Used Milling Machine Dialog for sale (65,136)

Condition: excellent (used), Year of construction: 1986, functionality: fully functional, Universal milling machine Deckel FP4M with 3-axis digital display Heidenhain ND780 in special light gray paint finish with CE approval!!! Technical data: >> Year of manufacture 1986, machine no. 2203-2471 >> Fixed angular table (newly planed) >> Speed: 50 - 2500 rpm Tjdpfx Aloz A S Rnj Aec >> Feed rate: 8 – 630 mm/min >> Drive power: 3.7 / 4.4 kW >> Spindle brake >> Rapid traverse rate 1300 mm/min >> Travel ranges X/Y/Z: 500/400/400 mm >> Vertical milling head on spindle support, adjustable by 150 mm >> Vertical quill and horizontal quill - SK40 >> Vertical quill extendable by 90 mm >> Clamping system M16 >> Weight approx. 1500 kg Accessories and equipment: >> 3-axis digital display Heidenhain ND780 >> Coolant system >> Chip tray >> Central lubrication About the machine: Offered is a Deckel FP4M universal milling machine with CE conformity in very good condition. The machine has been partially overhauled, has little backlash, and all spindles move easily and smoothly. Even at maximum speeds, the milling machine runs smoothly. Rapid traverse in all axes, the bellows are all new. The fixed angular table has been newly planed. A reliable and user-friendly machine. An oil change has been performed. Mechanically and electrically inspected. The digital display from Heidenhain makes working easier and even more precise. Take the opportunity to inspect and test the machine on-site while it is powered up.

Year of construction: 1972, condition: used, Controls: Heidenhain 2-axis digital readout, without clamping systems or tools, with large table, an on-site inspection is possible. Tedez Ea R Uopfx Al Aoc

Condition: used, Year of construction: 1988, Bed milling machine Manufacturer: Correa Type: A16 Tjdpfxezt U T Aj Al Aec Year of manufacture: 1988 Control system: HEIDENHAIN TNC415 Travel ranges X/Y/Z: 1,800 x 800 x 800 mm Clamping area: 2,000 x 630 mm Workpiece weight: 3,000 kg Operating hours: 12,103 Power: 19 kW Spindle type: ISO 50 Dimensions L/W/H: 4,886 × 2,720 × 2,500 mm Machine weight: 7,500 kg 28926

Condition: used, Year of construction: 1988, Bed milling machine Manufacturer: Correa Type: A10 Year of manufacture: 1988 Control: HEIDENHAIN TNC 355 Travel distances X/Y/Z: 1,300 x 630 x 630 mm Clamping area: 1,700 x 630 mm Workpiece weight: 3,000 kg Operating hours: 25,845 Power: 19 kW Spindle type: ISO 40 Dimensions L/W/H: 3,870 x 2,630 x 2,200 mm Tedpfszt U R Ijx Al Ajc Machine weight: 6,800 kg 28926

Condition: used, Technical details: x-travel: 700 mm y-travel: 450 mm z-travel: 450 mm control: Heidenhain TNC 121 spindle taper ISO: SK 40 quill stroke vertical: 120 mm spindle head swivable left - right: je 90° ° turning speed range: 40 - 1.600 U/min throat of the milling spindle: 200 mm table surface area: 1.050 x 627 mm table swivable approx.: +45/ -45 Grad table rotating: 360 Grad table movement - horizontal: 200 mm table feed: X/Z 5 - 5.000 mm/min table feed: Y 2,5 - 250 mm/min total power requirement: 8 kW weight approx.: 3,2 kg dimension machine approx.LxWxH: 2,3 x 2,0 x 1,850 m The MAHO MH 800 is a high-quality conventional universal tool milling machine designed for precise milling, drilling, and machining operations. It is ideally suited for toolmaking, mechanical engineering, fixture construction, as well as the production of individual components and small production batches. With Heidenhain 3-axis digital readout (DRO) Universal swivelling table Vertical milling head Tjdjzibabepfx Al Aoc *

