Used Test Daylight Press for sale (21,040)

Condition: good (used), Year of construction: 2008, pressing force: 300 t, control type: CNC control, actuation type: hydraulic, CNC crowning Hydraulic tool clamping EFL Easy Form laser measuring & correction system Set tooling Laser guide protection Controlled axis Y1/Y2/X/R/V-Axis Max. bending length: 4000mm Distance between supports: 3150mm Max. pressing force: 320T Distance table mount: 570mm Max. stroke: 300mm Table width: 200mm Support throat: 400mm Descent speed: 120mm/min Working speed: 14mm/min Return speed: 130mm/min Pgodpfswrza Aox Ap Del X-axis range: 1000mm Control: CADMAN Power: 42kW Length: 5800mm Width: 2300mm Height: 3800mm Weight: 23000kg

Condition: good (used), Manufacturer: WMW Zeulenroda Type: PYE 160 SS Year of manufacture: 1980 C-frame construction Die height 850 mm Thickness bolster plate 100 mm Throat C side 360 mm Specifications Metric US Standard Capacity 160,000 Table length 1,250 mm Table width 600 mm Ram stroke 500 mm Starting speed 100 mm/min Working speed 10 mm/min Return speed 125 mm/min Power 22.5 kW Dimensions (Estimate) Length: 2,150 mm Pgodpfxewp Nv Ho Ap Dol Width: 1,250 mm Height: 3,600 mm Weight: 7,500 kg Please note: The information on this page has been provided to the best of our knowledge and, where possible, from the manufacturer. The information is given in good faith, but accuracy cannot be guaranteed. Accordingly, they do not represent a warranty or contract terms. We recommend you check all important details.

Condition: good (used), Make: Ursviken Type: VPF 1000/800-5,0 Control: Siemens Simatic panel Year: 1970 Hydraulic press for fabrication off large componts like dish heads tanks boiler shipyard and steelconstruction Renewed in 2015 with Siemens SIMATIC panel and E-Cabinet Rittal Build in height 2950 mm Maximum die height 1500 mm Movable Table & Piston in X-Ways Large package Die tooling radius 10/20/30/50/60/80/100 Pressing force 210 kg/cm2 Maximum stroke 800 mm Machine 2350 mm placed in ground Specifications Metric US Standard Capacity Kg 1000 Ton Distance between column 5010 mm Table Length 3000 mm Table Width 2000 mm Table Height 550 mm Ram stroke 1450 mm Approche speed 50 mm/min. Pgodpfxskvmi Ss Ap Dol Working speed 5 mm/min. Return speed 50 mm/min. Dimensions (Estimate) Length 0 mm Width 0 mm Height 0 mm Weight 0 kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), Hydraulic press TCS - 150T MACH-ID 8821 Manufacturer: TCS Type: 150T Control system: Siemens SIMATIC OP7 Year of manufacture: 1999 Table load sliding table 20000 Kg Table load upper table 9000 kg Table out feed stroke 2100 mm Column diamater 180 mm Closing force 1500 Kn Opening force 700 Kn Laser safe CE Safety Power 15 kW Specifications Metric US Standard Distance between uprights 2000 mm Installation height 2000 mm Table length 1500 x 2000 mm ram stroke 1800 mm Starting speed 50 mm/min. Working speed 8 mm/min. Pedpfx Apoulwzmj Dsgl Return speed 50 mm/min. Table rotation 0 - 270 rpm Table rotation 0 - 180 ° Dimensions (estimation) length 4800 mm width 5600 mm height 5200 mm Please note: The information on this page is given in good faith and to the best of our knowledge, and where possible, has been obtained from the manufacturer, but accuracy cannot be guaranteed. Accordingly, it does not constitute a representation or contract and we recommend that you check all relevant details.

