Used Trumpf Tc 200 R for sale (380)

Condition: like new (used), Good parts conveyor belts for TruMatic 7000 / 6000 Nodpju S Ny Tofx Ag Tswh Very good condition

Condition: excellent (used), functionality: fully functional, Year of construction: 2019, control type: CNC control, laser type: fiber laser, laser power: 10,000 W, table length: 4,000 mm, table width: 2,000 mm, working length: 4,000 mm, working width: 2,000 mm, Equipment: CE marking, dust extraction, emergency stop, fume extraction, safety light barrier, Used Trumpf10kw 5040 4metre x 2metre Trumpf fiber laser for sale Year 2019 Nwsdpfoylax Nox Ag Teh Complete with active cut control option Selling without automation 10kw / 10,000 w 4metre x 2metre cutting bed

Condition: like new (used), Year of construction: 2022, functionality: fully functional, punching force: 18 t, working range: 2,500 mm, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, Used Trumpf TruPunch 3000 S20 with Sheet Master Compact sheet load and unload for sale Technical data TruPunch 3000 medium format (S20) Dimensions, weights Width 6282 mm Depth 6548 mm Height 2195 mm Weight with all units 10700 kg Control, hardware, electrics Hard disk type SSD Number and size of the hard disc 2 GB x 120 GB Hard disk memory for customer programmes 10 GB Screen Touch screen Screen size 21.5 in Interface USB Nsdpfjykt N Ssx Ag Towh Network connection RJ45 Control type Bosch CML75 Operating system Windows 10 IoT Axis data X/Y/C axis drive NC-controlled, maintenance-free three-phase current servo motors Punching head drive Electric drive Maximum axis speeds - X axis 90 m/min Maximum axis speeds - Y axis 60 m/min Maximum axis speeds - Simultaneous 108 m/min Maximum axis speeds - C axis (punching) 350 rpm Maximum axis speeds - C axis (tapping) 350 rpm Maximum punching stroke rate (E = 1 mm) 800 1/min Maximum marking stroke rate 1000 1/min Precision - Positioning deviation Pa +/- 0.1 mm Precision - Position range Ps +/- 0.03 mm Precision - Smallest programmable increment 0.001 mm Working range and workpiece size Maximum sheet thickness 6.4 mm Maximum workpiece weight 150 kg Working range - X axis 2500 mm Working range - Y axis 1250 mm Punch-specific data Maximum punching force 180 kN Maximum presser foot force 20 kN Maximum tool size, punching (outer circle) 76.2 mm Maximum tool size, forming (outer circle) 101.6 mm Single tool changing time 2.8 s MultiTool changing time 0.5 s Number of linear magazine stations 20 pieces Number of tools when using MultiTool / clamps 18 pieces - 180 pieces Loading / part removal Maximum part size, part removal flap, punching 400 mm x 600 mm Flap size (X x Y) 400 mm x 1250 mm Maximum part size, fixed chute, punching 180 mm x 180 mm Connected loads, ambient temperature Pressure range, compressed air connection minimum (same direction) / maximum (static) 7 bar / 14 bar Painting Main colour white, NCS S 0505-R80B Secondary colour blue, RAL DESIGN 250 20 20 Switch cabinet/periphery grey, RAL 7040 SheetMaster Compact 2500 x 1250 mm (AK05) General Maximum Y1 axis traverse speed (suction frame) 27 m/min Maximum Y2 axis traverse speed (unloading cart) 18 m/min Maximum Z axis traverse speed 20 m/min Y/Z axis drive Asynchronous motors controlled by frequency converter Loading Maximum sheet size 2500 mm x 1250 mm Minimum sheet size 1000 mm x 1000 mm Minimum sheet thickness 1 mm Maximum sheet thickness 6.4 mm Maximum sheet weight 160 kg Unloading Minimum sheet thickness 1 mm Maximum sheet thickness 6.4 mm Maximum sheet weight 160 kg Maximum stack height 190 mm Painting Main colour white, NCS S 0505-R80B Secondary colour blue, RAL DESIGN 250 20 20

Condition: used, Year of construction: 2001, functionality: fully functional, Press force 85 t, Bending length 2050 mm, Distance between uprights 1750 mm, Control DELEM, Stroke 215 mm, Throat depth 410 mm, Total power 13 kW, Weight 8,750 kg, Machine dimensions 3190 x 2100 x 2375 mm Nwsdpjw Imq Refx Ag Toh

