Used Cnc Centre Lathe for sale (13,295)

Condition: used, Year of construction: 2008, turning diameter: 380 mm, spindle speed (min.): 35 rpm, spindle speed (max.): 4,000 rpm, spindle bore: 77 mm, travel distance X-axis: 230 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 575 mm, total height: 1,680 mm, total length: 2,848 mm, total width: 1,860 mm, overall weight: 5,400 kg, CNC Lathe with Y-axis, driven tools, sub spindle and Gantry Loader CNC Control Mazatrol Matrix Nexus Turning diameter 276 / 380 mm Spindle bore diameter 77 mm Spindle speed 4000 R/min Spindle motor 26 Kw Movement X-axis 230 mm Movement Y-axis 100 mm Movement Z-axis 575 mm Movement W-axis 585 mm Min indexing C-axis main spindle 0,001 ° Number of tools on turret 12x Number of driven tools 12 x Tool Taper Mazak VDI Bar feeder LNS Quick Load Servo lll Spindle motor driven tools 4.500 R/min Ibjdjx Dcbpspfx Ah Usf If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, Year of construction: 2007, turning diameter over bed 0140 mm turning length 285 mm control 810D Siemens turning diameter over bed slide 140 mm swing dia. 300 mm spindle turning speed - stepless 0- 5000 U/min- rpm spindle bore 45 mm feeds 0- 12 m/min voltage 400 V connected load 14 KW face slide travel 250 mm longitudinal travel 285 mm dimensions of the machine ca. 2,7 x 1 x 1,6 m Ibodpox Hpyyjfx Ah Usf taper diameter VDI 20 mm main drive motor 10,2 kW weight of the machine ca. 1,7 t Machine has 8 position turret with 6 pos. live tooling. Machine has VDI 20. Machine is with tailstock !

Condition: used, Year of construction: 1996, functionality: fully functional, Equipment: documentation/manual, rotational speed infinitely variable, Geminis Lathe Type: CNC5/PLUS/1000/4000 CNC control: Fagor Year: 1996 Ibedpfx Ahsxvr E Ij Usf With 2 steadies + Tooling With 2 chucks Can be inspected under power Video available

Condition: new, Year of construction: 2025, 0583 mm 1710 mm 82 mm 436 mm 3000 U/min A1-8 DIN 55026 100 mm 235 mm Ibjdswp Tqnspfx Ah Usf

Condition: like new (used), Year of construction: 2011, functionality: fully functional, spindle motor power: 15,000 W, spindle speed (min.): 5,000 rpm, travel distance X-axis: 157 mm, travel distance Y-axis: 35 mm, travel distance Z-axis: 464 mm, rotational speed (max.): 6,000 rpm, total height: 1,885 mm, total length: 3,675 mm, total width: 2,258 mm, overall weight: 9,000 kg, CNC controller: Fanuc 18i-TB Ijdpfx Ahexiwnne Uebf Capacity X-axis travel mm: 157,5 Y-axis travel mm: 35 Z-axis travel mm: 464,8 B-axis travel mm: 600 C-axis: 360º (0,001º) Turning length mm: 399 Max. turning diameter mm: ø: 190 Distance between spindle centers mm: 750 Bar work capacity mm: 52 Upper turret Number of tool slots St .: 12 Speed driven tools RPM: 6.000 Drive power driven tools kW: 5.5 / 3.7 Number of upper turrets: 1 Lower turret Number of tool slots St .: 12 Speed driven tools RPM: 6.000 Drive power driven tools kW: 5.5 / 3.7 Milling function: Both Turrets Number of lower turrets: 1 Main spindle Speed spindle rpm: 5.000 Drive power spindle kW: 15 / 11 Counter spindle Speed spindle rpm: 4.500 Drive power spindle kW: 11 / 7.5 Equipment Part catcher Workarea light Bar Loader ILS - RBK Machine running time: Nominal Kva: 67,2 Basic machine dimensions / weight Length mm: 3.675 Width mm: 2.258 Height mm: 1.885 Weight kg: 9.000

Condition: used, Year of construction: 2000, functionality: fully functional, OKUMA LU 15M-1000 MM WITH BARFEEDER Maximum Turning Diameter: approx. 360 mm Maximum Turning Length (Z-axis travel): approx. 1000 mm Spindle Speed: up to 4,500 rpm Isdpfx Ahoxur Nws Uebf X-axis Travel: approx. 260 mm (≈ 10.24″) Z-axis Travel: approx. 640 mm (≈ 25.2″) Power Requirement: approx. 30 kW Machine Weight: approx. 4.8 tons Turrets: Dual turrets (example: upper turret 12 positions, lower turret 8 positions) Live Tooling (M-function): Yes, on the M version