Condition: excellent (used), Year of construction: 2024, Minimum width 65 mm Maximium width 185 mm Load is 200 Metric Ton / Meter Operation angle from 60 - 180 Gr Die length 1000 mm and 500 mm sections Minimale Breite: 65 mm Maximale Breite: 185 mm Belastung: 200 metrische Tonnen / Meter Arbeitswinkel: 60°–180° Matrizenlänge: 1000 mm und 500 mm Segmente Länge: 1200 mm Breite: 1200 mm Höhe: 800 mm Gewicht: 1500 kg Pjdox Sw Suspfx Ap Dogl Length:1200mm Width:1200mm Height:800mm Weight:1500kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: like new (used), Year of construction: 2016, functionality: fully functional, operating hours: 100 h, stroke length: 800 mm, operating speed: 9 mm/s, controller manufacturer: CADMAN TOUCH, working width: 12,000 mm, bending force (max.): 1,600 t, back gauge: 1,000 mm, distance between stands: 10,600 mm, control type: CNC control, number of axes: 15, Only 100 Working (table/guiders/tooling still in prohibitor) Installed never used in production only testing CNC T1 + T2 + T3 Bending help support arm in front 3 x HH 2600 Module backgauge 3 x Z1+R1+Delta1 Lower Tooling set Variable VLA 50-150 mm Upper Tooling set LVD 505; Adjustment V-Axis 59,3 to 249,3 mm Thermotec Oil chiller GC25T-35 max. 2200 kPa CADMAN TOUCH with the best software for pressbrakes Hydraulic top tool clamping Table width 500 mm Troath in column 1000 mm Max. bending length: 12000mm Distance between column: 10600mm Max. pressing force: 1600T Dis. Beam - Table: 1070mm Beam stroke: 800mm Table Width: 500mm Troth beam: 1000mm Approch speed: 80mm/min. Working speed: 9mm/min. Return speed: 90mm/min. Adjustment X-Axis back gauge:600mm Number of controlled axis: 15 (Y1/Y2/X/Z1/2/3, R1/2/3, Delta 1/2/3, T1/2/3 Control: CADMAN TOUCH Crowning: Yes Hydraulic toolclamping: Yes Power: 125kW Length: 14875mm Width: 5430mm Height: 7906mm Weight: 277500kg Why you need 1600 Ton Pressbrake, Bending force depends on: Material thickness Material strength Bend length Die opening When any of those go big, tonnage skyrockets. A 1600-ton press brake is used when: Plate is thick (20–60+ mm / ¾"–2½"+) Material is high-strength Parts are long (6–10+ meters / 20–30+ ft) Tight radii or deep bends are required Forming Heavy Welded structures like: Bridge girders Box columns Large beams and stiffeners Base frames for industrial machinery Shipbuilding Defence & Naval like: Hull sections Deck plates Bulkheads Reinforcement ribs Enegery & Infrastructure like: Wind tower sections Power plant components Pressure vessel shells (pre-forming) Transformer tanks Heavy Machining & Ground & Mining jobs like: Excavator frames Crusher housings Dump truck bodies Mining chute liners Furnace housings Kilns Massive welded assemblies Material to bend on 1600 t machine: Carbon steel: S235 / S275 / S355 A36, A572 Plate thickness: ~20–50 mm+ High strength steel Psdpfeygkuwsx Ap Dogl S690 / S700 Hardox, Strenx Much higher tonnage needed even at thinner gauges Stainles steel: 304 / 316 Needs ~1.5–2× the force of mild steel Wear-resistant plate Heat-resistant steels JOB Example: Bending 40 mm S355 steel over 8 meters can easily require 1,200–1,600 tons, depending on tooling. Bending instead of welding: Increases strength Reduces distortion Cuts weld time and cost Improves fatigue life Looks cleaner and more accurate A 1600-ton press brake is used when: The part is too thick Too strong Too long It’s not for sheet metal shops — it’s for heavy industry, shipyards, steel fabricators, and energy projects. Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Year of construction: 2024, condition: excellent (used), Segment radius top tooling for 1000 and 2000 Ton machine Full sets segmented on 835 mm and 10 sections to make 8000 mm Radius 30 / Radius 31 / Radius 32 / Radius 33 / Radius 35 Radius 36 / Radius 39 / Radius 40 / Radius 41 / Radius 42 Radius 43 / Radius 45 / Radius 47 / Radius 48 / Radius 50 Radius 51 /  Radius 53 / Radius 55 / Radius 57 / Radius 58 Radius 60 / Radius 62 /  Radius 70 / Radius 71 / Radius 73 / Radius 75 / Radius 80 Length:12000mm Width:2000mm Height:1000mm Psdpfx Aex Sxukep Dsgl Weight:15000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), Year of construction: 2002, Manufacturer: Millutensil Type: MIL 203 Control: Siemens SIMATIC OP7 Year of manufacture: 2002 Pressure 0 - 250 Bar T Size T-22 Opening force 35 Ton Closing force 150 Ton Distance between columns 2130 mm Table height above floor 770 mm Upper table rotation 180 degrees Specifications Metric US Standard Capacity 30000 Distance between the columns 2130 mm Table length 2000 mm Table width 1500 mm Table height 1500 mm Run-in speed 3900 - 4800 mm/min. Working speed 480 mm/min. Return speed 2100 - 3000 mm/min. Dimensions (approximate) Length 6150 mm Width 3500 mm Height 4800 mm Podpfx Aowpkv Iep Dogl Weight 28000 kg Please note: The information on this page has been obtained to the best of our knowledge and, where possible, from the manufacturer. The information is given in good faith, but accuracy cannot be guaranteed. Accordingly, they do not constitute representations or contractual conditions. We recommend that you verify all important details.

