Used Cnc Cutting Machine for sale (66,756)

Condition: good (used), Year of construction: 2008, Ref. -No.: 10581 Manufacturer: HEDELIUS Type: RS 80 Magnum Year of construction: 2008 Type of control: CNC-Steuerung Control: HEIDENHAIN iTNC 530 Storage location: Halberstadt Country of origin: Germany X-Travel: 945 mm Fgjdpfx Aas Ahmu Tjnei Y-Travel: 800 mm Z-Travel: 600 mm C-Axis: 360.000 x 0,001 ° Spindle Taper: ISO 40 Table Load: 600 kg Tool changer: 30 fach Spindle Speed: 10 - 8000 RPM Drive Capacity - Spindle Motor: 27 kW Total Power Requirement: 55 kW Weight Of The Machine Ca.: 16 t A-axis (swivel axis): ° Table clamping area: 800 x 630 mm Further information: - Pendulum machining with swivel rotary table and fixed machine table - Coolant system, chip conveyor - Complete housing The machine can be viewed under power by arrangement.

Condition: new, functionality: fully functional, Year of construction: 2026, control type: CNC control, degree of automation: automatic, actuation type: hydraulic, controller manufacturer: Shenzhen ICM Technology Development Co., Ltd., controller model: 880W02, pipe diameter (max.): 38 mm, pipe length (max.): 3 mm, tube wall thickness (max.): 2 mm, bending angle (max.): 190 °, bending radius (max.): 200 mm, bending radius (min.): 2 mm, mandrel length: 150 mm, number of axes: 2, table length: 3 mm, overall weight: 1,300 kg, total length: 3,900 mm, total width: 900 mm, total height: 1,400 mm, power: 4 kW (5.44 HP), input voltage: 400 V, input current: 20 A, input frequency: 50 Hz, type of input current: three-phase, oil tank capacity: 80 l, number of digital displays: 1, warranty duration: 36 months, Equipment: CE marking, documentation/manual, emergency stop, foot remote control, quick-change device, Full Automatic Pipe Bending Machine DW38CNC-2A-1S Equipped with a touchscreen and CNC control system; capable of storing up to 500 sets of parameter groups. Features a rebound compensation setting program, with built-in confidentiality protection for programs and processing data. Servo control is adopted for corner bending, pipe bending and material feeding functions. The operating system is protected by passwords and physical keys, and supports production quantity & runtime records for efficient production management. Comes with slow bending and slow core pulling functions. Fault messages are displayed on the screen to help operators troubleshoot problems promptly. Touchscreen This pipe bender is equipped with a Weinview industrial touchscreen for its operation interface, which delivers an intuitive operation experience and allows new operators to get started quickly. You can directly edit the pipe bending process parameters on the interface, such as feeding distance, rotation angle and bending angle, and separately set the running speed for each step. During operation, the interface displays real-time axis positions, bending progress and production cycle, and automatically counts total output and shift output to help you manage production efficiency effectively. It also supports manual single-step debugging, automatic continuous operation, program editing and equipment parameter setting. Different modes can be switched with one click, making it convenient for machine trial runs and mass production alike. Fsdey Uuw Topfx Aanegi Hydraulic solenoid valve manifold This integrated hydraulic solenoid valve manifold serves as the control center of the CNC pipe bender's hydraulic system. Adopting industrial-grade modular design, it integrates multiple solenoid valves to independently control the movements of the feeding axis, rotating axis, bending axis, as well as clamping, auxiliary pushing and other auxiliary mechanisms. Linked with the CNC system, it converts control commands into precise hydraulic power output, enabling smooth operation throughout pipe feeding, rotation and forming. Matched with high-pressure sealed hydraulic hoses, it maintains zero leakage and high stability under full-load operating conditions, delivering reliable performance for long-term mass production. Servo drive These four units are Mitsubishi servo drives equipped on our pipe bender, acting as the power core that governs key movements including material feeding, pipe rotation and pipe bending. Adopting Mitsubishi MR-JE series industrial-grade high-end servo drives, they feature high positioning accuracy and fast response. Both feeding distance and rotating angle can be controlled precisely with no deviation. With excellent stability, they rarely lose steps or malfunction during long-hour continuous operation. This ensures consistent bending precision for every pipe and a high finished product yield.