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, Pressure: 225 t Nedsyz S Ngopfx Ag Tjwh Bending length: 4050 mm Control: DA 69 TW Oil capacity: 400 l Total power requirement: 17 kW Machine weight approx.: 18,100 kg Dimensions: 5700 x 2610 x 3300 mm

Condition: good (used), Year of construction: 2005, functionality: fully functional, Press force 400 t Bending length 4050 mm Distance between uprights 3550 mm Control unit: CYBELEC ModEva 10 S Total power requirement 47 kW Machine weight approx. 30,400 kg Space requirements approx. 6000x3000x3450 mm Accessories/Equipment: - 2 bending aids in front of the machine - 2 backgauge fingers - Light curtain in front of the machine - CYBELEC ModEva 10 S control - Parking spot on the right for bending aid - Die shifting - Tool holder - Crowning - Pneumatic tool shifting Nedpfx Aoy Ew E Ijg Tjwh - Foot switch - Side safety doors - Controlled axes: Y1 - Y2 - R - Z1 - Z2

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2011, operating hours: 70,119 h, machine/vehicle number: A0111A0021, controller model: TruControl 1000, laser source model: Festkörperlaser, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,270 mm, Equipment: CE marking, safety light barrier, TECHNICAL DETAILS Working area: 2,500 x 1,270 mm Parts flap: 300 x 500 mm Clamping claws: 2 units Laser Solid-state laser: TruDisk 3001 LLK outlets: 1 unit Fiber optic cable: 10 m Cutting head Lens focal length: 200 mm MACHINE DETAILS Operating hours Laser on-time: 70,119 h Total operating hours: 73,936 h Control Laser control: TruControl 1000 Screen size: 15" EQUIPMENT Robust, easily accessible C-frame Precision linear guide system for high-accuracy processing Linear magazine including 2 clamping claws Maintenance-free drives Repositioning device with programmable hold-down Brush tables Good parts container Chip bin Enclosed beam guidance via fiber optic cable Nwsdpoy R Uatefx Ag Tjh ContourLine FocusLine NitroLine Chiller unit Diode-pumped excitation for long service life Upgradeable for up to 3 additional LLK outlets Quick-change cutting head system ControlLine Electro-hydraulic punching head Programmable hold-down plate Tool length compensation Punch lubrication spray Slug extraction system Open control based on Bosch PNC-P Control panel with TFT color display Teleservice via Internet Automatic shutdown USB port Network connection CE marking Multi-beam light barriers Laser source safety monitoring system Quick disconnect for hydraulics Scatter radiation protection Additional LLK outlet for operation with Trumpf system MultiTool function MultiBend function Thread forming function Marking / fast embossing function Roller and deburring technology function Softpunch function Adaptive stroke calibration Spray lubrication for die Additional clamping claw Individually opening clamping claws Height-adjustable clamping claws Automatic clamping claw closing Repositioning cylinder with height-adjustable pressure pieces Sensor for parts chute Loading/unloading aid for brush tables Vibration-damped foundation Chip conveyor with tilting bin Liftable brush segment Parts conveyor belt

Condition: good (used), functionality: fully functional, Year of construction: 2014, machine/vehicle number: D1101C3066, laser type: CO₂ laser, laser power: 6,000 W, total length: 1,145 mm, total width: 1,035 mm, total height: 620 mm, Equipment: CE marking, TruFlow 6000 laser resonator by Trumpf for sale. Nedpfxoyt Dchs Ag Towh The resonator is in good used condition and operates flawlessly. Two identical units are available (price is per unit).

Condition: excellent (used), functionality: fully functional, Year of construction: 2013, control type: CNC control, laser type: CO₂ laser, laser power: 5,000 W, table length: 6,000 mm, table width: 2,000 mm, Trumpf laser cutting system type Trulaser 5060 Laser power: 5 kW Working area: 6000x2000 mm Pallet changer Njdpfxsyvr R Hs Ag Tjwh Complete with accessories Operating hours – see image

