Used Jig Grinding Machine for sale (64,327)

Condition: refurbished (used), Year of construction: 2026, Karstens K11 650 The cylindrical grinding machine has been completely overhauled by PS-Karstens. Hedpsh Rixxofx Acrel The machine has been tested and is in very good condition. As specialists in Karstens cylindrical grinding machines, we can provide you with complete service (electrical and mechanical) for the machine after purchase. Technical Data: Centre distance: 650 mm Centre height: 180 mm Workpiece weight: 100 kg (between centers), 250 kg (supported) Grinding wheel diameter: 400 mm Workpiece spindle: Morse taper 4, infinitely variable speed 30–450 rpm, swiveling range 0–90° Tailstock: MT4, quill stroke 45 mm, micrometer adjustment Quill force: 200–600 N, hydraulically operated via foot pedal Table swiveling: 10 degrees Feed spindle adjustment range: 80 mm Rapid traverse: 50 mm Rough adjustment with air cushion: 280 mm External grinding spindle motor: 4 kW Internal grinding spindle motor: 2.2 kW Workpiece spindle motor: 0.55 kW Machine weight: net 3,800 kg Feed drive by DC motor Air-cushion-assisted rapid adjustment of the grinding spindle stock for fast and precise positioning of the grinding position. Separate drives for external and internal grinding spindles. Fully automatic operating sequence, feed movement controlled via cam switch: Rapid approach, rapid return, grinding mode, feed stop, micron feed. Automatic longitudinal grinding cycle Central coolant supply for all grinding positions Workpiece spindle head with infinitely variable drive for live and locked spindle operation. Feed control for both plunge and traverse grinding, input for retraction, feed amount, feed rates, dwell times, and idle strokes Paper band filter system approx. 250 L Comparable to Weiss/EMAG/GP cylindrical grinding machines/Studer/Kellenberger/Schaudt/Tschudin/Tacchella/Dannobat /Bahmüller/Fortuna

Condition: as good as new (ex-display), Year of construction: 2026, Karstens K11 1000 Premium Retrofit Cylindrical Grinding Machine Manufacturer: Karstens Hedeh Rimmjpfx Acrel Technical Data: Centre distance: 1100 mm Centre height: 180 mm / (250 mm optional) Workpiece weight: 100 kg between centres, 300 kg with support Grinding wheel diameter: 400 mm or 500 mm (external grinding wheel) Workpiece spindle: MT 4, infinitely variable speed from 30-450 rpm, swivel range 0 - 90° Tailstock: MT4, quill stroke 45 mm Quill force: 200-600 N manual, (up to 2500 N adjustable = optional) Table swivel: 10 degrees Infeed spindle travel: 80 mm Rapid traverse: 50 mm Coarse adjustment with air cushion: 280 mm External grinding spindle motor: 4 kW / (5.5 kW = option) Infinitely variable speed adjustment of grinding wheel via potentiometer Internal grinding spindle motor: 2.2 kW Workpiece spindle motor: 1.1 kW Hydraulic motor: 1.5 kW Lubrication motor: 0.1 kW Hydraulic tank: 80 litres Net machine weight: 3800 kg Infeed drive via DC motor Air cushion-supported rapid adjustable grinding spindle stock for fast and safe positioning to grinding location. Separate drive for spindles for external and internal grinding. Fully automatic operating sequence, infeed movement via rotary dial switch: Rapid approach, rapid return, grinding operation, infeed stop, mym-infeed. Automatic longitudinal grinding cycle Central coolant supply for all grinding zones Workpiece headstock with infinitely variable drive for both live and lockable spindle operation. New digital infeed control with Siemens panel and Siemens PLC for longitudinal grinding and plunge grinding, inputs for retraction, infeed amounts, feed rates, spark-out times, dwell strokes; compatible with the old Karstens infeed control; with colour Siemens touch panel. Similar to Weiss/ EMAG/ GP cylindrical grinders/ Studer/ Kellenberger/ Schaudt/ Tschudin/ Tacchella/ Dannobat/ Bahmüller / Fortuna

