Used Machine Bed for sale (88,647)

Condition: new, Year of construction: 2025, turning diameter over cross slide: 250 mm, turning length: 730 mm, turning diameter: 500 mm, spindle speed (max.): 1,800 rpm, CNC lathe machine CK 6150 with flat bed We offer a new CNC lathe machine model CK6150. We use this machine in our production and you can see it in operation before ordering. The CK 6150 lathe has a flat bed and hardening guides, which ensures a long period of operation of the equipment. The machine is equipped with a CNC system, the GSK CNC system is installed as standard. Optionally, the machine can be equipped with a Fanuc or Siemens CNC system. The machine can have a tool holder for 4-6 or 8 tools, depending on the customer's wishes. It is possible to install a hydraulic chuck on the machine, which will greatly simplify the process of installing parts on it and a hydraulic tailstock. The CK 6150 lathe can be equipped with additional supporting frame for more accurate manufacturing of long parts. Predpfsxdmgvox Adisd Technical specifications: Model CK 6150 x 1000 Maximum workpiece diameter over bed 500 mm Maximum workpiece diameter over support 250 mm Maximum workpiece length 1000 mm Maximum turning length 730 mm Spindle bore diameter 82 mm Spindle speed 150-1800 rpm Engine power 7.5 kW Mechanical chuck (hydraulic optional) Chuck size 250 mm. 4-position tool holder (6 or 8 optional) Maximum tool size for tool holder 25x25 mm Machine weight 2700 kg Machine dimensions 2650×1700×1820 mm We can also supply lathes CK 6140, CK 6150 and CK 6160 with other dimensions of the working part: CK 6140 dimensions of the working part 550/750 mm CK 6150 dimensions of the working part 1000/1500/2000 mm CK 6160 dimensions of the working part 1000/1500/2000 mm CK 6152E dimensions of the working part 1000/1500/2000/3000 mm CK 6165E dimensions of the working part 1000/1500/2000/3000 mm CK 6165E dimensions of the working part 1000/1500/2000/3000 mm CK 6185E dimensions of the working part 1000/1500/2000/3000/4000 mm CK 61100E dimensions of the working part 1000/1500/2000/3000 mm CK 61125E dimensions of the working part 1000/1500/2000/3000 mm

Condition: ready for operation (used), Year of construction: 2008, operating hours: 16,722 h, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 4,200 rpm, controller model: Heidenhain iTNC 530, Submission of a bid obligates the buyer to collect the machine by the end of this year! TECHNICAL DETAILS Travel X: 4,000 mm Travel Y: 1,200 mm Travel Z: 1,000 mm Maximum spindle speed: 4,200 rpm Tool holder: SK50 DIN 69871 Table load capacity: 10,000 kg MACHINE DETAILS Control system: Heidenhain iTNC 530 Operating hours Control unit on-time: 47,181 h Machine on-time: 45,697 h Program running time: 16,722 h Prjdpoxx Uayofx Adisd EQUIPMENT 45° diagonal milling head with 2.5° indexing Drum-type tool changer with 24 tool positions (vertical tool change) Machine enclosure: front guard with 2 doors Rear guard with additional door Side slats for machining of extra-long workpieces Longitudinal chip conveyor (discharge on right-hand side) Control cabinet air conditioning Swivel arm for machine control (operation from front and rear)

Condition: good (used), Year of construction: 2008, Traverses X Y Z: 3000 x 1300 x 2000mm, Pjdpfx Aevz A Risdijrd Table 2000 x 1600mm, table load 13,000 kgs, B axis 360 degrees, Heidenhain iTNC530, ISO SK50 spindle taper, 5,000rpm Spindle Speed, 60 station toolchanger, coolant, Interlocked guards.