Condition: excellent (used), functionality: fully functional, Year of construction: 2015, operating hours: 64,000 h, machine/vehicle number: S1631C0027, laser hours: 40,000 h, laser power: 3,000 W, Equipment: cooling unit, documentation/manual, safety light barrier, For Sale – TRUMPF TruLaser Cell 8030 (2015) | 3D Laser Cutting System A rare opportunity to acquire a premium 3D laser cutting system from TRUMPF, fully maintained and production-ready. Ideal for automotive, aerospace, and general metalworking applications requiring precision 3D contour cutting on tubes, hydroformed parts, and complex profiles. Machine at a glance Model: TRUMPF TruLaser Cell 8030 Year of manufacture: 2015 Laser source: 3,000 W TRUMPF (CO₂ / solid-state – to be confirmed on inspection) Operating hours: 70,000 h total / 41,125 h beam-on Condition: Fully operational, currently in series production Service history: Annual maintenance exclusively by TRUMPF – complete documentation available Nsdpfsukhltsx Ag Tswh Why this machine 5-axis CNC kinematics for demanding 3D geometries Enclosed, automation-ready workspace Proven performance in both high-mix/low-volume and medium series production Original TRUMPF engineering – Made in Germany Uninterrupted OEM service record – no third-party interventions Our difference: modular handover, not just a machine sale We are not a trading company. We are an active laser job shop operator (SOERMEL Groupe, France – 65 staff, 12 M€ revenue, IATF 16949 / EN 9100 / ISO 9001 certified). Buyers benefit from our operational know-how through four service packages – choose what fits your project: ModuleScope M1 – Ex WorksPick-up at our site, loaded onto your truck. Machine tested before handover.Buyers with own rigging and installation capacity. M2 – DeliveredM1 + international transport, insurance, and unloading at your facility (DAP/DDP on request).Buyers with internal installation team. M3 – Delivered & InstalledM2 + mechanical installation, utility connection, first power-up, laser alignment.Buyers without dedicated installation resources. M4 – TurnkeyM3 + commissioning, process validation with your parts, operator and maintenance training, acceptance protocol.Buyers who want the machine producing from day one. On-site inspection and sample cuts on your own parts available at our facility in France prior to purchase.

Condition: excellent (used), functionality: fully functional, Year of construction: 2015, operating hours: 70,000 h, machine/vehicle number: S1631C0047, laser hours: 38,125 h, laser power: 3,000 W, Equipment: CE marking, cooling unit, documentation/manual, emergency stop, fume extraction, safety light barrier, For Sale – TRUMPF TruLaser Cell 8030 (2015) | 3D Laser Cutting System A rare opportunity to acquire a premium 3D laser cutting system from TRUMPF, fully maintained and ready for production. Ideal for automotive, aerospace, and general metalworking applications requiring precise 3D contour cutting on tubes, hydroformed parts, and complex profiles. Machine at a glance Model: TRUMPF TruLaser Cell 8030 Year of manufacture: 2015 Laser source: 3,000 W TRUMPF (CO₂ / solid-state – to be confirmed upon inspection) Operating hours: 70,000 hours total / 41,125 hours beam-on Condition: Fully operational, currently in series production Service history: Annual maintenance exclusively performed by TRUMPF – complete documentation available Why this machine Njdpfx Agsy E Iv Re Towh 5-axis CNC kinematics for demanding 3D geometries Enclosed, automation-ready workspace Proven performance in both high-mix/low-volume and medium series production Original TRUMPF engineering – Made in Germany Uninterrupted OEM service record – no third-party interventions Our difference: modular handover, not just a machine sale We are not a trading company. We are an active laser job shop operator (SOERMEL Groupe, France – 65 employees, 12 million euros in revenue, IATF 16949 / EN 9100 / ISO 9001 certified). Buyers benefit from our operational know-how through four service packages – choose the one that fits your project: Module Scope M1 – Ex Works: Pick-up at our site, loaded onto your truck. Machine tested before handover. For buyers with their own rigging and installation capabilities. M2 – Delivered: M1 + international transport, insurance, and unloading at your facility (DAP/DDP on request). For buyers with an internal installation team. M3 – Delivered & Installed: M2 + mechanical installation, utility connection, first power-up, laser alignment. For buyers without dedicated installation resources. M4 – Turnkey: M3 + commissioning, process validation with your parts, operator and maintenance training, acceptance protocol. For buyers who want the machine producing from day one. On-site inspection and sample cuts on your own parts are available at our facility in France prior to purchase.