Condition: used, Year of construction: 2013, travel distance X-axis: 730 mm, travel distance Y-axis: 730 mm, travel distance Z-axis: 740 mm, controller manufacturer: Mazatrol, controller model: Matrix Nexus, workpiece weight (max.): 700 kg, total height: 2,814 mm, total length: 4,690 mm, total width: 2,330 mm, table width: 500 mm, table length: 500 mm, overall weight: 11,000 kg, spindle speed (max.): 18,000 rpm, Equipment: documentation/manual, CNC Horizontal Machining Centre Ibjdpfx Ahjx At Svj Uof CNC Control Mazatrol Matrix Nexus Pallet table size 500 x 500 mm Number of pallets 2 Table load 700 kg Movement X-Y-Z-axis 730x730x740 mm Table indexing 0,001 ° Spindle taper CAT 40 Spindle speed 18.000 1/Min Spindle motor 30/22 kW Magazin capacity 40 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail.

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, Technical details faceplate diameter 1800 mm swing diameter 2000 mm turning height 1270 / 1120 mm Control SIEMENS 840 D workpiece weight max. 5000 kg ram head dimension 250 x 250 mm table turning speeds 1 - 320 U/min cross rail - adjustment 400 mm ram head - cross travel (X) -2770 / +2275 mm ram head - vertical travel (Z) 1250 mm c-axis 360° (0,001°) deg milling drive 37 kW turning speed range - milling 10 - 3000 U/min power capacity - table 100 kW Torque 31784 Nm feed range (X/Z) 0,1 - 15000 mm/min weight of the machine ca. 55 t Additional information Used CNC vertical lathe for turning, drilling and milling First machine installation in the year 2011. Max. workpiece diameter: 2040 mm Max. workpiece height: 1270 mm Ram stroke: 1250 mm Max. workpiece weight: 5000 kg (per pallet/chuck) Table speed range: 1.0 - 320 rpm Table drive motor: 100 kW Drilling and milling spindle: 37 kW Crossbar travel: 2 steps of 200 mm each Total electrical connection value: 218 kVA CNC control: Siemens 840 D Number of NC axes: 4 (X, Z, C, crossbar adjustment) Travels: X-axis: -1650 to + 2165 mm Z-axis: 1250 mm Ijdpfxex D Uz Io Ah Uobf Rapid traverse X- Z-axis: 15 m/min Number of tool magazine spaces: 80 spaces in the chain magazine, of which 60 x HSK 100 and 20 x Capto C6 Disc magazine 12-pos. for rotary holders and attachment heads Coolant system with filter and circulation unit Chip conveyor Oil-mist-extractor 1 pallet with jaws, diameter 1800 mm 1 hydraulic chuck with base jaws, diameter 1800 mm Various drilling and milling heads 2 measuring probes Several turning tool holders Special feature: Pallet changer with two stations, equipped with a face plate Ø1800 mm and a six-jaw lever compensation chuck with mechanical centrifugal force compensation Ø1800 mm. Note: The machine is in a pit. Condition description: The cross roller bearing on the Carnaghi was replaced about half a year ago. The Siemens components in the control cabinet were also completely replaced at the end of 2023. The machine also has a measuring probe for tool measurement and an external Renishaw measuring probe for workpiece measurement. As a special feature, the machine also has a measuring probe installed on the Z-axis (Z1-axis). This brings an advantage in terms of accuracy and time, as the tool does not have to be put down for measuring. However, it is currently shut down and should be overhauled when it is put back into operation. The machine also has a Rotomors six-jaw lever compensating chuck with centrifugal force compensation, which was completely overhauled in 2020/21.