Condition: as good as new (ex-display), Year of construction: 2026, Centre height: 181 mm Centre distance: 1000 mm Maximum grindable workpiece diameter: 360 mm Max load cantilevered: 1000 N (100 kg) Max load between centres: 3000 N (300 kg) Z-axis: Table swivel angle: 10° Table drive, hydraulic: 0–4 m/min X-axis: Cross slide travel: 80 mm Rapid traverse (hydraulic): 50 mm Coarse adjustment – air cushion: 280 mm Infeed drive by DC motor Rapid infeed speed: 48 mm/min/Ø Infeed cycle: Plunge grinding / Longitudinal grinding 4 preselectable speeds: mm/min/Ø: 0.01–48 4 preselectable infeed increments: mm: 0.001–0.1 Automatic shut-off during stop-grinding: 0–99 s or 0–99 strokes Stepwise infeed: mm/Ø: 0.001 Grinding headstock universal, swivelling: 0–180° Grinding wheel (OD): D x width x bore: 500 x 100 x 127 mm or 203.2 mm Grinding wheel (face, option) D: 250 x 32 x 76.2 mm Hodpfx Acjtqf Rzsrjl Grinding wheel (ID, option) D: 2–250 mm Drive power, external/face: 5.5 (7.5) kW Drive power, internal: 2.2 kW Peripheral speed, external: 35 (50) m/s Grinding wheel wear (OD): mm/Ø: 160 Guard width: 100 mm Grinding spindle diameter: 60 mm Internal spindle mounting: 80 (100) mm Workpiece headstock: Infinitely variable drive: MK 4, 1/min: 30–270 / 50–450 Workpiece spindle lockable Spindle mounting: MK 4/24 mm Spindle nose for flange attachment: MK 4, cylindrical Ø63H6 x 6 mm Headstock swivels on rotating part: 0–90° Tailstock: Quill mounting / Quill diameter: MK 4, 750 mm Quill stroke: 45 mm Quill force, N: 100–800 / 250–1400 adjustable Quill operation: manual (foot switch) Quill fine adjustment: ±40 μm Connections: Total machine connected load: 6.5–10 kW Grinding headstock: 5.5 (7.5) kW Workpiece headstock: 0.55 (1.1) kW Coolant filtration: 0.75–2.2 kW Lubrication pump – guideways: 0.1 kW Hydraulic pump: 1.5 kW Hydraulic tank: 80 l Pneumatics: 6 bar Comparable to: Weiss / EMAG / GP cylindrical grinders / Studer / Kellenberger / Schaudt / Tschudin / Tacchella / Dannobat

Year of construction: 1989, condition: ready for operation (used), Center height: 150mm, center distance: 800mm, max. grinding length: 400mm, table dimensions X/Y: 1245mm/200mm, grinding spindle diameter: 80mm, grinding spindle length: 400mm, workpiece carrier: ISO50, spindle speed: 8000rpm. Documentation available. An on-site inspection is possible. Hedpfjy D Tp Tjx Acrol

Year of construction: 2021, condition: ready for operation (used), A Timesavers (Grindingmaster) wide belt grinding machine with two upper wide belt grinding units and one brushing unit is available. Contact roller diameter: 180mm/280mm, grinding belt accuracy: 0.01mm, brushing unit outer diameter: 300mm, brush oscillation: 150strokes/min, brush motor speed range: 8m-22m/s, table height adjustment: 1mm-100mm, grinding belt dimensions X/Y: 1630mm/2620mm. Machine dimensions X/Y/Z: approx. 4300mm/2650mm/2650mm, weight: approx. 5500kg, control: Siemens PLC. Including one IEP nanofilter cartridge extraction system. Documentation vorhanden. An on-site inspection is possible. Hjdpfx Acsy D Tq Rorsl

Condition: used, functionality: fully functional, Due to relocation, we are selling our surface grinding machine. The machine can be collected from our site in Königsbach-Stein. Hsdpfxoy Etbfe Acrjl