Condition: ready for operation (used), Year of construction: 2001, operating hours: 65,000 h, laser power: 3,200 W, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 115 mm, number of axes: 3, CO2 laser cutting machine manufactured in 2001. This TRUMPF Trumatic L3030 features a laser power of up to 3208 W in CW mode, providing efficient cutting capabilities. It operates on a 3-phase AC supply. If you are looking to get high-quality cutting capabilities, consider the TRUMPF Trumatic L3030 machine we have for sale. Contact us for further details. • Electrical • Supply voltage: 400 V • Phases: 3-phase AC • Frequency: 50 Hz • Rated power: 73 kVA • Rated current: 105 A • Maximum fuse protection: 125 A • Control voltage: 24 V DC • Control • Control system: Siemens Sinumerik 840D (CNC) with TRUMPF TASC3 laser control • Control software version: 2.4 • Laser performance • CW mode power: • 100%: 3208 W • 85%: 2756 W • 75%: 2407 W • Pulsed (5 kHz) power: • 100%: 3208 W • 75%: 2416 W • 50%: 1610 W • 25%: 810 W • 10%: 328 W • 5%: 157 W • 1%: 0 W • RF/drive • Reflected RF power: 0.3 kW • Maximum CW RF amplitude: 100% Njdpsyzymgofx Ag Towh • Switching frequency (CW): 50 kHz • Maximum pulse voltage: 10,000 V • Pressure and leakage • Operating pressure limits: 20.01–27.00 kPa • Maximum turbine pressure: 200 hPa • Leakage rate: 0.04 hPa/min • Thermal/CPU • Maximum CPU temperature: 49 °C • Actual CPU temperature: 43 °C • Optics/Alignment • Maximum beam alignment time: 600 s • Hours • Laser on hours: 65,000 h Additional equipment • RIEDEL chiller (cooling system) (2001), Type: L 15/21 TR3 • Supply voltage: 400 V • Phases: 3-phase • Frequency: 50 Hz • Nominal current: 42 A • Protection class: IP54 • Refrigerant: R134a • Refrigerant charge: 11.5 kg • Maximum water pressure: 20.2 bar

Condition: used, functionality: unexamined, Year of construction: 2006, We are offering this used TRUMPF Trumatic L3030 laser cutting machine, manufactured in 2006, for sale. Machine dimensions: approximately 550/300/200 cm, table dimensions: approximately 340/160/85 cm, consisting of: laser TLF 4000T and cooling unit RIEDEL L16/29-TR3.24, manufactured in 2006, including accessories and laser cooling unit L16/29-TR3.24. The machine is currently dismantled and was last in operation at Gast Metallwarenfabrik at the end of 2025. It was disassembled there by a specialist company that also delivers new TRUMPF machines. The machine is sold without any warranty. Loading is possible on site. Transport must be arranged by the buyer. Nsdpfx Agezbyk Rj Tjwh If you have any questions or require further information, please feel free to send us a message or call us.

Condition: excellent (used), functionality: fully functional, Year of construction: 2019, operating hours: 13,500 h, machine/vehicle number: A1240A0666, control type: CNC control, degree of automation: automatic, actuation type: electric, laser power: 4,000 W, sheet thickness (max.): 20 mm, sheet thickness steel (max.): 20 mm, sheet thickness stainless steel (max.): 15 mm, sheet thickness aluminum (max.): 10 mm, table length: 4,000 mm, table width: 2,000 mm, working length: 4,000 mm, working width: 2,000 mm, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 115 mm, feed rate X-axis: 4,000 m/min, feed rate Y-axis: 2,000 m/min, overall weight: 14,500 kg, total length: 12,000 mm, total width: 5,300 mm, total height: 2,200 mm, Equipment: centralized greasing system, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, safety light barrier, TRUMPF TruLaser 3040 (L32) laser cutting machine with 4000 W power, year of manufacture November 2019, the machine has been in use only since 2020. The machine is in very good condition, fully operational, and has been serviced regularly every 6 months by an authorized service provider. Technical data: TRUMPF TruFlow CO2 laser - max. power TruFlow 4000 (programmable in 1% increments): 4000 W Working area: X axis: 4000 mm Y axis: 2000 mm Z axis: 115 mm Maximum sheet weight: 1800 kg Dimensions and weight: Length: 12,000 mm Width: 5,300 mm Height: 2,200 mm Weight: 14,500 kg TRUMPF CNC control system based on Siemens Sinumerik 840D: Maximum mild steel thickness: 20 mm Maximum stainless steel thickness: 15 mm Maximum aluminium thickness: 10 mm Gas consumption: Laser gas CO2: 1 l/h Laser gas N2: 6 l/h Laser gas He: 13 l/h Cutting gas: O2, N2 depending on application Laser cooling: closed-loop system Nwjdpfx Aey D Ryvsg Tjh Total device power consumption (including cooling unit): with TruFlow 4000 – max. 61 kW Compressed air consumption: with TruFlow 4000 – 31 Nm³/h Paint - color: Fixed machine parts, extraction, control cabinets, cooling unit: blue - RAL 250 20 20; frame crossbeam and laser unit: white - NCS S 0505 R80B.