Condition: used, Used, well-maintained CNC tool milling machine MIKRON, model: WF 7D, with HEIDENHAIN control. Table clamping surface: 600 x 1200 mm Travel distances: X-axis, Y-axis, Z-axis 900 mm, 560 mm, 500 mm Spindle mount: SK 40 Spindle speed, continuously adjustable: 5 – 5000 rpm Feed rate, longitudinal and transverse: 0 – 8000 mm/min Rapid traverse, longitudinal and transverse: 8000 mm/min Fgedpo Ahz D Aofx Aanei Feed rate, vertical: 0 – 6000 mm/min Rapid traverse, vertical: 6000 mm/min Drive power, main drive: 8.5 / 11.5 kW Dimensions W x D x H: 240 x 360 x 220 cm Weight approx. 4500 kg Technical data and dimensions: Subject to change.

Condition: new, functionality: fully functional, Year of construction: 2025, control type: CNC control, degree of automation: automatic, pipe diameter (max.): 220 mm, pipe length (max.): 6,000 mm, cutting speed: 8,500 mm/min, workpiece weight (max.): 200 kg, input voltage: 380 V, input frequency: 50 Hz, overall weight: 4,500 kg, total length: 11,380 mm, total width: 2,500 mm, Equipment: CE marking, centralized greasing system, cooling unit, emergency stop, fume extraction, nozzle changer, safety light barrier, 2 Chuck Professional Pipe Laser Cutting Machine Max length of pipe: 6000mm*φ240mm Repeat positioning accuracy: ≤0.03mm Positioning accuracy: ≤0.05mm Max positioning speed: 85m/min Max acceleration: 1.0G Max rotating speed of chuck: 100r/min Round pipe: Φ10mm-Φ220mm Square pipe: 10mm*10mm ~ 150mm*150mm Rectangular pipe: 30*20mm~160*80mm Oval tube/flat oval tube: Short axis≥15mm, long axis≤210mm Channel steel: Max 20# I-beam: Max 18# H steel: Max 175*90mm High-quality chuck 1)High clamping accuracy; 2)Sealed and dustproof; 3)Various types of pipes can be clamped; 4)Low failure rate; High-strength cage structure welded bed, high temperature annealing, gantry milling processing, anti-vibration, anti-torsion and anti-deformation; Fgodsv Hkmvjpfx Aanji Professional industrial computer, resistant to high temperature and dust; Dust removal Hollow rear chuck, dust is removed from the inside of the pipe, the dust removal effect is good, meet the requirements of environmental protection; Short tail function Support two kinds of short tail functions: rear chuck inserted short tail, front chuck movable short tail; Ensure that workpieces & pipes can achieve short tails, reducing material waste.

