Used Cnc Lathe Machine for sale (84,163)

Condition: used, Year of construction: 2011, AXE AND STATUS TUSCAN LL-950 X 3000 HEAVY DUTY CNC LATHE MAKE TUSCAN, MADE IN TAIWAN MODEL LL-950x3000 YEAR 2011 CONTROL FANUC Oi-TD TURRET 12 STATION MAXIMUM CUTTING DIAMETER 950.0 mm Nwjdpexvclrjfx Ad Hop CENTRE HEIGHT 575.0 mm DISTANCE BETWEEN CENTRES 3000.0 mm SPINDLE NOSE A2-15 SPINDLE SPEED 9 – 500 RPM SPINDLE CENTRE MT # 6 SPINDLE POWER 30 / 37 Kw TOOL SIZE 32.0 mm TRAVERSES X AXIS: 480.0 mm Z AXIS: 3000.0 mm RAPID TRAVERSES X AXIS: 5M / MIN Z AXIS: 4M / MIN TAILSTOCK YES PLUS TWIN SWARF CONVEYOR 4 JAW CHUCK 3 X STEADIES FULLY FUNCTIONAL FULL SET OF MANUALS TURRET TOOLING

Condition: excellent (used), Year of construction: 2011, price reduction due to space required from €50000 to 46,995 MAZAK QUICKTURN SMART 200 M CNC LATHE MAZATROL SMART CONTROL 12 TOOL TURRET 360 MM TURNING DIA MAX 500 MM TURNING LENGTH 76 MM BORE FIXED HOLDERS + 3 X DRIVEN TOOLS PARTS CATCHER PROBING SWARF CONVEYOR HYDROFEED MULTIFEED MV 65 BARFEED HYD 3 JAW CHUCK TAILSTOCK 5000 RPM SPINDLE YEAR 2011 MACHINE IS AVAILABLE IMMEDIATELY LOADING FREE OF CHARGE AT OUR PREMISES Nsdpjvcnqqjfx Ad Hjwp LOCATION NORTHERN IRELAND

