Used Turning Lathe for sale (9,784)

Condition: good (used), Benzinger TNL NCS1J Lathe  Manufacturer's machine data, deviations possible.  centre height: 80 mm max. turning length 100 mm max. turning diameter over. bed 220 mm max. revolving diameter over. face slide 140 mm max path length in x 300 mm max path length in z 240 mm Mains connection: 380 V 50 Hz Complete factory closure, large selection of storage platforms, pallet racks, shelf racks, paternosters. High-quality industrial machines, lathes, grinding machines, hand machines. Financing through our bank is also possible. komplett-konzept.leasingo.de Bedpsg Icb Esfx Aiyeww Further articles - new and used - you will find in our shop! International shipping costs on request!

Condition: good (used), functionality: fully functional, Technical data: Center height 110 mm Center distance 160 mm Spindle bore 23 mm Motor power 1.7 kW Speed adjustable via potentiometer, approximately 100 – 2,300 rpm 3 preset speeds or 3 gear stages. Bsdpfx Aisz I Dk Rsyeww Equipment: • Operating modes: Manual + Automatic • Pneumatic clamping device • Tilting tailstock with 2 spindles for collet chucks K 12, with switch for changing the direction of rotation (for thread cutting) • Hand lever cross slide with stops, consisting of transverse and longitudinal slides. • Multifix steel tool holder, size A • Collet chuck with collets • Mounting elements and machine light

Condition: used, Year of construction: 2014, 2 Vertical Turning Machines (Tandem) Manufacturer: EMAG Model: VL 3 Year: 2014 Control: Fanuc 31/32i TECHNICAL SPECIFICATIONS FOR THE VL3 MACHINE (Subject to errors and omissions) WORKING AREA Chuck diameter: 170 mm Swing diameter: 210 mm X-travel: 400 mm Z-travel: 200 mm Loading time (depending on clamping device): 2–4 sec MAIN SPINDLE Spindle flange to DIN 55026, size 5 Spindle bearing diameter (front): 80 mm Maximum spindle speed: 7,500 rpm MAIN DRIVE AC asynchronous motor Power at 40/100% duty cycle: 25/16 kW Full power from spindle speed (100% ED): 1,800 rpm Torque at 40/100% duty cycle: 134/85 Nm FEED DRIVE Rapid traverse speed, X axis: 60 m/min Rapid traverse speed, Z axis: 30 m/min Feed force (X and Z): 5 kN Ball screw diameter (X/Z): 40 mm TURRET Cylinder shank mount DIN 69880, 12 positions Shank diameter: 40 mm ELECTRICAL EQUIPMENT according to VDE 0113 Operating voltage: 400 V Control voltage – DC: 24 V; AC: 230 V Frequency: 50 Hz Connected load without/with live tool: 28 / 31 kW Supply line protection: 50 A DIMENSIONS & WEIGHT Length: 2,500 mm Length incl. chip conveyor: 3,600 mm Width: 1,900 mm Height: 2,300 mm Bjdpfx Ajytn Emoiyeww Weight: approx. 5,500 kg Linear roller guides in the X-axis located outside the machining area. GANTRY SLIDE INCLUDING SLIDE GUIDE Motor spindle mounting AC synchronous drives for X and Z axes Encapsulated linear measuring systems Resolution all longitudinal axes: 0.001 mm (absolute measurement) Rapid traverse: X axis 60 m/min, Z axis 30 m/min 1 MOTOR SPINDLE size 5 DIN 55026 Max. speed: 7,500 rpm Power at 40/100% duty cycle: 25/16 kW Torque at 40/100% duty cycle: 134/85 Nm HYDRAULIC UNIT with gear pump. CENTRALIZED OIL SUPPLY for lubrication of ball screws and roller guides COOLING UNIT Controls the machine’s thermal balance. Keeps motor spindle, turret, and control cabinet at ambient temperature. TOOL CARRIER SYSTEM 1 12-STATION TURRET with mounting holes Ø40 DIN 69880 Shortest indexing time via electric motor drive Cooled for consistent accuracy Internal coolant supply to tool in cut position WORKPIECE STORAGE & TRANSPORT SYSTEM 1 CIRCULATING WORKPIECE FEEDER Storage capacity: 27 workpieces (Ø 30–85 mm), or 18 workpieces (Ø 30–130 mm), Max. workpiece height: 100 mm Loading height: 1020 mm Chain-type accumulating conveyor with transport prisms Workpieces are NC-positioned for clamping device take-over. The pick-up spindle retrieves blanks from the conversion-free storage and conveyor system. COOLANT AND CHIP REMOVAL SYSTEM 1 COOLANT SUPPLY with integrated coolant tank, capacity approx. 300 l, coolant filter Coolant pump delivery rate: approx. 80 l/min at 7 bar 1 CHIP CONVEYOR Discharge height: 1,250 mm, hinge belt design 1 EMULSION MIST EXTRACTION from the machining area ADDITIONAL EQUIPMENT AND EXPANSIONS WORKPIECE STORAGE & TRANSPORT SYSTEM 1 INTERFACE FOR EMAG TRANSFER AND FLIP UNIT OP20 COOLANT AND CHIP REMOVAL SYSTEM 1 FLUSHING NOZZLES: 2x in working area, 1x in machine base HYDRAULICS & PNEUMATICS 1 MAINTENANCE UNIT FOR COMPRESSED AIR with mounting 1 PICK-UP DEVICE BLOW-OFF (2 nozzles, WITHOUT maintenance unit – see maintenance unit compressed air)

