Used Horizontal Slot Mortising Machine for sale (65,954)

Condition: like new (used), Year of construction: 2024, operating hours: 100 h, functionality: fully functional, machine/vehicle number: 90L0865829G_00, overall weight: 1,000 kg, input frequency: 50 Hz, type of input current: AC, input voltage: 400 V, The CMS Proxima is an automatic horizontal edging machine (dry edging machine) from CMS Glass Technology for processing glass edges. Processing length: The maximum working length per cycle is approximately 2.6 to 2.7 meters (larger panes can be accommodated). Glass thickness: Can process glass from approximately 4 to 19 mm. It can be operated either as a stand-alone unit (with a simple setup table) or in combination with tilting float cutting tables or laminated safety glass (VSG) cutting tables. Chsdpfx Ajz E Axzjl Ajc

Condition: excellent (used), Year of construction: 1998, Haffner Door Lock Mortising Machine used, in good condition Manufacturer: Haffner Model: SL 100 Machine No.: 5372 Chodsyuty Sopfx Al Asc Column-type machine Chain mortising unit Door support Workpiece support Spindle for lever hole Spindle for faceplate Lubrication device Extraction port D 80/100 mm Required space approx. 1200 mm x 700 mm x 2000 mm Weight approx. 300 kg Location: 54634 Bitburg Delivery in as-inspected condition, without warranty or guarantee

Condition: excellent (used), Horizontal machining center OKK Csdozr Ilvspfx Al Ajhc Rotary pallet system Type HM600 CNC Fanuc series 310IS-Model A Tilting and fork-liftable chip conveyor from GOUBARD Tool holders, double-sided (60) Coolant tank

Condition: used, Year of construction: 1962, serial number 813 Cjdpfez Alc Hjx Al Ajhc stroke 160 mm automatic feeds ja cross-moving table 2-Achsen weight of the machine ca. 1,2 t

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: 156592, travel distance X-axis: 1,000 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 6,000 rpm, number of slots in tool magazine: 171, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Chjdpfjwu Epasx Al Aoc Travel X/Y/Z: 1,000 x 900 x 1,000 mm Pallet size: 630 x 630 mm Number of pallets: 2 Max. workpiece size: 1,000 mm diameter x 1,000 mm height Max. workpiece weight: 1,200 kg Spindle power: 40 HP Spindle speed: 6,000 rpm Tool magazine: 171 positions Spindle taper: DIN50 EQUIPMENT - Coolant supply through spindle - Chip conveyor

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, CNC Machining Centre – Horizontal | Brand: HÜLLER HILLE | Type: NBH 95 Year of manufacture: 2001 The machine can be inspected under power by prior appointment. Condition: In working order / ready for operation. TECHNICAL SPECIFICATIONS: Working area - X/Y/Z axes: 630/630/630 mm - Workpiece swivel range within the working area: Ø 750 mm - Spindle clearance above top edge of pallet: min./max. 150/780 mm Pallet - Pallet clamping area: 400 x 500 mm - Transport load per pallet: approx. 0,6 tons - Fixture height: 880 mm - Pallet changeover time: approx. 7 sec. NC rotary table (B-axis) - Smallest incremental step: 0,001 degrees - Positioning uncertainty A according to ISO 230-2: 0,003 degrees - Permissible torques on the clamped table: * Tangential torque: max. 3.200 Nm * Tilting torque: max. 4.500 Nm Working spindle / Gearbox headstock - Tool holder: HSK-A 63 - Diameter at front bearing: 80 mm - Drive power 100% duty cycle/40% duty cycle: 21/30 kW - Speed range: max. 16.000 rpm - Torque at 100% duty cycle / 40% duty cycle: max. 100/143 Nm Feed / Feed force / Rapid traverse - Feed range, X, Y and Z axes: 1 – 50,000 mm/min - Feed force, X, Y and Z axes, 40% duty cycle: approx. 10.000 N - Rapid traverse speed, X, Y and Z axes: 50 m/min - Rapid traverse of rotary table: 40 rpm - Acceleration: approx. 7 m/s² - Ball screw (pitch): Ø 40 (20) mm Tool magazine: Cedpoz Emp Rsfx Al Ashc - Tool positions: 144 - 2 additional tool cassettes, each with 47 positions - Number of tool loading and unloading stations: 1 - Tool diameter / max. tool diameter: 75 / 175 (200) mm - Tool length: max. 400 (450) mm - Tool weight: max. 12 kg - Magazine cassette load capacity (including cassette): max. 600 kg Electrical system - Total power requirement: 80 kW Machine installation - Space requirements, area: approx. 16,75 m², height: 3,2 m - Ready-to-use machine weight: approx. 13,5 tons ACCESSORIES / EQUIPMENT: - Control: Siemens SINUMERIK 840D - Chip conveyor - Additional equipment for automated production: MPS pallet storage system - Documentation - CE marking - ... Technical data sheet with full details, including information on the further features, available on request. No guarantee is given as to the completeness or accuracy of the technical specifications and specifications. – Subject to prior sale –

