Used Bending Prism for sale (3,407)

Year of construction: 2020, condition: ready for operation (used), controller manufacturer: SIEMENS, total height: 1,900 mm, General Data Measurements width 1300 mm Measurements depth 2450 mm Measurements height 1900 mm Control Unit Rcjdjx D Efqopfx Ah Uek Brand SIEMENS This LAFRANCONI LM 400 die bending machine was manufactured in 2020. It features a NC roller feeder, a max stroke rate of 350 1/min, and a material width capacity of 60 mm. The machine operates with a 20 KN center ram force and a 45 mm stroke. Powered by a 10.6 kW asynchronous spindle motor, it adjusts from 20 to 350 rpm. Dimensions are approximately 2450×1300×1900 mm. Contact us for more information about this machine. Application Types Bending

Year of construction: 1973, condition: like new (used), Used BRONX Heavy Duty Initial Pinch Pyramid bending rolls. Year of manufacture : 1973. MACHINE FORMERLY INSTALLED AT ROLLS ROYCE PLC IN DERBY UK. IMMEDIATELY FOR SALE AND NOW LOCATED IN BELGUIM WHERE IT CAN BE INSPECTED. SPECIFICATION CAPACITY Two sets of dimensions which are shown below as "Prebending & Rolling" and then "Rolling only". Material Mild Steel Mild Steel Tensile strength 28/32 tons/sq.in 28/32 tons/sq.in Maximum width 11’(3350mm) 11’(3350mm) Maximum thickness at this width 2” (50mm) 2½” (63.5mm) Minimum inside diameter of rolled cylinder at maximum capacity 30’ (762mm) 37 ½’ (953mm) Maximum thickness of plate when hot rolling (finished rolling temperature 850° C.) 4” (102mm) 5” (127mm) Minimum inside diameter of rolled cylinder at maximum capacity hot rolling 40” (1016mm) 50” (1270mm) MAIN PARTICULARS Diameter of all rolls - 27” (686mm) Body length of rolls - 11’2”(3403mm) Rolling speed - 12 f.p.m. (3600mm/min) Main drive motor - 150 H.P. Slip Ring Type Two bottom roll adjusting motors, each - 50 H.P. Slip Ring Type Combined operation of swing down bearing and top roll counterbalance Rcjdjh U Rzgjpfx Ah Uok - Hydraulically applied Hydraulic power pack motor - 10 H.P. Electrical equipment to be suitable for operation on a supply of - 400/440 volts, 3 phase, 50 cycles CONE ROLLING ATTACHMENT: To facilitate the rolling of taper or conical forms, a skid plate is fitted to the inside of the non-drive end housing. ELECTRICAL EQUIPMENT Motors: Main Drive - 150 H.P. half hour rated – slip ring screen protected – foot mounted type. Bottom Roll Adjustments - 50 H.P. half hour rated – slip ring screen protected – foot mounted type. Hydraulic Power Pack Motor - 10 H.P. continuously rated – Squirrel cage – screen protected – foot mounted type. Control Gear: Main Drive - Drum type reversing control gear with 5 minute rated wire wound resistances, designed to pass 100% full load on the first notch or operating position in each direction. The controller will be fitted with off position interlock and limit switch rings where necessary. Bottom Roll Adjustments - Drum type reversing control gear with 5 minute rated wire wound resistances designed to pass 100% full load on the first notch or operating position in each direction. The controllers will be fitted with off position interlock and limit switch rings where necessary. Hydraulic Power Pack - Direct-on-line contactor type starter, operated from a maintaining type push button station. Solenoid valves for operating cylinders are push button operated. Note: Full protection to be provided for all the above control gear by a circuit breaker, incorporating overload and no-volt protection. FEATURES AND EQUIPMENT Spare Roll included with the machine. LENGTH TBA MM WIDTH TBA MM HEIGHT TBA MM WEIGHT 95 tonnes NOTE: The information contained herein is provided in good faith, but however due to unforeseen errors or omissions cannot be binding as to accuracy.