Condition: good (used), Year of construction: 1991, travel distance X-axis: 560 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 400 mm, X-travel: 560 mm Y-travel: 500 mm Z-travel: 400 mm Todpjz Hbpnofx Al Aec Control: TNC 360 Spindle speed: 40-4,000 rpm Total power requirement: 7.5 kW Machine weight approx.: 2.6 t Space requirement approx.: 2.6 x 1.8 x 2.2 m

Condition: new, Centauro ALFA NC Machining Centre For Joinery Components & Doors A versatile and flexible NC controlled machining centre suitable for a variety of machining operations including hinge recessing, lock slots, handle holes, key slots and euro grooves etc. Programming is extremely simple thanks to the colour graphic touch screen controller using pre-installed electronic macros. As standard the machine can be equipped with one milling head that automatically moves for either vertical or horizontal machining. It also has interpolation of the axis. Optional additional machining operations include producing a square corner hinge plate recess or lock face recess by means of the additional milling unit. The operator simply selects in the program if they want a radius or square corner and the machine does the rest. In addition the same milling head can be used to make the small pilot hole for hinge screws etc. There is also the possibility to produce a square end tenon, round end tenon or dovetail / dovetail slot when the special front table is fitted. Lastly on request the machine can be configured to import ISO files from external design software (e.g ARTCAM Express) to enable detailed engraving of items such as name plates etc. Axis capacity - X 2800mm, Y 180mm, Z 150mm. (2400mm X capacity when optional drilling head fitted). 1 x ER32 collet for milling cutter 16mm max. dia. Max working table dimensions - 3000x618mm X axis positioning speed 35m/min. Y axis / Z axis positioning speed 6m/min. Retractable pneumatic positioning stops 2 off - on front of table Adjustable pneumatic workpiece clamps x 3 - mounted on rear of table. Left hand side ref. stop. Todpeb Tmngsfx Al Asc Front table extension supports x 2 Router motor power 3.3kw. Router motor RPM 0-18,000 rpm. Touch screen controller - Elco Power 1000. Dust extraction outlet x 1 80mm dia, 2 x 100mm dia CE side and rear safety guards with front light curtain.

Condition: excellent (used), fuel type: diesel, color: yellow, first registration: 01/2018, Year of construction: 2018, Drive: Track Unladen weight: 30,000 kg Technical condition: very good Visual condition: very good Price: On request Tsdeuxu Eqspfx Al Asc CATERPILLAR PM 622 ASPHALT MILLING MACHINE 4 x track drive Working width: 2235 mm Working depth: 0-330 mm 193 milling picks Hydraulically foldable discharge conveyor CAT Grade Control automatic levelling 2 x operator consoles with LC display Hydraulically liftable side plates Rear-view camera Weather protection roof, foldable Driver's seats Work lights Cleaning system CAT Diesel engine, C18 622 HP Original paint FOLLOW US ON INSTAGRAM: GEURTSTRUCKS WE SPEAK GERMAN WE SPEAK ENGLISH HABLAMOS ESPAÑOL

Condition: excellent (used), X-axis (Longitudinal): 400 mm Tedpfx Aoy Itr Nel Aoc Y-axis (Transverse): approx. 175 mm Z-axis (Vertical): 450 mm Table: 250 x 800 mm Spindle taper: ISO 30 Quill Digital display: Heidenhain 3-axis VRZ Accessories: Various holders Speeds: 50 to 3400 rpm Weight: approx. 900 kg

Condition: used, Year of construction: 1976, x-travel 1200 mm y-travel 400 mm z-travel 460 mm table-size 1500 x 400 mm control konventionell tool adaptor SK40 turning speed range 45 - 2000 U/min Todpfezip H Nox Al Ajc quill stroke ja mm weight of the machine ca. 3,2 t dimensions 2,8 x 2,5 x 2,1 m Equipment: - ELESTA digital display - Infinitely variable feed - Coolant system - Horizontal milling attachment - Chip guard - Chip trays - Hydraulic machine vice - Machine light - Documentation