Condition: ready for operation (used), Year of construction: 2014, travel distance X-axis: 1,626 mm, travel distance Y-axis: 1,270 mm, travel distance Z-axis: 813 mm, table width: 1,270 mm, table length: 1,400 mm, table load: 4,535 kg, overall weight: 20,800 kg, spindle speed (max.): 7,500 rpm, CNC Haas with 15-inch LCD screen Table size: 1400x1270 mm Maximum table load: 4,535 kg Spindle ISO 50, power 22.4 kW Maximum spindle speed: 7,500 rpm Travels: 1626x1270x813 mm 50-position tool changer Chip conveyor Weight: 20,800 kg Chodpoypv T Rofx Al Asc

Condition: good (used), Year of construction: 2009, Ref. -No.: 10662 Manufacturer: STARRAG HECKERT Type: HEC 1250 Athletic Year of construction: 2009 Type of control: CNC Control: Siemens 840D Storage location: Halberstadt Country of origin: Germany Machine-No.: 221XXX X-Travel: 2200 mm Y-Travel: 1600 mm Z-Travel: 1850 mm Spindle Diameter: 100 mm Max. Tool Weight: 35 kg Max. Tool Length: 800 mm Max. Tool Diameter: 250 mm Clamping Area: 1000 x 1250 mm Tool Piece Magazine With: 60 Pcs./pcs. Max. Torque: 25.000 Nm Chodpfxsz Adt Rj Al Aec Turning Speed Range - Stepless: 40000 mm / min Rapid Traverse: 40 m / min Numbers Of Pallets: 2 pallet change time: 47 s Weight Of The Machine Ca.: 26,5 t Position uncertainty P: 0,008 mm Position deviation Pa: 0,006 mm Positional dispersion Ps: 0,005 mm Maximum table rotation: 10 RPM Further information: - Design: Thermally symmetrical column design with optimal chip flow for machining castings. - Applications: Mechanical engineering, energy technology, and the machining of large gearboxes and engine components. - Powerful motor spindle (up to approx. 82 kW, depending on the model) for heavy-duty machining. - The Heckert HEC 1250 Athletic (built in 2009) is a high-performance, modular 4-axis large-scale machine for the precise complete machining of heavy workpieces. The machine can be viewed while powered on by prior arrangement.

Condition: good (used), Year of construction: 1998, Used Kitamura machining centers Type: Mycenter 2X Yasnac CNC control Max. spindle speed: 10,000 rpm Excl. clamping on the table Tool holder: SK 40 X: 610 mm Chjdpfx Aley U I H Ij Asc Y: 510 mm Z: 510 mm Tool changer