Condition: new, Year of construction: 2025, functionality: fully functional, NEWAY NL502 2 AXIS CNC LATHE WITH FANUC 0IT PLUS 3B YEAR OF MANUFACTURE - 2025 STANDARD INCLUDED FACTORY FITTED MACHINE OPTIONS  STD AIR - AIR GUN  STD CHIP - CONVEYOR SIDE HINGED WITH CHIP BOX  STD CHU - 10 INCH 3 JAW HOLLOW HYD CHUCK INC SET SOFT JAWS  STD CHU - STANDARD HYD CHUCKING CYLINDER - HOLLOW  STD CNC.OP - FANUC 0ITF 3B PLUS WITH 10.4 INCH COLOUR LCD DISPLAY & 8MB MEMORY  STD CNC.OP - MANUAL PULSE GENERATOR (MPG)  STD CS - COOLANT GUN  STD GUA - FRONT DOOR INTERLOCK  STD GUA - FULLY ENCLOSED SPLASH GUARDING SYSTEM  STD GUA - TELESCOPIC SLIDEWAY COVERS  STD HYD - STANDARD HYDRAULIC UNIT  STD LI - LED WORKING AREA LIGHTING SYSTEM  STD LI - PATROL LIGHT (3 COLOUR)  STD MISC - AIR CONDITIONING IN ELECTRICAL CABINET  STD MISC - BASIC MACHINE INSTALLATION PARTS  STD MISC - CE STANDARDS MACHINE CONFIGURATION  STD MISC - CENTRALIZED AUTOMATIC LUBRICATION SYSTEM  STD MISC - MACHINE MANUALS & OPERATOR HANDBOOKS  STD MISC - STANDARD ACCESSORIES  STD POW - TRANSFORMER (415V, 3PH, 50HZ)  STD SPGB TC - BELT DRIVE SPINDLE - 3,500 RPM - A2-6  STD SPGB TC - SPINDLE MOTOR FANUC 15.0 / 18.5 KW  STD TS - HYDRAULIC TAILSTOCK  STD TUR - 12 STATION SERVO TURRET MACHINE CONSTRUCTION & FEATURES  SOLID CAST IRON 45 DEGREE SLANT BED CONSTRUCTION  HARDENED & GROUND BOX GUIDEWAYS  12 STATION SERVO TURRET  10 INCH STANDARD CHUCK SIZE - 12 INCH & BAR CAPACITY UPGRADE OPTIONS  15.0 / 18.5 KW MAIN SPINDLE  HYDRAULIC TAILSTOCK MACHINE SPECIFICATION CAPACITY Max. Swing Diameter Over Bed Ø 600 MM Max. Swing Diameter Over Saddle Ø 480 MM Max. Turning Diameter Ø 500 MM Max. Turning Length 570 MM Max. Bar Capacity Ø 74 MM Nwsdoxt Nrmspfx Ad Hop X / Z AXIS TRAVEL X-Axis Travel 280 MM Z-Axis Travel 600 MM X / Z AXIS SERVO MOTOR TORQUE X-Axis Torque 10.5 NM Z-Axis Torque 10.5 NM SPINDLE HEADSTOCK STD Spindle Nose A2-8 Spindle Bore 86 MM Spindle Speeds 30 ~ 3,500RPM Chuck Size Ø 10” - 245 MM Spindle Power 15.0 / 18.5 KW FEEDRATES X-Axis Rapid Traverse Rate 16 M / MIN Z-Axis Rapid Traverse Rate 20 M / MIN Cutting Feed Rate 1 ~ 8,000 MM / MIN TURRET Number of Turret Stations 12 Turret Indexing Time 0.2 SEC / POS Tool Size - Turning 25 x 25 MM Tool Size - Boring Ø 40 MM TAILSTOCK Tailstock Quill Diameter Ø 100 MM Tailstock Quill Travel 100 MM Tailstock Quill Taper MT5 LIVE CENTER ACCURACY Positioning Accuracy (X / Z) 0.010 / 0.010 MM Repeatability (X / Z) 0.005 / 0.007 MM MISCELLANEOUS Power Requirement 35 KVA Power Supply 415V / 3PH / 50HZ Cutting Coolant Volume 240 L Machine Dimensions (L / W / H) 4,290 / 1,880 / 1,750 Machine Gross Weight 4,000 KGS

Condition: excellent (used), Hardinge HXL-S CNC Lathe Fagor Control Year 1998 Manuals Great Condition - Fully Working with no faults. We welcome any inspections Nwodpfx Adoxrvdgj Hop

Condition: used, Year of construction: 2001, Price: On request What are Presale Items at Second Owner? Presale items are machines that we sell in their current condition ("as-is"). We have purchased these machines based solely on photos and sell them with the information provided in the advertisement. Unfortunately, we do not have additional details, such as exact dimensions or machine specifications. Additionally, these machines are often not yet in stock and have not been inspected by us. These machines are offered at competitive prices, which means the prices are lower than usual, but the risk lies entirely with the buyer. Please carefully review the information in the advertisement before making a purchase. If you have any questions, feel free to contact us! - Year: 2001 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: AA1/011994 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets Nedpfx Ajxzcnkod Howp

Condition: excellent (used), Year of construction: 2019, Model: Alpha 1460 XS Year: 2019 Swing Over Bed: 460mm Swing Over Cross Slide: 270mm Swing In Gap: 730mm Distance Between Centres: 1500mm Spindle Speeds: To 2200 RPM (Variable) Spindle Bore: 78mm Machine With: 300mm 3 Jaw Chuck Nwsdpfoxphv Nox Ad Hsp 8 Station Indexing Turret (VDI 30) Various Tooling