Condition: used, Mecof Bed Milling Machine, Moving Column, 9m x 2.2m Table, Angle plate 1m x 2.5 x 1.2, two sub tables 1m x 1.5m. Heidenhain 426 control Pedpfxjxaz E So Adierd

Condition: ready for operation (used), controller manufacturer: Heidenhain, Type: ML120-12000 6 assen gelijktijdig (X / Y / Z / W / B / V) + 2-assige indexeerfreeskop (2,5°) 8 assen gelijktijdig (X / Y / Z / W / B / V) + continue orthogonale freeskop (A: +-120° / C: +-180°) Zware CNC-frees- en boormachine / CNC-vloerboor- en freesmachine ramgrootte: 630 x 500 mm - ramslag: 1250 mm spindeldiameter 130 mm - slag: 650 mm - zonder freeskop te gebruiken als boor CNC continue orthogonale freeskop (A: +-120° / C: +-180°) CNC indexeerfreeskop (2,5°) gereedschapswisselaar voor het automatisch wisselen van twee freeskoppen koeling door spindel gereedschapswisselaar met 60 posities spaantransportband Siemens aandrijvingen en motoren Heidenhain regel- en meetlinialen gewicht van de machine: 60 ton afmetingen van de machine: 19 meter x 12 meter x 6,65 meter TIRT3025 CNC draaitafel continu: - max. 60 ton werkstukgewicht - hydrostatische tafel - afmetingen: 3000 x 2500 mm - slag of draaitafel: 2500 mm - max 2 toeren per minuut - gewicht van de tafel: 37 ton - afmetingen: 6500 x 2500 x 1500 mm 3 T-sleuftafels - 7600 x 2800 mm - 7600 x 2480 mm - 4300 x 1800 mm - gewicht van de tafels: 50 ton Fresatrice a montante mobile - Freesmachine met mobiele kolom - Fraiseuse-aleseuse avec montant mobile - Fräs-Bohrmaschine mit beweglichem Ständer Longitudinal travel X-axe: 12 000 mm Crosstravel Y -axe: 1250 mm (ram-travel) Travel Z-axe (Height): 3500 mm Power on spindle: 37 kW Admission in millingheadspindle (ISO): ISO 50 Max quill travel Z': 1250 + 650 mm Predpoxpgf Nefx Adisd Max speedrange: 6 > 2000 rpm

Condition: excellent (used), Adcock & Shipley 2E Universal Milling Machine Horizontal Milling attachements fitted Universal Swivel Table Table size 40 x 10” Speeds 30 – 1200rpm Power Feed to Table & Rapids Coolant Gaurds 3 Phase Electrics For sale with Jet Machinery Ltd Jet Machinery Stock No: #78947 Machine Serial Number: 1586K2AGU0665 Cost: £2,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use. Prodexxbhwjpfx Adiod

Condition: used, Year of construction: 1999, x-travel 4000 mm y-travel 1000 mm z-travel 1500 mm Control Heidenhain 355 Pjdpsxzuz Nefx Adijrd weight max. 10 t ja more pictures available

Condition: good (used), Year of construction: 2009, functionality: fully functional, Technical details x-travel 4000 mm y-travel 1350 mm z-travel (Vert.) 1600 mm Predpfjxy Nlmjx Adied Control Heidenhain iTNC 530 table surface area 4200 x 1150 mm table load 13 t tool taper ISO 50 spindle turning speed - stepless 0 - 3000 U/min transmission ratio 2 spindle motor 28/38 kW feed range 5000 mm/min rapid traverse (X/Y) 12 m/min rapid traverse (Z) 10 m/min weight of the machine ca. 37 t dimensions of the machine ca. 12,9 x 6,53 x 3,79 m Additional information In January and October 2025 the milling head was overhauled (new bevel gears and bearings). Total costs 51.000,- Euro. Working hours (dated 31. July 2025): Machine on: 38.483 h Auto cycle: 12.798 h Spindle hours: 11.645 h * CNC-control HEIDENHAIN iTNC 530 * Electronic handwheel * 50-position tool changer * Controlled universal milling head, indexable 2.5 / 2.5 deg. * Coolant device * Cooling through the spindle * 2 chip conveyors * Oil cooler * Measuring probe * Machine documentation