Condition: excellent (used), Year of construction: 1991, Distance between column:1870mm Pjdpfxowyuqkj Ap Dogl Hight under roof: 1400mm Table Length: 1600mm Length: 3400mm Width: 3400mm Height: 3500mm Weight: 19000kg

Condition: good (used), Year of construction: 2000, pressing force: 15 t, table width: 300 mm, table length: 400 mm, Hydraulic clutch CE-Safety 2e hand opperator system Adjustable stroke / ram  Full set books / drawing / CE-Mark Note in the Neck / Throath machine is repaired ! Only EUR 5500 Capacity Kg: 15000 Table Length: 400mm Table Width: 300mm Hole in table:150mm Working height:280mm Pgsdpfxjyc R Nms Ap Dol Throat: 2170mm Stroke: 50mm Ram adjustment:4 - 80mm Length: 1500mm Width: 1500mm Height: 2100mm Weight: 1200kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), Year of construction: 2000, Capacity Kg Pgedpfeyc R Uijx Ap Del 15000 Table Length 400 mm Table Width 300 mm Hole in table 150 mm Working height 280 mm Throat 2170 mm Stroke 50 mm Ram adjustment 4 - 80 mm Hydraulic Clutch CE-Safety 2e hand opperator system Adjustable stroke / ram  Full set books / drawing / CE-Mark Length:1500mm Width:1500mm Height:2100mm Weight:1500kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 2000, stroke length: 850 mm, operating speed: 8 mm/s, total length: 15,400 mm, total width: 6,500 mm, total height: 11,400 mm, overall weight: 407,000 kg, controller manufacturer: Cybelec DNC 1200, working width: 15,400 mm, bending force (max.): 2,000 t, distance between stands: 12,000 mm, number of axes: 8, Extra Heavy Duty Pressbrake 1 set top tooling 88 Gr 1 set lower dies Cybelec DNC 106EC controller Y1,Y2,X,R1,R2,R3,R4,OWK Dynamic Crowning Lower Beam What kind off jobs built for: Shipbuilding & Naval like ; Hull sections, deck plates, bulkheads ribs Defence & Military; armored vehicle structures, reinforced structe hardox / strenx Mining and Heavy Equipment; dump bodies, crusher housing, excevator, chute liners Contruction and Fabrication; bridge giders, box columns, steel frames  On and Offshore; pilers, decks, spreaders, crane componenet, wind energy offshore parts Boiler an vessels; pressure vessels, power plant components, tower or pole section   Bending examples: 35 mm thickness at 10 meter length 26 mm thickness at 12 meter length 20 mm thickness at 15 meter length Max. bending length: 15400mm Distance between column: 12000mm Max. pressing force: 2000T Dis. Beam - Table: 1500mm Beam stroke: 850mm Troth beam: 1250mm Approch speed: 80mm/min. Working speed: 8mm/min. Return speed: 80mm/min. Pedpjyvh Arefx Ap Djgl Number of controlled axis:10 Crowning: Yes Hydraulic toolclamping: Yes Power: 132kW Length: 15400mm Width: 6500mm Height: 11400mm Weight: 407000kg