Condition: used, Year of construction: 2003, travel distance X-axis: 700 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 330 mm, FANUC ROBODRILL T21i DL CNC DRILL-TAP MACHINE MAKE FANUC, MADE IN JAPAN MODEL ROBODRILL T21i DL CONTROL FANUC 16I-MB YEAR 2003 TABLE SIZE 850.0 x 410.0 mm TRAVERSES X Y Z 700.0 x 400.0 x 330.0 mm SPINDLE SPEED 10 – 20,000 RPM ATC 21 STATIONS SPINDLE TRAPER ISO 30 RAPID TRAVERSE 54m/min DISTANCE BETWEEN SPINDLE NOSE TO TABLE 150.0 mm – 480.0 mm CUTTING FEEDRATE 1 – 30,000mm/min TOOL CHANGE TIME 1.6 sec Nwsdpfetnh Alsx Ad Hsp MAX TOOL DIA 80.0 mm MAX TOOL LENGTH 200.0 mm MAX TOLL WEIGHT 2 kgs POWER RATING 5.5 Kw PLUS SWARF TRAY COOLANT SYSTEM SET OF TOOLING SET OF MANUALS

Condition: like new (used), Year of construction: 2009, MORI SEIKI NL2000/500 CNC TURNING CENTRE YEAR 2009 CONTROL MSX-850 III CONTROL COLLECT CHUCK DRIVEN TOOLING Njdpfx Adexvrzps Howp 4 AXIS 16 TOOL TURRET TAILSTOCK PARTS CATCHER TOOL SETTING PROBING SPINDLE SPEED MAX 6000 RPM MAX TURNING DIA 356 MM X TRAVEL 260 MM Y TRAVEL 100 (+ - 50) Z TRAVEL 590 MM C AXIS MOVEMENT 0.001 BAR CAPACITY 65 MM X-MEDICAL MACHINE - ONLY USED ON PLASITC FITTED WITH DUST EXTRACTION MACHINE DIMENSIONS: - Length: 2,705 mm - Width: 2,000 mm - Height: 2,120 mm - Weight: 5,800 kg

Condition: excellent (used), Quality Vision OGP SmartScope FLASH CNC 300 For sale is an OGP SmartScope FLASH CNC 300, a high-quality multi-sensor coordinate measuring machine for precise 2D/3D measurement tasks. This system comes from industrial use and is ideally suited for quality assurance, production, toolmaking, and laboratory applications. Description: The FLASH CNC 300 is a CNC-controlled optical measuring system with optional laser and touch probe technology. It enables highly precise measurement of mechanical components – e.g. diameters, heights, distances, contours, and geometric elements. Thanks to its video technology, motorized zoom optics, and multi-sensor-capable architecture, it is particularly versatile in application. Technical Data: Model: SmartScope FLASH CNC 300 Manufacturer: Optical Gaging Products / Quality Vision International (USA) Measuring range (XYZ): 300 × 300 × 250 mm Max. workpiece weight: up to 30 kg System weight: approx. 160 kg Power supply: 230 V~, 50/60 Hz, 2.5 A Shipping weight (packed): approx. 340 kg Measuring Methods & Equipment: Optical video system with motorized 12:1 AccuCentric® zoom Automatic zoom calibration for highest repeatability LED illumination: - Transmitted light (profile) - Coaxial incident light - SmartRing™ LED ring light Optionally usable sensors: - Laser (TTL laser) Nwsdpexz A Evsfx Ad Hop - Touch probe / scanning probe - Microprobes / height measurement Supported software (model-dependent): Measure-X, ZONE3, etc. Fields of Application: - Quality assurance - Batch and single part inspection - Measurement of plastic, metal, and milled parts - Precision optics, mold, and tool measurement - Laboratory, production, and research Condition: used Scope of supply: (see image) (Specifications are subject to change and errors excepted!) We would be happy to answer further questions for you by phone.

Condition: excellent (used), Year of construction: 2010, The XYZ 200TC is a CNC lathe known for its precision and versatility. It features a Siemens 810D Shopturn control system, a 12-station VDI turret. Key Features and Specifications: Control System: Siemens 810D Shopturn. Turret: 12-station VDI turret. Chuck: Hydraulic 200mm 3-jaw chuck. Bar Capacity: 52mm. Swing Over Bed: 420mm. Maximum Machining Diameter: 200mm. Maximum Machining Length: 550mm. Nwedsxrvcvjpfx Ad Hep Spindle Speed: 4800 rpm. Spindle Bore: 62mm. Spindle Motor Power: 14.9kW. Other Features: Automatic tool setting arm, swarf conveyor, parts catcher, hydraulic tailstock, remote electronic handwheel, and through-tool and flood coolant. Weight: 4100kg. The XYZ 200TC is a slant-bed CNC lathe, which means the lathe bed is angled, allowing for better chip evacuation and access to the workpiece. It can be equipped with a multi-feed barfeed for automated feeding of bar stock. The machine is typically used in small to medium-sized workshops and production environments. Complete with bar feed, swarf conveyor and tooling.