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, USED KIHEUNG POINT U6 WITH HEIDENHAIN TNC POINT TO POINT CONTROL SERIAL NUMBER 3190597 YEAR 1999 MACHINE DELIVERY / AVAILABILITY - Ex Stock - Subject to Prior Sale. MACHINE CONSTRUCTION & FEATURES  TRAVELLING TABLE CNC MILLING MACHINE WITH UNIVERSAL MANUAL INDEXING HEAD  HEAVY-DUTY CAST-IRON BED CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY.  HEAVY DUTY CAST IRON CONTRUCTION WITH SOLID SLIDEWAYS  LINEAR SCALES. ADDITIONAL INCLUDED ACCESSORIES, OPTIONS & TOOLHOLDERS  COOLANT EQUIPMENT  MACHINE TABLE GUARDING INCLUDED. FIXED TABLE Working Surface 2,200 x 550 MM Tee Slot Configuration 5 T-SLOTS X 20H12 TRAVELS Longitudinal Column Travel (X-Axis) 1,600 MM Vertical Head Travel (Y-Axis) 900 MM Cross Travel (Z-Axis) 700 MM SPINDLE HEAD Spindle Nose Taper ISO 50 Spindle Speeds - 2 Ranges 40-1600 RPM Spindle Motor Power 11.0 KW SLIDE FEEDS Cutting Feedrate 2000 (LONG AND CROSS), 1000 (VERT) MM / MIN Rapid Traverse (X, Y-Axis) 5 M/MIN Rapid Traverse (Z-Axis) 2.5 M/MIN Rapid Traverse (Z-Axis) 15 M/MIN Psdjvrzv Eopfx Adierd POWER SUPPLY Voltage 415V / 50HZ / 3PH MACHINE Floor Space 4,750 x 2,720 MM Height 3,050 MM Weight 8,000 KGS

Condition: used, CME Universal miller model FU31CM, 1860 x 360mm table, (plus two covers at 300mm each) approx 500mm under tool, knuckle head, with horizontal attachment, , DRO Sony 4 axes ACURITE READOUT & SCALES.. 40 INT spindle. Machine in exceptional condition ex University. Pjdpfxjxp Iqme Adiord

Condition: ready for operation (used), total height: 3,300 mm, total width: 3,450 mm, total length: 6,000 mm, controller manufacturer: Siemens, empty load weight: 17,000 kg, Model: FTV 850 Koeling door spindel Het werkgebied kan in twee secties worden verdeeld 2 magnetische tafels Bewegende kolom, vergelijkbaar met Mazak VTC / Unisign / Hedelius Zware chassisstructuur Longitudinal travel X-axe: 1800 mm Crosstravel Y -axe: 850 mm Travel Z-axe (Height): 800 mm Dimensions clamping space - table: 2300 x 900 mm Pedpfx Adjwxz D Ueisrd Universal (2x 360°): ISO 50 Boring head (1 x90°): 19 kW

Condition: used, Year of construction: 2003, x-travel 3.000 mm y-travel 1.000 mm z-travel 1.500 mm control Heidenhain TNC 430 spindle tunring speed 5.000 U/min tool taper SK 50 number of tool places 40 Pos. Number of working hours ca. 15.829 h In our assessment, the machine is in good used condition and can be inspected under power by appointment. Technical features & accessories: - Automatic swivel head with B-axis, infinitely variable - Internal coolant supply 20 bar - Air blower through spindle - Chip conveyor - Chip flushing Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice. Prsdpfsxylqrex Adied Prior sale reserved.

Year of construction: 1991, condition: ready for operation (used), Control Unit Brand HEIDENHAIN Model TNC 355 NC Main Drive Spindle speed range 10 to 1600 Spindle bore 150 mm Number of axis 4 Movement X-Axis Movement 3000mm Y-Axis Movement 2000mm Y-Axis Rapid Traverse 7100 mm/min Z-Axis Movement 1600mm Z-Axis Rapid Traverse 7100 mm/min W-Axis Movement 700mm Pjdpfxoxzlu Hj Adijrd W-Axis Rapid Traverse 7100 mm/min Tools Type of tool holder SK50 Clamping Unit Clamping force 25 kN This 4-axis UNION BFK 150/2 Bed Type Milling Machine was manufactured in 1991. It features a Heidenhain control system and SK50 tool holder, with travel distances of X=3000mm, Y=2000mm, Z=1600mm, and W=700mm. If you are looking to get high quality milling capabilities consider the UNION BFK 150/2 machine we have for tact us for more information. Application Types Milling

Condition: good (used), Year of construction: 1965, Model maker milling machine with swivel head, MK 4, rotary table, d. Accessories Year of construction: 1965 X (mm): 1000 Prjdpsq Ixz Rofx Adied Y (mm): 600 Mounting (iso/mk): 4 Power (kw): 2