Condition: good (used), Year of construction: 1991, For sale Mazak SQT 10 M Lathe Manufactured in 1991 Main Technical Specifications (Year 1991) Feature Specification Ijdpfx Ahjx E R Ams Uebf Machine type Horizontal CNC lathe with live tooling and C axis CNC Control Mazatrol T32-3 Max turning diameter 230 mm (9 inches) Max machining length Approx. 300 mm to 305 mm (or 12 inches) Axis travels X axis: 160 mm; Z axis: 455 mm (or 17.93") Main spindle speeds 35 to 6,000 rpm Spindle motor power Typically 11 kW (approx. 15 HP) Turret capacity 12 positions (with live tooling capability) Live tools Speed from 120 to 3,000 rpm Machine weight Approx. 3,600 kg to 3,850 kg BT MACHINES PURCHASE AND SALE ALL TYPES OF INDUSTRIAL EQUIPMENT ALL TYPES OF MACHINE TOOLS

Condition: used, Year of construction: 2003, NAKAMURA TOME SUPER NTJ CNC LATHE MAKE NAKAMURA TOME, MADE IN JAPAN MODEL SUPER NTJ YEAR 2003 Iedpfx Aov I Tx Reh Ujbf CONTROL FANUC 18 iT B CHUCK SIZE 210.0 mm MAX TURNING DIA. 200.0 mm BETWEEN CENTRES 780.0 mm DRAW TUBE DIA. 80.0 mm TRAVELS: X AXIS: 750.0 mm Z AXIS: 130.0 mm TURRET 2 x 12 STATIONS SPINDLE SPEED Up to 5,000 rpm SPINDLE BORE 65.00 mm SPINDLE NOSE A2-6 PLUS CNC SHORT MAGAZINE BARFEED TURRET TOOLING SWARF CONVEYOR MANUALS

Condition: new, Year of construction: 2025, functionality: fully functional, NEWAY NL502 2 AXIS CNC LATHE WITH FANUC 0IT PLUS 3B YEAR OF MANUFACTURE - 2025 STANDARD INCLUDED FACTORY FITTED MACHINE OPTIONS  STD AIR - AIR GUN  STD CHIP - CONVEYOR SIDE HINGED WITH CHIP BOX  STD CHU - 10 INCH 3 JAW HOLLOW HYD CHUCK INC SET SOFT JAWS  STD CHU - STANDARD HYD CHUCKING CYLINDER - HOLLOW  STD CNC.OP - FANUC 0ITF 3B PLUS WITH 10.4 INCH COLOUR LCD DISPLAY & 8MB MEMORY  STD CNC.OP - MANUAL PULSE GENERATOR (MPG)  STD CS - COOLANT GUN  STD GUA - FRONT DOOR INTERLOCK  STD GUA - FULLY ENCLOSED SPLASH GUARDING SYSTEM  STD GUA - TELESCOPIC SLIDEWAY COVERS  STD HYD - STANDARD HYDRAULIC UNIT  STD LI - LED WORKING AREA LIGHTING SYSTEM  STD LI - PATROL LIGHT (3 COLOUR)  STD MISC - AIR CONDITIONING IN ELECTRICAL CABINET  STD MISC - BASIC MACHINE INSTALLATION PARTS  STD MISC - CE STANDARDS MACHINE CONFIGURATION  STD MISC - CENTRALIZED AUTOMATIC LUBRICATION SYSTEM  STD MISC - MACHINE MANUALS & OPERATOR HANDBOOKS  STD MISC - STANDARD ACCESSORIES  STD POW - TRANSFORMER (415V, 3PH, 50HZ)  STD SPGB TC - BELT DRIVE SPINDLE - 3,500 RPM - A2-6  STD SPGB TC - SPINDLE MOTOR FANUC 15.0 / 18.5 KW  STD TS - HYDRAULIC TAILSTOCK  STD TUR - 12 STATION SERVO TURRET MACHINE CONSTRUCTION & FEATURES  SOLID CAST IRON 45 DEGREE SLANT BED CONSTRUCTION  HARDENED & GROUND BOX GUIDEWAYS  12 STATION SERVO TURRET  10 INCH STANDARD CHUCK SIZE - 12 INCH & BAR CAPACITY UPGRADE OPTIONS  15.0 / 18.5 KW MAIN SPINDLE  HYDRAULIC TAILSTOCK MACHINE SPECIFICATION CAPACITY Max. Swing Diameter Over Bed Ø 600 MM Max. Swing Diameter Over Saddle Ø 480 MM Max. Turning Diameter Ø 500 MM Max. Turning Length 570 MM Max. Bar Capacity Ø 74 MM Iodpfx Aext Nrmjh Ujbf X / Z AXIS TRAVEL X-Axis Travel 280 MM Z-Axis Travel 600 MM X / Z AXIS SERVO MOTOR TORQUE X-Axis Torque 10.5 NM Z-Axis Torque 10.5 NM SPINDLE HEADSTOCK STD Spindle Nose A2-8 Spindle Bore 86 MM Spindle Speeds 30 ~ 3,500RPM Chuck Size Ø 10” - 245 MM Spindle Power 15.0 / 18.5 KW FEEDRATES X-Axis Rapid Traverse Rate 16 M / MIN Z-Axis Rapid Traverse Rate 20 M / MIN Cutting Feed Rate 1 ~ 8,000 MM / MIN TURRET Number of Turret Stations 12 Turret Indexing Time 0.2 SEC / POS Tool Size - Turning 25 x 25 MM Tool Size - Boring Ø 40 MM TAILSTOCK Tailstock Quill Diameter Ø 100 MM Tailstock Quill Travel 100 MM Tailstock Quill Taper MT5 LIVE CENTER ACCURACY Positioning Accuracy (X / Z) 0.010 / 0.010 MM Repeatability (X / Z) 0.005 / 0.007 MM MISCELLANEOUS Power Requirement 35 KVA Power Supply 415V / 3PH / 50HZ Cutting Coolant Volume 240 L Machine Dimensions (L / W / H) 4,290 / 1,880 / 1,750 Machine Gross Weight 4,000 KGS