Condition: ready for operation (used), total height: 3,300 mm, total width: 3,450 mm, total length: 6,000 mm, controller manufacturer: Siemens, empty load weight: 17,000 kg, Model: FTV 850 Koeling door spindel Het werkgebied kan in twee secties worden verdeeld 2 magnetische tafels Bewegende kolom, vergelijkbaar met Mazak VTC / Unisign / Hedelius Zware chassisstructuur Nodjwxz D Uopfx Ad Hswp Longitudinal travel X-axe: 1800 mm Crosstravel Y -axe: 850 mm Travel Z-axe (Height): 800 mm Dimensions clamping space - table: 2300 x 900 mm Universal (2x 360°): ISO 50 Boring head (1 x90°): 19 kW

Condition: used, Year of construction: 2003, control 840D-PCU 50 V1 3 coolant ja chip conveyor ja kW Nwjdpfxjqn A Rrs Ad Hep generator - rated current 110 A connected load 56 kW

Condition: used, MURATEC WIEDEMANN MOTORUM 2048 CNC TURRET PUNCH MACHINE MAKE MURATA WIEDEMANN, MADE IN JAPAN MODEL MOTORUM 2048 CONTROL FANUC 30i TOUCH SCREEN YEAR 2016 CAPACITY 20 TONS SHEET SIZE (WITH ONE REPOSITIONING) 1250mm x 2500mm SHEET THICKNESS MAX. 6.35 mm Y, X STOKE Y AXIS: 1360.0 mm X AXIS: 2550.0 mm PUNCHING ACCURACY +- 0.1mm THROAT DEPTH 1340.0 mm MAX ALLOWABLE SHEET WEIGHT 150 KG HIT RATE 1.0T 25 mm PITCH 8.3 mm stroke: 355 HPM 0.5 mm PITCH 1.4 mm stroke: 900 HPM SIMULTANEOUS AXIS SPEED 125 m/MIN PUNCHING ACCURACY +- 0.1 mm TURRET INDEX SPEED 35 RPM Nwjdoxvch Tjpfx Ad Hop COMPRESSED AIR QUANITY: 100NL/MIN PRSSURE: 0.5 MPa POWER SUPPLY 19 kVA PLUS GOOD SET OF TOOLING ONE OWNER FROM NEW VERY LESS HOURS SAFETY GUARDS

Condition: excellent (used), Year of construction: 2020, operating hours: 3,744 h, functionality: fully functional, turning diameter over cross slide: 630 mm, turning length: 2,200 mm, turning diameter: 775 mm, spindle bore: 117 mm, SMEC Samsung Turning Centre Model SL4500XY Year 2020 Fanuc Series Oi-TF Control 775 mm swing over bed 630 swing over cross slide Max machining dia – 680 mm Max length to be confirmed – 2000 mm Bar working dia – 117.5 mm X travel 350 mm Chuck size 534 mm SMW Autoblok Type SLU-X-4-ZS Steady Live Tooling – 6 Driven tools Swarf Conveyor Nwedpfew T Rq Eex Ad Hjp Swarf Skip A video can be sent of the machine running , everything is working as it should . came out of factory closer locally

Condition: excellent (used), Ecoca SJ-30HT, 3 Jaw Chuck, Tailstock, Toolarm, Year 2007 Control Fanuc 18-T Swing over bed 580 mm Swing over cross slide 434mm Max turning diameter 280mm Max turning length 460mm (centers) Chuck size 254mm (10") Bar passage (bore) 90mm or 75mm (SJ 30G) Spindle 3500–4200RPM; 25–30Hp / 11–15kW Spindle nose A2 8 Nwjdpfx Adowx Hnfe Hjp Spindle bore 90mm (through hole) X-axis travel 190mm Z-axis travel 520mm Rapid traverse X/Z 15m/min (X), 20m/min (Z) Tool turret 12 station hydraulic Curvic coupling Quill (tailstock) 90mm dia, taper MT 5, 120mm travel Spindle motor power 25/30Hp (18–22kW) Electrical power 40kVA supply Coolant tank147L Footprint 4460×1920mm Net weight 5000kg

