Machining Center - Universal

GROB-WERKE G550 / 2

Condition: used, Year of construction: 2000, greates pass round over bed 520 mm swing diameter over bed slide 480 mm turning length 3000 mm control 840 D SIEMENS number of tools 12 Driven tools - quantity 6 spindle bore 103 mm c-axis ja 0 Scope of delivery of the basic machine: SINUMERIK 840 D 3 controlled axes Rotation Ø over bed 520 mm Turning Ø over bed slide 480 mm Tool carrier with 12 cylindrical shank holders Ø 50 mm 1-stage AC main drive, 53 kW, 50 % ED Speed range 30 - 3000 min-¹ Main spindle head size 8 Clamping door for clamping devices chip conveyor THREE-DIMENSION 3000 mm 12 cylindrical shank holders DIN 69880-50x78 of which 6 positions can be equipped with driven tools, Power 6 kW at 60 % ED, speed range 20-2500 min-¹ 2 gear stages C-AXLE Speed range 0-20 min-¹ Max. Angle specification 9999.999° Working range according to work area diagram POWER CHUCK 3 NHF 315-82 A8 FABR. FORKARDT with centrifugal force compensation, Outer Ø 315 mm, bore Ø 82 mm, with hard top jaws, ground, rod material Ø max. 63 mm Fpjdpfowp S Sqox Abmob including draw tube and attachment

Condition: refurbished (used), Year of construction: 2011, functionality: fully functional, GF AgieCharmilles CUT 400 Year of construction 2011 Control Charmilles Millenium Travels (X / Y / Z): 800 x 550 x 510 mm Travel (U / V): 800 x 550 mm Max. Taper angle: +/- 30° at 510 mm height Integrated Collision Protection (ICP) on all 5 axes Maximum workpiece dimensions: 1450 x 900 x 510 mm Maximum workpiece weight: 3000 kg Fpsdpfx Abjuuz Iiomob Cutting speed of 400 mm²/min Best surface finish: Ra 0.2 µm Available wire diameters: 0.20 mm to 0.30 mm Incl. option for large wire reel with 25 kg (K250) Dimensions of the complete system: 2670 x 2870 x 2645 mm Total weight of the system: 6300 kg The machine is cleaned, overhauled and tested for all functions by us after receipt of order. Optional: - Commissioning of the machine on your premises - Training on site - Cooling unit - Transportation - Clamping bar set

Year of construction: 1979, condition: ready for operation (used), Max. grinding diameter: 300mm, Max. grinding length: 1950mm, Max. workpiece length: 2000mm Max Feed rate 1 – 30 m/min. Coolant supply 100 l/min Inf. variable speed range 2.000 – 6.000 RPM. Spindle 88 mm Fpjdpfx Aehq Uigjbmjb Centers height 150 mm Grinding wheels 100 – 250 mm Spindle power 3,5 kW Grinder Power 15 kW – 380 V – 50 Hz

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 1,500 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 610 mm, nominal power (apparent): 37 kVA, torque: 236 Nm, controller manufacturer: Heidenhain iTNC530, controller model: iTNC530, table width: 700 mm, table length: 1,700 mm, table load: 700 kg, rotational speed (max.): 12,000 rpm, overall weight: 9,000 kg, spindle speed (max.): 12,000 rpm, operating hours of spindle: 16,580 h, spindle motor power: 37 W, number of spindles: 1, number of slots in tool magazine: 48, Equipment: chip conveyor, documentation/manual, Heidenhain iTNC530 3-axis CNC machining center Stroke x 1500 mm Stroke Y 700 mm Fpodjvz Tyuepfx Abmob Stroke Z 610 mm Table dimensions: 1700x700mm SK40 tool holder Magazine 48 tools Rapid feed 36m/min Table load: 700 kg Spindle center coolant 20 bar Chip conveyor Crank

Condition: good (used), Year of construction: 2018, functionality: fully functional, MITUTOYO Contracer CV-2100M4 contour measuring device Fpodovun Tpjpfx Abmjb Horizontal measuring range X = 100mm Vertical measuring range Z = 50mm Column travel range Z2 = 350mm Inclination +/- 45° Dimensions (W, D, H) 745mm x 450mm x 885mm Total weight approx. 150kg Incl. PC system, Incl. cross table 218-001 Incl. rotating vice 2028-003

Condition: new, table diameter 350 mm table load 0,1 t swivelling range 0-90 Grad table load horiz. 100 kg table load vert. 50 kg boring diameter 30 mm table turning speeds 0,5 - 5 U/min voltage 230 V total power requirement 0,2 kW weight of the machine ca. 0,2 t dimensions of the machine ca. 0,5 x 0,5 x 0,5 m Welding table with hollow shaft D-DWP Tilt and turn tables with bore for turning, tilting and welding small workpieces from 100 kg. - Rotation and tilt axis - Infinitely variable speed - Compact model Fedpfx Abegvkk Njmepb - Incl. Foot pedal

Condition: new, Year of construction: 2021, Press brake Bernardo AKPL 1600 x 40 Technical data: Pressure force: 40 to bending length: 1600 mm distance between stand:1200mm stroke length: 100 mm Backgauge: 0 - 500 mm Projection: 200 mm table width: 150 mm table height: 760 mm Forward speed: 60 mm/sec Bending speed: 8 mm/sec Return speed: 60 mm/sec. Fpsdpoftuywofx Abmjb oil tank: 130 litres Engine power: 4,0 kW width: 2050 mm depth: 1800mm height: 2030mm Weight ca.3030 kg