Condition: like new (used), functionality: fully functional, Year of construction: 2019, operating hours: 250 h, machine/vehicle number: 0131, control type: NC control, degree of automation: semi-automatic, actuation type: hydraulic, pipe diameter (max.): 48 mm, pipe length (max.): 3,000 mm, tube wall thickness (max.): 4 mm, bending angle (max.): 180 °, overall weight: 670 kg, input voltage: 400 V, input frequency: 50 Hz, number of digital displays: 1, Equipment: CE marking, centralized greasing system, documentation/manual, emergency stop, T U B O M A T – simply smart. TUB-C G3001 The tube bending machine is ideally suited for single parts and small series production. The software allows individual tubes to be parameterized, simulated, and saved. Bending data is then transmitted to the machine via network (LAN). Standard bending equipment - Electronic Siemens SIMATIC control system - Function selection and operation via 4.3-inch touch panel - Familiar 4-fold preselection of bending angles or program mode - 80 memory locations for up to 10 sets - Actual/target value display for bending angles - Compact, forward-positioned bending head - Optimized tooling concept - Hydraulic bending drive, operated via proven hand lever - Hydraulic tube clamping - Hydraulic pressure die actuation - Hydraulic mandrel extraction - Mobile use possible - Saw unit for optimal right-angle cuts - Deburring unit for internal and external deburring - Universal base holder as drive unit for assembly attachments Technical Data - Tube capacity up to: 48.3 x 3.25 mm (E235, Rm = 2 x D) - Bending radius up to: 125 mm - Control: electronic - Max. bending angle: 180° (+10° overbend) - Bending accuracy: ±0.2° - Bending speed: 20°/s - Dimensions L/W/H: 3880 / 800 / 1250 mm - Weight: approx. 700 kg - Power: 2.4 kW - Electrical connection: 400 V / 50 Hz / 3 phase - Power supply requirements: CEE 16 A - Colour: RAL 9006 / 7021 / 5015 Software (Windows 11) PIPEFAB 4.0 BE Basic tube bending software package - Oracle Express database for single-user application - Creation of isometries (single tube) - ConCSVImp – import interface for CSV format - Calculation of bending data taking springback, elongation, and spring-in into account - Checking of clamping lengths, start and end lengths - Output of bending data (printout) - BendSim – bending simulation and graphical representation via parametric tool design - BendCon – creation and transfer of NC bending data for TUBOMAT - Data transfer via LAN Tool holders 1 set of adapters for bending rollers with 25 mm bore 1 clamping piece adapter installation space 100 mm 1 support for fixed pressure die installation space 100 mm Tools Bending tools consisting of bending roller, clamping piece, and pressure die (fixed) Tube diameters / Bending radii - Ø8.0 mm R=20 mm - Ø10.0 mm R=20.5 mm - Ø12.0 mm R=24.0 mm - Ø15.0 mm R=30.0 mm - Ø16.0 mm R=32.0 mm - Ø18.0 mm R=36.0 mm - Ø20.0 mm R=40.0 mm - Ø22.0 mm R=44.0 mm Mandrels 3000 mm for steel tubes Design with lubrication channel for minimal quantity lubrication (MQL) - 18.0 mm x wall thickness - 20.0 mm x wall thickness - 22.0 mm x wall thickness Pre-assembly studs for cutting ring fittings (L = light, S = heavy design) Tube Ø - 6 mm L - 6 mm S - 8 mm L - 8 mm S - 10 mm L - 10 mm S - 12 mm L - 12 mm S - 15 mm - 16 mm - 18 mm - 20 mm - 22 mm Back-up plates for cutting ring pre-assembly with automatic pressure adjustment for steel and stainless steel tubes Tube Ø - 6 mm L + S Rsdpfxjx E Rdwj Ah Ueck - 8 mm L + S - 10 mm L + S - 12 mm L + S - 15 mm - 16 mm - 18 mm - 20 mm - 22 mm Other tube diameters and wall thicknesses possible. The machine is used but in like-new condition. The machine can be inspected and demonstrated by prior arrangement. The machine must be collected from our premises but can be loaded by us. Commercial sale. Price plus 19% VAT. Subject to prior sale and errors.