Condition: used, functionality: fully functional, Due to relocation, we are selling our cylindrical grinding machine. Quality that lasts a lifetime! The machine can be picked up on site at our location in Königsbach-Stein. Hedpfjy Etazsx Acrsl

Condition: used, functionality: fully functional, Due to relocation, we are selling our bench grinder with stand from Safag. The machine can be collected on-site at our plant in Königsbach-Stein. Hsdpjy Etauefx Acrjl

Condition: used, functionality: fully functional, Due to relocation, we are selling our fully functional grinding machine. The machine can be collected on site at our facility in Königsbach-Stein. Hjdpfx Aoy Er U Rscrjl

Condition: ready for operation (used), Year of construction: 1991, grinding length: 1,000 mm, grinding width: 500 mm, travels 1000X550X550MM electromagnetic chuck 1000X500MM grinding wheel 400X80X127MM Hjdpeypv Rpsfx Acrjl Heidenhain digital readout - Z axis weight 5000KG

Condition: good (used), Year of construction: 1991, functionality: fully functional, machine/vehicle number: C4655, grinding length: 5,000 mm, grinding width: 500 mm, Sanding length: 5000 mm Sanding width: 500 mm Workpiece height: 250 mm spindle diameter in front bearing: 190.5 mm pivotable 0.7° Max. Torque: 1771 Nm Max. speed: 593 min/-1 Feed: infinitely variable 20-35,000 mm/min Trapezoidal segment head diameter 800 mm with Trapezsegmenten: 94/103x38x200mm Marposs measuring device Hydraulic upper part clamping and swiveling Sanding mist extraction system: Hydrocyclone cleaning system Machine weight approx. 27.6 tons Space requirement approx.: 11.2 x 4.3 x 3 m Hsdjq U Ihvspfx Acrsl

Condition: used, Year of construction: 1991, functionality: fully functional, machine/vehicle number: C4656, grinding length: 4,100 mm, grinding width: 200 mm, Reform AR41 Type 7 C4656/91 Year of manufacture: 1991 Grinding length: 4100mm Grinding width: 200mm Workpiece height: 190mm Table clamping area: 4169x202mm Segment head diameter: 250mm Spindle diameter in the front. Bearing: 45mm Swivelling: 2° Max. torque: 2x45.8Nm 2x grinding motor 7.5kW Feed: 2000-35000 mm/min Max. speed: 1460 min/-1 Total power requirement: 30 kW Heidenhain digital display Additional grinding device ZS 7.5kW Swivelling clamping table via swivel gear Paper belt filter cleaning including pumps Central lubrication system Machine weight approx. 8.2t Space requirement approx. 9.5x2.6x2m Hedpfx Ajtqtppscrol

Condition: used, Year of construction: 1990, functionality: fully functional, machine/vehicle number: C4652, grinding length: 5,100 mm, grinding width: 250 mm, overall weight: 9,100 kg, space requirement height: 2,300 mm, space requirement length: 9,000 mm, space requirement width: 4,000 mm, Reform AR 51 Type 7 Surface grinding machine Year of manufacture: 1990 Grinding length: 5100mm Grinding width: 250mm Workpiece height: 220mm Total power requirement: 36kW Used water system Lifting station, magnetic roller, pump Hjdpfxjtqtk Aj Acrol

Condition: ready for operation (used), Grinding rotary table machine SIELEMANN RF-PE with digital control. Hedpfjyzymmjx Acrol

Condition: new, Year of construction: 2025, 0600 mm Hedpfx Acswp Tmvsrjl 300 mm 342 mm 700x340 mm 355x38x127 mm