Condition: used, turning diameter over bed 2400 mm turning diameter over slide rest 2200 mm turning length 10000 mm power capacity 185 kW faceplate diameter 1650 mm turning speeds 1,5 -150 U/min max. workpiece weight 70000 kg clamping diameter 1400 mm Technical data Working range Maximum turning diameter over support: 2200 mm Maximum swing diameter over bed: 2400 mm Maximum turning length: 10,000 mm Clamping diameter in the headstock faceplate: 300 - 1,600 mm with special jaws up to 2,050 mm Clamping diameter in the tailstock faceplate: 300 - 1,400 mm Maximum workpiece weight: 70000 kg Main drive, faceplate Faceplate diameter: 2000 mm Faceplate speeds, continuously adjustable in 4 stages: 1.5 - 150 rpm Maximum torque at rated speed: 220,000 Nm Drive power of main motor: 185 kW Flange centre point angle: 70° Supports Travel of the plunge slide: 500 mm Travel of the face slide: 1400 mm Quick adjustment, longitudinal: 2000 mm/min Quick adjustment, face: 800 mm/min Infinitely variable feed, longitudinal: 0.6 - 300 mm/min Infinitely variable feed, face: 0.3 - 120 mm/min Max. cutting force at support: 20,000 kg Tailstock Faceplate diameter (removable): 1650 mm Fodexddvnepfx Abmepb Faceplate clamping diameter: 1400 mm Flange centre point angle: 70° Quick adjustment: 1250 mm/min Special equipment Copying device for first support Copying length 8500 mm Max. copying depth in one pass 500 mm Boring device: Boring bar 460 x 390 mm Drilling diameter 600 - 1000 mm Maximum drilling depth in one pass 2700 mm At Ks of 200 kp/mm² - s max. = 1.5 mm/rev a = max. chip cross-section 30 mm² at a projection of 1000 mm Reduced chip cross-section with increasing drilling depth A guide ruler for cone turning, adjustment angle up to 8° and a maximum cone length (in one pass) of 2000 mm, adjustment accuracy ± 5 minutes. A guide ruler for cone turning, adjustment angle up to 15° and a maximum cone length (in one pass) of 1000 mm, adjustment accuracy ± 5 minutes. 125 kg auxiliary crane on spindle box.

Condition: used, Year of construction: 2001, functionality: fully functional, machine/vehicle number: 124, Price upon request Fjdpfxewl An Io Abmspb Used CNC Vertical Lathe Manufacturer MORI SEIKI Model VL 55 Year of manufacture 2001 With MSC 518 CNC control, 12-tool turret, and chip conveyor Turning length = 653 mm Turning diameter = 550 mm X-axis = 350 mm Z-axis = 660 mm Speed up to = 2000 rpm Spindle power = 30 kW Approx. weight = 12.5 t Price upon request Specifications: Used CNC Vertical Lathe Manufacturer MORI SEIKI Model VL 55 YOM 2001 With MSC 518 CNC control, 12-tool turret, and chip conveyor Turning dia. = 550mm Turning length = 653 mm X-Axis = 350mm Z – Axis = 660 mm Speed = 2000 rpm Spindle power = 30 kW Weight approx.. = 12.5 t

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, Milling Machining Center - Vertical / Brand: DECKEL MAHO / Type: DMC 63V / Year of construction: 1999 The machine can be inspected by appointment under power. Well-maintained and very good functional condition. Spindle replacement: 18.03.2022 Spindle hours (03/13/2025): 51.206 h The machine has a Lehmann A-axis and counter bearing (as new). TECHNICAL DATA: Working area: - X-axis: 630 mm - Y-axis: 500 mm - Z-axis: 500 mm Feed/axis drives: - Advancing force X, Y, Z (100 % ED): 6.000 N - Feed rate: 0 - 30.000 mm/min - Rapid feed X, Y, Z: 30 m/min - Diameter ball screw/pitch (X, Y, Z): 40/20 mm Fpjdpfx Abov Nxbysmeb Positioning accuracy: - Pmax in X, Y, Z-axis to VDI/DGQ 3441: 0,015/0,010 mm (indirect/direct measuring system) Distance measuring system: - Input unit: 0,001 mm Working spindle: - Drive power (40/100 % ED): 13/9 kW - Torque (40/100 % ED): 83/57 Nm - Speed range: 1 - 10.000 rpm - Tool holder DIN 69 871-A: SK40 - Tool clamping force: 12.000 N Tool magazine: - Tool changing system: Pick-up - Number of magazine positions: 24 - max. Tool-Ø with vacant neighboring spaces: 80/140 mm - max. Tool length: 300 mm - max. Tool weight: 7 kg - Chip-to-chip time: 6,5 sec - Rotational speed/tool magazine: 47 rpm - max. Maximum loading weight of the tool magazine (24 x 3 kg): 72 kg Machine/Working table: - Clamping surface with T-slots DIN 650-14: 800 x 500 mm - Table load (set-up weight): 500 kg - Loading height: 850 mm - max. Workpiece height (at max. tool length): 240 mm EQUIPMENT: - CNC-Control: Siemens 810D powerline - Lehmann A-axis and counter bearing (as new) - Direct measuring system - Internal cooling through the spindle, 15 bar - Coolant system (emulsion) - Electronic hand wheel - Chip conveyor - Documentation - CE marking There is no guarantee for correctness and completeness of the technical details and accessoires. - Subject to prior sale -