Condition: used, Year of construction: 1997, Technical details: tube diameter: 4,75 - 8,0 mm wall strength: - mm bending radius min.: unterschiedlich, various, variada mm bending angle max.: 180 ° compressed air: min 4,5 bar Total power requirement: ca. 10 kW Weight approx.: 6,0 t dimension machine xH: 6,3x3,7x2,0 m dimensions electric cabinet: 1,8x0,5x2,7 m Rodsu Ibukepfx Ah Ueck dimension control panel: 0,85x0,68x1,65 m fully automatic numeric control for bending of hydraulic supply pipes, car brake pipes various length - various numbers of bending possible (max. 100 bendings per pipe) - 2 independent bending module, every modul has 2 NC axis with functions: " longitudinal process (axis 1 and 3) and " turning of bending head" and bending (axis 2 & 4) - program memory for 250 pipes (lines) - the feeding unit consits of manual a manually filled drum magazine (drum magazine pipe dia.=4,75mm up to dia=8,0mm with 500/1000 pcs) - load swiveling arm - control panel Bundy GHF 60134 accessories: - div. single and add-on parts *

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2017, control type: CNC control, shaft diameter: 50 mm, bending force (max.): 10 t, travel distance X-axis: 200 mm, shaft length: 200 mm, TECHNICAL DETAILS Maximum torque per roll: max. 2,500 Nm Bending force: 10 t X-axis travel: 200 mm Rsdpfoxw Sl Rjx Ah Ujck Shaft diameter: 50 mm Shaft length: 200 mm MACHINE DETAILS Control: CNC Dimensions & Weight Dimensions (L x W x H): 1,730 mm x 1,600 mm x 1,520 mm Weight: 1,800 kg Transport packages: 2

Condition: good (used), Year of construction: 1996, tube diameter 6 - 28 mm wall strength 2 mm bending radius min. 2 x D Control IPU 20 bending radius max. 5,0 x D mm bending angle max. 190 ° arbor length 3000 mm operating pressure 180 bar hydraulic motor 4 kW weight of the machine ca. 900 kg dimensions of the machine ca. 3,8 x 1,1 x 1,3 m Semi-automatic electro-hydr. mandrel tube bending machine with PLC control for 20 angles and display in the control panel for bending angle specification, angle detection and angle measurement via absolute value encoder, autom. tool plate reset, Turning device with digital display, hydr. quick chuck, aut. Mandrel lubrication, adjustable length stops. Operating modes: MANUAL and semi-automatic. Control buttons: hydraulics on / off, operating mode selection, clamp to / on, clamp forward / backward, mandrel forward / backward, bending forward / backward /, locking forward / backward, mandrel lubrication, turning device forward / backward, plate reset, length stop forward, emergency stop. The machine comes from a prototype construction and was only used a little until 2000. After that, the machines of this department were sold. However, the Rodpfx Asvtgn Nsh Uock purchaser did not use the pipe bending machine and therefore it has only stood in the warehouse and has not worked since then ((original paint). Please notice that the price of a new machine today is over € 60.000,--. Machine dealer with own stock of 1600 m².

Condition: ready for operation (used), Pressing force: 300 kN/30 t Tool height: 200 mm Stroke length: 0 – 300 mm Bending capacity with prism tool MW 125/240: 200 x 16 / 200 x 24 mm Bending speed: 0 – 1.3 m/min Drive motor: 380 V, 5.5 kW Weight: 800 kg Space requirement: 1250 x 820 x 1120 mm Rodpfx Ahox Apgcj Ueck

Condition: used, Year of construction: 1990, pressure ca. 20 t Rcsdpfx Asx E Dt Seh Ujk

Condition: like new (used), Year of construction: 2025, Rebar bending machine B 50 Technical data see data sheet Rjdpfx Aswr Ub Hoh Usck Dimensions 1.4x1.3x1.5 meters / Weight 400Kg Errors / input mistakes reserved