Condition: excellent (used), Year of construction: 1962, machine/vehicle number: 12.178, 🛠️ WALDRICH SIEGEN WS IIa 100/25 x 5000 CNC roll grinding machine – The perfect base for a retrofit! Hsdpfx Acefbb D Dersl Get your hands on a high-quality roll grinding machine from WALDRICH SIEGEN – renowned for its exceptional stability and precision in heavy-duty applications. The machine was converted to CNC by Herkules in 1996 and is in excellent mechanical condition. ⚠️ Important – but your opportunity! The machine is currently not operational as the electrical equipment and CNC control system need to be replaced. 👉 Your advantage: Take advantage of this opportunity for a bespoke retrofit and get state-of-the-art technology at a fraction of the cost of a new machine. 💰 📊 Technical highlights 🔩 Grinding diameter up to 1,200 mm 📏 Length up to 5,000 mm ⚖️ Workpieces up to 25 tonnes ⚙️ Grinding wheel up to 900 mm Ø 🚀 Drive power up to 97.5 kW 🎯 Precision up to 0.001 mm 🧰 Features 🔄 Cylindrical & crown grinding 🖥️ CNC grinding support 🔁 Automatic feed with wear compensation 🎨 Partially modernised & repainted 💡 Why this machine? ✅ Solid industrial quality ✅ Perfect for modernisation / retrofitting ✅ Ideal for large roller machining ✅ Significantly cheaper than comparable new machines 👀 Viewing available at any time! Flexible appointment available 📅

Condition: used, Year of construction: 2012, grinding diameter max. 320 mm grinding length 1.500 mm centre height 160 mm Control Touch Jones & Shipman between centers max. 100 kg Traverse Z-Axis 1.645 mm traversing speed m/min swivable +5 / -5 ° Hodpfx Acetqmrporsl Traverse X-Axis 260 mm traversing speed - 6 m/min grinding wheel motor 7,5 kW cutting speed 45 m/s Grinding wheel Ø x width x bore 450 x 50 x 203,2 mm Swivel range -15 / +90 ° turning speed range 0 - 660 U/min Torque 27 Nm tool adaptor MK 3 weight of the machine ca. 8,5 t dimensions of the machine ca. 5,5 x 2,5 x 2,0 m Cylindrical Grinding Machine JONES & SHIPMAN - Suprema Easy 1500 E - Replacement grinding wheel flange - Multi-grain diamond (for circumferential and lateral dressing, 10mm, 1 carat) - Tailstock with micro adjustment (max. adjustment range +-0.05mm) - Pneumatic quill retraction - Two-jaw bezel (range 8-75 mm)

Condition: good (used), functionality: fully functional, well-maintained tool grinder with accessories as shown in the pictures Hedpfxsy Hdm Ij Acrel

Condition: good (used), Year of construction: 1970, functionality: fully functional, Data : Tip width 300 mm Tip height 150 mm External grinding spindle 4.0 kW Grinding wheel max. 400 x 80 x 127 mm Spindle cone MK4 Hsdpfx Acsy Hdmzerjl Workpiece headstock 0.55 kW Workpiece speeds 30 - 450 rpm Internal grinding spindle 1.5 kW

Condition: excellent (used), functionality: fully functional, machine/vehicle number: 2219, center height: 260 mm, A very well-preserved external cylindrical grinding machine with internal grinding attachment Manufacturer: WMW Schleifmaschinenwerk GmbH Chemnitz Model: SA6/1Ux1000 Centre height: 260 mm Grinding length: 1000 mm Hedjy Hdqmjpfx Acrjl Machine number: 2219 Machine weight: 5900 kg Includes internal grinding attachment