Condition: excellent (used), Year of construction: 2006, Table size 3500 x 2500 mm Psdpfx Asxam Sdjp Djgl Siemens Simatic OP7 controller Max. work load 80 Ton New price 1 Mil EUR Working force up to 250 Bar Power 30 kW Distance between column:3700mm Hight under roof: 2650mm Table Length: 3500mm Ram stroke: 2100mm Approche speed: 80mm/min. Working speed: 8mm/min. Return speed: 50mm/min. Length: 7800mm Width: 5500mm Height: 6510mm Weight: 135000kg

Condition: excellent (used), Year of construction: 2014, operating speed: 8 mm/s, reverse speed: 100 mm/s, total length: 2,470 mm, total width: 2,000 mm, total height: 2,100 mm, overall weight: 3,800 kg, controller manufacturer: CYBELEC CNC, working width: 2,100 mm, bending force (max.): 40 t, distance between stands: 1,650 mm, control type: CNC control, number of axes: 4, actuation type: hydraulic, Press brake TOSKAR - TA 2100-40 MACH-ID 9474 Make: TOSKAR Type: TA 2100-40 Control: CYBELEC CNC Year: 2014 Cybelec 2D Controll system 4 Axis controlled Y1 / y2 / X / Delta-R 1 set universal tooling Fiessler laser safe  Sheet support arms front side Max. bending length: 2100mm Distance between column: 1650mm Max. pressing force: 40T Beam stroke: 130mm Table Width: 100mm Podpfx Aoyw Ip Iop Degl Troth beam: 300mm Approch speed: 100mm/min. Working speed: 8mm/min. Return speed: 100mm/min. Adjustment X-Axis back gauge:1009mm Number of controlled axis: 4 Power: 5.5kW Length: 2470mm Width: 2000mm Height: 2100mm Weight: 3800kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), Manufacturer: Millutensil Type: BV 25 PM Year of construction: 1987 Closing force up to 18000 Kg Opening force up to 15000 Kg Driven table in & out feed Upper table 270 Gr Upper size 900 x 550 Specifications Metric US Standard Distance between uprights 930 mm Installation height 760 mm Table length 755 x 755 mm ram stroke 600 mm Starting speed 1000 mm/min. Working speed Pgsdpfxsrr Ui Rj Ap Dol 1000 mm/min. Return speed 1000 mm/min. Table rotation 360 rpm Dimensions (estimate) length 1350 mm width 1350 mm Height 2000 mm weight 1500 kg