Condition: used, Year of construction: 1990, functionality: unexamined, machine/vehicle number: HVM-7580, table width: 1,000 mm, table length: 3,300 mm, type of input current: three-phase, input voltage: 380 V, CNC bed milling machine Anayak HVM-3300 in a moving column design, manufactured in 1990. Identified as VHM-3300 on the housing. Serial No. HVM-7580, connection 3 x 380 V, 50 Hz, 60 A, 40 kW. Fixed T-slot table 3,300 x 1,000 mm. Duplomatic Tracemaster SERF 2000 control system with CNC operating unit and screen, switchable between CNC and copying mode. Tjdpfxoz A Uigj Al Asc Milling head with vertical spindle and position indicator on the control panel, hydraulic unit with hydraulic tool clamping, central lubrication, telescopic covers, protective housing with sliding doors. Location: Homburg (Saar), Germany. Inspection by appointment only. Price on request, net plus VAT, ex works; dismantling and loading by agreement. All information without guarantee.

Condition: used, x-travel 315 mm y-travel 180 mm z-travel 320 mm 5 14 mm ISO 40 DIN 2079 45 - 1950 U/min flute distance 10 - 170 mm/min no. of flutes 4 m/min total power requirement 5,1 kW distance between table/spindle 1400 kg diameter of rotary table 3000 x 2700 x 1800 mm - Robust/powerful universal milling machine - HEIDENHAIN digital display Tjdsxwdvhspfx Al Aoc - Coolant device

Condition: used, Year of construction: 2001, total height: 2,620 mm, total length: 4,300 mm, total width: 2,350 mm, Colour: Grey Empty weight: 5.500 kg Price: On request - Year: 2001 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 7049-H00-KT1013 - Drive system: CNC - Horizontal/vertical: vertical - Control system brand: Heidenhain - Number of axes [pcs]: 4 - X-axis travel [mm]: 1020 - Y-axis travel [mm]: 510 - Z-axis travel [mm]: 560 - Table length [mm]: 1120 - Table width [mm]: 600 - Min. spindle speed [rpm]: 60 - Max. spindle speed [rpm]: 6000 - Options: Chip conveyor, External cooling, Tool magazine - └ Tool magazine [pcs.]: 21 Todjzl Dy Aopfx Al Asc - Transport dimensions: 4300mm x 2350mm x 2620mm (l x w x h) - Transport weight [kg]: 5500kg - Transport packages [pcs.]: 2 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: excellent (used), Year of construction: 2011, Vertical milling head with quill Horizontal spindle Sturdy cast iron frame with flat guides in all axes (hardened) Ball screw spindles Automatic axis clamping Hydraulic tool clamping Automatic gear shifting Collision protection coupling, Z-axis Distance-coded linear scale measuring systems Mechanical handwheels Automatic central lubrication Chip collection tray Coolant system, free-standing, 70 liters Machine light Leveling elements Chip splash guard Control system: Heidenhain TNC 124 Travel ranges X / Y / Z: 400 / 350 / 400 mm Feed rate X / Y / Z: 0 - 2000 mm/min Rapid traverse X / Y / Z: 5,000 / 5,000 / 4,000 mm/min Table size W x D: 650 x 350 mm Spindle speed: 1 - 4000 rpm Tool holder: ISO 40 / DIN 69871 Weight: approx. 2050 kg Tsdpfszlak Rox Al Asc Dimensions W x D x H: approx. 1916 x 1868 x 2220 mm Accessories: various tool holders