Condition: good (used), Year of construction: 2011, Ref. -No.: 10598 Manufacturer: HELLER Type: MC 2000 Year of construction: 2011 Type of control: CNC-Steuerung Control: Siemens 840 D sl Storage location: Halberstadt Country of origin: Hermany Machine-No.: 50XXXX X-Travel: 800 mm Y-Travel: 800 mm Z-Travel: 1000 mm Work spindle torque (25% ED): 242 Nm Tool Taper: SK 40 Numbers Of Tools In Magazin: 54 Tool Piece Magazine With: 80 Pcs./pcs. Turning Speeds: 10000 RPM Drive Capacity - Spindle Motor: 17 kW High-Pressure Pump: 50 bar Speed range - main spindle: 10000 RPM Numbers Of Pallets: 2 Size Of Pallet: 630 x 500 mm Weight Of The Machine Ca.: 13000 t spindle running time: 7000 H Operating hours: 14000 H Preparation area: 4 x 90° hydraulic pressure: 200 bar Further information: - The machine has been measured - The geometry is in excellent condition - The spindle runs a little rough - Clamping towers and cutting tool holders are also included - 2 additional clamping towers - 2 replacement pallets - 2-axis servo tool changer - Scraper conveyor for dry machining - Cold light in the work area - Central cooling unit for motor spindle and control cabinet - Control unit at the workpiece setup station - NC-controlled rotary table Codpfsx Hn D Rjx Al Aohc - Clamping hydraulics The machine can be viewed under power by appointment.

Year of construction: 2000, condition: good (used), For sale: Horizontal flow packer + infeed conveyor from Dekapack Model: S4 - 35 / 2 Control: Siemens S7 Chjdpfxswtq I Ej Al Ajc Documentation & electrical diagrams available. The machine is complete. Everything included as shown in the photos Transport upon agreement. Price: €5000,- EXW If you have any questions or remarks, please let us know! Best regards, Leo Holland

Condition: used, Vertical Slotting Machine GSP M 743 3-jaws chuck Ø 360 mm Table travel: X = 500 mm / Y = 450 mm Slide travel: 300 mm Throat depth: 500 mm Rotary table: Ø 690 mm Slide tilting: + 8° Rotative table/slide maxi height: 450 mm Motor power: 8 CV Strokes/min.: from 3 to 300 strokes/min. Equipped with one tool removal system upon lifting Voltage: 380 V Cedpfx Aozw A Aael Ashc Length: 2000 mm Depth: 2500 mm Total height: 2200 mm Weight: approx 4 T

Condition: excellent (used), Year of construction: 2004, operating hours: 19,000 h, functionality: fully functional, coolant supply: 40 bar, number of slots in tool magazine: 300, Equipment: documentation/manual, This machine was used solely for precision finishing and is in very good condition. Csdpfjz Hzymex Al Aohc

Condition: like new (used), Year of construction: 1987, Used Giddings and Lewis Model MC 50 Twin Pallet Horizontal Machining Centre with Live Spindle, 60 ATC and G&L 8000A Control System. Serial # 445-1052.Year of Manufacture: 1987 Machine Formerly Installed at Rolls Royce Plc In Derby UK. Immediately for Sale and now Located in Belgium where it can be Inspected. Spindle Diameter - 130 MM Spindle Taper - 50 ISO Spindle Travel (Z Axis) - 915 MM Spindle Speeds (4 Ranges) - 5 to 1500 RPM Main Motor - 30 HP Pallet Size - 1219 x 1245 MM Pallet Rotation Increments - 0.001 DEG (360,000 POSITIONS) Pallet Changer Max Load - 5000KGS Pallet Max Load Without APC - 9000 KGS Longitudinal Travel (W) - 1700 MM Vertical Travel Of Head (Y) - 1500 MM Cross Travel (X) - 1800 MM Feed Rates Per Minute - 1.00MM/MIN TO RAPID RATE Rapid Traverse Rate Per Minute (X And Y) - 4500 MM / MIN Rapid Traverse Rate Per Minute (Z And W) - 3000 MM / MIN Auto Tool Changer - 60 POSITIONS Electrical Supply - 415V, 3PH, 50HZ FEATURES AND EQUIPMENT High Pressure (25 Bar) Through Spindle Coolant, High Tolerance Machine. Accurate Machine which was well Maintained and Regularly Calibrated by Manufacturer. Renishaw Probing. Length - 11679 MM Chodpou Dahnofx Al Asc Width - 6502 MM Height - 4423 MM Weight - 40329 KGS