Condition: excellent (used), Year of construction: 2004, power: 25 kW (33.99 HP), stroke length: 350 mm, operating speed: 10 mm/s, total length: 6,000 mm, total width: 2,000 mm, total height: 3,400 mm, overall weight: 22,500 kg, travel distance X-axis: 1,000 mm, controller manufacturer: Delem DA 65W, working width: 4,300 mm, bending force (max.): 230 t, distance between stands: 3,700 mm, control type: CNC control, number of axes: 5, actuation type: hydraulic, Press brake DARLEY - EHP-LS 230 43/37 MACH-ID 9469 Psdpfx Ajyvh S Tep Dogl Make: DARLEY Type: EHP-LS 230 43/37 Control: Delem DA 65W Year: 2004 Max. bending length: 4300mm Distance between column: 3700mm Max. pressing force: 230T Beam stroke: 350mm Table Width: 250mm Troth beam: 400mm Approch speed: 100mm/min. Working speed: 10mm/min. Return speed: 100mm/min. Adjustment X-Axis back gauge:1000mm Number of controlled axis: 5 Crowning: yes Hydraulic toolclamping: yes Power: 25kW Length: 6000mm Width: 2000mm Height: 3400mm Weight: 22500kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: as good as new (ex-display), Year of construction: 2021, pressing force: 135 t, It has a cylinder for 10 to 135 T and a small additional cylinder for 1500 kg to 7 T. Empty speed 2-10mm second Pjdpfx Aeigg E Hjp Dsgl pressing speed 2 mm second table size 1100x650x120mm 800 mm maximum open height table height max. 900 mm travel of the cylinder is 400 mm total height 2900 mm weight 2,3 T 200 L tank Pump with 60 L capacity 5 KW main motor Control system PLC SIEMENS or PILZ RSS4000- S 7 1200 Safety control system PILZ Communication operator/press Color touch screen 10" OMRON/SIEMENS

Condition: used, Year of construction: 2021, machine/vehicle number: HB 2022-A-073, pressing force: 300 t, Portal straightening press with 300 T capacity a) idle and pressing speed up to 17 mm/sec. b) opening speed up to 55 mm/sec c) table size 2500x1600mm d) open height 700 mm e) total size approx. LBH 4500 x 2300 x 3700 mm f) Oil temperature indicator on the tank g) Lubrication via grease nipple h) table in grid construction,with T grooves according to customer's request, otherwise 22mm i) operation on swivel arm, mounted on the bridge j) pressure adjustment from 50 T to 300 T via MONITOR k) bridge moves by two gear motors, via racks l) Cylinder moves to the left and to the right via toothed racks m) Machine body double painted n) Cylinder induction hardened Type of construction Press design PORTAL PRESS Thermally neutral 80 - 120 °C Number of operating sides 3 side Pjdpfx Apsh Agnue Dsgl Forces Pressing force max. 3,000 kN Free ripping force max. 500 kN Pressure build-up time Closed die Steel to steel Max. 3 sec. Dimensions Max. Opening width 700 mm Stroke and min. opening 700 mm/ 0 mm Table height above floor approx. 9ß0 mm Height above floor (headroom) approx. 3700 mm Hall height min. 5.000 mm Deflection Determined at max. clamping force with 70% occupancy < = 0.8 mm/m Weight Total weight of press without operating materials and table plate approx. 22 T Speeds Fast closing with 17 mm sec. Pressing speed 8 mm sec. Opening 55 mm sec. Sound pressure Sound pressure level, measured at 1.5m height at the control panel after max. 78 db(A) DIN 45635-T16-KL3 Hydraulics Number of pressing cylinders 1 pc. Operating pressure max. 350 bar Pressing pressure build-up time 02. mz sec. Pressure accuracy during pressing stroke +/- 5 bar Main pump BOSCHREXROTH approx. 93 L/min Oil volume approx. HLPD 46 MW 900 liters Ambient temperature max. 45 °C Oil temperature max. 55 °C Electrical system Main supply 400 V AC Control voltage 24 V DC Frequency 50 Hz Hydraulic connection Main motor IE3 22 kW Total connection Approx. 30 kW

Condition: new, Year of construction: 2019, pressing force: 275 t, pressure:275 t distance between columns:3000 mm Pgjdpfsfxyigox Ap Dsl total power requirement:30 kW weight of the machine ca.:40 t draw back pressure:27 t pump capacity:Axialpumpe mit Proportionalventil :6000 mm :max. 3000 mm Table dimensions:6000 x 3000 mm table height over floor:700 mm distance between table / ram:1100 mm :450 l traversing speed:auf X und Y, 30-33 mm/sec. down speed:2-10 mm/sec :2-50 mm/sec. Cylinder hub:900 mm Cylinder diameter:440 mm Stestle extension:200 / 200 mm / Ø :40 mm Siemens Control System:S7 1200 Monitor Siemens 9":Touch Panel Tax desk:tragbar