Condition: reconditioned (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,000 mm, rapid traverse X-axis: 25,000 m/min, rapid traverse Y-axis: 25,000 m/min, year of last overhaul: 2025, RepairFIT by Dornhöfer The Difference. Including installation and commissioning! Technical details of the machine: Prodpfjv Rw Uujx Adiod Year of manufacture: 2008 Control: Heidenhain iTNC 530 Travel range: X-axis (mm) 2,500 Y-axis (mm) 1,250 Z-axis (mm) 1,000 Rotary table size: Length (mm) 1,000 Width (mm) 1,000 Spindle speed range: 15,000 rpm Feed rates: X, Y & Z axes (mm/min): 10 - 10,000 Max. rapid traverse speed X, Y & Z axes (mm/min): 25,000 Milling head: Automatic milling head, vertical Tool holder: HSK 63 A Main spindle drive power: 100% duty cycle KW25 - Chip conveyor - Cooling lubricant system - 3D thermal expansion compensation - Portable electronic handwheel Heidenhain HR 410 with 3m spiral cable - INA RUE 45 linear guideway system on all linear axes with central lubrication - Complete splash guard enclosure RepairFIT is our proven offering for a profitable entry into our product lines. The machines available in this line are procured by us following a rigorous selection process and subjected to a thorough inspection (deep dive check). After intensive cleaning, any obvious defects and faults identified are professionally repaired by our expert service team.

Condition: new, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 30,000 m/min, rapid traverse Y-axis: 30,000 m/min, rapid traverse Z-axis: 30,000 m/min, position of the milling head: Universal-Diagonal-Fräskopf, spindle speed (max.): 6,000 rpm, table width: 1,200 mm, table load: 6,000 kg, table length: 1,600 mm, torque: 1,178 Nm, power: 31 kW (42.15 HP), Equipment: rotational speed infinitely variable, BRAND NEW BED-TYPE MILLING MACHINE WITH ROTARY TABLE Control and Motors: HEIDENHAIN TNC 640 digital path control HEIDENHAIN package (motors, measuring systems, and handwheel) Prjdpfxeff Hz Hs Adied IKZ: Internal coolant supply – 36 bar Rotary Table: 1600 x 1200 mm – Dual-motor drive system Additional Equipment: ATC tool changer with double gripper, 40 positions Double hinged belt chip conveyor (longitudinal), one at the front and one at the rear Perimetric enclosure Accuracies: Positioning accuracy: ± 0.015 mm Repeatability: ± 0.008 mm Only inquiries from Germany will be answered.

Condition: ready for operation (used), Fanuc 6-assige robotfreescentrum voor aluminium en staal X-beweging van de robot: 10.500 mm Verlengd bereik van de robotarm (links en rechts): 3045 mm maximale werkstuklengte indien het een profiel betreft: 15 meter max. werkstukgrootte zonder verlengde armbereik: 10.500 x 3045 mm max. werkstukhoogte: 3500 mm 13-positie gereedschapswisselaar: - 12 elektrische gereedschappen - 1 meetsonde Freeskop: -SK40 - 10 kW op spindel 12.000 tpm / 15.000 tpm - 7,5 kW op spindel / 18 000 tpm - 4 kW op spindel / 24.000 tpm - automatische smering Er zijn veel configuraties mogelijk, afhankelijk van het type werkstuk. Momenteel zijn er twee aparte werkgebieden, maar u kunt dit wijzigen naar één werkgebied (voor een groot werkstuk) of het opsplitsen in meerdere aparte werkgebieden voor kleinere werkstukken. Prsdpfxsv Sfk He Adied

Condition: ready for operation (used), Year of construction: 2009, Immediately available from site: CNC bed milling machine Iberimex Podpfx Adoxy N Risiord Model Ecomill BF 2600 Year of manufacture 2009, low operating hours Heidenhain iTNC 530 control Table 2700 x 1050 mm Travel X/Y/Z: 2600/1000/950 mm Table load capacity: 6 t Internal coolant supply: 14 bar Hydraulic milling tool clamping SK 50 taper Spindle speeds: 24 – 1600 rpm Spindle drive: 25 kW Chip conveyor Weight: 14 t Offered at €24,000 plus VAT, ex-site.