Condition: good (used), Year of construction: 2000, functionality: fully functional, 2x MAZAK horizontal machining centers + FMS with 12 stations and 2 loading/unloading bays Model: FH 5800 Year: 2000 Maximum workpiece height: 710 mm Maximum table load: 500 KG X-axis travel: 710 Y-axis travel: 610 Z-axis travel: 660 Spindle connection: BT Maximum spindle speed: 12,000 Spindle power: 22 KW Table size: 500 x 500 Table indexing: 1 degree Chjdpfx Aoz Apgcjl Aec Tool magazine capacity: 120 tools per station High-pressure system through the spindle: 50 Bar, with a separate tank and paper filter Maximum workpiece diameter: 720 mm Tool presetting with contact probe for length and tool presence Chip conveyor: belt type

Condition: used, Slotting Machine MAILLEFER type MAC-350 M Useful travel: 0 - 350 mm Cjdjzw A Atjpfx Al Ajhc Slots width: max 36 mm Motor power: 2,5 CV Feeds: from 0,025 mm to 0,125 mm Bore: from 15 to 160 mm Automatic forward and stop Supplied with many tools (see photos) Dimensions (L x W x H): 1400 x 800 x 800 mm Weight: approx 700 kg

Condition: used, Horizontal machining center with 2-fold shuttle table STEINEL type BFZ 5 with CNC control SIEMENS Sinumerik 810 M serial no. 34 year of construction 1988 Travel X: 500 mm, Y: 400 mm, Z: 320 mm Clamping surface, table surface 500 x 400 mm Tool holder ISO 40 Spindle speed max. 6300 rpm infinitely variable Main spindle drive 12 kW Mains connection 380 Volt, 50 Hz, 30 kVA - Tool changer with 24 tool positions Csdpfx Aeutuyiol Ashc - Changing table with 2 stations - Interface for data transfer - Coolant unit with chip conveyor Space requirement L x W x H 4100 x 2500 x 2650 mm Weight approx. 8 tons good condition Transport dimensions: Machine L x W x H 3200 x 2500 x 2650 mm, approx. 7.5 tons. Chip conveyor L x W x H 3500 x 1100 x 2100 mm, approx. 600 kg

Condition: good (used), Year of construction: 2008, Ref. -No.: 10335 Manufacturer: HüLLER HILLE Type: NBH 170 Year of construction: 2008 Type of control: CNC-Steuerung Control: Sinumerik 840D pl Storage location: Halberstadt Country of origin: Germany X-Travel: 1000 mm Y-Travel: 800 mm Z-Travel: 800 mm B-Axis: 360 ° Distance spindle center - table: 150 mm Chedozkpuvepfx Al Aec Table Dimensions (Lengthxwidth): 500 x 630 mm Table Load: 800 kg Max. Workpiece Weight: 40 kg Max. Tool Length: 650 mm Max. Tool Diameter: 325 mm Workpiece Diameter At Full Load: 100 mm Tool Taper: HSK - 100 Spindle Speed: RPM Rapid Traverse: 60 m / min Machine length: 9500 mm Machine width: 4500 mm Machine Height: 3500 mm Further information: Coolant system = 1250 l

Condition: good (used), Year of construction: 2007, Horizontal machining center OKK Rotopalette Type HM500 Year 2007 Chodpozr Ik Sefx Al Asc CNC Fanuc Series 310 IS-model Tool magazine with 60 tools Chip conveyor Approximately 26 tool holders with ISO 50 connection Tilting and forklift-compatible chip bin, GOUBARD Inspection points with shelves and lighting, fan Tool displays, double-sided (60) Buffer tank