Condition: good (used), comac Series 3000, Model 303 Heavy-Duty Profile Bending Machine | 3 Driven Rolls The Series 3000 – Model 303 is a powerful and precise profile bending machine designed for demanding industrial bending applications. With its robust construction, three driven rolls, and modular roll system, this machine is suitable for a wide range of profiles, pipes, and tubes. Equipped with a solid 3 kW motor, individually adjustable bending rolls, a free-standing remote control, and both vertical and horizontal operating modes, the 303 offers maximum flexibility and ease of use. The machine complies with the 2006/42/EC Machinery Directive and is built for long-lasting, trouble-free performance. Key features Rcjdpfxox A Ivij Ah Usk - Compliant with 2006/42/EC safety standards - 3 driven rolls for maximum grip and perfect material feed - Independently adjustable bending rolls for double pre-bending of symmetrical profiles - Lateral guide rolls with three-dimensional adjustment - Modular rolls suitable for most standard profiles - Alloy steel bending rolls, heat treated to 60 HRC - Free-standing safety remote control - Suitable for vertical and horizontal installation - One-piece steel frame for extreme stability - Torque limiter on the upper shaft - Shafts and gears mounted on rolling bearings for high dynamic loads - Spline-driven power transmission for optimal force transfer Technical Specifications - Shaft diameter: 50 mm (upper/lower) - Roll diameter: 180 mm - Motor power: 3 kW - Feed speed: 5.5 m/min - Weight: 720 kg Bending Capacities Profile Up to Minimum bending radius 60 × 10 mm – Ø 450 mm 25 × 5 mm – Ø 200 mm 80 × 20 mm – Ø 400 mm 32 × 32 mm – Ø 400 mm Ø 40 – Ø 400 mm Ø 60.3 × 2.9 – Ø 800 mm Ø 20 × 1.5 – Ø 220 mm Ø 48.3 × 4 – Ø 500 mm 60 × 30 × 2.5 – – 50 × 3 – – 60 × 6 – Ø 600 mm 30 × 4 – Ø 350 mm 50 × 5 – Ø 500 mm 30 × 4 – Ø 350 mm 60 × 60 × 7 – Ø 600 mm 50 × 50 × 6 – Ø 600 mm 70 × 70 × 8 – Ø 700 mm 80 × 45 – Ø 500 mm 70 × 40 – Ø 600 mm 80 × 42 – Ø 500 mm

Condition: ready for operation (used), A defective press brake Trumpf is available. Press force: 2000kN, bending length: 4080mm, ram stroke: 365mm, table-ram distance: 632mm, max. opening height: 535mm, angular adjustment: +/-10mm, throat depth: 410mm, frame distance: 3680mm, table width: 200mm, working height: 1050mm. Machine dimensions X/Y/Z: approx. 4650mm/2250mm/2900mm, weight: approx. 18000kg. The control board is defective. The machine is equipped with intact bending aids on both sides. Documentation available. On-site inspection is possible. Rcedpfx Ahox I Rq As Uek

Condition: new, The Hydraulic Tube Bender 1/2 is a compact and mobile Tube Bending Machine designed for bending steel tubes of larger diameters with a powerful manual hydraulic pump. This machine boasts a capacity of 10 tons and comes complete with dies for commonly used tube dimensions, allowing you to create bends of up to 90 degrees. With its robust 3-leg stand and 6 bending segments, it ensures stability and ease of use during operation. The included attachments cater to various diameters, making this versatile tool ideal for your tube and profile processing needs. You can efficiently bend tubes while enjoying the benefits of its portable design. If you require a reliable Tube Bending Machine, consider the Hydraulic Tube Bender 1/2 from KNUTH to enhance your workshop capabilities. Don't hesitate to request a quote today! Rcjdpfx Aouzlh Ijh Ujk

Condition: excellent (used), Year of construction: 1992, Shaft diameter: 40 mm Bending capacity: Flat bar edgewise at 500 mm Ø: 60 x 10 mm Flat bar flatwise at 400 mm Ø: 100 x 15 mm Square bar at 500 mm Ø: 35 mm Angle iron, leg outwards at 450 mm Ø: 50 x 50 x 6 mm Rsdpfxex Anpvj Ah Usck Angle iron, leg inwards at 600 mm Ø: 50 x 50 x 6 mm T-section, T outwards/inwards at 600 mm Ø: 60 x 60 x 7/50 x 50 x 6 mm Round bar at 500 mm Ø: 35 mm Shaft speed: 7.5 rpm Electrical connection: 380 V, approx. 1.7 kW Space requirement: 910 x 640 x 1400 mm Weight: approx. 480 kg

Condition: excellent (used), functionality: fully functional, Speedburn 2000 x 1000 x +/- 900 mm aardgas 25 mbar Max. gas consumation 10 m³/uur Capaciteit 96 kW Max. temperatuur 700ºC Power 230V/50Hz - 10 A Temp. controll : Bentrup TC 405/30 Rjdjx Dtwnjpfx Ah Ujck