Condition: used, Year of construction: 2022, CNC CONTROL Controller: FANUC 0i-TF Plus Bsdpfx Aiez N H Nyoyjww CAPACITY Number of controlled axes: 7 (X1/Z1/Y1/X2/Z2/C1/C2) Max. bar diameter mm: ø 20 Max. machining length with guide bushing mm: 210 Rapid traverse m/min: X1/Y1: 24 / Z1/X2/Z2: 32 MAIN SPINDLE Max. spindle speed rpm: 10.000 Spindle power kW (S1/S6): 2,2 / 3,7 Max. drilling diameter (main spindle) mm: ø 10 Max. tapping (main spindle): M10 BACK SPINDLE Back spindle max. speed rpm: 12.000 Back spindle power kW (S1/S6): 1,5 / 2,2 Max. chucking diameter (back spindle) mm: ø 20 Max. drilling diameter (back spindle) mm: ø 8 Max. tapping (back spindle): M8

Condition: excellent (used), For sale is a set of steady rests for a Schaublin 150 lathe. Very good condition. Includes a set of 3 roller jaws. Price is for the complete set. Shipping available or collection in 5023 Salzburg. Bwjdpfx Ajy Rdaieiyjw

Condition: used, L + Z Lathe WAFUM Type TUD 40 Bsdpfx Asw Uf Hwsiyeww Machine no. No. 35689 Year of construction 1975 Center width 1500 mm Turning diameter over bed Ø 440 mm Center height above bed 220 mm Center height above support Ø 125 mm Spindle bore Ø 56 mm Spindle speed 18 - 1800 rpm 36 steps Chuck flange short taper DIN 55027 size 6 Inner tailstock taper MK 5 Drive power 4 and 6.7 KW - Spindle speed via 2 motor speeds and 18 gear stages - 3-jaw lathe chuck Ø 315 mm BISON with 2 sets of chuck jaws (lathe and drilling jaws) - MULTIFIX size B quick-change steel holder with 2 interchangeable cassettes - Fixed lynette with plain bearing inside Ø 125 mm - Moving lynette with plain bearing inside Ø 100 mm - Guide rail for turning slim cone with automatic longitudinal feed - 1 piece rotating center point - Hinged chuck guard Space requirement L x W x H 3100 x 1200 x 1450 mm weight 3000 kg good condition

Condition: good (used), Year of construction: 2012, 780mm Swing, Bwodpfxo Aggfbe Aiyjw 630mm Swing over the Cross-Slide, 481mm Max Cutting Diameter, 790mm max cutting length, 12 Station Turret, 76mm bar capacity, 3500rpm, 22kW Spindle, Fanuc i, Tool setter, 10” 3 jaw chuck, Low Volt Light, Tailstock, Swarf Conveyor,parts catcher, Coolant.