Condition: used, Year of construction: 2006, functionality: fully functional, Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 mm Swing diameter over face slide: 260 mm Face slide travel: 380 mm Main drive Drive power AC motor - 40/60/100% duty cycle: 33/27/22 kW Spindle box Spindle bore diameter: 106 mm Spindle diameter in front bearing: 140 mm Speed range (V constant): 1 - 2,000 rpm Ibjdpex Hhhiofx Ah Uof Cross slide Feed range, face: 0.001 - 1,000 mm/rev Feed range, face, optional up to: 5,000 mm/rev Feed range, longitudinal and thread pitch: 0.001 - 2,000 mm/rev Feed range longitudinal and thread pitch, optional up to: 13,000 mm/rev Feed force flat: 9,000 N Feed force longitudinal: 12,000 N Automatic tool turret Number of tool stations: 12 With tool drive for 6 stations Tool holder system (DIN69880) VDI40 Equipment SIMENS SINUMERIK 840D sl (Shop Turn with manual functions) COMBI control station C-axis with drilling, milling, and engraving cycles Residual material detection and machining – during roughing and contour pockets MULTIFIX C forne setup Three-jaw chuck SMW AUTOBLOK: HI-GRIP HGF260-81-3 Oil emulsion mist filter for work area extraction: MAHLE LTA600 4 driven axial tool holders 2 driven radial tool holders

Condition: used, Year of construction: 2000, turning length: 600 mm, turning diameter: 400 mm, spindle speed (max.): 4,000 rpm, spindle speed (min.): 31 rpm, travel distance X-axis: 250 mm, travel distance Z-axis: 620 mm, total height: 1,960 mm, total length: 5,000 mm, total width: 2,650 mm, overall weight: 7,000 kg, Equipment: documentation/manual, CNC Lathe with driven tools CNC Control Siemens 840 D Turning diameter 400 mm Turning Length 600 mm Spindle bore diameter 65 mm Spindle speed 31 - 4.000 R/min Spindle motor 30-20.5 kW Movement X-axis 250 mm Movement Z-axis 620 mm Driven tool stations 12 Number of driven tools 12 Tool taper VDI 40 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Isdpox Ahxwsfx Ah Ujbf Feel free to view our other advertisements for a complete overview of our stock.

Condition: as good as new (ex-display), The Numturn 500/1500 FA is a precision CNC Flat Bed Lathe designed for a wide range of applications, making it an excellent choice for the CNC Flat Bed Lathes category. With a robust construction featuring heavy ribbing of the machine frame and wide hardened V-guides, this lathe is engineered for heavy-duty machining. The Fagor 8055i control enhances your workshop programming experience, while the automatic 8-station servo-driven tool turret significantly increases productivity and flexibility for both single part and small batch production of larger workpieces. Its hydraulic power chuck offers adjustable holding force, and the heavy-duty tailstock provides high clamping force for secure machining. The completely lockable enclosure and smart central lubrication system contribute to a low-maintenance operation, allowing for more efficient workflows. KNUTH leads the way in reliability and performance, so if you're looking for a CNC Flat Bed Lathe that delivers robust construction and precise functionalities, you can request a quote today. Ibedpfjm E Ty Nex Ah Ujf