Condition: new, Machine type: Trough vibrator TV45 Shown: TV45 including sound insulation and WS25 for component separation Manufacturer: Eurotec Innovation GmbH Rated speed: 1500 rpm Gross volume: 115 liters Inner length container: 850 mm Inner width container: 380 mm Inner height of the container: 395 mm Supply line: 400V - 16A - 50Hz APPLICATION AREAS: - Deburring, smoothing and polishing - Descaling, derusting and cleaning - Rounding edges - Finishing of surfaces BENEFITS: - Wiper edge to reduce component build-up on the inner wall of the container - Particularly economical, even if used only occasionally - Optionally available as a version for pressure deburring and ball polishing - Robust construction with a low-maintenance vibration motor - Integrated holder for lifting and moving the system using a lift truck or forklift truck - Quick emptying of the container and changing of abrasives thanks to a large drainage opening for abrasives Hjdpfx Acjf Sqdtjrsl - Quick-change drainage sieve made of polyurethane - Rubber-cushioned feet to reduce the transmission of vibrations The stated price is net plus 19% sales tax and plus freight. A suitable switchgear is required to operate the system. The pictures show the system including accessories, which are optionally available. The price refers to the basic machine (TV45) ----- Please just contact us, we will be happy to advise you without obligation. ----- The European Commission provides a platform for out-of-court online dispute resolution (OS platform). The offer serves exclusively as an internet presentation of our goods. The contract negotiation comes about by means of telecommunication (email, fax, telephone, news portal), where we first make you a non-binding offer, in which we inform you about our general terms and conditions and the right of withdrawal with imprint before the purchase / contract is concluded.

Condition: good (used), grinding diameter 450 mm Hodpfxoxcblqo Acrsl grinding length 600 mm centre height 140 mm workpiece dia. 280 mm number of turns of spindle head 63 - 400 U/min grinding wheel speeds 20-35 m/s dimensions of the machine ca. 2,4 x 1,9 x 2,1 m

Condition: good (used), Year of construction: 2012, machine/vehicle number: 22002549, Offer 26118 Technical Specifications: - Possible working range with options: 0.3 - 30 mm Hedjy Dfqispfx Acrsl - Max. disc diameter: 164 mm - Point angle steplessly adjustable: 118 - 150° - Surface speed at the disc: 29 m/s - Rotational speed: 2800 rpm - Drive: 230 V / 0.2 kW - Required space approx.: W 450 x H 300 x D 450 mm - Weight approx.: 30 kg - Clamping range: 3.0 - 12 mm - Clamping range: 12 - 21 mm - Grinding attachment for 3-flute countersinks - Cross table

Condition: used, Year of construction: 1995, functionality: fully functional, Drum Grinding and Polishing Unit Manufacturer: UHLIG, Type UB 22 Year: 1995 Technical Data: Make: Werner Uhlig Model: UB 22 Hodpfx Aoyw Rhmscrol Year of manufacture: 1995 Drive: Worm gear with motor Rotational speed: 5.6 – 54 l/min Shaft diameter: 25 mm, max. torque: 34 Nm Motor power: 0.25 kW Dimensions: approx. 1.00 x 0.90 x 1.20 m Weight: approx. kg (not specified) Equipment: - Control with frequency inverter - 2 single-chamber drums, approx. 200 mm wide, diameter 260 mm - Infinitely variable drum speed - Fresh water rubber hose - Waste water drain connection All details are subject to change without notice. A demonstration under power is possible at any time in our exhibition hall.

Condition: good (used), Year of construction: 1986, Inner diameter: 20…400 mm Grinding depth: 315 mm Internal grinding spindle speeds, stepless: 2,640…16,500 rpm Workpiece spindle speed: 40…400 rpm Hjdpfx Acsy Emu Eorol Table feed rate: 0.1…8 m/min Rapid traverse: 10 m/min Table travel: 630 mm Total power requirement: 16 kW Machine weight approx.: 5.8 t Additional information: Grindable diameter within workpiece guard: internal 20…400 mm; external 500 mm Max. workpiece diameter in workpiece guard: 500 mm Max. grinding depth: 315 mm Grindable taper angle: 60° Internal grinding spindle speeds: 2,640…16,500 rpm Drive power for face grinding attachment: 4 kW Drive power for workpiece motor: 1.5 kW Workpiece spindle speeds: 40…400 rpm Table speed: 0.1…8 m/min Rapid traverse: 10 m/min Table travel: 630 mm Max. distance from workpiece spindle flange to grinding spindle carrier: 1,250 mm