Condition: used, Year of construction: 2021, CNC MACHINING CENTER Morbidelli N100 KEY FEATURES "BUMPERS": THE PERFECT COMBINATION OF SAFETY AND PRODUCTIVITY "PRO-SPACE" SAFETY DEVICES: SAFE AND COMPACT "HE" TABLE - FOCUS: EFFICIENCY AND SAVINGS AXES Morbidelli N100 12 Morbidelli N100 15 Morbidelli N100 18 Morbidelli N100 22 Working area in X-Y-Z axis * mm 2486-1255-150 3686 TECHNICAL DATA -1555-150 3686-1860-150 22-31 = 30862185-150 22-43 = 42862185-150 Travel X-Y-Z axes mm 3120-1685-250 4320-1985-250 4320-2285-250 22-31 = 37702585-250 22-43 = 49702585-250 Traverse speed of X-Y axes m/min 35 WORK TABLE Type Multifunction table made of aluminum Stops for "A" working area No. 4 Vacuum pump (Opt.) m³/h 250/300 DRILLING UNIT Vertical spindles No. – RPM 7 (4X-3Y) 8000 – 12 (8X-4Y) 8000 Horizontal spindles (Opt.) No. – RPM 4 (2X-2Y) 8000 – 6 (4X-2Y) 8000 Integrated saw blade in X (Opt.) Ø mm – RPM 125 – 10000 Motor power kW (HP) 2.2 (3) ELECTROSPINDLE Motor power Std. (S6) kW (HP) 6.6 (9) – 9.5 (13) Max. speed RPM 24000 Lateral tool changer 8 positions 10 positions 11 positions 13 positions INSTALLATION Installed power kVA 23÷28.5 Compressed air requirement l/min 400 Extraction air requirement m³/h 5300 Extraction air speed m/s 30 Extraction nozzle diameter (electrospindle + drilling unit + kit) mm 250 Machine weight kg 1950 2200 2500 22-31 = 2550 22-43 = 3200 * X Distance between stops - Y Max. panel width - Z Workpiece passage only electrospindle or electrospindle + drilling unit: diameter 200 mm; Extraction air requirement 3,400 m³/h In conjunction with the strip for panel ejection, the extraction nozzle diameter is always = 250 mm GENERAL FEATURES CNC machining center for processing panel materials. Self-supporting structure and work table Box construction made of cold-rolled steel, consisting of rectangular sections welded together; multifunctional work table made of aluminum with a single working area. Holes in a grid of 120 mm for vacuum connection, easily removable via a magnetic device (patented system). The entire surface is grooved at a distance of 20 mm so that the workpieces can be clamped using rubber seals, MODULSET or suction cups. Automatically retractable reference stops that ensure accurate positioning of the workpieces to be machined. Moving gantry It is a gantry structure made of cold-rolled steel in a box construction, consisting of rectangular sections. The working units are installed on the gantry. Working unit consisting of a drilling head with vertical spindles, horizontal spindles, an integrated grooving and sawing unit and an SCM electrospindle with a quick-change tool system of type HSK63F. Travel of the gantry and aggregate carrier The movement in the X, Y and Z axis takes place on linear prismatic recirculating ball guides by means of pre-tensioned ball screws. The movement transmission of the X and Y axes (moving column and carriage) takes place via a reduction gearbox with rack and pinion drive. The movement of the aggregate carrier in the Z direction takes place via pre-tensioned ball screws. Positioning of the working units and control of the machine functions takes place via "Brushless" three-phase servo motors and digital control units. CONTROL The control unit consists of a numerical control. Fgsdpfxjz Iyvpo Aanoi

Condition: new, Year of construction: 2026, control type: CNC control, degree of automation: automatic, actuation type: electric, controller manufacturer: Cypcut, sheet thickness (max.): 28 mm, pipe diameter (max.): 240 mm, pipe length (max.): 6,300 mm, workpiece weight (max.): 800 kg, Equipment: CE marking, documentation/manual, Complete set double use laser machine ( 6 Kw on the way ) sheet metal 3015 ( 3 x 1,5 meter ) Tube 15 to 240 mm diameter tube length 6,3 meters options for a perfect laser line. Fgodpjnqzb Iefx Aanji option 1 filter installation ( cutting air can leave in factory ) include anty fire box. option 2 Vacuum lift for sheet metalplate 800 kg load. no cable unit work on battery in vacuum unit. option 3 compressor for 16 BAR it give posibility to cut steel without gas. for quick cutting and SST steel it save lot of air and can increase the cutting feed consummable for long time cust free cutting time. option vacuume lifter from 800 Kg lifter work on battery in lifter box so with loading machine no cables around you special for save working arear. Price is EXW Include loaded on truck. Transport, installation, commissioning, training, and yearly service contracts are available upon request for an additional fee. Installation and training is always done by our high qualified Service team in 3 locations in Europe. Netherlands, Germany, Romania. Official Dealer Benelux, Romania, Germany CNC Top Ten b.v. Coevorden Holland

Condition: good (used), Flame cutting system, torch, oxyfuel cutting system, machine cutting torch, flame cutting machine, cutting torch, cutting machine, oxyfuel cutting machine, gas cutting torch -Manufacturer: Messer Griesheim, machine cutting torch, flame cutting machine -Type: Quicky -Cutting speed: adjustable 200 - 1000 mm/min -Voltage: 220/240 V -Dimensions: 470/390/H150 mm -Weight: 6.6 kg Fsdpfxo Ahgzfs Aansgi