Condition: used, Year of construction: 2002, machine/vehicle number: 6243, travel distance X-axis: 5,000 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 1,500 mm, Equipment: documentation/manual, Base machine / Travel ranges: X-axis machine stand 5,000 mm, Y-axis spindle head slide 2,100 mm, Z-axis spindle head 1,500 mm. Machine stand: Compact, torsion-resistant welded construction with hardened flat guide rails and telescopic steel covers against chips and coolant. Spindle head slide: Cast iron design with hydraulic weight compensation, guided via combined roller/sliding guides. Machine bed: Flat bed design with approximately 1,200 mm guide rail width and roller compact guides for high precision. Automatic universal milling head: CNC-swiveling milling head mounting 340 x 1°, Hirth gearing approximately 125 kN; milling head 180 x 1°, approximately 100 kN; milling spindle with hydromechanical tool quick-change system, clamping force approximately 25 kN; tool mounting SK 50, DIN 69871. Main drive: 37 kW at 100% ED, 53 kW at 40% ED; externally ventilated AC motor, 2-stage gearbox with automatic shifting; speed 22–4,000 1/min. Feed drives: Digital AC single drives; X/Y: 2–12,000 mm/min, Z: 2–15,000 mm/min. Control / Measuring systems: Tjdpfx Aljz Dvyco Aoc Central operation via Heidenhain TNC 430 M. Direct, non-contact linear measuring systems. Electrical system: EN 60204 / VBG 4, 400/230 V ±10%, 3 phases, 50 Hz, 24 V control voltage; connected load approximately 80 kVA. Control cabinet IP54, main motor IP55. Lubrication: Main gearbox/milling head drive oil circulation lubrication; main spindle grease long-life lubrication; guides/ball screws pulse central lubrication. Coolant: Internal/external coolant supply with paper band filter. Max. 50 l/min at 10 bar or 47 l/min at 16 bar; tank 500 l. Coolant/air switching. Oil cooler for temperature stabilization and increased manufacturing accuracy. Leveling system: Electromechanical via 2 vertical ball screws with separate drives, measuring systems and CNC axes. Work platform: Moving in the X-direction, with CNC control panel; electrically secured door with viewing window. Pick-up station: 10 tools; max. tool weight 25 kg, length 400 mm, Ø 125 mm, with free neighboring spaces Ø 250 mm. Clamping plate: 3,500 x 3,000 mm; T-slots 22 H12 DIN 650, spacing 250 mm; clamping surface accuracy grade 1 DIN 876. CNC rotary table: Clamping surface 1,250 x 1,600 mm / Ø 1,800 mm; Hirth division 360 x 1°; 6 longitudinal slots 22 H12, 2 guide slots 22 H7; T-slot spacing 160 mm; centering sleeve Ø100 H7 x 20 mm; max. 5 1/min; tilting moment 85,000 Nm; tangential moment 120,000 Nm; table load max. 11,500 kg. Additional equipment: Oriented spindle holder 360 x 1°; hinged band chip conveyor for X = 5,000 mm, feed width approximately 350 mm, discharge height approximately 1,250 mm; 3D wireless measuring probe; electronic handwheel HR 410 for 3 axes; pendulum machining for 2 work areas with monitored safety zones; manually movable splash guard. Collision monitoring: Brankamp CMS with piezoelectric strain gauge; if the process limit is exceeded, the axes are braked and the machine is switched off. Paint finish: Machine/control cabinet RAL 7035, milling head/spindle head RAL 5021; DD structural paint, semi-gloss, oil- and alkali-resistant. Power connection: 400 V, 3 phases, 50 Hz, 80 kVA, 160 A slow-blow; compressed air 4–6 bar, connection G 1/4. CE-relevant environmental protection to be provided on site; adapter plates for chip/coolant return are not included. Coordinate data: Y 730.0124. Documentation: Operating manual SHW-UF6L and Heidenhain TNC 430.