Condition: used, Year of construction: 2006, functionality: fully functional, Equipment: documentation/manual, rotational speed infinitely variable, Hardinge Lathe Nwsdpfxjxzp R Ss Ad Hop Model Talent 10/78 Siemens CNC Year 2006 With Tooling With Documentation With Chip Conveyor Video Available

Condition: ready for operation (used), Fanuc 6-assige robotfreescentrum voor aluminium en staal X-beweging van de robot: 10.500 mm Verlengd bereik van de robotarm (links en rechts): 3045 mm maximale werkstuklengte indien het een profiel betreft: 15 meter max. werkstukgrootte zonder verlengde armbereik: 10.500 x 3045 mm max. werkstukhoogte: 3500 mm 13-positie gereedschapswisselaar: - 12 elektrische gereedschappen - 1 meetsonde Freeskop: -SK40 - 10 kW op spindel 12.000 tpm / 15.000 tpm - 7,5 kW op spindel / 18 000 tpm - 4 kW op spindel / 24.000 tpm - automatische smering Er zijn veel configuraties mogelijk, afhankelijk van het type werkstuk. Momenteel zijn er twee aparte werkgebieden, maar u kunt dit wijzigen naar één werkgebied (voor een groot werkstuk) of het opsplitsen in meerdere aparte werkgebieden voor kleinere werkstukken. Nwjdpfxsv Sfk Hs Ad Hep

Condition: used, Year of construction: 2000, max. 800 mm turning length max. 800 mm chuck ohne documentation inkl. weight of the machine ca. 8 t +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. Nodpeh D Anajfx Ad Hswp +++++

Condition: used, Year of construction: 2001, DAEWOO - DOOSAN PUMA 400 LB CNC LATHE MAKE DAEWOO - DOOSAN, MADE IN KOREA MODEL PUMA 400 LB YEAR 2001 CONTROL FANUC 18 iT CHUCK SIZE 450.0 mm SWING OVER THE BED 700.0 mm SWING OVER SADDLE 480.0 mm MAX TURNING DIA. 380.0 mm BETWEEN CENTRES 2100.0 mm DRAW TUBE DIA. 117.5 mm TRAVELS: X AXIS: 362.0 mm Z AXIS: 2155.0 mm TURRET 10 STATIONS SPINDLE SPEED 20 - 2,000 rpm SPINDLE BORE 132.00 mm SPINDLE NOSE A2 - 11 BEARING DIA. 180.0 mm TURRET TOOL HEIGHT 25.0 mm TURRET BAR DIA. 50.0 mm TURRET INDEXING TIME 0.25 sec FEEDRATE RAPID TRAVERSE X: 16,000 mm/min Z: 18,000 mm/min FEEDRATE CUTTING FEED X , Z: 0,001 ~ 500.000 TAILSTOCK QUILL DIA. 120.0 mm TAILSTOCK QUILL BORE TAPER MT#6 TAILSTOCK QUILL TRAVEL 120.0 mm PLUS HYDRAULIC STEADY Nwodoxp Nfxopfx Ad Hjp TOOL SETTING ARM SWARF CONVEYOR TURRET TOOLING FULL SET OF MANUALS