Condition: used, functionality: fully functional, In this listing, you are purchasing a second-hand “Magnopro I-Cut 7550” die-cutting machine Item for sale: 1 x Magnopro I-Cut 7550 Condition: This listing is for a second-hand machine, which may show signs of wear (minor scratches or discolouration). The machine has been tested to ensure it is in working order Packaging and dispatch: Fgsdpoz I Tgusfx Aanoi You are welcome to view the machine during our opening hours. Please arrange an appointment to do so! Sturdy packaging and worldwide dispatch available on request! A video recording of a functional test will be made for you prior to dispatch or collection. For further information, please feel free to contact us directly.

Condition: excellent (used), functionality: fully functional, Year of construction: 2012, Operating hours: 28,000 h Fgjdoy Rnb Depfx Aanoi

Condition: good (used), Year of construction: 2008, Ref. -No.: 10641 Manufacturer: HERMLE Type: C 1200 V Fsdpfx Aae Ahmvuonogi Year of construction: 2008 Type of control: CNC-Steuerung Control: Heidenhain TNC 430 Storage location: Halberstadt Country of origin: Germany Machine-No.: 193XXXX X-Travel: 1200 mm Y-Travel: 900 mm Z-Travel: 500 mm Tool Taper: HSK 63 Tool changer: 30 Spindle Speed: 16000 RPM Weight Of The Machine Ca.: 14 t Further information: The machine can be viewed while it is powered on, subject to prior arrangement.

Condition: good (used), Year of construction: 2004, Ref. -No.: 10629 Manufacturer: MICHAEL DECKEL Type: S20 Turbo Year of construction: 2004 Type of control: CNC-Steuerung Storage location: Halberstadt Country of origin: Germany Workpiece Diameter: 250 mm Max. Grinding length: 340 mm Max. Workpiece Weight: 50 kg Grinding wheel diameter (max.): 150 mm Fgodpfo Ahkxyex Aansi Turning Speeds: 8000 RPM Workpiece holder: SK 50 Further information: The machine can be viewed while powered up.

Condition: new, functionality: fully functional, Year of construction: 2025, control type: CNC control, actuation type: mechanical, laser type: fiber laser, laser power: 6,000 W, power: 6 kW (8.16 HP), type of input current: three-phase, type of cooling: water, Equipment: CE marking, centralized greasing system, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, nozzle changer, safety light barrier, Series: GS-CEH Type: Exchange table, full protection, full protection exchange table Fgjdpfxjwxar Dj Aanji Laser power: 3KW, 6KW.12KW, 15KW, 20KW Standard hardware: Scrap car, fully automatic butter injection, dual-control workbench, adaptive multi-angle site placement, rear lift light-blocking door, beam light curtain, partition dust removal Optional hardware: Fire bricks, high-pressure proportional valve (standard above 6KW), safety door lock, independent laser cabinet, rear exchange table light curtain, rear camera, internal camera, monitoring display, radiation-proof glass, upper cover fan, upper cover, light-blocking rubber strip Optional functions: FDA configuration CSA configuration, TUV configuration conventional CE configuration

Condition: good (used), functionality: fully functional, Year of construction: 2006, The machine is being sold due to a plant modernization. Only 3,000 operating hours. Immediately available. Fgjdpjzlr Rpefx Aansi Machine already disassembled. Technical data: Manufacturer: TRUMPF Model: TruLaser Tube 5000 (T01) Year of manufacture: 2006 Control system: Siemens Sinumerik 840D Laser type: CO₂ laser TruFlow Working area, tube length: 6,500 mm Max. round tube diameter: 150 mm Max. rectangular profile / circumscribed circle: 150 mm Max. material weight: 20 kg/m Max. workpiece weight: 130 kg Automatic tube support Self-centering clamping technology

Year of construction: 2002, condition: like new (used), Panaroma AT400 Pasta stacking and cutting machine Fsdpfx Ajd R D Tvoanjgi 2002, Stainless stacking and cutting machine, 400mm width, designed to roll, to dust, to cut and to overcome the pasta sheet layers, suitable for lasagne or tagliatelle. Output up to 100Kg / hour, variable speed, with timer, 3ph, mobile

