Rapid Radial Drilling Machine

DONAU Danuflex 135

Condition: good (used), Year of construction: 1994, machine/vehicle number: 133120, Offer 24506 Dkjdpfx Aewndydsbueh Technical data: - Drilling capacity in solid steel ST 60 35 mm - Drilling capacity GG 25 42 mm - Thread cutting ST 60 M 30 - Thread cutting GG 25 M 36 - Drill spindle mount MK 4 - Quill stroke 170 mm - Drill spindle speeds stepless 20 - 3200 rpm - Drill feeds stepless 0.02 - 0.70 mm/rev - Drilling radius approx. min. / max. 490 / 1240 mm - Swivel angle 330° - Table size 1200 x 620 mm - Table height 900 mm - Motorized height adjustment / drill column stroke 450 mm - Hydraulic column + jib clamping - T-slots vertical on the left machine side - Coolant device - Drive 400 V / 5.0 kW - Space required approx. W 1500 x H 2600 x D 1700 - 2500 mm - Weight approx. 2100 kg

Condition: like new (used), Year of construction: 2021, Technical data: Conical bending machine Dodow An Uhjpfx Abuekh Working width: 1050 mm Max. bending capacity for standard steel St40: 4.0 mm Diameter of conical upper roller: 70 - 185 mm Diameter of side and central lower rollers: 105 mm Conical bending device Mobile control panel with digital display Hydraulic folding bearings CE marking Motor power: 5.5 kW Dimensions (length x width x height): approx. 3600 x 1200 x 1200 mm Net weight: approx. 3 tonnes Condition: Very little used, as new condition The seller is not liable for typing or data transmission errors. The machine is in appearance, technology and wear consistent with its age; used machines are sold without any warranty.

Condition: new, Year of construction: 2024, travel distance Y-axis: 600 mm, travel distance Z-axis: 450 mm, - Simple graphic programming, including GoTo function in manual mode - Machining lengths from 3000 - 16500mm, depending on version - Free programming in DIN/ISO (G commands) - 2-axis interpolation for X/Y-axis, including arcs - 3-axis linear interpolation (X/Y/Z) - 3-axis interpolation (X/Y/Z) for helical milling and thread milling - Rapid traverse X-axis = 30 m/min., Y-axis = 25 m/min. Main spindle BT 40 - 5 bearings, diameter 110/60 mm (3x angular contact ball bearings 7212, 2x deep groove ball bearings 6212) - Suitable for both high axial and radial loads = drilling and milling - Maximum tool length : 290 mm Dsdporb Afaofx Abuokh - Maximum tool diameter : 88 mm Guide X-axis - 2 pieces 45 mm linear guides with 2 full ball bearing carriages each X-axis drive - helical precision rack, travel 3,000 to 16,500 mm Y-axis guide - 2 35 mm linear guides, each with 2 fully spherical carriages Y-axis drive - Ball screw diameter 25 mm, travel 600 mm Z-axis guide - 2 35 mm linear guides, each with 2 fully spherical carriages Z-axis drive - Ball screw diameter 32 mm, travel 450 mm Standard version Automatic tool changer with 10 positions, mounted in the machine column

Condition: excellent (used), Year of construction: 2019, ROTOTHERM REC1280 Rotary Oven, Gas-Fired The Rototherm oven with a rotary rack is designed for baking: – bread – tin/toast bread – buns/rolls – small pastries Technical specifications: Rotary wheel diameter: 1260 mm Max tray size: 600 x 1000 mm Baking surface with 21 shelves: 12.6 m² Max rotary plate load: 350 kg Baking chamber height: 1830 mm Max rack height: 1813 mm Minimum room height: 2830 mm Dimensions (W/D/H): 1740 x 1900 x 2400 mm Net weight: 2400 kg NAVIGO II control: yes The ROTOTHERM Green rotary oven by Werner & Pfleiderer is a new-generation rotary oven providing up to 25% energy savings compared to the standard RE oven. Recipes are protected by access codes. The system allows programming of up to 250 recipes with 20 steps each. Dkjdpfsw Uih Ssx Abush

