Used Milling Recordings for sale (11,238)

Condition: excellent (used), Year of construction: 2024, 2024 Mazak Integrex J-200S 5-Axis Multi-Tasking CNC Lathe With Mazatrol Smooth G Control Main Spindle Hainbuch Ø215mm 3 Jaw Power Chuck, Sub Spindle Kitagawa B-208 3 Jaw Ø210mm Power Chuck. Maximum Swing Ø530mm. Maximum Swing Over Cross Slide Ø530mm. Maximum Machining Ø500mm. Maximum Bar Working Capacity Main Spindle Ø65mm, Sub Spindle Ø51mm. Maximum Machining Length 910mm. Maximum Support Weight Main Spindle Chuck Work 200kg, Maximum Support Weight Sub Spindle Chuck Work 200kg. Axis Travel 'X'=450mm, 'Z'=1,119mm, 'Y'=200mm, ,W,=1,436mm, 'B'=–30° To 210° (5° Increment'), C'=0.0001° Increment. Rapid Traverse 'X'=40m/min, 'Z'=40m/min, 'Y'=40m/min, 'W'=30m/min,C'=555rpm. Main Spindle Speed Range 35-5,000rpm (11kW Motor). Main Spindle Nose JIS A2-6”. Spindle Bore Ø76mm, Sub Spindle Speed Range 35-5,000rpm (11kW Motor). Main Spindle Nose JIS A2-5". Maximum Milling Spindle Speed 12,000rpm (7.5kW Motor). 72 Position ATC. Spindle Nose Capto C6. Turning Tool Shank 25mm², Boring Bar Ø40mm, Maximum Tool Ø125mm, Maximum Tool Length 210mm. Power Requirement 35.34kVA. Power On Hours 2,127. S/No.354479 (2024). NOTE: A loading fee will be added to buyer's invoice of £100 + VAT. Bwsdpfxs Ahg S Ej Aiwew With Through Coolant System, Cromar Chip Conveyor, Habor HBO-750PTSBM8 Oil Cooler, Habor HJ-400PSBM2 Oil Cooler, GTI GT 10L Slim Oil Mist Extractor, Parts Cathcher, Foot Switches, Signal Tower, Tooling Package (Consisting Of Kitagawa B-208 3 Jaw Ø210mm Power Chuck, Hainbuch Collets & Assorted Tooling) & Manuals (CD). Overall Machine Dimensions L3,790 x W2,420 x H2,500 mm. Weight 9,800kg.

Condition: used, Year of construction: 2003, 2003 Mazak Mega Turn A16N M/C CNC Vertical Turning Centre with Elevating Bridge, 'C' Axis & Mazatrol PC-Fusion Control Independant Ø1,600mm 4 Jaw Chuck. Maximum Swing Ø2,030mm. Maximum Table Load 12,000kg. Maximum Turning Height 1,828mm. Ram Travel 'Z'=1,067mm, 'X' Travel 599mm (Right), 1,016mm (Left). Cross Rail Travel 762mm. Maximum Table Speed 230rpm. Milling Spindle Maximum Speed 1,100rpm. 30 Position ATC. S/No. 163418 2 (2003). Note: Has Crossrail & Parameter Issue. With Chip Conveyor & Coolant System. Weight 32,300kg. Bwjdpfe Ahg Tfjx Aiwew

Year of construction: 2003, condition: excellent (used), Milling chuck Manufacturer: Clarkson SK 50 Type: 32073-y Bedpfx Ajfc A Tveiwsww Weight: 6.5 kg Delivered in a metal case.

Condition: used, Tool holder, milling holder, milling tool, boring head, spindle tool, reducing sleeves, clip-on holder Bjdpfx Asf Sgxdoiwoww -Milling mount: mount MK4 -Measures: see pictures -Dimension: Ø 56 x 670 mm -Weight: 7.5 kg