Condition: good (used), Year of construction: 2008, Ref. -No.: 10621 Manufacturer: PAMA Type: Speedmat 3/TR16 Year of construction: 2008 Type of control: CNC-Steuerung Control: SIEMENS SINUMERIK 840 D PL Storage location: Halberstadt Country of origin: Italy X-Travel: 3500 mm Y-Travel: 2500 mm Z-Travel: 2200 mm W-Axis: 800 mm Bore Spindle Diameter: 160 mm Table Load: 12000 kg Tool Taper: ISO 50 BIG PLUS Turning Speeds: 3500 RPM Max. Torque: 2.765 Nm Rapid Travel X/Y/Z: 25000 mm / min Drive Capacity - Spindle Motor: 46 kW Internal cooling: 15 / 45 bar External cooling: 50 / 4 bar Table surface: 1600 x 2000 mm Spindle speed gear stage 1: 2.120 1 / min Spindle speed gear stage 2: 2.765 1 / min Further information: Fgsdo Ahkxvjpfx Aanoi Automatic tool changer SK50 DIN 69871, 80 positions. Automatic angle milling head TS 35 with 360 positions, speed 2,000 rpm and torque 2,000 Nm. Automatic universal milling head TU25C (2-axis), speed 3,000 rpm and torque 800 Nm. Automatic accessory changer, 2+1 units. Touch probe (Renishaw). The machine can be inspected under power.

Condition: used, Year of construction: 2004, travel distance X-axis: 1,800 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,100 mm, controller manufacturer: Heidenhain, controller model: iTNC 530, workpiece height (max.): 1,100 mm, workpiece diameter (max.): 1,950 mm, workpiece weight (max.): 3,500 kg, total height: 4,375 mm, total length: 12,300 mm, total width: 11,200 mm, table width: 1,400 mm, table length: 1,600 mm, spindle speed (min.): 20 rpm, spindle speed (max.): 18,000 rpm, spindle motor power: 28 W, number of spindles: 1, number of slots in tool magazine: 120, Equipment: chip conveyor, documentation/manual, We are pleased to offer this CNC 5-axis universal machining center. It is a Deckel Maho DMC 200U from 2004 with the Heidenhain iTNC 530 control. Technical specifications: Table dimensions: 1600x1400mm Number of pallets: 2 Max. workpiece dimensions: 1950x1100 mm Max. workpiece weight: 3500 kg X-axis travel: 1800 mm Y-axis travel: 2000 mm Z-axis travel: 1100 mm B-axis (swivel of the head): -7/+187 ° C-axis (work table rotation): 360° Spindle speed: 18,000 rpm Spindle mount: HSK A-63 Fjdpfxsz Tqyks Aanogi Spindle motor: 28/19 kW Number of positions in tool magazine: 120 We realise that you may wish to receive further information or view the machine. In that case, please contact us, providing your company details so that we can get in touch with you.

Condition: good (used), Year of construction: 2026, Ref. -No.: 10648 Manufacturer: HAITIAN Type: V10 Year of construction: 2026 Type of control: CNC Control: FANUC 0i-MF Storage location: Halberstadt Country of origin: China X-Travel: 1000 mm Y-Travel: 600 mm Z-Travel: 600 mm Fsdpfe Ahkx Sjx Aansgi Spindle Taper: SK 40 Table Dimensions (Lengthxwidth): 1200 x 600 mm Table Load: 800 kg Max. Tool Weight: 8 kg Max. Tool Length: 300 mm Max. Tool Diameter: 80 mm Numbers Of Tools In Magazin: 24 Turning Speeds: 8000 RPM Rapid Traverse X-Axis: 36 m / min Rapid Travel Y-Axis: 36 m / min Rapid Traverse Z-Axis: 36 m / min Distance between spindle nose and table: 150 - 750 mm Machine length: 2800 mm Machine width: 3550 mm Machine Height: 2700 mm Weight Of The Machine Ca.: 6,5 t Tool-tool change time: 2,5 sec Feed rate X-axis: 15 m / min Feed rate Y-axis: 15 m / min Z-axis feed rate: 15 m / min Positioning accuracy: 0,008 / 0,006 / 0,006 X/Y/Z Repeatability: 0,005 / 0,004 / 0,004 X/Y/Z T-slot in the table: 5 x 18 x 100 mm Further information: - Documentation / Manual - Steplessly adjustable spindle speed - Chip conveyor - Drive type: Belt drive - Pull stud: MAS P40T-I (45°) - Power supply: 30 kVA - Pneumatic and hydraulic lubrication system - Coolant system - Internal coolant tank with chip conveyor - Full enclosure - Air gun - 3-color signal tower light - Standard accessories - Chip trolley This is a brand-new machine available at short notice, with a wide range of customization options to meet individual customer requirements. Various control systems, including FANUC, HEIDENHAIN, and Siemens, as well as different spindle configurations and a wide range of additional equipment options, are available. This allows the machine to be tailored to specific production requirements and machining applications.