Condition: excellent (used), Year of construction: 2018, Technical Data Main spindle, counter spindle Turning length: mm 660 Spindle bore: mm 65 Chuck diameter: mm 165 Speed max.: min-1 6,000 Power (100% / 40% duty cycle): kW 20 / 24 Torque (100% / 40% duty cycle): Nm 125 / 170 C-axis resolution: degrees 0.001 Slide travel X: mm 710 Rapid traverse: m/min 60 Feed force: N 6000 Turret, lower / upper Speed max.: min-1 7,200 Power max.: kW 9 Torque max.: Nm 16 Milling spindle Tool system: HSK-A40 Speed max.: min-1 7,200 Torque (25% duty cycle): Nm 52 Power (25% duty cycle): kW 22 Tool holder 1 Slide travel X: mm 230 Rapid traverse: m/min 30 Feed force: N 6000 Slide travel Y: mm +/-65 Rapid traverse: m/min 15 Feed force: N 10,000 Slide travel Z: mm 845 Rapid traverse: m/min 50 Feed force: N 6000 3 Turrets Turret 1 YB - 6-position tool changer HSK Turret 2 Y Turret 3 y Year of manufacture 2018 Control system Siemens SINUMERIK 840D sl Turning length up to 660 mm Spindle bore 65 mm Milling spindle with 360-degree B-axis Production hours approx. 7,200 h Turret, lower and upper Feature Specification Stations and tool positions 14 stations per turret (VDI 25), a total of 42 tool positions Maximum speed 7,200 min⁻¹ Maximum power 9 kW Maximum torque 16 Nm Milling spindle Feature Specification Tool system HSK-A40 Tool magazine 6 tool positions B-axis 360 degrees Maximum speed 7,200 min⁻¹ Torque at 25 percent duty cycle 52 Nm Power at 25 percent duty cycle 22 kW Tool holder 1 Feature Specification X-axis 230 mm, rapid traverse 30 m/min, feed force 6,000 N Y-axis ±65 mm, rapid traverse 15 m/min, feed force 10,000 N Z-axis 845 mm, rapid traverse 50 m/min, feed force 6,000 N Tool holder 2 Feature Specification X-axis 140 mm, rapid traverse 30 m/min, feed force 6,000 N Y-axis ±45 mm, rapid traverse 15 m/min, feed force 10,000 N Z-axis 810 mm, rapid traverse 50 m/min, feed force 6,000 N Workpiece removal Feature Specification Design Gantry part removal system with conveyor belt Maximum workpiece length 200 mm Maximum workpiece weight 5 kg Bedpfx Aiez Sywcsyeww Dimensions and connection values Feature Specification Length × Width × Height 5,355 × 2,235 × 2,400 mm Weight approx. 8,500 kg Connected power 42 kW Bar feeder magazine and accessories Feature Specification Bar feeder magazine INDEX MBL 65 Coolant system KNOLL system with band filter and high-pressure pump 80 bar Automation Automatic door Accessories Tool holder

Condition: like new (used), LATHE FOR WORKSHOP USE For sale: a HAGER HDE-59 BIG lathe with a distance between centers of 1,000 mm. This lathe, which was used in a workshop setting, is in excellent condition. Technical data: - Motor: 2.2 kW / 3 hp / 400 V - Speed ranges: 100-450 rpm Bsdpfxsz Ngb Ns Aiyjww 300-1,100 rpm 750-2,700 rpm - Center height: 250 mm - Distance between centers: 1,000 mm - Tool rest: 350 mm - Direction of rotation switch - Spindle: M33 x 3.5 mm with ASR (Euro) safety slot - Spindle and tailstock taper: MK3 - Hollow spindle diameter: 20 mm - Main spindle: 4-bearing - Quill travel: 150 mm (with scale) - Overall length: 1,780 mm - Weight: 235 kg The machine is located in A-5431 Kuchl and can be inspected at any time during our opening hours. Subject to prior sale! Related terms: lathe, turning machine, turning lathe, wood turning lathe, turning, lathe tools, woodturning, turning, machine, Hager Reference: R-A0117