Condition: used, Year of construction: 2006, 2006 DMG Gildemeister GMX 400 Linear Multi-Tasking Twin Spindle CNC Lathe With Siemens 840D Control & Pneumotec Gantry Parts Loading System Bodpfx Aj Ahg R Seiwsww With Dual Rohm KUBF-400/4 Ø400mm Power Chucks. Swing Ø640mm. Maximum Turning Ø640mm. Maximum Turning Length 1,500mm. Axis Travel 'X1'=550mm, 'Y'=220mm, 'Z1'=1,585mm, 'X2'=225mm, 'Z2'=1,400mm, 'Z3'=1,500mm, 'B'= ±120°. Rapid Travere 'X'=40m/min, 'Y'=24m/min, 'Z'=60m/min. Spindle Bore Ø107mm. Maximum Bar Capacity Ø92mm. Maximum Main Spindle Speed 4,000rpm (45kW Motor). Maximum Sub Spindle Speed 4,000rpm (45kW Motor). Maximum Rotary Spindle Speed 12,000 (22kW Motor). Rotary Spindle Taper Capto C6. 60 Position ATC. 12 Position Sauter Turret. 20 Position Loading Station With Air Blast Cleaning Tank. S/No. 07500001331 (2006). With Coolant Paper Filtration System, Chip Conveyor, IFM Mist Extraction Unit, Oil Chiller, Automatic Doors, Foot Switches, Wash Gun, Handwheel, Signal Tower & Manuals. Overall Dimensions L9,347 x W4,646 x H3,018mm. Weight 24,000kg.

Condition: excellent (used), Boring head, spindle head, drilling head, grooving drill head, grooving head, spindle drilling head, boring head, spindle tool -Adjustment: SK50 Bedpsb A Hvasfx Aiwjww -Tool holder: M20 -Price: for both recordings -Weight: 16 kg

Condition: excellent (used), Year of construction: 2018, Technical Data Main spindle, counter spindle Turning length: mm 660 Spindle bore: mm 65 Chuck diameter: mm 165 Speed max.: min-1 6,000 Power (100% / 40% duty cycle): kW 20 / 24 Torque (100% / 40% duty cycle): Nm 125 / 170 C-axis resolution: degrees 0.001 Slide travel X: mm 710 Rapid traverse: m/min 60 Feed force: N 6000 Turret, lower / upper Speed max.: min-1 7,200 Power max.: kW 9 Torque max.: Nm 16 Milling spindle Tool system: HSK-A40 Speed max.: min-1 7,200 Torque (25% duty cycle): Nm 52 Power (25% duty cycle): kW 22 Tool holder 1 Slide travel X: mm 230 Rapid traverse: m/min 30 Feed force: N 6000 Slide travel Y: mm +/-65 Rapid traverse: m/min 15 Feed force: N 10,000 Slide travel Z: mm 845 Rapid traverse: m/min 50 Feed force: N 6000 3 Turrets Turret 1 YB - 6-position tool changer HSK Turret 2 Y Turret 3 y Year of manufacture 2018 Control system Siemens SINUMERIK 840D sl Turning length up to 660 mm Spindle bore 65 mm Milling spindle with 360-degree B-axis Production hours approx. 7,200 h Turret, lower and upper Bwodpjz Sywcjfx Aiwow Feature Specification Stations and tool positions 14 stations per turret (VDI 25), a total of 42 tool positions Maximum speed 7,200 min⁻¹ Maximum power 9 kW Maximum torque 16 Nm Milling spindle Feature Specification Tool system HSK-A40 Tool magazine 6 tool positions B-axis 360 degrees Maximum speed 7,200 min⁻¹ Torque at 25 percent duty cycle 52 Nm Power at 25 percent duty cycle 22 kW Tool holder 1 Feature Specification X-axis 230 mm, rapid traverse 30 m/min, feed force 6,000 N Y-axis ±65 mm, rapid traverse 15 m/min, feed force 10,000 N Z-axis 845 mm, rapid traverse 50 m/min, feed force 6,000 N Tool holder 2 Feature Specification X-axis 140 mm, rapid traverse 30 m/min, feed force 6,000 N Y-axis ±45 mm, rapid traverse 15 m/min, feed force 10,000 N Z-axis 810 mm, rapid traverse 50 m/min, feed force 6,000 N Workpiece removal Feature Specification Design Gantry part removal system with conveyor belt Maximum workpiece length 200 mm Maximum workpiece weight 5 kg Dimensions and connection values Feature Specification Length × Width × Height 5,355 × 2,235 × 2,400 mm Weight approx. 8,500 kg Connected power 42 kW Bar feeder magazine and accessories Feature Specification Bar feeder magazine INDEX MBL 65 Coolant system KNOLL system with band filter and high-pressure pump 80 bar Automation Automatic door Accessories Tool holder

