggvepfx Apmop Safety equipment: ----- Laser, bumper SAFESCAN for Speed ??Pack CE mark HOMAG Speed ??Pack HOMAG Quality Package Enclosed energy chain Control system ----- PowerControl PC85 HOMAG powerTouch Handheld terminal HOMAG IPC Powerpack Software ----- HOMAG woodWOP 7.1 WoodScout diagnostic system MMR B...

Condition: good (used), Year of construction: 2006, functionality: fully functional, Overhauled: 2014 Dcedpfxe Adn Rge Apmop Control system: Heidenhain iTNC 530 Table: 10,000 x 3,000 mm X-axis travel: 10,000 mm Y-axis travel: 4,200 mm Z-axis travel: 1,100 mm Distance between columns: 3,500 mm Distance between table and spindle (without head): 2,000 mm Distance between table and 45° head: 1,298 mm Table load capacity: max. 30,000 kg Rapid traverse rate: 10 m/min Feed rates: 6 m/min Spindle speed: 3,000 RPM Spindle power: 40 kW 3 heads: 1. Vertical, integrated, 2. Universal orthogonal head 1°, 3. Universal twist head

Condition: good (used), Year of construction: 2003, functionality: fully functional, travel distance X-axis: 175 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 435 mm, Fanuc 18i-TB control Collet chuck device main spindle Collet chuck device sub spindle C-axis Y-axis 12-fold turret with driven tools chip conveyor bar loading device coolant device Technische Daten: / technical details max. Stangendurchlass / max. bar diameter 51 mm max. Drehdurchmesser / max. turning diameter 175 mm Verfahrweg X / travel X 175 mm Verfahrweg Z / travel Z 435 mm Verfahrweg Y / travel Y +-40 mm max. Drehzahl / max. spindle speed 5000 UpM/rpm Dcsdpfxe Af Ipks Apmsp Anzahl der Revolverplätze / number of tool places 12 Eilgang X,Z,Y / rapid feed X,Z,Y 18,20,12 m/min Gewicht/weight 4550 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: used, Year of construction: 2013, machine/vehicle number: 20130207F, with measuring table, dimensions: 6000 x 3000 mm, table plate weight: approx. 13,500 kg, measuring probe, manufacturer: RENISHAW. Dcodpfx Apo Af Nivjmjp

Condition: used, Year of construction: 2001, machine/vehicle number: .01720, with CNC control, manufactured by FIDIA, type: C20, travel ranges: X-axis: 2400 mm, Y-axis: 2850 mm, Z-axis: 1000 mm, with automatic tool changer with 20 tool stations, with T-slot clamping plate, size: approx. 2000 x 1800 mm, coolant system. Dcedpj Af Nlmefx Apmop

Condition: used, Year of construction: 2004, turning diameter 820 mm turning length 2000 mm control Siemens 840 D z-travel Z1=1980 Z2=2290 mm x-travel X1=500 X2=500 mm workpiece weight 1600 kg spindle nose A15 main spindle bore 160 mm feeds x-axis 0,1-18.000 mm/min rapid traverse X-axis 18 m/min Dodpfx Ae Aaq Sfspmscp feeds z-axis 0,1-24.000 mm/min rapid traverse Z-axis 30 m/min turret I 16 Wkzg. turret II 16 Wkzg. tool taper Capto C6 voltage 400 V main spindle speeds: 1-2.500 U/min total power requirement 180 KVA weight of the machine ca. 36 t dimensions of the machine ca. 9,7x2,5x4 m

Condition: used, spindle bore: 56 mm, spindle speed (max.): 2,600 rpm, spindle speed (min.): 10 rpm, travel distance X-axis: 155 mm, travel distance Z-axis: 540 mm, total height: 1,720 mm, total length: 2,550 mm, total width: 1,440 mm, overall weight: 2,800 kg, spindle nose: A2-6, CNC Lathe Manufacturer: MAZAK Model: QUICK TURN 10N Control: MAZATROL CAM T-2 Technical Details: Max. swing over bed: 440 mm Standard machining diameter: 150 mm Max. workpiece length: 507 mm X-axis: 155 mm Z-axis: 540 mm Spindle speed: 10 – 2,600 rpm Drive power (30 min rating): 7.5 kW Drive power (continuous operation): 5.5 kW Dcjdo Aa A Ryjpfx Apmep Spindle bore: 56 mm Spindle nose: A2-6 Number of tool stations: 8 positions Tool size: 20 x 20 x 150 mm Dimensions (L x W x H): 2,550 x 1,440 x 1,720 mm Approx. weight: 2,800 kg Condition: Used The machine does not include a chip conveyor! Accessories, tools, and work-holding devices shown are included in the scope of delivery only if explicitly stated in the additional information. Subject to changes and errors in the technical data and specifications; prior sale reserved!