Condition: ready for operation (used), Year of construction: 1987, turning length: 260 mm, turning diameter: 180 mm, Fanuc OT 10-position turret Iedpfox Ikunox Ah Uobf maximum spindle speed 4500 rpm weight 2300 kg

Condition: used, Year of construction: 2011, AXE AND STATUS TUSCAN LL-950 X 3000 HEAVY DUTY CNC LATHE Ibodpexvclrofx Ah Uof MAKE TUSCAN, MADE IN TAIWAN MODEL LL-950x3000 YEAR 2011 CONTROL FANUC Oi-TD TURRET 12 STATION MAXIMUM CUTTING DIAMETER 950.0 mm CENTRE HEIGHT 575.0 mm DISTANCE BETWEEN CENTRES 3000.0 mm SPINDLE NOSE A2-15 SPINDLE SPEED 9 – 500 RPM SPINDLE CENTRE MT # 6 SPINDLE POWER 30 / 37 Kw TOOL SIZE 32.0 mm TRAVERSES X AXIS: 480.0 mm Z AXIS: 3000.0 mm RAPID TRAVERSES X AXIS: 5M / MIN Z AXIS: 4M / MIN TAILSTOCK YES PLUS TWIN SWARF CONVEYOR 4 JAW CHUCK 3 X STEADIES FULLY FUNCTIONAL FULL SET OF MANUALS TURRET TOOLING

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: 1188877, Specification Table size 1016mm x 356mm X axis traverse 508mm Y axis traverse 406mm Z axis traverse 356mm Spindle BT40 Spindle speeds 0-10,000rpm Spindle motor 11.2kW Rapid feed rate 30.5m/min Toolchanger capacity 20 Tools Approximate weight 2313Kg   Machine Equipped with Haas CNC Control HRT 160 4th axis 11 off BT40 toolholders High flow coolant system Lighting Enclosed guarding Manual Ibsdpfx Aox Afpgsh Ujf

Condition: excellent (used), Year of construction: 2019, Model: Alpha 1460 XS Year: 2019 Swing Over Bed: 460mm Ibsdexphv Nspfx Ah Ujf Swing Over Cross Slide: 270mm Swing In Gap: 730mm Distance Between Centres: 1500mm Spindle Speeds: To 2200 RPM (Variable) Spindle Bore: 78mm Machine With: 300mm 3 Jaw Chuck 8 Station Indexing Turret (VDI 30) Various Tooling

Condition: excellent (used), Hardinge HXL-S CNC Lathe Fagor Control Year 1998 Manuals Great Condition - Fully Working with no faults. We welcome any inspections Ijdpfxexrvdgs Ah Usbf

Condition: ready for operation (used), Year of construction: 2010, General Data Measurements width 840 mm Measurements depth 1090 mm Measurements height 1960 mm Machine weight 620 kg Main Drive Number of axis 5 Ibsdpfx Ahex H A Rre Usf This 5-axis ESPE LAVA CNC 500 was manufactured in 2010, featuring a robust universal machining center design. It operates on a supply voltage of 200-240 V AC and supports a nominal output of 0.92-1.1 KW. The machine dimensions are 1090 mm in width, 1960 mm in height, and 840 mm in depth, weighing approximately 620 kg. If you are looking to get high-quality milling capabilities, consider the ESPE LAVA CNC 500 machine we have for sale. Contact us for more information. Application Types Milling

Condition: ready for operation (used), Year of construction: 2003, turning diameter over cross slide: 200 mm, turning length: 750 mm, turning diameter: 360 mm, spindle bore: 54 mm, spindle speed (max.): 3,000 rpm, rotational speed (max.): 3,000 rpm, overall weight: 1,600 kg, Order number Spindle bore 54 mm, maximum speed 3000 rpm Ibodpox H R Ulofx Ah Uof Capacity 750x360 mm 200 mm on the carriage Multifix turret type B