Condition: new, sheet width 1070 mm plate thickness 4 mm distance between columns 1100 mm Rodpfxovki E So Ah Ueck diameter of upper rolls 110 mm total power requirement 5,0 KW weight of the machine ca. 1,2 t dimensions of the machine ca. 2,0 x 0,9 x 1,1 mm

Condition: good (used), Year of construction: 1998, Tube diameter: 20 - 60.3 mm Tube feed length: 4500 mm Machine weight approx.: 0.11 t Total power requirement: kW Space requirement approx.: 5700 x 1600 x 900 mm Rodpfjx Nnm Rox Ah Uock - Preselection of 4 bending angles via rotary selector

Condition: good (used), Year of construction: 2003, machine/vehicle number: 02263, Offer 25492 Technical Data Rcodpfsx H R Rmex Ah Uok - Upper and lower rollers driven, each roller hydraulically adjustable - Suitable for prebending and conical rolling, side supports can be swung out - Operation via separate control panel with digital actual value display - Max. working width: 2050 mm - Max. sheet thickness at 400 N/mm² without prebending: 8 mm - Max. sheet thickness at 400 N/mm² with prebending: 6 mm - Bending capacity refers to at least 3 × top roller diameter - Hardened rollers - Top roller diameter: 190 mm - Side roller diameter: 170 mm - Bottom roller diameter: 140 mm - Drive: 400 V / 3.0 kW - Required space: approx. W 3500 x H 1300 x D 1300 mm - Weight: approx. 3200 kg

Condition: new, Year of construction: 2025, Take advantage of our Try&Buy offer and test the TruBend 7050 from 149.900€* incl. TRUMPF tool package incl. 90 days right of return *Offer only valid for new customers in Germany. The images shown correspond to extended equipment options and not the standard scope of the offer. Please contact us for details of the offer and further information. About the machine: With the TruBend Series 7000, you can bend small and medium-sized parts highly productively under the best working conditions. Winner of the Ergonomics Award, it takes the strain off your operator while working quickly and safely. You achieve energy savings of up to 74% compared to conventional hydraulic drives and achieve precise results for all applications. See the perfect interaction between man and machine for yourself! Precise and intuitive Control, tool clamping, positioning and angle measurement - every work step supports the path to the perfect result. User-friendly handling and precise design make the machine a compact high performer in your production. Consistently ergonomic If the bender is comfortable, the bending process runs smoothly: the TruBend Series 7000 was the first bending machine to receive an ergonomics certificate. The operator works comfortably with a standing and sitting aid and adjusts the support table individually. The sitting and standing aid as well as the swivel-mounted control protect the spine. LED lighting guarantees optimum visibility in the work area. Further information can be found on our website. TRUMPF quality Our fast remote service support takes care of your concerns anywhere in the world. For further technical data, please refer to the data sheet or visit our website. If you have any questions, please contact us. Rcedpfji Ubhxsx Ah Ujk About TRUMPF: In our 100-year company history, we have been able to help shape many thousands of sheet metal fabrications in Germany alone. We pass this experience on to our customers every day. With innovative machines and functions, the most comprehensive service concept on the market and experts in software, automation and Smart Factory, you will always receive an individual offer that is tailored to your requirements and makes you fit for the future. PS: We are also happy to support you when it comes to financing. With the financing, leasing or pay-per-use models of TRUMPF Financial Services, we are at your side for both financial and business challenges.

Condition: excellent (used), functionality: fully functional, Year of construction: 2003, A very well-maintained 4-roll CNC plate bending machine LUNA Model: 8344 17/06 Four-roll drive CNC control Mylock 100 Control system operates 4 functions: Feed, bending, clamping, and locking of the top roll Max. working width: 1750 mm Max. sheet thickness: 0.6 mm Year of manufacture: 2003 Rcodpfx Asx Nw N Ish Ujk Weight: 700 kg Made in Sweden

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, bending furnace with molds for sink 380 V 50 HZ KW 60 Usefull size = 2500 x 1200 mm / 98”x47” Rjdpfjx Dtwhox Ah Ujck