Condition: used, Year of construction: 2002, x-travel 400 mm y-travel 320 mm z-travel 440 mm table-size 80 x 325 mm spindle taper ISO Sk 40 spindle turning speed range 63 - 3150 U/min quill stroke 60 mm weight of the machine ca. 1,5 t dimensions 1,8 x 1,8 x 1,9 m Universal Milling Machine Tjdpfx Asw Tdxisl Ajc - Digital Display - Hydraulic Tool Clamp - Central Lubrication - Coolant System - Machine Light - Machine Feet - Counter Bearing - Chip Tray

Condition: refurbished (used), functionality: fully functional, 1. Machine specifications: * Work table - Clamping surface 375 x 1600 mm - Number of clamping slots 4 - Table load 1000 kg * Adjustable travel ranges, machine-controlled - Table longitudinal movement (x) 1000 mm - Cross slide transverse movement (y) 270 mm - Overarm vertical movement (z) 505 mm * Milling spindle - Drive power 7.5 kW - Max. torque 1850 Nm - Tool holder, steep taper ISO 50 - Diameter in front bearing 100 mm - Max. milling head diameter 250 mm - Quill adjustment 90 mm - Swivel range, on both sides 45 degrees * Speeds - Number 18 - Step ratio 1.25 - Range 45 ... 2240 min-1 * Feed rate Tjdpfx Asz H Tuvsl Ajc - Number of feeds 18 - Step ratio 1.25 - Range, longitudinal and transverse 16 – 800 mm/min - Range, vertical 5 - 250 mm/min - Drive power 1.5 kW - Rapid traverse, longitudinal and transverse 3150 mm/min - Rapid traverse, vertical 1000 mm/min * Coolant system - Flow rate 10 l/min - Capacity 45 l * Connected load 8 kW * Machine weight (net) 3150 kg * Space requirement 2800 x 2420 x 2635 mm * Last inspection 03/2026 2. Technical condition The machine was only used in production until February 2011!!! Due to the overhaul, the machine meets the acceptance conditions for new machines. All guideways have been re-scraped, the gearbox has been overhauled, and the feed and rapid traverse couplings have been replaced. The milling spindle has been overhauled, and a new paint job has been applied. 3. Warranty: 3 months 4. Price: 19,000.00 € 5. Delivery terms: * Pricing: Prices are quoted net for delivery of the machine ex works, excluding VAT. We reserve the right to sell the machine in the interim. * Payment terms: 30% down payment upon order 70% upon delivery * Delivery date: ex warehouse

Condition: used, Year of construction: 2000, Used bed-type milling machine from Wagner Tedjy Atypepfx Al Aec Model: SMB 2000 Heidenhain TNC 426 CNC control Including various tool holders (excluding tools) SK 50 spindle taper Swivelling milling head

Condition: like new (used), Year of construction: 2003, Retrofitted: 2026 Numerical control: HEIDENHAIN TNC-530 Tjdpfxey Nfz Ej Al Asc Technical features Dimensions Table dimensions: 20000 x 2500 mmNumber of T slots: 10T slots dimensions: 22 mm Traverses of axis X axis traverse: 20000 mmY axis traverse: 3800 mmZ axis traverse: 1250 mmVertical capacity: 100 / 1350 mmDistance between columns: 3200 mm Milling head Head type: Auto-indexing BC universal UAD milling head (0,1º)Tool clamping system: HydraulicTaper nose: ISO 50 (DIN 69871)   /   Pull stud: DIN 69872Speed range: 6000 rpmSpindle power: 27 kW Feedrates Rapid feedrates (X / Y,Z): 15000 / 12000 mm/min Weight and dimensions Maximum weight on table: 15000 kgMachine weight approximate: 150000 kgMachine dimensions approximate: 30190 x 8865 x 6200 mm Accessories Guarding: Door with platform access and new perimetral wire-mesh fenceAutomatic tool changer:ATC-120Chip conveyor:2 longitudinal hinge typeControl panel: 2 switched panels on each side of the tableElectronic handwheel: HR-510Coolant: External and internal high pressure through spindle Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features