Condition: used, turning diameter max. 360 mm turning length 505 mm control Mazatrol SmoothC max. swing diameter over bed 660 mm swing diameter over slide guides max 255 mm bar material dia. max. 80 mm turning speed range - spindle 35 - 4000 U/min max. torque on the spindle 358 Nm x-axis 225 mm rapid traverse X-axis 30 m/min z-axis 605 mm rapid traverse Z-axis 33 m/min spindle nose A2-8'' Njdpfx Aev Dxw Red Howp spindle bore 91 mm spindle hollow 80 mm Milling spindle speeds ( driven tools) 5000 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40%ED) kW tailstock quill taper MT 5 Travel- tailstock 565 mm Axial pressure max 5,0 Nm Tool turret 1 Numbers of tools 12 (angetrieben) turning tool - shaft cross cut 25 x 25 mm tool taper BMT Required air-pressure 5 / 160 bar / l/min voltage 400 V coolant tank 180 l engine output 18,5 (30min Betrieb) kW Rated power (100% continuous operation) 15 kW weight of the machine ca. 6 t dimensions of the machine ca. 3,6 x 2 x 1,8 m Machine incl. the following special accessories: Chip conveyor on the right side Productivity package C - special according to storage machine This package includes: High-performance coolant system (1.1 kW) Flow rate max. 17.6 l/min Preparation for chip conveyor (lateral) Automatic tool eye STANDARD ACCESSORIES Transformer for the European market Use of linear systems with guide carriage SD MEMORY I/F(1P) + USB MEMORY I/F(1P) 1 x USB memory interface (1 slot) Spindle bore 91 mm Set of manuals in electronic form on CD Mazak standard colour CE marking, metric, 50 Hz C-axis input accuracy 0.0001° NC controlled tailstock Tailstock pressure adjustment Tailstock with fixed quill MK5 SAFETY DEVICES Operator door with interlock switch Double foot switch Hydraulic pressure lock Fully enclosed work area Work area lighting Safety precautions according to global standard COOLANT SUPPLY Grundfos coolant pump type MTA (0.25kW / 7.6L/min) Complete coolant system Automatic switch-off via circuit breaker triggering MESSSYSTEM Absolute positioning system NUMERICAL CONTROL Synchronous tapping with milling spindle Relocation Detector Mazatrol SmoothC 10.4’ colour screen User macro (600 variables) EIA/ISO input function Tool path check in the background Thread cutting function (G33) Polar coordinate input (EIA) Drawing data direct input function Interface for LAN Various tool holders - All dimensions, weights and performance data are non-binding - Used machine without warranty -

Condition: excellent (used), Tuscan LC38 x 3000mm CNC Lathe Swing Over Bed 970mm Swing Over Cross Slide 420mm Centre Height 490mm Distance Between Centres 3000mm 12 Station Duplimatic Turret Tailstock Nodpfx Adevtw Ime Hswp Boring Bat Attachment Boring Bar 2 x 3 Point Fixed Steady 1 x Travelling Steady Fanuc OiTC Control C Axis & Driven Tools Serial Number LC223806086 Year 2010 /10

Condition: used, Year of construction: 2000, machine/vehicle number: 202000, Hegenscheidt MFD 7893 CNC Deep Rolling Machine Nwodpsxxyluofx Ad Hop max length 920mm, max radius of counter weight (deending on dtroke and bearing width) 195 - 270mm, max 8 main + 6 pin bearings, min/max main bearing dia 33 - 88mm, min/max pin bearing dia 30 - 84mm, max bearing width 18,5mm, max stroke 140mm, CNC SIEMENS SINUMERIK 840D, 400V 50Hz 35kVA, weight 13to

Condition: used, Year of construction: 1996, MAZAK SUPER QUICK TURN 10 MS CNC LATHE MAKE MAZAK, MADE IN JAPAN MODEL SUPER QUICK TURM 10 MS YEAR 1996 CONTROL MAZATROL T PLUS MAX SWING 435mm SWING OVER CARRIAGE 370mm MAX. MACHINING DIA 230mm MAX. BAR WORK DIA 42mm MAX DISTANCE BETWEEN SPINDLES 705mm SPINDLE MOTOR AC11kw (15HP) Nwjdsxnpp Ispfx Ad Hep SPINDLE SPEED 6000rpm 2ND SPINDLE MOTOR AC5.5kw (7.5HP) 2ND SPINDLE SPEED 6000 rpm ROTARY TOOL MOTOR AC2.2kw (3HP) ROTARY TOOL SPEED 3000 rpm TURRET TOOL CAPACITY 12 TOOLS STATIONS RAPID TRAVERSE RATE X,Z:30m/min (1180IPM),C: 400rpm MACHINE DIMENSION L x W x H, 2705mm x 1465mm x 1835mm MACHINE WEIGHT 3850kg PLUS C-AXIS SUB SPINDLE DRIVEN TOOLS (3 NO.S) PARTS CATCHER SWARF CONVEYOR TOOL SETTING PROBE COLLET CHUCK BUILT IN TRANSFORMER FULL SET OF MANUALS GOOD WORKING ORDER