Condition: ready for operation (used), Year of construction: 2001, operating hours: 2,609 h, functionality: fully functional, machine/vehicle number: 586034, center width: 3,010 mm, swing diameter over cross slide: 310 mm, quill stroke: 160 mm, spindle speed (max.): 2,800 rpm, No minimum price – guaranteed sale to the highest bidder! Submitting a bid obligates you to collect the item within the specified timeframe between December 1, 2026, and December 10, 2026! TECHNICAL DETAILS Bwsdpfx Aie Ahny Njysw Center distance: 3,010 mm Diameter of rotation over the compound slide: 310 mm Diameter of rotation: max. 580 mm Travel of the compound slide: 265 mm Spindle diameter in the front bearing: 120 mm Material passage: max. 72 mm Chuck diameter: 250 / 315 mm Spindle speed: 3–2,800 rpm Tailstock Outer diameter of the quill: 75 mm Quill travel: max. 160 mm Quill mounting: MK 5 MACHINE DETAILS CNC control: Siemens Operating voltage: 400 V Frequency: 50 Hz Connected power: 16 kVA Rated current: 25 A Dimensions & Weight Dimensions (L x W x H): 8,000 x 1,800 x 2,000 mm Machine weight: 5,000 kg Operating hours (meter reading): 2,609 h EQUIPMENT Chip conveyor Workshop cabinet Machine documentation External reference: Frankenthal - Lot 396

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, overall weight: 1,650 kg, 2 machines and bar feeders are for sale STAR Micronics SB-16 Type C 480 – CNC long-turn lathe CNC long-turn lathe from STAR Micronics, manufactured in 2007, equipped with a FANUC CNC control, main spindle and counter spindle, as well as powered tools. The machine features an FMB bar feeder magazine. - Manufacturer: STAR Micronics - Model: SB-16 Type C 480 - Machine type: CNC long-turn lathe - Year of manufacture: 10/2007 - Control: FANUC Series 18i-TB - Maximum bar diameter: 16 mm - Main spindle: Present - Counter spindle: Present - Powered tools: Present - Machine weight: approx. 1,650 kg Equipment: - FANUC CNC control - Main and counter spindle - FMB Turbo 2-18 bar feeder magazine Technical specifications based on previous machine research. Errors, changes and prior sale reserved. Bwodpfe Ahyztjx Aiysw

Condition: used, Year of construction: 2016, machine/vehicle number: 179057920, type of input current: three-phase, input voltage: 400 V, input frequency: 50 Hz, input current: 65 A, No minimum price – guaranteed sale to the highest bidder! Bwodpfozy Ukzex Aiyjw The machines are still assembled, but disconnected from the power supply. An 11-ton forklift is available on site for loading. For sale is a vertical turning lathe manufactured by WEISSER, model: Vector C-1R. TECHNICAL DETAILS Year of manufacture: 2016 Three-phase operating voltage: 400 V AC Frequency: 50 Hz Control voltage: 24 V DC Magnet voltage: 24 V DC Rated current of the machine: 65 A Main connection fuse: 100 A, time-delay

Condition: ready for operation (used), functionality: fully functional, Brand: KDM Model: KTM-12/16 Category: CNC vertical turning centers Year of construction: installed in September 2014 CNC control: FANUC Series 0i-TD Machining capabilities: - Maximum turning diameter: 1,600 mm - Maximum turning height: 1,300 mm - Table/chuck diameter: 1,250 mm - Hydraulic chuck diameter: 1,250 mm - Maximum table load: 6,000 kg - Distance from table surface to spindle nose: 1,205 mm Rotary table with C-axis: - Table rotation speed: 1–350 rpm - Gear range: 2 gears - Low range: 1–87.5 rpm - High range: 1–350 rpm - C-axis rotation speed: 0–2 rpm - Minimum C-axis indexing: 0.001° - Maximum table torque: 19,100 Nm RAM head with motorized spindle: - X-axis travel: -250 / +1,480 mm - Z-axis travel: 1,000 mm - Motorized spindle speed: 10–2,500 rpm Bjdpfj Af I U Tsx Aiyeww - Spindle gear range: 2 gears - Low range: 10–625 rpm - High range: 10–2,500 rpm - Spindle mounting: ISO 50 (7/24 no. 50) - Tool holder type: DIN 69871 - RAM section: 240 × 240 mm - External tool section: 40 × 40 mm Tool magazine: - Tool magazine capacity: 24 positions - Tool holder mounting: ISO 50 – DIN 69871 Equipment and accessories: - 6-jaw hydraulic chuck AUTOBLOK, diameter 1,200 mm - 6 original machine jaws included - RAM head with motorized spindle for milling and drilling operations - C-axis with minimum indexing of 0.001° - RENISHAW workpiece measuring probe - Tool presetting system - 24-position automatic tool magazine