Year of construction: 2011, condition: ready for operation (used), Main Drive Number of axis 3 Spindle Speed 4000 RPM Spindle motor power 25 kW Movement X-Axis Movement 3000 mm Z-Axis Movement 900 mm Y-Axis Movement 865 mm Table Table load 10000 kg Prjdpfsxyl Rlsx Adied This 3-axis Auerbach FBE 3000 Bed Type Milling Machine was manufactured in 2011. It features a robust clamping surface of 3100 x 800 mm, capable of handling a maximum table load of 10,000 kg. The machine is equipped with a multi-position milling head KFM 1, a tool holder SK 50, and offers a spindle power of 25 kW with speeds up to 4000 rpm. If you are looking to get high-quality milling capabilities, consider the Auerbach FBE 3000 machine we have for sale. Contact us for more information. Application Types Milling

Condition: good (used), Year of construction: 1984, Ref. -No.: 10594 Manufacturer: DECKEL GILDEMEISTER Type: MD 3S Year of construction: 1984 Type of control: CNC Control: ELTRO MPULS Storage location: Halberstadt Country of origin: Germany Turning Diameter: 400 mm Turning Length: 600 mm Pedpfoxxpcijx Adierd Swing Diameter: 600 mm Spindle Bore: 73 mm

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,200 mm, rapid traverse X-axis: 25 m/min, rapid traverse Y-axis: 25 m/min, rapid traverse Z-axis: 25 m/min, feed rate X-axis: 10 m/min, feed rate Y-axis: 10 m/min, feed rate Z-axis: 10 m/min, spindle speed (max.): 4,000 rpm, spindle speed (min.): 20 rpm, table width: 850 mm, table load: 5,000 kg, table length: 2,700 mm, overall weight: 15,500 kg, year of last overhaul: 2024, RefurbishmentPLUS by Dornhöfer The difference. Including installation and commissioning! MAIN TECHNICAL DATA Year of manufacture: 2007 Capacities / Travel: Longitudinal (X): 2,500 mm Vertical (Y): 1,250 mm Cross (Z): 1,200 mm Table size: Length: 2,700 mm Width: 850 mm Number of T-slots on the table surface: 6 T-slot width: 22H12 mm Reference slot: 22H8 mm Distance between slots: 140 mm Max. table load: 5 t/m² Paint finish: RAL 5011 (steel blue) and RAL 7035 (light gray) Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 form A Main drive: Drive power: 100% duty cycle KW24 Spindle speed range: Spindle speed: 20-4,000 rpm Torque: 479 Nm Feed rates: X, Y, and Z axes mm/min 10-10,000 Max. rapid traverse speed: X, Y, and Z axes mm/min 25,000 Weight: approx. 15,500 kg Pjdpfx Adoun Nnqsijrd BASIC MACHINE EQUIPMENT: Heidenhain iTNC 530 HSCI Automatic milling head, diagonal H200 Chip conveyor Coolant system STANDARD EQUIPMENT: - Portable electronic handwheel HR 510 with 3m spiral cable - Hydraulic counterbalance acting directly on the vertical slide - 3D thermal expansion compensation for Heidenhain CNC contouring controls - Complete splash guard enclosure consisting of two front doors and one rear door for operating the machine from the front and rear. All doors are equipped with viewing windows. - Heidenhain AC drive motors in all axes with diagonal drive technology - INA RUE 45 linear guideway system in all axes with central lubrication - Ball screws (IT5) in all axes - Heidenhain direct linear measuring system in all axes - Telescopic covers for the X-axis guideways - Automatic cyclic lubrication for all axes and motion components - Work area lighting Refurbishment+ – what does that mean? The RefurbishmentPLUS line offers you a machine that has been uncompromisingly restored to its original technical and visual condition. All assemblies have been completely disassembled, repainted, and rebuilt with new, original spare parts. Cables, hydraulics, guides, spindles, rolling bearings – everything new!

Condition: new, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 30,000 m/min, rapid traverse Y-axis: 30,000 m/min, rapid traverse Z-axis: 30,000 m/min, position of the milling head: Universal-Diagonal-Fräskopf, spindle speed (max.): 6,000 rpm, table width: 1,100 mm, table load: 10,000 kg, table length: 3,100 mm, torque: 1,178 Nm, power: 31 kW (42.15 HP), Equipment: rotational speed infinitely variable, FACTORY NEW BED MILLING MACHINE Control and Motors: HEIDENHAIN TNC 640 digital path control HEIDENHAIN package (motors, measuring systems, and handwheel) IKZ: Internal coolant supply, 36 bar Additional Equipment: Pjdpfxoh Ekrte Adierd ATC tool changer with double gripper, 24 positions Double hinge belt chip conveyor (longitudinal), one front and one rear 4th axis preparation (rotary table) Perimetric enclosure Accuracies: Positioning accuracy: ± 0.015 mm Repeatability: ± 0.008 mm Only inquiries from Germany will be answered.