Condition: used, Year of construction: 2020, turning diameter 380 mm turning length 511 mm control Mazatrol SmoothG turning diameter over slide 276 mm max. swing diameter over bed 675 mm Standard machining diameter 276 mm bar material dia. 65 mm x-axis 234 mm rapid traverse X-axis 30 m/min z-axis 625 mm rapid traverse Z-axis 33 m/min turning speeds 35 - 5000 U/min spindle nose A2-6 spindle bore 76 mm Motor output (40%ED) 26 KW 22 KW Max. Torque 465 Nm turning speeds 6000 U/min Main drive power 11 KW Nedpfxjtugggs Ad Hjwp Max. Torque 90 Nm Milling spindle speeds ( driven tools) 35-6000 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40% ED) kW Milling spindle power 3,7 kW Numbers of tools 12 (angetrieben) Tool cross section (outside) 25 qmm Boring bar- Ø 40 mm Drill- Ø 20 mm Mill- Ø 20 mm Tap- Ø M20x2,5 Switching time one turret station ca. 0,20 sec coolant tank 180 l connected load 46,2 kW weight of the machine ca. 5,9 t dimensions of the machine ca. 2,7 x 1,9 x 1,9 m incl. the following accessories: - Signal light (3-colour LED), rectangular - High-performance coolant system (1.1 kW) Flow rate max. 17.6 l/min, pressure (at pump) 5 bar. - Additional coolant nozzle main spindle - Preparation for oil mist extraction electrical/mechanical flange 98mm - Preparation for bar feed - Robot interface (Advance/Profibus) - Chip conveyor with low ejection height - Overload monitoring system - Drilling cycle with torque-dependent chip breaking - Preliminary use of a hollow clamping cylinder on counter spindle - Hollow clamping device incl. draw tube + cylinder - Clamping chuck Hainbuch Spanntop Nova Axfix mini size 52 - Chuck Hainbuch Spanntop Nova Axfix special mini size 52 - 2 x collets - Changing device for collet chuck STANDARD ACCESSORIES Automatic on/off and warm-up function Air blowing device on the chuck on the counter spindle Use of linear systems with guide carriage USB connection (1 connection) Set of manuals in electronic form on CD C-axis main spindle Input accuracy 0.0001° Spindle positioning counter spindle without C-axis Input accuracy 0.001° Tool turret with 12 stations VDI, Operator door with locking switch Double foot switch for both main and counter spindle Hydraulic pressure interlock Fully enclosed work area Work area lighting Safety precautions in accordance with global standards High-performance coolant system (520W) Flow rate max. 11.5 l/min. Complete coolant system Automatic opening/closing of the chuck jaws Automatic tool eye Absolute positioning system Preparation for chip conveyor (lateral) Synchronisation of main and counter spindle Synchronised tapping with milling spindle Relocation Detector Mazatrol SmoothG control 19" LCD colour screen (touch screen) User macro (600 variables) EIA/ISO input function Optional stop (optional stop) Tool path check in the background Thread cutting function (G33) Polar coordinate input (EIA) Drawing data direct input function Interface for LAN SD memory card I/F - Second-hand machine without warranty - All dimensions, weights and performance specifications are non-binding

Condition: used, Year of construction: 2000, machine/vehicle number: 6126, Comau CNC Crankshaft Turn Broaching Machine max crankshaft dimensions, ca.: dia 250 x 800 mm, Twin-Station Crankshaft Turn Broaching Machine for Main and Pin Bearings, internal part transfer, two twin-cutting-head stations, one CNC SIEMENS SINUMERIK 840D per station with X1/X2 and Z1/Z2 Axes and C1/C2/C3/C4 rotating spindle Axes for each station, LxWxH, ca. 8x3x3m, weight, ca. 30to Nwsdpexxx E Hjfx Ad Hop