Condition: used, Year of construction: 2018, operating hours: 1,500 h, functionality: fully functional, machine/vehicle number: 58281, working width: 1,700 mm, input voltage: 400 V, working length: 2,200 mm, number of slots in tool magazine: 18, control type: CNC control, Rittal Perforex BC 1007 HS CNC drilling and milling centre for automated machining of enclosures and flat panels: cut-outs, holes and threads straight from EPLAN Pro Panel / DXF. Built 2018 in Germany. Machine no. 58281, Rittal part no. 4050.107. Specification: Bwodpfx Ao Ahq D Hsiwew - Clampable flat panels (W x H): 2450 x 1700 mm - Max machinable panel area: 2200 x 1700 mm - Clampable enclosures (W x H x D): 1400 x 1600 x 1600 mm - Max machinable area, enclosures: 1200 x 1600 mm - Tool holder: pick-up system, 18 positions - Control: 4-axis CNC, Rittal OptiPanel, 15" monitor - Electrical supply: 400 V, 3-phase, 50 Hz, 32 A max - Control voltage: 24 V DC - Footprint (W x H x D): 4390 x 2410 x 2720 mm - Transport size (W x H x D): 3800 x 2300 x 2500 mm - Weight: approx. 2,300 kg Key features: - Enclosure (cube) and flat-panel machining - Pressure plate with swarf extraction - High-performance spindle, minimum-quantity lubrication - Automatic tool breakage check - Pneumatic clamping, DIN tooling - Machines mild steel, stainless, aluminium, copper and plastics - Direct import from EPLAN Pro Panel, DXF import Supplied with: - Safety guarding with light curtains - Operator console and keyboard - Tool magazine with tooling - Rear enclosure-machining bay - Control cabinet - Operator documentation Specification from Rittal published data for the BC 1007 HS; buyer to verify configuration on inspection. Viewing by appointment in Sunderland, UK. Buyer to arrange disconnection and collection unless agreed.

Condition: excellent (used), Year of construction: 2018, operating hours: 9,219 h, functionality: fully functional, machine/vehicle number: 2730218, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,700 mm, travel distance Z-axis: 1,500 mm, controller manufacturer: Heidenhaim, controller model: HAIDENAIN TNC 530 HSC, total height: 4,070 mm, total length: 6,800 mm, total width: 6,500 mm, table width: 1,300 mm, table length: 1,800 mm, table load: 6,000 kg, overall weight: 19,000 kg, spindle speed (max.): 3,500 rpm, operating hours of spindle: 9,219 h, number of slots in tool magazine: 32, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, MACHINE FEATURES Model: RTX 25 TG130 Serial Number: 2730218 RTX Series Features Structure: Fixed bed and moving column. Movements: Longitudinal table and transverse column with constant support. Rotary Table: Replaces the fixed rectangular version for continuous machining operations. Head: Bi-rotational head as standard for maximum flexibility. Type: Universal milling machine with fixed bed. Applications: Precision mechanical machining and complex profiles. Construction: Designed and assembled in Turin by Goglio Milling Systems. Travels Longitudinal Travel (X-axis) 2500 RCV UL1007 Transverse Travel (Y-axis) 1700 RCV UL1007 Vertical Travel (Z-axis) 1500 RCV UL0714 Rotary Table TG-130_1300x1800 Spindle Motor Power 24 kW Maximum Spindle Speed 3500 rpm Rapid Traverse Rate X-axis (CNC) 15,000 mm/min Rapid Traverse Rate Y-Z axis (CNC) 15,000 mm/min Bwedpfx Aeyn Rdujiwow Rapid Traverse Rate Axes (Manual) 6,000 mm/min Working Feed Rate (CNC) 10,000 mm/min Working Feed Rate (Manual) 2,500 mm/min Continuous Torque Motors X-Y Axis 36 Nm Continuous Torque Motors Z Axis 36 Nm Tool Holder Electro-hydraulic Spindle Taper ISO 50, Tool Drawbar BIR 200 Maximum Permissible Load on the Table 6,000 kg Bi-rotational Head Continuous for B-axis 0 - 360° Module Rotary Table Coupled to Hydraulic Rotating C-axis 0 - 360° continuous Machine Chiller Yes Tool Magazine 32 Positions Operating Temperature 10-40 degrees C Base Machine Mass 19000 Kg CNC HEIDENHAIN TNC 530 HSCI