Condition: ready for operation (used), Year of construction: 2016, operating hours: 23,500 h, functionality: fully functional, machine/vehicle number: 8107000021B, spindle bore: 32 mm, spindle speed (max.): 8,500 rpm, overall weight: 4,300 kg, controller model: FANUC 32i MB, bar length: 3,200 mm, DMG MORI GILDEMEISTER SPRINT 32/5 – Short/Long Turning Automaton Well-maintained machine, low operating hours, including IEMCA BOSS 338/32 HD bar feeder (up to 3,200 mm bar length), year of manufacture 2016, as well as a conversion kit to a long turning automaton (Swisstype kit) for short and long turning on a single machine. Delivery terms: Free on truck Availability: Immediate - subject to agreement NOTE: The machine must be picked up on a fixed date in mid/late October 2026; we will provide the exact date in advance! Technical data: Control: FANUC 32i MB Operating hours recorded: 25,263 Spindle hours recorded: 22,772 MAIN SPINDLE DATA: Max. turning diameter: 32 mm (guide bushing bore: 38 mm) Stroke Z1: 100 mm Max. speed: 8,500 RPM Drive power S1: 5.5 kW TAILSTOCK SPINDLE DATA: Max. turning diameter: 32 mm (guide bushing bore: 38 mm) Stroke Z2: 200 mm Max. speed: 8,500 RPM Drive power S1: 2.2 kW AXIS DATA X1: Travel: 70 mm Max. speed: 40 m/min Max. acceleration: 5 m/s² AXIS DATA Y1: Travel: 405 mm Max. speed: 30 m/min Bjdpfx Ajz A Tbuoiyoww Max. acceleration: 5 m/s² AXIS DATA X2: Travel: 300 mm Max. speed: 40 m/min Max. acceleration: 5 m/s² TOOL HOLDER DATA – SLIDE 1: Tool holder diameter: 25 mm Number of fixed tools for external machining: 6 Tool holder size: 16 × 16 mm Number of driven tools: 4 Collet type: ESX20 TOOL HOLDER DATA – SLIDE 2: Number of fixed tools for internal machining: 4 Tool holder diameter: 25 mm Scope of delivery: IEMCA BOSS 338/32 HD bar feeder (up to 3,200 mm bar length), year of manufacture 2016 Chip conveyor Available manuals Accessories as shown in the pictures Dimensions & Weight Footprint (L x W x H): approx. 7500 x 1600 x 2500 mm Weight: approx. 4300 kg Attention: Disc damaged! If you have any questions or would like to arrange a viewing, please do not hesitate to contact us! Additional notes: ► Upon request, we can offer transport to your destination. ► The goods are sold without any warranty. ► Technical data is subject to change.

Condition: good (used), Year of construction: 2018, functionality: fully functional, The equipment is as shown in the pictures. All tools visible in the pictures are included. Bwedpfsx Na Slsx Aiyew

Condition: used, SMT Lathe 80001350 The machine was designed and manufactured to produce rotor shafts for electric power tools. Bjdpfxehw Emqe Aiyjww The machine was designed and manufactured to automatically perform the following operations: - Automatic loading/unloading of parts from/to the tool carrier line, using a pick-and-place unit between the shaft ends. - Turning of the ring seat + milling of the commutator + turning of the commutator. - Ring assembly - commutator side - Ring assembly - drive wheel side The machine has several production programs for manufacturing different parts. Each program clearly corresponds to a specific shaft type. Technical data Anchor shaft length from 92.5 - 163.1 mm Bearing journal diameter, commutator side: 8; 10; 12.5 mm Drive side: 12; 8 mm Min. available length of bearing location: 3.6 mm Package diameter: 52; 55; 59 mm Ring dimensions Outer diameter: 40 - 57.4 mm Inner diameter: 37.4 - 56 mm Ring width: 4 - 8 mm Ring seat diameter: 44 - 50 mm Surface roughness of the ring seat: Rz 20 mm Main dimensions and weight of the machine Machine length: 2870 mm Machine width: 2600 mm Machine height: 2530 mm Machine weight: 5000 kg Electrical installation Rated current: 10 A Rated voltage (AC): 400 V Rated power: 7 kVA Rated frequency: 50 Hz Pneumatic installation Nominal pressure: 5 bar Maximum pressure: 10 bar You can find more items – new and used – in our shop! International shipping costs available upon request!