Condition: ready for operation (used), Year of construction: 2012, operating hours: 20,118 h, laser power: 6,000,000 W, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 115 mm, number of axes: 3, This 3-axis TRUMPF TruLaser 5030 was manufactured in 2012. It features a powerful 6,000 W laser and is equipped with a HANDTE MF-L 2000 extraction system. The machine has been completely freshly serviced and has a total of 20,118 laser hours. If you are looking to get high-quality laser cutting capabilities, consider the TRUMPF TruLaser 5030 CO2 laser cutting machine we have for sale. Contact us for further details. • Gesamtantriebsleistung: ca. 11,5 kW (nur Maschine ohne Zusatzausstattung) • Elektrische Ausführung: nach VDE-Richtlinien, Spannung 400 V ± 10 %, 50 Hz mit Nullleiter • Connected load: 400 V / 50 Hz / 12 kVA • Main fuse: 3x160 A • Fehlerstromschutzschalter in der Netzeinspeisung nur als allstromsensitive Ausführung mit 300 mA zulässig • Steuer- und Ventilspannung 24 V-DC • Multitasking Prozesssteuerung mit großem Bedienterminal und übersichtlicher Menüführung • Schaltschrank und Bedienpult frei aufgestellt • Lackierung Grundmaschine: lichtgrau - RAL 7035 • Lackierung Abdeckungen: rotviolett - RAL 4002 • Minimale Abschnittlänge: im automatischen Betrieb ab 10 mm • Mindest-Reststücklängen: ca. 180 mm • Verfahrweg des Nachschubgreifers: 3.000 mm • Gewicht des Schneidgutes: bis max. 4.000 kg • Länge der Maschine: 5.600 mm • Breite der Maschine: 4.300 mm • Höhe der Maschine: 2.550 mm (2.150 mm für Transport), Anlage zum Transport geteilt • Gewicht: ca. 3.100 kg • Materialauflagehöhe: 800 mm • Sägebandspannung: hydraulisch, elektrisch überwacht • Kühlmittelbehälter Fassungsvermögen: ca. 60 l • Kühlmittelpumpe Fördermenge: 40 l/min bei 2,5 m Förderhöhe, Leistung: 115 W • 3RD CNC 6006, Motor 13,1 kW, Spindeldrehzahl 50-5000 U/Min. • Tisch 6100x580 mm, ausgeführt mit Späneförderer • Verfahrwege X/Y/Z 6100x600x450 mm • Pendelbetrieb (Be- und Entladen während Maschine produziert) • Standardausführung inklusive: 15,4” Touchscreen PC und Pentium 5 PC, 8GB RAM, 120GB Festplatte • Grafische Programmierung • Automatische Werkzeuglängenvermessung • Bedienpult extern auf Linearführung • Verkleidung um Maschinenkopf • Laser-Gebietssensor (Pendelbetrieb) • Kühlanlage mit Emulsion • Ethernet-Anschluss für Teleservice • Gemäß Angebot vom 26. Januar 2022 • Inklusive: Tisch 70 mm abgesenkt und Säule 100 mm verlängert, Abstand Spindel-Tisch 295-745 mm • 16-fach Werkzeugwechsler • Elektronisches Handrad für manuelles Verfahren der Achsen • Kühlung durch die Spindel, Arbeitsdruck 4 Bar, ausgeführt mit Drehzufuhrventil geeignet für Kühlung mit nur Luft • Automatisches Tastsystem für die Höhe des Werkstücks (Z-Reader) • Komplette DrillCam CAD/CAM Software zum Konvertieren von 2D DXF, DWG, DSTV, NC, NC1 oder 3D STEP Dateien zu Maschinenprogrammen, auf der Steuerung der Maschine installiert • Safety: Light barrier system • Laser hours: 20,118 h • Condition/Service: Completely freshly serviced • Enclosed machine frame with integrated laser unit • Gantry drive combined with linear drives • Automatic pallet changer • Longitudinal conveyor belt • Cross conveyor (waste conveyor) • Work area lighting • PCS (Process Control System) • Positioning laser diode • Oil spray system • HI-LAS • HI-LAS PLUS • PMS (Plasma Monitoring System) • Trumpf Laser: CO2 laser TFL 6000 • Cooling unit • High-frequency excitation • Laser power control • Programmable cutting gas pressure setting • DIAS III • AutoLas Plus • Oil spray system for safe thick sheet metal processing • Automatic shut-off • Programmable power cycles • Laser logbook function Nedsyrfbcepfx Ag Tewh