Condition: used, Used Eiger model 5L SSE EXD stainless steel bead mill. Stainless steel chamber measures approximately 360mm x 200mm diameter. Unit is driven by 10hp, 420volt, 3/50 electric motor. Includes local controls. Bwedpez Ah Skjfx Aiwsw

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, IN EXCELLENT CONDITION - ORIGINAL PAINTWORK XYZ SMX 3500 CNC TURRET MILL PROTO TRAK CONTROL 3 AXIS CONTROL TABLE SIZE 1370 X 356 MM TRAVELS - X 770 / Y AXIS 500 / Z 500 MM 40 TAPER SPINDLE QUILL DIA 100 MM AIR DRAW BAR SPINDLE SPEED 40 - 5000 RPM TABLE GUARDS WEIGHT 2.4 TONS THERE IS ONE TOOL IN THE SPINDLE THAT WILL GO WITH Bwsdez Eh Egepfx Aiwjw

Condition: ready for operation (used), travel distance X-axis: 1,500 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 550 mm, spindle speed (max.): 2,066 rpm, spindle speed (min.): 30 rpm, Huron MU6 Universal Milling Machine Model: MU6 Table Size: 2000 x 460mm ‘X’ Longitudinal Travel: 1500mm ‘Y’ Cross Travel: 700mm ‘Z’ Vertical Travel: 550mm Spindle Speeds: 30 – 2066 RPM Bodoz S Nkrjpfx Aiwoww Spindle Taper: 50 INT Machine with: Digital Readout

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, machine/vehicle number: 06651, travel distance X-axis: 6,800 mm, travel distance Y-axis: 3,700 mm, travel distance Z-axis: 1,500 mm, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 10 m/min, total length: 15,000 mm, total width: 7,500 mm, spindle speed (max.): 4,000 rpm, total height: 7,000 mm, table height: 1,100 mm, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 10 m/min, distance between stands: 3,300 mm, type of input current: three-phase, table load: 50,000 kg, rotational speed (max.): 4,000 rpm, distance table center to spindle nose: 2,110 mm, overall weight: 110,000 kg, spindle motor power: 50,000 W, control cabinet length: 7,000 mm, control cabinet height: 2,000 mm, control cabinet width: 600 mm, Equipment: rotational speed infinitely variable, MODEL: Portal Type AGE: 1992 S/N #: 06651 CATEGORY: Mills, Planer Type, CNC CAPACITY: X-Axis Travel: 6800 mm Y-Axis Head Travel: 3700 mm Z-Axis Ram Stroke: 1500 mm, fixed crossrail Ram Cross Section: 500 mm x 500 mm Distance Between Columns: 3300 mm Distance Table To Ram Face: 2110 mm, vertical passage 2000 mm Table Size: 6000 x 2500 mm Spindle (Quill) Diameter: 250 mm Spindle Taper: ISO #50 Spindle Speeds: 0-4000 RPM Spindle Motor: 50 KW EQUIPPED WITH: FIDIA System C20 CNC Control, new in 2002 CNC biaxial continous milling head Universal Milling Head with Auto Indexing Right Angle Head with Auto Indexing Straight Milling Head Wagons for Head Change and Tool Pick-up Change Hydrostatic Bearings Coolant System Full Length Chip Conveyors both side Way Covers Bwsdpfx Aijyahv Sjwow Rapid movements: Z-10.000 mm/min, X and Y-15.000 mm/min Table load: max 50.000 kg Weight of the machine: 110.000 kg Outside dimensions: 15.000 x 7.500 x 7050 mm Machine has been tested before dismantling and is fully operational, all mechanical components in excellent condition, electrics new in 2018. Machine available from stock. The price is now SPECIAL FROM STOCK. Once we will reassemble the machine, price will grow significantly. We can assist you to assemble and run up the machine.

