Tool Room Milling Machine - Universal

AVIA FNE 40 NC / TNC 320

Condition: used, Year of construction: 2018, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 510 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, nominal power (apparent): 9 kVA, torque: 82 Nm, controller manufacturer: Siemens, table width: 560 mm, table length: 900 mm, table load: 600 kg, rotational speed (max.): 12,000 rpm, overall weight: 5,200 kg, number of spindles: 1, number of slots in tool magazine: 60, mount diameter: 40 mm, Equipment: chip conveyor, documentation/manual, Vertical machining center DMG MORI SLIMline Multi-Touch Control Table size: 900 x 560 mm Table load capacity: 600 kg Iodjw Ei E Hopfx Aa Ieia Direct path measuring system X, Y, Z SK 40 spindle taper 20 bar internal coolant supply 60-position tool changer Chip conveyor Renishaw probing kit for SIEMENS control

Condition: used, Year of construction: 2012, x-travel 850 mm y-travel 700 mm z-travel 500 mm Control Siemens 840 D rotary table 800 mm c-axis 0.001º ( ±360º) 0 B-axis (table) º mm number of spindle speeds 18.000 U/min/rpm tool taper HSK 63 Tools changer 38 fach/tools Internal cooling system 80 bar total power requirement 43 kVA weight of the machine ca. 10,6 t Equipment- Paper belt filter – 200 l tank- Active control cabinet cooling- Infrared probe M&H (Heidenhain)- Laser tool measuring system Blum- Chip conveyor- Cleaning pistol with pump 2 bar / 40 l min- 3D Quick Set- Electronic handwheel Iiodpfx Aoyxy E Rsa Isa

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, Tool Milling Machine Kunzmann WF4/3 with Heidenhain TNC 320 CNC Control – Excellent Condition, CE-Compliant, from Training Workshop! Technical Specifications: • Year of manufacture: 2010, Machine No. 347283 • Fixed angular table • Infinitely variable spindle speed up to 4,500 rpm • Infinitely variable feed in 3 axes from 0 to 2,000 mm/min • Rapid traverse X and Y axis: 5,000 mm/min Z axis: 4,000 mm/min • Travel X/Y/Z: 400/350/400 mm • Table size: 650 x 350 mm • Table load capacity: 250 kg • Vertical quill stroke: 60 mm • Vertical and horizontal quill – SK40 taper • Hydraulic clamping system • Weight approx. 1,800 kg • Space requirement approx.: 2.3 x 2 x 2 m Ijdpfxexuppuj Aa Ieia • Drive power: 15 KVA Accessories and Equipment: • Heidenhain TNC 320 CNC control • Hydraulic clamping, vertical and horizontal • Automatic central lubrication • Spindle brake • Technical documentation, spare parts diagrams, control manuals and programming examples • Handwheels • Coolant system • Electronic handwheel HR410 About the Machine: Offered for sale is a Kunzmann WF4/3 tool milling machine with Heidenhain TNC 320 CNC control. This universal milling machine is in excellent condition and has seen very few operating hours. It comes from a facility where it was used exclusively for training purposes. The control is very user-friendly. Additionally, the machine features hydraulic clamping both vertically and horizontally. Changing from vertical to horizontal operation is very straightforward by swinging away the vertical head. The ways are regularly lubricated via the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. You are welcome to view and test the Kunzmann on-site under power. There are 7 units of Kunzmann WF4/3 with the TNC 320 Heidenhain milling machines available. The machines are available immediately.

Condition: used, Year of construction: 2013, turning diameter . mm turning length 2000 mm control Siemens 840 D sl mainspindle: turning speed max. 3800 1/min mainspindle: torque max. 1200 Nm diameter of quill 140 mm center point MK6 quill power 5 - 30 kN feed rate Z-axis mm/min rapid traverse Z-axis 40 m/min feed rate X-axis - mm/min rapid traverse X-axis 25 m/min Iodpfxjvu E R Ss Aa Ioia total power requirement 125 kW weight of the machine ca. 20 t The machine can still be inspected under power at the production plant. The condition of the machine is good, the accuracy during turning operation is very good. The milling drive is not functional. A quotation from Niles for the repair of the milling drive is available on request. Including hydraulic steady rest.

Condition: good (used), Year of construction: 2001, Gildemeister NEF 520 CNC Lathe TECHNICAL DATA Iiedpfswftvisx Aa Ija Working Area Swing over bed: 500 mm Swing over cross slide: 290 mm Chuck diameter: 250 mm Cross travel: 260 mm Center distance: 850 / 1350 mm Turning Spindle Spindle head DIN 55027 Size: 8 Spindle bore diameter: 70 mm Spindle mount: metric 80 Spindle diameter in front bearing: 120 mm Main drive AC Drive power: 12 kW Max. torque: 920 Speed range: 10 – 3000 rpm Gear ratios: 2 Switchable speeds: Continuously variable Feed drive X-feed force: 5000 N Z-feed force: 10000 N X-rapid traverse: 8 m/min Z-rapid traverse: 10 m/min Multifix tool carrier; Size: C Tailstock Quill diameter: 80 mm Quill stroke: 180 mm Quill mount: MK5 Dimensions L x W x H: 2900 x 1953 x 1825 mm Weight: 2700 kg SCOPE OF OFFER INCLUDES (list not exhaustive): Gildemeister lathe SMW Autoblok Hi-Grip high-precision chuck Chuck jaws Multifix tool holder Complete operating documentation Exact scope of offer as shown in the photo gallery We assume no liability for the accuracy, completeness, or timeliness of the information provided.