Condition: new, functionality: fully functional, Year of construction: 2025, Equipment: CE marking, centralized greasing system, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, nozzle changer, safety light barrier, High-strength welding bed Partitioned smoke extraction system Fully automatic butter injection system Fully automatic cutting, material saving, fast speed Cutting area 4000 × 2000 mm X‑axis travel 1520 mm Y‑axis travel 4020 mm Z‑axis travel 80 mm Max. combined positioning speed 170 m/min Acceleration 2.8 G Machine dimensions (L×W×H) 9500 × 2900 × 2380 mm Footprint 10500 × 3400 mm Net weight 8500 kg Fgedpfxow A Iilo Aanji

Condition: ready for operation (used), functionality: fully functional, A very nice Ideal type 5251-90 is for sale. Fgsdpfx Aae Ahh T Ejnoi It features a digital display and automatic pressing, operating on 220 volts. It comes complete with an extra blade. You are welcome to test this machine at our location. We can arrange transportation and packaging for you and load it into a truck or container. Please inquire about a price including transportation (within the Netherlands). Best regards, Henk Hoos.

Condition: used, Max. cutting width: 760mm, max. insertion depth: 760mm, max. stack height: 110mm, table height: 900mm, length: 1750mm, width: 1520mm, height: 1400mm, weight: 1.04t, an on-site inspection is possible. Fgedpj Aiu S Asfx Aanji

Condition: good (used), Year of construction: 2006, Ref. -No.: 10651 Manufacturer: CHIRON Type: Mill 2000 Year of construction: 2006 Type of control: CNC Control: SIEMENS SINUMERIK 840 D - Safety Integrated Storage location: Halberstadt Country of origin: Germany Machine-No.: 498-XX X-Travel: 2000 mm Y-Travel: 500 mm Z-Travel: 640 mm Total Power Requirement: 29 kW Weight Of The Machine Ca.: 9,6 t Further information: 3-axis machining center equipped with a Siemens CNC control system and a 40-position tool magazine. The machine allows pendulum operation on two separate machining areas. Tool Interface: SK40 Working Area: Fgjde Ahkyaspfx Aansi X-axis: 2,000 mm (can be divided into 2 × 850 mm) Y-axis: 500 mm Z-axis: 640 mm Equipment: Screw chip conveyor with discharge to the left side Stand-alone Knoll coolant system for tool coolant supply and machine sump flushing The machine can be inspected under power.

Condition: good (used), Year of construction: 2012, Ref. -No.: 10659 Manufacturer: DECKEL MAHO Type: DMC 835V Year of construction: 2012 Type of control: CNC Control: Haidenhein iTNC 530 Storage location: Halberstadt Country of origin: Germany Machine-No.: 1541XXX X-Travel: 835 mm Y-Travel: 510 mm Z-Travel: 510 mm Number of T-slots: 5 Max. Tool Weight: 6 kg Max. Tool Length: 250 mm Max. Tool Diameter: 80 mm Tool change time: 1,6 s T - groove width: 14 mm T - slot spacing: 100 mm Fgjdpfx Aszw Tw Ujanji Tool Taper: SK40 Numbers Of Tools In Magazin: 30 Spindle Speed: 12000 RPM Max. Torque: 130 / 87 Nm Turning Speed Range - Stepless: 30 mm / min Total Power Requirement: 35 kW Dimensions Of The Machine Ca.: 4,5 x 3,5 x 2,7 m Weight Of The Machine Ca.: 5 t Changeover time chip - chip: 6 sec Feed rate: 1 - 20.000 (X / Y / Z) High pressure cooling: 20 bar Further information: The machine can be inspected while powered on by prior arrangement.