Condition: ready for operation (used), Year of construction: 2000, Available immediately from site: MTE CNC bed milling machine Type Kompakt Plus Year of manufacture: 2000 Heidenhain TNC 410 Table: 2200 x 750 mm Travels X/Y/Z: 2000/800/800 mm Table load capacity: 4 t Pjdpfexy N Nfjx Adisrd Spindle taper: SK 50 Hydraulic tool clamping Spindle speeds: 40 – 2500 rpm Spindle power: 15 kW Total power requirement: 30 kW Coolant system Weight: 12 t Price: EUR 16,500.— plus VAT, ex works.

Year of construction: 1991, condition: ready for operation (used), Control Unit Brand HEIDENHAIN Model TNC 415 This 3-axis Huron X 61 38 bed type milling machine was manufactured in 1991. It is equipped with a Heidenheim TNC 415 control system and offers substantial travel dimensions with an X-axis of 2400 mm, Y-axis of 1000 mm, and Z-axis of 1000 mm. The machine's transport dimensions are 3000 mm in breadth, 1400 mm in thickness, and 3000 mm in height. Consider the opportunity to buy this Huron X 61 38 machine we have for sale. Reach out for more information. Application Types Milling Psdpfsxl Hyxex Adiord

Condition: reconditioned (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 25,000 m/min, feed rate Y-axis: 25,000 m/min, feed rate Z-axis: 25,000 m/min, spindle speed (max.): 3,000 rpm, spindle speed (min.): 20 rpm, table width: 850 mm, table length: 3,700 mm, overall weight: 18,500 kg, RepairFIT by Dornhöfer The Difference. Including installation & commissioning! Year of manufacture: 2007 Travel / Stroke Capacities: Longitudinal (X): 3,500 mm Vertical (Y): 1,250 mm Cross (Z): 1,000 mm Table dimensions: Length: 3,700 mm Width: 850 mm T-slots: 5 x 22 H12 Reference slot: 1 x 22 H8 T-slot spacing: 140 mm Paintwork: RAL 5011 (steel blue) RAL 7035 (light grey) Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Form A Main drive: Drive power: 100% duty cycle 24 kW Spindle speed range: Spindle speed: 20-3,000 rpm Torque: 479 Nm Max. feed rate: X, Y, and Z axes 25,000 mm/min Mean acceleration: 2 m/s² Weight: approx. 18,500 kg HEIDENHAIN iTNC 530 HSCI Swiveling control pendant including Heidenhain iTNC 530 control (1 processor / 4 axes) with software options 1 and 2. Automatic Milling Head, Diagonal H4 Automatic indexing Soraluce “Diagonal” milling head, Type H4 / 2 planes with 2.5° x 2.5° indexing, 479 Nm, tool clamping force 18,000 N. Automatic tool changer: Automatic tool changer (random carousel) with 20 magazine positions: The automatic tool change is carried out in the vertical position of the tool spindle. Maximum tool diameter: 125 mm Maximum tool length: 250 mm Maximum tool weight: 15 kg Number of magazine positions: 20 Chip conveyor package: Three chip conveyors, two longitudinal screw conveyors and one cross hinge belt conveyor with integrated coolant tank, discharge height: 1,000 mm Coolant System 2: Prodpfx Adjxgn Efoijd Coolant/lubricant system 2 with discharge via shower ring and internal coolant supply according to DIN 69871 Form AD, tank capacity 500 l + 150 l lift tank with pump, delivery rate 50 l/min, delivery pressure 5/8 bar. Increased delivery pressure of high-pressure pump from 15 bar. RepairFIT is our proven offer for a profitable entry into our product lines. The machines available in this line are sourced by us following a strict selection process and undergo a thorough inspection (deep-dive check). After intensive cleaning, all identified visible defects and faults are professionally repaired by our expert service team.