Condition: new, Straightening press 150 tons with electric motor and additional manual operation by a hand lever pump, especially for fine work. Versions: 30t 60t 100t 150t 200t ᐳ 200 t: on request Special machines: on request New machine! We are also happy to build a customer-specific press for you. High quality hydraulic workshop press with 150 tons maximum pressing force. The press can also be opened and closed in the classic electric mode using a lever. For fine work (e.g. pressing in bearings, straightening, ...) the press also has a hand pump. This allows you to fine-tune the force manually. The printing cylinder is attached to a sliding carriage so that the cylinder can be moved sideways. In this way, you can make optimal use of the maximum stand passage width. Particularities: - 150 tons maximum pressing force - Pressure display with manometer - 2 operating modes: electrical operation or or manual operation - 2 independent hydraulic pumps - Control cabinet with motor protection monitoring and safety devices - adjustable passage height - Pull chains for easy adjustment of the passage height - massive machine frame - cylinder laterally adjustable (mounted on sliding carriage) The press can be tested under power on site. ----- Numerous other workshop presses in different designs, sizes and with optional additional equipment available! 30, 60, 100, 150, 180, 200 tons. Dkjdpef Sqckefx Abueh ----- Please just contact us, we will be happy to advise you without obligation. The stated price is net plus 19% VAT. All statements without guarantee! Europe-wide delivery possible! ----- The European Commission provides a platform for out-of-court online dispute resolution (OS platform). The offer serves exclusively as an internet presentation of our goods. The contract negotiation comes about by means of telecommunication (email, fax, telephone, news portal), where we first make you a non-binding offer, in which we inform you about our general terms and conditions and the right of withdrawal with imprint before the purchase / contract is concluded. Please just contact us, we will be happy to advise you without obligation.

Condition: new, Year of construction: 2023, pipe drilling machine, inclined drilling machine, automatic drilling machine TDM100, manual, with one drilling head IMMEDIATELY AVAILABLE FROM STOCK + TO BE INSPECTED UNDER POWER - minimum quantity lubrication - manual material clamping - manual feed - max. tube length 3.000mm (option 6.000mm) - positioning accuracy +/- 0,2mm - 10 stops (can be extended as required) - manual insertion and removal of material - drill head swivels +/- 50 - manual 360 degree tube swiveling device - power drilling unit 1 x 2,2 kW - motor speed 295 - 2950 rpm - display speed on touch panel - illumination drilling unit - integrated tool cabinet - round tube up to 114mm - square up to 100 x 100mm - flat material up to 100 x 15mm - T-profile up to 100 x 100 x 12mm Dodjlgvkiopfx Abuokh - L-profile up to 100 x 100 x 8mm - Double post up to 100 x 15mm - Flow drilling up to M12 - Drilling up to Ø 50mm

Condition: used, Cutter Manufacturer: Seydelmann Model: K 204 Ultra Made of stainless steel Volume: 200 liters 2 knife speeds 2 bowl speeds Djdpfotu I T Eox Abuekh 2 mixing speeds Dimensions: 280x205x255cm Electric power: 78kW Voltage: 400V, 3 phases, 50 Hz