Condition: excellent (used), Year of construction: 1986, functionality: fully functional, Retrofit / overhauling in May 2005 (with geometric measurement): - New Heidenhain iTNC-530 control - New electronics - New Siemens servomotors - Heidenhain glass scales - Revision of drilling spindle unit (total costs 118,436.00 EUR) Technical details spindle diameter 135 mm x-travel 1000 mm y-travel 700 mm z-travel 300 mm cross rail adjustment - vertical 780 mm distance between table/spindle 1000 mm table surface area 1100 x 842 mm distance between columns 1100 mm table load 1500 kg tool taper SK 45 spindle turning speed range 2400 rpm spindle drive 5,9 kW feed range 1 - 6000 mm/min weight of the machine ca. 10,6 t Equipment: Infrared measuring probe m&h 38.10-MINI Electron. Handwheel Various tool holders Transport dimensions: Dedpfx Aps Aa N Tbomscp - Machine (LxWxH) 3500 x 2600 x 2750 mm - Control cabinet (LxWxH) 2300 x 600 x 2300 mm - Hydraulic (LxWxH) 800 x 600 x 1000 mm

Condition: used, Year of construction: 2008, machine/vehicle number: 30655, overall weight: 5,500 kg, total length: 2,540 mm, total width: 2,290 mm, total height: 2,340 mm, FICEP P51 - CNC PUNCHING & DRILLING MACHINE FOR FLAT BAR AND PLATES | YEAR 2008 | 800 KN The Ficep P51 is a CNC-controlled punching and drilling machine for automated hole processing of flat bar and plates. Punching and drilling run in a single pass with automatic material feed - saving marking, re-clamping and handling on parts with many holes. CONDITION & HANDOVER Used machine from stock, year 2008, serial number 30655. - Condition and function are confirmed during the viewing or upon request. - Viewing possible by arrangement (no demonstration under power). - Service and reconditioning before handover by arrangement. FUNCTION & APPLICATION A hydraulic punching unit and an integrated drilling unit process the workpiece in one pass. A carriage with hydraulic, self-adjusting grippers and ball screw drive positions the material under CNC control (Ficep MINOSSE). Processes: punching, drilling, marking, countersinking and tapping. Typical applications: structural steelwork and connection technology as well as the fabrication of beams, brackets and frame structures with a high share of holes. TECHNICAL DATA - Manufacturer: Ficep | Model: P51 | Year: 2008 | Serial number: 30655 - Machine type: CNC punching and drilling machine - Punching force: 800 kN (approx. 80 t) | Punching units: 1 - Max. punching diameter: 46 mm | Material thickness (punching): 3-25 mm - Drilling units: 1 | Spindle power: 7.5 kW | Max. drilling diameter: 28 mm - Plate width: 100-500 mm | Plate length: from 100 mm, not limited by design thanks to roller conveyors - Workpiece weight: up to 100 kg (standard) / up to 250 kg (reduced positioning) - Travel: X 1,000 mm | Y 500 mm | Positioning speed: 20 m/min Dcedpfsz Nyvyjx Apmjp - Carriage drive: ball screw | Clamping: hydraulic grippers - Control: Ficep MINOSSE CNC - Frame: one-piece steel C-frame with integrated hydraulic unit, electrics, pneumatics and CNC unit - Machine dimensions (L x W x H): approx. 2,540 x 2,290 x 2,340 mm | Machine weight: approx. 5,500 kg SCOPE OF DELIVERY - 1 x Ficep P51 main machine (one-piece steel C-frame) - 1 x punching unit (800 kN) - 1 x drilling unit (7.5 kW) - 1 x carriage with hydraulic grippers and ball screw drive - 1 x Ficep MINOSSE CNC control unit - 1 x hydraulic unit (integrated in the machine frame) - 1 x safety light curtain LOGISTICS & LOCATION Location: Ulft (Netherlands), close to the German border. Dismantling, transport, installation and commissioning can be carried out by ASM by arrangement - individually calculated upon request. ABOUT ASM Arendsen Steel Machinery (ASM) specializes in reconditioned Ficep structural-steel machinery - from sawing and drilling lines and profile drilling machines to plasma cutting systems. Further Ficep machines on request. CONTACT / INQUIRY Arrange a viewing | Price on request | Request a callback. Sale exclusively to commercial customers (B2B).

Condition: used, Year of construction: 2012, Used machine Nesting cell Year of construction: 2012 Gantry machine in Gnatry design Working area in X = 4300 mm Working area in Y = 2250 mm Working area in Z = 125 mm Travel speed X - Y - Z-axis 100 - 100 - 20 m/min with grid table and sacrificial plate with 3 vacuum pumps, each with 300 m³/h (one of them from 2026) Spindle motor 12 kW Dodpfxoz Rrbqs Apmecp with torque support and C-axis with Homag Flex 5 tool interface Tool clamping system HSK-F 63 Tool changer with 14 tool positions Loading with vacuum lifter and roller conveyor Unloading with conveyor belt with manual label printer Safety device: stepping mat Caution! Drilling head is defective! Availability: approximately July 2027 Location: North Rhine-Westphalia