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 157152, MAZAK FH-6800 – Technical Specifications Manufacturer: Mazak Model: FH-6800 Year of manufacture: 2001 Machine type: Horizontal CNC Machining Centre CNC control: MAZATROL PC-FUSION 640M Number of axes: 4-axis Working range • X-axis travel: 1,050 mm • Y-axis travel: 800 mm • Z-axis travel: 880 mm • Pallet size: 630 × 630 mm • Pallet load capacity: approx. 1,500 kg • B-axis: 360° indexing • B-axis resolution: 0.001° Spindle • Spindle taper: CAT 50 • Maximum spindle speed: 7,000 rpm • Spindle motor: approx. 37 kW Cjdpfx Aloz D Azyj Ashc • High-pressure coolant through spindle: Yes, documented at 70 bar on one 2001 specification sheet Tool changer • Tool magazine capacity: 120 tools • Tool holder: CAT 50 • Automatic Tool Changer (ATC): 120 stations

Condition: good (used), Year of construction: 2008, Ref. -No.: 10564 Manufacturer: TOYODA Type: FH 630 SX Year of construction: 2008 Type of control: CNC-Steuerung Control: Fanuc 31i - A Storage location: Halberstadt Country of origin: Japan Serial no.: NS2XXX X-Travel: 1000 mm Y-Travel: 800 mm Z-Travel: 850 mm B-Axis: 360 ° Max. Workpiece Weight: 800 kg Max. Tool Weight: 27 kg Chodpfx Ajxvw Izsl Aec Max. Tool Length: 545 mm Max. Tool Diameter: Ø 120 mm Max. Size Of Workpiece Lxwxh: Ø 1000 x 1000 mm Tool Taper: BT - 50 Tool Piece Magazine With: 60 Pcs./pcs. Spindle Speed: 6000 RPM Machine length: 7000 mm Machine width: 3500 mm Weight Of The Machine Ca.: 20,1 t Further information: - Equipped with IKZ and chip conveyor - NC rotary table 360,000 * 0.001° Machine can be inspected under power by arrangement.

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 900 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 980 mm, rapid traverse X-axis: 50 m/min, rapid traverse Y-axis: 50 m/min, rapid traverse Z-axis: 50 m/min, rotational speed (max.): 8,000 rpm, spindle nose: ISO 50, number of spindles: 240, CNC MSX 701 III Travels (X/Y/Z axes): 900 / 800 / 980 mm Pallet working surface: 630 x 630 mm Pallet load capacity: 1,200 kg High-torque spindle max speed: 8,000 rpm Rapid traverse rate (X, Y, Z): 50 m/min Tool magazine capacity: 240 tools Spindle motor power (30 min / continuous): 37 / 30 kW Machine Configuration: 240-position RACK tool magazine Spindle taper DIN 69871 – ISO 50 Tool breakage detection in magazine Index table with 1° indexing FASTEMS interface, model MLS-MD Spindle speed 8,000 rpm – 37/30 kW TOOL IC SYSTEM BALLUFF interface No. 600 macro variables No. 1 load monitor No. 200 storable programs No. 512 tool life management No. 999 tool offsets Chedpfeykpg Hjx Al Ajc No. 48 workpiece coordinate systems Data server + ATA card Mori Seiki scraper-type chip conveyor with drum filter MARPOSS application, model MIDA T25G, with E86N radio transmission system META pumping unit, model M 50/50, partial filtration system, 50 bar high pressure COMET drilled pallet Instruction manuals and CE Declaration of Conformity

Condition: good (used), Year of construction: 2006, functionality: fully functional, Leadwell horizontal machining center Model: LCH-500 Year: 2006 Table size: 500 x 500 mm Control unit: Fanuc O-i MC X-axis travel: 700 mm Y-axis travel: 610 mm Z-axis travel: 610 mm Maximum spindle speed: 10,000 rpm Spindle connection: ISO 40 Chedpfxez An Uro Al Asc Spindle power: 18.5 kW Chip conveyor (belt type) Pallet changer High-pressure system at 20 bar through the spindle