Condition: new, sheet width 2070 mm plate thickness 4 mm Rcsdpfx Ahjfv H A Uo Uek distance between columns 2100 mm diameter of upper rolls 140 mm weight of the machine ca. 0,37 t

Year of construction: 2025, condition: new, functionality: fully functional, machine/vehicle number: 34835H_2027, Tool cabinet for press brake Good for WILA / TRUMPF tools or Type B L / W / H: 1180 mm x W 850 mm / H 1600mm, 450kg -ausziehbare drawers, allows the double-sided access to the tools -beliebige height adjustment of shelves -robust steel construction, powder coated -Lateral fork guide rails for transporting by forklift (cavity under the cabinet) -The drawers run on Rollengleitschienen (serve as additional stabilization) -The cabinet can be dismantled - Number of drawers: 4 pieces - Dimensions of drawer: - Total height 1200mm / 850mm total width / total depth 1180mm - Dimensions of the compartments in a drawer: - Fachhhoehe adjusted to 210mm (is varriabel) - Trade Height total usable ohnen shelves 1450mm - Trade width 130mm available - Trade depth usable 1100mm - Number of shelves: 5 pieces / completely continuous Rodpfxox Attyo Ah Usck

Year of construction: 2025, condition: new, functionality: fully functional, machine/vehicle number: 34835H_2026, Tool cabinet for press brake Good for WILA / TRUMPF tools or Type B L / W / H: 1180 mm x W 850 mm / H 1600mm, 450kg Rjdex Attgopfx Ah Ujck -ausziehbare drawers, allows the double-sided access to the tools -beliebige height adjustment of shelves -robust steel construction, powder coated -Lateral fork guide rails for transporting by forklift (cavity under the cabinet) -The drawers run on Rollengleitschienen (serve as additional stabilization) -The cabinet can be dismantled - Number of drawers: 4 pieces - Dimensions of drawer: - Total height 1200mm / 850mm total width / total depth 1180mm - Dimensions of the compartments in a drawer: - Fachhhoehe adjusted to 210mm (is varriabel) - Trade Height total usable ohnen shelves 1450mm - Trade width 130mm available - Trade depth usable 1100mm - Number of shelves: 5 pieces / completely continuous

Year of construction: 2025, condition: new, functionality: fully functional, machine/vehicle number: 34835_20_28, Tool cabinet for press brake Good for WILA / TRUMPF tools or Type B L / W / H: 1180 mm x W 850 mm / H 1200mm, 350kg -ausziehbare drawers, allows the double-sided access to the tools -beliebige height adjustment of shelves -robust steel construction, powder coated -Lateral fork guide rails for transporting by forklift (cavity under the cabinet) Rodpfx Ahex Atr Aj Ujck -The drawers run on Rollengleitschienen (serve as additional stabilization) -The cabinet can be dismantled - Number of drawers: 4 pieces - Dimensions of drawer: - Total height 1200mm / 850mm total width / total depth 1180mm - Dimensions of the compartments in a drawer: - Fachhhoehe adjusted to 210mm (is varriabel) - Trade Height total usable ohnen shelves 990mm - Trade width 130mm available - Trade depth usable 1100mm - Number of shelves: 4 pieces / completely continuous

Year of construction: 2025, condition: new, functionality: fully functional, machine/vehicle number: 3483520_28, Tool cabinet for press brake Good for WILA / TRUMPF tools or Type B Rjdpjx Atriefx Ah Ujck L / W / H: 1180 mm x W 850 mm / H 1200mm, 350kg -ausziehbare drawers, allows the double-sided access to the tools -beliebige height adjustment of shelves -robust steel construction, powder coated -Lateral fork guide rails for transporting by forklift (cavity under the cabinet) -The drawers run on Rollengleitschienen (serve as additional stabilization) -The cabinet can be dismantled - Number of drawers: 4 pieces - Dimensions of drawer: - Total height 1200mm / 850mm total width / total depth 1180mm - Dimensions of the compartments in a drawer: - Fachhhoehe adjusted to 210mm (is varriabel) - Trade Height total usable ohnen shelves 990mm - Trade width 130mm available - Trade depth usable 1100mm - Number of shelves: 4 pieces / completely continuous