Condition: good (used), Year of construction: 2000, High-performance CNC vertical machining center with SIEMENS 840 D, dual pallet changer, internal coolant system, linear guides, and 30-tool automatic tool changer. Table size: 2 x 1000 x 450 mm Tool holder DIN 69871: ISO 40 Travel ranges: X-axis: 1100 mm Y-axis: 500 mm Z-axis: 640 mm Spindle speed range: 50 – 10,000 rpm Fgedjd I R E Njpfx Aansi Table load: 600 kg Feed rate range, X/Y/Z, stepless: -10,000 mm/min Rapid traverse in all axes: 30 m/min Drive power: 18.5 kW Machine dimensions L x W x H: approx. 3605 x 3041 x 3220 mm Weight: approx. 6700 kg Accessories / Special features: • CNC control system SIEMENS 840 D • Dual pallet changer • 30-tool automatic tool changer • Full enclosure with safety doors, electrically secured • High spindle speed up to 10,000 rpm and drive power of 18.5 kW • Linear guides with double roller recirculating bearing, allowing high torques to be absorbed evenly in all directions • Ball screws in all 3 axes • The entire machine bed is made of Meehanite cast iron, ensuring precision, rigidity, and vibration damping • Tool holder DIN 69871, ISO 40 • Chip conveyor with integrated coolant system • 4th axis pre-configured • CE compliant Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 D - 44143 Dortmund - Wambel

Condition: good (used), Year of construction: 1998, Ref. -No.: 10583 Manufacturer: MTE Type: BF 4200 Year of construction: 1998 Type of control: CNC-Steuerung Control: Heidenhain TNC 426 Storage location: Halberstadt Country of origin: Germany Fodpfxj Ahkwie Aanegi X-Travel: 4000 mm Y-Travel: 1200 mm Z-Travel: 1500 mm Turning Speeds: 2.500 RPM Rapid Traverse X/Y/Z: 400 m / min Table surface area (LxW): 4200 x 1000 mm Tool changer: 40 Table load max.: 13.000 kg Tool Taper: SK 50 Weight: 20 t Number Of T-Slots: 7 Pcs Width of the T-slots: 22 mm Distance between the grooves: 140 mm Further information: - Heidenhain HR410 handwheel - 3D scanner, infrared - The ball screw on axes Z and Y runs clamped and supported on combined radial/axial roller bearings and radial ball bearings with 250 N/sqm stiffness. The machine can be viewed while powered up.

Condition: good (used), Year of construction: 2009, laser type: CO₂ laser, laser power: 3,200 W, X working area max.: 6500 mm Laser power: 3200 watts Control: SINUMERIK 840D Standard equipment: - Robust machine frame with integrated laser unit - CO2 laser TLF 2000, high-frequency excited, with cooling unit - Drives: Maintenance-free three-phase servo motors - Hl-LAS high-pressure cutting - Fast processing with SprintLas - Programmable cutting gas pressure adjustment - Laser cutting head with 5" lens, DIAS III - Quick-change device for cutting head - Laser power control - Laser logbook function - Automatic shut-off - Work area lighting - Control system SINUMERIK 840D: Open PC-based control, easy operation, diagnostic functions, maintenance logbook, technology data, teleservice, 3.5" floppy disk drive, RJ45 network connection - Safety: Multi-beam light barriers, fully enclosed and ventilated beam guidance, compact extractor, protective cabin Fodpfx Aao Ahi Trensgi - PRS 3001 unloading station with brush table - Chuck set D 20-85 mm Special equipment: + Upgraded to Laser TruFlow 3200 + SeamLine Tube + LoadMaster Tube 6.5 m, rear + Focus Line