Condition: new, Year of construction: 2019, machine/vehicle number: DF0362, pressing force: 250 t, pressure:250 t Pgsdjfxyinjpfx Ap Djl passage width:1800 mm stroke:600 mm total power requirement:22 kW weight of the machine ca.:24 t dimensions:ca. 3390 x 3400 x 3800 mm column diameter:160 mm return capacity:25 t max. working heidht:800 mm Table dimensions:1800 x 1600 mm :2350 x 1600 mm table height over floor:900 mm hydraulic table shift:25 mm/sec table load:5 t pre-running speed:10 mm/sec pressure speed:10 Return Speed:25 mm/sec speed rapid traverse:10 mm/sec :600 l Oil cooling (electric):1,5 kW (max) :46er / 10 my Monitor SIEMENS:10 Zoll

Condition: like new (used), Year of construction: 2024, pressing force: 200 t, Portal Straightening Press – Manufacturer: Hidrobrasil – 200 t Gantry Press – Table 4,000 × 2,000 mm For sale is a versatile portal straightening press from Hidrobrasil featuring a pressing force of 200 t. The machine is equipped with a large table area of 4,000 × 2,000 mm, a laterally movable cylinder, and a longitudinally adjustable bridge structure, making it ideal for large-format straightening, assembly, and special applications. ==== Technical Data + Information: Portal Straightening Press Hidrobrasil – 200 t Gantry Press ==== General Specifications Pedpjxrb Nbsfx Ap Dsgl - Manufacturer: Hidrobrasil - Model: Portal Straightening Press - Design: Gantry press - Pressing force: 200 t - Operating pressure: max. 285 bar ==== Working Area - Table size: 4,000 × 2,000 mm - Clear width / height: 1,500 mm - Column spacing: 2,050 mm - Stroke: 1,500 mm ==== Movements & Travel Paths - Lateral cylinder adjustment: max. 1,450 mm - Longitudinal bridge movement: max. 2,800 mm - Approach speed: 20 mm/s - Working speed: 2 mm/s ==== Construction & Equipment - Hydraulic power unit mounted on top of the press - Hydraulic block and valves by Bosch Rexroth - Air and oil filters by Filtrec - Combination air and water cooling - Stroke cylinder integrated in the worktable - Machine control via wireless remote (2-button system) - Anti-rotation device for the cylinder - Machine status and diagnostics system with touchscreen ==== Auxiliary Stroke Cylinder System - Number of stroke cylinders: 10 units - Rod diameter: 25 mm - Stroke: 80 mm - Controlled via hydraulic system or control unit ==== Control & Operation - Siemens PLC: S7-1200 - Siemens Touchscreen: KTP900 – 9" - Up to 99 programs storable - Functions: - Setting stroke, pressure, and hold time - Decompression time - Piece counter - Alarm management - Real-time monitoring of all parameters - Positioning accuracy: ± 0.1 mm ==== Safety & Monitoring - Emergency stop system - Two-hand/wireless operation with safety release - Safety stripe on gantry columns - Hydraulic oil temperature monitoring - Automatic shutdown at overtemperature (> 65°C) - Filter monitoring - CE compliant ==== Hydraulics - Main drive power: 5.5 kW - Oil volume: not supplied - Oil temperature control with automatic cooling ==== Electrical - Main supply: 400 V AC - Control voltage: 24 V DC - Components: Siemens, Allen Bradley, Phoenix ===== Straightening work, large components, assembly work, special purpose machine construction, steel construction, maintenance, press-fitting applications Gantry press, straightening press, hydraulic press, industrial press, special machine, tool matching press, tryout press, tool tryout press Are you looking for a hydraulic press tailored to your specific application? Contact us for an individual offer. Our hydraulic presses are manufactured in accordance with German Machinery Guidelines as well as European Machinery Directives (Directive 2006/42/EC), EC standards, and EU safety regulations. Furthermore, our presses exceed both Canadian and European safety requirements, as they comply with all aspects of the Brazilian national safety guideline NR 12, which builds upon them. Our core expertise lies in special purpose machine construction and press automation. The hydraulic systems of our presses primarily utilize components from leading European manufacturers.