Year of construction: 1990, condition: used, Punching machine Trumpf Trumatic 240 Nwsdpfsy Ru Idsx Ag Teh

Condition: good (used), functionality: fully functional, Year of construction: 2019, LiftMaster 1530 loading and unloading system for sale due to lack of use. It was previously used with an L20 CO2 laser. Nedozdiwmjpfx Ag Towh

Condition: good (used), functionality: fully functional, Year of construction: 2010, operating hours: 24,709 h, laser type: CO₂ laser, sheet thickness (max.): 20 mm, sheet thickness steel (max.): 20 mm, sheet thickness stainless steel (max.): 12 mm, sheet thickness aluminum (max.): 8 mm, working length: 3,000 mm, working width: 1,500 mm, Equipment: documentation/manual, Trumpf TruLaser 3030 (L20) CO2 laser. Nedpfxezdiqrs Ag Towh It has been used in a single shift operation throughout its lifespan and can be inspected while in operation.

Condition: ready for operation (used), Year of construction: 2001, - USED - CO2 LASER CUTTING MACHINE WITH PALLET CHANGER X-AXIS TRAVEL: 3000 mm Y-AXIS TRAVEL: 1500 mm Z-AXIS TRAVEL: 115 mm Nwedpfx Ajy T S Akjg Tjh WORKING AREA: 3000 x 1500 mm SOURCE: TLF 3000 TURBO ; 3000 W CONTROL UNIT: SIEMENS 840D WEIGHT: 11500 Kg OVERALL DIMENSIONS: 9800 x 5300 x 2000 mm NOTE: WITH LIBELLULA SOFTWARE

Condition: excellent (used), Year of construction: 2023, Laser Welding Robot Manufacturer: TRUMPF Model: TruLaser Weld 5000 (LR03) Year of construction: CW 51/2023 – Commissioned: 2024 4,000-watt solid-state (fiber) laser Operating hours: as new, used ADVANCED EQUIPMENT: 30 m LLK (laser light cable) TruDisk 4001 (solid-state, fiber) with 1 LLK-A, 1 unit, incl. chiller, incl. safety package for laser welding Workpiece Processing: Rotary module for shielding gas guidance FusionLine FusionLine combination nozzle Positioners: Rotary-tilt positioner with endless rotation Zero-point clamping system for rotary-tilt positioner Safety cabin extended to 4,800 x 4,800 mm (front x side) Data transmission: OPC UA for Machine Tools Basic (license may be required) EQUIPMENT: Machine: Collision protection KUKA Robot KR 70 Machine status indicator light Compressed air and shielding gas supply Machine designed for ambient temperatures up to 45°C Welding optics Perlator nozzle Welding optics BrightLine Scan Motorized focus adjustment Welding process visualizer Process gas at welding optics Linear nozzle Process gas and crossjet programmable Operation / Programming: KUKA smartPAD Production plan Touch panel with 21.5'' TFT color display Touchpoint user interface Data transfer: USB interface RJ-45 network interface Central Link Remote support interface Online update manager Safety: Work area monitoring Workpiece Processing: Forming gas Further Optional BASE EQUIPMENT: Automatic sliding door Compact dust extractor with 3,000 m³/h Support arm for operator panel Axis adjustment set Robot elevation (extended standard) Data usage agreement TECHNICAL DATA: Type: High Accuracy Robot Number of axes: 6 Rated payload: 70 kg Repeatability: +/- 0.05 mm Rotary-tilt positioner Max. working area: 2,000 x 1,000 mm x 1,200 mm Max. load: 500 kg Rotary table Max. working area: 2,350 mm (diameter) Max. working area (height): 1,150 mm Max. load (per side): 250 kg Rotary changer with turnover axis Max. working area (turnover drum diameter): 1,200 mm Max. working area (length): 2,600 mm Max. load (per side): 750 kg Turnover positioner Max. working area (turnover drum diameter): 2,000 mm Max. working area (length): 4,000 mm Max. load (per side): 1,000 kg Compact rotary changer with 3D clamping plate (rectangular) Max. working area (diameter): 3,000 mm Max. working area (height): 1,250 mm Max. load (per side): 600 kg Max. permissible mass moment of inertia: 600 kg*m² Rotary changer rotation range: +/- 180° Rotary changer rotation time (for 180°): 3.7 s Insert height: 830 mm Compact rotary changer with vertical rotary axes: Max. working area (diameter): 3,000 mm Max. working area (height): 1,250 mm Max. load (per side): 600 kg Max. permissible mass moment of inertia ring indexing table: 600 kg*m² Rotary changer rotation range: +/- 180° Rotary changer rotation time (for 180°): 3.7 s Vertical rotary axis rotation range: +/- 190° Nwsdpfx Agsw U Ezzs Toh Max. permissible mass moment of inertia vertical rotary axis: 359 kg*m² Insert height: 885 mm Compliance with CE and EU Machinery Directive must be verified by the buyer upon recommissioning if applicable. Original price: over EUR 580,000 This used machine can be inspected under operating conditions. All information provided without guarantee – sale excludes all warranties and liability. Subject to prior sale.