Condition: used, Year of construction: 1990, TECHNICAL DETAILS Travel ranges X-axis travel: 500 mm Y-axis travel: 400 mm Z-axis travel: 400 mm Bedpfx Aioz S Namjweww Work table Table size: 680 × 380 mm Control system CNC control: Philips 432 Feed rate and rapid traverse Feed rate range: 1–3,000 mm/min Rapid traverse: 6 m/min Spindle and tool holder Tool holder: ISO 40 Speed range: 20–3,150 rpm Main drive: 5 kW Milling head Swivel range of milling head: ±90° Performance data Total power requirement: 12 kW Machine weight: approx. 1.2 t Dimensions Space requirement: approx. 2.5 × 2 × 2 m EQUIPMENT Swiveling milling head Philips 432 CNC control

Condition: ready for operation (used), Year of construction: 1965, operating hours: 5,128 h, functionality: fully functional, machine/vehicle number: 01123, travel distance X-axis: 600 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 600 mm, table length: 1,000 mm, table width: 800 mm, No minimum price – guaranteed sale to the highest bidder! Submitting a bid obligates you to collect the item on time between December 1, 2026, and December 10, 2026! TECHNICAL DETAILS Speed range: 12.5–1,000 rpm Table dimensions: 1,000 × 800 mm Number of T-slots: 7 Travel range X-axis: approx. 600 mm Travel range Y-axis: approx. 500 mm Travel range Z-axis: approx. 600 mm MACHINE DETAILS Operating voltage: 380 V Frequency: 50 Hz Rated current: 14 A Dimensions & Weight Dimensions (L x W x H): 4,000 x 2,000 x 2,300 mm Machine weight: 6,000 kg Bjdpfxs Ahn Arj Aiwjww Operating hours (read): 5,128 h EQUIPMENT Tool holders WALTER dividing head Four-jaw chuck, diameter 200 mm Various clamping devices External reference: Frankenthal - Lot 391

Condition: used, Year of construction: 2018, functionality: fully functional, input voltage: 2,500 V, input frequency: 50 Hz, nominal power (apparent): 32 kVA, We offer a selection of brand new Schneider Electric components, all in original factory packaging. This equipment is ideal for industrial electrical installations, switchboards, and power distribution systems. Switch Disconnectors (3P, 4P) Schneider MTZ2 25HF Schneider MTZ2 25HA Schneider MTZ2 16HA Compact Breaker: Schneider NS630b – 1600 A Compact 16 pc Schneider EF593816 – Front power connections NEW! Molded Case Circuit Breakers (MCCB): Schneider NW25H2 – 2500 A – 4P Bedewrzl Sjpfx Aiweww Availability: In stock, ready for dispatch Photos, technical datasheets and prices available upon request

Condition: used, Year of construction: 1993, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel ranges X-axis: 500 mm Y-axis: 400 mm Z-axis: 420 mm Bedpfsz S Nc Iox Aiwoww Work table Table size: 800 × 400 mm Feed rate and rapid traverse Feed rate range: 1–3,000 mm/min Rapid traverse: 0.083–5 m/min Spindle and tool holder Tool holder: ISO 40 Speed range: 20–4,000 rpm Main drive: 5 kW Control system CNC control: Heidenhain TNC 355 Performance data Total power consumption: 10.9 kW Machine weight: approx. 2,300 kg Dimensions Space requirement: approx. 2.5 × 2.5 × 2.0 m EQUIPMENT Splash guard cabin Heidenhain TNC 355 CNC control

Condition: excellent (used), Year of construction: 2023, 400mm swing, 220mm max diameter, 490mm between Centres, Siemens 828 Control, 65mm bar capacity, 12 station VDI30 turret, 17kW Spindle Motor, Bsdpfsz Srv Djx Aiweww Spindle Speed 4000rpm, 0.001 degree C axis, +/- 35mm Y axis, low volt light, coolant, Tool setter, Tailstock, swarf conveyor

Condition: excellent (used), For sale: MC9050B industrial round wood rod milling machine, manufactured in 2018, designed for producing round wooden poles and cylindrical wooden components such as tool handles, broom handles, furniture parts, and similar products. Specifications: • Model: MC9050B • Year of manufacture: 2018 • Power supply: 380V (Three-phase) • Working diameter: 15–50 mm • Minimum workpiece length: 600 mm • Main motor: 3 kW • Approximate weight: 350 kg Condition: • Excellent working condition. • Complete machine, ready for immediate use. • Inspection and testing are welcome. Bwsdezmt U Espfx Aiwjw