Condition: used, BIGLIA B 470/YSM is a CNC turning lathe engineered for precision machining, delivering high accuracy and reliable performance. Capacities: turning diameter 210 mm, bar diameter 65 mm, turning length 300 mm, Y axis 110 mm; two turret slides (2) with 12 positions each and 12 driven tools per turret. Key specifications: max speed 4000 t/min; power of back spindle 11 kW; spindle motor 26 kW; voltage 50 Hz 3x 400 Volt; machine weight about 6150 kg; time under power 74536 Heures, operating time 24651 Heures, working time 8588 Heures. Accessories: bar feeder LNS HYDROBAR SPRINT. Capable of achieving tight tolerances; suitable for automotive, aerospace, medical, watchmaking and machine tool industries Bjdpfxjzqbh Ij Aiyjww

Condition: good (used), Technical specifications: * Over bed – 270 mm * Center height – 125 mm * Maximum distance between centers – 500 mm * Spindle bore – 28 mm * Collet type B32 * Longitudinal travel of the carriage – 440 mm * Cross travel – 130 mm * Travel of the small tool-holding carriage – 90 mm * Travel of the tailstock sleeve – 100 mm Bedpfx Aie Afu Injysww Equipment: * 3-jaw chuck, 125 mm diameter * Multifix A turret * 3 Multifix A tool holders * Quick-change tool system * 1 steady rest * 1 rear carriage

Condition: used, Year of construction: 2011, STAR ECAS-20 — CNC SWISS-TYPE AUTOMATIC LATHE MACHINE IDENTIFICATION — VERIFIED FROM NAMEPLATE Manufacturer: Star Micronics Co., Ltd., Japan Model: ECAS-20 Type: 570 Manufacturing date: March 2011 Serial number: 0509 Lot number: 047 Supply voltage: AC 200 V, three-phase Frequency: 50/60 Hz Rated apparent power: 8.0 kVA Machine weight: 3,500 kg CE marking: Present MODEL SPECIFICATIONS — MANUFACTURER DATA Configuration: 10 axes; independent front/back machining; simultaneous two-tool turning Control system: Star Motion Control System Maximum machining diameter: 20 mm Headstock stroke: 205 mm MAIN AND SUB-SPINDLES Maximum speed: 10,000 rpm each Motor output each: 2.2 kW continuous / 3.7 kW for 30 minutes C-axis indexing: 0.01° each Sub-spindle chucking diameter: 20 mm Front-ejection length: 80 mm Bjdpfx Aioz D Ezvjysww Workpiece projection: 30 mm TOOLING Turning positions: 4 front, 2 rear Tool shank: 12 mm; optional 16 mm Sleeve-holder positions: 4; optional 2 rear-end stationary tools Stationary drilling: Ø10 mm Tapping/die-cutting: M8 × 1.25 Optional driven positions: 3 front, 3 rear Driven-tool speed: 8,000 rpm Driven-tool motor: 0.75 kW Driven drilling: Ø8 mm Driven tapping: M6 × 1.0 Milling: Ø10 mm Slotting: 1.5 mm wide × 4 mm deep BACKWORKING Tool positions: 4 Drilling, stationary/driven: Ø10/Ø8 mm Tapping, stationary/driven: M8 × 1.25 / M6 × 1.0 CAPACITY AND DIMENSIONS Coolant tank: 120 litres Machine dimensions (W × D × H): 2,588 × 1,150 × 1,765 mm Overall installation dimensions with peripherals: Unconfirmed EQUIPMENT VISIBLE IN PHOTOGRAPHS Bar-feeding equipment with pendant control Fire-suppression cylinder and automatic CO₂ warning label CNC operator panel