Condition: as good as new (ex-display), Year of construction: 2024, functionality: fully functional, pressing force: 30 t, table width: 600 mm, table length: 600 mm, total length: 1,869 mm, total width: 850 mm, total height: 2,620 mm, overall weight: 2,900 kg, Hidrobrasil Single-Column Press – 30 t – 600 × 600 mm – 400 mm stroke For sale is a hydraulic single-column press (C-frame type) manufactured by Hidrobrasil, featuring 30 t pressing force and a compact design. The machine is equipped with a table size of 600 × 600 mm, making it ideal for assembly, straightening, and pressing operations, as well as for small batch production in workshop and manufacturing environments. ==== Technical Data & Information: Hydraulic Single-Column Press – 30 t Pgjdpevhcykofx Ap Del ==== General Information - Manufacturer: Hidrobrasil - Model: Single-Column Press - Design: C-frame press - Machine type: Assembly press - Pressing force: 30 t - Machine weight: approx. 2.9 t ==== Working Area - Stroke: 400 mm ==== Table & Ram - Table size: 600 × 600 × 100 mm - Clearance behind table: 50 mm - Table fixing points: 600 / 800 / 1000 mm ==== Speeds - Downward speed: 10 mm/sec - Upward speed: 24 mm/sec ==== Hydraulics & Drive - Motor power: 3 kW - Oil tank: 60 l ===== Assembly operations, press-fitting operations, straightening work, workshop applications, small series production Hydraulic press, single-column press, C-frame press, assembly press, industrial press

Condition: as good as new (ex-display), Year of construction: 2021, pressing force: 400 t, Gantry straightening press with 400 T capacity a) idle and pressing speed up to 17 mm/sec. b) opening speed up to 60 mm/sec c) table size 6000x3000mm d) open height 1500 mm e) total size approx. LBH 6000 x 5000 x 4500 mm f) Oil temperature indicator on the tank Psdpfxohyc Nwe Ap Degl g) Lubrication via grease nipple h) Table in grid construction, i) operation on swivel arm, mounted on the bridge j) pressure adjustment from 60 T to 400 T via MONITOR k) Bridge moves by two gear motors, via toothed racks l) Cylinder moves to the left and right via toothed racks m) Machine body powder coated, or double painted n) T-slots according to customer requirements o) cylinder induction hardened PORTAL PRESS Thermally neutral 80 - 120 °C Number of operating sides 3 side Forces Pressing force max. 4000 kN Free ripping force max. 600 kN Pressure build-up time Closed die Steel to steel Max. 3 sec. Dimensions Max. Opening width 1500 mm Stroke and min. opening 1500 mm/ 0 mm Table height above floor approx. 900 mm Height above floor (headroom) approx. 4500 mm Hall height min. 5500 mm Deflection Determined at max. clamping force with 70% occupancy < = 0.8 mm/m Weight Total weight of press without operating materials and table plate approx. 52 T Speeds Fast closing with 17 mm sec. Sound pressure Sound pressure level, measured at 1.5 m height at the control panel according to DIN 45635-T16-KL3 max. 78 db(A) Hydraulics Number of pressing cylinders 1 pc. Operating pressure max. 280 bar Pressing pressure build-up time 2-3 sec. Pressure accuracy during pressing stroke +/- 5 bar Main pump BOSCHREXROTH approx. 150 L/min Oil volume approx. HLPD 46 MW 900 liters Ambient temperature max. 45 °C Oil temperature max. 55 °C Electrical system Main supply 400 V AC Control voltage 24V DC Frequency 50 Hz Connection hydraulics Main motor IE3 30 kW Total connection Approx. 35 kW