Condition: excellent (used), Year of construction: 2019, Swing over bed 900mm, Swing over saddle 690 mm, Maximum turning diameter 650mm, maximum turning length 3070mm, bar capacity 165.5mm, Spindle speed 1,500rpm, milling speed 4,000rpm, spindle power 45/37KW, 12 station turret, Bodez Ehvfepfx Aiwsww Fanuc I Plus control. 3 jaw chuck, tool setter, Hydraulic steady, swarf conveyor,

Condition: used, Year of construction: 2000, No minimum price – guaranteed sale to the highest bidder! Bwodpez S Nizofx Aiwow TECHNICAL DETAILS Travel distances X-axis travel: 1,200 mm Y-axis travel: 620 mm Z-axis travel: 520 mm Control system CNC control: Heidenhain TNC 410 Work table Table size: 1,550 × 600 mm Design: continuous table for longer workpieces Tandem operation: possible with a dividing screen Feed rate and rapid traverse Feed rate range: 1–30,000 mm/min Rapid traverse: 45 m/min Spindle and tool holder Spindle speed: 40–8,000 rpm Tool holder: ISO 40 Tool changer Tool changer: 30 positions Performance data Total power consumption: 20 kVA Machine weight: approx. 9 tons Dimensions Space requirement: approx. 4.2 × 2.3 × 2.7 m EQUIPMENT Continuous work table Dividing screen for tandem operation 3 additional clamping tables Tool changer with 30 positions Heidenhain TNC 410 CNC control

Condition: like new (used), Year of construction: 2023, Maximum turning diameter 220mm, distance between centres 800mm, Bjdpfxsz D Eups Aiwoww swing over bed 240mm, spindle speed 4,000rpm, milling speed 12,000rpm, sub-spindle speed 4,000rpm, main spindle bar capacity 66mm, sub spindle bar capacity 66mm, 2 X 12 station turrets, spindle power 35Kw, Y axis + /- 45mm, swarf conveyor, coolant., Fanuc 31i.

Condition: excellent (used), Year of construction: 1995, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,050 mm, Equipment: documentation/manual, Asquith Butler 3000 Bed Type Milling Machine, Siemens Sinumeric 840C CNC Control, Auto Indexing Head, (Live 5 Axis orthogonal head) ,3.1 x 1.2m Table, Travels x-3m,y-1000,z-1050. New 1995. Bwjdpfxew A Aiao Aiwjw

Condition: used, Year of construction: 1990, TECHNICAL DETAILS Travel ranges X-axis: 800 mm Y-axis: 550 mm Z-axis: 500 mm Work table Table size: 1,000 × 630 mm Feed rate and rapid traverse Feed rate range: 0–10,000 mm/min Rapid traverse: 10 m/min Spindle and tool holder Tool holder: ISO 40 Speed range: 20–4,000 rpm Main drive: 10 kW Control system CNC control: Dialog 11 Performance data Total power consumption: 15 kW Machine weight: approx. 6,500 kg Dimensions Space requirement: approx. 3.0 × 2.5 × 2.0 m Overhaul and modernization Overhaul: 2010 by FPS Modernization: 2010 by FPS EQUIPMENT Bsdpfx Aijz S I D Djweww Splash guard cabin Tool changer with 30 positions Dialog 11 control

Condition: excellent (used), Nakamura-Tome Super NTJ 9-Axis Turn/Mill Centre Year: 2003/2004 Serial Number: B150509 Control: Fanuc 18i-TB Main Spindle Maximum bar capacity: 65 mm Maximum turning diameter: 190 mm Spindle nose: A2-6 Spindle power: 15 kW Spindle speed: 4,500 rpm C-axis indexing: 0.001° Sub-Spindle Maximum bar capacity: 51 mm Spindle nose: A2-5 Spindle power: 11 kW Spindle speed: 5,000 rpm C-axis indexing: 0.001° Stroke: 760 mm Upper Turret Number of tool stations: 24 Bodpfx As Aaz Nzoiwoww Motorised tool stations: 24 X-axis travel: 345 mm Y-axis travel: ±45 mm Z-axis travel: 1,240 mm B-axis travel: ±91° Live tooling speed: 6,000 rpm Live tooling power: 5.5 kW Lower Turret Number of tool stations: 24 Motorised tool stations: 12 X-axis travel: 167.5 mm Z-axis travel: 685 mm Live tooling speed: 6,000 rpm Live tooling power: 5.5 kW