Condition: ready for operation (used), Year of construction: 2022, machine/vehicle number: 30B.11.040.22, functionality: fully functional, TECHNICAL DETAILS Working area, X-axis: 3,300 mm Working area, Y-axis: 1,280 mm Working area, Z-axis: 250 mm Travel, X-axis: 4,000 mm Travel, Y-axis: 1,670 mm Travel, Z-axis: 500 mm Milling spindle Number of milling spindles: 1 Max. spindle speed: 24,000 rpm Main motor power: 11 kW Tool clamping system: HSK-F63 Table design: Cantilever table Table length: 3,300 mm Table width: 1,280 mm Material clamping: Pneumatic Drilling unit Drilling tools available Horizontal drilling spindles: 4 Vertical drilling spindles: 12 Tool changer positions: 12 MACHINE DETAILS Controlled axes: 4 Software: WoodFlash Voltage: 400 V Current consumption: 40 A Connected load: 18 kW Dimensions & Weight Dimensions (L x W x H): 6,250 x 3,494 x 2,300 mm Chodpszrmuvjfx Al Aec Shipping dimensions (L x W x H): 5,300 x 2,350 x 2,400 mm Shipping weight: 4,000 kg Shipping packages: 2 EQUIPMENT Sawing unit Vacuum pump Becker PICCHIO 2200, year of manufacture 2022 Safety light curtain Manual control panel Tools CNC documentation with user keys/licenses and USB stick Documentation CE marking

Condition: like new (used), Year of construction: 2008, travel distance X-axis: 700 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 700 mm, feed rate X-axis: 60 m/min, feed rate Y-axis: 60 m/min, feed rate Z-axis: 60 m/min, nominal power (apparent): 68 kVA, controller manufacturer: HEIDENHAIN iTNC 530, workpiece height (max.): 1,000 mm, workpiece diameter (max.): 800 mm, workpiece weight (max.): 600 kg, total height: 2,547 mm, total length: 5,866 mm, total width: 4,196 mm, table width: 500 mm, table length: 500 mm, overall weight: 12,000 kg, spindle speed (max.): 18,000 rpm, spindle motor power: 34,000 W, number of slots in tool magazine: 120, Equipment: chip conveyor, documentation/manual, CNC controller: HEIDENHAIN iTNC 530 Axes: X-axis travel mm: 700 Y-axis travel mm: 700 Z-axis travel mm: 700 Distance spindle nose - table surface mm: 100 - 800 Rapid traverse m/min: 60 Acceleration in the axes m/s2: 6 / 6 / 5 Worktable: Number of pallets: 2 + 5 Table dimensions mm: 500 x 500 Maximum workpiece size (D x H) mm: 800 x 1.000 Max. workpiece weight kg: 600 T-Slot version: DIN 55201-A2 APC time s: 9,5 División estandar Grados: 360º (1º) Spindle: Spindle speed rpm: 18.000 Spindle drive power kW: 34 / 28 Spindle torque Nm: 110 Tool system: Tool holder: HSK-A63 Tool magazine slots: 120 Max. Tool Diameter: 80 Max. Tool Length mm: 550 Max tool weight kg: 12 Chip-to-chip time s: 2,9 Equipment: Electronic Handwheel Chip conveyor Rotating inspection windows Rinsing gun Signal lamp Tool breakage probe 3D quickSET Workarea light CE conformity Cooling device blowing air through spindle center, selectable via M-function MPC – Machine Protection Control Paper band filter Infrared Probe Heidenhain TS640 Blum laser tool measurement Taper clear brushes Blum laser NT Hybrid Round pallet Storage (RPS 5) Measuring probe Heidenhain TS 640 Production package Internal cooling supply 40 BAR Cooling: Cooling through the Spindle Center bar: 40 BAR Tank capacity: 980 High-pressure bar: 40 BAR Machine running times: Under power: 95.210 Operating Time: 44.971 Chsdswhdhzjpfx Al Asc Rated power kVA: 68 Basic machine dimensions / weight: Length mm: 5.866 Width mm: 4.196 Height mm: 2.547 Weight kg: 12.000.