Condition: like new (used), Year of construction: 2001, operating hours: 10,356 h, travel distance X-axis: 1,800 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,100 mm, nominal power (apparent): 44 kVA, controller manufacturer: Heidenhain TNC 430, workpiece weight (max.): 5,000 kg, total height: 4,200 mm, total length: 7,900 mm, total width: 8,800 mm, spindle speed (min.): 10,000 rpm, Year of construction: 2001 CNC controller: Heidenhain TNC 430 Axes X-axis travel mm: 1800 Y-axis travel mm: 2000 Z-axis travel mm: 1100 C-axis degrees: 360º (0,001) B-axis degrees: -7/+187º Feed rates m/min: 60/40/40 Rapid traverse m/min: 60/40/40 Milling/turning table nc: Table dimensions mm: Ø1700x1400 Max. workpiece weight kg: 5000 Table rotation speed rpm: 200 Spindle Spindle speed rpm: 10000 Spindle drive power kW: 44/32(40%ED/cont) Spindle torque Nm: 288/187 (40/100%ED) Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 900 Tool system Tool holder: HSK-A 100 Tool magazine slots: 60 Tool changer: Double gripper Chip-to-chip time s: 13.5 Equipment Electronic Handwheel Iiodeyq Rpcepfx Aa Isa Chip conveyor Infrared probe Internal cooling lubricant supply Rotating inspection windows Rinsing gun Operating mode 4 Tool breakage probe Machine running times Under power: 132612 Spindle Working: 68009 Basic machine dimensions / weight Length mm: 7900 Width mm: 8800 Height mm: 4200

Condition: like new (used), Year of construction: 2021, functionality: fully functional, Weiler Praktikant VCD Precision Lathe (2021) Manufacturer: Weiler Model: Praktikant VCD Precision Lathe Year of manufacture: 2021 Condition: Used, excellent, like new, incl. new maintenance and measurement protocol prior to sale Centre distance: 650 mm Centre height: 160 mm Swing over bed: 320 mm Swing over cross slide: 190 mm Cross slide travel: 150 mm Top slide travel: 110 mm Top slide swivel range: +/-65° Bed saddle guideway length: 350 mm Bed width: 205 mm Tool shank cross-section (H x W): 20 x 20 mm Height from top slide to turning centre: 30 mm Spindle head according to ISO DIN 702-3 (DIN55027) size 5 Spindle diameter in front bearing: 70 mm Spindle bore: 43 mm Main spindle taper metric 50 Drive power: 6 kW Speed range: 30 – 4,000 rpm Number of gear stages: 1 Number of speeds: stepless Number of feeds: 24 Longitudinal feed: 0.02 – 0.63 mm/rev Facing feed: 0.006 – 0.2 mm/rev Quill diameter: 40 mm Quill stroke: 85 mm Quill taper: 3 Morse taper Weight, without packaging and accessories: approx. 1,150 kg Dimensions (L x W x H), net: 1,720 x 890 x 1,700 mm Headstock / Rear cover / Sliding guard: Light grey RAL 7035 Machine base / Machine bed: Basalt grey RAL 7012 Isdpfx Asx Ivy Nea Ieia Display housing: Blue NCSS 4550-R80B

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, The positions of the rotating tools are: T01-02-03-04 / T22-23 / T34-35 - equipped with Iemca Boss 332E/32 new in 2006 - lot of collets / guide bushes - MSC-501 Control - the machine has always worked with oil. Iiodpswpu Etefx Aa Ioa

Condition: used, Year of construction: 2009, travel -x axis 600 mm travel -y axis 450 mm travel -z axis 450 mm control HEIDENHAIN - TNC 530 number of spindle speeds 18.000 U/min tool taper HSK-A63 numbers of positions in the tool changer 120 5-axis simultaneous machining center | HERMLE - C 20 U equipped with ITC (80 bar), NC swivel rotary table, 120-way tool changer & pallet changer. Iodpfx Aoyy A N Usa Ieia The machine is in a well-maintained condition and can be inspected under power at any time in the Swiss factory location. The machine videos from the production plant will be shared on request. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: C 20 | C20 | C-20 | C20U

Condition: ready for operation (used), Year of construction: 2011, Travel X/Y/Z: 1000mm/500mm/635mm, tool holder: BT40, spindle speed: 10000rpm, tool positions: 40, control: Haas, spindle hours: approx. 4500h. 3-axis robot System 3R WorkPartner, year of manufacture: 2005, transfer weight: 80kg, stroke: 1500mm, pallet positions: 20. Including System 3R GPS 240 zero-point clamping system, tool measurement, tool breakage control, Renishaw 3D probe, and oil mist extraction. Documentation available. An on-site inspection is possible. Iodpfx Aasxg Rias Isia