Condition: good (used), Year of construction: 2000, functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, Machine design - Work table 1800 x 600 mm with 4T-slots - Boom travel 1050 mm - SK 40 drilling spindle with tool clamping device - Infinitely variable speed programming - Infinitely variable quill feed via three-phase servo motor - 2 T-slots 18 mm on the machine base at the rear - 2 T-slots 18 mm on the left machine base frame - Thread cutting device - Central lubrication - Coolant device - Machine light - CE marking - Safety device - USB interface Dimensions and travels Tool holder SK 40 Column diameter mm 195 Table dimensions mm 1800 x 600 Number of T-slots 4 Distance between T-slots mm 125 Quill stroke (Z-axis) mm 200 Column stroke (W-axis) mm 410 Distance spindle bottom edge - min mm 70 Table top edge max. mm 680 Distance spindle bottom edge - min mm 970 Floor max. mm 1580 Drilling radius mm 540 - 1590 Worktable height mm 900 Cutting values Drilling capacity into solid St 60  40 GG 22  50 Dodeu Aa I Sspfx Abujkh Thread cutting St 60 M 36 GG 22 M 42 Main spindle drive AC motor, frequency-controlled kW 5.5 at 100 % duty cycle. Speed range: min -1 15 - 2800 Torque Nm max. 250 constant from min -1 15 - 2000 Feed drives X-axis - AC - servo motor kW 0.25 Y-axis - AC - servo motor kW 0.25 Z-axis - AC - servo motor kW 4.50 W-axis - AC - servo motor kW 2.50 Rapid traverse speeds (X/Y/Z): m/min. 7.5 / 7.5 / 5 Rapid traverse speeds (W): m/min. 3 Feed rates stepless mm/min 5 - 2000 Accuracy Positioning accuracy X-, Y-axis to 1200 mm mm ± 0.075 Electrical data Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Hydraulic unit for clamping kW 0.75 Total connected load kVA 13.0 Weight Danumeric 440 (without packaging) with table 1800 x 600 mm kg 2800 CNC control Axes: 4 (X, Y, Z, W), expandable Processor: 32-bit CPU Screen: TFT flat screen, backlit, easy to read from all sides legible from all sides, 215 x 160 mm Position information: Cartesian or polar, absolute or incremental measurements, Unit of measurement: mm or inch or in degrees Interpolation: 2 axes (X, Y) Technology database: tool management, tool suggestions according to machining type, material-dependent cutting data suggestions Tool management: max. 500 tools Subroutine technology: yes Machining cycles Standard software options: Programming in dialog, 38 zero offsets, rotation and mirroring, teach-in for X, Y, Z, restart in program with selection functions for targeted entry Zero point determination: Cycles for determining zero points by manually probing the workpiece for by manually probing the workpiece for: - any clamped rectangular parts - any clamped round parts - Mediation of cast and flame-cut parts - Angular position detection for round parts by touching reference edges or surfaces Test graphics Graphic display of drilling patterns Data interfaces USB

Condition: new, Universal milling machine Make: OPTimill Model: MT 50 Item no.: 3336005 Condition: New machine Travels: - X-axis 580 mm Dksdpfx Asbnfxuobuoh - Y-axis 200 mm - Z-axis 340 mm serially equipped with: - 3-A digital readout DPA 31 PLUS - Automatic feed in X-axis - Long milling arbor 16 mm - Mandrel long 22 mm - Drill chuck holder B 18 - Gear rim drill chuck 3-16 mm/B 18 - Reducing chuck MK 2 with drive-out slot - Reducing sleeve MK 3 with drive-out slot - Machine light - Coolant device - Operating tool - Operating instructions

Condition: used, Year of construction: 1998, swing diameter 2000 mm table diameter 1800 mm turning height 1500 mm Control Siemens Sinumerik 840 C table turning speeds 0-280 U/min feed range 0-18000 mm/min workpiece weight max. 12000 kg total power requirement 177 kVA Feed drives: - Crossbeam support, vertical and horizontal mm/min - Crossbeam support, rapid traverse 18000 mm/min - Crossbeam adjustment speed 425 mm/min Dsdpfsxap Eysx Abuskh Milling drive: - Milling drive power 30 kW - Number of gear stages 2 stages - Stage jump 3.17 - Speed range of the 1st gear stage 10 - 224 - 950 rpm - Speed range of the 2nd gear stage 32 - 72 - rpm Tool system, cutting force: - Tool system 250.2 - Milling spindle holder according to 69871-A SK 50 - Cutting force on turning tool 50 kN Equipment/accessories: - Tool measuring probe - Various turning tool holders - Various clamping jaws - Various clamping devices - Various SK 50 mountings - Grinding spindle - Powered tools - Tool changer/head changer - Hydraulic unit - Chip conveyor - Technical documentation