Condition: used, Year of construction: 2001, pressure 130 t chamfer lenght 3060 mm distance between columns 2690 mm column arm 410 mm Nwsdpfx Agsyn R Hvs Toh stroke 365 mm dayligth 535 mm ajustment speed 200 mm/sec working feed 1.0 - 10.0 mm/sec return speed 135 mm/sec table width 120 mm table height 1050 mm tiltable up to +/- 10.0 mm Number of working hours ca. 31.800 h compressed air 5.0 - 7.0 bar oil volume 250 l operating pressure 340 bar voltage 400 V total power requirement 23.0 KVA weight of the machine ca. 12950 kg range L-W-H 3660 x 2310 x 2900 mm Equipment: - CNC electro-hydraulic folding/die bending press - DELEM CNC control - swiveling front left * High-resolution graphic screen * Clear, concise menus in the operator's language * Large tools and products library * Graphical 2D programming * automatic bending sequence calculation and collision detection * EMERGENCY stop button at the front - CNC axis adjustment: * Y1 - Y2 - X - R axis CNC crowning * Manual adjustment of the 2x stop fingers, from the front (Z axes) - CNC electro-motorized table crowning - CNC electro-pneumatic die displacement (I axis) - WILA / TRUMPF upper tool clamping - hydraulic - WILA / TRUMPF lower tool clamping - hydraulic - 2x front, robust support arms - movable - 1x freely movable 2-hand/foot control - 1x free-moving foot switch - Lateral safety device (hinged doors) - rear safety device (sliding doors) - original operating instructions ( french )

Condition: excellent (used), Year of construction: 2017, Programmable focusing optics Nwsdpfxjtrl Sgo Ag Tsh Manufacturer: Trumpf Type: PFO 33-2 R1030-1070 HA Year of manufacture: 2017 f: 255 Q γ: 1030 nm D33 Location: Dresden

Condition: used, Year of construction: 2001, functionality: fully functional, operating hours: 38,990 h, Hydraulic Press Brake Manufacturer: TRUMPF Model: TrumaBend V170 Year: 2001 Technical Details Manufacturer: TRUMPF Model: TrumaBend V170 Year of manufacture: 2001 Operating hours: 38,990 h Pressing force: 170 t Bending length: 4080 mm Stroke: 365 mm Frame gap: 3680 mm Table width: 200 mm Throat depth: 410 mm Rapid traverse: 200 mm/s Working speed: 1 – 11 mm/s Return speed: 135 mm/s Connected load: 21.4 kVA Oil capacity: 350 l Dimensions (approx.): L 4.70 x W 2.40 x H 2.98 m Nedpjyvqiuofx Ag Tewh Weight: 18 t Features • DA 2D graphic control • Hydraulic upper and lower tool clamping • Hydraulic WILA tool system • CNC-controlled crowning • Controlled axes: X, R, Y1, Y2 • 4 movable backgauge fingers, pneumatically clamped • Upper tool: 60°/R4, H 195mm, L = 3,850mm, segmented • Lower tool: V16/30°, R 1.6, H 100mm, L = 3,550mm, segmented • Lower tool: V40/80°, R 5, H 100mm, L = 3,100mm, segmented All information without guarantee. A powered demonstration is possible at any time in our showroom.