Condition: excellent (used), Year of construction: 2014, Automatic Lathe Citizen M32 Manufacturer: Citizen Machinery Co. Ltd Model: M32-4M5 Year of manufacture: 2014 Country of origin: Japan Machine weight: 3,550 kg Maximum machining diameter: 32 mm Max. machining length: 320 mm with one chuck Main spindle speed: 200–8,000 rpm Main spindle indexing: 1° C-axis resolution (spindle): 0.001° Counter spindle speed: 200–8,000 rpm Max. clamping diameter of counter spindle: 32 mm Max. drilling diameter front side: 12 mm Max. tapping diameter front side: M10 Max. tapping diameter rear side: M10 Spindle through-hole diameter: 37 mm Number of tool positions: up to 25, depending on configuration Rapid traverse X/Y/Z axes: up to 32 m/min Bar length: 2,500 mm Coolant tank capacity: 198 l Compressed air requirement: 0.5 MPa Noise level: Ø580 dB(A) Memory size: 5120 m, 2048 kB Minimum input increment: 0.1 µm Interface: RS232C Number of programs: 63 Tool offsets: 32 pairs X1 travel: 108 mm Y1 travel: 347 mm Z1 travel: 325 mm X2 travel: 120 mm Y2 travel: 44 mm Z2 travel: 212 mm Bwedpfx Aijydaadeyew X3 travel: 313 mm Z3 travel: 430 mm A3 travel: 150 mm A4 travel: 1,500 mm No guarantee is made for the accuracy, completeness or timeliness of the information provided.

Condition: used, Year of construction: 2019, Technical details: bar material dia.: 38 mm turning length: 350 mm turning speeds: 7.000 / 7.000 U/min number of tools: 30 (3 x 10) driven tools: ja / yes control: FANUC 31i-B5 rapid traverse: 30 m/min total power requirement: 10,5 kVA weight of the machine ca.: 6,5 t dimensions of the machine ca.: 2,50 x 1,45 x 1,75 plus Lademagazin m work piece power: 4 kW toolpiece turning speed range: 5.700 1/min Accerories main spindle power 11 kW sub spindle power 7,5 kW CNC sliding headstock machine STAR ST 38, 3 turrets, 12 CNC Axis (X1/Z1/Y1/C1/X2/Z2/Y2/YA2/C2/X3/Z3/Y3, Fireextinguisher KRAFT und BAUER FB 703, partscatcher and conveyor belt (for long parts), LTA oilmist suction, chiller for oil, machining with oil as coolant, reading hours: approx. 14.500 hours "machine on", approx. 4.100 hours "machining" Bwodemu Rtuspfx Aiyjw *

Condition: like new (used), CNC Swiss-type lathe Weco S 206 E II Machine Bar feeder Tools Bsdpey A Sghefx Aiyoww The machine has 7,000 operating hours

Condition: like new (used), Year of construction: 2027, TECHNICAL DATA: Turning diameter 2000 mm Max. workpiece height 1200 mm Max. workpiece weight 8000 kg Faceplate diameter 1800 mm Faceplate speed range / 4 automatic stages 0-210 rpm Bwjdpfx Aisf S Hcyjyjw Max. faceplate torque 31500 Nm Main drive power 55 kW EQUIPMENT: - 4-position turret or tailstock with 2 Capto clamping units - Central lubrication system SKF/VOGEL - Commissioning including training - 12 months warranty - Complete electrical equipment 230/400 V, 50 Hz, Made in Germany, CE standard OPTIONS: - Steel chucks - Tool changing system (10 positions) - Machine enclosure - Chip conveyor - Coolant preparation - Side support - Machine version with tailstock and 2x Capto C6 - ... CONTROL: CNC cycle control Fagor 8037TC/8055TC* or Siemens OTHER: CE Declaration of Conformity Geometrical acceptance test according to DIN 8609-2

Condition: used, Year of construction: 2007, functionality: fully functional, spindle speed (min.): 8,000 rpm, Long-turning lathe with a 10-station turret! Equipped with an FMB Turbo 3-36 bar feeder! TECHNICAL DETAILS Turning length: 320 mm Spindle speed (min.): 8,000 rpm Bar diameter: 32 mm Maximum drill diameter (front): 12 mm Maximum thread drilling size (front): M12 Rear spindle speed: 8,000 rpm Number of tools: 25 to 27 MACHINE DETAILS Dimensions & Weight Dimensions (W x D x H): 2,860 mm x 1,465 mm x 1,900 mm Weight: 4,300 kg EQUIPMENT 10-station turret Rotating tools for complex machining tasks FMB Turbo 3-36 Bsdpfxs Agnnkj Aiyoww

Condition: good (used), Lathe SCHAUBLIN 102N80, serial number 277444. Bodpfeztc Dvjx Aiysww