Condition: ready for operation (used), Year of construction: 1998, Available immediately from our location: Console milling machine REFORM Type UF 32 Tjdpfx Aloz Huyyo Aec Year of manufacture 1998 Table 1400 x 300 mm Travel ranges X/Y/Z 1100/300/520 mm SK 50 Spindle speeds 31.5 - 1400 rpm Drive power 7.5 kW Digital display Hydraulic vise Weight 2.7 tons Many tools and milling cutters included Price: Euro 2,750.00 + VAT, ex works

Condition: ready for operation (used), Year of construction: 2010, x-travel 280 / 300 mm y-travel 250 / 270 mm z-travel 300 / 310 mm turning speeds 45 - 2240 U/min turning speeds 18 Stufen spindle taper ISO 40 quill stroke 60.0 mm table: 670 x 320 mm table load 150 kg feed range 12.5 - 630 mm/min feed 18 Stufen rapid traverse 1.200 mm/min workpiece weight max. 150 kg T-slots 5x 12 x 63 mm total power requirement 1.6 kW weight of the machine ca. 1100 kg range L-W-H 1265 x 1080 x 1620 mm New price ~ 25.000 Euro (!!) Special price upon request - in checked conditions - machinevideo - ?v=7IsC5cg9WlI Features: - Robust electric-driven universal milling machine - ACURITE 3-axis digital display * with pivoting control panel, front right * including emergency stop button - Electric adjustment of all axes (X/Y/Z axes) * Rapid traverse in all 3 directions - Pivoting milling spindle guard - Coolant system - Lower chip tray Todpfx Ajxabqnol Asc - Vertical milling head with quill adjustment * Milling head rotation 90° * Tool holder ISO / DIN 40 / 2080 - Fixed angle table 670 x 320 mm * T-slot width x spacing 12 x 60 mm * Minimum distance between base table and spindle axis - 4 machine feet - Electrical diagram

Condition: used, Year of construction: 1977, Technical details: x-travel: 450 mm y-travel: 200 mm z-travel: 400 mm spindle taper ISO: SK 30 distance table/horizontal spindle: max. 400 mm cross rail adjustment - horizontal: 400 (manuell) mm range of revolution per miute: horizontal: 30 - 1275 / 18 step U/min spindle taper: horiz.+vertikal: SK30 Tedpfx Aovc Awfsl Aoc distance between table/spindle: vertikal: max. 430 mm quill travel: 60 mm swival range +/-: 90° Grad range of revolution per miute: Vertikalspindel: 50 - 215 / 18 step U/min clamping surface area: 860 x 240 mm table swivable approx.: 45° feed:: 0 - 1.000 / steples mm/min rapid traverse: 2.000 mm/min. total power requirement: 6,0 kW machine weight approx.: 3100 kg dimension machine xH: 1,6 x 1,6 x 1,9 m Coolant device 3-way DRO Heidenhain control panel Optional accessories *

Condition: ready for operation (used), Type RU 991 Longitudinal stroke 4500 mm Transverse stroke 1000 mm Vertical stroke 1000 mm Table dimension 6155x1000 mm Todpfevn Tc Ajx Al Ajc Spindle speed 15 - 1500 rpm (RPM) Dimensions 6400 x 2400 x 2600 Weight 18T

Condition: used, Year of construction: 1997, Maho milling machine MH 600 E with numerous accessories, in perfect working order. Todsz Affhopfx Al Aec

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 52335, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, table load: 6,000 kg, controller model: Heidenhain TNC 155, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 3,000 mm Tjdpfx Aozz Rmnsl Ajc Travel range, Y-axis: 1,000 mm Travel range, Z-axis: 1,000 mm Table load capacity: 6 t MACHINE DETAILS Control system: Heidenhain TNC 155 Apparent power: 45 kVA Phases: 3 Voltage: 380 V Frequency: 50 Hz Current: 85 A EQUIPMENT Manual swivel head, 0.1°