Condition: as good as new (ex-display), functionality: fully functional, Year of construction: 2022, operating hours: 60 h, +++ Demo machine, approx. 60 operating hours +++ +++ Descending Die +++ Basic machine: TruPunch 3000 large format (S20) Machine: - Box frame - Hybrid axis system - Linear tool magazine with 24 stations for clamps and tools - Hydraulic clamps (3x) - Drives with maintenance-free three-phase motors - Repositioning with programmable presser foot - Foot switch to close clamps - Part chute, right Nsdoxmfc Uopfx Ag Tjwh - Part removal flap, left - Sensor for part removal flap - SortMaster Compact retrofit-prepared Punching head: - Delta Drive - Rotating single-station tool adapter - Programmable presser foot position - Tool length compensation - Punch spray lubrication - Punching slug vacuum - Forming function - Punch stroke counter Control: - TRUMPF control based on Rexroth IndraMotion MTX - Touch panel with 19" TFT color display - Touchpoint - Auto-shutdown - Remote support interface - Program manager - Production plan Data transmission: - Central Link - Online Update Manager Safety: - CE marking and EC Machinery Directive - Double-beam safety light barrier Advanced standard configuration: - First index pin (inside right) - Ball tables - Part chute for finished part container - Chip container to rear for removal Advanced machine and punching features: - MultiTool function - MultiShear function - MultiBend function - Tapping function with thread counter - Forming tap breakage control - Lubricant level monitoring - Unlimited time license - Marking/Quick beading function (option) - Engraving function - Deburring and roller technology function - Adaptive stroke calibration - StripLine - Die spray lubrication with fill level monitoring - Descending Die - Integrated flattening function - Smart punch monitoring - Additional clamp - Height-adjustable clamp - Vibration damping - Chip container removed to front - Brush tables with loading and unloading assistance - Warped sheet detection Technical data TruPunch 3000 large format (S20) Dimensions / Weight: Width: 7644 mm Depth: 7666 mm Height: 2200 mm Weight (fully equipped): 13,800 kg Control / Hardware / Electrics: Hard disk type: SSD Number and size of hard disks: 2 x 120 GB Customer program memory: 10 GB Display: Touchscreen Display size: 21.5 in Interfaces: USB Network: RJ45 Control type: Bosch CML75 Operating system: Windows 10 IoT Axis data: X/Y/C axis drive: NC-controlled, maintenance-free three-phase servo motors Punching head drive: Electric Max. X axis speed: 90 m/min Max. Y axis speed: 60 m/min Max. simultaneous axis speed: 108 m/min Max. C axis speed (punching): 350 rpm Max. C axis speed (tapping): 350 rpm Max. punching stroke rate (E=1mm): 690 1/min Max. marking stroke rate: 1000 1/min Accuracy — positioning deviation Pa: +/- 0.1 mm Accuracy — position range Ps: +/- 0.03 mm Smallest programmable increment: 0.001 mm Working range / Workpiece size: Max. sheet thickness: 6.4 mm Max. workpiece weight: 230 kg X axis working range: 3000 mm Y axis working range: 1550 mm Punch-specific data: Max. punching force: 180 kN Max. presser foot force: 20 kN Max. tool size, punching (outer diameter): 76.2 mm Max. tool size, forming (outer diameter): 101.6 mm

Condition: used, functionality: fully functional, Year of construction: 2013, operating hours: 80,087 h, machine/vehicle number: S2321M0007, control type: CNC control, controller manufacturer: SIEMENS, controller model: SINUMERIK, laser type: fiber laser, laser source manufacturer: TRUMPF, laser source model: TruFiber, laser power: 400 W, Equipment: CE marking, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, safety light barrier, TruLaser Cell 3000 Highly dynamic and precise CNC laser machine solid polymer concrete machine body cantilever axes system 800 x 600 x 400mm travel X-Y-axes with linear motors direct absolute measuring system Z axis with linear guides and ball screw drives TRUMPF control based on SIEMENS Sinumerik 840D sl panel PC for process monitoring integrated switch cabinet and cooling unit water-air incl. start-up and instruction TruFiber 400 Laser equipment compl. TruFiber 400 (G2) Single mode fiber laser for industrial use in welding and cutting: laser power: 400W at fiber end beam quality: M2 1.1 laser light cable: 6m LLK-B operation mode: Cw / modulated max. modulation frequency: 50 kHz Nwodpfx Asyvfuweg Teh pilot laser: standard Trumpf coil feeding unit design tube • Clamping and guiding for coil material • Length up to 800mm • Thickness from 0,1mm to 1,9 mm • Width from 40 to 250 mm • Width adjustment with Handwheel • Cutted parts guidance in a Boxsystem or a funnelsystem • Pneumatic feeding coil 50mm stroke right • Coil feed control