Condition: used, Year of construction: 2001, DAEWOO - DOOSAN PUMA 400 LB CNC LATHE MAKE DAEWOO - DOOSAN, MADE IN KOREA MODEL PUMA 400 LB YEAR 2001 CONTROL FANUC 18 iT CHUCK SIZE 450.0 mm SWING OVER THE BED 700.0 mm SWING OVER SADDLE 480.0 mm MAX TURNING DIA. 380.0 mm BETWEEN CENTRES 2100.0 mm DRAW TUBE DIA. 117.5 mm TRAVELS: X AXIS: 362.0 mm Z AXIS: 2155.0 mm TURRET 10 STATIONS Ibedpoxp Nfxjfx Ah Uef SPINDLE SPEED 20 - 2,000 rpm SPINDLE BORE 132.00 mm SPINDLE NOSE A2 - 11 BEARING DIA. 180.0 mm TURRET TOOL HEIGHT 25.0 mm TURRET BAR DIA. 50.0 mm TURRET INDEXING TIME 0.25 sec FEEDRATE RAPID TRAVERSE X: 16,000 mm/min Z: 18,000 mm/min FEEDRATE CUTTING FEED X , Z: 0,001 ~ 500.000 TAILSTOCK QUILL DIA. 120.0 mm TAILSTOCK QUILL BORE TAPER MT#6 TAILSTOCK QUILL TRAVEL 120.0 mm PLUS HYDRAULIC STEADY TOOL SETTING ARM SWARF CONVEYOR TURRET TOOLING FULL SET OF MANUALS

Condition: excellent (used), Year of construction: 2010, The XYZ 200TC is a CNC lathe known for its precision and versatility. It features a Siemens 810D Shopturn control system, a 12-station VDI turret. Key Features and Specifications: Control System: Siemens 810D Shopturn. Turret: 12-station VDI turret. Chuck: Hydraulic 200mm 3-jaw chuck. Bar Capacity: 52mm. Swing Over Bed: 420mm. Maximum Machining Diameter: 200mm. Ibedpexrvcvofx Ah Uef Maximum Machining Length: 550mm. Spindle Speed: 4800 rpm. Spindle Bore: 62mm. Spindle Motor Power: 14.9kW. Other Features: Automatic tool setting arm, swarf conveyor, parts catcher, hydraulic tailstock, remote electronic handwheel, and through-tool and flood coolant. Weight: 4100kg. The XYZ 200TC is a slant-bed CNC lathe, which means the lathe bed is angled, allowing for better chip evacuation and access to the workpiece. It can be equipped with a multi-feed barfeed for automated feeding of bar stock. The machine is typically used in small to medium-sized workshops and production environments. Complete with bar feed, swarf conveyor and tooling.

Condition: used, Year of construction: 2004, ECOCA SJ20MC 3 AXIS CNC TURNING CENTRE MAKE ECOCA, MADE IN TAIWAN MODEL SJ 20MC YEAR 2004 CONTROL FANUC 18-T MAX. TURNING DIA 170.0 mm MAX. TURNING LENGTH 300.0 mm SWING OVER BED 380.0 mm OVER CROSS SLIDE 225 Ibsdstvav Iopfx Ah Uof MAX. SPINDLE SPEED 4,500 RPM POWER TOOL SPEED 4000 SPINDLE NOSE A-5 / A2-6 DRAW TUBE DIA 45 RAPID TRAVERSE RATE X24 / Z24 PLUS VDI20 TOOLING PARTS CATCHER SWARF CONVEYOR POWER TAIL STOCK TURRET TOOLING

Condition: used, Year of construction: 1996, MAZAK SUPER QUICK TURN 10 MS CNC LATHE MAKE MAZAK, MADE IN JAPAN MODEL SUPER QUICK TURM 10 MS YEAR 1996 CONTROL MAZATROL T PLUS MAX SWING 435mm SWING OVER CARRIAGE 370mm MAX. MACHINING DIA 230mm MAX. BAR WORK DIA 42mm MAX DISTANCE BETWEEN SPINDLES 705mm SPINDLE MOTOR AC11kw (15HP) SPINDLE SPEED 6000rpm 2ND SPINDLE MOTOR AC5.5kw (7.5HP) 2ND SPINDLE SPEED 6000 rpm ROTARY TOOL MOTOR AC2.2kw (3HP) ROTARY TOOL SPEED 3000 rpm TURRET TOOL CAPACITY 12 TOOLS STATIONS RAPID TRAVERSE RATE X,Z:30m/min (1180IPM),C: 400rpm MACHINE DIMENSION L x W x H, 2705mm x 1465mm x 1835mm MACHINE WEIGHT 3850kg PLUS C-AXIS SUB SPINDLE DRIVEN TOOLS (3 NO.S) Iodpfexnpp Ijx Ah Usbf PARTS CATCHER SWARF CONVEYOR TOOL SETTING PROBE COLLET CHUCK BUILT IN TRANSFORMER FULL SET OF MANUALS GOOD WORKING ORDER