Condition: new, Year of construction: 2021, pressing force: 10 t, Single-Column Press – Manufacturer Hidrobrasil – 10 t Assembly Press – Table 600 × 300 mm For sale is a hydraulic single-column press (C-frame) from Hidrobrasil with a pressing force of up to 10 t. The machine is designed for continuous shift operation and stands out due to its robust construction, reliable hydraulic components, and flexible range of applications in assembly and pressing processes. ===== Technical Specifications & Information: Hydraulic Single-Column Press – 10 t ==== General Specifications - Manufacturer: Hidrobrasil - Model: Single-Column Press / Assembly Press - Design: C-frame press / Single-column press - Press force: max. 10 t (100 kN) Pjdpfohaqygex Ap Degl - Machine weight: approx. 1.2 t - Dimensions (L × W × H): approx. 1,100 × 600 × 1,850 mm - Table height: 850 mm - Operation sides: 1 ==== Working Area - Max. opening width: 400 mm - Stroke: 350 mm ==== Table & Ram - Table plate: 600 × 300 mm - Ram plate: 300 × 300 mm - Design: with T-slots and central cylinder clamping ==== Speeds - Approach speed: 0 – 10 mm/s - Return speed: up to 25 mm/s - Pressing speed: 0 – 10 mm/s ==== Hydraulics - Number of cylinders: 1 - Operating pressure: max. 250 bar - Pressure accuracy: ± 5 bar - Pump: Gear pump, approx. 6 l/min - Oil volume: approx. 80 l (HLP 46) ==== Drive & Electrical System - Motor power: 2.2 kW - Total connected load: approx. 3 kW - Main supply: 400 V AC - Control voltage: 24 V DC - Frequency: 50 Hz ==== Features & Operation - Pressure adjustment via rotary knob (0.5 – 10 t) - Remote cable control for up/down movement - Oil temperature display - Control cabinet supply: 3,000 mm cable with 16 A plug - Machine body powder-coated / double painted ==== Control & Components - Control system: Siemens - Hydraulic components: Bosch Rexroth ==== Design & Safety - Robust machine body according to DIN 8651 - Cylinder induction-hardened and chrome-plated - CE certificate available - Documentation in German - Low maintenance and reliable - Complies with current EU directives ===== Suitable for: Assembly work, pressing work, small batch production, workshop applications, light forming technology Single-column press, C-frame press, hydraulic press, workshop press, assembly press, industrial press, die setting press, tryout press, tool try out press Looking for a hydraulic press tailored to your application? Contact us for a customized offer. Our hydraulic presses are manufactured in compliance with German and European machinery directives (Directive 2006/42/EC), EC standards, and EU safety regulations. Additionally, our presses exceed Canadian and European safety requirements, as they fully comply with the Brazilian national safety standard NR 12, which is based on and builds upon these. Our key strength lies in custom machinery construction and press automation. We offer custom-tailored hydraulic presses at surprisingly competitive prices. For the hydraulic systems of our presses, we predominantly use components from leading European manufacturers.

Condition: new, pressing force: 100 t, pressure:100 t passage width:700 mm stroke:450 mm weight of the machine ca.:6 t dimensions:ca. 3000 x 1210 x 3100 mm return capacity:10 t :22 kW Max Working height:850 mm :1 - 100 mm speed of return flow:1 - 100 mm/sec :1 - 10 mm/sec. Pgedpfefxyhqsx Ap Dol pestle plate:1090 x 600 mm table plate:1090 x 600 mm positioning accuracy:0,1 mm table height over floor:800 mm :300 l Oil cooling (electric):1,5 kW (max) ejector:d=100 mm ejector stroke:210 mm pressure of ejector:100 t no. of ejector pins:1 Stück Monitor WEG:15 Zoll :2.000,-- ? :2.400,-- ? :3.000,-- ? :2.400,-- ? :5.800,-- ?
